Wiring diagram: Headlights — Headlamps leveling circuit Cadillac SRX II facelift

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• Automatic Hdlp Pos Rtn Automatic Hdlp Pos Rtn 2 Ground
• Automatic Level Ctrl Pos Sens Sig Low Ref
• Computer Data Lines System 3208 3207
• Front Suspension Height Sensor
• Hdlp Lvl Sens Frt Sig Low Ref Data Comm Enable
• Hdlp Volt Hdlp Volt 2
• Headlamp Leveling Control Module
• Hi Spd Gmlan Ser Data - Hi Spd Gmlan Ser Data +
• Left Headlamp
• Left Headlamp Ballast
• Logic Left Headlamp Horizontal Motor
• Logic Left Headlamp Leveling Actuator
• Logic Right Headlamp Horizontal Motor
• Logic Right Headlamp Leveling Actuator
• Mdl- Afl/Ahl Fuse
• Outage Detection Sig Linear Interconnect N/W 6 Linear Interconnect N/W 7
• Rear Suspension Height Sensor
• Right Headlamp Ballast Right Headlamp
• Underhood Fuse Block
