MODEL IDENTIFICATION

Series (1)Model
"C"2WD Pickup, Sierra & Suburban
"G"(2) Van
"K"4WD Blazer, Pickup, Sierra, Suburban & Yukon
"P"Commercial Van
(1) Vehicle series is fifth character of VIN. (2) Includes Rally Van and Vandura.
(1)Vehicle series is fifth character of VIN.
(2)Includes Rally Van and Vandura.

MODEL IDENTIFICATION

INTRODUCTION

The following diagnostic steps help prevent overlooking simple problems. This is also where to begin diagnosis for no-start condition.

The first step in diagnosing any driveability problem is verifying the customer's complaint by test driving vehicle under the conditions in which the problem reportedly occurred.

Before entering self-diagnostics, perform a careful and complete visual inspection. Most engine control problems result from mechanical breakdowns, poor electrical connections or damaged/misrouted vacuum hoses. Before condemning the computerized system, perform each test listed in this article.

Note. Unless otherwise instructed in test procedures, perform all voltage tests using a Digital Volt-Ohmmeter (DVOM) with a minimum 10-megohm input impedance.

Note. Following table provides location of commonly used diagnostic information. These former "A" and "C" charts are now written in text and inserted into appropriate location of engine performance workflow. To learn about engine performance workflow, see AA - USING THIS SECTION (GENERAL HELP INFORMATION) article in GENERAL INFORMATION section.

System or ComponentDiagnostic Information Location
DIAGNOSTIC CIRCUIT CHECKSee DIAGNOSTIC CIRCUIT CHECK
A-1 & A-2, Malfunction Indicator Light (MIL)See DIAGNOSTIC CIRCUIT CHECK
A-3, No-StartSee A-3, NO-START DIAGNOSIS
A-6 & A-7, Fuel System DiagnosisSee BASIC FUEL SYSTEM CHECKS

GENERAL MOTORS "A" & "C" CHART REFERENCE

VISUAL INSPECTION

Visually inspect all electrical wiring. Look for chafed, stretched, cut or pinched wiring. Ensure electrical connectors fit tightly and are not corroded. Ensure vacuum hoses are properly routed and not pinched or cut. If necessary, see appropriate VACUUM DIAGRAMS article to verify routing and connections. Inspect air induction system for possible vacuum leaks.

  1. «VACUUM DIAGRAMS»(ref-19754) (for "C" & "K" Series)
  2. «VACUUM DIAGRAMS»(ref-19758) (For "G" & "P" Series)

Compression

Check engine mechanical condition using a compression gauge, vacuum gauge or engine analyzer capable of performing a relative compression test. If using engine analyzer, see engine analyzer instruction manual for availability and description of relative compression feature.

WARNINGBecause fuel injectors on many models are triggered by ignition switch during cranking mode, DO NOT use ignition switch during compression tests on fuel injected vehicles. Use a remote starter to crank engine to prevent fire hazard or engine's oiling system contamination.

Exhaust System Backpressure

Before replacing any components, check exhaust system for restrictions. Use a vacuum gauge or a low-pressure (1-5 psi) pressure gauge to check exhaust system.

If using a vacuum gauge, connect gauge to intake manifold vacuum, and start engine. Observe gauge while holding throttle steady at 2000-2500 RPM. If vacuum gauge reading slowly drops after stabilizing, exhaust system may be restricted.

  1. Check At AIR Pipe

Remove rubber hose at exhaust manifold AIR pipe check valve, and remove check valve. Install pressure gauge to hose and nipple via Propane Enrichment Device (J26911). Nipple should be inserted into exhaust manifold AIR pipe.

  1. Check At Oxygen Sensor

Remove oxygen sensor. Install backpressure tester in place of oxygen sensor. After test is completed, coat oxygen sensor threads with anti-seize compound before installation.

  1. Diagnosis

Check exhaust system for collapsed pipe, heat distress and possible internal muffler failure. If none of these conditions exists, check for restricted catalytic converter. Replace as required. Start engine and bring to operating temperature. Increase engine speed to 2000-2500 RPM. Note gauge. Exhaust system is restricted if reading exceeds 1.25 psi (.09 kg/cm 2 ).

A-3, NO-START DIAGNOSIS

Note. For diesel information, see appropriate G - DIESEL TESTS W/ CODES article below and TESTS W/O CODES - 6.5L DIESEL article in the ENGINE PERFORMANCE section.

  1. «TESTS W/CODES - 6.5L DIESEL»(/chevrolet/cab-chassis-k3500/1989-2000/remont/testing-diagnostics/#engine-controls-tests-wcodes-65l-diesel) (for "C" & "K" Series)
  2. «TESTS W/CODES - 6.5L DIESEL»(ref-19761) (for "G" & "P" Series)

Definition

No-start is defined as engine cranks okay but does not start. Engine may fire a few times.

FUEL PUMP FLOW TEST

  1. Disconnect fuel line at fuel filter inlet. Disconnect fuel injection pump electric shut-off solenoid wire (Pink).
  2. Crank engine 15 seconds. If fuel pump does not supply approximately 1/2 pint of fuel in 15 seconds, go to «FUEL SYSTEM PRESSURE TEST»(/chevrolet/cab-chassis-k3500/1989-2000/remont/testing-diagnostics/#engine-controls-basic-testing-65l-diesel__fuel-system-pressure-test) .

FUEL SYSTEM PRESSURE TEST

CAUTIONBegin fuel system trouble shooting and diagnosis with fuel system pressure test. Relieve fuel system pressure before disconnecting any components or installing fuel pressure gauge. See FUEL SYSTEM PRESSURE RELIEF under A-7, BASIC FUEL SYSTEM CHECKS (GASOLINE).
  1. Turn engine off. Disconnect fuel line at inlet to fuel filter assembly. Install low pressure fuel gauge to fuel line.
  2. Crank or run engine 10-15 seconds. If fuel pressure is not 5.8-8.7 psi (.41-.61 kg/cm 2 ), check fuel lines and fuel tank sending unit for restriction. If fuel lines and sending unit are okay, replace fuel pump.

DIAGNOSTIC CIRCUIT CHECK

Note. 6.5L with light duty emissions is equipped with a self-diagnostic system. For information on diagnostic system check and retrieving codes, see appropriate G - 6.5L DIESEL TESTS W/ CODES article in the ENGINE PERFORMANCE section below.

  1. «TESTS W/CODES - 6.5L DIESEL»(/chevrolet/cab-chassis-k3500/1989-2000/remont/testing-diagnostics/#engine-controls-tests-wcodes-65l-diesel) (for "C" & "K" Series)
  2. «TESTS W/CODES - 6.5L DIESEL»(ref-19761) (for "G" & "P" Series)

Preliminary Inspection

  1. Check all vacuum hoses for incorrect routing, restrictions, cuts and other damage. Inspect hoses beneath air cleaner assembly and other engine components.
  2. Inspect all wires in engine compartment for correct and good connections. Also check wires for pinched or chaffed spots, as well as contact with sharp edges or exhaust manifolds. (Scheme 262)or (Scheme 263).
  3. Perform preliminary inspection carefully and thoroughly. A thorough inspection can often identify cause of problem without further diagnosis.

Diagnostic Procedure

  1. Ensure all engine systems not related to Diesel Electronic Control (DEC) system are operating properly. DO NOT proceed with testing unless all problems not related to DEC system have been repaired. DEC system diagnosis should always begin with DIAGNOSTIC SYSTEM CHECK chart under DIAGNOSTIC CHARTS in appropriate G - 6.5L DIESEL TESTS W/ CODES article in the ENGINE PERFORMANCE section below. Performing this check determines whether DEC system and ECM are working properly. «TESTS W/CODES - 6.5L DIESEL»(/chevrolet/cab-chassis-k3500/1989-2000/remont/testing-diagnostics/#engine-controls-tests-wcodes-65l-diesel) (for "C" & "K" Series) «TESTS W/CODES - 6.5L DIESEL»(ref-19761) (for "G" & "P" Series)
  2. If trouble codes (other than Code 12) are displayed, determine whether codes are hard or intermittent trouble codes. A hard code remains until code-setting condition is repaired. Hard codes cause Malfunction Indicator Light (MIL) to come on.
  3. An intermittent code does not reset itself and is not present when vehicle is repaired. An intermittent code is often caused by loose connections. MIL goes out 10 seconds after fault goes away.

Scheme 262

Scheme 262

Scheme 263

Scheme 263

SUMMARY

If faults were not found while performing BASIC DIAGNOSTIC PROCEDURES, proceed to appropriate G - 6.5L TESTS W/ CODES article in the ENGINE PERFORMANCE section below. If no hard codes are found in self-diagnostics, or vehicle does not have a self-diagnostic system, proceed to TESTS W/O CODES - 6.5L DIESEL article in the ENGINE PERFORMANCE section for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.) or intermittent diagnostic procedures.

  1. «TESTS W/CODES - 6.5L DIESEL»(/chevrolet/cab-chassis-k3500/1989-2000/remont/testing-diagnostics/#engine-controls-tests-wcodes-65l-diesel) (for "C" & "K" Series)
  2. «TESTS W/CODES - 6.5L DIESEL»(ref-19761) (for "G" & "P" Series)

Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With M/T - 1 Of 2). Scheme 264

Scheme 264: Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With M/T - 1 Of 2)

Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With M/T - 2 Of 2). Scheme 265

Scheme 265: Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With M/T - 2 Of 2)

Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L60-E - 1 Of 2). Scheme 266

Scheme 266: Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L60-E - 1 Of 2)

Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L60-E - 2 Of 2). Scheme 267

Scheme 267: Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L60-E - 2 Of 2)

Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L80-E - 1 Of 2). Scheme 268

Scheme 268: Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L80-E - 1 Of 2)

Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L80-E - 2 Of 2). Scheme 269

Scheme 269: Wiring Diagram (Blazer, Pickup, Sierra, Suburban & Yukon - With 4L80-E - 2 Of 2)

Wiring Diagram (Van - VIN P With 4L60-E - 1 Of 2). Scheme 270

Scheme 270: Wiring Diagram (Van - VIN P With 4L60-E - 1 Of 2)

Wiring Diagram (Van - VIN P With 4L60-E - 2 Of 2). Scheme 271

Scheme 271: Wiring Diagram (Van - VIN P With 4L60-E - 2 Of 2)

Wiring Diagram (Van - VIN Y With 4L80-E). Scheme 272

Scheme 272: Wiring Diagram (Van - VIN Y With 4L80-E)

Wiring Diagram ("P" Series - Commercial - (VIN F) With 4L80-E - 1 Of 2). Scheme 273

Scheme 273: Wiring Diagram ("P" Series - Commercial - (VIN F) With 4L80-E - 1 Of 2)

Wiring Diagram ("P" Series - Commercial - (VIN F) With 4L80-E - 2 Of 2). Scheme 274

Scheme 274: Wiring Diagram ("P" Series - Commercial - (VIN F) With 4L80-E - 2 Of 2)

Wiring Diagram ("P" Series - Commercial - (VIN Y) With 4L80-E). Scheme 275

Scheme 275: Wiring Diagram ("P" Series - Commercial - (VIN Y) With 4L80-E)
