Wiper System & Washer System: Specifications Chevrolet Aveo I facelift

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Front Wheel Well Splash Shield Screws	1.5 N.m	13 lb in
Washer Fluid Reservoir Bolts and Nuts	9 N.m	80 lb in
Wiper Arm Linkage Nut	8.5 N.m	75 lb in
Wiper Arm Nut Front	15 N.m	11 lb ft
Wiper Arm Nut Rear	11 N.m	97 lb in
Wiper Motor Bolts	9 N.m	80 lb in

Scheme 1: Wiper/Washer Schematics (Notchback)

Scheme 2: Wiper/Washer Schematics (Hatchback)

Scheme 3: Wiper/Washer Component Views (Notchback)

Callout	Component Name
1	Wiper Motor - Rear
2	Windshield Wiper Motor
3	Windshield/Washer Fluid Pump - Front
4	Windshield/Washer Fluid Pump - Rear

Scheme 5: Wiper/Washer Component Views (Hatchback)

Callout	Component Name
1	Ignition Lock Module (North America)
1	Rear Fog Relay (LHD - w/Rear Fog)
2	Defog Relay (RHD)
2	Turn Signal/Hazard Flasher (LHD)
3	Wiper Relay
4	Park/Neutral Position (PNP) Relay (RHD)
4	Daytime Relay Lamp (DRL) Relay (Scandinavian)
5	Blink Relay
6	Blower Relay
7	Turn Signal/Hazard Flasher (RHD)
7	Park/Neutral Position (PNP) Relay (LHD)
8	Defog Relay (LHD)
8	Rear Fog Relay (RHD)
9	Fuse Block - I/P

Callout	Component Name
1	Wiper Motor - Rear
2	Windshield Wiper Motor
3	Windshield/Washer Fluid Pump - Front
4	Windshield/Washer Fluid Pump - Rear
