Arrows and Symbols

This service manual uses various symbols in order to describe different service operations.

Scheme 2

Scheme 2: Arrows and Symbols
CalloutComponent Name
1Front of Vehicle
2View Detail
2View Detail
3Ambient Air Mixed with Another Gas or Indicate Temperature Change
4Motion or Direction
5View Angle
6Dimension (1:2)
7Ambient/Clean Air Flow or Cool Air Flow
8Lubrication Point- Oil or Fluid
9Task Related
10Sectioning (1:3)
11Gas Other Than Ambient Air or Hot Air Flow
12Lubrication Point- Grease or Jelly
13Multidirectional Arrow

Acronyms and Units

AcronymMeaningDefinition
2WDTwo-Wheel DriveIndicates that a vehicle has 2 driven wheels OR that a 4WD vehicle uses only 2 wheels for propulsion. So it can be the description of a vehicle configuration OR the operational mode of the drivetrain.
4WDFour-Wheel DriveFour-wheeled vehicle with a drivetrain that allows all four wheels to receive power from the engine simultaneously which provides better control on various surfaces. Can be used to describe the configuration of the vehicle OR as the operational mode of the drivetrain. 4WD vehicles usually can turn 2 wheels off to be in a 2WD mode. See also AWD.
A/CAir ConditioningThe cooling and dehumidification of indoor air for thermal comfort.
A/DAnalog to DigitalUsed in context of converting electrical analog signals to digital signals.
ABSAntilock Braking SystemSystem on motor vehicles which prevents the wheels from locking while braking which helps the driver maintain control in heavy braking conditions.
ACAlternating CurrentAn electrical current whose magnitude and direction vary cyclically.
AMAmplitude ModulationMethod of impressing data onto an alternating-current (AC) carrier waveform.
APPAccelerator Pedal PositionA pedal that controls the throttle valve.
AWDAll-Wheel DriveAll-wheel-drive systems are designed to function on all types of surfaces, both on- and off-road and most of them cannot be switched off. This can also be called full-time four wheel drive. See also 4WD.
AWGAmerican Wire GaugeAmerican wire gauge is a standardized wire gauge system used since 1857 predominantly in the United States for the diameters of round, solid, nonferrous, electrically conducting wire. E.g. a wire of AWG10 has a diameter of 2.588mm, AWG20 corresponds to a diameter of 0.812mm.
B+Battery Positive VoltageThe electrical potential on the positive terminal of the battery.
BAROBarometric PressureAtmospheric pressure as measured by a barometer.
BCMBody Control ModuleThis module supplies vehicle occupants with visual and audible information and controls various vehicle functions
BECMBattery Energy Control ModuleControl module used to regulate the battery voltage.
BPPBrake Pedal PositionPosition of the foot pedal that moves a piston in the master brake cylinder.
CANController Area NetworkSerial data connection between control modules by Bosch
CCMChassis Control ModuleThe module that controls various vehicle functions on the Chassis, like Engine/Trans Mount, Active Grille Air Shutter, Load Leveling, etc
CDCompact DiscA small optical disk on which data such as music, text orgraphic images is digitally encoded.
CNGCompressed Natural GasThis a substitute for gasoline or diesel fuel. It is made by compressing natural gas (which is mainly composed by methane (CH4), in a percentage range of 70% to 98%)
COCarbon MonoxideThis is a product of the incomplete combustion of carbon-containing compounds, at room temperature this is a gas. It consists of one carbon atom covalently bonded to one oxygen atom.
CO2Carbon DioxideChemical compound composed of two oxygen atoms covalently bonded to a single carbon atom.
CPAConnector Position AssurancePart of an electrical connector that prevents the connector from moving out of its socket. Usually needs to be pressed to unlock the connector when disconnecting it.
CPPClutch Pedal PositionA lever operated with the foot that controls the coupling that connects or disconnects driving and driven parts of a driving mechanism.
CVConstant VelocityUsed in conjunction with CV joints, which connect two shafts at an angle while both shafts always have the same rotational speed without variations.
CVTContinuously Variable TransmissionA transmission in which the ratio of the rotational speeds of two shafts, as the input shaft and output shaft of a vehicle or other machine, can be varied continuously within a given range, providing an infinite number of possible ratios which improves fuel economy.
DDriveD on the transmission gear selector lever.
DABDigital Audio BroadcastTechnology for broadcasting of audio using digital radio (carries information via digital signal) transmission.
DCDirect CurrentContinuous current, constant flow of electric charge.
DLCData Link ConnectorThis is an electronic connector typically located underneath the driver's side dashboard, just above the pedals. The connector has 16 pins.
DMMDigital MultimeterElectronic measuring instrument that combines several functions in one unit. The most basic instruments include an ammeter, voltmeter and ohmmeter.
DOHCDual Overhead CamshaftDual overhead camshafts (DOHC) are higher performance engines, they produce more power and can run at higher speeds because they allow an engine to have four valves per cylinder. Each camshaft operates two of the valves, one camshaft handles the intake valves and one handles the exhaust valves
DPFDiesel Particulate FilterDevice designed to remove diesel particulate matter or soot from the exhaust gas of a diesel engine.
DRLDaytime Running LampsWhite lights mounted on the front of an automobile that automatically switch on when the key is turned and are intended for daytime use, to increase the visibility of the automobile.
DSCCDistance Sensing Cruise ControlA type of cruise control that automatically maintains the distance between vehicles.
DSPDigital Signal ProcessorA specialized microprocessor designed specifically for digital signal processing, generally in real-time computing.
DTCDiagnostic Trouble CodeAn electronic signal stored in an automotive computer, indicating the presence of a fault detected by that computer.
DVDDVDA popular optical disc storage media format the size of a CD. Used mainly for movies but also for data. DVD has no spelled out version (officially it does not mean Digital Video Disc or Digital Versatile Disc, it just means DVD).
EBCMElectronic Brake Control ModuleThis module contains a microprocessor and software for antilock braking system operation.
ECMEngine Control ModuleThis electronic module works with a vehicle's sensors and engine control devices to insure that the engine operates at maximum efficiency and performance. It performs three vital functions. Receives electronic signals from engine sensors. Analyzes the data and makes an engine performance decision (based on the pre-set parameters within the unit). Sends an "output command" to an actuator that adjusts engine performance.
ECTEngine Coolant TemperatureA measure of how hot or cold the fluid which flows through the engine in order to prevent its overheating, transferring the heat produced by the device to other devices that utilize or dissipate it.
EEPROMElectrically Erasable Programmable Read-Only MemoryA non-volatile storage chip used in computers and other devices to store small amounts of volatile data, e.g. calibration tables or device configuration.
EGRExhaust Gas RecirculationIs an NOx (nitrogen oxide and nitrogen dioxide) reduction technique used in most gasoline and diesel engines. EGR works by recirculating a portion of an engine's exhaust gas back to the engine cylinders.
EMIElectromagnetic InterferenceElectromagnetic interference (also called radio frequency interference) is a disturbance that affects an electrical circuit due to either electromagnetic conduction or electromagnetic radiation emitted from an external source.
ESDElectrostatic DischargeThe sudden and momentary electric current that flows between two objects at different electrical potentials.
EVElectric VehicleA category of vehicles that only have an electric drive system.
EVAPEvaporative EmissionA system that controls the fuel fumes in the fuel tank.
FMFrequency ModulationIn telecommunication this is a way to convey information over a carrier wave by varying its frequency.
FWDFront-Wheel DriveA form of engine/transmission layout used in motor vehicles, where the engine drives the front wheels only.
GMLANGeneral Motors Local Area NetworkA local-area network is a computer network covering a small geographic area, like a home or vehicle. This specific type of LAN connects several controllers inside the vehicle and was developed by General Motors.
GPSGlobal Positioning SystemSatellite-based navigation system made up of a network of 24 satellites placed into orbit by the U.S. Department of Defense.
GSMGlobal System for Mobile CommunicationsGlobally accepted standard for digital cellular communication.
GVWGross Vehicle WeightMaximum total weight of a road vehicle or trailer that is loaded, including the weight of the vehicle itself plus fuel, passengers, cargo and trailer tongue weight.
HDHeavy DutyRobust design to accommodate large work loads.
HIDHigh Intensity DischargeA type of light that produces a bright light by using gas filled bulbs. (gas is usually mercury, metal halide and high-pressure sodium) Uses very little battery power and is a very "cool" light.
HO2SHeated Oxygen SensorHeated oxygen sensors have an internal heater circuit that brings the sensor up to operating temperature more quickly than an unheated sensor. An oxygen sensor must be hot (about 600-650°F) before it will generate a voltage signal. The hot exhaust from the engine will provide enough heat to bring an O2 sensor up to operating temperature.
HVACHeating Ventilation Air ConditioningThis system is sometimes referred to as climate control. Ventilation air ducts installed throughout a vehicle that supply conditioned air to a room through rectangular or round outlet vents.
I 2 CInter-Integrated CircuitSerial data connection between Integrated Circuits (microchips) inside a control module invented by Phillips
IATIntake Air TemperatureTemperature of the air entering intake air flow system of the engine.
ICEInternal Combustion EngineAn engine in which the combustion of fuel and an oxidizer (typically air) occurs in a confined space called a combustion chamber.
IDIdentificationNumber or Code that identifies a component or control module. Can be written on the part or be transmitted on a bus or via radio.
ISPInternet Service ProviderA company that furnishes corporations and individual consumers with various services, mainly access to the Internet.
ISSInput Shaft SpeedRotational speed of the input shaft of a transmission.
LANLocal Area NetworkStandard network connection PC's.
LCDLiquid Crystal DisplayA thin, flat display device made up of any number of color or monochrome pixels arrayed in front of a light source or reflector.
LEDLight Emitting DiodeSmall light bulbs that fit easily into an electrical circuit they do not have a filament that will burn out and they do not get especially hot. They are illuminated solely by the movement of electrons in a semiconductor material.
LINLocal Interconnect NetworkComputer networking bus system used within automotive network architectures. Similar to CAN, but cheaper and less powerful.
LPGLiquefied Petroleum GasA mixture of mainly propane and butane, produced commercially and stored under pressure to keep it in a liquid state.
MAFMass Air FlowThe amount of air drawn into the engine
MAPManifold Absolute PressurePressure in the engine intake system after the throttle valve referenced to a perfect vacuum.
MDIMultiple Diagnostics InterfaceA device used by GM dealers that enables a PC to communicate with the control modules in a vehicle.
MILMalfunction Indicator LampAn indicator of the internal status of a car engine.
MOSTMedia Oriented Systems TransportSerial communication bus to transmit audio and video information.
NNeutralA state of the transmission in which it is not engaged.
NiMHNickel Metal HydrideA type of rechargeable battery that uses a hydrogen absorbing alloy for the negative electrode.
NOxNitrogen OxidesRefers to any of the following oxygen compounds of nitrogen or a mixture of them. Nitric Oxide, Nitrogen dioxide, Nitrous Oxide, Dinitrogen trioxide, Dinitrogen tetroxide, Dinitrogen pentoxide.
O2OxygenA colorless, odorless, tasteless, gaseous chemical element with the chemical symbol O and atomic number 8.
O2SOxygen SensorAn electronic device that measures the proportion of oxygen (O2) in the gas or liquid being analyzed.
OBDOn-Board DiagnosticA generic term referring to a vehicle's self-diagnostic and reporting capability.
OEMOriginal Equipment ManufacturerA producer that provides a product to its customers, who proceed to modify or bundle it before distributing it to their customers.
OSSOutput Shaft SpeedRotational speed of the output shaft of a transmission.
PParkA state in which the transmission is set so one can leave the vehicle.
PCBPrinted Circuit BoardA thin plate on which chips and other electronic components are placed.
PCMPowertrain Control ModuleA control module that features the functions of both, the engine and the transmission control module.
PCMCIAPersonal Computer Memory Card Industry AssociationAn international standards body and trade association with over 100 member companies that was founded in 1989 to establish standards for Integrated Circuit cards and to promote interchangeability among mobile computers where ruggedness, low power and small size were critical.
PINPersonal Identification NumberA secret numeric password shared between a user and a system that can be used to authenticate the user to the system.
PPEPersonal Protective EquipmentProtective clothing, helmets, goggles orother garment designed to protect the wearer's body from injury.
PRNDLPark, Reverse, Neutral, Drive, LowPark, Reverse, Neutral, Drive, Low (automatic transmission positions).
PTCPositive Temperature CoefficientRefers to materials that experience an increase in electrical resistance when their temperature is raised.
PTOPower Take-OffA splined driveshaft, usually on a tractor or truck that can be used to provide power to an attachment or separate machine. This mechanism allows implements to draw energy from the tractor's engine.
PVCPolyvinyl ChlorideA thermoplastic copolymer.
PWMPulse Width ModulationSquare shaped type of signal that carries the information in the ratio between on and off times.
RReverseRearward: directed or moving toward the rear
RAMRandom Access MemoryA type of computer data storage. It today takes the form of integrated circuits that allow the stored data to be accessed in any order.
RCTRadiator Coolant TemperatureThis is the heat intensity of the radiator coolant measured in degrees. The radiator is a part of the cooling system that removes the engine heat. Coolant is a mixture of water and antifreeze (ethylene glycol) which lowers the freezing point of the water in the coolant system, this fluid also picks up heat from the engine and transfers it to the air.
RDSRadio Data SystemA standard from the European Broadcasting Union for sending small amounts of digital information using conventional FM radio broadcasts.
RFRadio FrequencyA frequency or rate of oscillation within the range of about 3 Hz and 300 GHz. This range corresponds to frequency of alternating current electrical signals used to produce and detect radio waves.
ROMRead-Only MemoryA class of storage media used in computers and other electronic devices. Data stored in ROM cannot be modified.
RPORegular Production OptionA three digit/letter code given to parts, assemblies and systems originally installed on the vehicle. These RPO codes designate options and are assigned by General Motors.
RSARear Seat AudioAn auxiliary set of controls that operate the main audio system from the rear seat. Rear passengers can also operate a different media source than the front passengers.
RWDRear-Wheel DriveA common engine/transmission layout in which the engine is in the front of the vehicle, but the front mid-engine, rear mid-engine and rear engine layouts are also used.
SCVSpeed Controlled VolumeThe volume control is set for a desired sound level in the vehicle as the vehicle increases its speed, the sound level is adjusted.
SDMSensing and Diagnostic ModuleThe name given to air bag modules used in General Motors vehicles.
SIMSubscriber Identity ModulePart of a removable smart card Integrated Circuit Card. This is used for mobile cellular telephone devices such as mobile computers and mobile phones. SIM cards securely store the service-subscriber key used to identify a subscriber. The SIM card allows users to change phones by simply removing the SIM card from one mobile phone and inserting it into another mobile phone or broadband telephony device.
SIRSupplemental Inflatable RestraintTechnical term for the air bag. Air bag is a stretchable membrane, which inflates during an automobile accident to provide cushioning to the passenger's head and torso to prevent injury to the passengers.
SPISerial Peripheral InterfaceThis is an interface that enables the serial (one bit at a time) exchange of data between two devices. An SPI operates in full duplex mode. This means that data can be transferred in both directions at the same time. It is a standard bus technology like CAN or I2C.
SPSService Programming SystemSystem that enables repair facilities to update the software in control modules.
SUVSport Utility VehicleA passenger vehicle which combines the towing capacity of a pickup truck with the passenger-carrying space of a minivan.
SVSService Vehicle SoonIndicator lamp or symbol for a malfunction related to a vehicle component or system.
TATraffic AnnouncementMessage spoken on radio regarding the movement of vehicles or pedestrians through an area or along a route. The buttons on radios that enable this announcements are also often labeled TA.
TACThrottle Actuator ControlA motor which moves the engine throttle plate or valve, controlled by the engine control module. A throttle plate limits the amount of air entering a internal combustion gasoline engine.
TAPTransmission Adaptive PressureThe transmission control module learns each component's characteristics and adjusts fluid pressure accordingly.
TCCTorque Converter ClutchResides in a torque converter to connect an engine to an automatic transmission. The clutch is applied when conditions are correct to achieve a 1:1 ratio of engine crankshaft to transmission input shaft.
TCMTransmission Control ModuleA module that controls electronic automatic transmissions. It uses sensors from the vehicle as well as data provided by the Engine Control Module to calculate how and when to change gears in the vehicle for optimum performance, fuel economy and shift quality.
TDCTop Dead CenterThe piston is in its highest position relative to the combustion chamber.
TISTechline Information SystemThe PC-based global dealership diagnostic software that provides the technician the ability to reference the most recent service information via the service department's computer.
TPATerminal Position AssuranceAn additional locking mechanism inside an electric connector that holds the pins in place.
TVTelevisionA telecommunication system for broadcasting and receiving moving pictures and sound over a distance.
USBUniversal Serial BusA type of communication bus connection between a computer and a peripheral device.
VCIVehicle Communications InterfaceA diagnostic tool that communicates to modules of multiple communication protocols in a vehicle by converting vehicle serial data into PC serial data communication.
VINVehicle Identification NumberUsed by manufacturers to uniquely identify motor vehicles using 17 characters.
VSCMVehicle Stability Control ModuleThis module uses information from several sensors to detect a loss of vehicle traction, then works with the antilock brake system to apply individual brakes to help keep the vehicle on its intended path.
VSSVehicle Speed SensorSends data regarding how fast the car is traveling at the moment of driving. It is designed to be able to record the rate at which the vehicle's crankshaft is spinning.
WOTWide Open ThrottleWhen the throttle blade or valve is at its maximum open position, allowing maximum air to enter an internal combustion gasoline engine.
WLANWireless Local Area NetworkStandard to transmit digital data via radio frequency.
XMXM (Satellite Radio)XM Satellite Radio Holdings (XM) is one of two satellite radio services in the United States and Canada. XM provides pay-for-service radio, analogous to cable television. Its service includes 73 different music channels, 39 news, sports, talk and entertainment channels, 21 regional traffic and weather channels and 23 play-by-play sports channels (2008).
XMLExtensible Markup LanguageA markup language that defines a set of rules for encoding documents in a format that is both human-readable and machine-readable.

Acronyms

UnitMeaningDefinition
M 2Square MeterArea
AAmpereElectrical
AhAmpere HourElectrical
CCoulombElectrical
DBmDecibel MeterElectrical
DBmVDecibel MillivoltElectrical
MV/DIVMillivolts per DivisionElectrical
MV/sMillivolts per SecondElectrical
OhmsOhmElectrical
VVoltElectrical
V/DIVVolts per DivisionElectrical
V/msVolts per MillisecondElectrical
WWattElectrical
Mm 3 /strokeCubic Millimeters per StrokeFlow
Gal/hGallons per HourFlow
G/sGrams per secondFlow
G/strokeGrams per StrokeFlow
Kg/100kmKilograms per 100 KilometerFlow
Kg/hKilograms per HourFlow
Km/LKilometer/literFlow
L/100kmLiters per 100 KilometersFlow
L/hLiters per HourFlow
L/minLiters per MinuteFlow
MPGMiles per GallonFlow
Mg/sMilligrams per SecondFlow
Mg/strokeMilligrams per strokeFlow
FtFeetLength
InInchLength
MMeterLength
MiMileLength
BarBarMechanical
Bar/minBars per MinuteMechanical
In. H2OInches of WaterMechanical
In. H2O/sInches of Water per secondMechanical
KPa/sKilopascals per SecondMechanical
NNewtonMechanical
Newton MeterMechanical
PaPascalMechanical
Pa/sPascals per SecondMechanical
Lb ftPound FootMechanical
PSIPound-Force per Square InchMechanical
CountsCountsMisc.
CyclesCyclesMisc.
DBDecibelMisc.
°DegreeMisc.
°CDegree CentigradeMisc.
°CADegree Crankshaft AngleMisc.
°FDegree FahrenheitMisc.
°/sDegree per SecondMisc.
HzHertzMisc.
Kbit/sKilobit per secondMisc.
LxLuxMisc.
PpmParts per MillionMisc.
%PercentMisc.
%/minPercents per MinuteMisc.
%/secPercents per SecondMisc.
PulsesPulsesMisc.
1RatioMisc.
RPMRevolutions per MinuteMisc.
StepsStepsMisc.
W/m 2Watts per Square MeterMisc.
GG (Acceleration)Movement
Km/hKilometers per HourMovement
M/sMeters per SecondMovement
M/s 3Meters per Second CubedMovement
M/s 2Meters per Second SquaredMovement
MPHMiles per HourMovement
Mm/sMillimeters per SecondMovement
DDayTime
HHourTime
Hh:mm:ssHour:Minute:SecondTime
Ms/DIVMilliseconds per DivisionTime
MinMinuteTime
SSecondTime
S/DIVSeconds per DivisionTime
Yy-mm-ddYear-Month-Day (2 digits)Time
Yyyy-mm-ddYear-Month-Day (4 digits, preferred)Time
M 3Cubic MeterVolume
GalGallonVolume
LLiterVolume
MLMillilitersVolume
US galUS GallonVolume
US ptUS PintVolume
US qtUS QuartVolume
KgKilogramWeight

Units

Customer Concern Verification Sheets

The GM Customer Concern Verification Sheets have been designed to improve communications between the service customer and the technician. The more clearly the technician understands the concern and its symptoms, the more likely the concern will be fixed right the first time.

The GM-wide Customer Concern Verification Sheets are available in GM GlobalConnect. The Customer Concern Verification Sheets may be printed and reproduced locally.

Dealers

All U.S. GM Dealers participating in the Center of Learning / GM Service Technical College (STC) Programs can enroll through the Center of Learning website at https://www.centerlearning.com. Within the website, there are individual training paths that are designed to assist in planning the training needs for each individual and their job role. Dealers who have questions about Center of Learning Training should contact the Center of Learning help desk at 1-888-748-2687. The help desk is available Monday through Friday, 8:00 am - 9:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.

Fleets

GM Fleet customers with GM Warranty In-Shop agreements are able to participate in service technical training through the Center of Learning/GM Service Technical College (STC).

Assistance for GM fleet registered customers using GM STC training is provided by the Center of Learning help desk at 1-888-748-2687. The help desk is available Monday through Friday, 8:00 am-9:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.

Most GM STC course materials have associated charges.

To purchase authentic GM STC Training Materials, contact the GM Training Materials Headquarters at 1-800-393-4831.

Non-GM Dealer Technicians

Technician training for non-GM dealers is available through ACDelco. This training is for ACDelco PSC and Fleet program members employed in the automotive or truck service industry.

ACDelco courses are available at approved GM STC Training Centers. Availability and schedules can be obtained by calling 1-800-825-5886 (prompt 1) or contact us via the web at www.acdelcotechconnect.com and select the Training tab. Seminars are also offered through the ACDelco Warehouse Distribution channel. Contact your Local ACDelco representative or distributor directly for more information.

Scheme 3

Scheme 3: Vehicle, Engine and Transmission ID and VIN Location, Derivative and Usage
PositionDefinitionCharacterDescription
The VIN plate (1) is the legal identifier of the vehicle. The VIN plate is located on the upper left corner of the instrument panel (I/P) and can be seen through the windshield from the outside of the vehicle.
1Country of Origin3Mexico
2ManufacturerGGeneral Motors
3MakeNChevrolet MPV
4GVWR/Brake System/Body StyleA4, 001-5000/Hydraulic/Four Door Cab - Utility
F5, 001-6000/Hydraulic/Four Door Cab - Utility
5-6Line, Chassis Type and SeriesL/1Captiva Sport 1LS FWD
L/2Captiva Sport 2LS FWD
L/3Captiva Sport 1LT FWD
L/4Captiva Sport LTZ FWD
L/7Captiva Export Non US, Non Canada
7Restraint SystemEActive Manual Belts, Airbags - Driver and Passenger Front (1st row), Front Seat Side (1st row), Roof Side (All seating rows)
8Engine TypeKRPO LEA Engine Flexible Fuel, 4 Cylinder, 2.4L, SIDI, DOHC, Aluminum, HO
5RPO LFW Engine Gas, 6 Cylinder, 3.0L, SIDI, DOHC, VVT, E85 MAX, Aluminum
9Check DigitCheck Digit
10Model YearE2014
11Plant LocationSRamos Arizpe, Mexico
12-17Plant Sequence Number1000001

Vehicle Identification Number (VIN) System

PositionDefinitionCharacterDescription
All engines and transmissions are stamped or laser etched with a partial VIN. This table identifies the different VIN derivative characters and their respective positions.
NChevrolet
2Model YearE2014
3Plant LocationSRamos Arizpe, Mexico
4-9Plant Sequence Number1000001
A VIN derivative can be used to determine if a vehicle contains the original engine or transmission by matching the VIN derivative positions to their accompanying positions in the complete VIN.

VIN Derivative Characters

2.4L RPO LEA Engine ID and VIN Derivative Location

Refer to Engine Identification (LAF, LEA or LUK) .

3.0L RPO LFW Engine ID and VIN Derivative Location

Refer to Engine Identification .

4T40/45/50 Transmission ID and VIN Derivative Location

Refer to Transmission Identification Information .

Scheme 4

Scheme 4: Vehicle Certification, Tire Placard, Anti-Theft and Service Parts ID Label
CalloutDescription
Vehicle Certification Label The vehicle certification label is located on the driver door and displays the following assessments: Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR), front and rear The gross vehicle weight (GVW) is the weight of the vehicle and everything it carries. The gross vehicle weight must not exceed the Gross Vehicle Weight Rating. Include the following items when figuring the GVW: The base vehicle weight (factory weight) The weight of all vehicles accessories The weight of the driver and the passengers The weight of the cargo
1Name of Manufacturer
2Gross Vehicle Weight Rating
3Gross Axle Weight Rating (Front, Rear)
4Canadian Safety Mark (w/RPO Z49)
5Certification Statement
6Vehicle Class Type (Pass Car, etc.)
7Vehicle Identification Number
8Date of Manufacture (Mo/Yr)
Tire Placard The tire placard label is located on the center pillar and displays the following assessments
9Specified Occupant Seating Positions
10Maximum Vehicle Capacity Weight
11Tire Pressure, Front, Rear and Spare (Cold)
12Original Equipment Tires Size
Service Parts ID Label The vehicle service parts identification label is located in the driver side rear door. The label is use to help identify the vehicle original parts and options.
13Model Designation
14Order Number
15Exterior Color
16Paint Technology
17Vehicle Identification Number
18Wheel Base
19Part Number Location
Anti-Theft Label
20The Federal law requires that General Motors label certain body parts on this vehicle with the VIN. The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and recovery of parts from stolen vehicles. Labels are permanently affixed to an interior surface of the part. The label on the replacement part contains the letter R, the manufacture's logo and the DOT symbol. The anti-theft label must be covered before any painting and rustproofing procedures and uncovered after the procedures. Failure to follow the precautionary steps may result in liability for violation of the Federal Vehicle Theft Prevention Standard and possible suspicion to the owner that the part was stolen.

Vehicle Certification, Tire Placard, Anti-Theft and Service Parts ID Label

RPO Code List

The following table provides the description of the RPO codes that are available on the vehicle. The vehicles RPO list is printed on the Service Parts Identification Label.

RPODescription
01ATRIM COLOR SEAT - JET BLACK
01CTRIM COLOR SEAT - LIGHT TITANIUM
03YTRIM COLOR SEAT - CHARCOAL
1ABTRIM COLOR DOOR PANEL - JET BLACK
1ARTRIM COLOR DOOR PANEL - MED TITANIUM
4AAINTERIOR TRIM - JET BLACK
4APINTERIOR TRIM - JET BLACK/LIGHT TITANIUM
5A7WHEEL SPARE - NONE
5EAEQUIPMENT - PACKAGE, CO2- REDUCTION
5VDACCESSORY - PROTECTOR - FRONT BUMPER
5Y3ACCESSORY - TOW BALL - TRAILER HITCH
9L3TIRE SPARE - NONE
A84COMPARTMENT DOOR - NON-LOCKING
AA7WINDOW - POWER OPERATED, QUICK OPENING
ACOIDENTIFICATION - ACCESSORY CATALOG OFFERING
ADHINTERIOR TRIM CONFIG - #32
ADWINTERIOR TRIM CONFIG - #27
ADXINTERIOR TRIM CONFIG - #30
ADZINTERIOR TRIM CONFIG - #34
AE8ADJUSTER FRONT SEAT - POWER, 8 WAY
AENINTERIOR TRIM CONFIG - #35
AH5ADJUSTER FRONT SEAT - POWER, 8 WAY, NO MEMORY, DRIVER
AKNWINDOW TYPE - TINTED
AKWWINDSHIELD TYPE - TINTED
AL0SENSOR INDICATOR - INFLATABLE RESTRAINT, FRONT PASSENGER/CHILD PRESENCE DETECTOR
AM9SEAT REAR - SPLIT BACK, FOLDING
AP9NET - CONVENIENCE
AQ2NET - CONVENIENCE, PACKAGE
AQPRESTRAINT - HEAD, REAR SEAT, CENTER
AR9SEAT - FRONT BUCKET, DELUXE
AT3RESTRAINT PROVISIONS - CHILD, REAR SEAT, ANCHORAGE, REINFORCED
AT7RESTRAINT SYSTEM REAR - SEAT, SHLDR, RETR, 3 POINT, 3 SHLDR
AT8RESTRAINT PROVISIONS - CHILD, REAR SEAT, REAR FACING
ATGLOCK CONTROL, ENTRY - REMOTE ENTRY, STANDARD RANGE
ATHLOCK CONTROL, ENTRY - REMOTE ENTRY, EXTENDED RANGE, PASSIVE ENTRY, ALL DOORS
AWWNET - CONVINCE, REAR COMPARTMENT, FLOOR
AXPVEHICLE TYPE - MULTI-PURPOSE PASSENGER VEHICLE
AXXVEHICLE TYPE - VEHICLE TYPE - NOT REQUIRED
AY0RESTRAINT SYSTEM - SEAT, INFLATABLE, DRIVER AND PASSENGER FRONT, SEAT SIDE, ROOF SIDE
B2OMOLDING BODYSIDE - LOWER, EXTRA WIDE, MOLDED COLOR
B34COVERING FRONT - FLOOR MATS, CARPETED INSERT
B35COVERING REAR - FLOOR MATS, CARPETED INSERT
B3VTEST - EXTENDED WATER
B6GPLATE - DOOR SILL COVER, STAINLESS STEEL
B6HPLATE - DOOR SILL COVER, PLASTIC
B6JMOLDING ROCKER - NARROW, MOLDED COLOR
BAAORNAMENTATION - EXTERIOR, MOLDING, FENDER, SILVER
BAGPARTS PACKAGE - EXPORT
BI1ORNAMENTATION - INTERIOR, BEZEL, RADIO SPEAKER, SILVER
BLSPLATE INSCRIPTION - TYPE "B"
BTMSWITCH - ENGINE START, KEYLESS
BTVREMOTE START - ENGINE
BUQPLANT CODE - BUPYEONG 2, KOREA
C13WIPER SYSTEM WINDSHIELD - INTERMITTENT
C25WIPER SYSTEM REAR WINDOW - INTERMITTENT
C36HEATER - AUXILIARY
C37HEATER - SEAT, DRIVER
C38HEATER - SEAT, PASSENGER
C4GGVW RATING - 2294 KG (5057 LBS)
C4HGVW RATING - 2214 KG (4880 LBS)
C4JGVW RATING - 2189 KG (4825 LBS)
C60HVAC SYSTEM - AIR CONDITIONER FRONT, MANUAL CONTROLS
C67HVAC SYSTEM - AIR CONDITIONER FRONT, ELECTRONIC CONTROLS
C68HVAC SYSTEM - AIR CONDITIONER FRONT, AUTO, ELECTRONIC CONTROLS
CE1WIPER SYSTEM - WINDSHIELD, PULSE, MOISTURE SENSITIVE
CF5ROOF - SUNROOF, GLASS, SLIDING, ELECTRIC
CJ2HVAC SYSTEM - AIR CONDITIONER FRONT, AUTO TEMP CONT, AUX TEMP CONT
CL7COUNTRY - URUGUAY
CL8COUNTRY - PARAGUAY
CV2COUNTRY - BRAZIL
CV3COUNTRY - MEXICO
CV4COUNTRY - ISRAEL
CW4COUNTRY - CARIBBEAN (ANTIGUA, ANTILLES, BAHAMAS, BARBADOS, BERMUDA, CAY, HAITI, DOMINICAN, JAMAICA, NASSAU, S.M., TRINIDAD)
CX2COUNTRY - COLOMBIA
CX3COUNTRY - ECUADOR
CX5COUNTRY - AUSTRALIA
CX6COUNTRY - NEW ZEALAND
CZ1COUNTRY - CENTRAL AMERICA (BELIZE, COSTA RICA, EL SALVADOR, GUATEMALA, HONDURAS, NICARAGUA, PANAMA)
D31MIRROR INSIDE REARVIEW - TILT
D42SHADE - REAR COMPARTMENT
D63TRAY - FRONT FLOOR DEPOSIT
D6HMIRROR INSIDE FRONT VANITY - SUNSHADE, DRIVER, W/MIRROR, COVER, HOLDER, PASSENGER, W/MIRROR, COVER
D6IMIRROR INSIDE FRONT VANITY - SUNSHADE, DRIVER, W/MIRROR, COVER, HOLDER, ILLUM, PASSENGER, W/MIRROR, COVER, ILLUM
D6KSEAT BACK - FOLDING, FLAT, PASSENGER SIDE
D7AHANDLE OUTSIDE DOOR - BODY COLOR, CHROME STRIP
D91HANDLE, REAR CLOSURE - O/S, L/GATE, R/CMPT, COLOR
DD1MIRROR OUTSIDE - LEFT AND RIGHT, REMOTE CONTROL, ELECTRIC, HEATED, LIGHT SENSITIVE LEFT SIDE ONLY
DD8MIRROR INSIDE REARVIEW - LIGHTT SENSITIVE
DG7MIRROR OUTSIDE - LEFT AND RIGHT, REMOTE CONTROL, ELECTRIC, COLOR
DH0MIRROR INSIDE REARVIEW; - TILT, AUTO, LIGHT SENSITIVE (DO NOT USE AFTER M.Y. 2015)
DLSMIRROR OUTSIDE - LEFT AND RIGHT, REMOTE CONTROL, ELECTRIC, HEATED, MANUAL FOLDING, COLOR, TURN SIGNAL INDICATOR
E2UORNAMENTATION - LETTERING, "LS"
E3EHANDLE, REAR CLOSURE - O/S, L/GATE, R/CMPT, CHROME
E3LBODY EQUIPMENT - STEPSIDE - NONE
E62BODY EQUIPMENT - STEPSIDE, PUBX
E7XFIRE EXTINGUISHER - 1KG
E96COVER - REAR COMPT LID, INNER
EBFTRIM SEAT - LEATHER, MERIDIAN
EF7COUNTRY - UNITED STATES OF AMERICA (USA)
EQGTRIM SEAT - CLOTH, MEGAN
EQKTRIM SEAT - LEATHER, PINNACLE
EQXTRIM SEAT - CLOTH, WICKER SR
EXPEXPORT
EYITRIM SEAT - CLOTH, MARK
EYYTRIM SEAT - CLOTH, MEGAN VAR1
F45CHASSIS - CONTINUOUSLY VARIABLE REAL TIME DAMPING
F46CHASSIS ALL WHEEL DRIVE (AWD)
F82RATIO - TRANSAXLE FINAL DRIVE 3.23
FCSTRIM DOOR - URETHANE, MONDIAL, VAR 1
FCUTRIM DOOR - PU LEATHER
FE1SUSPENSION SYSTEM - SOFT RIDE
FE9CERTIFICATION - EMISSION, FEDERAL
FHSVEHICLE FUEL - GASOLINE E85
FHWVEHICLE FUEL - DIESEL B5
FIKTRIM DOOR - URETHANE, LONGITUDE
FILTRIM DOOR - CLOTH, MANA
FKMTRIM DOOR - CLOTH, MEGAN
FX6RATIO - TRANSAXLE FINAL DRIVE 3.87
G67LEVEL CONTROL - AUTO, AIR
G6DPRIMARY COLOR - EXTERIOR, DARK BURGUNDY (339X)
GANPRIMARY COLOR - EXTERIOR, SWITCHBLADE SILVER MET (G)
GARPRIMARY COLOR - EXTERIOR, CARBON FLASH MET (G) 501Q
GAZPRIMARY COLOR - EXTERIOR, SUMMIT WHITE (G) 8624
GBEPRIMARY COLOR - EXTERIOR, CRYSTAL CLARET TINTCOAT (G)
GBUPRIMARY COLOR - EXTERIOR, ICE WHITE (G) 703S
GH8EQUIPMENT - PORT OF ENTRY FITTED
GJEPRIMARY COLOR - PLACID GREY MET (809S)
GLJPRIMARY COLOR - EXTERIOR, ASHEN GRAY METALLIC 810T
GUEPRIMARY COLOR - EXTERIOR, SMOKEY EYE GREY MET (748U)
GWSPRIMARY COLOR - EXTERIOR, SILVER TOPAZ METALLIC (101V)
GWTPRIMARY COLOR - EXTERIOR, CHAMPAGNE SILVER MET (102V)
GWXPRIMARY COLOR - EXTERIOR, SUBTERRANEAN MET (105V)
GXHPRIMARY COLOR - BERLIN BLUE MET (122V)
GYLPRIMARY COLOR - EXTERIOR, SANDY BEACH BROWN METALLIC (206V)
GYNPRIMARY COLOR - EXTERIOR, SNOWFLAKE WHITE PEARL (203V)
GYOPRIMARY COLOR - EXTERIOR, DEEP ESPRESSO BROWN METALLIC (204V)
HDNORNAMENTATION - EMBLEM, "HOLDEN"
I14ENGINEERING YEAR - 2014
JL9BRAKE SYSTEM - POWER, FRONT AND REAR DISC, ANTILOCK, FRONT AND REAR WHEEL
K09GENERATOR - 120 AMP
K13EXHAUST - FILTER EXHAUST SYSTEM, PARTICLE
K34CRUISE CONTROL - AUTOMATIC, ELECTRONIC
K5NBATTERY - LN3, FLA, 12V, 80AH, 750 SAE CCA
KA0KEY - VEHICLE, DUAL
KA1HEATER - SEAT, FRONT
KD4RECEPTACLE - ELECTRICAL, FRONT CONSOLE
KDOEQUIPMENT - INTR, AIR QUALITY CONTROL
KG4GENERATOR - 150 AMP
KG8GENERATOR - 130 AMP
KG9GENERATOR - 140 AMP
KI2KNOB - TRANS CONT LEVER, POLYURETHANE
KTIKIT, TIRE - INFLATOR
LE9ENGINE - GAS, 4 CYL, 2.4L, MFI, DOHC, E85 MAX, ALUM
LEAENGINE - GAS, 4 CYL, 2.4L, SIDI, DOHC, E85 MAX, ALUM, GM
LFWENGINE - GAS, 6 CYL, 3.0L, SIDI, DOHC, VVT, E85 MAX, ALUM, GM
LNQENGINE - DIESEL, 4 CYL, L4, 2.2L, CRI, DOHC, TURBO, 132 KW
LNSPOWER OPTION - DIESEL L4 TURBO 132KW 2.2L 184 GROSS HP
MDCMOLDING B/S UPPER - BRIGHT
MH7TRANSMISSION - AUTO 6 SPD, HMD, X23FHD
MHJTRANSMISSION - AUTO 6 SPD, 6T50, AWD
MHKTRANSMISSION - AUTO 6 SPD, 6T50
MTFPROVISIONS - FIRE EXTINGUISHER MOUNTING
MX0MERCHANDISED TRANSMISSION - AUTOMATIC PROVISIONS, O/D
N08LOCK CONTROL FUEL FILLER DOOR, REMOTE CONTROL
N10EXHAUST SYSTEM - DUEL
N37STEERING COLUMN TILT, TELESCOPING
NBQEXHAUST - SPORTY, CHROME
NC7EMISSION OVERRIDE - FEDERAL SYSTEM
NE1CERTIFICATION - EMISSION, GEOGRAPHICALLY RESTRICTED REGISTRATION FOR VEHICLES UP TO 14, 000 LBS GVW
NE9EMISSION SYSTEM - EEC 09
NK5STEERING WHEEL - STANDARD
NNZCONTROL - STEERING WHEEL, HVAC, REDUNDANT CONTROLS
NP5STEERING WHEEL - LEATHER WRAPPED
NR0STEERING WHEEL - LEATHER, 4 SPOKES
NT7EMISSION SYSTEM - FEDERAL, TIER 2
NU5EMISSION SYSTEM - CALIFORNIA, BIN 4
NV8STEERING - POWER, MAGNETIC SPEED, VARIABLE ASSIST
NVHSTEERING - POWER, NON-VARIABLE EFFORT, HYDRAULIC
PNIPANEL - CONVENIENCE, REAR COMPT, DISPLAY
QMUTIRE ALL - P235/60R17 SL 100H BW AL3
QNTTIRE ALL - P235/55R18 SL 99T BW AL2
RC9PLATE - CHROME SKID FRONT AND REAR
RHDVEHICLE DRIVE - RIGHTHAND DRIVE
RJATIRE SPARE - T135/70R16 SL 100M BW SPR
RJBTIRE ALL - 235/50R19-SL 99H BW HW4
RJETIRE ALL - 235/60R17 SL102H BW HW3
RJGTIRE ALL - 235/55R18 SL 100H BW HW3
RKSTIRE SPARE - 215/70R16 SL 100T BW HWY
RSBWHEEL - 17 X 7.0, J, ALUMINUM, DESIGN 1
RSXWHEEL - 18 X 7.0, J, ALUMINUM, DESIGN 1
RT6WHEEL - 19 X 7.0, J, ALUMINUM, DESIGN 1
RU9WHEEL SPARE - 16 X 6.5, J, STEEL, DESIGN 1
RV6WHEEL - 18 X 7.0, J, ALUMINUM, DESIGN 2
RVFWHEEL - 17 X 7.0, J, ALUMINUM, DESIGN 3
RVXACCESSORY - BALL MOUNT - TRAILER HITCH
RVZWHEEL SPARE - 16 X 4.0, T, STEEL, DESIGN 1
RWSACCESSORY - FLOOR MATS - CARPET
RWVACCESSORY - CARGO AREA ORGANIZER - FIXED
RYTACCESSORY - FIRST AID KIT
RZSWHEEL - 17 X 7.0, J, ALUMINUM, DESIGN 8
S08ACCESSORY - HIGHWAY SAFETY KIT
S5QACCESSORY - NAVIGATION SYSTEM - PORTABLE
S5XACCESSORY - PARK ASSIST - REAR
SA1ACCESSORY - SECURITY SYSTEM UPGRADE - KEYLESS ENTRY
SAHACCESSORY - SILL PLATES - CHROME
SAIACCESSORY - SILL PLATES - STAINLESS
SALPLANT CODE - RAMOS ARIZPE, MEXICO
SD5ACCESSORY - TIRE PRESSURE MONITOR
SDDACCESSORY - TRAILER HITCH - FIXED
SDIACCESSORY - TRIANGLE - REFLECTIVE
SFEACCESSORY - WHEEL LOCKS
SVCHOLDER - CUP, FRONT
T2YPROVISIONS - SEAT, CHILD
T3NLAMP SYSTEM - DAYTIME RUNNING, SEPARATE CAVITY
T3ULAMP FRONT FOG - FRONT FOG
T47LAMP - TAIL AND STOP, WITH FOG, ECE
T62LAMP SYSTEM - DAYTIME RUNNING - DELETE
T79LAMP - FOG, REAR
T83CONTROL, HEADLAMPS - AUTOMATIC ON-OFF
T96LAMP - FRONT FOG, FMVSS
TCALAMP - DOME, CENTER
TFKALARM - SEAT BELT WARNING
TFMALARM - SEAT BELT WARNING, LEFT
TFNALARM - SEAT BELT WARNING, RIGHT
TGHLANGUAGE CONTROL - SPANISH, PORTUGUESE, FRENCH
TM7BATTERY - LN2, FLA, 12V, 60AH, 438 ENCCA
TR8REFLECTOR - WARNING, DISABLED VEHICLE
TS6LAMP - STOP, HIGH LEVEL
TSGBATTERY - LN5, FLA, 12V, 90AH, 800 ENCCA
U05HORN - DUAL
U18SPEEDOMETER - INSTRUMENT, KILO
U19SPEEDOMETER - INSTRUMENT, KILO AND MILES, KILO ODOMETER
U2JDIGITAL AUDIO SYSTEM - S-BAND, NOT INSTALLED
U2KDIGITAL AUDIO SYSTEM - S-BAND
U61SPEAKER SYSTEM - 10, DELUXE
U77ANTENNA - REAR WINDOW, RADIO
UCRSYSTEM, NAVIGATION - LOW COST VARIANT
UD7PARK ASSIST - REAR
UE0COMMUNICATION SYSTEM - VEHICLE, G.P.S. - NOT INSTALLED
UE1COMMUNICATION SYSTEM - VEHICLE, G.P.S. 1
UE8CLOCK - ELECTRIC, DIGITAL
UFRSENSOR INDICATOR - FRONT AND REAR OBSTACLE DETECTION (DO NOT USE AFTER 2014)
UG1OPENER - GARAGE DOOR, UNIVERSAL
UG7THEFT DETERRENT - VEHICLE TRACKING AND RESTART PREVENTION
UH8CLUSTER - INSTRUMENT, COOL TEMP, TRIP ODOMETER, TACH
UHVRADIO - AM/FM, TOUCHSCREEN, NAVIGATION, CONNECTED, HD, CD, AUX JACK, USB PORT
UHWRADIO - AM/FM, TOUCHSCREEN, CONNECTED, HD, CD, AUX JACK, USB PORT
UJMTIRE PRESS INDICATOR MANUAL LEARN
UK3CONTROL - STEERING WHEEL, ACCESSORY
UL2FREQUENCIES - EUROPEAN
UL4FREQUENCIES - SOUTH AMERICA
UP9WIRELESS INTERFACE - SHORT RANGE, VOICE RECOG, MUSIC NAVIGATOR, STREAMING AUDIO
UPFWIRELESS INTERFACE - SHORT RANGE, VOICE REC
UPRRADIO - AM/FM STEREO, SEEK/SCAN, AUTO REV MUSIC SEARCH CASS, COMPACT DISC, MP3, EQUALIZER, ETR
UQ4SPEAKER SYSTEM - 4, BASE
UR3INDICATOR - FUEL ECONOMY
USRRECEPTACLE - USB
UUIRADIO - AM/FM STEREO, SEEK/SCAN, CD, AUTO TONE, CLOCK, ETR, MP3, RDS, USB PORT
UVCCAMERA - REAR VIEW
UW6SPEAKER SYSTEM - 6, CUSTOM
UX8SPEAKER SYSTEM - 8, DELUXE
V2STRAILER PROVISIONS - WIRING HARNESS
V3DLUGGAGE CARRIER CLR - ROOF, BLACK
V3ELUGGAGE CARRIER CLR - ROOF, SILVER
V59RAIL - ROOF
V68VEHICLE STATEMENT - AUSTRALIA
V8IVEHICLE STATEMENT - ISRAEL
V8ZMODEL CONVERSION - CHEVROLET LTZ
V92TRAILER PROVISIONS
V9FMODEL CONVERSION CHEVROLET LS
V9GMODEL CONVERSION CHEVROLET LT
V9HMODEL CONVERSION - CHEVROLET LIGHT AWD
VAVACCESSORY - FLOOR MATS - ALL WEATHER
VC5LABEL - SHIPPING, EXCEPT US, US POSSESSIONS OR JAPAN
VD4PROVISION OPTIONS - POOR FUEL QUALITY CHARACTERISTICS
VEVEQUIPMENT - SKID PLATE, FASCIA, MOLDED COLOR
VEYEQUIPMENT - SKID PLATE, FASCIA, SILVER
VG1PROTECTOR - UNDERHOOD COMPOUND, CORROSION PREVENTIVE, WATER BASED, CLEAR
VG4PROTECTOR - UNDER VEHICLE COMPOUND, CORROSION PREVENTIVE, WATER BASED, BLACK
VGCPROTECTOR - FILM, PAINT ETCH PREVENTIVE
VH4MUD FLAPS
VHOBUMPER FRONT - SPORT, MOLDED COLOR
VHYPROTECTOR - BODY SHEET METAL, HIGH CORROSION PREVENTIVE
VIXPLATE - VEHICLE IDENTIFICATION - VISUAL (GMDAT)
VK3LICENSE PLATE FRONT - FRONT MOUNTING PKG
VMGBUMPER REAR - STEP, STAINLESS, BODY AND MOLDED COLOR
VMHBUMPER REAR - STEP, MOLDED, UPPER BODY AND LOWER MOLDED COLOR
VMUBUMPER FRONT - UPPER BODY AND LOWER MOLDED
VNWVIN FORMAT - EU (ISO) TYPE
VPHVEHICLE PREPARATION - OVERSEAS DELIVERY
VQKACCESSORY - SPLASH GUARDS - CUSTOM MOLDED
VQPACCESSORY - CROSS RAILS - ROOF RACK - INTEGRATED - BRIGHT
VR6HOOK - TIE DOWN SHIPPING
VT7OWNER'S MANUAL - ENGLISH LANGUAGE
VTBACCESSORY - PROTECTOR - REAR BUMPER
VTWCOMPARTMENT - STOWAGE, I/P, W/LID
VTXCOMPARTMENT - STOWAGE, I/P, WO/LID
VUWCOMPARTMENT - STOWAGE, I/P, CENTER, VAR. 1
VUXCOMPARTMENT - STOWAGE, I/P, CENTER, VAR. 2
VY7KNOB - TRANSMISSION CONTROL LEVER, LEATHER
VZ3LABEL - MERCURY DISPOSAL NOTIFICATION
VZEVIN MODEL YEAR - 2014
W12NAVIGATION DISC DATA - NAV DATA 2
W1YCONTROL - STEERING WHEEL, RADIO, REDUNDANT CONTROLS
W2DACCESSORY - CARGO NET
WCMORNAMENTATION - LETTERING "LT"
WMPORNAMENTATION - NAME PLATE "CAPTIVA"
WPFSALES PACKAGE - PREFERRED
WPGSALES PACKAGE - ENHANCED CONVENIENCE
WWAORNAMENTATION - LETTERING "LTZ"
Y8AGVW RATING - NONE
Y92MERCHANDISED PKG - SPECIAL EDITION
YF5CERTIFICATION - EMISSION, CALIFORNIA
YMBIDENTIFICATION - LIMITED PERSONALIZATION OPTION (LPO)

RPO Code List

Metric Fasteners

This vehicle provides fastener dimensions using the metric system. Most metric fasteners are approximate in diameter to equivalent English fasteners. Make replacements using fasteners of the same nominal diameter, thread pitch and strength.

A number marking identifies the OE metric fasteners except cross-recess head screws. The number also indicates the strength of the fastener material. A Posidrive® or Type 1A cross-recess identifies a metric cross-recess screw. For best results, use a Type 1A cross-recess screwdriver or equivalent, in Posidrive® recess head screws.

GM Engineering Standards and North American Industries have adopted a portion of the ISO-defined standard metric fastener sizes. The purpose was to reduce the number of fastener sizes used while retaining the best thread qualities in each thread size. For example, the metric M6.0 X 1 screw, with nearly the same diameter and 25.4 threads per inch replaced the English 1/4-20 and 1/4-28 screws. The thread pitch is midway between the English coarse and fine thread pitches.

Scheme 5

Scheme 5: Fastener Strength Identification
CalloutComponent Name
1English Bolt, Grade 2 (Strength Class)
2English Bolt, Grade 5 (Strength Class)
3English Bolt, Grade 7 (Strength Class)
4English Bolt, Grade 8 (Strength Class)
5Metric Nut, Strength Class 9
6Metric Bolts, Strength Class Increases as Numbers Increase

The most commonly used metric fastener strength property classes are 9.8 and 10.9. The class identification is embossed on the head of each bolt. The English, inch strength classes range from grade 2 to grade 8. Radial lines are embossed on the head of each bolt in order to identify the strength class. The number of lines on the head of the bolt is 2 lines less than the actual grade. For example, a grade 8 bolt will have 6 radial lines on the bolt head. Some metric nuts are marked with a single digit strength identification number on the nut face.

The correct fasteners are available through GM SPO. Many metric fasteners available in the aftermarket parts channels are designed to metric standards of countries other than the United States and may exhibit the following

  1. Lower strength
  2. No numbered head marking system
  3. Wrong thread pitch

The metric fasteners on GM products are designed to new, international standards. The following are the common sizes and pitches, except for special applications

  1. M6.0 X 1
  2. M8 X 1.25
  3. M10 X 1.5
  4. M12 X 1.75
  5. M14 X 2.00
  6. M16 X 2.00

Thread Inserts

General Purpose Thread Repair Kits.

These kits are available commercially.

Repair Procedure

  1. Determine the size, the pitch and the depth of the damaged thread. If necessary, adjust the stop collars on the cutting tool and tap to the required depth.
  2. Drill out the damaged threads. Clean out any chips.
  3. Lubricate the tap with light engine oil. Tap the hole. Clean the threads.
  4. Thread the thread insert onto the mandrel of the installer. Engage the tang of the insert onto the end of the mandrel.
  5. Lubricate the insert with light engine oil, except when installing in aluminum and install the insert.
  6. If the tang of the insert does not break off when backing out the installer, break the tang off with a drift.

Registered and Non-Registered Trademarks

Listed below are Registered Trademarks (®) or Non-Registered Trademarks (™) which may appear in this service information.

A
AC®
ACCUTURN®
ACDelco®
Active Fuel Management™
Acuzinc®
Airbank®
Allison®
AMMCO®
AUTOFUSE®
AUTOTRAC®
B
Bendix®
Bluetooth®
BON-AMI®
Bosch®
Bose®
C
Caterpillar®
CAT®
C-Quam®
D
Delco®
Delco Bose®
Delco Electronics®
Delco Freedom®
Delco LOC II®
Delco Moraine®
Delco Remy®
Delco Sound®
Delco Supreme®
Delco Tech®
DELCORE®
Delphi®
DEX-COOL®
DEXOIL®
DEXRON®
DEXSTEER™
DNR®
Dolby®
DR®
Duracell®
Duraguard®
Durastop®
Duramax™
E
Eaton Corporation®
EMD®
ETR®
F
FLO-LITE®
G
General Motors®
GM®
GM Goodwrench Service®
GM Optikleen®
GM Parts™
GM Pass®
GM Ultralite®
GMAC®
Goodwrench®
GTP®
H
Homelink™
HYDRA-MATIC®
I
Illumination®
INSTA-TRAC®
Intune®
L
LOCTITE™
Lord Fusor™
M
MAGNASTEER®
Maxifuse®
Metripack®
Micropack®
Minifuse®
Mr Goodwrench®
N
Northstar®
O
OnStar®
Optikleen®
P
PASS-KEY®
PASS-KEYII®
PASSLOCK™
PK3®
Posidrive®
Pro®
Q
Quad 4®
R
RAINSENSE™
Rapid Fire®
S
ScotchBrite™
Scotchguard™
Signals®
Sikkens™
Soft-Ray®
Solar-Ray®
Stabilitrak®
Sunrayce®
Superlube®
Syclone®
T
Tech 2®
Techline®
Teflon®
Tefzel®
Theft-I®
Theftlock®
Tiltmaster®
TORX®
Transjel®
Transguide®
Twilight Sentinel®
U
Ultralite®
V
Velcro®
W
Weatherpack™

Registered and Non-Registered Trademarks

Key and Lock Cylinder Coding

This vehicle has two different types of ignition lock cylinders based on what type of steering column the vehicle is equipped with. The electric power steering (EPS) option, usually found on 4 cylinder models and the non EPS, usually found on 6 cylinder models, use different ignition lock cylinder designs.

Ignition Lock Cylinder - Non EPS

The non EPS ignition lock cylinder uses 8 of the 10 key cut positions, 1-8 when counting from the key head. The tumbler orientations alternate in adjacent locations from side to side with 4 tumblers on each side.

  1. Hold the uncoded cylinder assembly (2) positioned so the side with the security plug (3) faces to the left of the key head.
  2. Insert one tumbler spring (7) into each of the 4 tumbler spring holes.
  3. The first tumbler (1) to be loaded will be key cut position 1, the first number in the key code. Install this tumbler in the tumbler slot closest to the head of the lock cylinder (2), the end where the key is inserted.
  4. Advancing one tumbler slot at a time, install tumblers 3, 5 and 7 sequentially on the same side as tumbler 1.
  5. Turn the lock cylinder over and insert one tumbler spring (7) into each of the 4 tumbler spring holes on the opposite side of the lock cylinder.
  6. Insert tumbler 2 into the tumbler slot closest to the head of the lock cylinder (2), the end where the key is inserted.
  7. Advancing one tumbler slot at a time, install tumblers 4, 6 and 8 sequentially on the same side as tumbler 2.
  8. Check for correct tumbler loading by holding the tumblers (1) in position and inserting the correct key into the lock cylinder. All tumblers (1) should be flush with the housing of the lock cylinder.
  9. Lightly lubricate the tumblers and small detent recessed areas the tumblers are in with GM Super Lube or equivalent light lithium grease.
  10. Insert the key into the coded lock cylinder (2) and hold the lock cylinder positioned so the side with the security plug (3) faces to the left of the key head.
  11. Hold the ignition lock housing positioned so the security plug actuator lever (3) also faces to the right of the key head.
  12. Push the exposed end of the security plug actuator lever (3) toward the center of the lock cylinder housing (1) and hold it. Insert the coded lock cylinder (2) with the key in it into the ignition lock cylinder housing (1) until the cap is flush with the housing.
  13. Rotate the keyed lock cylinder counterclockwise slightly until it stops and detents outward slightly. The key should be able to be removed and the lock cylinder should remain in the housing.
  14. Install the retaining clip (1) onto the coded lock cylinder where it comes out of the back of the lock cylinder housing.
  15. Install the trim cap (4) on the ignition lock assembly.

Ignition Lock Cylinder - EPS

The ignition lock cylinder used 7 of the 10 key cut positions, 4-10 when counting from the key head. The tumbler (3) orientations alternate in adjacent locations from side to side with 3 on one side and 4 on the other.

  1. Hold the uncoded cylinder plug (5) positioned so the side with the sidebar slot is facing to the left and the 3 spring holes are on top.
  2. Insert one tumbler spring (7) each into the 3 tumbler spring holes.
  3. The first tumbler to be loaded will be key cut position number 5, the fifth number in the key code. Determine the cut depth at this position and install the corresponding tumbler (8) into the tumbler slot second from the front of the cylinder plug (5) (the end where the key is inserted).
  4. In the same manner, determine the cut depth and corresponding tumbler and install the 2 remaining tumblers (8) into the tumbler slots located at key cut positions 7 and 9.
  5. Check for correct loading by holding the tumblers (8) in position and fully inserting the matching key into the cylinder plug (5). All tumblers should be flush with the outside diameter of the cylinder plug.
  6. Rotate the cylinder plug (5) so that the side with the sidebar slot is facing to the right and then remove the matching key. Remember the tumblers (8) are not self-retaining and must be held in place.
  7. Insert one tumbler spring (7) each into the 4 tumbler spring holes.
  8. The first tumbler to be loaded will be key cut position number 4. Determine the cut depth at this position and install the corresponding tumbler (8) into the tumbler slot nearest the front of the cylinder plug (5).
  9. In the same manner, determine the cut depth and corresponding tumbler and install the 3 remaining tumblers (8) into the slots located at key cut positions 6, 8 and 10.
  10. Check for correct loading by holding the tumblers (8) in position and fully inserting the matching key into the cylinder plug assembly (5). All tumblers should be flush with the outside diameter of the cylinder plug.
  11. Lightly lubricate tumbler (8) surfaces using the lubrication provided.
  12. Hold the cylinder plug (5) positioned so the side with the sidebar slot is facing to the left. Insert the U-shaped plunger shaft (6) into the grooves on the right side of the cylinder plug.
  13. Install the cylinder plug assembly (5) into the cylinder sleeve assembly (4). There is a slight interference fit between the cylinder plug and the cylinder sleeve assembly, so be sure that the cylinder plug is fully seated into the bottom of the cylinder sleeve. The cylinder plug should be slightly below flush with the inner face of the cylinder sleeve. Once the cylinder plug assembly is fully installed into the cylinder sleeve assembly, the tumblers (8) will be fully enclosed and retained.
  14. Install the actuator (11) into the pocket in the front face of the cylinder plug.
  15. Install the security plate (10) on top of the cylinder plug in the cylinder sleeve assembly.
  16. Securely stake the security plate (10) into the cylinder sleeve assembly (4). Assemble the cylinder sleeve assembly and security plate. When loading cylinder sleeve assembly into the staking tool, ensure staking cup number 12 is positioned cup toward cylinder sleeve. Secure assembled staking tool in a vise. Rotate the forcing screw (13) in order to uniformly stake the cylinder sleeve material over the security plate. Rotating screw (13) requires the use of BO-47869 Lock Cylinder Staking Tool . Tighten the forcing screw (13) to 23-28 N.m (17-21 lb ft). Once the security plate has been staked to the assembly, ensure the actuator can rotate freely inside the assembly by inserting a key and removing it.
  17. Install and stake the cover (9) onto the head of the cylinder sleeve assembly (4) by crimping the cover material in 4 places into the pockets around the head of the cylinder sleeve. Ensure the cover is securely held onto the cylinder sleeve and that the key can be inserted into the cylinder sleeve assembly through the slot in the cover.
  18. Install the sidebar (3) into the cylinder sleeve assembly (4).
  19. Install the 2 sidebar springs (2) into the cylinder sleeve assembly (4).
  20. Install the stake and the 2 sidebar spring retainers (1) onto the cylinder sleeve assembly (4) by crimping the material on the cylinder sleeve onto the sidebar spring retainers. Ensure the sidebar spring retainers are securely attached to the cylinder sleeve.
  21. Insert the matching key into the cylinder assembly and confirm the following: The sidebar drops to be flush or below flush with the outer diameter of the cylinder sleeve (4) when the matching key is fully inserted into the cylinder assembly. The sidebar protrudes out of the diameter of the cylinder sleeve when the matching key is removed from the cylinder assembly. With the matching keys installed, the plunger protrudes to be flush or almost flush with the rear of the cylinder sleeve.
  22. Install the ignition cylinder assembly into the steering column of the vehicle

Door Lock Cylinder

The door lock cylinder uses 8 of the 10 key cut positions, 1-8 when counting from the key head. The tumbler orientations alternate in adjacent locations from side to side with 4 tumblers on each side.

  1. Hold the uncoded door lock cylinder (3) with the housing window facing up.
  2. Insert one tumbler spring (2) into each of the 4 tumbler spring holes.
  3. The first tumbler (1) to be loaded will be key cut position 2, the second number in the key code. Install this tumbler in the tumbler slot closest to the head of the lock cylinder housing, the end where the key is inserted.
  4. Advancing one tumbler slot at a time, install tumblers 4, 6 and 8 sequentially on the same side as tumbler 2.
  5. Turn the lock cylinder over and insert one tumbler spring (2) into each of the 4 tumbler spring holes on the opposite side of the lock cylinder.
  6. Insert tumbler 1 into the tumbler slot closest to the head of the lock cylinder housing (3), the end where the key is inserted.
  7. Advancing one tumbler slot at a time, install tumblers 3, 5 and 7 sequentially on the same side as tumbler 1.
  8. Check for correct tumbler loading by holding the tumblers (1) in position and inserting the correct key into the lock cylinder. All tumblers (1) should be flush with the housing of the lock cylinder.
  9. Lightly lubricate the tumblers and small detent recessed areas the tumblers are in with GM Super Lube or equivalent light lithium grease.
  10. Holding the tumblers in place, remove the key from the coded lock cylinder (3) and install the key door spring (4) with the center loop of the spring facing the key slot.
  11. Install the key door (5) and hold in the closed position while pushing the key door cover (6) onto the coded lock cylinder (3). The key door (5) should be under tension from the key door spring (4) and the key door cover (6) tab will engage with the assembled lock cylinder (3), holding the key door cover in place once installed.
  12. Install the coded lock cylinder assembly into the door lock cylinder housing so the cut out area in the back of the lock cylinder assembly (3) lines up with the cut out area in the back of the door lock cylinder housing (11).
  13. Install the door lock cylinder housing cap (7) and crimp the cap into position in 2 areas at 1 o'clock and 7 o'clock when looking at the face of the assembly in car position.
  14. Install the return spring (10), inner winding end first, in the smaller notch in the lock cylinder housing (11).
  15. Using a small flat-blade tool, pull the outer winding of the spring (10) clockwise until it engages with the larger notch in the lock cylinder housing (11). Ensure the return spring is seated fully in the opening.
  16. Install the door lock cylinder lever (9) and lever retaining clip (8).
  17. Install the coded door lock cylinder assembly into the door handle.

Scheme 6

Scheme 6: Lifting and Jacking the Vehicle
WARNINGTo avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the vehicle to the hoist.
WARNINGTo avoid any vehicle damage, serious personal injury or death, always use the jackstands to support the vehicle when lifting the vehicle with a jack.
CAUTIONWhen you are lifting a vehicle with a runway lift, be certain that the lift pads do not contact the Electronic Parking Brake Control Module, the brake pipes or the body harness. If such contact occurs, vehicle damage or unsatisfactory vehicle performance may result.
CAUTIONPerform the following steps before beginning any vehicle lifting or jacking procedure: Remove or secure all of the vehicle contents in order to avoid any shifting or any movement that may occur during the vehicle lifting or jacking procedure. The lifting equipment or the jacking equipment weight rating must meet or exceed the weight of the vehicle and any vehicle contents. The lifting equipment or the jacking equipment must meet the operational standards of the lifting equipment or jacking equipment manufacturer. Perform the vehicle lifting or jacking procedure on a clean, hard, dry, level surface. Perform the vehicle lifting or jacking procedure only at the identified lift points. DO NOT allow the lifting equipment or jacking equipment to contact any other vehicle components. Failure to perform the previous steps could result in damage to the lifting equipment or the jacking equipment, the vehicle, and/or the vehicle contents.

Vehicle Lifting - Frame Contact Lift

Front Lift Pads

When lifting the vehicle with a frame-contact lift, place the front lift pads on the rocker outer panel weld flange, as shown

Rear Lift Pads

When lifting the vehicle with a frame-contact lift, place the rear lift pads on the rocker outer panel weld flange, as shown.

Runway Lift

The use of a 2 inch (50.8 mm) or higher spacer will need to be placed below the marked lifting point, close to the C pillar to clear the Electronic Parking Brake Control Module from the hoist. Spacers will be required on both sides of the vehicle to raise the vehicle evenly on both sides. It is recommended to use a wooden or rubber block as a spacer.

Vehicle Jacking

CAUTIONWhen you are jacking the vehicle at the front locations, be certain that the jack or the jack lift pad does not contact the front fascia, front fascia air dam or the front fenders. If such contact occurs, vehicle damage may result. When jacking at selected front locations additional clearance may be required for the jacking points.

Note. When you are lifting a vehicle with a service jack, block the wheels at the opposite end from which you are lifting. Use jack stands to provide additional support.

Note. Place jackstands ONLY under strong and stable vehicle structures.

Front of Vehicle

Place the service jack pad in the same location as shown for the front lift pads.

Rear of Vehicle

Place the service jack pad in the same location as shown for the rear lift pads.
