Installation Chevrolet Camaro IV рестайлинг

Automatic Transmission Servicing 9 illustrations ~832 words

Installation

  1. Install a new 3-4 accumulator piston seal (1) to the 3-4 accumulator piston. (Scheme 131) Install the 3-4 accumulator pin (1) into the transmission case and retain the pin with Transjel(tm) (J-36850). (Scheme 134) Install the 3-4 accumulator piston (2) onto the pin (1) in the transmission case. Ensure that the 3-4 accumulator piston legs face away from the transmission case.
  2. Install the locating pins (J-25025-B) (2, 3) to the transmission case. (Scheme 135) Install the spacer plate-to-transmission case gasket and the spacer plate-to-valve body gasket to the spacer plate; use Transjel(tm) (J-36850) in order to retain the gaskets to the spacer plate. (Scheme 133) The case gasket is identified by a "C". Be sure to place the case gasket on the transmission case side of the spacer plate.
  3. The valve body gasket is identified by a "V". Be sure to place the valve body gasket on the valve body side of the spacer plate. Ensure that the solenoid screens (1, 2) are in place on the spacer plate. Place the check ball (3) on the spacer plate in the location shown. Place the 3-4 accumulator spring (4) on the spacer plate. (Scheme 136) Install the spacer plate and related components to the transmission.
  4. Install the spacer plate support and the spacer plate support retaining bolts. (Scheme 132) Tighten the spacer plate support retaining bolts to specification. See «TORQUE SPECIFICATIONS»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__torque-specifications). After installing the spacer plate support (2), look through the hole in the spacer plate to ensure that the check ball (1) has remained in the proper location. (Scheme 137) Install a new 1-2 accumulator piston seal (1) to the 1-2 accumulator piston. (Scheme 131)
  5. Install the 1-2 accumulator inner and outer springs to the 1-2 accumulator cover. Install the 1-2 accumulator piston onto the pin in the 1-2 accumulator cover. Ensure that the piston legs face the accumulator cover. (Scheme 130) Install the 1-2 accumulator cover and the accumulator cover retaining bolts. (Scheme 129) Tighten the accumulator cover retaining bolts to specification. See «TORQUE SPECIFICATIONS»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__torque-specifications). Remove the guide pins from the transmission case.
  6. Install the control valve body. See «VALVE BODY & PRESSURE SWITCHES»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing). Install the transmission oil pan and filter. See «DRAINING & REFILLING»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__draining-refilling) under LUBRICATION. Lower the vehicle. Fill the transmission to the proper level with appropriate fluid. See «LUBRICATION»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__lubrication).

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137
  1. Raise and suitably support the vehicle. Remove the propeller shaft. See appropriate DRIVESHAFT & UNIVERSAL JOINTS article in DRIVE AXLES. Remove the rear axle torque arm. See appropriate REAR article in SUSPENSION.
  2. Remove the catalytic converter hanger. Remove the case extension bolts (1). Remove the case extension (2). Remove the case extension O-ring (3). (Scheme 138) Discard the O-ring (3). Remove the case extension seal. Remove the output shaft sleeve (1), if necessary. (Scheme 139) Remove the output shaft seal (2), if necessary.

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139
  1. Install the output shaft sleeve seal (2), if necessary. (Scheme 139) Install the output shaft sleeve (1) using (J-21426), if necessary. Install a new case extension seal using a soft face hammer and (J-21426). (Scheme 140) Install a new case extension O-ring (3). Install the case extension (2).
  2. Install the case extension bolts (1). Tighten the case extension bolts (1) to 26 ft. lbs. (35 N.m). Install the rear axle torque arm. See appropriate REAR article in SUSPENSION.
  3. Install the propeller shaft. See appropriate DRIVESHAFT & UNIVERSAL JOINTS article in DRIVE AXLES. Install the catalytic converter hanger. Lower the vehicle. Check the transmission fluid level.

Scheme 140

Scheme 140
Scheme 140
  1. Remove the transmission oil pan and filter. See «DRAINING & REFILLING»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__draining-refilling) under LUBRICATION. Remove the 1-2 accumulator if necessary. See «ACCUMULATOR ASSEMBLY, SPACER PLATE & GASKETS»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing).
  2. Disconnect the internal wiring harness electrical connectors from the following components: transmission fluid pressure switch, 1-2 shift control solenoid, 2-3 shift control solenoid, pressure control solenoid, TCC PWM solenoid and 3-2 control solenoid. (Scheme 170)
  3. Remove the pressure control solenoid retainer. Remove the pressure control solenoid. (Scheme 141) Remove the 1-2 and 2-3 shift solenoid retainers. Remove the 1-2 and 2-3 shift solenoids. (Scheme 142) Remove the 3-2 control solenoid retainer. Remove the 3-2 control solenoid. (Scheme 143)

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143
  1. Install the 3-2 control solenoid. Install the 3-2 control solenoid retainer. (Scheme 143) Install the 1-2 and 2-3 shift solenoids. Install the 1-2 and 2-3 shift solenoid retainers. (Scheme 142) Install the pressure control solenoid. Ensure that the electrical tabs are facing outboard. Install the pressure control solenoid retainer and retaining bolt. (Scheme 141) Tighten the pressure control solenoid retaining bolt to specification. See «TORQUE SPECIFICATIONS»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__torque-specifications).
  2. Connect the internal wiring harness electrical connectors to the following components: transmission fluid pressure switch, 1-2 shift control solenoid, 2-3 shift control solenoid, pressure control solenoid, TCC PWM solenoid and 3-2 control solenoid. (Scheme 170) Install the 1-2 accumulator. See «ACCUMULATOR ASSEMBLY, SPACER PLATE & GASKETS»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing).
  3. Install the transmission oil pan and filter. See «DRAINING & REFILLING»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__draining-refilling) under LUBRICATION. Fill the transmission to the proper level with appropriate fluid. See «LUBRICATION»(/chevrolet/camaro/iv-1998-2002/remont/automatic-trans/#automatic-transmission-servicing__lubrication).
