Accessory AC and DC Power Control Module Programming and Setup

This module does not require programming or setup.

Audio Amplifier Programming and Setup

There is no setup procedure for this module.

Introduction

A new body control module (BCM) must be programmed with the latest operating software and vehicle calibrations. Ensure that the following conditions exist in order to prepare for BCM programming

1. The battery is fully charged.
2. The ignition switch is in the ON position.
3. The data link connector (DLC) is accessible.
4. All disconnected control modules and devices are connected.

Programming the BCM

Note. After the procedure is completed, the personalization settings of the BCM are set to default settings. Inform the customer that the personalization must be set again.

Note. The vehicle will not start and many other functions may not operate properly if a replacement BCM is not properly set up. The following procedures must be followed

1. Programming the BCM. Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Brake Pedal Position Sensor Calibration. Refer to «Brake Pedal Position Sensor Calibration»(/chevrolet/captiva/i-2011-2013/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-calibration) .
3. Learning the restraints ID.

Learning the Restraints ID

Navigate on the scan tool to Vehicle Control Systems > Module Setup > Body Control Module > Setup SDM Primary Key in BCM, then follow the instructions on the screen.

Note. After programming, perform the following to avoid future misdiagnosis

1. Turn the ignition OFF for 10 seconds.
2. Connect the scan tool to the data link connector.
3. Turn the ignition ON, with the engine OFF.
4. Use the scan tool in order to retrieve history DTCs from all control modules.
5. Clear all history DTCs.

Communication Center Call Transceiver Programming and Setup

This device requires no SPS programming or setup. However, if the module has been replaced, the following procedures are required

1. Program the vehicle VIN number into the replacement part by making the following scan tool selections: Telematic Veh. Locate and Immo. Module Setup Program VIN If for some reason the Tech 2 can not read the VIN, you will have to manually enter the VIN.
2. After the VIN has been programmed into the module, the dealer will need to update the Brazil database with the new SIM number for the replacement part.
3. If the vehicle has been disabled, the dealer will need to call the Brazil government hotline to have the unit reset.

Communication Interface Module Programming and Setup

Special Tools

EL-49642 SPS Programming Support Tool

For equivalent regional tools, refer to Special Tools .

Each of the following service procedures require programming or setup procedures to be performed on the communication interface module.

Communication Interface Module Replacement

Note. It is critical to use the service replacement Communication Interface Module only in the vehicle for which it was ordered. Failure to perform the following procedures will result in a red LED, DTC(s) being set, and limited or incomplete OnStar® services. An OnStar® button press to the OnStar® call center is not required to complete the procedure. It may take up to 24 hours for OnStar® service to become fully activated after performing the procedures. Perform the following procedure only once. Repeat attempts of the procedure may result in a delay of the activation process. To fully activate an OnStar® module, both the setup and activation request procedures must be completed on all vehicles with and without an active OnStar® subscription to insure the unit has been setup properly for the vehicle it has been installed into and also to update the OnStar® with the correct unit information. To initialize the Turn-by-Turn feature, the vehicle must first be driven In open sky condition at speeds greater than 10 mph (16 kph) or more for a minimum of 5 miles (8 km) , and perform at least 2 left and 2 right 90 degree turns coming to complete stops prior to each turn. On vehicles up fitted with TTY capabilities, it is necessary to perform a power cycle of the OnStar® Interface Module (OTIM), and toggle the TTY mode after completing the Communication Interface Module installation and setup procedures.

1. Install EL-49642 SPS programming support tool .
2. Access the Service Programming System (SPS) and follow the on-screen instructions.
3. On the SPS Supported Controllers screen, select ONSU Onstar® Module Setup and Service Activation and follow the on-screen instructions.
4. At the end of programming, choose the "Clear All DTCs" function on the SPS screen.
5. The default language for the new Communication Interface Module is English. To change to an alternate language, access the scan tool.
6. Inform the customer that it may take up to 24 hours for the OnStar® service to become fully activated.

Control Solenoid Valve and Transmission Control Module Assembly Programming and Setup (6T45/6T50)

The following service procedures require either a programming or a setup event be performed for a complete repair. The transmission control module (TCM) is part of the control solenoid (w/body and TCM) valve assembly, and is not serviced separately.

Transmission Control Module (TCM) Replacement

If the TCM is replaced, the following procedures must be performed

1. TCM Reprogramming
2. The Service Fast Learn Adapts - Refer to «Service Fast Learn Adapts»(/chevrolet/captiva/i-2011-2013/remont/automatic-trans/#automatic-transmission-6t456t50-diagnostic-information-and-procedures__service-fast-learn-adapts)

TCM Reprogramming

1. If the TCM needs to be reprogrammed, refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Perform the Service Fast Learn Adapts - Refer to «Service Fast Learn Adapts»(/chevrolet/captiva/i-2011-2013/remont/automatic-trans/#automatic-transmission-6t456t50-diagnostic-information-and-procedures__service-fast-learn-adapts) .

1. Turn the ignition OFF for 30 seconds.
2. Turn the ignition ON with the engine OFF.
3. Use the scan tool in order to retrieve history DTCs from all modules.
4. Clear all history DTCs.

Setup for Component Replacement

The replacement of some components will require a setup procedure for complete repair.

If any of the following components are replaced, the Service Fast Learn Adapts procedure must be performed

1. Transmission replacement
2. Any internal transmission repair
3. Any speed sensor

Refer to Service Fast Learn Adapts .

Digital Radio Receiver Programming and Setup

Each of the following service procedures requires programming or setup procedures to be performed on the digital radio receiver.

XM™ Activation

1. Radio ON, tune to the XM™ channel 0 and record the radio ID. The radio ID will be required for activation of the new receiver.
2. Call XM™ radio to deactivate the faulty receiver and activate the new receiver. US: 1-800-556-3600 Canada: 1-877-438-9677
3. Park the vehicle outside in an area with an unobstructed view of the southern sky.
4. Leave the vehicle outside with the ignition switch in the ACC position and the radio ON, tune to the XM™ channel 1 for 30 minutes to activate XM™ service.
5. Once activated, the radio will receive the remaining XM™ channels.

EBCM Replacement

If the electronic brake control module (EBCM) is replaced, the following procedures must be performed.

EBCM Reprogramming-Refer to Service Programming System (SPS) .

EBCM Programming and Setup - Hybrid

If the electronic brake control module (EBCM) is replaced or needs reprogrammed, the following procedures must be performed

1. EBCM Reprogramming--Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Perform the module setup EBCM Relearn.
3. Perform the module setup Acceleration Sensor Reset.
4. Perform the module setup BMC Prim. Piston Pos. Relearn.

The replacement of ABS components such as the steering wheel position sensor may require a setup procedure for complete repair . Refer to Steering Angle Sensor Centering

Electronic Compass Module Programming and Setup

The electronic compass module requires a calibration after the module is replaced, repaired, or as required for proper module operation. Refer to Compass Calibration and Magnetic Variance .

Electronic Parking Brake Control Module Programming and Setup

If the electronic parking brake control module is replaced, the following procedures must be performed

Refer to Service Programming System (SPS) .

Calibration with Scan Tool

Note. Verify the rear brakes are clear of any obstacles before starting the calibration procedure. During the procedure the rear brakes will cycle several times, stay clear of all moving parts until the process is complete.

Perform the Parking Brake Calibration procedure in Module Setup.

Calibration without Scan Tool

1. Ignition ON, apply and hold the brake pedal.
2. Push and hold the electric parking brake switch down for 5-6 seconds.
3. Release the electric parking brake switch.
4. Momentarily push the electric parking brake switch down.
5. Remove the EPB MODULE fuse and reinstall.
6. Apply the electric parking brake.
7. Release the electric parking brake.

Engine Control Module Programming and Setup (LFW)

The following service procedures require either a programming or a setup event performed for a complete repair.

ECM Replacement

If the engine control module (ECM) is replaced, the following procedures must be performed

1. ECM Reprogramming-Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Theft Deterrent-Refer to «Immobilizer System Component Programming»(/chevrolet/captiva/i-2011-2013/remont/door-locks-anti-theft-systems/#immobilizer-system) .
3. Brake Pedal Position Sensor Learn-Refer to «Brake Pedal Position Sensor Learn»(/chevrolet/captiva/i-2011-2013/remont/automatic-trans/#automatic-transmission-6t456t50-diagnostic-information-and-procedures__brake-pedal-position-sensor-learn) .
4. The CKP System Variation Learn-Refer to «Crankshaft Position System Variation Learn»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions__crankshaft-position-system-variation-learn) .
5. The Throttle/Idle Learn procedure-Refer to «Throttle/Idle Learn»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-30l-repair-instructions) .
6. Engine Oil Life Remaining-When available, use a scan tool to reset the Engine Oil Life Remaining back to the original percentage recorded before the module was replaced.
7. Transmission Fluid Life Remaining-When available, use the scan tool to reset the Transmission Fluid Life Remaining back to the original percentage recorded before the module was replaced.

ECM Reprogramming

1. If the ECM needs to be reprogrammed, refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Engine Oil Life Remaining-When available, use a scan tool to reset the Engine Oil Life Remaining back to the original percentage recorded before the module was reprogrammed.
3. Turn the ignition OFF for 30 seconds.
4. Turn the ignition ON with the engine OFF.
5. Use the scan tool in order to retrieve history DTCs from all modules.
6. Clear all history DTCs.

The replacement of some components will require a setup procedure for complete repair.

If any of the following components are replaced, the CKP Variation Learn Procedure must be performed. Refer to Crankshaft Position System Variation Learn .

1. Engine replacement
2. Any engine repair that disturbs the CKP sensor or its relationship with the crankshaft reluctor wheel
3. CKP sensor

If the throttle body is replaced or a throttle body cleaning procedure is completed, the Throttle/Idle Learn Procedure must be performed. Refer to Throttle/Idle Learn .

Engine Control Module Programming and Setup (LEA)

The following service procedures require either a programming or a setup event performed for a complete repair.

If the engine control module (ECM) is replaced, the following procedures must be performed

1. ECM Reprogramming-Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Theft Deterrent-Refer to «Immobilizer System Component Programming»(/chevrolet/captiva/i-2011-2013/remont/door-locks-anti-theft-systems/#immobilizer-system) . The ECM will learn the incoming fuel continue password immediately upon receipt of a password message. Once a password message is received, and a password is learned, a learn procedure must be performed to change this password again. An ECM which has been previously installed in another vehicle will have learned the other vehicle's fuel continue password, and will require a learn procedure after programming to learn the current vehicle's password.
3. Brake Pedal Position Sensor Learn-Refer to «Brake Pedal Position Sensor Learn»(/chevrolet/captiva/i-2011-2013/remont/automatic-trans/#automatic-transmission-6t456t50-diagnostic-information-and-procedures__brake-pedal-position-sensor-learn) .
4. Throttle Learn Procedure-Refer to «Throttle/Idle Learn»(/chevrolet/captiva/i-2011-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
5. Engine Oil Life Remaining-When available, use a scan tool to reset the Engine Oil Life Remaining back to the original percentage recorded before the module was replaced.
6. Transmission Fluid Life Remaining-When available, use the scan tool to reset the Transmission Fluid Life Remaining back to the original percentage recorded before the module was replaced.

1. If the engine control module (ECM) needs to be reprogrammed, refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Engine Oil Life Remaining-When available, use a scan tool to reset the Engine Oil Life Remaining back to the original percentage recorded before the module was reprogrammed.

The replacement of some components will require a setup procedure for complete repair.

If any of the following components are replaced, an Idle Learn Procedure must be performed. Refer to Throttle/Idle Learn .

1. Throttle body assembly
2. ECM

Fuel Pump Flow Control Module Programming and Setup

If the fuel pump control module (FPCM) is replaced, it must be programmed. Refer to Service Programming System (SPS) .

Replace and Program ECU or Reprogram ECU

This ECU does not require SPS programming but does require the following setup procedures after a new ECU is installed

The customer must learn the device they wish to control. This must be done at the device (garage door opener, electric gate, etc.) and cannot be performed at a dealership. Refer to the vehicle owner's manual for programming instructions.

Heated Seat Module Replacement

If the heated seat module is replaced or if the module needs to be reprogrammed, refer to Service Programming System (SPS) .

HVAC System Control Module Programming and Setup

Each of the following service procedures may require programming or setup procedures to be performed on the HVAC control module or HVAC actuators.

HVAC Control Module Replacement

If the HVAC control module is replaced it must be programmed with the latest operating software and vehicle calibrations. Refer to Service Programming System (SPS) .

HVAC Control Module Reprogramming

Do not reprogram the HVAC control module, unless directed by a service procedure, or a service bulletin.

Reprogram HVAC Control Module-Refer to Service Programming System (SPS) .

Actuator Replacement

If an actuator is replaced, the following procedure must be performed

1. Re-Calibrating Actuators-Refer to «Actuator Recalibration»(/chevrolet/captiva/i-2011-2013/remont/manual-hvac-system/#hvac-system-manual) for the manual system.
2. Re-Calibrating Actuators-Refer to «Actuator Recalibration»(/chevrolet/captiva/i-2011-2013/remont/automatic-hvac-system/#hvac-system-automatic) for the automatic system.

Inflatable Restraint Sensing and Diagnostic Module Programming and Setup

Note. The air bag indicator light may remain ON after the body control module (BCM), or inflatable restraint sensing and diagnostic module (SDM) is replaced, and during the programming procedure for the BCM until after the procedure is completed. When installing a new SDM, there may be several DTCs set prior to programming. Once programmed, these DTCs should be in history and can be cleared.

1. Ignition ON, program the SDM. Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. In the BCM Module Setup menu, select Setup SDM Primary Key in BCM. Follow the scan tool on screen instructions.
3. In the SDM Module Setup menu, select Setup SDM. Follow the scan tool on screen instructions.
4. Cycle the ignition from OFF to ON. Verify no DTCs are set. If any DTCs are set, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/captiva/i-2011-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) .

Inflatable Restraint Vehicle Rollover Sensor Programming and Setup

1. Key ON, Engine OFF. With the scan tool perform the Setup New ROS procedure for the inflatable restraint vehicle rollover sensor (ROS).
2. Key OFF then ON again. Clear all codes and verify no current faults are present.

Compass Calibration and Variance Procedures

When the inside rearview mirror with compass is replaced, the compass must be setup utilizing the Compass Calibration and Magnetic Variance .

Instrument Cluster Programming and Setup

When replacing the Instrument Panel Cluster (IPC), the replacement IPC must be calibrated and the odometer information transferred to the new unit.

Note. it is important to use the following procedures in the sequence listed.

1. Calibrate the IPC using the «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Transfer the odometer information to the replacement IPC using IPC SETUP in the «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .

Passenger Presence System Preload Test

The passenger presence system (PPS) consists of an electronic control module, a sensor mat in the seat, a harness, and PASSENGER AIR BAG ON/OFF indicators. The passenger presence system is designed to tell the difference between an empty seat, child seats, and a small person, such as a child who has outgrown child restraints. This is done by a combination of the force measured and the pattern generated by an occupied seat through an algorithm. A digital pressure value is generated by an occupant. The harder you push, the higher the digital pressure value. This digital pressure value is generated by an algorithm is used to determine the type of occupant sitting in the front passenger seat. If the digital pressure value measured and pattern generated is that of an empty seat, child seat, or small person, then the passenger presence module will send a serial data signal to the inflatable restraint sensing and diagnostic module to disable the passenger instrument panel air bag. If the digital pressure value measured and pattern generated is that of a person of adult size, then the passenger presence module will send a serial data signal to the inflatable restraint sensing and diagnostic module to enable the passenger instrument panel air bag. The inflatable restraint sensing and diagnostic module will notify the customer of the enable/disable status by illuminating one of the PASSENGER AIR BAG ON/OFF indicator. If the passenger seat bottom cushion, seat bottom trim, or heater pad has been serviced, reinstalled, or removed for any reason, the procedure below will check for any preloads on the passenger presence system. A service replacement passenger presence system module does not require an unlock procedure prior to an initial preload test.

Note. DTC B0081 11 will set if the preload system test is performed with items on the passenger seat Before the passenger presence system can be checked for preloads the front passenger seat must be completely empty of all items. The presence of any items on the front passenger seat will affect the calibration and operation of the passenger presence system. When the preload test is performed, the instrument panel cluster and dash lights will begin illuminating at varying intensity. This is normal operation during the preload test procedure and does not indicate additional system faults. The Diagnostic Repair Verification must be performed after successfully completing the preload test procedure to ensure the system is functioning properly.

Passenger Presence System Preload System Test

1. Empty the front outboard passenger seat (this system is susceptible to heavy material).
2. With the scan tool, perform the Preload Passenger Presence System procedure.
3. Using the scan tool, check for DTC B0081 in history. If the test fails or DTC B0081 11 is current, confirm that the seat is empty. Perform the passenger presence sensor learn test again. If the test fails again, for heated seats, ensure that the sensor pad is on top of the heater element. Once the test successfully completes, cycle the ignition OFF.
4. Perform the «Diagnostic Repair Verification»(/chevrolet/captiva/i-2011-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-repair-verification) after successfully completing the preload test procedure to ensure the system is functioning properly.

Radio Programming and Setup

Each of the following service procedures require programming or setup procedures to be performed on the radio.

Radio Replacement

For uplevel radios, setup is completed using the Service Programming System (SPS). Refer to Service Programming System (SPS) .

For the base radio, use the program VIN procedure available in Special Functions menu of the scan tool. After programming the VIN cycle the ignition key with the retained accessory power (RAP) disabled.

Rear Differential Clutch Control Module Programming and Setup

Special Tools

EL-49642 SPS Programming Support Tool

For equivalent regional tools, refer to Special Tools .

Note. DO NOT program a control module unless directed to by a service procedure or a service bulletin. If the ECU is not properly configured with the correct calibration software, the ECU will not control all of the vehicle features properly. Ensure the programming tool is equipped with the latest software and is securely connected to the data link connector. If there is an interruption during programming, programming failure or ECU damage may occur. Stable battery voltage is critical during programming. Any fluctuation, spiking, over voltage or loss of voltage will interrupt programming. Install the EL-49642 SPS programming support tool to maintain system voltage. If not available, connect a fully charged 12 V jumper or booster pack disconnected from the AC voltage supply. DO NOT connect a battery charger. Turn OFF or disable systems that may put a load on the vehicles battery such as; interior lights, exterior lights (including daytime running lights), HVAC, radio, etc. During the programming procedure, follow the SPS prompts for the correct ignition switch position. Clear DTCs after programming is complete. Clearing powertrain DTCs will set the Inspection/Maintenance (I/M) system status indicators to NO.

To program a replacement or an existing ECU, perform the following procedure

1. Install EL-49642 SPS programming support tool.
2. Access the Service Programming System (SPS) and follow the on-screen instructions.
3. On the SPS Supported Controllers screen, select RDCM Rear Differential Clutch Control Module- Programming and follow the on-screen instructions.
4. On the SPS Supported Controllers screen, select RDCM Rear Differential Clutch Control Module- Setup and follow the on-screen instructions.
5. At the end of programming, choose the"Clear All DTCs" function on the SPS screen.

Unsuccessful Programming Recovery

In the event of an interrupted or unsuccessful programming event, perform the following steps

1. DO NOT turn the ignition OFF. Ensure that all ECU, DLC and programming tool connections are secure and the TIS terminal operating software is up to date.
2. Attempt to reprogram the ECU.
3. If the ECU can still not be programmed, turn the ignition OFF for at least one minute.
4. Turn the ignition ON and attempt to reprogram the ECU. The ECU should program. If the ECU still cannot be programmed, replace the ECU.

Remote Control Door Lock Receiver Programming and Setup

Remote Control Door Lock Receiver Replacement - Copy and Paste TPM Information

This procedure will learn the TPM information to the new RCDLR using the Copy and Paste function on the scan tool. This procedure will extract the TPM Tire Type information as well as the sensor data from the existing RCDLR prior to its replacement and store this information in the scan tool. After RCDLR replacement and SPS programming, the tire type and sensor data stored in the scan tool is written to the new RCDLR, negating the need to perform the tire type setup and sensor learn procedure.

This procedure should be considered as the first programming choice when replacing an RCDLR. The Copy and Paste procedure eliminates the possibility of incorrectly inputting the tire type or learning stray TPM sensors.

1. Using a scan tool, navigate to the Copy and Paste TPM Information procedure and copy the existing TPM information from the RCDLR using the outline below. Follow the on-screen instructions after selecting Step 1: Vehicle Control Systems Module Setup Remote Control Door Lock Receiver Copy and Paste TPM Information Step 1
2. At this point, install the new RCDLR.
3. Program the RCDLR - Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
4. Using a scan tool, navigate to the Copy and Paste TPM Information procedure to paste the stored TPM information using the outline below. Follow the on-screen instructions after selecting Step 2: Vehicle Control Systems Module Setup Remote Control Door Lock Receiver Copy and Paste TPM Information Step 2
5. Program the keyless entry transmitters - Refer to «Remote Control Door Lock Transmitter Programming»(/chevrolet/captiva/i-2011-2013/remont/door-locks-anti-theft-systems/#keyless-entry-system-and-remote-functions) .

Remote Control Door Lock Receiver Replacement - TPM Sensor Learn

This procedure will learn TPM information to the new RCDLR by manually inputting the tire type using the scan tool and performing the TPM sensor learn. This procedure should be performed if the above Copy and Paste procedure can not be completed. An example of this would be an RCDLR that is unable to communicate with the scan tool and is required to be replaced.

1. RCDLR Programming-Refer to «Service Programming System (SPS)»(/chevrolet/captiva/i-2011-2013/remont/communication-devices/#programming-and-setup-all-systems__service-programming-system-sps) .
2. Keyless Entry Transmitter Programming-Refer to «Remote Control Door Lock Transmitter Programming»(/chevrolet/captiva/i-2011-2013/remont/door-locks-anti-theft-systems/#keyless-entry-system-and-remote-functions) .
3. Tire Type Setup: Install a scan tool. Select Remote Control Door Lock Receiver under Module Setup in the Vehicle Control System menu. Select Tire Type/Pressure Selection. Follow the on-sceen instructions.
4. Tire Pressure Monitoring Sensor Learn-Refer to «Tire Pressure Indicator Sensor Learn»(/chevrolet/captiva/i-2011-2013/remont/warning-system/#tire-pressure-monitoring-system__tire-pressure-indicator-sensor-learn) .

Serial Data Gateway Module Programming and Setup

The following service procedures require either a programming or a setup event be performed for a complete repair.

Serial Data Gateway Module (SDGM) Replacement

If the SDGM is replaced, SDGM programming must be performed. Refer to Service Programming System (SPS) .

Serial Data Gateway Module (SDGM) Reprogramming

When SDGM reprogramming must be performed, refer to Service Programming System (SPS) .

Ensure the following conditions exist in order to prepare for SDGM programming or reprogramming

1. The battery is fully charged.
2. The ignition switch is in the RUN position.
3. The Techline equipment cable connection at the data link connector (DLC) is secure.

Program the SDGM using the latest software matching the vehicle. Refer to up-to-date Techline equipment user instructions.

If the SDGM fails to program, proceed as follows

1. Ensure the DLC and SDGM connections are good.
2. Inspect the Techline equipment for the latest software version.
3. Attempt to program the SDGM. If the SDGM still cannot be programmed properly, replace the SDGM.

Serial Data Gateway Module (SDGM) Setup

This device requires no setup.

Service Programming System (SPS)

Special Tools

EL-49642 SPS Programming Support Tool

For equivalent regional tools, refer to Special Tools .

For step-by-step control module programming instructions, please refer to the techline information system (TIS) terminal.

Review the information below to ensure proper programming protocol.

Note. DO NOT program a control module unless you are directed by a service procedure or you are directed by a General Motors service bulletin. Programming a control module at any other time will not permanently correct a customers concern. It is essential that the TIS terminal, MDI, and/or Scan Tool, is equipped with the latest software before performing service programming. Due to the time requirements of programming a controller, install EL-49642 SPS Programming Support Tool to maintain system voltage. Stable battery voltage is critical during programming. Any fluctuation, spiking, over voltage or loss of voltage will interrupt programming. If the above tool is not available, DO NOT connect a battery charger, connect a fully charged 12V jumper or booster pack disconnected from the AC voltage supply. Some modules will require additional programming/setup events to be performed before or after programming. Some vehicles may require the use of a CANDi or MDI module for programming. Review the appropriate service information for these procedures. DTCs may set during programming. Clear DTCs after programming is complete. Clearing powertrain DTCs will set the Inspection/Maintenance (I/M) system status indicators to NO.

Ensure the following conditions are met before programming a control module

1. Vehicle system voltage: There is not a charging system concern. All charging system concerns must be repaired before programming a control module. Battery voltage is greater than 12 volts but less than 16 volts. The battery must be fully charged before programming the control module. Turn OFF or disable any system that may put a load on the vehicles battery, such as the following components: Interior lights Exterior lights including daytime running lights (DRL)-Applying the parking brake, on most vehicles, disables the DRL system Heating, ventilation, and air conditioning (HVAC) systems Engine cooling fans Radio, etc.
2. The ignition switch must be in the proper position. SPS prompts you to turn ON the ignition, with the engine OFF. DO NOT change the position of the ignition switch during the programming procedure, unless instructed to do so.
3. Make certain all tool connections are secure, including the following components and circuits: Scan Tool The RS-232 communication cable port The connection at the data link connector (DLC) The voltage supply circuits MDI The USB, Ethernet or Wireless communication port The connection at the data link connector (DLC)
4. DO NOT disturb the tool harnesses while programming. If an interruption occurs during the programming procedure, programming failure or control module damage may occur.

In the event of an interrupted or unsuccessful programming event, perform the following steps

1. DO NOT turn the ignition OFF. Ensure that all control module and DLC connections are secure and the TIS terminal operating software is up to date.
2. Attempt to reprogram the control module.
3. If the control module can still not be programmed, turn the ignition OFF for at least one minute.
4. Turn the ignition ON and attempt to reprogram the control module. The control module should program. If the control module still cannot be programmed, replace the control module.

After successfully programming the control module, ensure that all post programming procedures are performed; refer to Control Module References for the appropriate control module Programming and Setup document for any required procedures.

Sunroof Control Module Programming and Setup (Tilt and Slide System)

When replacing the sunroof motor/control module, the sunroof motor/actuator initialization/teach procedure must be followed.

Initialization and Learn Procedures

In order for the sunroof system to perform correctly it needs to establish its position and the force profile it will encounter under normal closing conditions. These two procedures need to be run when a new controller is placed on a vehicle, when a service procedure is performed on any mechanical component, or if the system seems to lose track of its known position.

Initialization and Reinitialization

When the sunroof controller is not initialized it will perform all 'Open' requests, but no 'Express close' or LIN-Bus communicated close commands. It will only perform a 'Close' operation requested by the switch with obstacle detection disabled. If an initialization procedure is interrupted the controllers will return to the not initialized state. Which procedure is run depends on the state of the controller.

For a module which is not initialized begin the process by holding the sunroof switch in the 'Close' position. The sunroof will move to the end of physical travel in the closed direction and store that position. During this time it is necessary to keep the switch active until the process completes. At the completion of the procedure the sunroof should back off slightly to its soft stops. The rest of the defined positions are determined by offsets from this home position.

For a module which has been previously initialized release the switch after the sunroof is considered fully closed by the software. Then hold the sunroof switch in the closed position for 10 s. The sunroof shall resume motion in the 'Close' direction until the end of travel is detected. During this time it is necessary to keep the switch active until the process completes. At the completion of the procedure the sunroof should back off slightly to its soft stops.

For learning the force profile for anti-pinch algorithm after initialization or re-initialization move the roof to the fully open position and release the switch. Activate the 'Open' function of the switch continuously for more than 15 s. At this point, the sunroof will automatically begin to move to the fully closed position. During this time it is necessary to keep the switch active until the process completes.

Theft Deterrent Module Programming and Setup

1. Connect a scan tool to the vehicle in the Pass-thru arrangement.
2. Turn ON the ignition, with the engine OFF.
3. Ensure that all power consuming devices are turned OFF on the vehicle.
4. On the Techline Terminal, select Service Programming System and follow the Techline Terminal on-screen instructions. Go to TDM Theft Deterrent Module from the controller list and select the appropriate on-screen calibration options.
5. After the programming has completed, turn the ignition OFF for 30 seconds.
6. Turn ON the ignition with the engine OFF.
7. On the Techline Terminal, go to V.T.D. Vehicle Theft Deterrent Learn from the controller list and select Vehicle Theft Deterrent Learn, ECM or PK3 Replaced. Follow the on-screen instructions.
8. At this point the scan tool must remain connected for the duration of the 10-minute relearn procedure.
9. Observe the scan tool, after approximately 12 minutes the scan tool will display "Programming Successful, Turn OFF Ignition". The vehicle is now ready to relearn the key information and/or the passwords on the next ignition switch transition from OFF to CRANK.
10. Turn OFF the ignition and wait 2 minutes.
11. With a master vehicle key, turn the ignition to the RUN position for 15 seconds, then start the vehicle. The TDM and ECM have now relearned the pre-release password and the challenge/response data.
12. With a scan tool, clear any DTCs.

Special Tools

Illustration Tool Number/ Description EL 46079 J 46079 Tire Pressure Monitor Diagnostic Tool EL 49642 EL 50113 Europe- Use recommended equivalent workshop equipment SPS Programming Support Tool

Scheme 1

Scheme 2

See also:
• Data Link References
• Diagnostic System Check - Vehicle
• Diagnostic Trouble Code (DTC) List - Vehicle
• Cigar Lighter/Power Outlet Schematics
• Body Control Module Scan Tool Information
• Body Control System Schematics
• Immobilizer Schematics
• Communication Interface Module Scan Tool Information
• OnStar Schematics
• Transmission Control Module Scan Tool Information (6T30/6T40/6T45/6T50)
• Automatic Transmission Controls Schematics
• Control Solenoid Valve and Transmission Control Module Assembly Replacement
• Digital Radio Receiver Scan Tool Information
• Electronic Brake Control Module Scan Tool Information
• Antilock Brake System Schematics
• Driver Information System Schematics
• Electronic Parking Brake Control Module Scan Tool Information
• Park Brake System Schematics
• Engine Control Module Scan Tool Information (LEA)
• Engine Controls Schematics (LEA)
• Engine Controls Schematics (LFW)
• Engine Control Module Replacement
• Engine Control Module Replacement
• Fuel Pump Flow Control Module Scan Tool Information
• HVAC Schematics
• Heated/Cooled Seat Schematics
• Heating, Ventilation and Air Conditioning Control Module Scan Tool Information
• HVAC Schematics
• Inflatable Restraint Passenger Presence System Scan Tool Information
• SIR Schematics
• Inflatable Restraint Sensing and Diagnostic Module Scan Tool Information
• Inflatable Restraint Vehicle Rollover Sensor Scan Tool Information
• Inside Rearview Mirror Schematics
• Instrument Cluster Scan Tool Information
• Radio Scan Tool Information
• Rear Differential Clutch Control Module Scan Tool Information
• Rear Axle Schematics
• Remote Control Door Lock Receiver Scan Tool Information
• Remote Function Schematics
• Serial Data Gateway Module Scan Tool Information
• Sunroof Schematics
• Theft Deterrent Module Scan Tool Information
• Theft Deterrent System Schematics
• Brake Pedal Position Sensor Calibration
• Service Fast Learn Adapts
• Steering Angle Sensor Centering
• Brake Pedal Position Sensor Learn
• Crankshaft Position System Variation Learn
• Diagnostic Repair Verification
• Tire Pressure Indicator Sensor Learn
• Accessory AC and DC Power Control Module Programming and Setup
• Body Control Module Programming and Setup
• Communication Center Call Transceiver Programming and Setup
• Communication Interface Module Programming and Setup
• Control Solenoid Valve and Transmission Control Module Assembly Programming and Setup (6T30/6T40/6T45/6T50)
• Digital Radio Receiver Programming and Setup
• Electronic Compass Module Programming and Setup
• Electronic Parking Brake Control Module Programming and Setup
• Engine Control Module Programming and Setup (LF1, LFW or LFX)
• Fuel Pump Flow Control Module Programming and Setup
• HVAC System Control Module Programming and Setup
• Inflatable Restraint Sensing and Diagnostic Module Programming and Setup
• Inflatable Restraint Vehicle Rollover Sensor Programming and Setup
• Instrument Cluster Programming and Setup
• Radio Programming and Setup
• Audio Amplifier Programming and Setup
• Rear Differential Clutch Control Module Programming and Setup
• Remote Control Door Lock Receiver Programming and Setup
• Serial Data Gateway Module Programming and Setup
• Sunroof Control Module Programming and Setup (Tilt and Slide System)
• Theft Deterrent Module Programming and Setup
• Service Programming System (SPS)
• Special Tools
• Control Module References
