Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Front Wheel Well Splash Shield Screws | 1.5 N.m | 13 lb in |
| Washer Fluid Reservoir Bolts and Nuts | 9 N.m | 80 lb in |
| Wiper Arm Linkage Nut | 8.5 N.m | 75 lb in |
| Wiper Arm Nut Front | 15 N.m | 133 lb in |
| Wiper Motor Bolts | 9 N.m | 80 lb in |
| Wiper Arm Nut Rear | 11 N.m | 97 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Ignition Lock Module (North America) |
| 1 | Rear Fog Relay (LHD - w/Rear Fog) |
| 2 | Defog Relay (RHD) |
| 2 | Turn Signal/Hazard Flasher (LHD) |
| 3 | Wiper Relay |
| 4 | Park/Neutral Position (PNP) Relay (RHD) |
| 4 | Daytime Relay Lamp (DRL) Relay (Scandinavian) |
| 5 | Blink Relay |
| 6 | Blower Relay |
| 7 | Turn Signal/Hazard Flasher (RHD) |
| 7 | Park/Neutral Position (PNP) Relay (LHD) |
| 8 | Defog Relay (LHD) |
| 8 | Rear Fog Relay (RHD) |
| 9 | Fuse Block - I/P |
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Multifunction Alarm Module |
| 2 | Ignition Key Alarm Switch |
| 3 | Defogger Switch |
| 4 | Clock/Tele Tail |
| 5 | Cluster |
| 6 | Radio |
| 7 | Tweeter Right/Left Similar |
| 8 | Cigar Lighter |
| 9 | Wiper Switch |
| 10 | Blower Switch |
| 11 | Horn Switch |
| 12 | Headlamp Switch |
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | Wiper Motor - Rear |
| 2 | Windshield Wiper Motor |
| 3 | Windshield/Washer Fluid Pump - Front |
| 4 | Windshield/Washer Fluid Pump - Rear |
Wiper/Washer System Connector End Views
Motor Wiper - Rear Connector Part Information KET MG 610394 3-Way F Sealed Series Pin Wire Color Circuit No. Function 1 RD/D-BU 441 Ignition 3 Voltage 2 BK 850 Ground 3 GY/RD 393 Rear Window Wiper Motor Control
Windshield Washer Fluid Pump - Front Connector Part Information KET MG 640605 2-Way F 090 WP Series (WH) Pin Wire Color Circuit No. Function 1 BK 250 Ground 2 D-GN/WH 94 Windshield Washer Switch Signal
Windshield Washer Fluid Pump - Rear Connector Part Information KET MG 640605 2-Way F 090 WP Series (WH) Pin Wire Color Circuit No. Function 1 BK 250 Ground 2 BK 392 Rear Window Washer Pump Control
Windshield Wiper Motor Connector Part Information KET MG 641107-5 6-Way F (BK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 D-GN 96 Windshield Wiper Switch Pulse Delay Signal 3 RD 441 Ignition 3 Voltage 4 BK 250 Ground 5 D-BU 92 Windshield Wiper Motor Low Speed 6 WH 95 Windshield Wiper Motor High Speed
Windshield Wiper Switch Connector Part Information KET MG 610154 9-Way F 118 (PA) Series (WH) Pin Wire Color Circuit No. Function 1 GY 393 Rear Window Wiper Motor Control 2 L-GN/BK 392 Rear Window Washer Pump Control 3 RD 441 Ignition 3 Voltage 4 D-GN/WH 94 Windshield Washer Switch Signal D-GN/WH 94 Windshield Washer Switch Signal 5 D-BU 92 Windshield Wiper Motor Low Speed 6 BN 97 Windshield Wiper Switch Mist/Off/Low Signal 7 PU 91 Windshield Wiper Switch Signal 2 8 RD 441 Ignition 3 Voltage 9 WH 95 Windshield Wiper Motor High Speed
Diagnostic Starting Point - Wiper/Washer Systems
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Wiper/Washer Systems in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Symptoms - Wiper/Washer Systems
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Wiper/Washer System Description and Operation or to Rear Wiper/Washer System Description and Operation . |
Visual/Physical Inspection
- Inspect for aftermarket devices which could affect the operation of the Windshield Wiper/Washer System.
- Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
- Inspect the washer fluid reservoir for the proper fluid level.
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.
Wipers Do Not Work at Any Speed
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| 1 | Inspect fuse F17. Is fuse F17 open? | Go to Step 2 | Go to Step 3 | |
| 2 | Inspect for a short circuit and repair it, if necessary. Replace the fuse. Is the repair complete? | System OK | ||
| 3 | Inspect the battery voltage at fuse F17. Is battery voltage available at fuse F17? | 11-14 V | Go to Step 5 | Go to Step 4 |
| 4 | Repair the open in the power supply circuit to fuse F17. Is the repair complete? | System OK | ||
| 5 | Turn the ignition ON. Turn the wiper switch to HI. Is battery voltage available at wiper motor connector terminal 6? | 11-14 V | Go to Step 6 | Go to Step 7 |
| 6 | Replace the wiper motor. Refer to Wiper Motor Replacement . Is the repair complete? | System OK | ||
| 7 | Disconnect the wiper switch connector. Turn the ignition ON. With a voltmeter, measure voltage at connector terminal 8. Is battery voltage available at the wiper switch connector terminal 8? | 11-14 V | Go to Step 9 | Go to Step 8 |
| 8 | Repair the open circuit between wiper switch connector terminal 8 and fuse F17. Is the repair complete? | System OK | ||
| 9 | Use an ohmmeter to test the continuity of the wiper switch. Turn the wiper switch to HI. Check for continuity between wiper switch terminal 8 and 9. Is there continuity between terminals 8 and 9? | 0 ohms | Go to Step 11 | Go to Step 10 |
| 10 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| 11 | Repair the open circuit between the wiper switch and the wiper motor. Is the repair complete? | System OK |
Wipers Do Not Work at Any Speed
Wipers Do Not Work on HI Speed
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| 1 | Turn the ignition ON. Turn the wiper switch to HI. Is battery voltage available at wiper motor connector terminal 6? | 11-14 V | Go to Step 2 | Go to Step 3 |
| 2 | Replace the wiper motor. Refer to Wiper Motor Replacement . Is the repair complete? | System OK | ||
| 3 | Use an ohmmeter to test the continuity of the wiper switch. Turn the wiper switch to HI. Check for continuity between the wiper switch terminal 8 and 9. Is there continuity between terminals 8 and 9? | 0 ohms | Go to Step 5 | Go to Step 4 |
| 4 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| 5 | Repair the open circuit between wiper switch connector terminal 9 and wiper motor connector terminal 6. Is the repair complete? | System OK |
Wipers Do Not Work on HI Speed
Wipers Do Not Work on LO Speed
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| 1 | Turn the ignition ON. Turn the wiper switch to LO. Is battery voltage available at wiper motor connector terminal 5? | 11-14 V | Go to Step 2 | Go to Step 3 |
| 2 | Replace the wiper motor. Refer to Wiper Motor Replacement . Is the repair complete? | System OK | ||
| 3 | Use an ohmmeter to test the continuity of the wiper switch. Turn the wiper switch to LO. Check for continuity between the wiper switch terminal 8 and 5. Is there continuity between terminals 8 and 5? | 0 ohms | Go to Step 5 | Go to Step 4 |
| 4 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| 5 | Repair the open circuit between the wiper switch connector terminal 5 and the wiper motor connector terminal 5. Is the repair complete? | System OK |
Wipers Do Not Work on LO Speed
Wipers Do Not Work on Intermittent
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| IMPORTANT: The wiper relay is located behind the instrument panel, below the cluster dimmer switch. Remove the cluster dimmer switch and the instrument panel side cover to access the wiper relay. | ||||
| 1 | Turn the ignition ON. Use a voltmeter to test for battery voltage at the wiper relay connector terminal 15. Is battery voltage available at connector terminal 15? | 11-14 V | Go to Step 3 | Go to Step 2 |
| 2 | Repair the open circuit between the wiper relay connector terminal 15 and fuse F17. Is the repair complete? | System OK | ||
| 3 | Turn the ignition ON. Turn the wiper switch to INT. Using a voltmeter, is battery voltage available at the wiper relay connector terminal I? | 11-14 V | Go to Step 7 | Go to Step 4 |
| 4 | Turn the ignition ON. Turn the wiper switch to INT. Using a voltmeter, is battery voltage available at wiper switch connector terminal 7? | 11-14 V | Go to Step 6 | Go to Step 5 |
| 5 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| 6 | Repair the open circuit between the wiper switch connector terminal 7 and the wiper relay connector terminal I. Is the repair complete? | System OK | ||
| 7 | Turn the ignition ON. Turn the wiper switch to INT. Using a voltmeter, is battery voltage pulsing at wiper relay connector terminal 53e? | 11-14 V | Go to Step 11 | Go to Step 8 |
| 8 | Using an ohmmeter, check the wiper relay ground circuit, connector terminal 31. Is the ground circuit OK? | 0 ohms | Go to Step 10 | Go to Step 9 |
| 9 | Repair the open ground circuit. Is the repair complete? | System OK | ||
| 10 | Replace the wiper relay. Is the repair complete? | System OK | ||
| 11 | Disconnect the wiper switch connector. Turn the wiper switch to INT. Using an ohmmeter, check the wiper switch. Is there continuity between terminals 5 and 6? | 0 ohms | Go to Step 13 | Go to Step 12 |
| 12 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| 13 | Repair the open circuit between the wiper switch and the wiper relay. Is the repair complete? | System OK | ||
| IMPORTANT |
|---|
| The wiper relay is located behind the instrument panel, below the cluster dimmer switch. Remove the cluster dimmer switch and the instrument panel side cover to access the wiper relay. |
Wipers Do Not Work on Intermittent
Washers Inoperative
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| 1 | Do the windshield wipers operate when the washer switch is activated? | Go to Step 4 | Go to Step 2 | |
| 2 | Turn the ignition ON. While activating the washer switch, use a voltmeter to test for battery voltage at the windshield wiper switch. Is battery voltage available at the windshield wiper switch connector terminal 4? | 11-14 V | Go to Step 8 | Go to Step 3 |
| 3 | Replace the windshield wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| 4 | Is there washer fluid in the windshield washer fluid reservoir? | Go to Step 6 | Go to Step 5 | |
| 5 | Fill the windshield washer fluid reservoir. Is the repair complete? | System OK | ||
| 6 | Are the windshield washer hoses or the nozzles clogged or damaged? | Go to Step 7 | Go to Step 8 | |
| 7 | Repair the washer hoses and the nozzles. Is the repair complete? | System OK | ||
| 8 | Turn the ignition ON. With the windshield washer activated, use a voltmeter to test for battery voltage at the windshield washer pump. Is battery voltage available at the windshield washer pump? | 11-14 V | Go to Step 10 | Go to Step 9 |
| 9 | Repair the open circuit between the windshield washer pump and the windshield wiper switch. Is the repair complete? | System OK | ||
| 10 | Use an ohmmeter to check the ground circuit at the windshield washer pump. Is the ground circuit OK? | 0 ohms | Go to Step 12 | Go to Step 11 |
| 11 | Repair the windshield washer pump ground circuit. Is the repair complete? | System OK | ||
| 12 | Replace the windshield washer pump. Refer to Washer Pump Replacement (Typical) . Is the repair complete? | System OK |
Washers Inoperative
Wipers Inoperative - All Modes
| Checks | Actions |
|---|---|
| Inspect the wiper switch for damage. | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . |
| Inspect the wiper switch for improper installation. | Remove and inspect the wiper switch. Refer to Wipers/Washer Switch Replacement . Reinstall the wiper switch. |
Wipers Inoperative - All Modes
Wipers Blades Do Not Park
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| 1 | Turn the ignition ON. Use a voltmeter to test the battery voltage at the wiper motor. Is battery voltage available at wiper motor connector terminal 3? | 11-14 V | Go to Step 3 | Go to Step 2 |
| 2 | Repair the open circuit between the wiper motor and fuse F17. Is the repair complete? | System OK | ||
| 3 | Turn the ignition ON. Turn the wiper switch to HI. Use a voltmeter to test for a pulse of battery power at the wiper motor when turning the wiper switch OFF. Is a pulse of battery voltage available at the wiper motor connector terminal 2 when the wiper switch is turned OFF? | 11-14 V | Go to Step 5 | Go to Step 4 |
| 4 | Replace the wiper motor. Refer to Wiper Motor Replacement . Is the repair complete? | System OK | ||
| 5 | Turn the ignition ON. Turn the wiper switch to HI. Use a voltmeter to test for a pulse of battery power at the wiper relay when turning the wiper switch OFF. Is a pulse of battery voltage available at the wiper relay connector terminal 31b when the wiper switch is turned OFF? | 11-14 V | Go to Step 7 | Go to Step 6 |
| 6 | Repair the open circuit between the wiper motor and the wiper relay. Is the repair complete? | System OK | ||
| 7 | Disconnect the wiper relay from the connector. Use an ohmmeter to test the continuity of the relay. Is there continuity between wiper relay connector terminals 31b and 53e? | 0 ohms | Go to Step 9 | Go to Step 8 |
| 8 | Replace the wiper relay. Is the repair complete? | System OK | ||
| 9 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK |
Wipers Blades Do Not Park
Washer Inoperative - Rear
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| 1 | Inspect the washer fluid level. Is there fluid in the washer reservoir? | Go to Step 3 | Go to Step 2 | |
| 2 | Fill the washer reservoir. Is the repair complete? | System OK | ||
| 3 | Verify that the hoses are not obstructed or leaking by disconnecting the washer hose and blowing through it toward the reservoir and also toward the nozzle. Are the hoses obstructed or leaking? | Go to Step 4 | Go to Step 5 | |
| 4 | Repair or replace the hoses. Is the repair complete? | System OK | ||
| 5 | Inspect the function of the rear wiper. Does the rear wiper function correctly? | Go to Step 7 | Go to Step 6 | |
| 6 | Repair the rear wiper. Is the rear wiper repair complete? | Go to Step 7 | ||
| 7 | Disconnect the electrical connector at the rear washer pump. Use an ohmmeter to check continuity between the BK wire of the rear washer pump connector and ground. Does the ohmmeter indicate the specified value? | 0 ohms | Go to Step 9 | Go to Step 8 |
| 8 | Repair the open or the high-resistance ground connection. Is the repair complete? | System OK | ||
| 9 | Inspect the voltage at the rear washer pump connector, L-GN/BK wire, when the rear washer is turned ON. Is the voltage equal to the specified value? | 11-14 V | Go to Step 10 | Go to Step 11 |
| 10 | Replace the rear washer pump. Refer to Washer Pump Replacement (Typical) . Is the repair complete? | System OK | ||
| 11 | Disconnect the wiper switch. Connect an ohmmeter between terminal 2 and terminal 3 of the wiper switch. Observe the ohmmeter when the switch is moved to the rear WASH position. Does the ohmmeter indicate the specified value? | 0 ohms | Go to Step 12 | Go to Step 13 |
| 12 | Repair the open circuit between terminal 2 of the wiper switch connector and the rear washer pump. Is the repair complete? | System OK | ||
| 13 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK |
Washer Inoperative - Rear
Wiper Inoperative - Rear (Hatchback)
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| IMPORTANT: If the front wiper is operating correctly, begin the diagnostic table at Step 5. It would not be necessary to check the fuse or power supply circuit. | ||||
| 1 | Inspect fuse F17. Is fuse F17 open? | Go to Step 2 | Go to Step 3 | |
| 2 | Inspect for a short circuit and repair, if necessary. Replace fuse F17. Is the repair complete? | System OK | ||
| 3 | Turn the ignition ON. Inspect the voltage at fuse F17. Does the voltage equal the specified value? | 11-14 V | Go to Step 5 | Go to Step 4 |
| 4 | Repair the open power supply circuit for fuse F17. Is the repair complete? | System OK | ||
| 5 | Disconnect the rear wiper motor electrical connector. Turn the ignition ON. Inspect the voltage at the RD/D-BU wire of the rear wiper motor electrical connector. Does the voltage equal the specified value? | 11-14 V | Go to Step 7 | Go to Step 6 |
| 6 | Repair the open circuit for the RD wire between fuse F17 and connector at the rear wiper motor. Is the repair complete? | System OK | ||
| 7 | With the rear wiper motor still disconnected, use an ohmmeter to check continuity between ground and the BK wire of the rear wiper motor connector. Does the ohmmeter indicate the specified value? | 0 ohms | Go to Step 9 | Go to Step 8 |
| 8 | Repair the open ground circuit for the rear wiper motor. Is the repair complete? | System OK | ||
| 9 | Turn the ignition ON. Turn the rear wiper ON. Inspect the voltage at the GY/RD wire at the rear wiper motor connector. Does the voltmeter indicate the specified value? | 11-14 V | Go to Step 10 | Go to Step 11 |
| 10 | Replace the rear wiper motor. Refer to Wiper Motor Replacement - Rear . Is the repair complete? | System OK | ||
| 11 | Disconnect the wiper switch electrical connector. Turn the ignition ON. Check the voltage at terminal 3 - RD. Is the voltage equal to the specified value? | 11-14 V | Go to Step 13 | Go to Step 12 |
| 12 | Repair the open circuit between fuse F17 and the wiper switch connector terminal 3. Is the repair complete? | System OK | ||
| 13 | Connect an ohmmeter between terminals 1 and 3 of the wiper switch. Observe the ohmmeter when the rear wiper switch is moved to the WIPE position. Does the ohmmeter indicate the specified value? | 0 ohms | Go to Step 14 | Go to Step 15 |
| 14 | Repair the open circuit between terminal 1 of the wiper connector, GY wire, and the rear wiper motor. Is the repair complete? | System OK | ||
| 15 | Replace the wiper switch. Refer to Wipers/Washer Switch Replacement . Is the repair complete? | System OK | ||
| IMPORTANT |
|---|
| If the front wiper is operating correctly, begin the diagnostic table at Step 5. It would not be necessary to check the fuse or power supply circuit. |
Wiper Inoperative - Rear (Hatchback)
Removal Procedure
- Disconnect the negative battery cable.
- Remove the front left wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/aveo/i-2003-2008/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
- Remove the screws and the front wheel well splash shield.
- Disconnect the washer hoses from the reservoir.
- Disconnect the reservoir pump electrical connectors.
- Remove the bolts, the nuts and the reservoir.
Installation Procedure
- Install the reservoir with the nuts and the bolts. Tighten: Tighten the washer fluid reservoir nuts and bolts to 9 N.m (80 lb in).
- Connect the reservoir pump electrical connectors.
- Connect the washer hoses to the reservoir.
- Install the front wheel well splash shield with the screws. Tighten: Tighten the front wheel well splash shield screws to 1.5 N.m (13 lb in).
- Install the front left wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/aveo/i-2003-2008/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
- Connect the negative battery cable.
- Disconnect the negative battery cable.
- Remove the left front left wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/aveo/i-2003-2008/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
- Remove the screws and the front wheel well splash shield.
- Disconnect the electrical connector.
- Disconnect the washer hose.
- Remove the washer pump.
- Install the washer pump.
- Connect the washer hose.
- Connect the electrical connector.
- Install the front wheel well splash shield with the screws. Tighten: Tighten the front wheel well splash shield screws to 1.5 N.m (13 lb in).
- Install the front left wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/aveo/i-2003-2008/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
- Connect the negative battery cable.
- Open the hood.
- Disconnect the washer hose from the nozzle.
- Remove the nozzle from the hood.
- Install the nozzle onto the hood.
- Connect the washer hose to the nozzle.
- Close the hood.
- Open the hood.
- Disconnect the windshield washer hose from the washer nozzles on the hood.
- Remove the front left wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/aveo/i-2003-2008/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
- Remove the screws and the front wheel well splash shield.
- Disconnect the washer hose from the washer reservoir.
- Connect the washer hose to the washer reservoir.
- Install the front wheel well splash shield with the screws. Tighten: Tighten the front wheel well splash shield screws to 1.5 N.m (13 lb in).
- Install the front left wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/aveo/i-2003-2008/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
- Connect the windshield washer hose to the washer nozzles on the hood.
- Close the hood.
- Open the hood.
- Remove the nut from the wiper arm.
- Pull the wiper arm off.
- Install the wiper arm.
- Secure the wiper arm with the nut. Tighten: Tighten the wiper arm nut to 15 N.m (133 lb ft).
- Close the hood.
- Rotate the wiper blade on the arm.
- Pull the wiper blade off the arm.
Scheme 6
Push the wiper blade onto the arm.
Scheme 7
Slide the insert out of the wiper blade.
Slide the insert into the wiper blade.
- Disconnect the negative battery cable.
- Put the wiper arms in the upright position.
- Remove the left side portion of the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/chevrolet/aveo/i-2003-2008/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Remove the nut securing the wiper arm linkage to the motor drive shaft.
- Pry the wiper arm linkage off the motor drive shaft.
- Disconnect the electrical connectors.
- Remove the bolts and the wiper motor.
- Install the wiper motor with the bolts. Tighten: Tighten the wiper motor bolts to 9 N.m (80 lb in).
- Connect the electrical connector.
- Press the wiper arm linkage onto the motor drive shaft.
- Install the wiper arm linkage to the motor drive shaft with the nut. Tighten: Tighten the wiper arm linkage nut to 8.5 N.m (75 lb in).
- Install the left side portion of the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/chevrolet/aveo/i-2003-2008/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Connect the negative battery cable.
- Remove the washer hose from the nozzle.
- Remove the washer nozzle.
- Install the washer nozzle.
- Install the washer hose to the nozzle.
- Open the wiper arm access cap.
- Remove the nut and the rear wiper arm.
- Install the rear wiper arm with the nut. Tighten: Tighten the wiper arm nut to 11 N.m (97 lb in).
- Close the wiper arm access cap.
- Disconnect the negative battery cable.
- Remove the rear window wiper arm. Refer to «Wiper Arm Replacement - Rear»(/chevrolet/aveo/i-2003-2008/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Remove the hatchback door lower garnish molding. Refer to «Hatchback Door Lower Garnish Molding Replacement»(/chevrolet/aveo/i-2003-2008/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
- Remove the bolts and the rear wiper motor.
- Disconnect the electrical connector.
- Connect the electrical connector.
- Install the rear wiper motor with the bolts. Tighten: Tighten the wiper motor bolts to 9 N.m (80 lb in).
- Install the hatchback door lower garnish molding. Refer to «Hatchback Door Lower Garnish Molding Replacement»(/chevrolet/aveo/i-2003-2008/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
- Install the rear window wiper arm. Refer to «Wiper Arm Replacement - Rear»(/chevrolet/aveo/i-2003-2008/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Connect the negative battery cable.
- Disconnect the negative battery cable.
- Remove the lower steering column cover panel screws and remove the lower steering column cover panel.
- Turn the steering wheel to expose the upper steering column cover panel connecting screws. Remove the upper steering column cover panel screws and remove the upper steering column cover panel.
- Remove the wiper switch by pushing in on the tabs on either side of the switch housing.
- Disconnect the electrical connections from the wiper switch.
- Connect the electrical connections to the wiper switch.
- Install the wiper switch by snapping it into the switch housing.
- Install the lower steering column cover panel. Install the lower steering column cover panel screws. Tighten: Tighten the lower steering column cover panel screws to 3 N.m (27 lb ft).
- Install the upper steering cover panel. Install the upper steering column cover panel screws. Tighten: Tighten the upper steering column cover panel screws to 3 N.m (27 lb ft).
- Connect the negative battery cable.
Wiper/Washer System Description and Operation
The windshield wiper system consists of a wiper motor, a linkage, a wiper arm and blade, and a wiper/washer switch. The windshield wiper circuit incorporates a self parking device which consists of a worm gear and a cam plate in order to keep the circuit complete temporarily when the switch is turned OFF. The wiper system is driven by a permanent magnet-type motor. The windshield wiper motor is mounted on the dash panel and is directly connected to the windshield wiper linkage.
The windshield wiper motor has two speeds, LO and HI, and intermittent wiper capability. The wiper switch is an integral part of the wiper/washer switch. Windshield wiper operation is actuated through the lever on the right side of the steering column.
Windshield Washer System
The windshield washer system is equipped with a washer fluid reservoir, a washer fluid pump, hoses, nozzles, and a wiper/washer switch. The windshield washer reservoir is mounted behind the front left wheel well splash shield. Attached to the reservoir is a washer pump, which pumps fluid through the hoses to the two nozzles mounted on the hood. The washer switch is an integral part of the wiper/washer switch. Windshield washer operation is actuated through the lever on the right side of the steering column.
Rear Wiper/Washer System Description and Operation
The hatchback rear window wiper system consists of a wiper motor, a wiper arm, and a blade. The rear window wiper motor is located inside the hatchback door and is directly connected to the rear window wiper. The hatchback rear window washer systems equipped with a separate washer fluid pump, hose, and nozzle. The rear window washer reservoir is mounted behind the front left wheel well splash shield. Attached to the reservoir is a washer pump, which pumps fluid through a hose to the nozzle mounted on the hatch.
See also:
• Testing for Intermittent Conditions and Poor Connections
• Battery Disconnect Caution
• Tire and Wheel Removal and Installation
• Fastener Notice
• Air Inlet Grille Panel Replacement
• Hatchback Door Lower Garnish Molding Replacement
• Symptoms - Wiper/Washer Systems
• Wiper/Washer System Description and Operation
• Rear Wiper/Washer System Description and Operation
• Wiper Motor Replacement
