Heating, Ventilation, and Air Conditioning: Component Locations

Heating, Ventilation, and Air Conditioning: Component Locations Cadillac STS I facelift

Special Tools

J 39400-A Halogen Leak Detector. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 41447 R-134A A/C Tracer Dye-Box of 24. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 42220 Universal 12V Leak Detection Lamp. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 43872 Fluorescent Dye Cleaner. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 46297 A/C Dye Injector Kit. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 46297-12 Replacement Dye Cartridges. See «Special Tools»(ref-338121-S30929613952009081700000) .

J 43600 ACR 2000 Air Conditioning Service Center. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 45037 A/C Oil Injector. See «Special Tools»(ref-338121-S30929613952009081700000) .

WARNING

To prevent personal injury, avoid breathing A/C Refrigerant and lubricant vapor or mist. Work in a well ventilated area. To remove refrigerant from the A/C System, use service equipment designed for recovery that is certified to meet the requirements of the appropriate SAE Standards. If an accidental system discharge occurs, ventilate the work area before continuing service. Additional health and safety information may be obtained from the refrigerant, refrigerant recovery, and lubricant manufacturers.

WARNING

For personal protection, goggles and lint-free gloves should be worn and a clean cloth wrapped around fittings, valves, and connections when doing work that includes opening the refrigerant system. If refrigerant comes in contact with any part of the body severe frostbite and personal injury can result. The exposed area should be flushed immediately with cold water and prompt medical help should be obtained.

CAUTION

R-134a is the only approved refrigerant for use in this vehicle. The use of any other refrigerant may result in poor system performance or component failure.

CAUTION

To avoid system damage use only R-134a dedicated tools when servicing the A/C system.

CAUTION

Use only Polyalkylene Glycol Synthetic Refrigerant Oil (PAG) for internal circulation through the R-134a A/C system and only 525 viscosity mineral oil on fitting threads and O-rings. If lubricants other than those specified are used, compressor failure and/or fitting seizure may result.

CAUTION

R-12 refrigerant and R-134a refrigerant must never be mixed, even in the smallest of amounts, as they are incompatible with each other. If the refrigerants are mixed, compressor failure is likely to occur. Refer to the manufacturer instructions included with the service equipment before servicing.

The J 43600 is a complete air conditioning service center for R-134a. See Special Tools . The ACR 2000 recovers, recycles, evacuates and recharges A/C refrigerant quickly, accurately and automatically. The unit has a display screen that contains the function controls and displays prompts that will lead the technician through the recover, recycle, evacuate and recharge operations. R-134a is recovered into and charged out of an internal storage vessel. The ACR 2000 automatically replenishes this vessel from an external source tank in order to maintain a constant 5.45-6.82 kg (12-15 lbs) of A/C refrigerant.

The ACR 2000 has a built in A/C refrigerant identifier that will test for contamination, prior to recovery and will notify the technician if there are foreign gases present in the A/C system. If foreign gases are present, the ACR 2000 will not recover the refrigerant from the A/C system.

The ACR 2000 also features automatic air purge, single pass recycling and an automatic oil drain.

Refer to the J 43600 ACR 2000 manual for operation and setup instruction. See Special Tools . Always recharge the A/C System with the proper amount of R-134a. Refer to Refrigerant System Capacities for the correct amount.

J 41447 R-134A A/C Tracer Dye - Box of 24. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 42220 Universal 12V Leak Detection Lamp. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 43600 ACR 2000 Air Conditioning Service Center. See «Special Tools»(ref-338121-S30929613952009081700000) .
J 45268 A/C Flush Adapter Kit. See «Special Tools»(ref-338121-S30929613952009081700000) .

J 39400-A Halogen Leak Detector. See Special Tools .

J 38185 Hose Clamp Pliers

Illustration Tool Number/ Description J 38185 Hose Clamp Pliers J 39400-A Halogen Leak Detector J 41447 R-134A A/C Tracer Dye - Box of 24 J 42220 Universal 12V Leak Detection Lamp J 43600 ACR 2000 Air Conditioning Service Center J 43872 Fluorescent Dye Cleaner J 45037 A/C Oil Injector J 45268 A/C Flushing Adapter Kit J 45689 A/C Quick Joint Tool J 46297 A/C Dye Injector Kit J 46297-12 Replacement Dye Cartridges
