VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 1
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Severe Service
- Short Trips (4 Miles Or Less)
- Towing Or Heavily Loaded
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
- Trips Less Than 10 Miles In Freezing Temperatures
Normal Service
- No Severe Service Operating Conditions
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
SERVICE LABOR TIMES
Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
TIRE INFLATION
The tire specification decal is located on the rear of the driver's door.
WHEEL TIGHTENING
Tighten all wheel lug nuts to 100 ft. lbs. (140 N.m).
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
1993-96
3.4L and 3.8L engines use Group 75-60 batteries.
5.7L engines use Group 75Z-72 batteries.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
ANTI-LOCK BRAKE SYSTEM (ABS)
| CAUTION | Never mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors. |
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below. |
REPLACING BLOWN FUSES
| CAUTION | Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload. |
BRAKE PAD WEAR INDICATOR
| CAUTION | Indicator will cause a squealing or scraping noise, warning that brake pads need replacement. |
CATALYTIC CONVERTER
| CAUTION | Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle. |
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C); Ethylene-Glycol -35° F (-37°C) - 263° F (128°C). |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
SPARK PLUGS
Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.
TRACTION CONTROL SYSTEM (IF EQUIPPED)
| CAUTION | If tires are allowed to spin at high speeds when TRACTION OFF light is on, tires can explode. Also, spinning the tires with the warning light on can cause the transaxle to overheat. DO NOT spin wheels above 35 MPH. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
BASIC NEW CAR LIMITED WARRANTY (1987-88)
Everything is covered for 12 months or 12,000 miles, whichever occurs first. Warranty covers cost of all parts and labor needed to repair or adjust any items (except tires) that have been proven defective in material, workmanship or factory preparation under normal vehicle use.
POWERTRAIN WARRANTY
Powertrain warranty takes effect upon the expiration of the 12-month/12,000-mile Basic New Car Limited Warranty and last for 6 years or 60,000 miles whichever occurs first. Covers all moving internal and external parts, including seals and water pump on engine and clutch cover and U-joints on transaxle. Items not covered include accessory drive belts, clutch discs and brake pads.
BUMPER TO BUMPER PLUS COVERAGE LIMITED WARRANTY (1993)
Everything covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are covered up to their first scheduled replacement interval only.
Note. 1993 vehicles are covered for 3 years or 36,000 miles with no deductible.
SUPPLEMENTAL INFLATABLE RESTRAINT COVERAGE
Begins at Warranty Start Date and lasts 3 years regardless of mileage.
CORROSION COVERAGE
Begins at Warranty Start Date and lasts 6 years or 100,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.
FEDERAL EMISSIONS DEFECT & PERFORMANCE WARRANTY EXCEPT CALIFORNIA)
Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.
The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a Federally required state or local emissions test.
Other emission control parts related to these components are covered by the Performance warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.
EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
EMISSION "DEFECT" WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
Scheme 9
Fuse & Circuit Breaker Identification
- 1 - 15 Amp Air Bag, SIR Components
- 2 - 20 Amp Back-Up Lights, Turn Flasher, DRL Module (Canada)
- 3 - 25 Amp HVAC Selector Switch, Rear Defogger
- 4 - 10 Amp (1993-94) Engine Control Module (1993), Instrument Cluster, Powertrain Control Module (1994), PASS-Key II Decoder Module 25 Amp (1995) (If Equipped) Radio - Bose Sound System, Remote CD Changer, Power Antenna
- 5 - 15 Amp Engine Control Module (1993), PASS-Key II Decoder Module, Powertrain Control Module (1994-95), Fuel Pump Relay
- 6 - 20 Amp Brake Light/Cruise Release Switch, Hazard Flasher
- 7 - 15 Amp Power Door Locks, Power Mirrors, Hatch Release
- 8 - 15 Amp Amplifier, Audio Alarm, Courtesy/Glove Box/Dome Lights, Console Compartment, Remote Lock Control, Rearview Mirror, Radio, Hatch Release (1995)
- 9 - 10 Amp Audio Alarm System, DRL Module (Canada), Instrument Cluster, Diagnostic Energy Reserve Module (DERM), Remote Lock Control
- 10 - 20 Amp Exterior Lights
- 11 - 25 Amp Horn Relay, Cigarette Lighter
- 12 - 35 Amp (Circuit Breaker) (1993) Power Seats, Rear Defogger 30 Amp (Circuit Breaker) (1994-95) Power Seats, Rear Defogger
- 13 - 5 Amp Instrument Panel Lamp Brightness Control
- 14 - 25 Amp Windshield Wiper/Washer
- 15 - 35 Amp (Circuit Breaker) (1993) Power Windows 30 Amp (Circuit Breaker) (1994-95) Power Windows, Convertible Top Switch
- 16 - 3 Amp Diagnostic Energy Reserve Module (DERM)
- 17 - 15 Amp Radio, Steering Wheel Controls
Fuse Panel Identification (1996 Camaro). Scheme 10
- 1 - 20 Amp Hazard Flasher, Brake Switch
- 2 - 15 Amp Traction Control Switch, Transmission Range Switch, Back-Up Light Switch, Turn Flasher, DRL Module (Canada)
- 3 - 15 Amp Powertrain Control Module (PCM), Fuel Pump Relay
- 4 - 25 Amp Radio Power Antenna, Bose Relay, Remote CD Changer
- 5 - 20 Amp Daytime Running Lamps (DRL) Module, Headlight Switch
- 6 - 20 Amp HVAC Selector Switch, Rear Defogger Timer/Relay, Rear Defogger Switch, Rear Defogger Switch/Timer
- 7 - 15 Amp Park Lamp Relay, Hatch Release Relay, Power Mirror Switch, Radio, Shock Sensor, Instrument Cluster
- 8 - 20 Amp Body Control Module (BCM)
- 9 - 10 Amp Body Control Module (BCM), Brake Switch (BTSI), Instrument Cluster, (DRL) Module, Auxiliary Accessory Wire
- 10 - 15 Amp Inflatable Restraint Diagnostic Energy Reserve Module (SDM)
- 11 - 25 Amp Cigar lighter, Data Link Connector (DLC), Auxiliary Accessory Wire
- 12 - 30 Amp (Circuit Breaker) Rear Defogger Switch/Timer, Rear Defogger Timer/Relay, Power Seats
- 13 - 10 Amp Powertrain Control Module (PCM), EVAP Canister Purge Vacuum Switch, EVAP Canister Purge Valve, Transmission, Exhaust Gas Recirculation (EGR) Valve
- 14 - 25 Amp Wiper Motor Assembly, Wiper/Washer Switch
- 15 - 30 Amp (Circuit Breaker) Power Window Switch (RH, LH), Power Window Control Module, Convertible Top Switch
- 16 - 5 Amp Door Illuminating Lamp (LH, RH), Headlight Switch, Fog Lamp Switch, Instrument Cluster, HVAC Control Assy, PRNDL Illumination Lamp, Ashtray Lamp, Radio, Steering Wheel Controls-Radio, Rear Window Defogger Switch/Timer, Traction Control Switch
- 17 - 15 Amp Body Control Module (BCM), Radio, Amplifier, Steering Wheel COntrols-Radio
Scheme 11
Fuse & Relay Identification
- 1 - 5 Amp ABS Electronic Brake Control
- 2 - 20 Amp Fog Lights
- 3 - Not Used
- 4 - Not Used
- 5 - 5 Amp ABS Brake System
- 6 - 10 Amp Coolant Fan Relays, EVAP Canister Purge Solenoid, EGR, Reverse Lockout Solenoid, Low Coolant Relay
- 7 - 20 Amp Air Injection Pump, AIR Pump Relay
- 8 - Not Used (1993-94) 10 Amp (1995) 3.8L VIN K) Powertrain Control Module (PCM)
- 9 - 7.5 Amp Fuel Injectors
- 10 - 7.5 Amp Fuel Injectors
- 11 - 10 Amp 3.8L VIN K): Camshaft Position Sensor, Crankshaft Position Sensor, Electronic Ignition Module (1995) 5.7L VIN P): Ignition Coil Ignition Coil Driver 3.4L VIN S): Camshaft Position Sensor, Crankshaft Position Sensor, Electronic Ignition Module
- 12 - 20 Amp A/C Compressor Relay, Cruise Control Switches and Module, Low Coolant Relay
- 13 - Relay A/C Compressor
- 14 - Relay ABS Brake System
- 15 - Relay Primary (Driver) Coolant Fan
- 16 - Relay AIR Pump
- 17 - Relay Secondary (Passenger) Coolant Fan
- 18 - Relay Low Coolant (1993), ASR (1994-95)
- 19 - Relay Fog Lights
- 20 - Relay High Blower (1993), Not Used (1994-95)
- 1 - 5 Amp ABS Electronic Brake Control Module, ABS - ASR/TCS Relay
- 2 - 15 Amp EVAP Canister Purge Soleniod Valve, Powertrain Control Module PCM) (V6, VIN K)
- 3 - 15 Amp (Firebird) Headlamp Door Module
- 4 - 15 Amp (Firebird) Headlamp Door Module
- 5 - 20 Amp ABS Brake Pressure Valve Soleniods
- 6 - 5 Amp Electronic Brake Control Module (EBCM), or Electronic Brake/Traction Control Module (EBTCM)
- 7 - 20 Amp Coolant Fans Relays, AIR Pump Relay
- 8 - 20 Amp Horn Relay
- 9 - 15 Amp Fuel Injectors
- 10 - 20 Amp Heated Oxygen Sensors, Mass Air Flow Sensor, Brake Switch TCC), Reverse Lockout Solenoid, Skip Shift Solenoid
- 11 - 10 Amp Ignition Coil, Crankshaft Position Sensor, Electronic Ignition Control Module
- 12 - 20 Amp A/C Compressor Relay, Cruise Control Switches and Module
- 13 - Relay A/C Compressor
- 14 - Relay ABS Brake System
- 15 - Relay Coolant Fan #1
- 16 - Relay AIR Pump
- 17 - Relay Coolant Fan #2
- 18 - Relay
- 19 - Relay Fog Lights
- 20 - Relay Coolant Fan #3
