VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 8
SHORT TRIP/CITY & LONG TRIP/HIGHWAY SERVICE DEFINITIONS
Note. Starting in the 1996 model year, General Motors has renamed their maintenance schedules; One is referred to as the Short-Trip/City and the other is the Long Trip/Highway schedule. These schedule requirements are similar to the familiar Severe Service and Normal schedules and can be used in place of one another.
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Severe Service
- Short Trips (4 Miles Or Less)
- When Most Trips Are Less Than 10 Miles And Outside Temperatures Remain Below Freezing.
- Towing Or Heavily Loaded
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
Normal Service
- Driven More Than 10 Miles Daily
- No Severe Service Operating Conditions
Scheme 9
Scheme 10
Note. For more information regarding jacking or hoisting the vehicle, refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.
Scheme 11
Scheme 12
Note. For more information regarding cooling system service, refer to the 5.7L V8 - VIN [P] article in the ENGINE MECHANICAL section.
SERVICE LABOR TIMES
Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
TIRE INFLATION
Tire pressure specification decal is attached to rear face of driver's door. Inflation pressures listed on decal are always cold pressures and must never exceed maximum values molded into tire side wall. These pressures should be used for all driving conditions, as they provide the best balance of fuel economy, tire life, riding comfort and handling.
Note. When using compact spare tire, it must be inflated to 60 psi, and vehicle must not be driven faster than 50 MPH.
WHEEL TIGHTENING
| Application | Ft. Lbs. (N.m) |
|---|---|
| All | 100 (140) |
| (1) Always tighten wheel lug nuts in a crisscross pattern. All wheel lug nuts have right-hand threads. | |
| (1) | Always tighten wheel lug nuts in a crisscross pattern. All wheel lug nuts have right-hand threads. |
TIGHTENING SPECIFICATIONS (1)
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
ANTI-LOCK BRAKE SYSTEM (ABS)
| CAUTION | Never mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors. |
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below. |
REPLACING BLOWN FUSES
| CAUTION | Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload. |
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
| CAUTION | Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle. |
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) or Ethylene-Glycol -35° F (-37°C) - 263° F (128°C). |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
RADIATOR FAN WITH TOW PACKAGE
| WARNING | Keep hands away from mechanical (fan-clutch) radiator fan. |
SPARK PLUGS
Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.
TAILGATE
| WARNING | DO NOT drive vehicle with tailgate open, as carbon monoxide can enter vehicle. |
TRACTION CONTROL SYSTEM (IF EQUIPPED)
| CAUTION | If tires are allowed to spin at high speeds when TRACTION OFF light is on, tires can explode. Also, spinning the tires with the warning light on can cause the transaxle to overheat. DO NOT spin wheels above 35 MPH. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
BUMPER TO BUMPER PLUS COVERAGE LIMITED WARRANTY (1991-93)
Everything covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are covered up to their first scheduled replacement interval only.
Note. 1992-93 vehicles are covered for 3 years or 36,000 miles with no deductible.
BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY (1994-96)
Everything is covered for 4 years or 50,000 miles, whichever occurs first. Also covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. Maintenance items are covered up to their first scheduled replacement interval only.
CORROSION WARRANTY
Warranty covers any rust-through in body sheet metal due to corrosion. Warranty period is 6 years or 100,000 miles, whichever occurs first. Warranty begins on date vehicle is delivered or put in use, whichever occurs first.
EMISSION COMPONENTS DEFECT WARRANTY
General Motors Corporation warrants all GM's emission components in vehicle to be free of defects in material and workmanship, which would cause it to fail to meet Federal standards for emission control system at the time vehicle was built. Warranty begins on date vehicle is delivered or first put in use, whichever occurs first. Refer to customer's copy of warranty information for exact warranty periods on specific models.
EMISSION PERFORMANCE WARRANTY
The following are primary components affecting vehicle's emissions performance. Other emission control-related parts are covered by the Performance warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered.
Primary components are normally covered for 5 years or 50,000 miles with a few exceptions. Refer to customers copy of warranty information for exact warranty periods on specific models.
Gasoline Engines
- Air Injector Reactor (AIR) Pump, Air Distributor And Valves
- Pulse AIR Valve And Associated Parts
- PCV Valve System And Oil Filler Cap
- EGR Valve And Associated Controls
- Choke Switches And Carburetor Parts
- Engine Control Module And Associated Sensors (If Equipped)
- Electronic Fuel Injection System
- Carburetor Feedback Control System
- Throttle Return Control Parts (If Equipped)
- Catalytic Converter, Catalyst And Associated Parts
- Fuel Tank, Filler Cap, Restrictor And Vapor Control Valves
- Evaporative Emission Control Carbon Canister And Associated Controls
- Emission Related Hoses, Clamps, Belts, Pulley, Tubes, Fittings And Wiring Harness
- Thermostatic Air Cleaner Switch, Control Valve And Associated Parts
- EFE Valve, Heater And Associated Controls (If Equipped)
- Exhaust System-To-Catalytic Converter
- Distributor Parts And Associated Controls
- Spark Plugs And Ignition Wires
- Intake, Exhaust Manifolds And Turbocharger (California)
SUPPLEMENTAL INFLATABLE RESTRAINT COVERAGE
Covers supplemental restraint system (if equipped) for 4 years, regardless of mileage.
EMISSIONS DEFECT & PERFORMANCE WARRANTIES (EXCEPT CALIFORNIA)
Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.
The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally required state or local emissions test.
Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.
EMISSION PERFORMANCE WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
EMISSION DEFECT WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
ROADSIDE ASSISTANCE
Included in the Customer One Care Warranty is 24 Hour Roadside Assistance coverage, which provides the following services
- Flat Tire Service
- Out of Gas
- Battery Jump Assistance
- Lockout Service
- Towing Service
- Trip Routing
- Trip Interruption Expense
Note. 24 Hour Roadside Assistance phone number is 800-442-6537
FUSIBLE LINKS
Fusible links will melt to prevent fire if a large current flows through electrical systems without passing through fuses.
Scheme 13
Fuse & Circuit Breaker Identification
- 1 - 15 Amp Underhood Light, Power Antenna, Keyless Entry, Courtesy Lights, Compass/Lighted Mirror, Horn, Lighted Visor, Door Locks, Power Mirrors, Rear Glass Release, Audible Warning System
- 2 - 15 Amp Audible Warning System, Cigarette Lighter, Rear Wiper, Glove Box Light, Radio, Trunk Light, Rear Gate Ajar Light, Trunk Release
- 3 - 10 Amp Anti-Lock Brake System (1991 Caprice), Bose Amplifier 1992-93 Caprice)
- 4 - 10 Amp (Exc. 1993 Wagon) 25 Amp (1993 Wagon) Bose Radio Amplifier (1991 Caprice), Electronic A/C 1992 Caprice), Electronic Level Control (10 Amp 1993 Sedan), Electronic Level Control (25 Amp 1993 Wagon)
- 5 - 7.5 Amp Instrument Panel Lights
- 6 - 20 Amp Keyless Entry, Alternator, Heater, Air Conditioner, Daytime Running Lights
- 7 - 30 Amp (1991) Electronic A/C Blower Motor Blank (1992-93 Caprice)
- 8 - 15 Amp Rear Wiper/Washer
- 9 - 10 Amp Radio
- 10 - 25 Amp Windshield Wiper/Washer, Washer Fluid Level
- 11 - 7.5 Amp Fuel Injectors
- 12 - 10 Amp Supplemental Inflatable Restraint
- 13 - 10 Amp Speed Signal Module, ECM, EGR Solenoid, Air Control ESC Module, Canister Purge, Cluster Electronics/Warning Indicator
- 14 - 15 Amp Twilight Sentinel, Parking, Side Marker & License Lights, Daytime Running Lights
- 15 - 30 Amp Rear Window Defogger
- 16 - 7.5 Amp Heated Mirrors
- 17 - 15 Amp Audible Warning System, TCC Brake Switch, Compass Mirror, Supplemental Inflatable Restraint, Gauges/Warning Indicator, Headlight Switch Illumination, Rear Window Defogger, Fluid Warning, Anti-Lock Brake System, Twilight Sentinel, Daytime Running Lights, Low Oil Module, Park/Neutral Relay, Height Sensor, Power Vent Switch (1991 Caprice)
- 18 - 15 Amp Turn Signal Lights, Back-Up Lights Cruise Control
- 19 - 20 Amp Stoplights, Hazard Lights
- 20 - 5 Amp ECM, Supplemental Inflatable Restraint
- 21 - 30 Amp Circuit Breaker Keyless Entry, Power Door Locks, Power Seats, Tailgate Lock Relay, Power Vent Motor (1991 Caprice)
- 22 - Blank Or Spare
- 23 - 30 Amp Circuit Breaker Power Windows
- 24 - Blank Or Spare
- 25 - Blank Or Spare
Scheme 14
Fuse & Circuit Breaker Identification
- 1 - Blank
- 2 - Blank
- 3 - Blank
- 4 - Blank
- 5 - Blank
- 6 - 15 Amp Turn Signal Lamp Flasher, Park Neutral Position Sw.
- 7 - 10 Amp Anti-Lock Brake (ABS) Control Module
- 8 - 15 Amp Tailgate Sw. Module (Wagon)
- 9 - 10 Amp Radio
- 10 - 25 Amp Windshield Wiper Motor Module
- 11 - 10 Amp Rear Defog Relay, Air Bag, I/P Cluster, Headlamp Sw.
- 12 - 10 Amp Auto Level Control (Wagon)
- 13 - 10 Amp Automatic Inside Rearview Mirror, Chime Module, TCC Cruise Brake Sw., Twilight Sentinel, Daytime Running Lights Canada), Keyless Entry System
- 14 - 10 Amp Pass-Key II
- 15 - 15 Amp Air Bag
- 16 - 10 Amp Cruise Control
- 17 - 20 Amp Heater & A/C Control
- 18 - Blank
- 19 - Blank
- 20 - 10 Amp Instrument Cluster, Daytime Running Lights (Canada)
- 21 - Blank
- 22 - Blank
- 23 - Blank
- 24 - 10 Amp Air Bag, Theft Deterrent Relay
- 25 - Blank
- 26 - 20 Amp Power Antenna
- 27 - 10 Amp Heat Sensor, Trunk Lamp
- 28 - 20 Amp Cigarette Lighter
- 29 - 20 Amp Keyless Entry System, Trunk Release, Rear Glass Release Liftgate Wiper Latch Sw. (Wagon)
- 30 - 15 Amp Radio
- 31 - 20 Amp Headlamp Sw., Twilight Sentinel, Daytime Running Lights Canada)
- 32 - 25 Amp Horn
- 33 - 10 Amp Chime Module, Heater and A/C, Glove Box Light, Instrument Cluster
- 34 - 10 Amp Pass-Key II
- 35 - 15 Amp Dome Lamp, Front Reading Lights, Rear Reading Lights, Automatic Inside Rearview Mirror, Illuminated Visor Vanity Mirror, Power Door Locks, Front Door Courtesy Lights, Rear Door Courtesy Lights, Power Mirror Sw. Instrument Panel Courtesy Lights
- 36 - 15 Amp Rear Wiper (Wagon)
- 37 - 20 Amp Hazard Warning Flasher, Stop Lights
- 38 - Blank
- 39 - Blank
- 40 - Blank
- 41 - 10 Amp Cornering Lamps, Side Marker Lamp, Turn-Park Lamp
- 42 - 10 Amp Instrument Cluster, Radio, Brightness Control, Headlamp and Instrument Panel Lamp Dimmer Sw., Panel Lamps Dimming Module
- 43 - 10 Amp License Lights, Taillights, Tail/Stop/Turn Lights, Marker Lamps
- 44 - 10 Amp Heater Power Mirrors
- 45 - Blank
- 46 - Blank
- 47 - 30 Amp (Circuit Breaker) Power Window Sw., Power Window Lockout Sw.
- 48 - 30 Amp (Circuit Breaker) Door Locks, Power Seat Sw., Passenger Seat Lumbar Controls
- 49 - 30 Amp (Circuit Breaker) Rear Window Defog Sw.
- 50 - Blank
Scheme 15
| WARNING | Always disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician. |
Fuse Identification
- 1 - 25 Amp ELC Automatic Level Control Air Compressor (ALC)
- 2 - 15 Amp F/P Fuel Pump Relay, Fuel Pump and Engine Oil Pressure Switch Powertrain Control Module (PCM)
- 3 - 20 Amp AIR Primary Air Pump Relay, Underhood Lamp
- 4 - 10 Amp EMI Automatic Transmission, Mass Air Flow Sensor (MAF), Secondary Air Pump Relay, EGR Control Valve Relay, Evaporative Emission Canister Purge Valve Solenoid, LH Heated Oxygen Sensor, RH Heated Oxygen Sensor
- 5 - 10 Amp PCM/IGN Powertrain Control Module (PCM), Ignition Coil Electronic Brake Control Module
- 6 - 10 Amp FUEL INJ Fuel Injector (1, 4, 6, 7)
- 7 - 10 Amp PRI-FAN Primary Engine Coolant Fan, A/C Compressor Relay
- 8 - 10 Amp SEC-FAN Secondary Engine Coolant Fan, Generator
- 9 - 10 Amp FUEL INJ Fuel Injector (2, 3, 5, 8)
- 10 - 60 Amp BODY 1 Main
- 11 - 60 Amp BODY 2 Fuse Block
- 12 - 40 Amp PRI COOL FAN Primary Engine Coolant Fan
- 13 - 40 Amp SEC COOL FAN Secondary Engine Coolant Fan
Relay Identification
- A - Fuel Pump Relay
- B - A/C COMP Relay
- C - Air Pump Relay
- D - PRI - Cool Relay
- E - SEC - Cool Relay
Scheme 16
Fuse Identification
- 1 - Blank
- 2 - Blank
- 3 - Blank
- 4 - Blank
- 5 - Blank
- 6 - Blank
- 7 - 10 Amp (SEO - Police Models) HUD Projector, Night Vision Control Unit, Auxiliary Display
- 8 - 15 Amp Rear Wiper
- 9 - 15 Amp Radio
- 10 - 25 Amp Windshield Wiper Motor Module
- 11 - 10 Amp Rear Defogger Relay, Air Bag (DERM), I/P Cluster, Headlamp Switch
- 12 - 15 Amp Turn Signals, Back-up Lamp, PRNDL Position Sensor
- 13 - 10 Amp Automatic Inside Rearview Mirror, Chime Module, TCC Cruise Brake Sw., Twilight Sentinel, Daytime Running Lights Canada), Keyless Entry System
- 14 - 10 Amp Pass-Key II
- 15 - 15 Amp Air Bag (DERM)
- 16 - 10 Amp Cruise Control
- 17 - 20 Amp Heater & A/C Control
- 18 - 10 Amp Seat Heater, Power Steering Control Module
- 19 - Blank
- 20 - 10 Amp Instrument Cluster, Daytime Running Lights (Canada)
- 21 - 15 Amp (SEO - Police Models) RH Spot Lamp (Police)
- 22 - 15 Amp (SEO - Police Models) LH Spot Lamp (Police)
- 23 - Blank
- 24 - 10 Amp Air Bag, Theft Deterrent Relay
- 25 - Blank
- 26 - 10 Amp (SEO - Police Models) Night Vision Roof Unit (Police)
- 27 - 10 Amp Automatic Level Control, Trunk Lamp
- 28 - 20 Amp Cigarette Lighter
- 29 - 20 Amp Keyless Entry System, Trunk Release, Rear Glass Release Liftgate Wiper Latch Sw. (Wagon)
- 30 - 15 Amp Radio
- 31 - 20 Amp Headlamp Switch, Twilight Sentinel, Daytime Running Lights Canada)
- 32 - 25 Amp Horn Relay
- 33 - 10 Amp Chime Module, Heater and A/C, Glove Box Light, Instrument Cluster
- 34 - 10 Amp Pass-Key II
- 35 - 15 Amp Dome Lamp, Front Reading Lights, Rear Reading Lights, Automatic Inside Rearview Mirror, Illuminated Visor Vanity Mirror, Power Door Locks, Front Door Courtesy Lights, Rear Door Courtesy Lights, Power Mirror Sw. Instrument Panel Courtesy Lights
- 36 - 15 Amp Rear Wiper (Wagon)
- 37 - 20 Amp Hazard Warning Flasher, Stop Lights
- 38 - 30 Amp Blower Motor Control
- 39 - 20 Amp Power Door Lock Relay
- 40 - 20 Amp Heated Seats
- 41 - 10 Amp Cornering Lamps, Side Marker Lamp, Turn-Park Lamp
- 42 - 10 Amp Instrument Cluster, Radio, Brightness Control, Headlamp and Instrument Panel Lamp Dimmer Sw., Panel Lamps Dimming Module
- 43 - 10 Amp License Lights, Taillights, Tail/Stop/Turn Lights, Marker Lamps
- 44 - 10 Amp Heater Power Mirrors
- 45 - 10 Amp (SEO - Police Models) HUD Projector
Circuit Breaker Identification
- 1 - 20 Amp (Circuit Breaker) Power Seat Recline, Lumbar Support, Power Antenna Relay
- 2 - 30 Amp (Circuit Breaker) Power Window Switch, Power Window Lockout Switch
- 3 - 25 Amp (Circuit Breaker) Door Locks, Power Seat Switch
- 4 - 30 Amp (Circuit Breaker) Rear Window Defogger Switch
- 5 - Not Used
Scheme 17
| WARNING | Always disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician. |
Fuse Identification
- 1 - 25 Amp ELC Automatic Level Control Air Compressor (ALC)
- 2 - 15 Amp F/P Fuel Pump Relay, Fuel Pump and Engine Oil Pressure Switch Powertrain Control Module (PCM)
- 3 - 25 Amp AIR Primary Air Pump Relay, Underhood Lamp
- 4 - 15 Amp EMI Automatic Transmission, Mass Air Flow Sensor (MAF), Secondary Air Pump Relay, EGR Control Valve Relay, Evaporative Emission Canister Purge Valve Solenoid, LH Heated Oxygen Sensor, RH Heated Oxygen Sensor
- 5 - 10 Amp PCM/IGN Powertrain Control Module (PCM), Ignition Coil Electronic Brake Control Module
- 6 - 10 Amp FUEL INJ Fuel Injector (1, 4, 6, 7)
- 7 - 10 Amp PRI-FAN Primary Engine Coolant Fan, A/C Compressor Relay
- 8 - 10 Amp SEC-FAN Secondary Engine Coolant Fan, Generator
- 9 - 10 Amp FUEL INJ Fuel Injector (2, 3, 5, 8)
- 10 - 80 Amp BODY 1 Main
- 11 - 60 Amp BODY 2 Fuse Block
- 12 - 40 Amp PRI COOL FAN Primary Engine Coolant Fan
- 13 - 40 Amp SEC COOL FAN Secondary Engine Coolant Fan
Relay Identification
- A - Fuel Pump Relay
- B - A/C COMP Relay
- C - Air Pump Relay
- D - PRI - Cool Relay
- E - SEC - Cool Relay
