Horn System Chevrolet Aveo I

Horns 4 illustrations ~241 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Horn Bolt21 N.m16 lb ft

Fastener Tightening Specifications

Horns Schematic Icons

Horns Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Horns Schematics

Scheme 2

Scheme 2: Horns Component Views
CalloutComponent Name
1Multifunction Alarm Module
2Ignition Key Alarm Switch
3Defogger Switch
4Clock/Tele Tail
5Cluster
6Radio
7Tweeter Right/Left Similar
8Cigar Lighter
9Wiper Switch
10Blower Switch
11Horn Switch
12Headlamp Switch

Scheme 3

Scheme 3
CalloutComponent Name
1Horn Relay

Scheme 4

Scheme 4
CalloutComponent Name
1Horn

Horns Connector End Views

Horn Connector Part Information KET MG 641156 2-Way 090 WP Series (GY) Pin Wire Color Circuit No. Function 1 BK/WH 28 Horn Relay Control 2 OG 1440 Battery Positive Voltage

Horn Relay Connector Part Information AK 36905 9-Way Relay F (GY) Pin Wire Color Circuit No. Function 85 OG 340 Battery Positive Voltage 86 BK/WH 29 Horn Control 87 BK 450 Ground 30 BK 28 Horn Relay Control

Removal Procedure

  1. Disconnect the negative battery cable.
  2. Remove the bolt from the horn.
  3. Disconnect the electrical connector.
  4. Remove the horn.

Installation Procedure

  1. Connect the electrical connector.
  2. Install the horn with the bolt. Tighten: Tighten the horn bolt to 21 N.m (16 lb ft).
  3. Connect the negative battery cable.

Horns System Description and Operation

The horn is located under the hood. It is attached near the radiator at the front of the vehicle. The horn is activated by pressing the steering wheel pad, which grounds the horn's electrical circuit.
