Frame and Underbody Chevrolet Captiva I рестайлинг

Fastener Tightening Specifications

Fastener Tightening Specifications

Alignment Checking

Use a measuring tram gauge as an accurate method of determining the alignment of the underbody. The tram gauge set required to perform the recommended measuring checks must include a vertical pointer capable of reaching 457 mm (18 in).

The following 2 types of measurement may be made using a tram gauge

1. Direct point to point measurements
2. Measurements calculated on a horizontal plane (datum line) parallel to the underbody

Dimensions that are measured to gauge holes are measured to the center of the holes and flush to the adjacent metal surface unless otherwise specified. It is recommended that the diagonal dimensions be cross body checked on both sides in order to verify the dimensional accuracy of the vehicle underbody. Set vertical pointers equally as needed per your application.

Drivetrain and Front Suspension Frame Alignment Check (2.4L South America Only)

Special Tools

L-0906002 Front Suspension Frame Template

For equivalent region tools, refer to Special Tools .

1. Install the L-0906002 template.
2. After checking, remove the special tool.

Drivetrain and Front Suspension Frame Alignment Check (3.0L South America Only)

Special Tools

L-0806002 Front Suspension Frame Template

For equivalent region tools, refer to Special Tools .

1. Install the L-0806002 template.
2. Fit L-0806002 template in the front suspension frame holes, as shown.
3. Fit the rear end of tool in the chassis holes, as shown.
4. After checking, remove the special tool.

Frame Replacement (Except South America)

Special Tools

J 39580 Engine Support Table

Removal Procedure

1. Remove the radiator opening upper cover. Refer to «Radiator Opening Upper Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
2. Secure the radiator, air conditioning condenser, and fan module assembly to the upper tie bar to keep the assembly with the vehicle when the frame is removed.
3. Install the engine support fixture. Refer to «Engine Support Fixture (Except South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle__engine-support-fixture-except-south-america) .
4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
5. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/captiva/i-2011-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
6. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
7. Remove the two push pins securing the front bumper air deflector to the frame. Refer to «Front Bumper Fascia Air Deflector Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
8. Remove both left and right stabilizer shaft insulator clamps. Refer to «Stabilizer Shaft Insulator Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system) .
9. Remove the lower ball joints from the steering knuckles. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
10. Disconnect the steering shaft coupling from the steering gear. Refer to «Steering Shaft Coupling Replacement (NVH - Power, Non-Variable Effort, Hydraulic)»(/chevrolet/captiva/i-2011-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
11. Remove the power steering gear mounting bolts (1) and secure the gear out of the way using mechanic's wire or equivalent. Refer to «Steering Gear Replacement»(/chevrolet/captiva/i-2011-2013/remont/manual-power-steering/#power-steering-system) .
12. Remove the front transmission mount thru bolt.
13. Remove the rear transmission mount bolts from the frame.
14. Lower the vehicle until the frame contacts the J 39580 engine support table.
15. Remove the frame reinforcements. Refer to «Drivetrain and Front Suspension Frame Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
16. Remove the front frame bolts.
17. Raise the vehicle off of the frame.
18. If replacing the frame, remove the lower control arms. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .

Installation Procedure

1. If removed, Install the lower control arms. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
2. Lower the vehicle on to the frame.
3. Install the front frame bolts. Tighten Tighten the bolts to 155 (114 lb ft).
4. Install the frame reinforcement. Refer to «Drivetrain and Front Suspension Frame Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
5. Raise the vehicle off of the J 39580 engine support table.
6. Install the rear transmission mount bolts to the frame. Tighten Tighten the bolts to 50 (37 lb ft).
7. Install the front transmission mount thru bolt. Tighten Tighten the bolt to 110 (81 lb ft).
8. Install the power steering gear mounting bolts (1). Refer to «Steering Gear Replacement»(/chevrolet/captiva/i-2011-2013/remont/manual-power-steering/#power-steering-system) .
9. Install the steering shaft coupling to the steering gear. Refer to «Steering Shaft Coupling Replacement (NVH - Power, Non-Variable Effort, Hydraulic)»(/chevrolet/captiva/i-2011-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
10. Install the lower ball joints to the steering knuckles. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
11. Install both left and right stabilizer shaft insulator clamps. Refer to «Stabilizer Shaft Insulator Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system) .
12. Install the two push pins securing the front bumper air deflector to the frame. Refer to «Front Bumper Fascia Air Deflector Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
13. Install the engine splash shields. Refer to «Engine Splash Shield Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
14. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/captiva/i-2011-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
15. Remove the engine support fixture. Refer to «Engine Support Fixture (Except South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle__engine-support-fixture-except-south-america) .
16. Re2.4Lse the radiator, air conditioning condenser, and fan module assembly from the upper tie bar.
17. Install the radiator opening upper cover. Refer to «Radiator Opening Upper Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
18. Check the wheel alignment. Refer to «Wheel Alignment Measurement»(/chevrolet/captiva/i-2011-2013/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-measurement) .

Frame Replacement (2.4L South America Only)

Special Tools

1. L-0906001 Engine Support Table Adapter
2. L-0806003 Engine Support Bracket
3. L-9703386 Device Placement and Removal of the whole Engine/Transmission/Frame or the front Suspension
4. L-9703392 Hydraulic Jack
5. L-0906002 Front Suspension Frame Template

For equivalent regional tools, refer to Special Tools .

1. Remove the radiator opening upper cover. Refer to «Radiator Opening Upper Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
2. Secure the radiator, air conditioning condenser, and fan module assembly to the upper tie bar to keep the assembly with the vehicle when the frame is removed.
3. Install the engine support fixture. Refer to «Engine Support Fixture (South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle__engine-support-fixture-south-america) .
4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
5. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/captiva/i-2011-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
6. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
7. Remove the two push pins securing the front bumper air deflector to the frame. Refer to «Front Bumper Fascia Air Deflector Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
8. Remove both left and right stabilizer shaft insulator clamps. Refer to «Stabilizer Shaft Insulator Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system) .
9. Remove the lower ball joints from the steering knuckles. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
10. Disconnect the steering shaft coupling from the steering gear. Refer to «Steering Shaft Coupling Replacement (NVH - Power, Non-Variable Effort, Hydraulic)»(/chevrolet/captiva/i-2011-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
11. Remove the power steering gear mounting bolts (1) and secure the gear out of the way using mechanic's wire or equivalent. Refer to «Steering Gear Replacement»(/chevrolet/captiva/i-2011-2013/remont/manual-power-steering/#power-steering-system) .
12. Remove the front transmission mount thru bolt.
13. Remove the rear transmission mount bolts from the frame.
14. Install the tool kit under the vehicle so that the shoe pins are aligned with the front suspension frame holes. Lower the vehicle until the frame contacts the J 39580 engine support table.
15. Remove the frame reinforcements. Refer to «Drivetrain and Front Suspension Frame Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
16. Remove the front frame bolts.
17. Raise the vehicle off of the frame.
18. If replacing the frame, remove the lower control arms. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .

1. If removed, Install the lower control arms. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
2. Lower the vehicle until it is touching the front suspension frame.
3. Install the front frame bolts. Tighten Tighten the bolts to 155 (114 lb ft).
4. Install the frame reinforcement. Refer to «Drivetrain and Front Suspension Frame Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
5. Raise the vehicle off of the J 39580 engine support table.
6. Install the rear transmission mount bolts to the frame. Tighten Tighten the bolts to 50 (37 lb ft).
7. Install the front transmission mount thru bolt. Tighten Tighten the bolt to 110 (81 lb ft).
8. Install the power steering gear mounting bolts (1). Refer to «Steering Gear Replacement»(/chevrolet/captiva/i-2011-2013/remont/manual-power-steering/#power-steering-system) .
9. Install the steering shaft coupling to the steering gear. Refer to «Steering Shaft Coupling Replacement (NVH – Power, Non-Variable Effort, Hydraulic)»(/chevrolet/captiva/i-2011-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
10. Install the lower ball joints to the steering knuckles. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
11. Install both left and right stabilizer shaft insulator clamps. Refer to «Stabilizer Shaft Insulator Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system) .
12. Install the two push pins securing the front bumper air deflector to the frame. Refer to «Front Bumper Fascia Air Deflector Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
13. Install the engine splash shields. Refer to «Engine Splash Shield Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
14. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/captiva/i-2011-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
15. Remove the engine support fixture. Refer to «Engine Support Fixture (Except South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle__engine-support-fixture-except-south-america) , «Engine Support Fixture (South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-24l-repair-instructions-on-vehicle__engine-support-fixture-south-america) .
16. Re2.4Lse the radiator, air conditioning condenser, and fan module assembly from the upper tie bar.
17. Install the radiator opening upper cover. Refer to «Radiator Opening Upper Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
18. Check the wheel alignment. Refer to «Wheel Alignment Measurement»(/chevrolet/captiva/i-2011-2013/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-measurement) .

Frame Replacement (3.0L South America Only)

Special Tools

1. L-0806003 Engine Support Bracket
2. L-9703386 Device Placement and Removal of the whole Engine/Transmission/Frame or the front Suspension
3. L-9703392 Hydraulic Jack
4. L-0906002 Front Suspension Frame Template

For equivalent regional tools, refer to Special Tools .

1. Remove the radiator opening upper cover. Refer to «Radiator Opening Upper Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
2. Secure the radiator, air conditioning condenser, and fan module assembly to the upper tie bar to keep the assembly with the vehicle when the frame is removed.
3. Install the engine support fixture. Refer to «Engine Support Fixture (South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-30l-repair-instructions-on-vehicle__engine-support-fixture-south-america) .
4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
5. Remove the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/captiva/i-2011-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
6. Remove the engine splash shields. Refer to «Engine Splash Shield Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
7. Remove the catalytic converters. Refer to «Catalytic Converter Replacement - Left Side (3.0L)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) , and «Catalytic Converter Replacement - Right Side (3.0L)»(/chevrolet/captiva/i-2011-2013/remont/exhaust/#engine-exhaust-system) .
8. Remove the clamps from the power steering hoses.
9. Remove the clamps from the bumper.
10. If equipped with All-Wheel Drive (AWD), remove the propeller shaft. Refer to «Propeller Shaft Replacement»(/chevrolet/captiva/i-2011-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
11. Remove the two push pins securing the front bumper air deflector to the frame. Refer to «Front Bumper Fascia Air Deflector Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
12. Remove both left and right stabilizer shaft insulator clamps. Refer to «Stabilizer Shaft Insulator Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system) .
13. Remove the lower ball joints from the steering knuckles. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
14. Disconnect the steering shaft coupling from the steering gear. Refer to «Steering Shaft Coupling Replacement (NVH – Power, Non-Variable Effort, Hydraulic)»(/chevrolet/captiva/i-2011-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
15. Remove the power steering gear mounting bolts (1) and secure the gear out of the way using mechanic's wire or equivalent. Refer to «Steering Gear Replacement»(/chevrolet/captiva/i-2011-2013/remont/manual-power-steering/#power-steering-system) .
16. Remove the front transmission mount through bolt.
17. Remove the rear transmission mount bolts from the frame.
18. Install the tool kit under the vehicle so that the shoe pins are aligned with the front suspension frame holes. Lower the vehicle until the frame contacts the J 39580 engine support table.
19. Remove the frame reinforcements. Refer to «Drivetrain and Front Suspension Frame Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
20. Remove the front frame bolts.
21. Raise the vehicle off of the frame.
22. If replacing the frame, remove the lower control arms. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .

1. If removed, Install the lower control arms. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
2. Lower the vehicle until it is touching the front suspension frame.
3. Install the front frame bolts. Tighten Tighten the bolts to 155 (114 lb ft).
4. Install the frame reinforcement. Refer to «Drivetrain and Front Suspension Frame Reinforcement Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
5. Raise the vehicle off of the tool kit.
6. If equipped with All-Wheel Drive (AWD), install the propeller shaft. Refer to «Propeller Shaft Replacement»(/chevrolet/captiva/i-2011-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
7. Install the rear transmission mount bolts to the frame. Tighten Tighten the bolts to 50 (37 lb ft).
8. Install the front transmission mount through bolt. Tighten Tighten the bolt to 110 (81 lb ft).
9. Install the power steering gear mounting bolts (1). Refer to «Steering Gear Replacement»(/chevrolet/captiva/i-2011-2013/remont/manual-power-steering/#power-steering-system) .
10. Install the steering shaft coupling to the steering gear. Refer to «Steering Shaft Coupling Replacement (NVH – Power, Non-Variable Effort, Hydraulic)»(/chevrolet/captiva/i-2011-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
11. Install the lower ball joints to the steering knuckles. Refer to «Lower Control Arm Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
12. Install both left and right stabilizer shaft insulator clamps. Refer to «Stabilizer Shaft Insulator Replacement»(/chevrolet/captiva/i-2011-2013/remont/suspension-front/#front-suspension-system) .
13. Install the two push pins securing the front bumper air deflector to the frame. Refer to «Front Bumper Fascia Air Deflector Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
14. Install the engine splash shields. Refer to «Engine Splash Shield Replacement»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
15. Install the tire and wheel assemblies. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/captiva/i-2011-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
16. Remove the engine support fixture. Refer to «Engine Support Fixture (South America)»(/chevrolet/captiva/i-2011-2013/remont/mechanical/#engine-mechanical-30l-repair-instructions-on-vehicle__engine-support-fixture-south-america) .
17. Re2.4Lse the radiator, air conditioning condenser, and fan module assembly from the upper tie bar.
18. Install the radiator opening upper cover, if equipped. Refer to «Radiator Opening Upper Cover Replacement»(/chevrolet/captiva/i-2011-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
19. Check the wheel alignment. Refer to «Wheel Alignment Measurement»(/chevrolet/captiva/i-2011-2013/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-measurement) .

Drivetrain and Front Suspension Frame Insulator Replacement

Special Tools

CH-47672-A Frame Insulator Remover/Installer

For equivalent regional tools, refer to Special Tools .

1. Remove the frame from the vehicle. Refer to «Frame Replacement (Except South America)»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody__frame-replacement-except-south-america) , «Frame Replacement (2.4L South America Only)»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody__frame-replacement-24l-south-america-only) , «Frame Replacement (3.0L South America Only)»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody__frame-replacement-30l-south-america-only) .
2. Remove the upper frame insulator (1).
3. For the removal of a front frame insulator, assemble the CH-47672-A press as shown.
4. Use the CH-47672-A press to remove the front frame insulator from the frame.
5. To remove a rear insulator, cut out frame insulator core (1) from frame insulator (2).
6. Remove the rear frame insulator core (1) from the outer frame insulator (2).
7. Remove the rear frame insulator from the drivetrain and front suspension frame using a chisel or equivalent.

1. C2.4Ln the frame insulator opening.
2. Apply thin coat of rubber lubricant GM P/N 1051717 (Canadian P/N 5728223), or equivalent to the inside of the frame insulator opening and to the insulator.
3. Install the CH-47672-A clamp to the bushing. Align the clamp screws with the split portion of the bushing. Position the edge of the clamp where the bushing chamfer blends with the straight section of the bushing. Alternately tighten the clamp screws until the split edges of the bushing are parallel and almost touching.
4. Install the frame insulator to the front frame opening with the insulator splits aligned in a forward and rearward direction relative to the vehicle.
5. Assemble the CH-47672-A clamp and the frame insulator as shown to the frame.
6. Use the CH-47672-A press to begin installing the frame insulator into the frame. STOP and remove the CH-47672-A clamp (1) before the clamp becomes trapped between the CH-47672-A press and frame.
7. Use the CH-47672-A press to finish installing the frame insulator into the frame.
8. Remove the CH-47672-A remover/installer from the insulator and frame. Inspect and confirm that the insulator (2) is in direct contact with the frame (1).
9. Install the upper frame insulator (1)
10. Install the frame to the vehicle. Refer to «Frame Replacement (Except South America)»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody__frame-replacement-except-south-america) , «Frame Replacement (2.4L South America Only)»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody__frame-replacement-24l-south-america-only) , «Frame Replacement (3.0L South America Only)»(/chevrolet/captiva/i-2011-2013/remont/frames-subframes-crossmembers/#frame-and-underbody__frame-replacement-30l-south-america-only) .

Scheme 1

Front Wheelhouse Liner Replacement

Scheme 2

Rear Wheelhouse Panel Liner Replacement

Scheme 3

Engine Splash Shield Replacement

Scheme 4

Assist Step Replacement

Scheme 5

Drivetrain and Front Suspension Frame Reinforcement Replacement

Underbody Inspection

1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/captiva/i-2011-2013/remont/ignition-switchsteering-lock/#general-information) .
2. Check for obvious deterioration on the floor pan.
3. Check for loose dirt and corrosion around the inside of the floor pan reinforcement member access holes. This is the first indication that corrosion may exist in hidden areas. Perform all repairs before the final c2.4Lning and protective treatment is performed.
4. Using a chisel, ensure that the drain provisions in the floor pan reinforcement members are open. Open the drain holes in the body side panels using a punch and a drift.

Scheme 6

Trailer Hitch Replacement

Special Tools

Illustration Tool Number/ Description CH-47672 Cradle Bushing Remover/Installer J-39580 J-9703386 J-9703392 L-0806003 L-0906001 L-0906002 L-0906003 L-0906004 Engine Support Table J-43828 Ball Joint Remover SA9140E Torque Angle Gauge

Scheme 7

Scheme 8

Scheme 9

Scheme 10

See also:
• Radiator Opening Upper Cover Replacement
• Engine Support Fixture (Except South America)
• Lifting and Jacking the Vehicle
• Tire and Wheel Removal and Installation
• Stabilizer Shaft Insulator Replacement
• Lower Control Arm Replacement
• Steering Shaft Coupling Replacement (NVH - Power, Non-Variable Effort, Hydraulic)
• Steering Gear Replacement
• Fastener Caution
• Wheel Alignment Measurement
• Engine Support Fixture (South America)
• Engine Support Fixture (South America)
• Catalytic Converter Replacement - Left Side (3.0L)
• Propeller Shaft Replacement
• Special Tools
• Engine Splash Shield Replacement
• Drivetrain and Front Suspension Frame Alignment Check - South America (2.4L)
• Frame Replacement (Except South America)
• Frame Replacement (2.4L South America Only)
• Frame Replacement (3.0L South America Only)
