Exterior lamps circuit for Chevrolet Aveo I (2003-2008)

Exterior lamps circuit (1 of 3)

Aveo Chevrolet I (2003-2008): Exterior lamps circuit (1 of 3)

Get access

BLK WIRE BRN WIRE BRN/DK BLU WIRE HATCHBACK HEAD HEADLAMP SWITCH HOT AT ALL TIMES ILLUM LAMP ILLUM LH ILLUM RELAY ILLUM RH LAMP CONTROL MODULE (BEHIND DRIVER SIDE KNEE BOLSTER) LEFT FRONT DOOR JAM SWITCH LEFT FRONT PARK POSITION LAMP LEFT FRONT TURN SIGNAL LAMP LEFT SIDE MARKER LAMP LICENSE LAMP LEFT TAIL LAMP LIGHTS ON SIG BATT SAVR SIG BATT VOLT GROUND LT DR AJAR SIG KEY IN IGN SIG LT BLU WIRE LT GRN WIRE NOTCHBACK OFF PARK ORG/ WIRE PPL PPL PPL RIGHT FRONT PARK POSITION LAMP RIGHT FRONT TURN SIGNAL LAMP RIGHT REAR TAIL LAMP RIGHT SIDE MARKER LAMP TURN SIGNAL SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE

Exterior lamps circuit (2 of 3)

Aveo Chevrolet I (2003-2008): Exterior lamps circuit (2 of 3)

Get access

ANTI-THEFT SYSTEM BLK WIRE BRN WIRE CHMSL CHMSL LEFT TAIL LAMP ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY) GRN WIRE HATCHBACK HORN FUSE 12 HOT AT ALL TIMES I/P FUSE BLOCK IGNITION KEY ALARM SWITCH LEFT TAIL LAMP LT GRN WIRE METER, HAZARD FUSE 14 NOTCHBACK ORG/ WIRE RIGHT TAIL LAMP STOP LAMP FUSE 13 STOPLAMP SWITCH (ON BRAKE PEDAL ASSEMBLY) SW OUT WARNING SYSTEM

Exterior lamps circuit (3 of 3)

Aveo Chevrolet I (2003-2008): Exterior lamps circuit (3 of 3)

Get access

7 9 RIGHT IND LEFT IND BLINK RELAY (IN PASSENGER COMPT FUSE BLOCK) BLK WIRE BRN WIRE DK BLU WIRE DK GRN WIRE DOOR LOCKS SYSTEM GRY WIRE HAZARD SWITCH HOT IN RUN OR START I/P CLUSTER I/P FUSE BLOCK LEFT FRONT TURN SIGNAL LAMP LEFT FRONT TURN SIGNAL REPEATER LAMP LEFT TAIL LAMP LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RIGHT FRONT TURN SIGNAL LAMP RIGHT FRONT TURN SIGNAL REPEATER LAMP RIGHT TAIL LAMP TIE BAR) TSIG FUSE 3 TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD FLASHER (IN PASSENGER COMPARTMENT FUSE BLOCK) WHT WIRE
