Removal Procedure
- Remove the rear upper compartment trim. Refer to «Rear Compartment Trim Panel Replacement»(ref-338115-S24701225692009081700000) .
- Release the tabs securing the rear park assist module (3) to the module bracket.
- Disconnect the electrical connectors.
Installation Procedure
- Connect the electrical connectors.
- Install the module (3) to the bracket.
- Install the rear upper compartment trim. Refer to «Rear Compartment Trim Panel Replacement»(ref-338115-S24701225692009081700000) .
- Refer to «Control Module References»(ref-338152-S12253781062009081700000) for programming and setup information.
- Remove the rear overhead console.
- Remove screws securing the rear park assist tell tale module to the overhead console.
- Disconnect the electrical connectors.
- Connect the electrical connectors.
- Install the screws securing the rear park assist tell tale module to the overhead console and tighten to 2 N.m (18 lb in).
- Install the rear overhead console.
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Vehicle Direction Alert Alarm Warning Module Procedure Disconnect the electrical connector. Use a small flat bladed tool and insert along the top edge in the recessed notches and push in both tabs to release the upper edge of the module. Then slide upward to disengage the lower tabs of the module from the bracket. Refer to Control Module References for set-up and programming information. |
