Scheme 1
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Cigar Lighter |
| 2 | Auxiliary Power Outlet |
Power Outlet Connector End Views
Auxiliary Power Outlet Connector Part Information KET MG 630685-5 2-Way F 250 Series (BK) Pin Wire Color Circuit No. Function 1 OG 40 Battery Positive Voltage 2 BK 450 Ground
Cigar Lighter Connector Part Information KET MG 630685-5 2-Way F 250 Series (BK) Pin Wire Color Circuit No. Function 1 OG 40 Battery Positive Voltage 2 BK 450 Ground
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Power Outlets in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Visual/Physical Inspection
Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.
Symptom List
Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom
- «Cigar Lighter Inoperative»(/chevrolet/aveo/i-2003-2008/remont/body-electrical/#power-outlets__cigar-lighter-inoperative)
- «Auxiliary Outlets Inoperative»(/chevrolet/aveo/i-2003-2008/remont/body-electrical/#power-outlets__auxiliary-outlets-inoperative)
Cigar Lighter Inoperative
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Did you review the cigar lighter/auxiliary outlets circuit description and perform the necessary inspections? | Go to Step 2 | Go to Symptoms - Power Outlets |
| 2 | Verify that the cigar lighter is inoperative. Does the cigar lighter operate normally? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Connect a test lamp from the cigar lighter connector cavity 2 to ground. Did the test lamp illuminate? | Go to Step 5 | Go to Step 4 |
| 4 | Repair the open or short to ground or high resistance in power feed circuit between the FF fuse and the cigar lighter. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 8 | |
| 5 | Connect the test lamp from the cigar lighter connector cavity 1 to cavity 2. Did the test lamp illuminate? | Go to Step 6 | Go to Step |
| 6 | Replace the cigar lighter. Refer to Cigar Lighter Housing Replacement . Is the repair complete? | Go to Step 8 | |
| 7 | Repair the open or high resistance in the ground circuit between the cigar lighter and ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 8 | |
| 8 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Cigar Lighter Inoperative
Auxiliary Outlets Inoperative
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Did you review the cigar lighter/auxiliary outlets circuit description and perform the necessary inspections? | Go to Step 2 | Go to Symptoms - Power Outlets |
| 2 | Verify that the auxiliary power is inoperative. Does the auxiliary power operate normally? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Connect a test lamp from the cigar lighter connector cavity 2 to ground. Did the test lamp illuminate? | Go to Step 5 | Go to Step 4 |
| 4 | Repair the open or short to ground or high resistance in power feed circuit between the F1 fuse and the cigar lighter. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 8 | |
| 5 | Connect the test lamp from the auxiliary power outlet connector cavity 1 to cavity 2. Did the test lamp illuminate? | Go to Step 6 | Go to Step |
| 6 | Replace the auxiliary power outlet. Is the repair complete? | Go to Step 8 | |
| 7 | Repair the open or high resistance in the ground circuit between the auxiliary power outlet and ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 8 | |
| 8 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Auxiliary Outlets Inoperative
Removal Procedure
- Disconnect the negative battery cable.
- Remove the cigar lighter from the cigar lighter housing.
- Remove the floor console. Refer to «Console Replacement - Front Floor»(/chevrolet/aveo/i-2003-2008/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
- Remove the cigar lighter housing from the instrument panel.
- Disconnect the cigar lighter electrical connector.
Installation Procedure
- Connect the cigar lighter electrical connector.
- Install the cigar lighter housing in the instrument panel.
- Install the floor console. Refer to «Console Replacement - Front Floor»(/chevrolet/aveo/i-2003-2008/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
- Install the cigar lighter in the cigar lighter housing.
- Connect the negative battery cable.
