DESCRIPTION & OPERATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See 1993 COMPUTER RELEARN PROCEDURES or 1994 COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
A permanent magnet (PM) motor operates each power window. Each motor raises and lowers the glass when voltage is supplied to it. The direction the motor turns depends on polarity of the supply voltage. The switches control the supply voltage polarity.
The master door lock/power window switch assembly controls both motors. The right window switch controls only the right window motor. Each motor is protected by a built-in circuit breaker. If a window switch is held too long with the window obstructed or after the window is fully up or down, the circuit breaker opens the circuit. The circuit breaker resets automatically as it cools.
COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Convenience Center | Under Left Side of Instrument Panel. (Scheme 1) |
| Window Motor, Left Front | Inside Left Front Door |
| Window Motor, Right Front | Inside Right Front Door |
| Window Motor, Left Rear | Inside Left Rear Door |
| Window Motor, Right Rear | Inside Right Rear Door. (Scheme 3) |
| Window Switch, Left Front | On Left Trim Panel |
| Window Switch, Left Rear | On Rear Door Trim Panel |
| Window Switch, Master | On Left Front Door Trim Panel |
| Window Switch, Right Front | On Right Door Trim Panel |
| Window Switch, Right Rear | On Rear Door Trim Panel. (Scheme 3) |
| C240 | At Convenience Center. (Scheme 4) |
| C244 | At Radio |
| C247 | At Convenience Center. (Scheme 4) |
| C257 | At Convenience Center. (Scheme 4) |
| C325 | Left Body Hinge Pillar. (Scheme 4) |
| C326 | Left Body Hinge Pillar. (Scheme 4) |
| C328 | Right Body Hinge Pillar. (Scheme 4) |
| C330 | Right Body Hinge Pillar. (Scheme 4) |
| C331 | Right Body Hinge Pillar. (Scheme 4) |
| C332 | Left Body Hinge Pillar. (Scheme 4) |
| C341 | At Left Center Pillar. (Scheme 5) |
| C342 | At Right Center Pillar. (Scheme 5) |
| G202 | At DLC Connector, Under Left Side Of Instrument Panel. (Scheme 6) |
| S207 | Under Left Side Of Instrument Panel. (Scheme 7) |
| S213 | Under Left Side Of Instrument Panel, Near S207 |
| S272 | Power Window And Door Locks Harness, Near Convenience Center Leads. (Scheme 4) |
| S277 | Power Window And Door Locks Harness, Near Convenience Center Leads. (Scheme 4) |
| S279 | Power Window And Door Locks Harness, Near Convenience Center Leads. (Scheme 4) |
| S500 | Power Window And Locks Harness, Left Front Door, Near Power Window Motor Lead. (Scheme 8) |
| S501 | Power Window And Locks Harness, Left Front Door, Near Power Window Motor Lead. (Scheme 8) |
COMPONENT LOCATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
DOOR ADJUSTMENT
Note. This procedure can only be used when bolt-on service replacement hinges are installed.
Scheme 9
- Loosen the body side pillar bolts to the door hinge. Adjust door up or down, forward or rearward, and in or out at the door hinges. Adjust gap between the rocker panel and the door to the specifications (Scheme 9)
- Adjust gap between the door and the roof panel. Adjust gap between the rear of the door and the rear pillar. Adjust gap between the door and the fender. Note that door surface is flush with other panels to within 0.04"(1.0 mm). Tighten the hinge bolts to 26 ft. lbs. (35 N.m).
- Adjust bolt to properly engage the door lock. Tighten bolt to 46 ft. lbs. (63 N.m). Install door striker bolt. (Scheme 10)
Scheme 10
SYSTEM TESTS
| Symptom | Perform Test |
|---|---|
| Both Power Windows Do Not Operate - Pickup | A |
| Power Window Left Dose Not Operate Or Only Goes In One Direction - Pickup | B |
| Power Window Right Only Operates From Driver's Side Window Switch - Pickup | C |
| Power Window Right Dose Not Operate From Either Switch - Pickup | D |
| Power Window Do Not Operate From Driver's Side Window Switch - Suburban, Crew Cab & Utility | E |
| Power Windows Only Operate From Driver's Side Window Switch - Suburban, Crew Cab & Utility | F |
| Power Window Switch Illumination Lamp(s) Do Not Light | G |
| Power Windows Do Not Operate Or Only Go In One Direction - Suburban, Crew Cab & Utility | H |
SYMPTOM INDEX
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 11)
Scheme 11
TEST B: POWER WINDOW LEFT DOSE NOT OPERATE OR ONLY GOES IN ONE DIRECTION - PICKUP
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 12)
Scheme 12
TEST C: POWER WINDOW RIGHT ONLY OPERATES FROM DRIVER'S SIDE WINDOW SWITCH - PICKUP
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 13)or (Scheme 14).
Scheme 13
Scheme 14
TEST D: POWER WINDOW RIGHT DOSE NOT OPERATE FROM EITHER SWITCH - PICKUP
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 15)
Scheme 15
TEST E: POWER WINDOW DO NOT OPERATE FROM DRIVER'S SIDE WINDOW SWITCH - SUBURBAN, CREW CAB & UTILITY
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 16)
Scheme 16
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 17)
Scheme 17
TEST G: POWER WINDOW SWITCH ILLUMINATION LAMP(S) DO NOT LIGHT
Check condition of GAGES fuse. If fuse is in good condition, use the following diagnostic procedures. (Scheme 18)
Scheme 18
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, use the following diagnostic procedures. (Scheme 19)
Scheme 19
REMOVAL & INSTALLATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See 1993 COMPUTER RELEARN PROCEDURES or 1994 COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Scheme 20
Scheme 21
- Remove door trim panel. See «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows). Lower the window all the way down.
- Remove screws holding the module to the door. Pull back the water deflector. (Scheme 20)
- Disconnect lock and handle rods from the back of the module. Tape them to the door.
- Disconnect module wiring connector, if present. Pull the wiring from the door hinge pillar to reach the connector. Remove the boot over the wiring. Push the wiring harness into the door.
- Remove upper belt through window run channel (Scheme 21) Move the channel away from the glass. Tilt the module and window glass assembly and lift it out of the bottom of the door.
Installation
- Install module and glass assembly into the door. (Scheme 20) Fit the glass into the rear channel in the door.
- Install upper run channel bolt and tighten it.
- Connect lock and handle rods to the back of the module.
- Connect wiring connector if present. Pull the wiring through the boot and connect it inside the door hinge pillar.
- Install new water deflector. Refer to «WATER DEFLECTOR»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows__water-deflector).
- Install top front and the top rear module screws.
- Install module to door screws.
- Install lower run channel bolt.
- Install door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows).
Scheme 22
Scheme 23
- Remove trim panel pull strap if present. Remove the plug on each side of the strap and the screws underneath.
- Remove door handle bezel.
- Remove armrest screws.
- Remove armrest pad.
- Use Trim Pad Retainer Clip Remover (J 24595-C) to remove the retainers from the inner door panel. (Scheme 22)or (Scheme 23).
- Remove door trim pad.
- Remove bezel with switches fit through cut-out in trim panel.
- Connect retainers to the door trim panel if any remained in the door. Replace any broken retainers.
- Install bezel with switches through cut-out in trim panel.
- Put the trim pad in place on the door and push the retainers into the holes on the door.
- Install window handle if used
- Install armrest pad.
- Install T armrest screws.
- Connect door handle bezel.
- Install pull strap, if present.
Scheme 24
WATER DEFLECTOR
Water deflectors are used to seal the door inner panel and prevent water from entering into the body. The deflector is secured with a self sealing adhesive. (Scheme 25)
Removal
Remove door trim panel. Refer to DOOR TRIM PANEL . Remove water deflector by pulling it back from the door module.
Install water deflector by pressing it against the door module in the area of the adhesive to make a continuous seal. Tuck the two lower tabs through slots in the door module. Tape over tabs and slots. Install door trim panel. Refer to DOOR TRIM PANEL .
Scheme 25
WINDOW GLASS
| CAUTION | Always wear heavy gloves when handling glass to avoid the risk of personal injury. |
For window replacement (Scheme 21), (Scheme 26) and (Scheme 27).
- Roll the window all the way down.
- Remove door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows) .
- Remove module panel. Refer to «DOOR MODULE»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows) .
- Remove glass from the channel. Fold back the tab on the channel and slide the glass out
- Install glass into the channel. Fold the tab on the channel up.
- Install module and glass assembly into the bottom of the door. First fit the glass into the rear channel in the door. Fit the glass into the front run channel while pulling the channel toward the glass.
- Install upper front run channel bolt.
- Connect lock rods to module.
- Connect boot over the wiring harness from the door to the body.
- Connect wiring to the connector inside the door hinge pillar.
- Install lower front run channel bolt.
- Install lock rods to the module.
- Install new water deflector. Refer to «WATER DEFLECTOR»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows__water-deflector) .
- Install module to door screws, starting with the top front and top rear screws. Tighten the lower front run channel screw.
- Install door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows) .
WINDOW REGULATOR
Note. The power window motor is not serviced. It is replaced as a unit with the regulator.
- Disconnect negative battery cable.
- Remove door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows).
- Remove water deflector. Refer to «WATER DEFLECTOR»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows__water-deflector).
- Disconnect door lock linkage.
- Remove door module and glass. Refer to «DOOR MODULE»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows).
- Remove window, bend the tab down on the window run channel to slide the door glass, from the regulator roller assembly. (Scheme 26)and (Scheme 27).
- Remove regulator assembly rivets.
- Remove regulator and motor as a unit.
- Install regulator and motor assembly to the module panel.
- Install window, bend the tab upward on the window run channel.
- Install window and module to the door.
- Connect lock rods to the retainer clips.
- Install module panel screws, starting with the top front, and top rear screws.
- Connect door lock linkage.
- Install new water deflectors. Refer to «WATER DEFLECTOR»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows__water-deflector) .
- Install door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows) .
- Connect negative battery cable.
Scheme 26
Scheme 27
- Roll up the window. Remove door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows). Remove window run channel bolts from door. Pull back water deflector. Disconnect run channel from the door. (Scheme 21)
- Install window run channel to door. Install window run channel bolts to door. Reseal water deflector. Install door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/cab-chassis-c3500/1989-2000/remont/windows/#power-windows).
WINDOW RUN CHANNEL WEATHERSTRIP
Roll down the window. Remove window run channel weatherstrip by pulling weatherstrip from front or rear channel runs. Install window run channel weatherstrip by sliding it between run channel and glass.
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
