FUSE PANEL LOCATION
The fuse block is located behind a cover in the dash to the left of the steering column.
Scheme 1
Fuse & Circuit Breaker Identification
- 1 - Gauges 20 Amp Cruise Control, Rear Window Defogger Timer, 4-Wheel Drive Display Illumination, Auxiliary Battery Relay, Seat Belt Reminder, Cluster Ignition Feed
- 2 - Turn-B/U 15 Amp Back-Up Lights, Turn Signals
- 3 - EMC/Ign 10 Amp Torque Converter Clutch, Air Injection Reactor Diverter, Electronic Spark Control, EGR, Electronic Control Module, Anti-Lock Switch
- 4 - Inj A 10 Amp Throttle Body Injectors
- 5 - Brake 15 Amp Anti-Lock Brakes, Cluster Speedometer
- 6 - A/C Htr 25 Amp HVAC, 4-Wheel Drive, Auxiliary Battery
- 7 - Ctsy 20 Amp Courtesy Lights, Glove Box Light, Radio
- 8 - Park Lt 20 Amp Horn Relay, Horn Feed, Cigarette Lighter, Parking Lights
- 9 - P Lps 5 Amp; 20 Amp ("C" & "K" Series) C49 Switch Illumination, Headlight ON Warning, Radio Illumination, Heater & A/C Illumination, Rear Window Defogger
- 10 - Stop/Haz 15 Amp Hazard Flasher, Seat Belt Reminder, Stoplights, Rear Anti-lock Memory
- 11 - Wiper 25 Amp Windshield Washer/Wiper
- 12 - Radio 10 Amp Radio Feed
- 13 - Acc/Ign 30 Amp (Circuit Breaker) Power Windows
- 14 - Acc/Batt 30 Amp (Circuit Breaker) Door Locks, Rear Window Defogger
- 15 - Crank 5 Amp Discreet Crank
- 16 - 4WD 25 Amp 4WD; 15 Amp ("C" & "K" Series) Speedometer
- 17 - 15 Amp DRL (Canada)
