Tire pressure monitoring circuit for Chevrolet Avalanche I (2001-2006)
Tire pressure monitoring circuit
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
GRY WIRE
IGN
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT TIRE PRESSURE MONITOR SENSOR SOLID STATE
LEFT REAR TIRE PRESSURE MONITOR SENSOR SOLID STATE
MESSAGE DISPLAY
PASSENGER DOOR MODULE (PDM) CLASS 2 SERIAL DATA
RECEIVE INPUT
RIGHT FRONT TIRE PRESSURE MONITOR SENSOR SOLID STATE
RIGHT REAR TIRE PRESSURE MONITOR SENSOR SOLID STATE
TAN WIRE
TIRE PRESSURE IND
