Object Detection System Cadillac XLR I

Fastener Tightening Specifications

Fastener Tightening Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Object Detection Connector End Views

Object Sensor - LR Corner

Object Sensor - LR Middle

Object Detection Connector End Views

Object Sensor - LR Middle

Object Sensor - RR Corner

Object Detection Connector End Views

Object Sensor - RR Corner

Object Sensor - RR Middle

Object Detection Connector End Views

Object Sensor - RR Middle

Scheme 7

Object Detection Connector End Views

Rear Object Sensor Control Module

Scheme 8

Object Detection Connector End Views

Rear Parking Assist (RPA) Diagnostic Connector

Scheme 9

Object Detection Connector End Views

Rear Parking Assist (RPA) Display

Diagnostic Starting Point - Object Detection

Begin the system diagnosis by reviewing the system Description and Operation, refer to Object Detection Description and Operation . Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Object Detection in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Diagnostic Trouble Code (DTC) Displaying

This vehicle is equipped with an on-board diagnostic display feature capable of displaying DTCs using the 3 indicators on the rear parking assist display. After the bulb check has been completed, the red outside indicator flashes to indicate a malfunction with the system. The module disables operation of the ultrasonic rear parking assist (URPA) system under this condition.

In order to enter the diagnostic mode, complete the following actions

1. With the ignition turned OFF, short the rear parking assist diagnostic connector to ground while the vehicle is in PARK. Refer to «Object Detection Component Views»(/cadillac/xlr/i-2003-2009/remont/collisionavoidance/#object-detection-system) for the location of the rear parking assist diagnostic connector.
2. Turn the ignition ON.
3. Place your foot on the brake.
4. Shift the vehicle into REVERSE within 5 seconds. If the vehicle is not shifted into reverse within 5 seconds after turning the ignition ON, the diagnostic mode will still be initiated. However, a reverse input wiring fault will be registered as sequence #7 as shown in the Diagnostic Indicator table below. Refer to «Diagnostic Trouble Code (DTC) Clearing»(/cadillac/xlr/i-2003-2009/remont/collisionavoidance/#object-detection-system__diagnostic-trouble-code-dtc-clearing) for specific steps on how to clear DTCs. After the reverse input wiring code is cleared, repeat the DTC displaying steps in order to enter the diagnostic mode.

When the diagnostic mode is first entered, the rear parking assist display displays the amber outside indicator and the red outside indicator. Then the indicators on the rear parking assist display will display one or more of the sequences in the table below to indicate where the fault exists within the rear parking assist system. Refer to Diagnostic Trouble Code (DTC) Clearing for the specific steps on how to clear diagnostic trouble codes.

Diagnostic Indicators

Diagnostic Trouble Code (DTC) Clearing

The rear parking assist diagnostic sequences may be cleared in one of the following ways

Vehicle Moving

1. Drive the vehicle forward at least 24 km/h (15 mph).
2. Stop the vehicle.
3. Turn the ignition OFF.

Vehicle Stopped

1. Turn the ignition ON.
2. Place foot on the brake.
3. Shift the vehicle into REVERSE within five seconds.
4. Turn the ignition OFF.

Symptoms - Object Detection

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the system. Refer to «Checking Aftermarket Accessories»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
3. Make sure the rear parking assist sensors located on the vehicle rear bumper are clear. Remove any snow, mud or ice that is blocking the sensors.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Rear Parking Assist Malfunction»(/cadillac/xlr/i-2003-2009/remont/collisionavoidance/#object-detection-system)
2. «Rear Parking Assist Inoperative - Red Indicator Flashes»(/cadillac/xlr/i-2003-2009/remont/collisionavoidance/#object-detection-system__rear-parking-assist-inoperative-red)

Diagnostic Aids

Before performing this procedure, ensure that the vehicle park brake is SET.

Rear Parking Assist Malfunction

Rear Parking Assist Inoperative - Red Indicator Flashes

Rear Parking Assist Inoperative - Red Indicator Flashes

Removal Procedure

1. Use a flat-bladed tool to remove the bezel and the telltale from the rear window trim panel.
2. Remove the bezel from the telltale.
3. Disconnect the electrical connector.
4. Remove the telltale.

Installation Procedure

1. Connect the electrical connector to the telltale.
2. Install the bezel to the telltale.
3. Install the bezel and the telltale to the rear window trim panel.

1. Remove the rear fascia. Refer to «Rear Bumper Fascia Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#bumper-system) .
2. Disconnect the electrical connector (1) from the rear object sensor.
3. Release the locking tabs (1) attaching the sensor to the sensor housing.
4. Remove the rear object sensor (1) from the sensor housing.
5. Remove the rear object sensor retainer ring (1) from the sensor.

1. Paint the new rear object sensor. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/xlr/i-2003-2009/remont/paintcoatings/#paintcoatings__basecoatclearcoat-paint-systems) .
2. Ensure the paint thickness does not exceed 6 mils. Use a paint thickness gage suitable for non-ferrous metals. Refer to «Paint Gages»(/cadillac/xlr/i-2003-2009/remont/paintcoatings/#paintcoatings__paint-gages) .
3. Install the sensor retainer ring (1) to the sensor.
4. Position the sensor (1) to the sensor housing.
5. Install the sensor to the sensor housing until the sensor (1) is fully seated.
6. Connect the electrical connector (1) to the sensor.
7. Install the rear fascia. Refer to «Rear Bumper Fascia Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#bumper-system) .

The housings are adhesively retained to the backside of the fascia and must be removed prior to paint refinish operations every time the fascia is refinished due to paint bridging concerns. Adhesive tape cannot be removed and re-used with retention confidence. Thus the rear object sensor housing is considered a onetime use application, requiring that all 4 housings be replaced every time the fascia is refinished.

1. Remove the rear fascia. Refer to «Rear Bumper Fascia Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#bumper-system) .
2. Remove the rear object sensor. Refer to «Rear Object Sensor Replacement»(/cadillac/xlr/i-2003-2009/remont/collisionavoidance/#object-detection-system) .
3. Remove the sensor housing (1) from the fascia.
4. Remove all remaining adhesive.

1. Clean the sensor housing mating surface of the fascia with a lint-free rag using a naptha solvent or equivalent.
2. Mating surface must be dry before applying adhesion promoter.
3. Apply adhesion promoter 3M Products P/N 06396 or equivalent to the sensor housing mating surface (1) of the fascia.
4. Remove the protective paper backing from the sensor housing.
5. Position the sensor housing (1) to the fascia.
6. Press firmly to secure the sensor housing to the fascia.
7. Install the rear object sensor. Refer to «Rear Object Sensor Replacement»(/cadillac/xlr/i-2003-2009/remont/collisionavoidance/#object-detection-system) .
8. Install the rear fascia. Refer to «Rear Bumper Fascia Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#bumper-system) .

1. Remove the trim assembly from the rear compartment panel stowage. Refer to «Body Rear Compartment Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the nuts from the rear object alarm detection module.
3. Disconnect the electrical connector.
4. Remove the module.

1. Connect the electrical connector.
2. Align the module to the bracket.
3. Install the nuts to the rear object alarm detection module. Tighten: Tighten the nuts to 10 N.m (89 lb in).
4. Install the trim assembly to the rear compartment panel stowage. Refer to «Body Rear Compartment Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .

Object Detection Description and Operation

The object alarm system monitors the distance and how close a vehicle is to an object when backing up in a parking maneuver. The object alarm system will notify the driver of any objects of interest when backing up at speeds less than 5 km/h (3 mph). The distance between a vehicle and an object of interest is monitored by the 4 ultrasonic sensors located in the rear bumpers of the vehicle. The object sensors receive the echo signals reflected off an object of interest while the vehicle is backing up at speeds less than 5 km/h (3 mph). The rear object sensor control module receives the vehicle speed input from the ECM via the vehicle speed signal circuit. When the backing up speed exceeds 5 km/h (3 mph), the rear parking aid (RPA) system is disabled. The object detection system uses visual displays and audible warnings from the radio speakers to warn the driver of an object of interest within the defined field of view. The BCM controls the RPA chime function via the chime control circuit and will send serial data request to the radio to sound the chime as needed. The visual RPA display comprises of two amber and one red indicators and these indicators illuminate based on the vehicle distance to the object of interest. When the RPA system is activated the RPA display first performs a bulb check before any normal operation. The object sensor is a three wire sensor comprising of the supply voltage circuit, signal circuit and the low reference circuit. Power and ground is provided to the object sensors from the rear object sensor control module via the object sensor supply voltage circuit and low reference circuit. The typical object sensor signal circuit voltage when the system is active is between 7.2 V-9.2 V. The object detection system is initiated when the rear object sensor control module receives the transmission reverse input from the BCM via the backup lamp supply voltage circuit.

When the ignition is ON and the vehicle is placed into reverse, the URPA performs a bulb check. During the bulb check, the 3 indicators on the display illuminate for approximately 2 seconds to indicate that the system is working. The URPA performs a bulb check and operates when the following conditions are present

1. The ignition is ON.
2. The vehicle is placed in REVERSE (R).
3. The vehicle speed is less than 5 km/h (3 mph). At speeds greater than 5 km/h (3 mph), the URPA is disable. The red indicator flashes to warn the driver that the URPA is disabled.

The URPA senses how close the vehicle is to an object. The distance is determined by the 4 ultrasonic sensors located on the rear bumper. When the system detects an object, one of the following will occur

1. If the object is less than 0.3 m (11 in) away from the rear of the vehicle, the amber outside, amber middle, and the red outside indicators flash and the chime sounds continuously.
2. If the object is less than 0.3-0.5 m (11-20 in) away from the rear of the vehicle, the amber outside, amber middle, and the red outside indicators are on and the chime sounds continuously.
3. If the object is 0.5-1.0 m (20-40 in) away from the rear of the vehicle, the amber outside, and the amber middle indicators are on.
4. If the object is 1.0-1.5 m (40-60 in) away from the rear of the vehicle, the amber outside indicator is on and the chime sounds one time on the first detection of an object.

The URPA can detect objects 7.6 cm (3 in) wide and at least 25.4 cm (10 in) tall. It cannot detect objects above the level of the roof.

If the red indicator flashes continuously, the on-board diagnostic needs to be entered to determine if a malfunction is present. Refer to Diagnostic Trouble Code (DTC) Displaying .
