Engine Controls/fuel - 2.4l - Repair Instructions Chevrolet Captiva I рестайлинг

Scheme 1

Engine Control Module Replacement

Scheme 2

Engine Control Module Bracket Replacement

Crankshaft Position System Variation Learn

Note. The Crankshaft Position Variation Learn procedure is also required when the following service procedures have been performed, regardless of whether DTC P0315 is set: An engine replacement An engine control module (ECM) replacement A crankshaft balancer replacement A crankshaft replacement A crankshaft position sensor replacement Any engine repairs which disturb the crankshaft to crankshaft position sensor relationship.

Note. The ECM monitors certain component signals to determine if all the conditions are met to continue with the Crankshaft Position Variation Learn procedure.

1. Ignition ON, observe the DTC information with a scan tool. Verify no other DTCs are set, except DTCs P0300-P0304, or P0315. If DTCs are set, except DTCs P0300-P0304, or P0315, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/captiva/i-2011-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) for further diagnosis.
2. Select the Crankshaft Position Variation Learn Procedure with a scan tool and perform the following: NOTE: Close the hood. NOTE: The engine must be at operating temperature. Block drive wheels. Set parking brake. DO NOT apply brake pedal. Turn the air conditioning (A/C) OFF. When directed, apply and hold brake pedal for the duration of the procedure. Ignition ON, engine running at operating temperature. The vehicle must remain in Park or Neutral. NOTE: While the learn procedure is in progress, release the throttle immediately when the engine starts to decelerate. The engine control is returned to the operator and the engine responds to throttle position after the learn procedure is complete. Accelerate to wide open throttle (WOT) and release when the fuel cut-off occurs.
3. The scan tool displays: Learn Status: Learned this Ignition.
4. Verify DTC P0315 ran and passed This Ignition Cycle. If DTC P0315 failed or did not run This Ignition Cycle, or another DTC is present, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/captiva/i-2011-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) for the applicable DTC that set.
5. Once the Crankshaft Position Variation Learn procedure has successfully completed, and in order to store the crankshaft position variation values in the ECM, turn OFF the ignition and verify all vehicle systems are OFF. This may take up to 2 minutes.

Description

The engine control module (ECM) learns the airflow through the throttle body to ensure the correct idle. The learned airflow values are stored within the ECM. These values are learned to adjust for production variation and will continuously learn during the life of the vehicle to compensate for reduced airflow due to throttle body coking. Anytime the throttle body airflow rate changes, for example due to cleaning or replacing, the values must be relearned.

An engine that had a heavily coked throttle body that has been cleaned or replaced may take several drive cycles to learn out the coking. To accelerate the process, the scan tool has the ability to reset all learned values back to zero. A new ECM will also have values set to zero.

The idle may be unstable or a DTC may set if the learned values do not match the actual airflow.

Conditions for Running the Idle Learn Procedure

Reset Procedure

1. DTCs P0068, P0101, P0102, P0103, P0106, P0107, P0108, P0116, P0117, P0118, P0119, P0121, P0122, P0123, P0128, P0171, P0172, P0201-P0204, P0222, P0223, P0300-P0304, P0351-P0354, P0496, P0506, P0507, P0601-P0604, P0606, P062B, P062F, P0630, P0641, P0651, P0697, P06A3, P1101, P1516, P16F3, P2101, P2119, P2122, P2123, P2127, P2128, P2135, P2138, P2176, or P2610 are not set.
2. Ignition ON, engine OFF.
3. The vehicle speed sensor (VSS) is 0 km/h (0 mph).

Learn Procedure

1. DTCs P0068, P0101, P0102, P0103, P0106, P0107, P0108, P0116, P0117, P0118, P0119, P0121, P0122, P0123, P0128, P0171, P0172, P0201-P0204, P0222, P0223, P0300-P0304, P0351-P0354, P0496, P0506, P0507, P0601-P0604, P0606, P062B, P062F, P0630, P0641, P0651, P0697, P06A3, P1101, P1516, P16F3, P2101, P2119, P2122, P2123, P2127, P2128, P2135, P2138, P2176, or P2610 are not set.
2. The engine speed is between 450-4,000 RPM.
3. The engine vacuum is greater than 5 kPa.
4. The mass air flow (MAF) is greater than 2 g/s.
5. The ignition 1 voltage is greater than 10 V.

Reset/Learn Procedure

Reset Procedure - Performed after the throttle body is cleaned or replaced

1. Ignition ON, engine OFF, perform the Idle Learn Reset in Module Setup with a scan tool.
2. Engine idling, monitor the Throttle Body Idle Airflow Compensation parameter. The Throttle Body Idle Airflow Compensation value should equal 0 % and the engine should be idling at a normal idle speed.
3. Clear the DTCs and return to the diagnostic that referred you here.

Learn Procedure - Performed after the ECM is programmed or replaced

1. Engine idling for 3 minutes.
2. Monitor the Desired Idle Speed and the actual Engine Speed with a scan tool.
3. The ECM will start to learn the new idle cells and Desired Idle Speed should start to decrease.
4. Ignition OFF for 60 s.
5. Engine idling for 3 minutes.
6. After the 3 minute run time the engine speed should return to normal. NOTE: During the drive cycle monitor the DTC information with a scan tool to verify DTC P0506 and P0507 do not set. If DTC P0506 and P0507 set, clear the DTCs so the ECM can continue to learn. If the engine idle speed has not been learned the vehicle will need to be driven at speeds above 70 km/h (44 mph) with several decelerations and extended idles.
7. After the drive cycle, the engine speed should return to normal. If the engine idle speed has not been learned, turn OFF the ignition for 60 s and repeat step 6.
8. Once the engine speed has returned to normal, clear DTCs and return to the diagnostic that referred you here.

Scheme 3

Engine Coolant Temperature Sensor Replacement

Scheme 4

Mass Airflow Sensor with Intake Air Temperature Sensor Replacement

Removal Procedure

1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Remove the evaporative emission (EVAP) canister purge tube from the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
3. Reposition the EVAP canister purge tube out of the way.
4. Disconnect and reposition the fuel injector wiring harness out of the way .
5. Disconnect the engine harness electrical connector from the manifold absolute pressure (MAP) sensor.
6. Remove the MAP sensor and seal.

Installation Procedure

1. Lubricate the NEW MAP sensor seal with clean engine oil.
2. Install the MAP sensor into the intake manifold.
3. Connect the engine harness electrical connector to the MAP sensor.
4. Position and connect the fuel injector wiring harness.
5. Position the EVAP canister purge tube to the intake manifold.
6. Connect the EVAP canister purge tube to the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
7. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Scheme 5

Heated Oxygen Sensor Replacement - Sensor 1

Scheme 6

Heated Oxygen Sensor Replacement - Sensor 2

1. Remove the driver knee bolster reinforcement. Refer to «Driver Knee Bolster Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
2. Disconnect the instrument panel wiring harness electrical connector (2) from the accelerator pedal position (APP) sensor (1).
3. Remove the APP sensor bolts (1).
4. Remove the APP sensor (2).

1. Position the APP sensor (2) against the brake pedal assembly.
2. Install the APP sensor bolts (1) and tighten to 10 N.m (89 lb in).
3. Connect the instrument panel wiring harness electrical connector (2) to the APP sensor (1).
4. Install the driver knee bolster reinforcement. Refer to «Driver Knee Bolster Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Note. DO NOT prop open the throttle blade with the ignition key in the ON position as it may set a diagnostic trouble code (DTC).

1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Disconnect the engine wiring harness electrical connector from the throttle body assembly.
3. Remove the throttle body assembly bolts.
4. Remove the throttle body assembly.
5. Inspect the throttle body assembly gasket, and replace it if necessary.

1. Install the throttle body assembly to the vehicle.
2. Install the throttle body assembly bolts and tighten to 10 N.m (89 lb in).
3. Connect the engine wiring harness electrical connector to the throttle body assembly.
4. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Throttle Body Cleaning

1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) . WARNING: Turn OFF the ignition before inserting fingers into the throttle bore. Unexpected movement of the throttle blade could cause personal injury. CAUTION: Do not insert any tools into the throttle body bore in order to avoid damage to the throttle valve plate.
2. Inspect the throttle body bore and the throttle plate for deposits. You will need to open the throttle plate in order to inspect all surfaces. CAUTION: Do not use any solvent that contains Methyl Ethyl Ketone (MEK). This solvent may damage fuel system components.
3. Clean the throttle body bore and the throttle plate using a clean shop towel with GM Top Engine Cleaner, P/N 1052626 or ACDelco Carburetor Tune-Up Conditioner, P/N X66-P, or an equivalent product.
4. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
5. Perform the Throttle/Idle Learn procedure. Refer to «Throttle/Idle Learn»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Fuel Pressure Relief

1. Remove the fuel pump module 20A fuse from the underhood electrical center.
2. Start the vehicle and allow the engine to idle until the engine stops. The engine will stop in approximately 20-30 seconds.
3. Turn the ignition OFF.

Fuel Pressure Gauge Installation and Removal

Special Tools

CH-48027 Digital Pressure Gauge

For equivalent regional tools, refer to Special Tools (Diagnostic Tools) .

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Connect the CH-48027-1 (1) to the CH-48027-2 (2).
3. Remove the shop towel from around the fuel pump feed pipe service port, and place in an approved gasoline container.
4. Perform any tests and/or diagnostics as needed. For the proper usage of the CH-48027 digital pressure gauge , refer to the manufacture's directions.

1. Relieve the fuel system pressure, if required. Perform the following steps: Wrap a shop towel around the fuel pump feed pipe service port. Place the hose on the CH-48027-2 (2) into an approved gasoline container. Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail. Close the valve on the CH-48027-2 (2). Remove the hose on the CH-48027-2 (2) from the approved gasoline container. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
2. Disconnect the CH-48027-1 (1) from the CH-48027-2 (2).
3. Disconnect the CH-48027-2 (2) from the CH-48027-3 (3).
4. Disconnect the CH-48027-3 (3) from the fuel Pump feed pipe service port.
5. Install the service port cap.
6. Install the engine cover, if required.
7. Tighten the fuel fill cap.

Metal Collar Quick Connect Fitting Service

Special Tools

EN-37088-A Fuel Line Disconnect Tool Set

For equivalent regional tools, refer to Special Tools (Diagnostic Tools) .

1. Relieve the fuel system pressure before servicing any fuel system connection. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Remove the retainer from the quick connect fitting.
3. Blow dirt out of the fitting using compressed air.
4. Choose the correct tool from the EN-37088-A set for the size of the fitting. Insert the tool into the female connector, then push inward in order to release the locking tabs.
5. Pull the connection apart.
6. Use a clean shop towel in order to wipe off the male pipe end.
7. Inspect both ends of the fitting for dirt and burrs. Clean or replace the components as required.

1. Apply a few drops of clean engine oil to the male pipe end.
2. Push both sides of the fitting together in order to snap the retaining tabs into place.
3. Once installed, pull on both sides of the fitting in order to make sure the connection is secure.
4. Install the retainer to the quick connect fitting.

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Using compressed air, blow any dirt out of the quick connect fitting.
3. This step applies to the Bartholomew style connectors ONLY. Squeeze the plastic quick connect fitting release tabs.
4. This step applies to the Q release type connectors ONLY. Release the fitting by pushing the tab toward the other side of the slot in the fitting.
5. This step applies to the Squeeze to release style connectors ONLY. Squeeze where indicated by arrows on both sides of the plastic ring surrounding the quick connect fitting.
6. This step also applies to the Squeeze to release style connectors ONLY. Squeeze where indicated by the arrows on both sides of the plastic ring surrounding the quick connect fitting.
7. This step applies to the Sliding retainer style connectors ONLY. Release the fitting by pressing on one side of the release tab causing it to push in slightly. If the tab does not move, try pressing the tab in from the opposite side. the tab will only move in one direction.
8. This step applies to the Push down TI style connectors ONLY. Release the fitting by pressing on the tabs indicated by the arrow.
9. Pull the connection apart.
10. Wipe off the male pipe end using a clean shop towel.
11. Inspect both ends of the fitting for dirt and burrs.
12. Clean or replace the components as required.

1. Apply a few drops of clean engine oil to the male connection end.
2. Push both sides of the quick connect fitting together in order to cause the retaining feature to snap into place.
3. Once installed, pull on both sides of the quick connect fitting in order to make sure the connection is secure.

Scheme 7

Fuel Filter Replacement

Fuel Tank Draining

Special Tools

1. SA9127E-7 Fuel Pressure/Flow Adapter
2. SA9804E Fuel Tank Drain Hose

For any operation requiring removal of the fuel tank, there should be no more than 11.4 L (3 gal) of fuel remaining. This minimizes the weight of the fuel tank assembly and eases handling. The fuel level can be determined by reading the fuel level gauge. A reading below 1/4 full indicates that no more than 11.4 L (3 gal) are remaining.

Using The Fuel Pump

Using the fuel pump to drain the tank is the easiest procedure if the fuel pump is operable. The fuel can be pumped out with the vehicle on the ground or on a hoist.

On The Ground

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Disconnect the fuel feed quick connect fitting from the fuel rail. Refer «Metal Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__metal-collar-quick-connect-fitting-service) .
3. Install the 3/8 in. x 1/4 in fitting from the SA9127E-7 Fuel Pressure/Flow Adapter into the fuel feed quick connect fitting.
4. Connect a suitable drain hose to the other end of the adapter and connect the drain hose to a certified fuel handling cart.
5. Connect a scan tool to the vehicle diagnostic connector and turn the ignition ON.
6. Energize the fuel pump using the scan tool.
7. Pump out the fuel until no more than 1/4 tank of fuel remains.

On The Hoist

1. Connect a scan tool to the vehicle diagnostic connector and turn the ignition ON.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
3. Raise the vehicle on a hoist to a comfortable working height, keeping the scan tool outside of the vehicle and accessible from under the car.
4. Disconnect the fuel tank fuel feed line quick connect fitting from the chassis fuel feed pipe. Refer «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
5. Install the 3/8 in. x 1/4 in fitting from the SA9127E-7 Fuel Pressure/Flow Adapter into the fuel feed quick connect fitting.
6. Connect a suitable drain hose to the other end of the adapter and connect the drain hose to a certified fuel handling cart.
7. Energize the fuel pump using the scan tool.
8. Pump out the fuel until no more than 1/4 tank of fuel remains.

Siphoning The Fuel Tank

If the fuel pump is inoperative, the tank can be drained by siphoning from the tank. A suitable means is through the fuel fill pipe with the correct type and stiffness of tubing as used with the SA9804E Fuel Tank Drain Hose.

1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
2. Open the fuel fill door and remove the gas cap.
3. Insert the siphon hose guide/funnel into the fuel fill pipe opening.
4. Insert the hose into the guide funnel and into the fuel fill pipe. Some resistance may be encountered when the tip of the siphon hose reaches the inlet check valve. Repeated probing may be necessary to slide the hose tip through the check valve cage.
5. Begin the fuel siphoning process. Place the fuel into an approved fuel container.
6. Remove the siphon hose from the fuel fill pipe after draining is complete.

1. Ensure that the fuel level in the tank is less than 1/4 full. If necessary, drain the fuel tank to at least this level. Refer to «Fuel Tank Draining»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-draining) .
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
3. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
4. Raise and support the vehicle . Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
5. Remove the exhaust system. Refer to «Exhaust Muffler Replacement (N10-Left Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (NB5)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (N10-Right Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) .
6. Remove the propeller shaft. Refer to «Propeller Shaft Replacement»(/chevrolet/captiva/i-2011-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
7. Place a suitable container under the fuel line connection in order to catch any dripping fuel.
8. Remove the evaporative emission canister. Refer to «Evaporative Emission Canister Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
9. Disconnect the chassis fuel supply line (2) from the fuel tank.
10. Disconnect the fuel filler tube, EVAP vent hose, and fresh air hose from the fuel tank.
11. Disconnect the fuel tank electrical connector and remove the electrical connector retainer from the rear frame.
12. Using a suitable adjustable jack, support the fuel tank.
13. Remove the fuel tank strap nuts and lower the fuel tank straps.
14. Lower the front of the fuel tank (with shield), and pull the tank forward to clear the rear drive module.
15. If replacing the fuel tank, remove the fuel tank module assemblies. Refer to «Fuel Tank Fuel Pump Module Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , and «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
16. If replacing the fuel tank, remove the heat shield, hoses and wiring harness and transfer to the new tank.

1. If previously removed, install the fuel tank module assemblies. Refer to «Fuel Tank Fuel Pump Module Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , and «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
2. Using a suitable adjustable jack, install the fuel tank heat shield and fuel tank assembly to the vehicle.
3. Install the fuel tank straps and the fuel tank strap-to-body nuts and tighten to 20 N.m (15 lb ft).
4. Connect the fuel tank electrical connector and install the electrical connector retainer to the rear frame.
5. Connect the EVAP vent, and fresh air hoses to the fuel tank.
6. Connect the fuel filler tube to the fuel tank. Tighten the fuel filler tube clamp to 5 N.m (44 lb in).
7. Connect the chassis fuel supply line (2) to the fuel tank.
8. Install the evaporative emission canister. Refer to «Evaporative Emission Canister Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
9. Install the propeller shaft. Refer to «Propeller Shaft Replacement»(/chevrolet/captiva/i-2011-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
10. Install the exhaust system. Refer to «Exhaust Muffler Replacement (N10-Left Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (NB5)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (N10-Right Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) .
11. Lower the vehicle .
12. Fill the fuel tank with gasoline.
13. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
14. Prime the fuel system: Cycle the ignition ON for 5 seconds and then OFF for 10 seconds. Repeat the previous step twice. Crank the engine until it starts. The maximum starter motor cranking time is 20 seconds. If the engine does not start, repeat steps 14.1-14.3.

1. Ensure that the fuel level in the tank is less than 1/4 full. If necessary, drain the fuel tank to at least this level. Refer to «Fuel Tank Draining»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-draining) .
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
3. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
4. Raise and support the vehicle . Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
5. Remove the exhaust system. Refer to «Exhaust Muffler Replacement (N10-Left Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (NB5)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (N10-Right Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) .
6. Disconnect the canister vent valve electrical connectors.
7. Disconnect the vent hose from the canister filter.
8. Disconnect the fuel tank vent pipe from the evaporative emission canister.
9. Disconnect the chassis fuel supply line (2) from the fuel tank.
10. Disconnect the fuel filler tube, EVAP vent hose, and fresh air hose from the fuel tank.
11. Disconnect the fuel tank electrical connector and remove the electrical connector retainer from the rear frame.
12. Support the fuel tank using a suitable jack.
13. Remove the fuel tank strap nuts, and lower the fuel tank straps.
14. Lower the fuel tank from the underbody of the vehicle.
15. If replacing the fuel tank, remove the fuel tank module assemblies. Refer to «Fuel Tank Fuel Pump Module Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , and «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
16. If replacing the fuel tank, remove the heat shield, hoses and wiring harness, and transfer to the new tank.

1. If previously removed, install the fuel tank module assemblies. Refer to «Fuel Tank Fuel Pump Module Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , and «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
2. Using an adjustable jack, slowly raise and reposition the fuel tank (3) in order to install the tank to the vehicle.
3. Install the fuel tank straps and the fuel tank strap-to-body nuts and tighten to 20 N.m (15 lb ft).
4. Connect the fuel tank electrical connector and install the electrical connector retainer to the rear frame.
5. Connect the EVAP vent, and fresh air hoses to the fuel tank.
6. Connect the fuel filler tube to the fuel tank. Tighten the fuel filler tube clamp to 5 N.m (44 lb in).
7. Connect the chassis fuel supply line (2) to the fuel tank.
8. Connect the fuel tank vent pipe to the evaporative emission canister.
9. Connect the vent hose to the canister filter.
10. Connect the canister vent valve electrical connector.
11. Install the exhaust system. Refer to «Exhaust Muffler Replacement (N10-Left Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (NB5)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Muffler Replacement (N10-Right Side)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) .
12. Lower the vehicle .
13. Fill the fuel tank with gasoline.
14. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
15. Prime the fuel system: Cycle the ignition ON for 5 seconds and then OFF for 10 seconds. Repeat the previous step twice. Crank the engine until it starts. The maximum starter motor cranking time is 20 seconds. If the engine does not start, repeat steps 15.1-15.3.

Fuel System Cleaning

Special Tools

SA9127E-7 Fuel Pressure/Flow Adapter

After it is determined that the fuel system is contaminated, the following procedure to clean it is recommended.

1. Place the vehicle on a hoist and open the hood.
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
3. Remove the fuel tank. Refer to «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) , «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
4. Disconnect the fuel feed line at the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__metal-collar-quick-connect-fitting-service) .
5. With compressed air, blow out the fuel feed. Catch the fuel in a container at the opposite end of the line.
6. Remove the fuel tank modules. Refer to «Fuel Tank Fuel Pump Module Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , and/or «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
7. Inspect the inlet filter on the primary pump. If plugged or damaged, the fuel pump module must be replaced.
8. Flush the tank with hot water for at least 6 minutes. Invert and drain. All metal chips/debris must be removed from the tank prior to installation.
9. Install the fuel pump modules to the fuel tank using a new fuel pump seal. Do not connect the fuel feed line to the new filter.
10. Install the fuel tank to the vehicle.
11. Connect the fuel line to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__metal-collar-quick-connect-fitting-service) .
12. Put at least 22.7 liters (6 gallons) of clean fuel into the fuel tank.
13. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/captiva/i-2011-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
14. Connect a scan tool to the vehicle and turn the ignition ON.
15. Raise the vehicle on a hoist and install the male quick connect adapter SA9127E-7 fuel pressure/flow adapter into the fuel feed line.
16. Install the drain hose to the adapter and place the other end in an approved container.
17. Energize the fuel pump with the scan tool for 1-2 minutes. Refer to Energizing the Fuel Pump. This will pump about 1.9 liters (2 quarts) of fuel and purge any debris in the fuel pump.
18. Disconnect the fuel drain hose adapter at the fuel feed line and connect the fuel line to the fuel filter.
19. Energize the fuel pump and check all connections for leaks.
20. De-energize the pump, lower the vehicle, and start the engine.

Fuel Tank Fuel Pump Module Replacement

Special Tools

J-45722 Fuel Tank Sender Wrench

For equivalent regional tools, refer to Special Tools (Diagnostic Tools) .

1. Remove the fuel tank. Refer to «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) , «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Disconnect the crossover tube from the secondary fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
3. Disconnect the electrical connectors (1).
4. Disconnect the fuel and evaporative emission lines (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
5. Using the J-45722 wrench , remove the cam lock ring (1) by turning counterclockwise.
6. Remove the primary fuel tank module (1) and the O-ring (2).
7. If replacing the fuel pump module only, remove the primary fuel level sensor. Refer to «Primary Fuel Level Sensor Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

1. If replacing the fuel pump module only, install the primary fuel level sensor. Refer to «Primary Fuel Level Sensor Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Install a NEW O-ring (2) and the primary fuel tank module (1).
3. Using the J-45722 wrench , install the cam lock ring (1) by turning clockwise.
4. Connect the electrical connectors (1).
5. Connect the fuel and evaporative emission lines (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
6. Connect the crossover tube to the secondary fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
7. Install the fuel tank. Refer to «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) , «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Fuel Tank Fuel Pump Module Replacement - Secondary

Special Tools

CH-48482 Fuel Tank Sender Wrench

For equivalent region tools, refer to Special Tools (Diagnostic Tools) .

1. Remove the fuel tank. Refer to «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) , «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
2. Disconnect the electrical connector (1).
3. Disconnect the evaporative emission line (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
4. Using the CH-48482 wrench , remove the cam lock ring (1) by turning counterclockwise.
5. Partially raise the secondary fuel pump module and disconnect the crossover tube (1) by squeezing the plastic retaining tabs (2).
6. Remove the secondary fuel tank module (1) and the O-ring (2).

1. Partially install the secondary fuel pump module and connect the crossover tube (1) by sliding into position.
2. Install a NEW O-ring (2) and the secondary fuel tank module (1).
3. Using the CH-48482 wrench , install the cam lock ring (1) by turning clockwise.
4. Connect the electrical connector (1).
5. Connect the evaporative emission line (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
6. Install the fuel tank. Refer to «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) , «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .

1. Open the rear compartment floor stowage compartment cover.
2. Remove the spare tire spacer (1).
3. Remove the rear compartment floor stowage compartment. Refer to «Rear Compartment Floor Stowage Compartment Replacement»(/chevrolet/captiva/i-2011-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
4. Disconnect the body wiring harness electrical connector (1) from the fuel pump flow control module.
5. Remove the fuel pump flow control module bolts (1).
6. Slide the fuel pump flow control module towards the driver side of the vehicle.
7. Remove the fuel pump flow control module (2) from the vehicle.

1. Install the fuel pump flow control module (2) to the vehicle.
2. Slide the fuel pump flow control module towards the passenger side of the vehicle.
3. Install the fuel pump flow control module bolts (1). Tighten Tighten the bolts to 10 N.m (89 lb in).
4. Connect the body wiring harness electrical connector (1) to the fuel pump flow control module.
5. Install the rear compartment floor stowage compartment. Refer to «Rear Compartment Floor Stowage Compartment Replacement»(/chevrolet/captiva/i-2011-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
6. Install the spare tire spacer (1).
7. Close the rear compartment floor stowage compartment cover.
8. Program the fuel pump flow control module. Refer to «Control Module References»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) .

1. Remove the fuel tank. Refer to «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) , «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Disconnect the fuel tank wiring harness electrical connector (1) from the fuel tank pressure sensor.
3. Disengage the retaining tab (1) securing the fuel tank pressure sensor.
4. Carefully lift and remove the fuel tank pressure sensor (2) from the fuel pump module.

1. Install the fuel tank pressure sensor (2) to the fuel pump module assembly until the sensor engages the retaining tab (1).
2. Connect the fuel tank wiring harness electrical connector (1) to the fuel tank pressure sensor.
3. Install the fuel tank. Refer to «Fuel Tank Replacement (AWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) , «Fuel Tank Replacement (FWD)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Scheme 8

Primary Fuel Level Sensor Replacement

1. Remove the fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
2. Disconnect the fuel level sender electrical connector (1) from the fuel tank fuel pump module cover.
3. Remove the fuel level sensor wiring from the retaining feature (2) on the fuel tank fuel pump module.
4. Push in the fuel level sensor retainers (1), in order to disengage the retainers from the module.
5. Slide the fuel level sensor (2) up, out of the fuel tank fuel pump module.

1. Position the fuel level sensor (2) to the fuel tank fuel pump module.
2. Push the fuel level sensor down until the retainers (1) engage the fuel tank fuel pump module.
3. Connect the fuel level sender electrical connector (1) to the fuel tank fuel pump module cover.
4. Install the fuel level sensor wiring to the retaining feature (2) on the fuel tank fuel pump module.
5. Install the fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement - Secondary»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .

Scheme 9

Fuel Tank Filler Pipe Replacement

Scheme 10

Fuel Pump Cover Replacement

Scheme 11

Fuel Feed Pipe Replacement (With Direct Injection)

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
3. Disconnect the body wiring harness electrical connector (1) from the fuel pressure sensor (2).
4. Wrap a shop towel around the fuel pressure sensor fitting in order to absorb any fuel that may leak out.
5. Remove the fuel pressure sensor (1) from the fuel line.
6. Remove and discard the fuel pressure sensor O-ring seal (2).

1. Lubricate a NEW fuel pressure sensor O-ring seal with clean engine oil.
2. Install the NEW fuel pressure sensor O-ring seal (2) onto the fuel line fitting.
3. Install the fuel pressure sensor (1) to the fuel line. Tighten the sensor to 15 N.m (11 lb ft).
4. Connect the body wiring harness electrical connector (1) to the fuel pressure sensor (2).
5. Lower the vehicle.
6. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.

Scheme 12

Fuel Line Replacement - Chassis

Scheme 13

Fuel Feed Intermediate Pipe Replacement

Fuel Pump Replacement

Special Tools

EN-48896 High Pressure Fuel Pump Installation Alignment Gauge

1. Relieve the low and high side fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Disconnect the engine wiring harness electrical connector from the high pressure fuel pump.
3. Remove the low pressure feed pipe. Refer to «Fuel Feed Pipe Replacement (With Direct Injection)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
4. Remove the high pressure pipe. Refer to «Fuel Feed Intermediate Pipe Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) . Discard this pipe.
5. Remove and discard the high pressure fuel pump bolts (1).
6. Remove the high pressure fuel pump (2).
7. Remove and discard the high pressure fuel pump O-ring (3).
8. Remove and discard the high pressure fuel pump gasket (4).
9. Remove the high pressure fuel pump roller lifter (5).

1. Use the EN-48896 alignment gauge to ensure that the camshaft lobe is in the base circle position. At base circle the tool will be flush with the head.
2. Lubricate the high pressure fuel pump cylinder head bore and roller lifter with camshaft prelube GM P/N 12345501 (Canadian P/N 992704) or equivalent.
3. Install the high pressure fuel pump roller lifter (5).
4. Install a NEW high pressure fuel pump O-ring (3).
5. Position the NEW high pressure fuel pump gasket (4) and bolts (1) to the fuel pump.
6. Install the high pressure fuel pump (2). Force will be required while hand tightening the bolts.
7. Tighten the high pressure fuel pump retaining bolts to 15 N.m (11 lb ft).
8. Ensure the high pressure fuel pump and fuel rail fittings are clean prior to assembly.
9. Install a NEW high pressure fuel pipe. Refer to «Fuel Feed Intermediate Pipe Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
10. Install the fuel feed pipe to the high pressure fuel pump. Refer to «Fuel Feed Pipe Replacement (With Direct Injection)»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
11. Connect the high pressure fuel pump wiring harness.
12. Install the fuel tank cap.
13. Inspect for leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
14. Install the pressure relief cap to the fuel feed pipe.
15. Install the high pressure fuel pump cover. Refer to «Fuel Pump Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Scheme 14

Fuel Injection Fuel Rail Fuel Pressure Sensor Replacement

Scheme 15

Fuel Injector and Fuel Rail Replacement

1. Relieve the high side fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__fuel-pressure-relief) .
2. Remove the fuel injection fuel rail assembly. Refer to «Fuel Injector and Fuel Rail Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
3. Remove and discard the fuel injector retainers (1).
4. Clean and inspect the fuel rail and injectors. Refer to «Fuel Rail and Injectors Cleaning and Inspection»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-off-vehicle-overhaul__fuel-rail-and-injectors-cleaning-and) .

1. Install NEW fuel injector retainers (1).
2. Install the fuel injection fuel rail assembly. Refer to «Fuel Injector and Fuel Rail Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Scheme 16

Evaporative Emission Canister Purge Solenoid Valve Replacement

Scheme 17

Evaporative Emission Canister Purge Tube Replacement

1. Remove the evaporative emission (EVAP) canister. Refer to «Evaporative Emission Canister Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Rotate the EVAP canister vent solenoid valve (1) clockwise.
3. Remove the EVAP canister vent solenoid valve (1) from the EVAP canister.

1. Install the EVAP canister vent solenoid valve (1) to the EVAP canister.
2. Rotate the EVAP canister vent solenoid valve (1) counterclockwise until it reaches the positive stop.
3. Install the EVAP canister. Refer to «Evaporative Emission Canister Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Scheme 18

Evaporative Emission Line Replacement - Canister to Tank

Scheme 19

Evaporative Emission Line Replacement - Engine to Chassis

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
2. Disconnect the EVAP canister fresh air hose/pipe from the fuel tank fresh air hose/pipe (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
3. Disconnect the EVAP canister vent hose/pipe from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
4. Disconnect the EVAP canister purge hose/pipe (1) from the EVAP canister.
5. Remove the EVAP canister-to-underbody nuts (3).
6. Lower the EVAP canister.
7. Disconnect the EVAP vent solenoid electrical connector (1).
8. Remove the EVAP canister (4) from the vehicle.

1. Connect the EVAP vent solenoid electrical connector (1).
2. Install the EVAP canister (4) to the underbody of the vehicle.
3. Install the EVAP canister-to-underbody nuts (3). Tighten Tighten the nuts to 9 N.m (80 lb in).
4. Connect the EVAP canister purge hose/pipe (1) to the EVAP canister.
5. Connect the EVAP canister vent hose/pipe (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
6. Connect the EVAP canister fresh air hose/pipe to the fuel tank fresh air hose/pipe (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
7. Lower the vehicle.

Evaporative Emission System Cleaning

Special Tools

CH-41413 Evaporative Pressure and Purge Station

For equivalent regional tools, refer to Special Tools (Diagnostic Tools) .

Inspection Procedure

1. Turn OFF the ignition.
2. Remove the EVAP canister purge solenoid valve. Refer to «Evaporative Emission Canister Purge Solenoid Valve Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
3. Lightly tap the EVAP canister purge solenoid valve on a hard surface.
4. Inspect for carbon particles exiting either of the vacuum ports. If no carbon particles were detected, but a blockage was detected during a diagnostic procedure, install the original EVAP canister purge solenoid valve. Continue with the cleaning procedure. If carbon particles are found during the inspection procedure, continue with the cleaning procedure. If a diagnostic procedure directed you to replace the EVAP canister purge solenoid valve and no carbon particles were detected, replace the EVAP canister purge solenoid valve. Return to the published service procedure.

Cleaning Procedure

1. Raise and suitable support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
2. Remove the EVAP canister. Refer to «Evaporative Emission Canister Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
3. Turn OFF the main valve on the CH-41413 station.
4. Disconnect the hose from the diagnostic station pressure regulator.
5. Using a section of vacuum hose, connect one end onto the EVAP pressure/purge diagnostic station pressure regulator.
6. Connect the other end of the vacuum hose to the canister side of the purge pipe.
7. Turn ON the main nitrogen cylinder valve and continue to discharge nitrogen for 15 seconds.
8. If the nitrogen does not clear the blockage, replace the purge pipe.
9. Return the EVAP pressure/purge diagnostic station to the stations original condition.
10. Install a NEW EVAP canister. Refer to «Evaporative Emission Canister Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
11. Lower the vehicle.
12. Install a NEW EVAP canister purge solenoid valve. Refer to «Evaporative Emission Canister Purge Solenoid Valve Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
13. Return to the diagnostic table that sent you here.

1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle) .
3. Disconnect the engine wiring harness electrical connector(s) (1) from the ignition coil(s).
4. Remove the ignition coil bolt(s).
5. Remove the ignition coil(s).

1. Install the ignition coil(s).
2. Install the ignition coil bolt(s). Tighten Tighten the bolt(s) to 10 N.m (89 lb in).
3. Connect the engine wiring harness electrical connector(s) (1) to the ignition coil(s).
4. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle) .
5. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

1. Remove the ignition coil(s). Refer to «Ignition Coil Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Remove the spark plugs using a 5/8 inch spark plug socket.

1. Install the spark plugs. Specification The spark plug gap is 1.0 mm (0.040 in). Tighten Tighten the plugs to 20 N.m (15 lb ft).
2. Install the ignition coil(s). Refer to «Ignition Coil Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Spark Plug Usage

1. Ensure that the correct spark plug is installed. An incorrect spark plug causes driveability conditions. Refer to the Electronic Parts Catalog.
2. Ensure that the spark plug has the correct heat range. An incorrect heat range causes the following conditions: Spark plug fouling - colder plug Pre-ignition causing spark plug and/or engine damage - hotter plug

Spark Plug Inspection

1. Inspect the terminal post (1) for damage. Inspect for a bent or broken terminal post (1). Test for a loose terminal post (1) by twisting and pulling the post. The terminal post (1) should NOT move.
2. Inspect the insulator (2) for flashover or carbon tracking, soot. This is caused by the electrical charge traveling across the insulator (2) between the terminal post (1) and ground. Inspect for the following conditions: Inspect the spark plug boot for damage. Inspect the spark plug recess area of the cylinder head for moisture, such as oil, coolant, or water. A spark plug boot that is saturated causes arcing to ground.
3. Inspect the insulator (2) for cracks. All or part of the electrical charge may arc through the crack instead of the electrodes (3, 4).
4. Inspect for evidence of improper arcing. Measure the gap between the center electrode (4) and the side electrode (3) terminals. Refer to «Ignition System Specifications»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-specifications__ignition-system-specifications) . An excessively wide electrode gap can prevent correct spark plug operation. Inspect for the correct spark plug torque. Refer to «Ignition System Specifications»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-specifications__ignition-system-specifications) . Insufficient torque can prevent correct spark plug operation. An over torqued spark plug, causes the insulator (2) to crack. Inspect for signs of tracking that occurred near the insulator tip instead of the center electrode (4). Inspect for a broken or worn side electrode (3). Inspect for a broken, worn, or loose center electrode (4) by shaking the spark plug. A rattling sound indicates internal damage. A loose center electrode (4) reduces the spark intensity. Inspect for bridged electrodes (3, 4). Deposits on the electrodes (3, 4) reduce or eliminates the gap. Inspect for worn or missing platinum pads on the electrodes (3, 4) If equipped. Inspect for excessive fouling.
5. Inspect the spark plug recess area of the cylinder head for debris. Dirty or damaged threads can cause the spark plug not to seat correctly during installation.

Spark Plug Visual Inspection

1. Normal operation-Brown to grayish-tan with small amounts of white powdery deposits are normal combustion by-products from fuels with additives.
2. Carbon Fouled-Dry, fluffy black carbon, or soot caused by the following conditions: Rich fuel mixtures Leaking fuel injectors Excessive fuel pressure Restricted air filter element Incorrect combustion Reduced ignition system voltage output Weak coils Worn ignition wires Incorrect spark plug gap Excessive idling or slow speeds under light loads can keep spark plug temperatures so low that normal combustion deposits may not burn off.
3. Deposit Fouling-Oil, coolant, or additives that include substances such as silicone, very white coating, reduces the spark intensity. Most powdery deposits will not effect spark intensity unless they form into a glazing over the electrode.

Scheme 20

Crankshaft Position Sensor Replacement

Scheme 21

Camshaft Position Sensor Replacement - Intake

Scheme 22

Camshaft Position Sensor Replacement - Exhaust

1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle) .
3. Disconnect the engine wiring harness electrical connectors (2, 3) from the appropriate camshaft position (CMP) actuator solenoid valve.
4. Remove the exhaust CMP actuator solenoid valve bolt and valve (1), if required.
5. Remove the intake CMP actuator solenoid valve bolt and valve (2), if required.
6. Inspect the CMP actuator solenoid valve O-ring seals for damage, replace as necessary.

1. Lubricate the CMP actuator solenoid valve O-ring seals with clean engine oil.
2. Install the intake CMP actuator solenoid valve (2) and bolt, if required. Tighten the bolt to 10 N.m (89 lb in).
3. Install the exhaust CMP actuator solenoid valve (1) and bolt, if required. Tighten the bolt to 10 N.m (89 lb in).
4. Connect the engine wiring harness electrical connectors (2, 3) to the appropriate CMP actuator solenoid valve.
5. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle) .
6. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

1. Hoist and raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
2. Disconnect the engine wiring harness electrical connector (3) from the knock sensor electrical connector (4).
3. Remove the knock sensor electrical connector (4) from the oil level indicator tube bracket.
4. Remove the knock sensor bolt.
5. Remove the knock sensor.

1. Install the knock sensor.
2. Install the knock sensor bolt and tighten to 25 N.m (18 lb ft).
3. Install the knock sensor electrical connector (4) to the oil level indicator tube bracket.
4. Connect the engine wiring harness electrical connector (3) to the knock sensor electrical connector (4).

Scheme 23

Air Cleaner Element Replacement

Scheme 24

Air Cleaner Assembly Replacement

Scheme 25

Air Cleaner Outlet Duct Replacement

1. Remove the front bumper fascia. Refer to «Front Bumper Fascia Replacement (Base)»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
2. Remove the air cleaner inlet duct bolts (1).
3. Pull on and dislocate the air cleaner inlet duct (1) from the air cleaner assembly and vehicle body grommet.

1. Position the air cleaner inlet duct (1) in the vehicle body grommet and air cleaner assembly.
2. Install the air cleaner inlet duct bolts (1). Tighten Tighten the bolts to 6 N.m (53 lb in).
3. Install the front bumper fascia. Refer to «Front Bumper Fascia Replacement (Base)»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .

See also:
• Battery Negative Cable Disconnection and Connection
• Control Module References
• Engine Control Module Replacement
• Fastener Caution
• Diagnostic Trouble Code (DTC) List - Vehicle
• Cooling System Draining and Filling (Static Fill)
• Cooling System Draining and Filling (GE 47716)
• Intake Manifold Cover Replacement
• Adhesives, Fluids, Lubricants, and Sealers
• Lifting and Jacking the Vehicle
• Driver Knee Bolster Reinforcement Replacement
• Special Tools (Diagnostic Tools)
• Gasoline/Gasoline Vapors Warning
• Exhaust Muffler Replacement (N10-Left Side)
• Propeller Shaft Replacement
• Battery Disconnect Warning
• Special Tools (Diagnostic Tools)
• Rear Compartment Floor Stowage Compartment Replacement
• Fuel Tank Fuel Pump Module Replacement
• Rear Wheelhouse Panel Liner Replacement
• Fuel Pressure Relief
• Intake Manifold Cover Replacement
• Metal Collar Quick Connect Fitting Service
• Adhesives, Fluids, Lubricants, and Sealers
• Fuel Rail and Injectors Removal
• Fuel Rail and Injectors Cleaning and Inspection
• Fuel Rail and Injectors Installation
• Ignition System Specifications
• Front Bumper Fascia Replacement (Base)
• Air Cleaner Outlet Duct Replacement
• Fuel Pressure Relief
• Metal Collar Quick Connect Fitting Service
• Fuel Tank Draining
• Fuel Tank Fuel Pump Module Replacement
