DESCRIPTION & OPERATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Each outside mirror has 2 reversible motors: one to adjust the mirror view up and down, the other to adjust the mirror view right and left. The driver operates 4 switches that control the polarity of the voltage to the motors. The mirror select switch directs these control voltages to either the right or left outside mirror.
COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Convenience Center | Behind Left Side Of Instrument Panel. (Scheme 1) |
| Fuse Block | Behind Left Side Of Instrument Panel. (Scheme 1) |
| Power Mirror Motor (Left) | Inside Left Mirror Housing. |
| Power Mirror Motor (Right) | Inside Right Mirror Housing. |
| Power Mirror Switch | Center Of Instrument Panel. (Scheme 1) |
| C224 (In-Line Fuse Amp) | Behind Left Side of Instrument Panel, Near Fuse Block. (Scheme 1) |
| C248 | Behind Left side Of Instrument Panel, At Fuse Block. (Scheme 1) |
| C284 | Below Right Side Of Instrument Panel, At Right Shroud. (Scheme 2) |
| C285 | Below Left Side Of Instrument Panel. At Left Shroud. (Scheme 2) |
| P225 | Left A-Pillar. (Scheme 2) |
| P226 | Right A-Pillar. (Scheme 2) |
| P520 | At Left A-Pillar. (Scheme 3) |
| P620 | At Right A-Pillar. (Scheme 3) |
| S252 | In Crossbody Harness, Left Side Of Instrument Panel. (Scheme 2) |
| S253 | In Crossbody Harness, Left Side Of Instrument Panel. (Scheme 2) |
| S254 | In Crossbody Harness, Left Side Of Instrument Panel. (Scheme 2) |
COMPONENT LOCATIONS
Scheme 1
Scheme 2
Scheme 3
PRELIMINARY INSPECTION
- Check condition of INSTR LPS, HORN/DM and the in-line (C224) fuse(s). If fuse(s) is blown, locate and repair source of the overload. Replace the fuse.
- If the problem still exists, refer to «SYSTEM INDEX»(/chevrolet/astro/i-1985-2005/remont/mirrors/#mirrors-power) .
SYSTEM TESTS
SYSTEM INDEX
TEST A: BOTH POWER MIRRORS DO NOT OPERATE
If both power mirrors do not operate (Scheme 4)
Scheme 4
TEST B: LEFT POWER MIRROR DOES NOT OPERATE OR ONLY MOVES IN ONE DIRECTION
If left power mirror does not operate or only moves in one direction (Scheme 5) See CONNECTOR IDENTIFICATION.
Scheme 5
TEST C: RIGHT POWER MIRROR DOES NOT OPERATE OR ONLY MOVES IN ONE DIRECTION
If right power mirror does not operate or only moves in one direction (Scheme 6) See CONNECTOR IDENTIFICATION.
Scheme 6
REMOVAL & INSTALLATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
- Remove power window and lock controls.
- Remove window handle using J 9886-01.
- Remove door handle bezel. (Scheme 7)
- Remove fasteners in armrest and lower panel.
- Feed power controls through panel.
- Remove trim panel retainers from the door. Pry the trim panel from the door frame at the window seal. (Scheme 8)
- To install, reverse removal procedure.
Scheme 7
Scheme 8
- Remove door trim panel. Refer to «DOOR TRIM PANEL»(/chevrolet/astro/i-1985-2005/remont/mirrors/#mirrors-power).
- Remove garnish molding (front).
- Remove mirror-to-door nuts. (Scheme 9)
- Disconnect controller and cable from door or electrical connector.
- Remove mirror head.
- To install, reverse removal procedure and tighten nut to 10 N.m (89 INCH Lbs.).
Scheme 9
TORQUE SPECIFICATIONS
| Application | INCH Lbs. (N.m) |
|---|---|
| Mirror Nuts | 89 (10) |
TORQUE SPECIFICATIONS
Scheme 10
Scheme 11
