Cellular System, Entertainment System, and Navigation System: Specifications Cadillac STS I facelift

Entertainment Systems 12 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Amplifier Mounting Bolts9 N.m80 lb in
Antenna Base Screw1 N.m9 lb in
Front Door Speaker Mounting Screws2 N.m18 lb in
Front I/P Speaker Mounting Screws2 N.m18 lb in
Front Seat Speaker Screw2 N.m18 lb in
Global Position Antenna Mounting Screws2 N.m18 lb in
Microphone Mounting Screws2 N.m18 lb in
Navigation Data Module Screws9 N.m80 lb in
Onstar Module Mounting Screws9 N.m80 lb in
Radio Antenna Module Bolt9 N.m80 lb in
Radio Front Floor Console Speaker Screw2 N.m18 lb in
Radio Mounting Bolts9 N.m80 lb in
Rear Door Speaker Mounting Screws2.5 N.m22 lb in
Rear Speaker Mounting Nut9 N.m80 lb in
Rear Speaker Mounting Screws9 N.m80 lb in
TV Antenna Amplifier Screw9 N.m80 lb in
TV Antenna Mounting Screws2 N.m18 lb in
TV Antenna Module Mounting Screws9 N.m80 lb in

Scheme 1

Scheme 1: Radio/Navigation System Schematics
Scheme 1: Radio/Navigation System Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: OnStar Schematics
Scheme 11: OnStar Schematics

Scheme 12

Scheme 12
Scheme 12
