Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Washer Solvent Container Nuts | 12 N.m | 106 lb in |
| Wiper Arm Nut | 29 N.m | 21 lb ft |
| Wiper Drive System Module Screws | 8 N.m | 70 lb in |
| Wiper Motor Screws | 5 N.m | 45 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Dimmer/Head Up Display (HUD) Switch |
| 2 | Turn Signal/Multifunction Switch |
| 3 | Inflatable Restraint Steering Wheel Module |
| 4 | Instrument Panel Cluster (IPC) |
| 5 | Air Temperature Sensor - Inside |
| 6 | Windshield Wiper/Washer Switch |
| 7 | Driver Information Center (DIC) Switch |
| 8 | Hazard Switch |
| 9 | CD Changer |
| 10 | Valet Switch |
| 11 | Inflatable Restraint I/P Module |
| 12 | Inflatable Restraint I/P Module Disable Switch |
| 13 | I/P Compartment Lamp |
| 14 | Radio |
| 15 | HVAC Control Module |
| 16 | Cigar Lighter |
| 17 | Courtesy Lamp Switch - Console |
| 18 | Folding Top Switch |
| 19 | Inflatable Restraint I/P Module Disable Switch LED |
| 20 | Traction Control Switch |
| 21 | Auxiliary Power Outlet |
| 22 | Courtesy Lamp - Console |
| 23 | Automatic Transmission Shift Lever |
| 24 | Ignition Mode Switch |
| 25 | Steering Wheel Controls - Right |
| 26 | Horn Switch |
| 27 | Data Link Connector (DLC) |
| 28 | Steering Wheel Controls - Left |
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Windshield Washer Solvent Container |
| 2 | Windshield Washer Fluid Pump |
| 3 | Windshield Washer Fluid Level Switch |
| 4 | Headlamp Washer Fluid Pump |
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | Windshield Wiper Motor |
Scheme 6
| Callout | Component Name |
|---|---|
| 1 | Outside Moisture Sensor (CE1) |
Scheme 7
| Connector Part Information OEM: 12052613 Service: 12085212 Description: 2-Way F Metri-Pack 480 Series Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Wiper/Washer Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 1350 | Ground |
| B | PU | 1197 | Headlamp Washer Pump Control |
Headlamp Washer Fluid Pump
Scheme 8
| Connector Part Information OEM: 15398934 Service: 88953367 Description: 8-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: 43030-0010/23 Core/Insulation Crimp: H/H Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU) |
Wiper/Washer Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | GY | 91 | Windshield Wiper Motor Relay Coil Supply Voltage |
| B | L-GN | 1715 | Windshield Wiper Switch High Signal |
| C | BK | 1550 | Ground |
| D | YE | 143 | Accessory Voltage |
| E | L-BU | 1714 | Windshield Wiper Switch Low Signal |
| F | PK | 94 | Windshield Washer Switch Signal |
| G | PK | 5780 | Windshield Wiper Motor Park Switch Fused Signal |
| H | Not Used |
Outside Moisture Sensor
Scheme 9
| Connector Part Information OEM: 12162195 Service: 88987183 Description: 2-Way F Metri-Pack 150.2 Series Sealed, Pull To Seat (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Wiper/Washer Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 1350 | Ground |
| B | TN/WH | 99 | Windshield Washer Fluid Level Signal |
Windshield Washer Fluid Level Switch
Scheme 10
| Connector Part Information OEM: 15326801 Service: 15306156 Description: 2-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Wiper/Washer Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 1350 | Ground |
| B | OG | 228 | Windshield Washer Pump Control |
Windshield Washer Fluid Pump
Scheme 11
| Connector Part Information OEM: 15393432 Service: 89046627 Description: 5-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Wiper/Washer Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 1450 | Ground |
| B | YE | 196 | Windshield Wiper Motor Park Switch Signal |
| C | YE | 243 | Accessory Voltage |
| D | PU | 92 | Windshield Wiper Motor High Speed Control |
| E | D-GN | 95 | Windshield Wiper Motor Low Speed Control |
Windshield Wiper Motor
Windshield Wiper Motor
| Connector Part Information OEM: 15393432 Service: 89046627 Description: 5-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Wiper/Washer Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 1450 | Ground |
| B | YE | 196 | Windshield Wiper Motor Park Switch Signal |
| C | YE | 243 | Accessory Voltage |
| D | PU | 92 | Windshield Wiper Motor High Speed Control |
| E | D-GN | 95 | Windshield Wiper Motor Low Speed Control |
Windshield Wiper Motor
Diagnostic Starting Point - Wiper/Washer Systems
Begin the system diagnosis with Diagnostic System Check - Vehicle . The Diagnostic System Check - Vehicle will provide the following information
- The identification of the control modules which command the system
- The ability of the control modules to communicate through the serial data circuit
- The identification of any stored diagnostic trouble codes (DTCs) and their status
The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.
Scan Tool Output Controls
| Scan Tool Output Control | Additional Menu Selection(s) | Description |
|---|---|---|
| Headlamp Washer | Turns the headlamp washer on/off. |
Scan Tool Output Controls
Scan Tool Data List
| Scan Tool Parameter | Data List | Units Displayed | Typical Data Value |
|---|---|---|---|
| Operating Conditions: Ignition ON, Engine OFF | |||
| Battery Voltage Signal | Data | Volts | 12.5 |
| Wiper Relay Cmd. | Data | On/Off | Off |
BCM Data
| Scan Tool Parameter | Data List | Units Displayed | Typical Data Value |
|---|---|---|---|
| Operating Conditions: Ignition ON, Engine OFF | |||
| Windshield Washer Fluid | Data | OK/Low Fluid | Off |
IPC Data
Circuit Description
The body control module (BCM) provides a high side drive output that controls the headlamp washer relay.
DTC Descriptor
This diagnostic procedure supports the following DTC
DTC B3810 Headlamp Washer Relay Circuit
| DTC Symptom | DTC Symptom Descriptor |
|---|---|
| 02 | Short to ground |
| 05 | Short to battery or open |
DTC B3810
Conditions for Running the DTC
The only requirements are valid operating voltage and ground.
Conditions for Setting the DTC
All of the following conditions exist for more than 1 second
B3810 02
The BCM detects a short to ground in headlamp washer relay control when output is active.
B3810 05
The BCM detects a short to battery or an open in headlamp washer relay control when output is inactive.
The BCM disables the headlamp washer function.
Conditions for Clearing the DTC
- A current DTC clears when the malfunction is no longer present.
- A history DTC clears when the module ignition cycle counter reaches the reset threshold, without a repeat of the malfunction.
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: During the headlamp washer fluid pump relay operation, listen for an audible click. Command the ON and the OFF states. Repeat the commands as necessary.
- 3: Verifies that the BCM is providing voltage to the headlamp washer fluid pump relay.
- 4: Tests for an open in the ground circuit to the headlamp washer fluid pump relay.
- 5: Tests for constant voltage to the headlamp washer fluid pump relay.
- 6: Test the headlamp washer fluid pump relay control circuit for a short to ground or open.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Turn ON the ignition, with the engine OFF. With a scan tool, command the headlamp washer relay ON and OFF. Does the headlamp washer relay turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the headlamp washer relay. Turn ON the ignition, with the engine OFF. Connect a test lamp to ground. Probe the control circuit of the headlamp washer relay with the test lamp. With a scan tool, command the headlamp washer relay ON and OFF. Does the test lamp turn ON and OFF with each command? | Go to Step 4 | Go to Step 5 |
| 4 | Connect a test lamp across the control circuit of the headlamp washer relay and the ground circuit of the headlamp washer relay. With a scan tool, command the headlamp washer relay ON and OFF. Does the test lamp turn ON and OFF with each command? | Go to Step 8 | Go to Step 10 |
| 5 | Does the test lamp remain illuminated with each command? | Go to Step 7 | Go to Step 6 |
| 6 | Test the control circuit of the headlamp washer relay for a short to ground or an open. Refer to Circuit Testing and to Wiring Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 7 | Turn ON the ignition, with the engine OFF. Test the control circuit of the headlamp washer relay for a short to voltage. Refer to Circuit Testing and to Wiring Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 8 | Inspect for poor connections at the headlamp washer relay. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 11 |
| 9 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 12 |
| 10 | Repair the ground circuit of the headlamp washer relay. Refer to Wiring Repairs . Did you complete the repair? | Go to Step 13 | |
| 11 | Replace the headlamp washer relay. Did you complete the replacement? | Go to Step 13 | |
| 12 | Replace the BCM. Refer to Control Module References for replacement, setup, and programming. Did you complete the replacement? | Go to Step 13 | |
| 13 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC. Does the DTC reset? | Go to Step 2 | System OK |
DTC B3810
Symptoms - Wiper/Washer Systems
| IMPORTANT | Refer to the system description and operation from the following list in order to familiarize yourself with the system functions. |
- «Wiper/Washer System Description and Operation»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system)
- «Headlamp Washer System Description and Operation»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system)
Visual/Physical Inspection
- Inspect for aftermarket devices which could affect the operation of the Windshield Wiper/Washer System. Refer to «Checking Aftermarket Accessories»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) .
- Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
- Inspect the washer fluid reservoir for the proper fluid level.
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Symptom List
Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom
- «Low Washer Fluid Indicator Malfunction»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__low-washer-fluid-indicator-malfunction)
- «Washers Always On»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__washers-always-on)
- «Washers Inoperative»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__washers-inoperative)
- «Wipers Always On»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__wipers-always-on)
- «Wipers Inoperative - All Modes»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__wipers-inoperative-all-modes)
- «Wipers Inoperative - One or More Modes»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__wipers-inoperative-one-or-more)
- «Headlamp Washers Inoperative»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__headlamp-washers-inoperative)
- «Headlamp Washers Always On»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__headlamp-washers-always-on)
Low Washer Fluid Indicator Malfunction
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: The DIC always displays low washer fluid or does not display anything with low washer fluid. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Verify the fault is present. Does the system operate normally? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the windshield washer fluid level switch connector. Turn ON the ignition, with the engine OFF. Wait 60 seconds. Does the driver information center (DIC) display low washer fluid? | Go to Step 6 | Go to Step 4 |
| 4 | Turn OFF the ignition. Connect a fused jumper wire from the windshield washer fluid level signal circuit terminal in the washer fluid level switch connector to a good ground. Turn ON the ignition, with the engine OFF. Wait 60 seconds. Does the DIC display low washer fluid? | Go to Step 5 | Go to Step 7 |
| 5 | Turn OFF the ignition. Connect a fused jumper wire across the windshield washer fluid level switch harness connector terminals. Turn ON the ignition, with the engine OFF. Wait 60 seconds. Does the DIC display low washer fluid? | Go to Step 9 | Go to Step 8 |
| 6 | Test the windshield washer fluid level signal circuit for a short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 11 |
| 7 | Test the windshield washer fluid level signal circuit for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 11 |
| 8 | Repair the washer fluid level switch ground circuit for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you complete the replacement? | Go to Step 13 | |
| 9 | Inspect for poor connections at the windshield washer fluid level switch. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 10 |
| 10 | Replace the windshield washer fluid level switch. Refer to Washer Solvent Container Level Sensor Replacement . Did you complete the replacement? | Go to Step 13 | |
| 11 | Inspect for poor connections at the instrument panel cluster (IPC). Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 12 |
| 12 | Replace the IPC. Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement? | Go to Step 13 | |
| 13 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Low Washer Fluid Indicator Malfunction
Washers Always On
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: The windshield washer pump is always ON. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn the windshield wiper/washer switch to the OFF position. Turn ON the ignition, with the engine OFF. Is the windshield washer fluid pump always ON? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 3 | Are the windshield wipers always ON? | Go to Step 4 | Go to Step 14 |
| 4 | Turn OFF the ignition. Disconnect the windshield wiper/washer switch connector. Turn ON the ignition, with the engine OFF. Is the windshield washer fluid pump always ON? | Go to Step 5 | Go to Step 8 |
| 5 | Turn OFF the ignition. Disconnect the connector 1 of the body control module (BCM). Disconnect the windshield washer switch signal circuit from the BCM. Reconnect the connector 1 of the BCM. Turn ON the ignition, with the engine OFF. Is the windshield washer fluid pump always ON? | Go to Step 6 | Go to Step 10 |
| 6 | Turn OFF the ignition. Disconnect the outside moisture sensor connector. Turn ON the ignition, with the engine OFF. Is the windshield washer fluid pump always ON? | Go to Step 7 | Go to Step 12 |
| 7 | Repair the windshield washer fluid pump control circuit for a short to ground. Refer to Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 17 | |
| 8 | Inspect for poor connections at the windshield wiper/washer switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 17 | Go to Step 9 |
| 9 | Replace the windshield wiper/washer switch. Refer to Windshield Wiper and Washer Switch Replacement . Did you complete the replacement? | Go to Step 17 | |
| 10 | Inspect for poor connections at the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 17 | Go to Step 11 |
| 11 | Replace the BCM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement? | Go to Step 17 | |
| 12 | Inspect for poor connections at the outside moisture sensor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 17 | Go to Step 13 |
| 13 | Replace the outside moisture sensor. Refer to Windshield Outside Moisture Sensor Replacement . Did you complete the replacement? | Go to Step 17 | |
| 14 | Disconnect the windshield washer relay. Is the windshield washer pump ON? | Go to Step 15 | Go to Step 16 |
| 15 | Repair the windshield washer fluid pump supply circuit for a short to voltage. Refer to Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 17 | |
| 16 | Replace the windshield washer relay. Is the repair complete? | Go to Step 17 | |
| 17 | Reconnect all previous disconnected circuits or connectors. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Washers Always On
Washers Inoperative
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: The windshield washer is inoperative and windshield wipers operate normally. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn the ignition ON. Press the windshield washer switch. Do the windshield washers operate normally? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Turn the ignition OFF. Disconnect the windshield washer relay. Connect a test lamp from battery positive voltage to the windshield washer relay control circuit terminal in the underhood fuse block. Turn the ignition ON, with the engine OFF. Press the windshield washer switch. Does the test lamp illuminate? | Go to Step 4 | Go to Step 7 |
| 4 | Turn the ignition OFF. Connect the windshield washer relay. Disconnect the windshield washer fluid pump connector. Connect a test lamp across the windshield washer fluid pump harness connector terminals. Turn the ignition ON, with the engine OFF. Press the windshield washer switch. Does the test lamp illuminate? | Go to Step 9 | Go to Step 5 |
| 5 | Test the windshield washer fluid pump supply voltage circuit for an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 6 |
| 6 | Test the windshield washer fluid pump ground circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 11 |
| 7 | Disconnect the windshield washer/wiper switch. Test the windshield washer relay control circuit for an open or short to B+. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Turn the ignition ON, with the engine OFF when testing for a short to B+. Did you find and correct the condition? | Go to Step 14 | Go to Step 8 |
| 8 | Test the ground circuit of the windshield washer/wiper switch for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 12 |
| 9 | Inspect for poor connections at the windshield washer fluid pump. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 10 |
| 10 | Replace the windshield washer fluid pump. Refer to Washer Pump Replacement . Is the repair complete? | Go to Step 14 | |
| 11 | Replace the windshield washer relay. Is the repair complete? | Go to Step 14 | |
| 12 | Inspect for poor connections at the windshield wiper/washer switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 13 |
| 13 | Replace the windshield wiper/washer switch. Refer to Windshield Wiper and Washer Switch Replacement . Is the repair complete? | Go to Step 14 | |
| 14 | Reconnect all previous disconnected connectors/relay. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Washers Inoperative
Wipers Always On
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: Windshield wipers are always ON. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn the windshield wiper/washer switch OFF. Turn ON the ignition. Are the windshield wipers always ON? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 3 | Are the windshield wipers always ON in high speed? | Go to Step 4 | Go to Step 9 |
| 4 | Turn OFF the ignition. Disconnect the wiper HI/LO relay. Turn ON the ignition, with the engine OFF. Are the windshield wipers always ON? | Go to Step 5 | Go to Step 6 |
| 5 | Turn OFF the ignition. Disconnect the windshield wiper motor. Turn ON the ignition, with the engine OFF. Test the windshield wiper motor high speed control circuit for a short to B+. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 16 |
| 6 | Reconnect the wiper HI/LO relay. Disconnect the windshield wiper/washer switch. Turn ON the ignition, with the engine OFF. Are the windshield wipers always ON? | Go to Step 7 | Go to Step 18 |
| 7 | Turn OFF the ignition. Disconnect the outside moisture sensor. Turn ON the ignition, with the engine OFF. Are the windshield wipers always ON? | Go to Step 8 | Go to Step 21 |
| 8 | Turn OFF the ignition. Repair the wiper HI/LO relay control circuit for a short to ground. Refer to Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 24 | |
| 9 | Turn OFF the ignition. Disconnect the wiper ON/OFF relay. Turn ON the ignition, with the engine OFF. Are the windshield wipers always ON? | Go to Step 10 | Go to Step 11 |
| 10 | Turn OFF the ignition. Disconnect the windshield wiper motor. Turn ON the ignition, with the engine OFF. Test the windshield wiper motor low speed control circuit for a short to B+. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 16 |
| 11 | Turn OFF the ignition. Reconnect the wiper ON/OFF relay. Disconnect the windshield wiper/washer switch. Turn ON the ignition, with the engine OFF. Are the windshield wipers always ON? | Go to Step 13 | Go to Step 12 |
| 12 | Turn OFF the ignition. Disconnect the outside moisture sensor. Test the windshield wiper switch low signal circuit for a short to ground or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 18 |
| 13 | Turn OFF the ignition. Disconnect the outside moisture sensor. Turn ON the ignition, with the engine OFF. Are the windshield wipers always ON? | Go to Step 14 | Go to Step 21 |
| 14 | Turn OFF the ignition. Disconnect the connector 1 of the BCM. Disconnect the windshield wiper switch signal 2 circuit from the BCM. Reconnect the connector 1 of the BCM. Turn ON the ignition, with the engine OFF. Is the windshield washer pump always ON? | Go to Step 15 | Go to Step 22 |
| 15 | Turn OFF the ignition. Repair the windshield wiper motor low speed control circuit for a short to ground. Refer to Wiring Repairs in Wiring Systems. Is the repair complete? | Go to Step 24 | |
| 16 | Inspect for poor connections at the windshield wiper motor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 17 |
| 17 | Replace the windshield wiper motor. Refer to Windshield Wiper Motor Replacement Is the repair complete? | Go to Step 24 | |
| 18 | Inspect for poor connections at the windshield wiper/washer switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 20 |
| 19 | Replace the windshield wiper/washer switch. Refer to Windshield Wiper and Washer Switch Replacement . Is the repair complete? | Go to Step 24 | |
| 20 | Inspect for poor connections at the outside moisture sensor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 21 |
| 21 | Replace the outside moisture sensor. Refer to Windshield Outside Moisture Sensor Replacement . Did you complete the replacement? | Go to Step 24 | |
| 22 | Inspect for poor connections at the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 24 | Go to Step 23 |
| 23 | Replace the BCM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement? | Go to Step 24 | |
| 24 | Reconnect all previous disconnected circuits or connectors. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Wipers Always On
Wipers Inoperative - All Modes
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: Windshield wipers are inoperative in all modes. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn the ignition ON. Attempt to operate the windshield wipers in all modes. Are the windshield wipers inoperative in all modes? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 3 | Turn the ignition OFF. Disconnect the wiper HI/LO relay. Connect a test lamp between the wiper HI/LO relay voltage supply circuit at the switch of the relay and a good ground. Turn the ignition ON, with the engine OFF. Turn the windshield wiper/washer switch to LOW/HIGH position. Does the test lamp illuminate? | Go to Step 11 | Go to Step 4 |
| 4 | Connect a test lamp between the wiper HI/LO relay voltage supply circuit at the coil of the relay and a good ground. Turn the ignition ON, with the engine OFF. Does the test lamp illuminate? | Go to Step 5 | Go to Step 10 |
| 5 | Turn the ignition OFF. Disconnect the wiper ON/OFF relay. Connect a test lamp between the wiper ON/OFF relay voltage supply circuit at the switch of the relay and a good ground. Turn the ignition ON, with the engine OFF. Does the test lamp illuminate? | Go to Step 6 | Go to Step 8 |
| 6 | Turn OFF the ignition. Test the supply voltage circuit between the wiper relays for an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 7 |
| 7 | Test the windshield wiper ON/OFF relay control circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 9 |
| 8 | Repair the voltage supply circuit to the switch of the wiper ON/OFF relay for a short to ground or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 14 | |
| 9 | Replace the wiper ON/OFF relay. Did you complete the replacement? | Go to Step 14 | |
| 10 | Repair the voltage supply circuit to the wiper relays coils for a short to ground or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 14 | |
| 11 | Turn the ignition OFF. Disconnect the windshield wiper motor. Test the ground circuit of the windshield wiper motor module for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 12 |
| 12 | Inspect for poor connections at the wiper motor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Go to Step 13 |
| 13 | Replace the wiper motor. Refer to Windshield Wiper Motor Replacement Is the repair complete? | Go to Step 14 | |
| 14 | Reconnect all previous disconnected components. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Wipers Inoperative - All Modes
Wipers Inoperative - One or More Modes
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: Windshield wipers are inoperative in one or more modes. | ||||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle | |
| 2 | Turn ON the ignition. Attempt to operate the windshield wipers in all modes. Do the windshield wipers operate normally in HIGH position? | Go to Step 3 | Go to Step 17 | |
| 3 | IMPORTANT: In the INT position the wipers operate only if the outside moisture sensor detects moisture on the windshield. Turn ON the ignition. Attempt to operate the windshield wipers in LOW, MIST, and INT modes. Do the windshield wipers operate normally in all positions? | Go to Step 5 | Go to Step 4 | |
| 4 | Did the windshield wipers operate in any of the above positions tested? | Go to Step 15 | Go to Step 8 | |
| 5 | Turn ON the ignition. Attempt to operate the windshield washer function. Do the windshield wipers operate normally for several cycles? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 6 | |
| 6 | Turn OFF the ignition. Disconnect the outside moisture sensor. Connect a test lamp between B+ and windshield washer switch signal at outside moisture sensor connector. Depress the wash button of the windshield wiper/washer switch. Does the test lamp illuminate? | Go to Step 28 | Go to Step 7 | |
| 7 | Repair the open in windshield washer switch signal circuit between the outside moisture sensor and underhood fuse block. Refer to Connector Repairs . Did you complete the repair? | Go to Step 30 | ||
| 8 | Turn OFF the ignition. Disconnect the WIPER ON/OFF relay. Connect a test lamp between the windshield wiper motor relay coil supply voltage circuit at the relay and B+. Turn ON the ignition. Turn the windshield wiper/washer switch to LOW position. Does the test lamp illuminate? | Go to Step 13 | Go to Step 9 | |
| 9 | Turn OFF the ignition. Disconnect the outside moisture sensor. Connect a test lamp between accessory voltage and ground circuit at outside moisture sensor connector. Turn ON the ignition. Does the test lamp illuminate? | Go to Step 10 | Go to Step 11 | |
| 10 | Turn OFF the ignition. Test the windshield wiper motor relay coil supply voltage circuit for an open. Refer to Circuit Testing and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 13 | |
| 11 | Turn OFF the ignition. Test the accessory voltage circuit for an open. Refer to Circuit Testing and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 12 | |
| 12 | Turn OFF the ignition. Test the ground circuit of the outside moisture sensor for an open. Refer to Circuit Testing and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 28 | |
| 13 | Turn OFF the ignition. Disconnect the windshield wiper motor. Connect a test lamp between the windshield wiper motor low speed control circuit of the windshield wiper motor connector and a good ground. Turn ON the ignition. Turn the windshield wiper/washer switch to LOW position. Does the test lamp illuminate? | Go to Step 23 | Go to Step 14 | |
| 14 | Turn OFF the ignition. Disconnect the WIPER HI/LO relay. Test the windshield wiper motor low speed control circuit for an open. Refer to Circuit Testing and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 25 | |
| 15 | Disconnect the outside moisture sensor. Disconnect the windshield wiper/washer switch. Test the windshield wiper switch low signal circuit for high resistance. Did you find and correct the condition? | Go to Step 30 | Go to Step 16 | |
| 16 | Test the resistance from the windshield wiper switch low signal circuit to the ground circuit in the windshield wiper/washer switch. Operate the windshield wiper/washer switch in all of the delay positions. Does the resistance remain within the specified values and decrease as the delay speed is increased? | 300ohms-4Kohms | Go to Step 28 | Go to Step 26 |
| 17 | Turn OFF the ignition. Disconnect the WIPER HI/LO relay. Connect a test lamp between the coil supply voltage circuit of the WIPER HI/LO relay and a good ground. Turn ON the ignition. Does the test lamp illuminate? | Go to Step 19 | Go to Step 18 | |
| 18 | Repair the coil supply voltage circuit of the WIPER HI/LO relay for an open. Did you complete the repair? | Go to Step 30 | ||
| 19 | Turn OFF the ignition. Connect a test lamp between the coil supply voltage circuit and the control circuit of the WIPER HI/LO relay. Turn ON the ignition. Turn the windshield wiper/washer switch to HIGH position. Does the test lamp illuminate? | Go to Step 21 | Go to Step 20 | |
| 20 | Turn OFF the ignition. Disconnect the windshield wiper/washer switch. Test the WIPER HI/LO relay control circuit for an open. Did you find and correct the condition? | Go to Step 30 | Go to Step 26 | |
| 21 | Turn OFF the ignition. Reconnect the WIPER HI/LO relay. Disconnect the windshield wiper motor. Connect a test lamp between windshield wiper motor high speed control circuit of the windshield wiper motor connector and a good ground. Turn ON the ignition. Turn the windshield wiper/washer circuit to HIGH position. Does the test lamp illuminate? | Go to Step 23 | Go to Step 22 | |
| 22 | Turn OFF the ignition. Test the windshield wiper motor high speed control circuit between WIPER HI/LO relay and windshield wiper motor for an open. Did you find and correct the condition? | Go to Step 30 | Go to Step 25 | |
| 23 | Inspect for poor connections at the windshield wiper motor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 24 | |
| 24 | Replace the windshield wiper motor. Refer to Windshield Wiper Motor Replacement . Is the repair complete? | Go to Step 30 | ||
| 25 | Replace the WIPER HI/LO relay. Refer to Relay Replacement (Within an Electrical Center) or Relay Replacement (Attached to Wire Harness) . Did you perform the replacement? | Go to Step 30 | ||
| 26 | Inspect for poor connections at the windshield wiper/washer switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 27 | |
| 27 | Replace the windshield wiper/washer switch. Refer to Windshield Wiper and Washer Switch Replacement . Did you perform the replacement? | Go to Step 30 | ||
| 28 | Inspect for poor connections at the outside moisture sensor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 30 | Go to Step 29 | |
| 29 | Replace the outside moisture sensor. Refer to Windshield Outside Moisture Sensor Replacement . Did you perform the replacement? | Go to Step 30 | ||
| 30 | Reconnect all previous disconnected components. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 | |
| IMPORTANT |
|---|
| In the INT position the wipers operate only if the outside moisture sensor detects moisture on the windshield. |
Wipers Inoperative - One or More Modes
Headlamp Washers Inoperative
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: The headlamp washers are inoperative. The windshield washers and headlamps operate normally. The LOW WASHER FLUID message is not displayed. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn ON the ignition, with the engine OFF. Turn the headlamps ON. Depress the windshield washer switch 4 times. Do the headlamp washers operate at the fourth press of the windshield washer switch? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Use the special function Headlamp Washer on the scan tool under Wipers/Washer Systems menu. Do the headlamp washers operate when the headlamp washer relay is commanded ON? | Go to Step 4 | Go to Step 5 |
| 4 | Turn OFF the ignition. Disconnect the body control module (BCM). Disconnect the W/S WASH relay. Test the windshield washer switch signal between BCM connector and W/S WASH relay for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 18 | Go to Step 16 |
| 5 | Turn the headlamps OFF. Turn OFF the ignition. Disconnect the headlamp washer relay. Connect a test lamp from the battery voltage circuit of the headlamp washer relay switched input to a good ground. Does the test lamp illuminate? | Go to Step 6 | Go to Step 9 |
| 6 | Connect a 30-amp fused jumper wire across the headlamp washer relay switched input and output. Turn the ignition ON, with the engine OFF. Turn the headlamps ON. Depress the windshield washer switch 4 times. Does the headlamp washer fluid pump operate? | Go to Step 10 | Go to Step 7 |
| 7 | Connect the headlamp washer relay. Disconnect the harness connector of the headlamp washer fluid pump. Connect a test lamp from the headlamp washer pump control circuit to the ground circuit of the headlamp washer fluid pump connector. Turn ON the ignition, with the engine OFF. Turn the headlamps ON. Depress the windshield washer switch 4 times. Does the test lamp illuminate? | Go to Step 12 | Go to Step 8 |
| 8 | Connect a test lamp from the headlamp washer pump control circuit of the headlamp washer pump to a good ground. Turn ON the ignition, with the engine OFF. Turn the headlamps ON. Depress the windshield washer switch 4 times. Does the test lamp illuminate? | Go to Step 15 | Go to Step 14 |
| 9 | Repair the battery voltage circuit of the headlamp washer relay switched input for an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 18 | |
| 10 | Inspect for poor connections at the headlamp washer relay. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 18 | Go to Step 11 |
| 11 | Replace the headlamp washer relay. Is the repair complete? | Go to Step 18 | |
| 12 | Inspect for poor connections at the headlamp washer fluid pump. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 18 | Go to Step 13 |
| 13 | Replace the headlamp washer fluid pump. Refer to Headlamp Washer Pump Replacement . Is the repair complete? | Go to Step 18 | |
| 14 | Repair an open or high resistance on the headlamp washer pump control circuit. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 18 | |
| 15 | Repair an open or high resistance on the windshield washer pump ground circuit. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 18 | |
| 16 | Inspect for poor connections at the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 18 | Go to Step 17 |
| 17 | Replace the BCM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement? | Go to Step 18 | |
| 18 | Reconnect all previous disconnected components. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 5 |
Headlamp Washers Inoperative
Headlamp Washers Always On
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Wiper/Washer Schematics Connector End View Reference: Wiper/Washer Connector End Views DEFINITION: The headlamp washers are always ON. The windshield washers operate normally. | |||
| 1 | Did you perform the diagnostic system check - vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn the ignition OFF. Are the headlamp washers always ON? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 3 | Disconnect the headlamp washer relay. Are the headlamp washers always ON? | Go to Step 4 | Go to Step 5 |
| 4 | Disconnect the headlamp washer fluid pump connector. Repair the headlamp washer pump control circuit for a short to B+. Did you complete the repair? | Go to Step 6 | |
| 5 | Replace the headlamp washer relay. Did you complete the replacement? | Go to Step 6 | |
| 6 | Reconnect all previous disconnected components. Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Headlamp Washers Always On
Wiper Arm Tip Pressure Check
- Remove the wiper blade from the arm. Refer to «Windshield Wiper Blade Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Attach a scale to the wiper arm tip and measure the force required to lift the wiper arm perpendicular to the windshield to the normal working height of the wiper arm (the height with the blade attached). The force required should be 9.8 newtons (35 ounces) for the driver side arm, and 7.8 newtons (28 ounces) for the passenger side.
- Replace the wiper arm if tip pressure is not within specifications. Refer to «Windshield Wiper Arm Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
Scheme 12
Remove the wiper blade from the arm. Refer to Windshield Wiper Blade Replacement .
Look down the length of the wiper blade element. The rubber part of the wiper blade element (2) that contacts the glass, must be on the center line of the wiper blade, plus or minus 15 degrees (1).
Removal Procedure
- Open the hood.
- Remove the plastic retainer (1) from the upper neck of the washer solvent container filler tube (2). The filler is located next to the master cylinder.
- Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) . IMPORTANT: Ensure that the hoist is clear of the left front fender, to allow the lower fender to be moved away from the chassis for clearance.
- Remove the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Remove the left front, lower wheelhouse splash shield fasteners (1, 2, 3). Note the position of the fender for installation alignment.
- Disconnect the output hose (4) from the washer pump. Drain the contents into a suitable container.
- Disconnect the headlamp washer output hose (1) by sliding the lock (5) and pulling off the hose.
- Disconnect the electrical connectors (3) from both washer pumps, and the level sensor.
- Remove the washer solvent container mounting bolts (1, 2).
- Remove the washer solvent container. Hold the fender away for clearance.
Installation Procedure
- Transfer washer pumps and level sensor to replacement container.
- Place the washer solvent container into mounting position.
- Install the washer solvent container mounting bolts (2). Tighten: Tighten the screws to 11 N.m (97 lb in).
- Connect the electrical connectors (3) to the washer pumps, and to the level sensor.
- Connect the washer pump output hose (4) to the pump.
- Connect the headlamp washer output hose (1) to the washer pump. Seat the slide-lock (5) hose clamp.
- Align the fender, and install the left front lower wheelhouse splash shield, and fasteners (1, 2, 3).
- Install the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Lower the vehicle.
- Install a new plastic retainer onto the washer solvent container fill tube.
- Refill the washer solvent container. Inspect the operation of the headlamp washer pump Inspect the operation of the windshield washer pump Inspect the operation of the level sensor and warning lamp
- Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) . IMPORTANT: Ensure that the hoist is clear of the left front fender to allow the lower fender to be moved away for access to the washer container.
- Remove the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Remove the left front lower wheelhouse splash shield fasteners (1, 2, 3) at the rear of the wheelhouse.
- Remove the shield.
- Disconnect the output hose (4) from the washer pump. Drain the contents into a suitable container.
- Disconnect the electrical connector from the level sensor (2).
- Remove the washer solvent container level sensor (2) by twisting the sensor out of the washer solvent container.
- Install the level sensor rubber grommet into the washer solvent container.
- Lubricate the sensor body and grommet with washer fluid, to aid in installation.
- Twist and insert the sensor body through the grommet until the sensor is seated as originally positioned.
- Connect the electrical connector (3) to the level sensor (2).
- Align and install the left front lower wheelhouse (1, 2, 3) splash shield.
- Install the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Lower the vehicle.
- Refill the washer solvent container.
- Inspect the operation of the pumps and the level sensor for leaks.
- Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) . IMPORTANT: Ensure that the hoist is clear of the left front fender, to allow the lower fender to be moved away from the body for clearance.
- Remove the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Remove the left front lower wheelhouse splash shield fasteners (1, 2, 3) at the rear of the wheelhouse.
- Disconnect the output hose (4) from the washer pump, and drain the contents into a suitable container.
- Disconnect the electrical connector (3) from the washer pump.
- Remove the washer pump by twisting the pump out of the washer solvent container.
- Install the washer pump rubber grommet into the washer solvent container.
- Lubricate the pump body and grommet with washer fluid to aid in installation.
- Insert the pump body through the grommet until the pump is seated as originally positioned.
- Connect the electrical connector (3) to the washer pump.
- Connect the washer pump output hose (4) to the washer pump.
- Lower the vehicle.
- Refill the washer solvent container.
- Inspect the operation of the pumps and level sensor, also for leaks.
- Align the fender to the body, and install the left front lower wheelhouse splash shield and fasteners (1, 2, 3).
- Install the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) . IMPORTANT: Ensure that the hoist is clear of the left front fender, to allow the lower fender to be moved away from the body for clearance.
- Remove the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Remove the left front lower wheelhouse splash shield fasteners (1, 2, 3) from the rear of the wheelhouse. Note the position of the fender for installation alignment.
- Disconnect the output hose (4) from the lower mounted windshield washer pump. Drain the contents into a suitable container.
- Disconnect the headlamp washer pump output hose (1) by disengaging the slide lock (5), and pulling the hose off.
- Disconnect the electrical connector from the headlamp washer pump.
- Twist the washer pump out of the washer solvent container, and remove.
- Dampen the headlamp washer pump body rubber grommet.
- Insert the pump through the grommet until the pump is seated as originally oriented.
- Connect the electrical connector to the headlamp washer pump.
- Connect the headlamp washer pump output (1) hose to the pump. Secure the sliding lock (5).
- Connect the output hose (4) from the lower mounted windshield washer pump.
- Lower the vehicle.
- Refill the washer solvent container.
- Inspect the operation of the washer pumps and the level sensor, and for leaks.
- Align the fender, and install the fasteners (1, 2, 3) to the left front lower wheelhouse splash shield.
- Install the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Remove the fasteners (1, 3) and push-pins (2) from the forward wheelhouse splash shield (4) to access the underside of the bumper cover.
- Slide the hose lock connector (4) at the headlamp washer (2). Disconnect the hose.
- Remove the retaining clip (3) from the headlamp washer.
- Remove the headlamp washer (2) from the topside of the bumper cover (1).
- Install the headlamp washer to the topside of the bumper cover.
- Install the retaining clip (3) to the headlamp washer (2) at the underside of the bumper cover (1).
- Connect the hose to the headlamp washer. Slide the lock connector (4) to the closed position.
- Install the wheelhouse splash shield (4) and fasteners (1, 2, 3) to the forward part of the wheelhouse. Tighten: Tighten the threaded fasteners to 2 N.m (18 lb in).
- Inspect the washer for leaks. Verify the operation of the washer.
Scheme 13
| IMPORTANT | The headlamp washer hose consists of multiple sections (4), and slide-lock connectors (5), from the pump to the headlamp washers (1). It may be necessary to work underhood, or inside the front fascia to service the Tee fitting (3), and hose clips (2). If it is necessary to access the washer solvent container hose, refer to Headlamp Washer Pump Replacement . |
- Remove the forward wheelhouse fasteners (1, 2, 3) and the splash shield (4) to access the underside of the bumper cover.
- Slide the hose lock connector (4) at the headlamp washer supply hose, and disconnect the coupling.
- Connect the headlamp washer supply hose to the headlamp washer. Slide the lock connector (4) to the closed position.
- Verify the operation of the washer. Inspect the washer for leaks.
- Install the wheelhouse splash shield (4) and fasteners (1, 2, 3) to the forward part of the wheelhouse. Tighten: Tighten the threaded fasteners to 2 N.m (18 lb in).
- Open the hood.
- Disconnect the washer pump hose (5) from the driver side air inlet grille.
- Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) . IMPORTANT: Ensure that the hoist is clear of the left front fender, to allow the lower fender to be moved away from the body for clearance.
- Remove the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Remove the left front lower wheelhouse splash shield fasteners (1, 2, 3) at the rear of the wheelhouse.
- Disconnect the washer pump output hose (4) by twisting the hose away from the washer pump.
- Connect the washer pump outlet hose (4) to the pump (3).
- Lower the vehicle.
- Connect the upper washer hose connection (5)at the air inlet grille.
- Inspect the operation of the pumps and the level sensor, and for leaks.
- Align the lower fender to the body, and install the lower wheelhouse splash shield and fasteners (1, 2, 3).
- Install the left front wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/xlr/i-2003-2009/remont/wheel-tire-system/#tires-and-wheels) .
- Open the hood.
- Turn the ignition switch to the ACCY position.
- Turn the wiper switch to the DELAY position.
- Turn the ignition switch OFF when the wiper arms are in the mid-wipe position.
- Place a piece of masking tape (5) onto the windshield at the tip of each wiper blade (6) to aid in the wiper arm reinstallation.
- Disconnect the washer hose (3) from the air inlet grille panel.
- Remove the wiper arm nut cover (1).
- Remove the wiper arm nut (2).
- Firmly grasp the wiper arm at the hinged joint. Apply a rocking motion toward the windshield to loosen the arm from the wiper shaft (4).
- Remove the wiper arm.
- Remove the wiper blade (6) from the wiper arm. Refer to «Windshield Wiper Blade Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Install the wiper blade (6) onto the wiper arm. Refer to «Windshield Wiper Blade Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Inspect the wiper transmission shaft (4) and wiper arm splines for corrosion, clean if necessary.
- Position the tip of the wiper blade (6) to the marks made on the windshield with masking tape (5).
- Install the wiper arm onto the wiper transmission (4) splined shaft.
- Install the wiper arm nut (2). Tighten: Tighten the nut (2) to 29 N.m (21 lb ft).
- Install the wiper arm nut cover (1).
- Connect the washer hose (3) to the air inlet grille panel.
- Remove the masking tape (5) from the windshield.
- Inspect the wipers for proper operation.
- Turn the ignition switch to the ACCY position.
- Turn the wiper switch to the DELAY position.
- Turn the ignition OFF when the wipers are in the mid-wipe position.
- Pull up on the wiper blade release tang, and slide the wiper blade out from the inside radius of the wiper arm.
- Remove the wiper blade from the wiper arm, by guiding it out through the opening in the blade.
- Install the hook of the wiper arm through the opening in the wiper blade.
- Position the wiper blade pivot into the inside radius of the wiper arm hook.
- Press the wiper blade pivot into the wiper arm hook until the pivot locks into the wiper arm.
- Inspect the wipers for proper operation.
- Remove the wiper blade from the wiper arm. Refer to «Windshield Wiper Blade Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- The wiper blade element (4) has two notches at one end which are engaged by the bottom claw set (3) of the wiper blade (1). At the notched end of the wiper blade (2), pull the blade element from the wiper blade (1).
Scheme 14
| IMPORTANT | The replacement blade elements (4) have tape retaining the metal flexor strips. Remove the tape when the element is installed. |
- Starting at the heel end of the wiper blade slide the wiper blade element, notched end last, into the wiper blade claw sets (1).
- Ensure that the 2 element notches are engaged by the last claw set, and that all the other claws, (2) and (3), are properly engaged in the slots of the element (1) on both sides.
- Install the wiper blade onto the wiper arm. Refer to «Windshield Wiper Blade Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
Wiper Motor Cover Replacement
| IMPORTANT | The wiper motor cover is not serviced separately from the wiper motor. |
Refer to Windshield Wiper Motor Replacement .
Tools Required
- J 39232 Wiper Linkage Separator
- J 39529 Wiper Linkage Installer
- Remove the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Using the J 39232 , disconnect the wiper transmission from the wiper motor crank arm to aid in the removal of the wiper drive system module.
- Remove the wiper drive system module screws (1).
- Remove the wiper drive system module from the plenum to gain access to the wiper motor electrical connector.
- Disconnect the wiper motor electrical connector.
- Remove the wiper drive system module from the vehicle.
- Position the wiper drive system module to the vehicle.
- Connect the wiper motor electrical connector.
- Install the wiper drive system module into the plenum.
- Install the wiper drive system module screws (1). Tighten: Tighten the screws to 8 N.m (71 lb in).
- Using the J 39529 , connect the wiper transmission to the wiper motor crank arm.
- Install the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Inspect the wipers for proper operation.
- Remove the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Remove the wiper drive system module. Refer to «Wiper Drive System Module Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Remove the wiper motor crank arm. Refer to «Wiper Motor Crank Arm Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__wiper-motor-crank-arm-replacement) .
- Remove the wiper motor mounting screws.
- Remove the wiper motor from the wiper motor module.
- Position the wiper motor to the wiper motor module.
- Install the wiper motor screws. Tighten: Tighten the screws to 10 N.m (89 lb in).
- Install the wiper motor crank arm. Refer to «Wiper Motor Crank Arm Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__wiper-motor-crank-arm-replacement) .
- Install the wiper drive system module. Refer to «Wiper Drive System Module Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Install the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Inspect the wipers for proper operation.
Windshield Wiper Transmission Replacement
Tools Required
- J 39232 Wiper Linkage Separator
- J 39529 Wiper Linkage Installer
- Remove the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Remove the wiper drive system module. Refer to «Wiper Drive System Module Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Using the J 39232 , disconnect the wiper transmission from the wiper motor crank arm.
- Remove the wiper transmission screws.
- Remove the wiper transmission from the wiper motor module assembly.
- Position the wiper transmission to the wiper motor module assembly.
- Install the wiper transmission screws. Tighten: Tighten the screws to 10 N.m (89 lb in).
- Using the J 39529 , connect the wiper transmission to the wiper motor crank arm.
- Install the wiper drive system module. Refer to «Wiper Drive System Module Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
- Install the air inlet grille panel. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
- Install the wiper arms. Refer to «Windshield Wiper Arm Replacement»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
Wiper Motor Crank Arm Replacement
| IMPORTANT | The wiper motor crank arm is not serviced separately from the wiper motor. |
Refer to Windshield Wiper Motor Replacement .
| IMPORTANT | The windshield outside moisture sensor coupler is permanently mounted to the windshield and is not serviceable. Damage to the windshield or the windshield outside moisture sensor coupler will occur, if removed. |
- Remove the trim cover from the windshield outside moisture sensor.
- Release the windshield outside moisture sensor coupler retaining clips.
- Remove the windshield outside moisture sensor from the windshield coupler.
- Disconnect the windshield outside moisture sensor electrical connector.
- Connect the windshield outside moisture sensor electrical connector.
- Position the windshield outside moisture sensor to the windshield coupler.
- Fasten the windshield coupler retainer clips.
- Position the trim cover to the windshield outside moisture sensor.
- Press the trim cover inward to secure the trim cover to the windshield outside moisture sensor.
Wiper Chatter Repair
Some vehicles may exhibit a condition where the windshield wiper blades chatter or wipe unevenly. Several different conditions can cause wiper blade chatter. To completely repair wiper blade chatter, all of the following should be checked and repaired as necessary.
- The windshield must be clean. Refer to «Windshield Glass Cleaning»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__windshield-glass-cleaning) .
- The wiper blade element must be clean. Refer to «Blade Element Cleaning»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__blade-element-cleaning) .
- The wiper arm tip pressure must be within specifications. Refer to «Wiper Arm Tip Pressure Check»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system__wiper-arm-tip-pressure-check) .
- The wiper blade element set must be within specifications. Refer to «Wiper Blade Element Check»(/cadillac/xlr/i-2003-2009/remont/wiperwasher-systems/#wiper-system-washer-system) .
Windshield Glass Cleaning
Clean the windshield with windshield cleaner, GM P/N 1050011 (Canadian P/N 992727) or equivalent. The cleaner should not harm the paint finish or scratch the glass. The glass is clean when the water no longer beads, but sheets across the entire glass surface.
Blade Element Cleaning
- Lift the blade off the windshield.
- Clean the element with a cloth saturated in full strength washer solvent.
- Rinse the blade with water.
- Lower the blade to the windshield.
- Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/xlr/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
- Remove the steering column bracket. Refer to «Steering Column Bracket Replacement»(/cadillac/xlr/i-2003-2009/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) in Instrument Panel, Gages, and Console.
- Remove the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/xlr/i-2003-2009/remont/steering-column-switches/#steering-wheel-steering-column) in Steering Wheel and Column.
- Remove the wire harness assembly from the wire restraint clips (1).
- Disconnect the wire connector.
- Disconnect the windshield wiper and washer switch assembly.
- Remove the switch assembly in the following manner. Press on the locking tabs of the switch assembly. Pull the switch assembly out of the switch mounting bracket.
- Remove the 2 pan head tapping screws (1).
- Remove the switch mounting bracket (2).
- Remove the turn signal cancel cam and steering shaft upper bearing spring. Refer to «Turn Signal Cancel Cam and Steering Shaft Upper Bearing Spring Replacement»(/cadillac/xlr/i-2003-2009/remont/steering-column-switches/#steering-wheel-steering-column) .
- Remove the turn signal and multifunction switch assembly only. Refer to «Turn Signal Multifunction Switch Replacement»(/cadillac/xlr/i-2003-2009/remont/steering-column-switches/#steering-wheel-steering-column) .
- Slide the switch mounting bracket off of the steering column shaft assembly.
- Install the side mounted switch mounting bracket (2) to the steering column tilt head assembly. If not a side mounted bracket go to step 3.
- Install the 2 pan head tapping screws (1). Tighten: Tighten the screws to 7 N.m (62 lb in).
- To install the windshield washer and wiper switch assembly go to step 7.
- Slide the switch mounting bracket onto the steering column shaft assembly.
- Install the turn signal and multifunction switch assembly only. Refer to «Turn Signal Multifunction Switch Replacement»(/cadillac/xlr/i-2003-2009/remont/steering-column-switches/#steering-wheel-steering-column) .
- Install the turn signal cancel cam and steering shaft upper bearing spring. Refer to «Turn Signal Cancel Cam and Steering Shaft Upper Bearing Spring Replacement»(/cadillac/xlr/i-2003-2009/remont/steering-column-switches/#steering-wheel-steering-column) .
- If necessary, install the switch assembly into the switch mounting bracket so that the locking tabs snap into place.
- Connect the wire harness assembly.
- Install new wire harness straps.
- Install the wire harness assembly into the wire restraint clips (1).
- Install the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/xlr/i-2003-2009/remont/steering-column-switches/#steering-wheel-steering-column) in Steering Wheel and Column.
- Install the steering column bracket. Refer to «Steering Column Bracket Replacement»(/cadillac/xlr/i-2003-2009/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) in Instrument Panel, Gages, and Console.
- Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/xlr/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
Windshield Wiper/Washer System Components
The windshield wiper/washer system consists of the following components
- Outside moisture sensor
- Windshield wiper/washer switch
- Windshield wiper motor
- Windshield washer fluid pump
- Windshield washer fluid level switch
- Washer fluid pump relay
- Wiper RUN/ACC relay
- Wiper ON/OFF relay
- Wiper HI/LO relay
- Wiper 30A fuse
- W/S WASH 15A fuse
- RUN/ACCESSORY power 10A fuse
Windshield Wiper/Washer System Operation
The outside moisture sensor controls wiper motor operation for all low speed modes. The high speed mode maybe controlled by the both windshield wiper/washer switch and the outside moisture sensor. The windshield wiper motor is a 2 speed motor and is operated at low speed in all modes except HIGH. The accessory voltage supply circuit to the outside moisture sensor provides the power for controlling the wiper motor. The MIST, LOW, and DELAY modes are controlled by the windshield wiper/washer switch through a series of internal resistors, and the switch position determines the point on the resistor assembly where the reference voltage is applied. For these modes, the windshield wiper switch signal circuit supplies the signal from the switch assembly to the outside moisture sensor which determines the operating mode. Windshield wiper motor high speed operation is controlled by the windshield wiper/washer switch and the outside moisture sensor through the windshield wiper switch high speed signal circuit. The low speed modes energize the wiper ON/OFF relay and the voltage is supplied through the wiper HI/LO relay to the windshield wiper motor. At HIGH position the wiper HI/LO is energized and supplies voltage to the high speed circuit of the windshield wiper motor.
The windshield washer fluid pump is controlled by the windshield wiper/washer switch through the windshield washer fluid pump relay. The windshield washer fluid pump relay coil and switch are supplied battery positive voltage, and during the windshield window wash modes the windshield wiper/washer switch grounds the washer fluid pump relay control circuit energizing the relay. During the windshield washer operation the switch signals the outside moisture sensor also, to provide low speed wipers operation.
The outside moisture sensor provides automatic operation for low and high speed when the windshield wiper/washer switch is in DELAY position. The outside moisture sensor is an electronic module that uses infrared radiation to determine the level of windshield visibility for the driver, and commands the wiper motor/controller assembly to drive the wipers to maintain a pre-selected level of visibility.
Windshield Wiper/Washer Signals to the BCM
The BCM receive two signals indicating the operation of windshield wipers and washer. The windshield wiper switch signal 2 circuit is used by the BCM to turn ON the headlamps. The windshield washer switch signal is used by BCM to control the headlamp washers.
Low Washer Fluid Message
The Low Washer Fluid message is controlled by the instrument panel cluster using an input from the windshield washer fluid level switch. The windshield washer fluid level signal circuit is supplied ignition voltage through a resistor then monitored within the instrument cluster. The windshield washer fluid level switch is normally open so the instrument cluster detects ignition voltage on the windshield washer fluid level signal circuit whenever the washer fluid level is not low. When the washer fluid reaches the point where the driver should be informed that the washer fluid is low, the windshield washer fluid level switch closes. When the windshield washer fluid level switch is closed the windshield washer fluid level signal circuit voltage is pulled low, and the instrument panel displays the Low Washer Fluid message on the driver information center. In order to prevent the Low Washer Fluid message from being displayed while sloshing is occurring in the washer fluid container, the instrument cluster is programed with a 1 minute delay before displaying the Low Washer Fluid message during an ignition cycle.
Headlamp Washer System Components
The headlamp washer system consists of the following components
- Headlamp washer relay
- Headlamp washer fluid pump
- HDLP WASH 20A fuse
- Windshield wiper/washer switch
- BCM
Headlamp Washer System Operation
Battery voltage is supplied to the headlamp washer relay switched input. The BCM controls the operation of the headlamp washer relay. The headlamps need to be in ON position to allow the headlamp washer operation. At every fourth operation of the windshield washer a headlamp wash cycle is initiated. A headlamp wash cycle consists of a prewash, then a pause, and then a wash operation.
Special Tools
Special Tools Illustration Tool Number/ Description J 39232 Wiper Transmission Separator J 39529 Wiper Linkage Installer
Scheme 15
Scheme 16
See also:
• Diagnostic System Check - Vehicle
• Testing for Intermittent Conditions and Poor Connections
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Control Module References
• Checking Aftermarket Accessories
• Relay Replacement (Within an Electrical Center)
• Lifting and Jacking the Vehicle
• Tire and Wheel Removal and Installation
• Fastener Notice
• Air Inlet Grille Panel Replacement
• SIR Caution
• SIR Disabling and Enabling
• Steering Column Bracket Replacement
• Steering Column Trim Covers Replacement
• Wiper/Washer Schematics
• Low Washer Fluid Indicator Malfunction
• Washers Always On
• Washers Inoperative
• Wipers Always On
• Wipers Inoperative - All Modes
• Wipers Inoperative - One or More Modes
• Headlamp Washers Inoperative
• Headlamp Washers Always On
• Wiper Motor Crank Arm Replacement
• Windshield Glass Cleaning
• Blade Element Cleaning
• Wiper Arm Tip Pressure Check
