Scheme 67
Important Preliminary Checks Before Starting
Perform the Diagnostic System Check - Vehicle before using the Symptom Tables in order to verify that all of the following are true
Visual/Physical Inspection
- Inspect for aftermarket devices which could affect the operation of the system. Refer to «Checking Aftermarket Accessories»(/chevrolet/aveo/i-2006-2012/remont/body-electrical/#wiring-systems-and-power-management-inline-harness-connector-end-views-diagnosis__checking-aftermarket-accessories) .
- Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Symptom List
Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom
- «Shift Lever Does Not Move with Brake Pedal Depressed»(/chevrolet/aveo/i-2006-2012/remont/automatic-trans/#shift-interlock-system__shift-lever-does-not-move-with)
- «Shift Lever Can Be Moved without Brake Pedal Depressed»(/chevrolet/aveo/i-2006-2012/remont/automatic-trans/#shift-interlock-system__shift-lever-can-be-moved-without)
Shift Lever Does Not Move with Brake Pedal Depressed
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics | |||
| 1 | Turn the ignition ON, with the engine OFF. Apply the parking brake and block the wheels. Press and hold the brake pedal. Attempt to move the shift lever out of the PARK position. Does the shift lever move out of the PARK position? | System OK | Go to Step 2 |
| 2 | Turn the ignition OFF. Connect a test lamp between the battery positive voltage supply circuit at the brake switch and a good ground. Turn the ignition ON, with the engine OFF. Does the test lamp illuminate? | Go to Step 3 | Go to Step 7 |
| 3 | Check for the wiring harness circuit between the brake switch terminal 2 and a good ground with a test lamp. Does the test lamp illuminate? | Go to Step 8 | Go to Step 4 |
| 4 | Connect a test lamp between the ignition 1 voltage supply circuit at the shift lock solenoid and a good ground. Does the test lamp illuminate? | Go to Step 5 | Go to Step 9 |
| 5 | Check for the wiring harness circuit between the shift lock solenoid terminal 3 and a good ground with a test lamp. Does the test lamp illuminate? | Go to Step 6 | Go to Step 10 |
| 6 | Check for the wiring harness circuit between the P position switch terminal 2 and a good ground with a test lamp. Does the test lamp illuminate? | Go to Step 15 | Go to Step 11 |
| 7 | Repair the open in the battery positive voltage supply circuit of the brake switch. Is the repair complete? | Go to Step 17 | |
| 8 | Check for poor connections at the brake switch. Do you find and correct the condition? | Go to Step 17 | Go to Step 12 |
| 9 | Repair the open in the ignition 1 voltage supply circuit of the shift lock solenoid. Is the repair complete? | Go to Step 17 | |
| 10 | Check for poor connections at the shift lock solenoid. Do you find and correct the condition? | Go to Step 17 | Go to Step 13 |
| 11 | Check for poor connections at the P position switch. Do you find and correct the condition? | Go to Step 17 | Go to Step 14 |
| 12 | Replace the brake switch. Is the repair complete? | Go to Step 17 | |
| 13 | Replace the shift lock solenoid. Is the repair complete? | Go to Step 17 | |
| 14 | Replace the P position switch. Is the repair complete? | Go to Step 17 | |
| 15 | Inspect the key interlock system. If needed, repair the key interlock system circuit. Is the problem found? | Go to Step 16 | Go to Step 17 |
| 16 | Replace the instrument panel fuse box which contains the multifunction module. Is the repair complete? | Go to Step 17 | |
| 17 | Operate the system in order to verify the repair. Did you find and correct the condition? | System OK | Go to Step 1 |
Shift Lever Can Be Moved without Brake Pedal Depressed
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics | |||
| 1 | Turn the ignition ON, with the engine OFF. Apply the parking brake and block the wheels. Attempt to move the shift lever out of the PARK position without pressing the brake pedal. Does the shift lever move out of the PARK position without pressing the brake? | Go to Step 2 | System OK |
| 2 | Turn the ignition OFF. Connect a test lamp between the battery positive voltage supply circuit at the brake switch and a good ground. Turn the ignition ON, with the engine OFF. Does the test lamp illuminate? | Go to Step 3 | Go to Step 7 |
| 3 | Check for the wiring harness circuit between the brake switch terminal 2 and a good ground with a test lamp. Does the test lamp illuminate? | Go to Step 8 | Go to Step 4 |
| 4 | Connect a test lamp between the ignition 1 voltage supply circuit at the shift lock solenoid and a good ground. Does the test lamp illuminate? | Go to Step 5 | Go to Step 9 |
| 5 | Check for the wiring harness circuit between the shift lock solenoid terminal 3 and a good ground with a test lamp. Does the test lamp illuminate? | Go to Step 6 | Go to Step 10 |
| 6 | Check for the wiring harness circuit between the P position switch terminal 2 and a good ground with a test lamp. Does the test lamp illuminate? | Go to Step 15 | Go to Step 11 |
| 7 | Repair the open in the battery positive voltage supply circuit of the brake switch. Is the repair complete? | Go to Step 17 | |
| 8 | Check for poor connections at the brake switch. Do you find and correct the condition? | Go to Step 17 | Go to Step 12 |
| 9 | Repair the open in the ignition 1 voltage supply circuit of the shift lock solenoid. Is the repair complete? | Go to Step 17 | |
| 10 | Check for poor connections at the shift lock solenoid. Do you find and correct the condition? | Go to Step 17 | Go to Step 13 |
| 11 | Check for poor connections at the P position switch. Do you find and correct the condition? | Go to Step 17 | Go to Step 14 |
| 12 | Replace the brake switch. Is the repair complete? | Go to Step 17 | |
| 13 | Replace the shift lock solenoid. Is the repair complete? | Go to Step 17 | |
| 14 | Replace the P position switch. Is the repair complete? | Go to Step 17 | |
| 15 | Inspect the key interlock system. If needed, repair the key interlock system circuit. Is the problem found? | Go to Step 16 | Go to Step 17 |
| 16 | Replace the instrument panel fuse box which contains the multifunction module. Is the repair complete? | Go to Step 17 | |
| 17 | Operate the system in order to verify the repair. Did you find and correct the condition? | System OK | Go to Step 1 |
Removal Procedure
- Disconnect the negative battery cable.
- Remove the floor console. Refer to «Front Floor Console Replacement (Notchback)»(/chevrolet/aveo/i-2006-2012/remont/gauges-instrument-panels/#instrument-panel-trim-and-console-trim) or «Front Floor Console Replacement (Hatchback)»(/chevrolet/aveo/i-2006-2012/remont/gauges-instrument-panels/#instrument-panel-trim-and-console-trim) .
- Disconnect the wiring harness connectors from the shift control lever.
- Loosen the control cable adjusting nut.
- Disconnect the control cable from the shift control lever assembly.
- Remove the shift control lever assembly mounting bolts.
- Remove the shift control lever assembly.
- Remove the two shift lever control knob retaining screws, the then knob from the assembly.
- Carefully remove the shift select cover from the lever assembly.
- Remove the shift lock solenoid retaining screws.
- Remove the solenoid from the assembly.
Installation Procedure
- Install the shift lock solenoid on the assembly.
- Install the shift lock solenoid retaining screws.
- Carefully install the shift select cover to the lever assembly.
- Install the shift lever control knob, then the retaining screws.
- Install the shift control lever assembly and mounting bolts. Tighten: Tighten the shift control lever assembly mounting bolts to 8 N.m (71 lb in).
- Connect the control cable to the shift control lever assembly.
- Tighten the control cable adjusting nut. Tighten: Tighten the control cable adjusting nut to 8 N.m (71 lb in).
- Connect the harness connector.
- Adjust the control cable. Refer to «Range Selector Lever Cable Adjustment»(/chevrolet/aveo/i-2006-2012/remont/automatic-trans/#how-to-overhaul-the-automatic-transmission-aisin-81-40le-removal-installation-service-troubleshooting-diagnosis__range-selector-lever-cable-adjustment) .
- Install the floor console. Refer to «Front Floor Console Replacement (Notchback)»(/chevrolet/aveo/i-2006-2012/remont/gauges-instrument-panels/#instrument-panel-trim-and-console-trim) or «Front Floor Console Replacement (Hatchback)»(/chevrolet/aveo/i-2006-2012/remont/gauges-instrument-panels/#instrument-panel-trim-and-console-trim) .
- Connect the negative battery cable.
