Power Outlets Chevrolet Captiva I рестайлинг 2

Body Electrical 3 illustrations ~803 words

Scheme 203

Scheme 203: Accessory Power Outlets Wiring Schematics
Scheme 203: Accessory Power Outlets Wiring Schematics

Diagnostic Instructions

  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/captiva/i-2-2013-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/captiva/i-2-2013-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/captiva/i-2-2013-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Visual/Physical Inspection

  1. Inspect for aftermarket devices which can affect the operation of the power outlets. Refer to «Checking Aftermarket Accessories»(/chevrolet/captiva/i-2-2013-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories)
  2. Inspect the accessible system components or the visible system components for obvious damage or for obvious conditions which can cause the symptom.

Intermittent

Electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections

Symptom List

Refer to Power Outlet Receptacle Malfunction in order to diagnose the system.

  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/captiva/i-2-2013-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/captiva/i-2-2013-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/captiva/i-2-2013-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
B+11
Ground1
1. Accessory Power Receptacle Malfunction

Circuit/System Description

The accessory power receptacles are supplied B+ all the time.

Reference Information

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/captiva/i-2-2013-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
  2. «Connector Repairs»(/chevrolet/captiva/i-2-2013-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/captiva/i-2-2013-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/captiva/i-2-2013-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Circuit/System Testing

  1. Ignition OFF, disconnect the harness connector at the appropriate X80 accessory power receptacle.
  2. Test for less than 5 ohms between the ground circuit terminal C and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
  3. Ignition ON, verify that a test lamp illuminate between the B+ circuit terminal A and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
  4. If all circuits test normal, test or replace the X80 accessory power receptacle.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Cigar Lighter Receptacle or 12-Volt Accessory Power Receptacle Replacement

Special Tools

J 42059 Cigar Lighter Socket Remover

Removal Procedure

  1. Remove the auxiliary power outlet fuse from the fuse block.
  2. Remove the receptacle: Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in) from the front of the receptacle. The J 42059 cigar lighter socket remover pushes the plastic latches from these tab windows and the receptacle can be pulled straight out. Place one side of the "T" portion of the J 42059 cigar lighter socket remover into the tab window. The J 42059 cigar lighter socket remover will not fit straight into the receptacle. Angle the J 42059 cigar lighter socket remover slightly for insertion into the receptacle. Insert the other side of the "T" into the opposite tab window. You must move the J 42059 cigar lighter socket remover handle toward horizontal to engage the other tab window. Use the J 42059 cigar lighter socket remover to pull the receptacle straight out.
  3. If J 42059 cigar lighter socket remover tool fails to release the lighter socket from the retainer, perform the following alternate method: Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 cigar lighter socket remover as directed above to remove the socket.

Installation Procedure

  1. Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
  2. Install the retainer by pressing into place fully seated.
  3. Connect the electrical connector to the receptacle.
  4. Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
  5. Install the accessory power receptacle fuse.

Scheme 204

Scheme 204: Accessory AC and DC Power Control Module Replacement
Scheme 204: Accessory AC and DC Power Control Module Replacement
CalloutComponent Name
Preliminary Procedure Remove the quarter lower rear trim panel - left side. Refer to Quarter Lower Rear Trim Panel Replacement .
1Accessory AC and DC Power Control Module Bolt (Qty: 3) CAUTION: Fastener Caution . Tighten 10 N.m (89 lb in)
2Accessory AC and DC Power Control Module Procedure Disconnect the electrical connectors. For programming and setup procedures, refer to Control Module References .
CAUTION
Fastener Caution .

Accessory AC and DC Power Control Module Replacement

Scheme 205

Scheme 205: 120-Volt Accessory Power Receptacle Replacement
Scheme 205: 120-Volt Accessory Power Receptacle Replacement
CalloutComponent Name
1120 Volt Accessory Power Receptacle Procedure Disconnect the electrical connectors. Unsnap accessory power receptacle from the left rear quarter panel.

120-Volt Accessory Power Receptacle Replacement

System Description

The vehicle is fitted with a cigarette lighter and/or with a 12 V accessory power receptacle. The cigarette lighter and accessory power outlets are controlled by an ignition operated relay. The accessory power receptacle and cigarette lighter are operational when the ignition is turned to either the On or the Accessories positions. To operate the cigarette lighter, press in the lighter knob. When the element is hot, the lighter automatically pops out and is ready for use.

Special Tools

Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
