Configurable Customer Control System Chevrolet Avalanche II

Memory Modules 2 illustrations ~1735 words

Scheme 1

Scheme 1: Steering Wheel Secondary/Configurable Control Schematics

DIAGNOSTIC CODE INDEX

DTCDescription
DTC B1529B1529 03: Device Voltage Reference Output Circuit Voltage Below Threshold B1529 07: Device Voltage Reference Output Circuit Voltage Above Threshold
DTC B3622B3622 07: Steering Wheel Controls Signal Circuit

DIAGNOSTIC CODE INDEX

Diagnostic Starting Point - Secondary and Configurable Customer Controls

Begin the system diagnosis with the Diagnostic System Check - Vehicle (with HP2) or Diagnostic System Check - Vehicle (without HP2) . The Diagnostic System Check - Vehicle will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored DTCs and their status

The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.

Diagnostic Instructions

  1. Perform the «Diagnostic System Check - Vehicle (with HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-with) or «Diagnostic System Check - Vehicle (without HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-without) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
B+ Voltage ReferenceB1529 031B1529 07
Signal11B3622 07
1. Steering Wheel Controls Inoperative

Circuit/System Description

The body control module (BCM) supplies voltage to the audio steering wheel control switches and monitors the return signal. Each switch state is associated to a set resistance value and when pressed a specific voltage drop occurs across the resistor unique to the switch. The BCM identifies the switch selection and activates the feature.

Conditions for Running the DTC

  1. Battery voltage is between 9-16 volts
  2. The ignition is ON.

Conditions for Setting the DTC

B1529 03

  1. The BCM detects a short to ground in the B+ voltage reference circuit.
  2. The above condition is present for greater than 30 seconds.

B1529 07

  1. The BCM detects a short to voltage in the B+ voltage reference circuit.
  2. The above condition is present for greater than 30 seconds.

Action Taken When the DTC Sets

The BCM will ignore switch inputs.

Conditions for Clearing the DTC

  1. The condition responsible for setting the DTC no longer exists.
  2. A history DTC will clear once 100 consecutive malfunction free ignition cycles have occurred.

Reference Information

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.

Circuit/System Testing

  1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
  2. Ignition ON, test for B+ between the voltage reference circuit terminal 3 and ground. If less than the specified value, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM. If greater than the specified value, test the voltage reference circuit for a short to voltage. If the circuit tests normal, replace the BCM.
  3. If all circuits test normal, test or replace the right steering wheel control switch.

Component Testing

  1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
  2. Test the resistance between the voltage reference terminal 3 and the signal terminal 4 while depressing the appropriate steering wheel controls switch listed below. If not the specified range, replace the steering wheel switch.
Function SwitchMinimum Resistance ValueMaximum Resistance Value
Mute/Voice Recognition1.0k Ohms1.4k Ohms
Volume Down1.3k Ohms1.7k Ohms
Volume Up1.7k Ohms2.1k Ohms
Previous2.8k Ohms2.6k Ohms
Next2.2k Ohms3.2k Ohms
Source3.6k Ohms4.0k Ohms
Seek5.1k Ohms5.5k Ohms
No Switch PressedO.L.O.L.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(/chevrolet/avalanche/ii-2006-2013/remont/memory-modules/#configurable-customer-control-system)
  2. «Control Module References»(/chevrolet/avalanche/ii-2006-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming
  1. Perform the «Diagnostic System Check - Vehicle (with HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-with) or «Diagnostic System Check - Vehicle (without HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-without) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
B+ Voltage ReferenceB1529 031B1529 07
Right Steering Wheel Control Switch Signal11B3622 07
1. Steering Wheel Controls Inoperative

The body control module (BCM) monitors the steering wheel control signal circuit voltage. If the voltage level is too high, damage may result in the system. When a high voltage condition is detected, the BCM will ignore the switch command.

  1. Battery voltage is between 9-16 volts
  2. The ignition is ON.

The BCM detects a short to voltage in the steering wheel control switch signal circuit.

The BCM will ignore switch inputs.

  1. The condition responsible for setting the DTC no longer exists.
  2. A history DTC will clear once 100 consecutive malfunction free ignition cycles have occurred.

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.

  1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
  2. Ignition ON, test for B+ between the voltage reference circuit terminal 3 and ground. If less than the specified value, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
  3. Test for B+ between the voltage reference circuit terminal 3 and the signal circuit terminal 4. If less than the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
  4. Ignition OFF, disconnect the X1 harness connector at the BCM.
  5. Test for infinite resistance between the signal circuit terminal 4 and ground. If less than the specified value, test the signal circuit for a short to ground.
  6. If all circuits test normal, test or replace the right steering wheel control switch.
  1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
  2. Test the resistance between the voltage reference terminal 3 and the signal terminal 4 while depressing the appropriate steering wheel controls switch listed below. If not the specified range, replace the steering wheel switch.
Function SwitchMinimum Resistance ValueMaximum Resistance Value
Mute/Voice Recognition1.0k Ohms1.4k Ohms
Volume Down1.3k Ohms1.7k Ohms
Volume Up1.7k Ohms2.1k Ohms
Previous2.2k Ohms2.6k Ohms
Next2.8k Ohms3.2k Ohms
Source3.6k Ohms4.0k Ohms
Seek5.1k Ohms5.5k Ohms
No Switch PressedO.L.O.L.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(/chevrolet/avalanche/ii-2006-2013/remont/memory-modules/#configurable-customer-control-system)
  2. «Control Module References»(/chevrolet/avalanche/ii-2006-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

Symptoms - Secondary and Configurable Customer Controls

IMPORTANTPerform the Diagnostic System Check - Vehicle (with HP2) or Diagnostic System Check - Vehicle (without HP2) before using the Symptom Tables in order to verify that all of the following conditions are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Steering Wheel Controls Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which may affect the operation of the Steering Wheel Controls System. Refer to «Checking Aftermarket Accessories»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__checking-aftermarket-accessories) .
  2. Inspect for easily accessible or visible system components for obvious damage or conditions which may cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to Steering Wheel Controls Malfunction in order to diagnose the symptom.

  1. Perform the «Diagnostic System Check - Vehicle (with HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-with) or «Diagnostic System Check - Vehicle (without HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-without) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
B+ Voltage ReferenceB1529 031B1529 07
Right Steering Wheel Control Switch Signal11B3622 07
1. Steering Wheel Controls Inoperative

The body control module (BCM) supplies voltage to the audio steering wheel control switches and monitors the return signal. Each switch state is associated to a set resistance value and when pressed a specific voltage drop occurs across the resistor unique to the switch. The BCM identifies the switch selection and activates the feature.

Diagnostic Aids

  1. This diagnostic is for the audio steering wheel controls.
  2. Before diagnosis of the steering wheel controls, ensure the primary controls of the associated component are functioning properly.

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.

  1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
  2. Ignition ON, test for B+ between the voltage reference circuit terminal 3 and ground. If less than the specified value, test the voltage reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
  3. Test for B+ between the voltage reference circuit terminal 3 and the signal circuit terminal 4. If less than the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
  4. Ignition OFF, disconnect the X1 harness connector at the BCM.
  5. Test for infinite resistance between the signal circuit terminal 4 and ground. If less than the specified value, test the signal circuit for a short to ground.
  6. If all circuits test normal, test or replace the right steering wheel control switch.
  1. Ignition OFF, disconnect the harness connector at the right steering wheel control switch.
  2. Test the resistance between the voltage reference terminal 3 and the signal terminal 4 while depressing the appropriate steering wheel controls switch listed below. If not the specified range, replace the steering wheel switch.
Function SwitchMinimum Resistance ValueMaximum Resistance Value
Mute/Voice Recognition1.0k Ohms1.4k Ohms
Volume Down1.3k Ohms1.7k Ohms
Volume Up1.7k Ohms2.1k Ohms
Previous2.2k Ohms2.6k Ohms
Next2.8k Ohms3.2k Ohms
Source3.6k Ohms4.0k Ohms
Seek5.1k Ohms5.5k Ohms
No Switch PressedO.L.O.L.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(/chevrolet/avalanche/ii-2006-2013/remont/memory-modules/#configurable-customer-control-system)
  2. «Control Module References»(/chevrolet/avalanche/ii-2006-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

Scheme 2

Scheme 2: Steering Wheel Control Switch Assembly Replacement
CalloutComponent Name
WARNING: Refer to SIR Warning . Preliminary Procedure Disable the supplemental inflatable restraint (SIR) system. Refer to SIR Disabling and Enabling . Remove the horn switch. Refer to Steering Wheel Horn Switch Replacement .
1Steering Wheel Trim Cover (Qty: 2) Procedure: Remove the 4 horn contact screws.
2Steering Wheel Control Switch Assembly Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tip: Quantity may vary with vehicle options. Tighten: 1 N.m (9 lb in)
3Steering Wheel Control Switch Assembly (Qty: 2) Tip: Quantity may vary with vehicle options. Ensure the steering wheel control switch(es) are properly seated to the steering wheel shroud during installation.
WARNING
Refer to SIR Warning .
CAUTION
Refer to Fastener Caution .

Steering Wheel Controls Description and Operation

The steering wheel control switches duplicate the function of the primary controls of the associated component, through a network of multiple momentary contact switches and a series of resistors. The body control module (BCM) supplies voltage to the switches and monitors the return signal for when a switch is pressed, a specific voltage drop occurs. The BCM identifies the one selected, then sends a serial data message that is received by the component controlled, activating the feature.

This section is intended to diagnosis the circuits between the BCM and the steering wheel control switches. If the primary control for the device is inoperative, refer to the appropriate section for the component the steering wheel control switch is functioning.
