Engine Cooling System: Specifications Chevrolet Aveo I facelift

Cooling System (Mechanical) 6 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Coolant Pump Mounting Bolts10 N.m89 lb in
Electric Cooling Fan Assembly Mounting Bolts4 N.m35 lb in
Electric Cooling Fan Motor Nut3.2 N.m28 lb in
Electric Cooling Fan Motor Retaining Screws4 N.m35 lb in
Negative Battery Terminal Retainer Bolt15 N.m11 lb ft
Surge Tank Attaching Bolt10 N.m89 lb in
Thermostat Housing Mounting Bolts20 N.m15 lb ft
Upper Left Radiator Retaining Bolt7 N.m62 lb in
Upper Right Radiator Retaining Bolt7 N.m62 lb in

Scheme 1

Scheme 1: Engine Cooling Schematics (Notchback)
Scheme 1: Engine Cooling Schematics (Notchback)

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Engine Cooling Schematics (Hatchback)
Scheme 3: Engine Cooling Schematics (Hatchback)

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: Cooling System Component Views (Notchback)
Scheme 6: Cooling System Component Views (Notchback)
CalloutComponent Name
1Bolt
2Radiator Bracket
3Radiator Bumper
4Radiator
5Drain Cock
6Spring Clamp
7Upper Radiator Hose
8Cooling Fan
9Bolt
