Fuse Block and Flasher Locations. Scheme 1
Scheme 1: Fuse Block and Flasher Locations
| Application | Location |
|---|
| Caballero & El Camino |
| Fuse Block | Near Parking Brake |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | On Fuse Block |
| Camaro, Caprice & Impala |
| Fuse Block | Near Parking Brake |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | On Fuse Block |
| Cavalier |
| Fuse Block | Near Parking Brake |
| Hazard Flasher | Near Glove Box |
| Turn Signal Flasher | Left of Steering Column |
| Celebrity & Citation |
| Fuse Block | Near Parking Brake |
| Hazard Flasher | Near Glove Box |
| Turn Signal Flasher | Left of Steering Column |
| Chevette |
| Fuse Block | Near Parking Brake |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | Right of Steering Column |
| Malibu & Monte Carlo |
| Fuse Block | Near Parking Brake |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | On Fuse Block |
| (1) Numbers refer to locations on Graphic. (Scheme 1) |
| (1) | Numbers refer to locations on Graphic. (Scheme 1) |
FUSE BLOCK & FLASHER LOCATIONS (1)
