Accessory Power Socket Chevrolet Avalanche II

Body Electrical 4 illustrations ~2008 words

Scheme 1

Scheme 1: Cigar Lighter/Power Outlet Schematics
Scheme 1: Cigar Lighter/Power Outlet Schematics

Scheme 2

Scheme 2
Scheme 2

Diagnostic Starting Point - Power Outlets

Begin the system diagnosis by reviewing the Power Outlets Description and Operation . Reviewing the Description and Operation will help to determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help to determine if the condition described by the customer is normal operation. Refer to Symptoms - Power Outlets in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Symptoms - Power Outlets

The following steps must be completed before using the symptom tables.

  1. Perform the «Diagnostic System Check - Vehicle (with HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-with) or «Diagnostic System Check - Vehicle (without HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-without) .
  2. Review the system operation in order to understand the system functions. Refer to «Power Outlets Description and Operation»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket) .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which can affect the operation of the power outlets. Refer to «Checking Aftermarket Accessories»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__checking-aftermarket-accessories) .
  2. Inspect the accessible system components or the visible system components for obvious damage or for obvious conditions which can cause the symptom.

Intermittent

Electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to Power Outlet Receptacle Inoperative in order to diagnose the system.

Diagnostic Instructions

  1. Perform the «Diagnostic System Check - Vehicle (with HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-with) or «Diagnostic System Check - Vehicle (without HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-system-check-vehicle-without) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/avalanche/ii-2006-2013/remont/oem-general-information/#vehicle-diagnostic-information-2-of-2__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
Battery Voltage11
Ignition 1 Voltage11
Signal112
Line Hot111
Line Neutral111
Ground1
1. accessory AC/DC power control module always OFF 2. accessory AC/DC power control module always ON

Circuit/System Description

The accessory AC/DC power control module converts 12 volt direct current (DC) battery voltage to 110-120 volt alternating current (AC) in order to operate AC powered devices. The accessory AC/DC power control module provides up to 150 watts of power. The accessory AC/DC power control module is connected to a chassis ground circuit and receives fuse protected battery voltage.

The accessory power outlet has an internal switch, that detects when an AC powered device is plugged into the outlet. When the ignition is ON and a 120 volt AC powered device is plugged into the accessory power outlet, the normally-open switch in the accessory power outlet, closes. When the accessory AC/DC power control module detects the voltage from the accessory power outlet switch, the inverter module begins to supply 110-120 volts AC to the accessory power outlet after a 1.5 second delay.

Diagnostic Aids

A household 120 volt duplex receptacle outlet tester should not be used to diagnose this system. The tester will indicate an open ground, which is a normal condition.

Reference Information

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/avalanche/ii-2006-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Circuit/System Verification

  1. Ignition ON, connect an AC power extension cord to the accessory power outlet. Inserting the extension cord plug into the accessory power outlet turns the accessory AC/DC power control module ON.
  2. Test for 110-120 volts AC across the line hot and line neutral terminals of the extension cord.
  3. Test for 59-61 Hz AC across the line hot and line neutral terminals of the extension cord. If not within the specified value, replace the accessory AC/DC power control module.

Circuit/System Testing

  1. Ignition OFF, disconnect the harness connectors at the accessory AC/DC power control module.
  2. Ignition OFF and the scan tool disconnected, open and close the driver door and wait 1 minute. Test for less than 5 ohms between the ground circuit terminal 1 X2 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
  3. Ignition ON, verify that a test lamp illuminates between the B+ circuit terminal 2 X2 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
  4. Test for less than 1.0 volt between each appropriate control circuit terminal listed below and ground: Control terminal 2 X1. Control terminal 4 X1. Control terminal 6 X1. If greater than the specified value, test the appropriate circuit for a short to voltage. If the circuit tests normal, test or replace the accessory power outlet.
  5. Test for infinite resistance between each appropriate control circuit terminal listed below and ground: Control terminal 2 X1. Control terminal 4 X1. Control terminal 6 X1. If less than the specified value, test the appropriate circuit for a short to ground.
  6. Ignition OFF, test for less than 5 ohms between the accessory power outlet line circuit terminal and the accessory AC/DC power control module terminal listed below: The line hot circuit terminal 3 and the accessory AC/DC power control module terminal 4 X1. The line neutral circuit terminal 6 and the accessory AC/DC power control module terminal 2 X1. If greater than the specified range, test the appropriate line circuit for an open/high resistance. If the circuit tests normal, test or replace the accessory power outlet.
  7. Disconnect the harness connector at the accessory power outlet.
  8. Ignition ON, verify that a test lamp illuminates between the ignition voltage circuit terminal 4 and ground. If the test lamp does not illuminate, test the ignition voltage circuit for a short to ground or an open/high resistance.
  9. Connect the harness connector at the accessory power outlet.
  10. Connect an AC powered device to the accessory power outlet.
  11. Ignition ON, verify that a test lamp illuminates between the accessory AC/DC power control module signal circuit terminal 2 X1 and ground. If the test lamp does not illuminate, test the signal circuit for an open/high resistance. If the circuit tests normal, test or replace the accessory power outlet.
  12. If all circuits test normal, replace the accessory AC/DC power control module.

Component Testing

Accessory Power Outlet

  1. Ignition OFF, remove the accessory power outlet.
  2. Test for greater than 1M ohm between terminal 6 and terminal 3. If less than the specified range, replace the accessory power outlet.
  3. Test for less than 3 ohms between the following terminals: The terminal 6 and the accessory hot terminal The terminal 3 and the accessory neutral terminal If greater than the specified range, replace the accessory power outlet.
  4. Test for infinite resistance between terminal 4 and terminal 1. If not the specified value, replace the accessory power outlet.
  5. Connect an AC powered device to the accessory power outlet.
  6. Test for less than 3 ohms between terminal 4 and terminal 1. If greater than the specified range, replace the accessory power outlet.
  7. Test for 2.9-3.1 volts, with the DMM set on the diode setting and the positive test lead to terminal 6 and the negative test lead to terminal 3. If not within the specified range, replace the accessory power outlet.
  8. Test for 0.0-0.1 volts, with the DMM set on the diode setting and the positive test lead to terminal 3 and the negative test lead to terminal 6. If greater than the specified range, replace the accessory power outlet.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Accessory Power Receptacle Replacement (HP2)»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket)
  2. «Control Module References»(/chevrolet/avalanche/ii-2006-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for control module replacement, setup, and programming

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .

Removal Procedure

  1. Remove the auxiliary power outlet fuse from the fuse block.
  2. Remove the receptacle: Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in) from the front of the receptacle. The J 42059 pushes the plastic latches from these tab windows and the receptacle can be pulled straight out. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) . Place one side of the "T" portion of the J 42059 into the tab window. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) . The J 42059 will not fit straight into the receptacle. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) . Angle the J 42059 slightly for insertion into the receptacle. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) . Insert the other side of the "T" into the opposite tab window. You must move the J 42059 handle toward horizontal to engage the other tab window. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) . Use the J 42059 to pull the receptacle straight out. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) .
  3. If J 42059 tool fails to release the lighter socket from the retainer, perform the following alternate method:. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) . Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 as directed above to remove the socket. See «Special Tools»(/chevrolet/avalanche/ii-2006-2013/remont/body-electrical/#accessory-power-socket__special-tools) .

Installation Procedure

  1. Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
  2. Install the retainer by pressing into place fully seated.
  3. Connect the electrical connector to the receptacle.
  4. Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
  5. Install the accessory power receptacle fuse.

Scheme 3

Scheme 3: Accessory AC and DC Power Control Module Replacement
Scheme 3: Accessory AC and DC Power Control Module Replacement
CalloutComponent Name
Preliminary Procedure: Remove the left side rear quarter trim panel. Refer to Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/E61) or Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/o E61) .
1Tire Inflator Bracket Nut (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Tire Inflator Bracket
3Accessory AC and DC Power Control Module Nut Tighten: 9 N.m (80 lb in)
4Accessory AC and DC Power Control Module Procedure Disconnect the electrical connectors. For programming and setup procedures, refer to Control Module References .
CAUTION
Refer to Fastener Caution .

Scheme 4

Scheme 4: Accessory Power Receptacle Replacement (HP2)
Scheme 4: Accessory Power Receptacle Replacement (HP2)
CalloutComponent Name
1Rear Seat Cup Holder Procedure: Remove cup holder to access receptacle.
2Accessory Power Receptacle Procedure Squeeze tabs to unsnap the receptacle from the left side rear quarter trim panel. Disconnect the electrical connector.

System Description

The alternating current (AC) accessory power outlet system consists of the accessory AC/DC power control module and the accessory power outlet. The accessory AC/DC power control module converts 12 volt direct current (DC) battery power to 110-120 volts AC power to operate AC powered devices. The power inverter module within the accessory AC/DC power control module provides up to 150 watts of power. The accessory power outlet is designed to accept two and three prong 110-120 volt power cords. The accessory power outlet provides the usual hot and neutral line circuits. The neutral circuit is isolated from the chassis ground. The center terminal receptacle is empty and does provide a circuit ground.

System Operation

The accessory AC/DC power control module receives fuse protected battery voltage and is connected to the 12 volt electrical system ground. The accessory power outlet has an internal switch, that detects when an AC powered device is plugged into the outlet. When the ignition is ON, and a 120 volt AC powered device is plugged into the accessory power outlet, the normally open switch in the accessory power outlet, closes. When the accessory AC/DC power control module detects the voltage from the accessory power outlet switch, the inverter module begins to supply 110-120 volts AC to the accessory power outlet after a 1.5 second delay. An LED indicator in the accessory power outlet illuminates when the outlet is receiving AC voltage. The accessory AC/DC power system is protected against circuit overload and circuit shorts to ground.

Isolation Fault Protection

The accessory AC/DC power control module contains a ground fault circuit interrupter (GFCI). GFCI monitors the 110 volt AC circuit for the following conditions

  1. The hot circuit or the neutral circuit becomes shorted to the vehicle chassis ground
  2. The current flow through the hot circuit and the neutral circuit differs from each other by greater than 6 mA

If either of the above conditions is detected, the accessory AC/DC power control module will turn OFF. The module remains OFF, until the AC powered device is unplugged from the outlet, and then plugged into the outlet after a 3 second delay.

Overload Shutdown

The accessory AC/DC power control module will turn OFF if the current in the 110 volt circuit exceeds 3.8 amps for 1 second, or 2.5 amps for 10 seconds. The module will turn ON again, when the AC powered device is unplugged from the outlet, and then plugged into the outlet after a 3 second delay.

Special Tools

Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
