DESCRIPTION & OPERATION
| WARNING | Vehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIR BAG RESTRAINT SYSTEM article. |
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
CIRCUIT OPERATION
A permanent magnet (PM) motor operates each of the power windows. Each motor raises or lowers the glass when voltage is supplied to it. The direction the motor turns depends on the polarity of the supply voltage. The switches control the supply voltage's polarity.
The master switch assembly controls all of the motors. Each power window switch controls only one of the motors.
Each motor is protected by a built in electronic circuit breaker Positive Temperature Coefficient (PTC). If a power window switch is held too long with the window obstructed or after the window is fully up or down, the PTC resistance increases. The resistance returns to normal after voltage is removed from the motor.
MASTER SWITCH OPERATION
When the ignition switch is in RUN position, battery voltage is applied to the master switch assembly through circuit breaker No. 12 and PNK wire. See WIRING DIAGRAMS . When any of the UP switches in the master switch assembly are operated, battery voltage is applied to the power window motor through the DK BLU or DK BLU/WHT wires.
The power window motor is grounded through the DN contact in the master switch assembly. The motor runs to drive the window up. When any of the DN switches in the master switch assembly are operated, battery voltage is applied to the power window motor in the opposite direction through the BRN or TAN wires. The power window motor is grounded through the UP contact in the master switch assembly. The motor runs to drive the window down.
If the left front DN switch in the master switch assembly is pressed past the first detent, the window will travel to the full down position without holding the DN switch depressed.
POWER WINDOW SWITCH OPERATION (4-DOOR ONLY)
When the ignition switch is RUN, battery voltage is applied to the power window switches through circuit breaker 12 and the PNK wires to terminal A. See WIRING DIAGRAMS . When the UPswitch in the left rear power window switch is operated, battery voltage is applied to the left rear power window motor through the DK BLU wire.
The motor is grounded through the BRN wire, and the DN contact in the master switch assembly. The motor runs to drive the window up. When the DN switch in the left rear power switch is operated, battery voltage is applied to the left rear power window motor in the opposite direction through the BRN wire. The motor is grounded through the DK BLU wire, and the UP contact in the master switch assembly. The motor runs to drive the window down. The other windows operate similarly from their individual power window switches.
COMPONENT LOCATIONS
Note. For more information on fuses and circuit breakers, see FUSES & CIRCUIT BREAKERS article in ELECTRICAL.
| Component | Location |
|---|---|
| Fuse Block | Behind Left Side Of Instrument Panel, Near Shroud. (Scheme 1) |
| Power Window Motor | In Front Of Respective Door. (Scheme 2) |
| C211 (3 Cavities) | Behind Left Side Of Instrument Panel, Near Shroud. (Scheme 3) |
| C306 (6 Cavities) | Ahead Of Right Rear Door, At Base of Right Center Door Pillar. (Scheme 3) |
| C307 (6 Cavities) | Ahead Of Left Rear Door, At Base of Left Center Door Pillar. (Scheme 3) |
| C310 | Under Center Of Console. (Scheme 4) |
| G300 | Under Left Front Seat, Near Door Sill. (Scheme 5) |
| S310 | Convertible Harness, Below Console. (Scheme 4) |
| S311 | Crosscar Harness, Under Left Front Seat, Near Door Sill. (Scheme 3) |
| S312 | Crosscar Harness, Under Left Front Seat, Near Door Sill. (Scheme 3) |
| S318 | Convertible Harness, In Console. (Scheme 4) |
COMPONENT LOCATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
LUBRICATION
All door hardware mechanisms can be lubricated with part no. 1052349, Lubricate Spray Lube "A", part no. 1052196, Lubricate Auto-Lube "A", or equivalent.
FRONT DOOR LOCK HANDLE (BERETTA)
- Apply slight downward pressure on the lock lever.
- When holding lock lever down, rotate the outside handle-to-lock rod adjusting nut until the end of the rod is aligned with the hole in the attaching clip on the lock assembly. (Scheme 6)
- Check door lock for proper operation.
Scheme 6
Front Doors
- Remove trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Loosen the water deflector.
- Loosen the front run channel retainer bolts. (Scheme 14)
- Loose up travel stop.
- Cycle window to full-down position.
- Tighten retainer bolts finger tight.
- Cycle window to check run channel adjustments.
- Window to full position.
- Position and tighten up travel stop bolt on regulator. Tighten retainer bolts. See «TORQUE SPECIFICATIONS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__torque-specifications). Tighten up travel stop bolt.
PRELIMINARY INSPECTION
Verify customer complaint by operating suspected system. Visually inspect for obvious signs of mechanical and electrical damage. Inspect for blown fuses and damaged relays. Inspect for loose or corroded connections, damaged wiring harnesses and/or switches. Check for a broken or partially broken wire inside insulation, which could cause system malfunction but prove good in a continuity/voltage check with system disconnected. Ensure any aftermarket electronic equipment is properly installed. If fault is found, repair as necessary. If no fault is found, perform system operation check. See SYSTEM OPERATION CHECK .
- If all the power windows do not operate, check the circuit breaker 12in instrument panel fuse block.
- Check that ground G300 is clean and tight.
- If a motor's internal circuit breaker trips, it will not reset until voltage is removed from the motor.
SYSTEM OPERATION CHECK
- Use the System Check Table as a guide to normal operation. (Scheme 7)
- If problem exists, repair by symptom. See «SYMPTOM INDEX»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
Scheme 7
SYSTEM TESTS
| Symptom | Do Test |
|---|---|
| No Power Windows Operate From Any Switch. | A , B & D |
| No Power Windows Operate From The Master Switch Assembly. | A & B . |
| The Left Or Right Power Window Does Not Operate (2-Door) | B & D |
| The Left Front Power Window Does Not Operate (4-Door) | B & D |
| The Right Front, Left Rear Or Right Rear Power Window Does Not Operate From The Master Switch Assembly | B , C & D |
| A Power Window Operates From The Master Switch Assembly But Does Not Operate From Its Individual Power Window Switch (4-Door) | E |
SYMPTOM INDEX
Do the tests listed for your symptom in the Symptom Index. If your symptom does not appear in the Symptom Index, perform all of the tests.
TEST A: WINDOW POWER & GROUND TEST
To test power window power and ground (Scheme 8)
Scheme 8
TEST B: MASTER SWITCH ASSEMBLY TEST
To test master switch assembly (Scheme 9)& (Scheme 10).
Scheme 9
Scheme 10
TEST C: POWER WINDOW SWITCH TEST (4-DOOR ONLY)
To test power window switch on 4-door (Scheme 11)
Scheme 11
TEST D: POWER WINDOW MOTOR TEST
To test power window motor (Scheme 12)(Scheme 12).
Scheme 12
TEST E: POWER WINDOW SWITCH POWER TEST (4-DOOR ONLY)
To test for power at window switch, 4-door only (Scheme 13)
Scheme 13
REMOVAL & INSTALLATION
| WARNING | Vehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIR BAG RESTRAINT SYSTEM article. |
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Removal (Front Doors)
- Remove door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove inner belt sealing strip. (Scheme 14)
- Remove upper door trim panel.
- Remove front upper trim panel.
- Remove front run channel retainer.
- Remove outside mirror.
- Remove run channel by grasping channel and removing from door frame with guide assembly.
Scheme 14
Installation (Front Doors)
- Install guide assembly to door frame by engaging clips on guide assembly to door frame.
- Start at upper rear corner and working downward to seat vertical leg of channel into door frame and guide assembly, continuing below the belt line. Working forward from upper rear corner, seat channel into door window frame across top and down front portion of door and continue to belt line.
- Install outside mirror retaining nuts.
- Install front run channel retainer.
- Install the door upper trim panel.
- Install inner belt sealing strip.
- Install door trim panel.
Removal (Rear Doors)
- Remove trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove inner panel sealing strip.
- Remove guide on inside front of door upper frame. Use flat blade tool to disengage clips.
- With glass in down position. Pull front and upper part of run channel out of door frame. Slide run channel down and out of division channel. Pull up to disengage run channel from guide on glass.
Installation (Rear Doors)
- Install run channel to door frame and division bar.
- Insert front vertical leg of channel into door frame below belt line.
- Rotate the glass and engage rear guide on glass to run channel in division bar.
- Install guide. Align clip to door frame and press in to secure.
- Install inner panel sealing strip.
- Install trim panel.
- Remove the door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove sealing strip by lifting up on strip. (Scheme 15)
- Remove fastener.
- Remove Filler.
Scheme 15
- Install filler.
- Install fastener.
- Install sealing strip by placing sealing strip over door inner panel and engaging retaining clips on sealing strip to pinch-weld flange.
- Install the door trim panel.
- Remove door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove sealing strip by lifting up on strip. (Scheme 16)
- Remove fasteners.
- Remove fillers.
- Install fillers.
- Install fasteners.
- Install sealing strip by placing sealing strip over door inner panel and engaging retaining clips on sealing strip to pinch-weld flange.
- Install door trim panel.
Scheme 16
DOOR WINDOW
The door window assembly consists of a frameless piece of solid tempered safety plate glass. All styles have a rivet retained lower sash channel. The window guides on the Beretta are bonded on and are not serviceable except by replacement of the window assembly.
The service window assembly will have the guides already installed. The Corsica front door window rear guides are serviceable. The front guide is bonded to the glass and is not serviceable except by replacement of the window assembly. The service window assembly will have the guide already installed.
Removal (Front)
- Remove trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove hanger plates. See «TRIM PANEL HANGER PLATE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Remove inner panel sealing strip. See «DOOR INNER BELT SEALING STRIP & FILLER»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove rear run channel guide. See «DOOR GLASS RUN CHANNEL & GUIDE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove front run channel. Pull up to disengage rear guide on window.
- Remove front run channel retainer. See «DOOR GLASS RUN CHANNEL & GUIDE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Disengage the sash panel with window in half down position, rotate and lift window up and out of door frame.
Installation (Front)
- Install front window run channel and guide. See «DOOR GLASS RUN CHANNEL & GUIDE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Lower window into door and engage lower sash channel to regulator. engage rear guide with rear vertical section of front run channel. Raise to full up position.
- Loosely install run channel retainer 2 bolts. Cycle window to full down position. Align retainer. Tighten bolts to 97 INCH lbs. (11 N.m). Check for proper operation.
- Install inner belt sealing strip. See «DOOR INNER BELT SEALING STRIP & FILLER»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Install water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Install hanger plates. See «TRIM PANEL HANGER PLATE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Install trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
Removal (Rear Door)
- Remove trim panel. (Scheme 17)
- Remove inner belt sealing strip.
- Remove outer belt sealing strip.
- Remove hanger plate.
- Loosen the water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector).
- Mask outboard side of division channel with protective tape.
- Remove regulator to lower sash bolts.
- Remove lower glass to bottom of door and remove front portion of glass from run channel.
- Place a wedge between division channel and door outer panel.
- Remove the glass, making sure rear guide on glass is disengaged from division channel. Lift glass upward and through access created by wedging division channel and door panel.
Installation (Rear Door)
- Install glass to door from outboard side of door frame.
- Install front portion of glass run channel to door frame by lowering glass to bottom of door.
- Install rear on glass to division channel.
- Install bolts, regulator to sash. See «TORQUE SPECIFICATIONS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__torque-specifications) .
- Remove wedge and masking tape.
- Install the water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Install the hanger plate.
- Install the outer belt sealing strip.
- Install the inner belt sealing strip.
- Install the trim panel.
Scheme 17
FRONT DOOR HANDLE
Note. If replacing handle only, remove lock cylinder had anti-theft shield, and transfer to new handle assembly.
Removal (Beretta)
The outside door handles used on the Beretta are mounted on the door upper rear vertical frame. The Beretta handles have adjustable outside handle-to-lock rods. This allows for the adjustment of the amount of effort needed to operate the outer handle.
- Remove outer door handle retaining screws.
- Remove nut on top of cover assembly. (Scheme 6)
- Remove cover assembly.
- Remove upper and lower lock to door retaining nuts.
- Remove lock to handle rod clip.
- Remove lock to handle rod.
- Remove handle assembly.
Installation (Beretta)
- Place handle assembly to position on door.
- Install lock handle rod. (Scheme 6)
- Install lock handle rod clip.
- Install upper and lower door handle retaining nuts.
- Install cover assembly.
- Install nut at top of cover assembly.
- Install screws and adjust door handle. See «FRONT DOOR LOCK HANDLE (BERETTA)»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__front-door-lock-handle-beretta) under ADJUSTMENTS.
- Remove trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector).
- Remove rivet securing handle to door inner panel by first center punching a depression in head of rivet, then drilling out rivet using a 4.8 mm (3/16 in.) drill bit. (Scheme 18), (Scheme 19) and (Scheme 20).
- Inside remote handle by sliding rearward to disengage tabs on handle from slots in module assembly.
- Install inside remote handle to module assembly by placing tabs on handle into slots in module and sliding forward.
- Install rod to handle.
- Install rivet using 3/16 x 1/4 inch peel type rivets.
- Install water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Install trim panel.
Scheme 18
Scheme 19
Scheme 20
INSIDE DOOR HANDLE & LOCK ESCUTCHEON
Note. When removing a door trim panel or switch plate, the ignition switch must be in the off position. This will eliminate the possibility of shorting out the switch if a screwdriver, awl or metal object is used to remove the switch from the harness.
- Use small flat blade to disengage lock slider from lock rod.
- Remove the screws.
- Remove the escutcheon from the trim panel. (Scheme 21)
- Remove the wire connector from switch.
- Remove the switch.
Scheme 21
- Install the switch to the escutcheon.
- Install the wire connector to switch. Install the escutcheon over the inside lock handle and lock rod.
- Install the escutcheon over inside lock handle and lock rod.
- Install the escutcheon to trim panel.
- Install the screws.
- Install the slider on the lock rod, push rearward to secure on rod.
- Use a small flat blade to disengage lock slider from lock rod. (Scheme 22)
- Remove screws.
- Remove slider on lock rod, push rearward to secure on rod.
- Install escutcheon to trim panel.
- Install screws.
- Install slider on lock rod, push rearward to secure on rod.
Scheme 22
Removal (Beretta - Front Doors)
- Remove trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove inner belt sealing strip. See «DOOR INNER BELT SEALING STRIP & FILLER»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Loosen water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector).
- Remove screws and nut from door lock pillar cover. (Scheme 6)
- Remove front window channel retainer. See «RUN CHANNEL RETAINER»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove door window. See «DOOR WINDOW»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__door-window).
- Remove outside door handle.
- Remove sealing strip retaining screws.
- Remove sealing strip. (Scheme 23)
Scheme 23
Installation (Beretta - Front Doors
- Install sealing strip.
- Install sealing strip retaining screws.
- Install outside door handle. See «FRONT DOOR HANDLE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__front-door-handle) .
- Install door window. See «DOOR WINDOW»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__door-window) .
- Replace front run channel retainer. See «RUN CHANNEL RETAINER»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Replace front door lock pillar handle cover. See «FRONT DOOR HANDLE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__front-door-handle) .
- Install water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Install door inner belt sealing strip. See «DOOR INNER BELT SEALING STRIP & FILLER»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows)
- Install trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
Removal (Corsica - Front Doors)
- Remove screw. (Scheme 24)
- Remove sealing strip by placing cloth body tape along door outer panel at bottom of sealing strip and using tool J 2772-02 or equivalent.
Installation (Corsica - Front Doors)
- Install sealing strip by locating sealing strip to door and pressing down on sealing strip at clip locations to engage fasteners on sealing strip over flange on door.
- Install screw.
- Install protective tape from door outer panel.
Scheme 24
- Remove screw. (Scheme 25)
- Remove scaling strip by placing cloth body tape along door outer panel at bottom of sealing strip and using tool J 2772-02, or equivalent, and lifting up on sealing strip to disengage clips on sealing strip from door flange.
- Install sealing strip by locating to door flange and pressing down on sealing strip at clip locations to engage clips.
- Install screw.
Scheme 25
Removal
- Remove the trim panel. «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows)
- Remove the electrical connection.
- Depress tabs to release switch from reinforcement trim panel.
Installation
- Install wire harness and connector through opening in trim panel.
- Install trim panel.
- Install electrical connection.
- Install switch to trim. Press to engage tabs.
Scheme 26
- Remove the trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove the water deflector.
- Remove the bolts. (Scheme 37)& (Scheme 38).
- Remove the front run channel retainer.
- Loosely install 2 front run channel retainer bolts. Adjust cycle window to full down position. Align retainer. Tighten bolts to 97 INCH lbs. (11 N.m).
- Install the water deflector.
- Install the trim panel.
- Remove the inside door handle and lock escutcheon. See «INSIDE DOOR HANDLE & LOCK ESCUTCHEON»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__inside-door-handle-lock-escutcheon).
- Pull handle screws using Torx #30.
- Disengage the nine clips and velcro retainer with Door Trim Removal Tool (J 38778). see scheme 47
- Pull trim upward and detach from inner sealing strip.
- Remove trim panel from door. (Scheme 27)
- Remove clips and velcro retainer from trim panel.
- Install the clip and velcro retainer into door trim panel.
- Inspect door side velcro retainer. If required, install in door inner panel. (Scheme 27)
- Position trim panel to door. Align top edge to inner sealing strip.
- Press trim panel into sealing strip.
- Route door lock harness through opening trim pad.
- Install trim panel to door inner panel. Align guide pins to slots in the inner panel.
- Position clips against holes in door inner panel.
- Apply pressure to secure velcro and engage clips.
- Pull handle screws using Torx No. 30.
- Install inside door handle and lock escutcheon.
Scheme 27
Scheme 28
- Remove inside door handle and lock escutcheon. See «INSIDE DOOR HANDLE & LOCK ESCUTCHEON»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__inside-door-handle-lock-escutcheon).
- Pull handle screws using No. 30 Torx.
- Disengage seven clips and two velcro retainers with Door Trim Removal Tool (J 38778). see scheme 47
- Pull trim upward and detach from inner sealing strip.
- Remove trim panel from door. (Scheme 29)
- Remove clips and velcro retainer from trim panel.
- Remove window switch.
- Install clips and velcro retainer into door trim panel.
- Inspect door side velcro retainer. If required, install in door inner panel.
- Position trim panel to door. Align top edge to inner sealing strip.
- Press trim panel into sealing strip.
- Install route window harness through opening in trim pad.
- Install trim panel to door inner, align guide pins to slots in the inner panel.
- Position clips against holes in door inner panel.
- Apply pressure to secure velcro and engage clips.
- Pull handle screws. Tighten screws. See «TORQUE SPECIFICATIONS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__torque-specifications) .
- Install inside door handle and lock escutcheon.
Scheme 29
Removal (Front Door Upper Trim Panel)
- Remove door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows)
- Remove screws. (Scheme 30)& (Scheme 31).
- Rotate panel to disengage upper panel from clip on Beretta. Use Door Trim Removal Tool (J 38778) to disengage clip on Corsica. see scheme 47
- Remove control cable to panel set screw.
- Remove clip on Beretta, fastener on Corsica.
Installation (Front Door Upper Trim Panel)
- Install clip, fastener to upper trim panel.
- Install control cable to panel.
- Install set screw. See «TORQUE SPECIFICATIONS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__torque-specifications) .
- Position trim panel to door. Align clip to cutout in door panel and slide up to secure on Beretta. On Corsica, align fastener to door in hole and press panel to engage fastener to inner panel.
- Install door trim panel.
Scheme 30
Scheme 31
- Remove door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows)
- Drill out rivets with a 3/16 in. drill bit.
- Remove hanger plates. (Scheme 32)
- Install hanger plates to inner panel.
- Install the rivets.
- Install the door trim panel.
Scheme 32
- Remove door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows)
- Drill out rivets with a 3/16 in. drill bit.
- Remove the hanger plate. (Scheme 33)
- Install the hanger plate to door inner panel over water deflector.
- Install rivets.
- Install door trim panel.
Scheme 33
WATER DEFLECTOR
Waterproof deflectors are used to seal the door inner panel and prevent entry of water into the body. The deflector is secured by an adhesive sealer material along the front edges, rear edges and bottom, and by the application of waterproof sealing tape. Whenever work is performed where the water deflector has been disturbed, the deflector must be properly sealed and taped to the inner panel to prevent water leaks. For service sealing, strip caulking is recommended if additional sealing material is required.
- Remove the door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove the door trim hanger plates installed over the water deflector. (Scheme 34)
- Remove the water deflector by peeling deflector off door inner panel and removing waterproof tape.
- Remove the water deflector to door inner panel, making sure that tabs on bottom of deflector are in slots in bottom of door inner panel.
- Apply waterproof tape over slots in bottom of door inner panel where water deflector tabs were installed.
- Install hanger plates.
- Install waterproof tape to any damaged areas of deflector.
- Install the trim panel.
Scheme 34
Note. To aid in removal and installation procedure refer to illustration. See .
- Remove the door trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove the door trim hanger plates installed over the water deflector. (Scheme 35)
- Remove the water deflector by peeling deflector off door inner panel and removing waterproof tape.
- Install the water deflector to door inner panel, making sure that tabs on bottom of deflector are in slots in bottom of door inner panel.
- Apply waterproof tape over slots in bottom of door inner panel where water deflector tabs were installed.
- Install hanger plates.
- Install waterproof tape to any damaged areas of deflector.
- Install the trim panel.
Scheme 35
- Remove trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove hanger plates. See «TRIM PANEL HANGER PLATE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Remove inner panel sealing strip.
- Remove rear run channel guide.
- Remove front run channel. Pull up to disengage rear guide on glass.
- Remove front run channel retainer.
- Disengage the sash channel with window in half down position, rotate and lift window up and out of door frame.
- Install glass run channel and guide.
- Lower glass into door and engage lower sash channel to regulator. Engage rear guide with rear vertical section of front run channel. Raise to full up position.
- loosely install 2 lower front run channel retainer bolts. Adjust cycle glass to full down position. Align retainer. Tighten bolts. See «TORQUE SPECIFICATIONS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__torque-specifications) .
- Install inner belt sealing strip.
- Install the water deflector.
- Install hanger plates.
- Install trim panel.
- Remove the door window glass. «WINDOW GLASS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows)
- Remove the guide by wrapping tape around blade of tool BT-7323A or equivalent and inserting tool between guide and glass at fastener. Carefully pry apart.
- Heat guide with hot air gun or soak in hot water for about one minute.
- Guide to glass by aligning to hole in glass and pressing guide together at fastener location.
- Door window channel by pulling rearward on window until guideis engaged to division channel.
- Install door window glass.
- Remove door window glass.
- Remove guide by wrapping tape around blade of tool BT-7323A or equivalent and inserting tool between guide and glass fastener. (Scheme 36) Carefully pry apart.
- Heat guide with hot air gun or soak in hot water for about one minute.
- Install guide to glass by aligning to hole in glass and pressing guide together at fastener location.
- Install door glass to rear division channel by pulling rearward on glass until guide is engaged to division channel.
- Install door glass.
Scheme 36
WINDOW REGULATORS
| CAUTION | If the electric motor removal from the regulator is required, refer to the door window electric motor removal and installation procedure. The regulator lift arm is under tension from the counterbalance spring and can cause personal injury if the sector gear is not locked in position. |
- Tape glass in full-up position. Remove the trim panel. See «TRIM PANEL»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove the hanger plates. See «TRIM PANEL HANGER PLATE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove the water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Remove the lock module.
- Remove the rivets, drill out using a 3/16 in. bit.
- Remove the regulator by disengaging roller from window sash channel, disconnect electrical connector to motor (power window systems) and removing regulator through door inner access hole.
- Install regulator through access hole and attach roller to window sash channel.
- Install electrical connector to motor.
- Install rivets using 1/4 x 1/2 inch peel type.
- Install lock module.
- Install water deflector.
- Install hanger plates.
- Install trim panel.
Scheme 37
Scheme 38
Scheme 39
- Tape glass in full-up position. Remove the trim panel.
- Remove the hanger plate. See «TRIM PANEL HANGER PLATE»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows) .
- Remove the water deflector. See «WATER DEFLECTOR»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__water-deflector) .
- Remove the screws, regulator to sash channel.
- Remove the rivets using a 3/16 in. drill bit.
- Remove electrical connector to motor.
- Remove the regulator through access hole in door inner panel.
- Install the regulator through the access hole.
- Install the electrical connector to the motor.
- Install the rivets using 1/4 x 1/2 inch peel type rivets.
- Install screws, regulator to sash channel.
- Install the water deflector.
- Install the hanger plate.
- Install the trim panel.
WINDOW REGULATOR MOTOR
Note. To aid in removal and installation procedure refer to illustration. (Scheme 40), (Scheme 42) and (Scheme 41).
- Remove the window regulator. See «WINDOW REGULATORS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__window-regulators).
- Drill a hole through the regulator sector gear and backplate, and install a bolt and nut to lock sector gear in position. Do not drill hole closer than 13 mm (1/2 in) to edge of sector gear or backplate. (Scheme 40)
- Using a 3/16 in. drill bit, drill out the ends of all three motor to regulator attaching rivets from the motor side of the assembly.
- Remove motor from regulator and the remaining portions of the rivets. Depending on the position of the regulator, it may be necessary to remove portions of one remaining rivet later.
Scheme 40
Scheme 41
- Position the new motor to regulator back plate, and with the aid of a helper, install new rivets (1/4 x 31/32 inch) by collapsing or crushing the end of the rivet with a ball been hammer. (Scheme 41)
- Once motor is secured to the back plate with two rivets, remove the bolt that was installed previously to secure the sector gear to the back plate. Use an electric power source, rotate regulator in the desired direction to provide access to the remaining rivet. NOTE: It may be necessary to grind a portion off of the sector gear to provide space to remove and install the remaining rivet. (Scheme 42)
- Once the remaining rivet can be removed, install new rivet (1/4 x 31/32 inch).
- Install regulator and motor assembly.
- Remove window regulator. See «WINDOW REGULATORS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__window-regulators) .
- Remove the motor by drilling out rivets holding motor to actuator using a 6.3 mm (1/4 in.) drill bit.
- Remove window regulator motor.
- Install the motor to regulator using a rivet (1/4 x 31/32 inch ).
- Install the window regulator.
- Remove the window regulator. See «WINDOW REGULATORS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows__window-regulators) .
- Connect regulator motor to harness connector.
- Remove tape from tabs on regulator.
- Run tape out of regulator.
- Cut service tape to 874 mm (34-1/2 in.) for power window regulator.
- Install tape to regulator.
- Slots on tape to tabs on regulator.
- Install regulator.
- Remove door window. See «WINDOW GLASS»(/chevrolet/beretta/i-1987-1996/remont/windows/#power-windows).
- Remove the rivets by using a 3/16 in. drill bit, taking care not to enlarge holes in sash channel. Replace sash if holes are enlarged during drilling operation.
- Remove sash channel and spacer. (Scheme 37)and (Scheme 38).
- Locate spacer to glass.
- Install the sash channel to spacer and glass.
- Install the rivets through holes in sash, spacer and glass using 3/16 x .527 inch aluminum dome-head blind rivets.
- Install door window.
- Remove door window and place glass on a protected surface to prevent damage.
- Remove rivets using a 3/16 in. drill bit, taking care not to enlarge holes in sash channel. If sash channel holes are enlarged during drilling operation, replace sash channel.
- Remove sash channel and spacer. (Scheme 43)
- Locate spacer to glass.
- Install sash channel to spacer and glass.
- Install rivets through holes in sash, spacer and glass using 3/16 x .527 inch aluminum dome-head blind rivet.
- Install door window.
Scheme 42
TORQUE SPECIFICATIONS
| Application | Ft. Lb. (N.m) | |
|---|---|---|
| Front Door Hinge Bolts (Body Side) | 18 (24) | |
| Front Door Hinge Nuts (Door Side) | 18 (24) | |
| Front/Rear Door Lock Striker | 39 (53) | |
| Rear Door Hinge Bolts (Body Side) | 18 (24) | |
| Rear Door Hinge Nuts (Door Side) | 18 (24) | |
| INCH Lbs. (N.m) | ||
| Front Door Outside Mirror Cable Set Screw | 9 (1) | |
| Front Door Outside Mirror Nuts | 62 (7) | |
| Front/Rear Door Lock to Door Pillar Screws | 62 (7) | |
| Front/Rear Door Pull Handle | 14 (1.6) | |
| Front Run Channel Retainer Bolts | 97 (11) | |
| Rear Door Vent Division Channel to Door | 97 (11) | |
| Rear Door Window Sash to Regulator | 75 (8.5) | |
TORQUE SPECIFICATIONS
Scheme 43
Scheme 44
Scheme 45
Scheme 46
See also:
• AIR BAG RESTRAINT SYSTEM
• COMPUTER RELEARN PROCEDURES
• FUSES & CIRCUIT BREAKERS
• WIRING DIAGRAMS
• TORQUE SPECIFICATIONS
• SYSTEM OPERATION CHECK
• A
• B
• D
• C
• E
• WATER DEFLECTOR
• FRONT DOOR LOCK HANDLE (BERETTA)
• DOOR WINDOW
• FRONT DOOR HANDLE
• INSIDE DOOR HANDLE & LOCK ESCUTCHEON
• WINDOW REGULATORS
