Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| CHMSL Mounting Screws | 3 N.m | 27 lb in |
| Cupholder Screws | 2 N.m | 18 lb in |
| Daytime Running Lamp Module Screws | 2.5 N.m | 22 lb in |
| Door Jamb Switch Screw | 4.5 N.m | 40 lb in |
| Headlamp Assembly Bolts | 6 N.m | 53 lb in |
| Interior Courtesy Lamp Housing Screws | 2 N.m | 18 lb in |
| License Plate Lamp Screws | 1.5 N.m | 13 lb in |
| Tail Lamp Assembly Screws | 3 N.m | 27 lb in |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
| Callout | Component Name |
|---|---|
| 1 | Turn Signal Lamp Assembly (Left Side Shown, Right Side Similar) |
| 2 | Fog Lamp (Left Side Shown, Right Side Similar) |
| 3 | Park/Turn Signal Lamp (North America - Left Side Shown, Right Side Similar) |
Scheme 27
| Callout | Component Name |
|---|---|
| 1 | Turn Signal Lamp Assembly - Front (Left Side Shown, Right Side Similar) |
| 2 | Tail Lamp Assembly (Left Side Shown, Right Side Similar) |
| 3 | Tail/Stop Lamps (Left Side Shown, Right Side Similar) |
| 4 | Backup Lamp/Rear Fog Lamp (Left Side Shown, Right Side Similar) |
| 5 | Turn Signal Lamp - Rear (Left Side Shown, Right Side Similar) |
| 6 | Side Marker Lamp - Rear (Left Side Shown, Right Side Similar) |
| 7 | Park/Turn Signal Lamp - Front (Left Side Shown, Right Side Similar) |
| 8 | Side Marker Lamp - Front (Left Side Shown, Right Side Similar) |
| 9 | Turn Signal Repeater Lamp (Left Side Shown, Right Side Similar) |
Scheme 28
| Callout | Component Name |
|---|---|
| 1 | Rear Compartment Lamp |
| 2 | Ashtray Lamp (Optional) |
| 3 | Rear Compartment Lid Switch |
Scheme 29
| Callout | Component Name |
|---|---|
| 1 | Headlamp Switch, Turn Signal Switch |
| 2 | Dome Lamp |
| 3 | I/P Dimmer Switch |
| 4 | Daytime Running Lamps (DRL) Control Module |
| 5 | Hazard Switch |
Scheme 30
| Callout | Component Name |
|---|---|
| 1 | Headlamp (Right Side Shown, Left Similar) |
Scheme 31
| Callout | Component Name |
|---|---|
| 1 | Headlamp Level Switch (Except North America) |
| 2 | Fog Lamp Switch - Rear (Except North America) |
| 3 | Hazard Lamp Switch |
| 4 | Shift Indicator Lamp |
| 5 | Stop Lamp Switch |
Scheme 32
| Callout | Component Name |
|---|---|
| 1 | Center High Mounted Stop Lamp |
| 2 | License Plate Lamp |
| 3 | Door Jamb Switch - (Left Rear Shown, Right Rear and Front Switches Similar) |
Scheme 33
| Callout | Component Name |
|---|---|
| 1 | Multifunction Alarm Module |
| 2 | Ignition Key Alarm Switch |
| 3 | Defogger Switch |
| 4 | Clock/Tele Tail |
| 5 | Cluster |
| 6 | Radio |
| 7 | Tweeter Right/Left Similar |
| 8 | Cigar Lighter |
| 9 | Wiper Switch |
| 10 | Blower Switch |
| 11 | Horn Switch |
| 12 | Headlamp Switch |
| Callout | Component Name |
|---|---|
| 1 | Turn Signal Lamp Assembly (Left Side Shown, Right Side Similar) |
| 2 | Fog Lamp (Left Side Shown, Right Side Similar) |
| 3 | Park/Turn Signal Lamp (North America - Left Side Shown, Right Side Similar) |
| Callout | Component Name |
|---|---|
| 1 | Turn Signal Lamp Assembly - Front (Left Side Shown, Right Side Similar) |
| 2 | Tail Lamp Assembly (Left Side Shown, Right Side Similar) |
| 3 | Tail/Stop Lamps (Left Side Shown, Right Side Similar) |
| 4 | Backup Lamp/Rear Fog Lamp (Left Side Shown, Right Side Similar) |
| 5 | Turn Signal Lamp - Rear (Left Side Shown, Right Side Similar) |
| 6 | Side Marker Lamp - Rear (Left Side Shown, Right Side Similar) |
| 7 | Park/Turn Signal Lamp - Front (Left Side Shown, Right Side Similar) |
| 8 | Side Marker Lamp - Front (Left Side Shown, Right Side Similar) |
| 9 | Turn Signal Repeater Lamp (Left Side Shown, Right Side Similar) |
| Callout | Component Name |
|---|---|
| 1 | Rear Compartment Lamp |
| 2 | Ashtray Lamp (Optional) |
| 3 | Rear Compartment Lid Switch |
| Callout | Component Name |
|---|---|
| 1 | Headlamp Switch, Turn Signal Switch |
| 2 | Dome Lamp |
| 3 | I/P Dimmer Switch |
| 4 | Daytime Running Lamps (DRL) Control Module |
| 5 | Hazard Switch |
| Callout | Component Name |
|---|---|
| 1 | Headlamp (Right Side Shown, Left Similar) |
| Callout | Component Name |
|---|---|
| 1 | Headlamp Level Switch (Except North America) |
| 2 | Fog Lamp Switch - Rear (Except North America) |
| 3 | Hazard Lamp Switch |
| 4 | Shift Indicator Lamp |
| 5 | Stop Lamp Switch |
| Callout | Component Name |
|---|---|
| 1 | Center High Mounted Stop Lamp |
| 2 | License Plate Lamp |
| 3 | Door Jamb Switch - (Left Rear Shown, Right Rear and Front Switches Similar) |
| Callout | Component Name |
|---|---|
| 1 | Multifunction Alarm Module |
| 2 | Ignition Key Alarm Switch |
| 3 | Defogger Switch |
| 4 | Clock/Tele Tail |
| 5 | Cluster |
| 6 | Radio |
| 7 | Tweeter Right/Left Similar |
| 8 | Cigar Lighter |
| 9 | Wiper Switch |
| 10 | Blower Switch |
| 11 | Horn Switch |
| 12 | Headlamp Switch |
Scheme 34
| Callout | Component Name |
|---|---|
| 1 | Ignition Lock Module (North America) |
| 1 | Rear Fog Relay (LHD - w/Rear Fog) |
| 2 | Defog Relay (RHD) |
| 2 | Turn Signal/Hazard Flasher (LHD) |
| 3 | Wiper Relay |
| 4 | Park/Neutral Position (PNP) Relay (RHD) |
| 4 | Daytime Relay Lamp (DRL) Relay (Scandinavian) |
| 5 | Blink Relay |
| 6 | Blower Relay |
| 7 | Turn Signal/Hazard Flasher (RHD) |
| 7 | Park/Neutral Position (PNP) Relay (LHD) |
| 8 | Defog Relay (LHD) |
| 8 | Rear Fog Relay (RHD) |
| 9 | Fuse Block - I/P |
Ashtray Lamp (Optional) Connector Part Information MG 610070 2-Way F 090 (2.3 mm) Series (WH) Pin Wire Circuit Function 1 BN/WH - Illumination Supply Voltage 2 BK - Ground
Backup Lamp Switch (1.6L) (M/T) Connector Part Information ZPF 2-3 or AK 7207 2-Way F Pin Wire Circuit Function A BN - Ignition 2 Voltage B L-GN - Backup Lamp Supply Voltage
Center High Mounted Stop Lamp Connector Part Information MG 610392 2-Way F Series Sealed (WH) Pin Wire Circuit Function 1 L-BU - Stop Lamp Supply Voltage/Stop Lamp Switch Signal 2 BK - Ground
Courtesy/Reading Lamp (w/o Sunroof) Connector Part Information MG 610489 2-Way F 090 (2.3 mm) Series Pin Wire Circuit Function 1 GY - Courtesy Lamp Control 2 RD/WH - Ignition 3 Voltage
Fog Lamp - Left Front Connector Part Information 12124819 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Circuit Function 1 YE - Fog Lamp Supply Voltage 2 BK - Ground
Fog Lamp - Right Front Connector Part Information 12124819 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Circuit Function 1 YE - Fog Lamp Supply Voltage 2 BK - Ground
Hazard Switch Connector Part Information MG 610056 10-Way F 090 (2.3 mm) Series (WH) Pin Wire Circuit Function 1 - - Not Used 2 BN/WH - Instrument Panel Lamps Dimming Control (w/Dimming) 3 BN/WH - Illumination Supply Voltage 4 - - Not Used 5 L-BU - Left Turn Signal Lamps Supply Voltage 6 D-BU - Right Turn Signal Lamps Supply Voltage 7 L-BU - Turn Signal Flasher Signal 8 RD/WH - Battery Positive Voltage 9 PU - Turn Signal Switch Signal PU 10 PK - Ignition Voltage
Headlamp - Left Connector Part Information OPES-PH2 3-Way Connector F (WH) Pin Wire Circuit Function 1 BN/WH - Left Headlamp High Beam Supply Voltage 2 L-GN/BK - Left Headlamp Low Beam Supply Voltage 3 BK - Ground
Headlamp - Right Connector Part Information OPES-PH2 3-Way Connector F (WH) Pin Wire Circuit Function 1 YE - Right Headlamp Low Beam Supply Voltage 2 D-GN/WH - Headlamp Leveling Motor Supply Voltage 3 BK - Ground
Headlamp Leveling Motor - Left (Except North America) Connector Part Information 164357 3-Way Pin Wire Circuit Function 1 BK - Ground 2 D-GN - Headlamp Leveling Motor Feed 3 PU - Park Lamp Feed - Left
Headlamp Leveling Motor - Right (Except North America) Connector Part Information 164357 3-Way Pin Wire Circuit Function 1 BK - Ground 2 D-GN - Headlamp Leveling Motor Feed 3 BN/WH - Park Lamp Feed - Right
Headlamp Leveling Switch (Except North America) Connector Part Information 5557-06R 6-Way Mini Fit Conn. Rec. Housing (WH) Pin Wire Circuit Function 1 BN/WH - Right Park Lamp Supply Voltage 2 L-GN/BK - Headlamp Low Beam Supply Voltage 3 D-GN - Headlamp Leveling Motor Supply Voltage 4 BN/WH - Ground 5 - - Not Used 6 BK - Ground
Headlamp Switch Connector Part Information MG 650887 6-Way F 250 III Series (NA) Pin Wire Circuit Function 1 BN/WH - Front Fog Relay Control 2 BK/WH - Headlamp Control 3 BK/WH - Ground 4 - - - 5 D-GN/WH - Front Fog Lamp Switch Signal 6 L-BU - Park Lamps Control
I/P Dimmer Switch Connector Part Information MG 610045 3-Way F 250 Series (WH) Pin Wire Circuit Function 1 BN/WH - Instrument Panel Lamps Dimming Control 2 BK - Ground 3 BN/WH - Right Park Lamp Supply Voltage
License Lamp Connector Part Information MG 630679 2-Way F 090 (2.3 mm) Series (WH) Pin Wire Circuit Function 1 BK - Ground 2 PU - Left Park Lamp Supply Voltage
Rear Compartment Lamp Connector Part Information 836277 2-Way F (GY) Pin Wire Circuit Function 1 RD/WH - Battery Voltage 2 GY/BK - Rear Compartment Lid Ajar Switch Signal
Shift Indicator Lamp Connector Part Information MG 610070 2-Way F 090 (2.3 mm) Series (WH) Pin Wire Circuit Function 1 BN/WH - Right Park Lamp Supply Voltage 2 BN/WH - Instrument Panel Lamps Dimming Control w/Dimming Ground w/o Dimming
Stop Lamp Switch Connector Part Information MG 610267 4-Way F 250 D/L Series (WH) Pin Wire Circuit Function 1 PU - Stop Lamp Supply Voltage 2 L-BU - Stop Lamp Switch Output 3 PK - Ignition Positive Voltage 4 RD/WH - Battery Positive Voltage
Tail Lamp Assembly - Left Connector Part Information 936233-1 8-Way F 090 Series (BK) Pin Wire Circuit Function 1 OG - Rear Fog Lamp Supply Voltage (Euro - LHD) 2 BK - Ground BK - Ground 3 BK - Ground 4 L-GN - Backup Lamp Feed 5 L-BU - Turn Signal Lamp Feed - Left 6 BN - Stop Lamp Supply Voltage 7 PU - Park Lamp Feed PU - Park Lamp Feed 8 PU - Park Lamp Feed
Tail Lamp Assembly - Right Connector Part Information 936233-1 8-Way F 090 Series (BK) Pin Wire Circuit Function 1 OG - Rear Fog Lamp Supply Voltage (Euro-RHD) 2 BK - Ground BK - Ground 3 BK - Ground 4 L-GN - Backup Lamp Feed 5 D-BU - Turn Signal Lamp Feed - Right 6 BN - Stop Lamp Supply Voltage 7 BN/WH - Park Lamp Feed BN/WH - Park Lamp Feed 8 BN/WH - Park Lamp Feed
Turn Signal Lamp - Left Front (North America) Connector Part Information 936187-2 3-Way F .090 Series Pin Wire Circuit Function 1 PU - Park Lamp Feed 2 BK - Ground 3 L-BU - Left Turn Signal Supply Voltage
Turn Signal Lamp - Left Front (LHD/RHD) Connector Part Information 936184-2 2-Way F .090 Series (BK) Pin Wire Circuit Function 1 BK - Ground 2 L-BU - Left Turn Signal Supply Voltage
Turn Signal Lamp - Right Front (North America) Connector Part Information 936187-2 3-Way F .090 Series Pin Wire Circuit Function 1 BN/WH - Park Lamp Feed 2 BK - Ground 3 D-BU - Right Turn Signal Supply Voltage
Turn Signal Lamp - Right Front (LHD/RHD) Connector Part Information 936184-2 2-Way F .090 Series (BK) Pin Wire Circuit Function 1 BK - Ground 2 D-BU - Right Turn Signal Supply Voltage
Turn Signal/Multifunction Switch Connector Part Information MG 610203 7-Way F 118 (PA) Series (BK) Pin Wire Circuit Function 1 L-BU - Left Turn Signal Lamps Supply Voltage 2 PU - Turn Signal Flasher Signal 3 D-BU - Right Turn Signal Lamps Supply Voltage 4 L-BU - High Beam Relay Control 5 WH - Low Beam Relay Control 6 BK/WH - Headlamp Control 7 BK - Ground BK/WH
Turn Signal Repeater Lamp - Left Connector Part Information MG 610320-5 2-Way F SWP Series (BK) Pin Wire Circuit Function 1 BK - Ground 2 L-BU - Left Turn Signal Supply Voltage
Turn Signal Repeater Lamp - Right Connector Part Information MG 610320-5 2-Way F SWP Series (BK) Pin Wire Circuit Function 1 BK - Ground 2 D-BU - Right Turn Signal Supply Voltage
Ashtray Lamp (Optional) Connector Part Information KET MG 610070 2-Way F 090 (2.3 mm) Series (WH) Pin Wire Color Circuit No. Function 1 BN/WH 309 Right Park Lamp Supply Voltage 2 BK 450 Ground
Backup Lamp - Left or Right Connector Part Information 12092379 3-Way F Lamp Socket Wedge Base W3 (WH) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B - - Not Used G BK 450 Ground
Backup Lamp Switch (1.2L) (M/T) Connector Part Information KET MG 610320 2-Way F SWP Series (BK) Pin Wire Color Circuit No. Function 1 PK 439 Ignition 1 Voltage 2 L-GN 24 Backup Lamp Supply Voltage
Backup Lamp Switch (1.4L, 1.5L, 1.6L) (M/T) Connector Part Information ZPF 2-3 or AK 7207 2-Way F Pin Wire Color Circuit No. Function A PK 439 Ignition 1 Voltage B L-GN 24 Backup Lamp Supply Voltage
Blink Relay Connector Part Information AK 36409 4-Way Relay (BK) Pin Wire Color Circuit No. Function 30 OG 1040 Battery Positive Voltage 85 L-BU 1508 Turn Signal Switch Signal 86 BK 450 Ground 87 GY 1524 Turn Signal
Center High Mounted Stop Lamp Connector Part Information KET MG 610392 2-Way F Series Sealed (WH) Pin Wire Color Circuit No. Function 1 BN 20 Stop Lamp Supply Voltage/Stop Lamp Switch Signal 2 BK 850 Ground
Daytime Running Lamp (DRL) Control Module (North America) Connector Part Information PED 12064998 8-Way Connector F (BK) Pin Wire Color Circuit No. Function A OG 140 Battery Voltage B L-GN/WH 11 Headlamp High Beam Supply Voltage C YE/D-GN 12 Headlamp Low Beam Supply Voltage D BN 233 DRL Indicator 233 E BK 450 Ground F PK 239 Ignition 1 Voltage G WH 629 DRL ON Indicator Control H - - Not Used
Scheme 35
Daytime Running Lamp (DRL) Control Module (Scandinavia) Connector Part Information F8-4 8-Way F (BK) Pin Wire Color Circuit No. Function 1 OG 140 Battery Positive Voltage 2 PU 709 Left Park Lamp Supply Voltage 3 BN 27 DRL Relay On Signal 4 YE/GN 12 Headlamp Low Beam Supply Voltage 5 BK 450 Ground 6 PK 239 Ignition 1 Voltage 7 BN/WH 309 Right Park Lamp Supply Voltage 8 GN 31 Oil Pressure Indicator Control
Scheme 36
Daytime Running Lamp (DRL) Relay (Scandinavia) Connector Part Information AK 36905 9-Way F Pin Wire Color Circuit No. Function 30 BN/WH 309 DRL Relay Supply Voltage 85 OG 340 Battery Positive Voltage 86 BN 1080 DRL Relay Control 87 BN 27 Lights On Signal
Fog Lamp - Left Front Connector Part Information PED 12124819 2-Way Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function 1 L-BU 1769 Fog Lamp Switch Supply Voltage 2 BK 250 Ground
Fog Lamp - Right Front Connector Part Information PED 12124819 2-Way Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function 1 L-BU 1769 Fog Lamp Switch Supply Voltage 2 BK 250 Ground
Fog Lamp Switch - Rear (Except North America) Connector Part Information KET MG 610152 6-Way F 090 (2.3 mm) Series (WH) Pin Wire Color Circuit No. Function 1 BN/WH 309 Right Park Lamp Supply Voltage 2 - - Not Used 3 BK 450 Ground (w/o Dimming) 4 L-GN/RD 230 Instrument Panel Lamps Dimming Control (w/Dimming) BK 450 Ground 5 - - Not Used 6 D-GN/WH 1977 Rear Fog Lamps Switch Signal
Fog Lamp - Rear (Left or Right) - w/Rear Fog Lamps Connector Part Information 12092379 3-Way F Lamp Socket Wedge Base W3 (BK) Pin Wire Color Circuit No. Function A WH 122 Rear Fog Lamps Supply Voltage B - - Not Used G BK/YE 450 Ground
Hazard Switch Connector Part Information KET MG 610056 10-Way F 090 (2.3 mm) Series (WH) Pin Wire Color Circuit No. Function 1 - - Not Used 2 L-GN/RD 230 Instrument Panel Lamps Dimming Control (w/Dimming) BK 450 Ground (w/o Dimming) 3 BN/WH 309 Right Park Lamp Supply Voltage 4 YE 18 Right Park Lamp Supply Voltage 5 D-BU 14 Left Turn Signal Lamps Supply Voltage 6 WH 15 Right Turn Signal Lamps Supply Voltage 7 L-BU 1508 Turn Signal Switch Signal 8 OG 1040 Battery Positive Voltage OG/PU Battery Positive Voltage (RHD) 9 D-GN 16 Turn Signal Flasher Signal Turn Signal Switch Supply Voltage 10 PK 339 Ignition Voltage
Headlamp - Left Connector Part Information OPES-PH2 3-Way Connector F (WH) Pin Wire Color Circuit No. Function 1 PU 311 Right Headlamp High Beam Supply Voltage 2 PU/WH 312 Right Headlamp Low Beam Supply Voltage 3 BK 150 Ground
Headlamp - Right Connector Part Information OPES-PH2 3-Way Connector F (WH) Pin Wire Color Circuit No. Function 1 GY 711 Right Headlamp Low Beam Supply Voltage 2 YE 712 Headlamp Leveling Motor Supply Voltage 3 BK 150 Ground
Headlamp Leveling Motor - Left (Except North America) Connector Part Information AMP 164357 3-Way Pin Wire Color Circuit No. Function 1 PU/WH 312 Left Headlamp Low Beam Supply Voltage 2 D-GN 189 Headlamp Leveling Motor Supply Voltage 3 BK 50 Ground
Headlamp Leveling Motor - Right (Except North America) Connector Part Information AMP 164357 3-Way Pin Wire Color Circuit No. Function 1 YE 712 Right Headlamp Low Beam Supply Voltage 2 D-GN 189 Headlamp Leveling Motor Supply Voltage 3 BK 250 Ground
Headlamp Leveling Switch (Except North America) Connector Part Information MOLEX 5557-06R 6-Way Mini Fit Conn. Rec. Housing (WH) Pin Wire Color Circuit No. Function 1 BN/WH 309 Right Park Lamp Supply Voltage 2 YE/D-GN 12 Headlamp Low Beam Supply Voltage 3 PU 189 Headlamp Leveling Motor Supply Voltage 4 BK 450 Ground 5 - - Not Used 6 BK 450 Ground
Headlamp Park Position Lamp - Left (Except North America) Connector Part Information KET MG 610320 2-Way F SWP Series (BK) Pin Wire Color Circuit No. Function 1 PU 709 Left Park Lamp Supply Voltage 2 BK 450 Ground
Headlamp Park Position Lamp - Right (Except North America) Connector Part Information KET MG 610320 2-Way F SWP Series (BK) Pin Wire Color Circuit No. Function 1 BN/WH 309 Right Park Lamp Supply Voltage 2 BK 50 Ground
Headlamp Switch Connector Part Information MOLEX 5559-06P 7-Way F Mini Fit Conn. Crimp Pin Housing (WH) Pin Wire Color Circuit No. Function 1 BN/WH 309 Battery Positive Voltage 2 WH/YE 318 Rear Fog Lamp Relay Control 3 BK 450 Ground 4 WH/BK 1346 Headlamp HI Relay Control 5 WH 352 Headlamp Low Relay Control 6 BN 1080 DRL Relay Headlamp Switch Signal 7 BK 450 Ground
I/P Dimmer Switch Connector Part Information KET MG 610045 3-Way F 250 Series (WH) Pin Wire Color Circuit No. Function 1 L-GN/RD 230 Instrument Panel Lamps Dimming Control BN/WH 2 BK 450 Ground 3 BN/WH 309 Right Park Lamp Supply Voltage
Lamp Control Module (Except North America) Connector Part Information KET MG 610054 8-Way F 090 (2.3 mm) Series Pin Wire Color Circuit No. Function 1 - - Not Used 2 BN/D-BU 1081 Park Lamp On Signal 3 BN 1080 Park Lamp Relay Control 4 OG 640 Battery Positive Voltage 5 BK 450 Ground 6 PU 126 Left Front Open Switch Signal 7 L-GN 80 Key in Ignition Switch Signal 8 - - Not Used
License Lamp Connector Part Information KET MG 630679 2-Way F 090 (2.3 mm) Series (WH) Pin Wire Color Circuit No. Function A WH 709 Left Park Lamp Supply Voltage PU B BK 450 Ground
Park/Turn Signal Lamp - Left Connector Part Information 12093279 3-Way F Lamp Socket Wedge Base W3 (BK) Pin Wire Color Circuit No. Function A YE 14 Left Turn Signal Lamps Supply Voltage B BN 709 Left Park Lamp Supply Voltage G BK 250 Ground
Park/Turn Signal Lamp - Right Connector Part Information 12093279 3-Way F Lamp Socket Wedge Base W3 (BK) Pin Wire Color Circuit No. Function A YE 15 Right Turn Signal Lamps Supply Voltage B BN 309 Right Park Lamp Supply Voltage G BK 50 Ground
Courtesy/Reading Lamp (w/o Sunroof) Connector Part Information KET MG 610489 2-Way F 090 (2.3 mm) Series Pin Wire Color Circuit No. Function 1 WH 156 Courtesy Lamp Control 2 BN 541 Ignition 3 Voltage
Rear Compartment Lamp Connector Part Information AK 36277 2-Way Connector (GY) Pin Wire Color Circuit No. Function 1 BN 541 Ignition 3 Voltage 2 OG/BK 737 Rear Compartment Lid Ajar Switch Signal
Scheme 37
Rear Compartment Lid Switch (Trunk) Connector Part Information KET ST 730173-1 1-Way 250 Series Connector (CL) Pin Wire Color Circuit No. Function 1 OG/BK 737 Rear Compartment Lid Ajar Switch Signal
Rear Fog Relay Connector Part Information AK 36907 9-Way Pin Wire Color Circuit No. Function 1 - - Not Used 2 D-GN/WH 1977 Rear Fog Lamp Switch Signal 3 - - Not Used 4 RD 122 Rear Fog Lamp Supply Voltage 5 WH/YE 318 Rear Fog Lamp Relay Coil Supply Voltage 6 RD 122 Rear Fog Lamp Supply Voltage 7 WH 13 Rear Fog Lamp Relay Coil Supply Voltage 8 BK 450 Ground 9 - - Not Used
Scheme 38
Shift Indicator Lamp Connector Part Information KET MG 610070 2-Way F 090 (2.3 mm) Series (WH) Pin Wire Color Circuit No. Function 1 BN/WH 309 Right Park Lamp Supply Voltage 2 L-GN/RD 230 Instrument Panel Lamps Dimming Control w/Dimming BK 450 Ground w/o Dimming
Side Marker Lamp - Left Front Connector Part Information 12110053 2-Way Pin Wire Color Circuit No. Function A BN 709 Left Park Lamp Supply Voltage B YE 14 Left Turn Signal Lamps Supply Voltage BK
Side Marker Lamp - Left Rear Connector Part Information MG 610320 2-Way Pin Wire Color Circuit No. Function A BN 709 Left Park Lamp Supply Voltage PU B BK 250 Ground
Side Marker Lamp - Right Front Connector Part Information 12110053 2-Way Pin Wire Color Circuit No. Function A BN 309 Right Park Lamp Supply Voltage B YE 15 Right Turn Signal Supply Voltage BK
Side Marker Lamp - Right Rear Connector Part Information 12110053 2-Way Pin Wire Color Circuit No. Function A BN 309 Right Park Lamp Supply Voltage B BK 250 Ground
Stop Lamp Switch Connector Part Information KET MG 610267 4-Way F 250 D/L Series (WH) Pin Wire Color Circuit No. Function 1 L-BU 20 Stop Lamp Supply Voltage/Stop Lamp Switch Signal BN 20 Stop Lamp Supply Voltage/Stop Lamp Switch Signal 2 OG 540 Battery Positive Voltage 3-4 - - Not Used
Tail/Stop Lamp - Left Rear Lower Connector Part Information 12092379 3-Way F Lamp Socket Wedge Base W3 (BK) Pin Wire Color Circuit No. Function A RD 20 Stop Lamp Supply Voltage B D-BU 709 Left Park Lamp Supply Voltage G BK 250 Ground
Tail/Stop Lamp - Left Rear Upper Connector Part Information 12160394 3-Way Lamp Socket Wedge Base W3 Right Angle (WH) Pin Wire Color Circuit No. Function A RD 20 Stop Lamp Supply Voltage B D-BU 709 Left Park Lamp Supply Voltage G BK 450 Ground
Tail/Stop Lamp - Right Rear Lower Connector Part Information 12092379 3-Way F Lamp Socket Wedge Base W3 (BK) Pin Wire Color Circuit No. Function A RD 20 Stop Lamp Supply Voltage B D-BU 309 Right Park Lamp Supply Voltage G BK 450 Ground
Tail/Stop Lamp - Right Rear Upper Connector Part Information 12160394 3-Way Lamp Socket Wedge Base W3 Right Angle (WH) Pin Wire Color Circuit No. Function A RD 20 Stop Lamp Supply Voltage B D-BU 309 Right Park Lamp Supply Voltage G BK 450 Ground
Turn Signal Lamp - Left Front (Except North America) Connector Part Information AMP 936184-3 2-Way F Pin Wire Color Circuit No. Function 1 BK 50 Ground 2 L-BU 14 Left Turn Signal Lamps Supply Voltage
Turn Signal Lamp - Left Rear Connector Part Information 12092379 3-Way F Lamp Socket Wedge Base W3 (WH) Pin Wire Color Circuit No. Function A YE 14 Left Turn Signal Lamps Supply Voltage B - - Not Used G BK/YE 450 Ground
Turn Signal Lamp - Right Front (Except North America) Connector Part Information AMP 936184-3 3-Way Pin Wire Color Circuit No. Function 1 BK 250 Ground 2 D-BU 15 Right Turn Signal Lamps Supply Voltage
Turn Signal Lamp - Right Rear Connector Part Information 12092379 3-Way F Lamp Socket Wedge Base W3 (WH) Pin Wire Color Circuit No. Function A YE 15 Right Turn Signal Lamps Supply Voltage B - - Not Used G BK/YE 450 Ground
Turn Signal Repeater Lamp - Left Connector Part Information KET MG 610320 2-Way F SWP Series Pin Wire Color Circuit No. Function 1 D-BU 14 Left Turn Signal Lamps Supply Voltage 2 BK 250 Ground
Turn Signal Repeater Lamp - Right Connector Part Information KET MG 610320 2-Way F SWP Series (BK) Pin Wire Color Circuit No. Function 1 D-BU 15 Right Turn Signal Lamps Supply Voltage 2 BK 250 Ground
Turn Signal/Multifunction Switch Connector Part Information KET MG 610203 7-Way F 118 (PA) Series (BK) Pin Wire Color Circuit No. Function 1 L-BU 14 Left Turn Signal Lamps Supply Voltage 2 D-GN 16 Turn Signal Flasher Signal 3 D-BU 15 Right Turn Signal Lamps Supply Voltage 4 WH/BK 1346 Headlamp Supply Voltage/Headlamp Control 5 WH 352 Headlamp Relay Coil Supply Voltage 6 BK/WH 1352 Headlamp Control 7 BK 450 Ground
Turn Signal/Hazard Flasher Connector Part Information AK 36906 9-Way (GN) Pin Wire Color Circuit No. Function 1 - - Not Used 2 GY 1524 Turn Signal 3-5 - - Not Used 6 D-GN 16 Turn Signal Flasher Signal 7 - - Not Used 8 BK 450 Ground 9 - - Not Used
Begin the system diagnosis by reviewing the Symptoms - Lighting Systems . Reviewing the symptom information will help you determine the correct symptom diagnostic procedure when a malfunction exists.
| IMPORTANT | The following steps must be completed before using the symptoms tables. |
Review the system operation in order to familiarize yourself with the system functions. Refer to the following procedures
- «Exterior Lighting Systems Description and Operation»(ref-300825-S42714810622008101600000)
- «Interior Lighting Systems Description and Operation»(ref-300825-S17459857772008101600000)
