Lighting System: Specifications Chevrolet Captiva I facelift

Exterior Lights 12 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
CHMSL to Rear Liftgate Spoiler Screw2.5 N.m22 lb in
Dome Lamp Screw2 N.m18 lb in
Fog Lamp Bracket Nut3 N.m27 lb in
Fog Lamp Bracket to Fascia Screws1.5 N.m13 lb in
Front Fog Lamp Opening Cover Screw1.5 N.m13 lb in
Headlamp Assembly Bolts-Base7.5 N.m66 lb in
Headlamp Assembly Bolts-Redline7.5 N.m66 lb in
Headlamp Housing Bracket Assembly Screw2.5 N.m22 lb in
Key Hole Lamp Retaining Screw2.5 N.m22 lb in
License Plate Bulb Assembly Screws.9 N.m8 lb in
Rear Bumper Reflector Nut.5 N.m4 lb in
Tail Lamp Screws2.5 N.m22 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlamp Controls
Scheme 1: Headlamp Controls

Scheme 2

Scheme 2: Headlamps and Daytime Running Lights
Scheme 2: Headlamps and Daytime Running Lights

Scheme 3

Scheme 3: Fog Lights (T37 or T96)
Scheme 3: Fog Lights (T37 or T96)

Scheme 4

Scheme 4: Park, License, and Tail Lamps
Scheme 4: Park, License, and Tail Lamps

Scheme 5

Scheme 5: Marker Lamps
Scheme 5: Marker Lamps

Scheme 6

Scheme 6: Turn Signal/Hazard Lamps
Scheme 6: Turn Signal/Hazard Lamps

Scheme 7

Scheme 7: Stop Lamps
Scheme 7: Stop Lamps

Scheme 8

Scheme 8: Backup Lamps
Scheme 8: Backup Lamps

Scheme 9

Scheme 9: Dome/Reading, Ignition Switch, and Rear Compartment Courtesy Lamps
Scheme 9: Dome/Reading, Ignition Switch, and Rear Compartment Courtesy Lamps

Scheme 10

Scheme 10: Courtesy/Reading and Sunshade Lamps
Scheme 10: Courtesy/Reading and Sunshade Lamps

Scheme 11

Scheme 11: Dimming Control, Garage Door Opener, and Shift Lever Position Indicator
Scheme 11: Dimming Control, Garage Door Opener, and Shift Lever Position Indicator

Scheme 12

Scheme 12: Center Console, Door, and Instrument Panel Dimming
Scheme 12: Center Console, Door, and Instrument Panel Dimming
