Garage Door Opener Cadillac XLR I

Scheme 1

Scheme 2

Scheme 3

Garage Door Opener Connector End Views

Vanity Mirror Lamp - Left

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure to use when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Verify with the customer that they attempted programming with the key in the ON position or with the vehicle running (Buick LaCrosse/Allure). Verify with the customer that they have attempted to program for rolling code. Verify with the customer that they have referred to the owners manual and have contacted the HomeLink toll free assistance line. Refer to Symptoms - Garage Door Opener in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Visual/Physical Inspection

1. Turn the ignition key to the ON position and press any garage door opener (GDO) button. The LED should light when the unit has power and is functional.
2. Inspect for aftermarket devices which could affect the operation of the GDO. Refer to «Checking Aftermarket Accessories»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) in Wiring Systems.
3. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to Garage Door Opener Inoperative in order to diagnose the symptom.

Garage Door Opener Inoperative

The universal garage door opener (UGDA) is serviced as part of the driver sunshade. Refer to Sunshade Replacement .

Refer to Control Module References for programming and setup information.

The GDO is programmed by using the customer's hand-held transmitter(s).

Turn the ignition OFF while programming the GDO transmitter. Follow these steps to program up to 3 channels

1. If you have previously programmed a transmitter, proceed to Step 2. Otherwise, hold down the 2 outside buttons on the GDO transmitter for approximately 20 seconds, until the light on the GDO transmitter begins to flash rapidly. Then release the buttons. This procedure erases any previous settings and initializes the memory for all 3 channels.
2. Decide which of the 3 channels you want to program to the transmitter you have.
3. Hold the end of the hand-held transmitter against the front surface of the GDO (less than 1 inch) so you can still see the light.
4. Using both hands, press the hand-held transmitter button and the desired button on the GDO transmitter. Continue to hold both buttons through Step 5.
5. Hold down the buttons on both transmitters until you see the light on the GDO transmitter flash slowly and then rapidly. The rapid flashing, which could take up to 90 seconds, indicates that the GDO transmitter has been programmed. Release the buttons on both transmitters when the light starts to flash rapidly.

Training the GDO for Rolling Code Receivers

This procedure is for training the customer's rolling code garage door openers to their GDO transmitter. The GDO must already be programmed to its hand-held transmitter. The training process below must be completed within 30 seconds or it must be repeated.

1. Locate the train button on the garage door opener receiver. Refer to the operator's manual for the garage door opener (or call HomeLink™ at 1-800-355-3515 for assistance). Follow instructions for the garage door opener in order to determine when the unit is in train mode.
2. Return to the GDO transmitter in the vehicle, and press the button that you want trained for rolling codes 3 times, for 1 second each time. If not successfully programmed, try 2-5 seconds each time.
3. Press the button used again in order to verify that the GDO transmitter has been programmed.

You may use either the hand-held transmitter or the GDO to open the garage door.

The GDO is compatible with most, but not all, types and brands of transmitters. If the GDO light does not flash rapidly after 90 seconds, there may be a compatibility conflict with the transmitter used to program the GDO. Call HomeLink™ at 1-800-355-3515 in order to address compatibility concerns.

Erasing Channels

To erase programmed channels, hold down the 2 outside buttons until the light on the GDO transmitter begins to flash. Individual channels cannot be erased, but can be reprogrammed using the Garage Door Opener Programming and the Training GDO for Rolling Code Receivers procedures.

Non-Compatible Garage Door Openers

The garage door opener (GDO) is located in the overhead console or drivers side sunshade. If battery voltage is lost due to a condition such as a dead battery, the GDO unit relies on the non-serviceable internal power backup supply. The unit is programmed using the customer's hand-held transmitters for the garage doors, electric entrance gates, or lighting and security systems.

The GDO is rolling code capable. Rolling code is a system that allows the code that the customers receiver receives from the GDO to change every time the GDO is used within operating range of the receiver. Rolling code programming requires the customer to push a learn/program button on the GDO receiver at their home. This button is usually located on the receiver unit under a cover (light cover) on one end of the unit. The customer must follow the GDO manufacturers instructions to program/learn the receiver to accept the HomeLink as an authorized opener for their unit. When the receiver and the GDO are initially programmed together, a code is established and a new code is created for every new transmission. The software in the receiver recognizes the GDO and accepts the new code.

The GDO is compatible with most, but not all types and brands of transmitters. If a problem should occur with a compatibility conflict with a transmitter, call HomeLink™ at 1-800-355-3515.

The GDO is a transmitter operating between 288-399 MHz. The power and range of the transmitter is limited to comply with laws governing the generation of radio frequency interference (RFI). The transmitter is programmed by the user to accept the signal generated by the user's transmitters. Refer to Control Module References for replacement, setup, and programming.

The GDO has 3 buttons that may be programmed for individual transmitter/receiver combinations to control up to 3 GDOs, security gates, and lighting systems. Each button represents a transmitter code section of the transmitter, which operates separately from any other button, and may be considered a separate transmitter. Operation consists of simply pressing a button to activate the corresponding transmitter.
