Instrument cluster — Instrument cluster circuit, without tachometer Chevrolet Aveo I
All systems — 26 systems
- Air conditioning 3
- Anti-lock brakes
- Anti-theft
- Computer data lines
- Cooling fan
- Cruise control 2
- Defoggers
- Engine performance 1.6l vin 6
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster 4
- Interior lights 3
- Power distribution
- Power door locks
- Power mirrors 2
- Power top/sunroof
- Power windows 2
- Radio
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission
- Warning systems
- Wiper/washer
Components on these wiring diagrams 18
Click a component to highlight it on every diagram it appears on.
