Object Detection System: Other — Cadillac SRX II facelift (2012-2016)

Reference Information

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Active Safety System, UGN, N America) , Object Detection Description and Operation (with Front and Rear Park Assist, UD5) , Object Detection Description and Operation (with Rear Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT, N America) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFG, N America) , Object Detection Description and Operation (with Forward Collision Alert, UEU) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Haptic Signal Motor Seat) , Object Detection Description and Operation (with Adaptive Cruise Control, KSG, N America) , Object Detection Description and Operation (with Active Safety System, UGN, except N America) , Object Detection Description and Operation (with Adaptive Cruise Control, KSG, except N America) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT, Except N America) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT, Except N America)

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Ignition ON.
Verify that B094B 45 or B094C 45 is not set. If DTC is set Program the appropriate B218 Side Object Sensor Module. Verify the DTC does not set. If the DTC sets, replace the appropriate B218 Side Object Sensor Module. If the DTC does not set All OK. If DTC is not set
Verify that B094B 00, B094C 00, B094B 08, B094C 08, B094B 54 or B094C 54 is not set. If DTC is set Replace the appropriate B218 Side Object Sensor Module. If the DTC is not set
Verify that B094B 58 or B094C 58 is not set. If DTC is set Verify the area in front of the sensor is clean, unobstructed, and damage-free. If not clean, unobstructed, and damage-free, clean or repair as necessary. If clean, unobstructed, and damage-free, replace the appropriate B218 Side Object Sensor Module. If DTC is not set
All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for side object sensor module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that B094C is not set. If DTC is set Replace the B218R Side Object Sensor Module - Right. If the DTC is not set
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for side object sensor module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition OFF, ignition ON.
Verify that both side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF when the ignition is first turned ON. If both side blind zone alert indicators do not briefly turn ON and OFF Verify the system is enabled If disabled, refer to diagnostic aids for cause of disable. If enabled, refer to Circuit/System Testing (below). If only one indicator does not briefly illuminate during the self test Refer to Circuit/System Testing (below). If both side blind zone alert indicators briefly turn ON and OFF
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Outside Rearview Mirror Glass Replacement»(ref-644746-S38148663762014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for Side Object Sensor Module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that DTC B1405 is not set. If the DTC is set Refer to «DTC B1405 (Rear Park Assist - UD7)»(ref-644761-S27183452282014072300000) , «DTC B1405 (Front and Rear Park Assist - UD5)»(ref-644761-S08404986382014072300000) If the DTC is not set
Verify that DTC B0954 01, B0955 01, B0956 01, B0957 01 B0954 21, B0955 21, B0956 21 or B0957 21 is not set. If the DTC is set Verify the B78 Front Object Sensors are not contaminated with snow, mud, dirt, slush, or ice. If contaminated, clean sensor. If there is no contamination Refer to Circuit/System Testing (below). If the DTC is not set
Verify that DTC B0954 3A, B0955 3A, B0956 3A or B0957 3A is not set. If the DTC is set Replace the B78 Front Object Sensor with the correct sensor type. If the DTC is not set
Ignition ON, transmission in REVERSE.
Verify the scan tool Parking Assist System Status parameter displays Enabled. If the Parking Assist System displays Disabled Refer to Circuit/System Testing (below). If the Parking Assist System displays Enabled
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Front Parking Assist Alarm Sensor Replacement»(ref-644761-S12303777712014072300000)
«Rear Parking Assist Alarm Sensor Replacement»(ref-644761-S22731149992014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for front and rear parking assist control module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that DTC B1405 is not set. If the DTC is set Refer to «DTC B1405 (Rear Park Assist - UD7)»(ref-644761-S27183452282014072300000) , «DTC B1405 (Front and Rear Park Assist - UD5)»(ref-644761-S08404986382014072300000) If the DTC is not set
Verify that DTC B0958 01, B0959 01, B0960 01, B0961 01, B0958 21, B0959 21, B0960 21 or B0961 21 is not set. If the DTC is set Verify the B78 Rear Object Sensors are not contaminated with snow, mud, dirt, slush, or ice. If contaminated, clean sensor. If there is no contamination Refer to Circuit/System Testing (below). If the DTC is not set
Verify that DTC B0958 3A, B0959 3A, B0960 3A or B0961 3A is not set. If the DTC is set Replace the B78 Rear Object Sensor with the correct sensor type. If the DTC is not set
Ignition ON, transmission in REVERSE.
Verify the scan tool Parking Assist System Status parameter displays Enabled. If the Parking Assist System displays Disabled Refer to Circuit/System Testing (below). If the Parking Assist System displays Enabled
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Rear Parking Assist Alarm Sensor Replacement»(ref-644761-S22731149992014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for front and rear parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the scan tool Park Assist Switch parameter changes between Active and Inactive when cycling the parking assist switch. If the Parking Assist Switch parameter does not change between Active and Inactive Refer to «Parking Assist Switch Malfunction»(ref-644761-S37945167172014072300000) . If the Parking Assist Switch parameter changes between Active and Inactive
Verify the Park Assist Switch Indicator turns ON and OFF when cycling the parking assist switch. If the indicator does not turn ON and OFF Refer to «Parking Assist Switch Indicator Malfunction»(ref-644761-S37945167172014072300000) . If the indicator turns ON and OFF
All OK.

Perform the Diagnostic Repair Verification after completing the repair

«Accessory Switch Replacement»(ref-644717-S15816537482014072300000) - Multifunction Switch - Center Console replacement.
«Control Module References»(ref-644727-S14842497662014072300000) for active safety control and front and rear parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(ref-644761-S23933398022014072300000) If the DTC is not set
Verify the lane departure warning indicator turns ON and OFF while pressing and releasing the lane departure warning switch. If the indicator does not turn ON and OFF Refer to Circuit/System Testing (below). If the indictor turns ON and OFF
All OK.

Perform the Diagnostic Repair Verification after completing the repair

«Accessory Switch Replacement»(ref-644717-S15816537482014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for frontview camera module and active safety control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that no other DTCs are set except for DTC B1011. If any other DTCs are set Diagnose this first. Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-644698-S15398667192014072300000) . If no other DTCs are set
Verify the scan tool Front View Camera Module Disable History displays no current malfunction. If a current malfunction is displayed Diagnose the system that sets the malfunction. Refer to «Diagnostic Aids»(ref-644761-S12439223632014072300000) . If no current malfunction is displayed
Verify the scan tool Vehicle Direction Camera System Status parameter is Normal. If not Normal Refer to «Lane Departure Warning System Malfunction»(ref-644761-S41784093672014072300000) . If Normal
Verify the scan tool Vehicle Direction Camera Calibration Status parameter is Calibrated. If not Calibrated Calibrate the Vehicle Direction Camera Control Module. Refer to «Front View Camera Module Calibration»(ref-644761-S31498063962014072300000) . If Calibrated
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for frontview camera module replacement, programming, and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify DTC B1015 is not. If DTC B1015 is set Program the control module the DTC originally set in. Verify the DTC does not set. If the DTC is sets, replace the control module the DTC set in. If the DTC does not set All OK If DTC B1015 is not set
All OK

Perform the Diagnostic Repair Verification after completing the repair

Control Module References for the parking assist control module, frontview camera module, radar sensor module, or active safety control module replacement, programming and setup.

Schematic Reference

«Data Communication Schematics»(ref-644719-S20740415782014072300000)
«Control Module References»(ref-644727-S14842497662014072300000)

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Data Link Communications Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify DTC B101D is not set. If DTC B101D is set Replace the B218L Side Object Sensor Module - Left. Verify no new DTCs set and side object system operates properly. If there are new DTCs refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-644698-S15398667192014072300000) , or if the system does not operate properly, refer to «Side Blind Spot Alert System Malfunction (N America)»(ref-644761-S34828087832014072300000) , «Side Blind Spot Alert System Malfunction (Except N America)»(ref-644761-S08616999972014072300000) . If there are no new DTCs and the side object system operates properly If DTC B101D is not set
All OK

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for B218L Side Object Sensor Module - Left replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that DTC B2545 is not set. If the DTC is set Refer to «DTC B2545»(ref-644751-S31694558482014072300000) . If the DTC is not set
Verify the rearview camera has no debris on the lens and that the bezel and bezel seal are not damaged. If debris is found on the lens Clean the lens. If the lens, bezel, or bezel seal are damaged, replace as necessary. If no debris on the lens
Ignition ON, transmission in R.
Verify the backup lamps are illuminated. If the backup lamps are not illuminated Refer to «Backup Lamps Malfunction»(ref-644751-S10594308092014072300000) . If the backup lamps are illuminated
Engine running, transmission in R.
Verify a clear rear vision image is displayed on the P17 Info Display Module. If a clear image is not displayed Refer to Circuit/System Testing (below). If a clear image is displayed
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Rearview Driver Information Camera Replacement»(ref-644761-S09825045442014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for Body Control Module and Human Interface Control Module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, engine running, transmission in R.
Verify the scan tool Park Assist Sensor Reference Voltage parameter is between 7.2-9.2 V. If Park Assist Sensor Reference Voltage is not between 7.2-9.2 V Refer to Circuit/System Testing (below). If Park Assist Sensor Reference Voltage is between 7.2-9.2 V
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for rear parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, engine running, transmission in R.
Verify the scan tool Park Assist Sensor Reference Voltage parameter is between 7.2-9.2 V. If Park Assist Sensor Reference Voltage is not between 7.2-9.2 V Refer to Circuit/System Testing (below). If Park Assist Sensor Reference Voltage is between 7.2-9.2V
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Front Parking Assist Alarm Sensor Replacement»(ref-644761-S12303777712014072300000)
«Rear Parking Assist Alarm Sensor Replacement»(ref-644761-S22731149992014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for parking assist control module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the P45LR Seat Haptic Movement Motor - Driver Left Rear turns on and off when commanding the Driver Seat Cushion Left Rear Haptic Movement On and Off with a scan tool. If the motor does not function Refer to Circuit/System Testing (below). If the motor functions
Verify the P45RR Seat Haptic Movement Motor - Driver Right Rear turns on and off when commanding the Driver Seat Cushion Right Rear Haptic Movement On and Off with a scan tool. If the motor does not function Refer to Circuit/System Testing (below). If the motor functions
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Front Seat Lane Departure Warning Actuator Replacement»(ref-644761-S23553504702014072300000) - seat haptic movement motor - driver replacement.
«Control Module References»(ref-644727-S14842497662014072300000) for seat memory control module - driver replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the scan tool Vehicle Direction Warning Switch Status parameter changes between On and Off while cycling the Lane Departure Warning Switch. If the parameter does not change Refer to Circuit/System Testing (below). If the parameter changes
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Accessory Switch Replacement»(ref-644717-S15816537482014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for Frontview Camera Module replacement, programming, and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that B390A 08 or B390A 45 is not set. If either DTC is set Program the appropriate B233 Radar Sensor Module - Short Range. Verify the DTC does not set. If the DTC sets, replace the appropriate B233 Radar Sensor Module - Short Range. If the DTC does not set All OK. If DTC is not set
Verify that B390A 54 is not set. If DTC is set Replace the appropriate B233 Radar Sensor Module - Short Range. If the DTC is not set
Verify that B390A 58 is not set. If DTC is set Verify the area in front of the sensor is clean, unobstructed, and damage-free. If not clean, unobstructed, and damage-free, clean or repair as necessary. NOTE: After correcting the problem, it may be necessary to drive the vehicle to clear the DTC. Refer to «Diagnostic Aids»(ref-644761-S16575147092014072300000) . If clean, unobstructed, and damage-free, replace the appropriate B233 Radar Sensor Module - Short Range. If DTC is not set
Verify that B390A 67 is not set. If DTC is set in both modules Verify modules have not been swapped side to side. If modules have been swapped, swap them back. if modules have not been swapped or DTC persists, refer to Circuit/System Testing (below). If DTC is set in one module Refer to Circuit/System Testing (below). If DTC is not set
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for radar sensor module - short range replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify there are no DTCs set, except for DTC B101E 4B in the B233B Radar Sensor Module - Long Range or K109 Frontview Camera Module. If other DTCs are set Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-644698-S15398667192014072300000) . If no other DTCs are set Perform the calibration procedure. Refer to «Radar Sensor Module - Long Range Calibration»(ref-644761-S36566531652014072300000) .
Verify DTC B390C 66 is not set If DTC B390C 66 is set Replace and calibrate the B233B Radar Sensor Module - Long Range. If DTC B390C 66 is not set
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for radar sensor module - long range replacement, programming, and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify there are no DTCs set, except for DTC B101E 4B in the B233B Radar Sensor Module - Long Rage or K109 Frontview Camera Module. If other DTCs are set Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-644698-S15398667192014072300000) . If no other DTCs are set
Perform the calibration procedure. Refer to «Front View Camera Module Calibration»(ref-644761-S31498063962014072300000) .
Verify DTC B390D 66 is not set If DTC B390D 66 is set Replace and calibrate the K109 Frontview Camera Module. If DTC B390D 66 is not set
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for frontview camera module replacement, programming, and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Note. DTC P15F6 is an informational DTC. Diagnose all other K20 Engine Control Module DTCs prior to DTC P15F6.

Verify there are no other K20 Engine Control Module or communication DTCs set. If a DTC is set Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-644698-S15398667192014072300000) If a DTC is not set
Complete the diagnosis by looking for an intermittent serial data circuit fault. Refer to «Scan Tool Does Not Communicate with High Speed GMLAN Device»(ref-644719-S16180281052014072300000) . If an intermittent serial data circuit fault is found Repair as necessary. If an intermittent serial circuit fault is not found
Clear DTCs and operate the vehicle in the conditions that the customer experienced.
Verify DTC P15F6 does not set. If the DTC sets Replace K124 Active Safety Control Module If the DTC does not set
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for active safety control module replacement, programming, and setup.

Symptoms - Object Detection

Note. The following steps must be completed before using the symptom tables

Perform the «Diagnostic System Check - Vehicle»(ref-644698-S03753758692014072300000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link. Note: The rear vision camera does not communicate on the serial data bus.
Review the system operation in order to familiarize yourself with the system functions. Refer to «Object Detection Description and Operation (with Active Safety System, UGN, N America)»(ref-644761-S11697016882014072300000) , «Object Detection Description and Operation (with Front and Rear Park Assist, UD5)»(ref-644761-S10937575362014072300000) , «Object Detection Description and Operation (with Rear Park Assist, UD7)»(ref-644761-S07076214662014072300000) , «Object Detection Description and Operation (with Side Blind Zone Alert, UFT, N America)»(ref-644761-S16331970222014072300000) , «Object Detection Description and Operation (with Rear Cross Traffic Alert, UFG, N America)»(ref-644761-S02277546972014072300000) , «Object Detection Description and Operation (with Forward Collision Alert, UEU)»(ref-644761-S34349040872014072300000) , «Object Detection Description and Operation (with Lane Departure Warning, UFL)»(ref-644761-S19880672072014072300000) , «Object Detection Description and Operation (with Haptic Signal Motor Seat)»(ref-644761-S41590974642014072300000) , «Object Detection Description and Operation (with Adaptive Cruise Control, KSG, N America)»(ref-644761-S38148261282014072300000) , «Object Detection Description and Operation (with Active Safety System, UGN, except N America)»(ref-644761-S15442867912014072300000) , «Object Detection Description and Operation (with Adaptive Cruise Control, KSG, except N America)»(ref-644761-S11234740752014072300000) , «Object Detection Description and Operation (with Side Blind Zone Alert, UFT, Except N America)»(ref-644761-S03671456892014072300000) , «Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT, Except N America)»(ref-644761-S13193462952014072300000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the P45LR Seat Haptic Signal Motor - Driver Left Rear turns on and off when commanding the Driver Seat Cushion Left Rear Haptic Movement On and Off with a scan tool. If the motor does not function Refer to Circuit/System Testing (below). If the motor functions
Verify the P45RR Seat Haptic Signal Motor - Driver Right Rear turns on and off when commanding the Driver Seat Cushion Right Rear Haptic Movement On and Off with a scan tool. If the motor does not function Refer to Circuit/System Testing (below). If the motor functions
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Front Seat Lane Departure Warning Actuator Replacement»(ref-644761-S23553504702014072300000) - seat haptic movement motor - driver replacement.
«Control Module References»(ref-644727-S14842497662014072300000) for K40D Seat Memory Control Module - Driver replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Note. Refer to Diagnostic Aids before performing Circuit/System Verification.

Without Active Safety System, UGN

Ignition ON.
Verify the scan tool Forward Collision Alert Function Status parameter is not Malfunction. If the parameter is Malfunction Refer to «Circuit/System Testing - Frontview Camera Module Malfunction»(ref-644761-S28229257202014072300000) If parameter is not Malfunction
Verify the forward collision alert indicators illuminate momentarily when turning ignition OFF and then ON. If the indicators do not illuminate Refer to «Circuit/System Testing - Forward Collision Alert Indicator Malfunction»(ref-644761-S28229257202014072300000) . If the indicators illuminate
Verify the driver information center forward collision alert distance indicator toggles between far, medium, near and off. If the setting does not change Refer to «Circuit/System Testing - Forward Collision Alert Switch Malfunction»(ref-644761-S28229257202014072300000) . If the setting changes
Verify the area of the K109 Frontview Camera Module is not contaminated. If contaminated Clean the windshield If not contaminated
All OK.

With Active Safety System, UGN

Ignition ON.
Verify the forward collision alert indicators illuminate momentarily when turning ignition OFF and then ON. If the indicators do not illuminate Refer to «Circuit/System Testing - Forward Collision Alert Indicator Malfunction»(ref-644761-S28229257202014072300000) . If the indicators illuminate
Verify the driver information center forward collision alert distance indicator toggles between far, medium, near and off. If the setting does not change Refer to «Circuit/System Testing - Forward Collision Alert Switch Malfunction»(ref-644761-S28229257202014072300000) . If the setting changes
Verify the area of the K109 Frontview Camera Module is not contaminated. If contaminated Clean the windshield If not contaminated
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Cruise Control Switch Replacement»(ref-644773-S01017937842014072300000) - Steering Wheel Controls Switch - Left replacement.
«Forward Collision Alert Display Replacement»(ref-644761-S02459931542014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for frontview camera module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information.

Ignition ON.
Verify the scan tool Park Assist Switch parameter while pressing and releasing the parking assist switch. The parameter should change between Active and Inactive. If the parameter does not change between Active and Inactive Refer to «Circuit/System Testing - Parking Assist Switch Circuit Malfunction»(ref-644761-S32479607962014072300000) . If the parameter changes between Active and Inactive
Command the Park Assist Switch LED output control On and Off with the scan tool. The parking assist switch indicator should turn On and Off when changing between the commanded states. If the indicator does not turn ON and OFF Refer to «Circuit/System Testing - Parking Assist Switch Indicator Circuit Malfunction»(ref-644761-S32479607962014072300000) . If the indicator does turn ON and OFF
Transmission in R, verify the Engine Control Module (ECM) scan tool Reverse Position Switch parameter is Active. If the parameter is not Active Refer to «Backup Lamps Malfunction»(ref-644751-S10594308092014072300000) . If the parameter is Active
Transmission in R, verify the scan tool Park Assist System Status parameter displays Enable. If the parameter is not Enabled Refer to «Diagnostic Aids»(ref-644761-S16502223162014072300000) to determine the cause. If the parameter is Enabled
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Accessory Switch Replacement»(ref-644717-S15816537482014072300000) - Multifunction Switch - Center Console replacement.
«Control Module References»(ref-644727-S14842497662014072300000) for body control module, active safety control module and front and rear parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to «Circuit/System Testing - Left Side Object Sensor Malfunction»(ref-644761-S28491688722014072300000) . If the scan tool can communicate with the left side object sensor
Verify the scan tool can communicate with the right side object sensor. If the scan tool can not communicate with the right side object sensor Refer to «Circuit/System Testing - Right Side Object Sensor Malfunction»(ref-644761-S28491688722014072300000) . If the scan tool can communicate with the right side object sensor
Verify that the rear cross traffic indicators turn ON and then turn OFF when commanding the Rear Cross Traffic Visual Alert Indicators ON and OFF with a scan tool. If alert indicators do not turn ON and OFF Verify the system is enabled. If disabled, refer to «diagnostic aids»(ref-644761-S39151561422014072300000) for cause of disable. If enabled test or replace the display. If indicators turn ON and OFF
Verify that the haptic seat motors turn ON and then turn OFF when commanding the Rear Cross Traffic Haptic Alert motors ON and OFF with a scan tool. If haptic alert motors do not turn ON and OFF Verify the system is enabled. If disabled, refer to «diagnostic aids»(ref-644761-S39151561422014072300000) for cause of disable. If enabled refer to «Seat Haptic Signal Motor Malfunction»(ref-644761-S35268044622014072300000) . If haptic alert motors turn ON and OFF
Verify that the audible alert turns ON and then turn OFF when commanding the Rear Cross Traffic Audible Alert ON and OFF with a scan tool. If the audible alert does not turn ON and OFF Verify the system is enabled. If disabled, refer to «diagnostic aids»(ref-644761-S39151561422014072300000) for cause of disable. If enabled refer to audio system malfunction. If audible alert turns ON and OFF
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for side object sensor module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that DTC B2545 is not set. If the DTC is set Refer to «DTC B2545»(ref-644751-S31694558482014072300000) . If the DTC is not set
Verify the rearview camera has no debris on the lens and that the bezel and bezel seal are not damaged. If debris is found on the lens Clean the lens. If the lens, bezel, or bezel seal are damaged, replace as necessary. If no debris on the lens
Ignition ON, transmission in R.
Verify the backup lamps are illuminated. If the backup lamps are not illuminated Refer to «Backup Lamps Malfunction»(ref-644751-S10594308092014072300000) . If the backup lamps are illuminated
Engine running, transmission in R.
Verify a clear rear vision image is displayed on the P17 Info Display Module. If a clear image is not displayed Refer to Circuit/System Testing (below). If a clear image is displayed
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Rearview Driver Information Camera Replacement»(ref-644761-S09825045442014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for Body Control Module, and Human Interface Control Module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to «Circuit/System Testing - Left Side Object Sensor Malfunction»(ref-644761-S03657129922014072300000) . If the scan tool can communicate with the left side object sensor
Verify the scan tool can communicate with the right side object sensor. If the scan tool can not communicate with the right side object sensor Refer to «Circuit/System Testing - Right Side Object Sensor Malfunction»(ref-644761-S03657129922014072300000) . If the scan tool can communicate with the right side object sensor
Ignition OFF, ignition ON.
Verify that both side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF when the ignition is first turned ON. If both side blind zone alert indicators do not briefly turn ON and OFF Verify the system is enabled If disabled, refer to «diagnostic aids»(ref-644761-S17937695302014072300000) for cause of disable. If enabled, refer to «Circuit/System Testing - Side Object Indicator Malfunction»(ref-644761-S03657129922014072300000) . If only one indicator does not briefly illuminate during the self test Refer to «Circuit/System Testing - Side Object Indicator Malfunction»(ref-644761-S03657129922014072300000) . If both side blind zone alert indicators briefly turn ON and OFF
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Outside Rearview Mirror Glass Replacement»(ref-644746-S38148663762014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for side objects sensor module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to «Circuit/System Testing - Left Side Object Sensor Malfunction»(ref-644761-S04965118102014072300000) . If the scan tool can communicate with the left side object sensor
Verify DTC U18A6 is not present If DTC U18A6 is present Diagnose this DTC first. Refer to «Diagnostic Trouble Code List»(ref-645772) . If DTC U18A6 is not present
Ignition OFF, ignition ON.
Verify that both side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF during the system self test. If both side blind zone alert indicators do not briefly turn ON and OFF Verify the system is enabled If disabled, refer to «diagnostic aids»(ref-644761-S42594763302014072300000) for cause of disable. If enabled, refer to «Circuit/System Testing - Side Object Indicator Malfunction»(ref-644761-S04965118102014072300000) . If only one indicator does not briefly illuminate during the self test Refer to «Circuit/System Testing - Side Object Indicator Malfunction»(ref-644761-S04965118102014072300000) . If both side blind zone alert indicators briefly turn ON and OFF
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Outside Rearview Mirror Glass Replacement»(ref-644746-S38148663762014072300000)
«Control Module References»(ref-644727-S14842497662014072300000) for side object sensor module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Electrical Information Reference

«Circuit Testing»(ref-644726-S12298670162014072300000)
«Connector Repairs»(ref-644726-S09053351542014072300000)
«Testing for Intermittent Conditions and Poor Connections»(ref-644726-S21103124652014072300000)
«Wiring Repairs»(ref-644726-S20665353652014072300000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON.
Verify that DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(ref-644761-S23933398022014072300000) . If the DTC is not set
Verify that DTC B0987 is not set. If the DTC is set Refer to «DTC B0987»(ref-644761-S20534660762014072300000) . If the DTC is not set
Verify the scan tool Frontview Camera System Status parameter is Normal. If the parameter is Undefined or Malfunction Refer to «Diagnostic Aids»(ref-644761-S41014190622014072300000) . If the parameter is Normal
Verify the scan tool Lane Departure Warning Switch Status parameter changes between ON and OFF when pressing the lane departure warning switch. If the parameter does not change between On and Off Refer to «Circuit/System Testing - Lane Departure Warning Switch Malfunction»(ref-644761-S42454646122014072300000) . If the parameter changes between On and Off
Verify the scan tool Lane Departure Warning Indicator Status parameter changes change between On and Off when pressing the lane departure warning switch. If the parameter does not change between On and Off Refer to «Circuit/System Testing - Lane Departure Warning Switch Indicator Malfunction»(ref-644761-S42454646122014072300000) . If the parameter changes between On and Off
All OK.

Perform the Diagnostic Repair Verification after completing the repair.

«Accessory Switch Replacement»(ref-644717-S15816537482014072300000) - S48E Multifunction Switch - Center Console replacement.
«Control Module References»(ref-644727-S14842497662014072300000) for active safety control module and frontview camera module replacement, programming and setup.

Scheme 18

Scheme 18: Front Seat Lane Departure Warning Actuator Replacement

Callout	Component Name
WARNING: Refer to SIR Warning . Preliminary Procedure Remove the front seat. Refer to Driver or Passenger Seat Removal and Installation . Remove the driver or passenger seat cushion cover and pad. Refer to Front Seat Cushion Cover and Pad Replacement .
1	Front Seat Lane Departure Warning Actuator Topper Pad (Qty: 2) Procedure Gently peel away the topper pad from the seat cushion pad. When removing the topper pad be careful not to damage the motor. NOTE: The topper pad must be replaced every time the motor is replaced.
2	Front Seat Lane Departure Warning Actuator Motor (Qty: 2) Procedure Reposition the heater element as needed to gain access to the actuator wire. Cut the original actuator wire that connects to the main harness and splice in the new actuator wire. Refer to Splicing Copper Wire Using Splice Sleeves Remove the original actuator and discard it. Note the routing of the original wire and harness location for installation. NOTE: Adjust the splice location so that each splice is at least 40 mm (1.5 in) away from other splices, harness branches, or connectors.

WARNING
Refer to SIR Warning .

NOTE
The topper pad must be replaced every time the motor is replaced.

NOTE
Adjust the splice location so that each splice is at least 40 mm (1.5 in) away from other splices, harness branches, or connectors.

Front Seat Lane Departure Warning Actuator Replacement

Scheme 19

Scheme 19: Forward Range Radar Module Replacement

Callout	Component Name
Preliminary Procedure Remove the front bumper fascia energy upper absorber. Refer to Front Bumper Fascia Energy Upper Absorber Replacement .
1	Forward Range Radar Module Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
2	Forward Range Radar Module Fastener Tighten 9 (80 lb in)
3	Forward Range Radar Module Bracket
4	Forward Range Radar Module Bracket Fastener (Qty: 3)
5	Forward Range Radar Module Procedure Disconnect the electrical connector. For programming and set up, refer to Control Module References . Use a digital angle gauge to align the forward range radar module vertically (at the edge or on the bracket behind the module). NOTE: The digital angle gauge must have an accuracy of ±0.5 degrees (9 mm/m). The vertical position of forward range radar module is 90 degrees (±3 degrees).

CAUTION
Refer to Fastener Caution .

NOTE
The digital angle gauge must have an accuracy of ±0.5 degrees (9 mm/m). The vertical position of forward range radar module is 90 degrees (±3 degrees).

Forward Range Radar Module Replacement

Scheme 20

Scheme 20: Short Range Radar Sensor Replacement

Callout	Component Name
Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement .
1	Short Range Radar Sensor (Qty 2) Procedure Place the front bumper fascia face down on a clean protected surface. Disconnect the electrical connector. Release the tab retainer (arrow) and slide the left hand side object sensor to the right or slide the right hand side object sensor the left and remove. For programming and set up, refer to Control Module References .

Short Range Radar Sensor Replacement

Scheme 21

Scheme 21: Active Safety Control Module Replacement

Callout	Component Name
Preliminary Procedure Remove the rear compartment floor panel rail. Refer to Rear Compartment Floor Panel Rail Replacement .
1	Floor Trim Front Panel
2	Active Safety Control Module Procedure Release the locking retainer from the active safety control module bracket. Disconnect the electrical connectors. For programming and set up, refer to Control Module References .

Active Safety Control Module Replacement

Scheme 22

Scheme 22: Forward Collision Alert Display Replacement

Callout	Component Name
Preliminary Procedure Remove the windshield defroster nozzle grille. Refer to Windshield Defroster Nozzle Grille Replacement .
1	Forward Collision Alert Display Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
2	Forward Collision Alert Display Procedure Disconnect the electrical connector.

CAUTION
Refer to Fastener Caution .

Forward Collision Alert Display Replacement

Scheme 23

Scheme 23: Front and Rear Object Alarm Module Replacement

Callout	Component Name
Preliminary Procedure Remove the left body side trim panel. Refer to Body Side Trim Panel Replacement .
1	Front And Rear Object Alarm Module Nuts (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in)
2	Front And Rear Object Alarm Module Procedure Disconnect the electrical connectors. For programming and set up, refer to Control Module References

CAUTION
Refer to Fastener Caution .

Front and Rear Object Alarm Module Replacement

Adaptive Cruise Control

The front long range, front short range radars, and front view camera scans the road environment to detect targets within its specified field of view. With input from the front radars and front view camera the active safety control module controller then makes throttle and/or brake commands to the engine control module (ECM) and electronic brake control module (EBCM) via the serial data circuit in order to control the vehicle acceleration/deceleration based on the data from the radar. The ECM and EBCM provide throttle control and automatic braking needed for proper cruise speed adjustment.

Active cruise control allows a driver to set and maintain a following distance to the preceding nearest vehicle in the path ahead. The active safety control module controller calculates a follow speed limit to ensure an acceptable distance is maintained to the preceding vehicle in front, should one be present. The adaptive cruise control system automatically adjusts the speed when the vehicle comes up behind a slower travelling vehicle in front. The system applies limited automatic braking and throttle control without driver input when necessary to maintain the set following distance. The preceding vehicle's speed and acceleration along with the active cruise control vehicle speed and acceleration and the distance between the 2 vehicles are factors used by the active safety control module controller to determine the follow speed limit. The vehicle speeds up to the original driver selected set speed when the pathway becomes clear without driver input.

Automatic Collision Preparation System

With the input from the front camera module, front long range radar and front short range radar, the active safety control module prepares the vehicle's braking system to reduce brake response time. Once the collision is deemed unavoidable, and if the driver still does not react more aggressively, braking is applied automatically. The system may help reduce collision damage and may even help avoid some crashes at very low speeds.

Forward Collision Alert

With input from the frontview camera module and front short and long range radar modules, the active safety control module evaluates collision threats in the vehicle's forward path and alerts the driver of a potential collision. Alerts will only be possible if the system has detected a vehicle ahead and turned on the green vehicle ahead indicator. The active safety control module will send a command via serial data to turn on the forward collision alert telltale when approaching a vehicle directly ahead too quickly. The active safety control module will also send a command via serial data to pulse the driver seat (if equipped and enabled) or create a beeping noise through the speakers when approaching a vehicle directly ahead too quickly.

Lane Departure Warning

With input from the frontview camera module the active safety control module will issue a warning via serial data to the instrument cluster to turn on the lane departure warning telltale when the system detects that the vehicle has unintentionally crossed a lane marking. In addition, an audible alert or haptic alert will signal the driver the vehicle has unintentionally left the lane. The memory seat module will command three pulses to the left or right side of the seat depending on the lane departure direction. The front view camera is located behind the windshield, looking out at the road ahead and detecting any lane markings. The system can be turned off by using the lane departure warning switch.

The lane departure warning telltale will be illuminated green when the system is ready to assist and will be a flashing an amber color when crossing the lane unintentionally.

Integrated Brake Assist

With the input from the frontview camera module, front long range radar and front short range radar, the active safety control module provides a boost to the driver's commanded braking as much as is needed to potentially avoid a frontal impact. Integrated brake assist may activate when the brake pedal is applied quickly by providing a boost to braking based on the speed of approach and distance to a vehicle ahead. The driver can override this behavior by releasing the brake pedal or pressing the accelerator pedal.

Rear Emergency Automatic Braking

The rear automatic braking system is designed to help avoid or reduce the harm caused by backing crashes. If the system detects the vehicle is backing too fast to avoid a collision, it may automatically brake hard to a stop.

With the input from the rear short range radar and park assist system, the active safety control module attempts to avoid imminent collision by automatically braking the vehicle when going in reverse. Two levels of warning are used to encourage the driver to take control. The first level will pulse the left and right sides of the seat twice (if equipped and enabled) or beep once when an object is first detected. When the system detects a potential collision, the second level will provide five pulses on the left and right sides of the driver seat or five beeps, and there may be a brief, sharp application of the brakes.

Pressing the brake pedal after the vehicle comes to a stop will release the rear automatic braking. Also, when it is safe to do so, pressing the accelerator pedal firmly at any time will override the rear automatic braking.

Vehicle Ahead Indicator

With input from the frontview camera module and front long range radar, the active safety control module will issue a command via serial data to turn on the green vehicle ahead indicator. This is an indication that the forward collision system is ready to assist.

Driver Information Center Messages

Adaptive Cruise Control Temporarily Unavailable

The active safety control module will send this message if the adaptive cruise control has been disengage or disabled. There are many reasons that can cause this, some will also set DTCs. Check vehicle for DTCs and also check the Adaptive Cruise Control Inhibit History and Disengage History scantool data. Definitions of parameters can be found in Active Safety Control Module Scan Tool Information .

Park Assist Temporarily Unavailable

This message sets if there is a problem with the park assist feature. Check vehicle for DTCs. Verify if the problem is with park assist only or if lane departure warning and adaptive cruise control are also inoperative. If all are inoperative, check the Adaptive Cruise Control Inhibit History and Disengage History scantool data for the reason for the malfunction. Definitions of parameters can be found in Active Safety Control Module Scan Tool Information .

Service Adaptive Cruise Control and Service Front Camera

The message is set if the Active Safety Control Module is not communicating to the instrument cluster. Check vehicle for DTCs.

Service Driver Assist System

This message can be set by either the Active Safety Control Module if there is a problem with the driver assist system or by the Memory Seat Module if there is a problem with the haptic seat circuits. Check vehicle for DTCs.

Parking Assist System Driver Information Center Messages

SERVICE PARK ASSIST

The driver information center displays SERVICE PARK ASSIST when the parking assist control module detects a malfunction in the parking assist system and the system is disabled. The driver information center also displays SERVICE PARK ASSIST when a loss of communication occurs with the parking assist control module.

PARK ASSIST OFF

The PARK ASSIST OFF message is displayed in the driver information center when the parking assist system is disabled due to conditions that disable or inhibit the system. The parking assist control module requests the driver information center display PARK ASSIST OFF when it detects that one of the following conditions

The parking assist system is manually disabled using the parking assist switch.
An object is attached to the rear of the vehicle, such as a trailer, bicycle rack, trailer hitch receiver, or tow bar. Also, an object extending beyond a lowered tailgate will disable the system.
The parking assist sensors are covered by snow, mud, dirt, slush, or ice.
The vehicle bumper is damaged.
Excessive paint thickness on a replacement parking assist sensor.
The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

SERVICE PARK ASSIST

PARK ASSIST OFF

The parking assist system is manually disabled using the parking assist switch.
An object is attached to the rear of the vehicle, such as a trailer, bicycle rack, trailer hitch receiver, or tow bar. Also, an object extending beyond a lowered tailgate will disable the system.
The parking assist sensors are covered by snow, mud, dirt, slush, or ice.
The vehicle bumper is damaged.
Excessive paint thickness on a replacement parking assist sensor.
The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

Scheme 24

Scheme 24: Side Blind Zone Alert Block Diagram

Callout	Component Name
HW	Hard-Wired
DA	Serial Data
HW	Hard-Wired
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
HW	Hard-Wired
HW	Hard-Wired
B218R	B218R Side Object Sensor Module - Right
A9B	A9B Outside Rearview Mirror - Passenger
A11	A11 Radio
B218L	B218L Side Object Sensor Module - Left
A9A	A9A Outside Rearview Mirror - Driver
K40	K40 Seat Memory Control Module
P45LR	Seat Haptic Movement Motor - Driver Left Rear
P45RR	Seat Haptic Movement Motor - Driver Right Rear

Description and Operation

The side blind zone alert system shall detect and report "objects of interest" on either side of the vehicle, within a specified "blind spot" zone. The system is designed to alert the driver, with a visual display placed on the side view mirror, to the presence of objects of interest that may not be visible in the inside rearview mirror and outside rear view mirrors. Although this system is intended to help drivers avoid lane change crashes, it does not replace driver vision and therefore should be considered a lane change aid. Even with the side blind zone alert system, the driver must check carefully for objects outside of the reporting zone (e.g., a fast approaching vehicle) before changing lanes. In the event that the system senses a malfunction through its diagnostic routines, the system will be disabled and the driver will be visually notified.

When the system detects a vehicle in the side blind zone while driving forward, an amber warning symbol will light up in the appropriate outside mirror. This indicates that it may be unsafe to change lanes. If the driver then activates the turn signal, the amber warning symbol starts flashing as an extra warning not to change lanes.

Side blind zone alert is active when the vehicle is out of park or the parking brake is off on manual transmission vehicles and at speeds up to approximately 140 km/h (87 MPH). If a vehicle is detected in the blind zone, the warning symbols will turn illuminate on the appropriate side. When the vehicle is started, both outside mirror displays will briefly come on to indicate that the system is operating. The warning symbols will vary brightness based on the ambient light conditions.

The side blind zone alert system is made up of the following components

Left side object sensor module (also used for rear cross traffic alert)
Right side object sensor module (also used for rear cross traffic alert)
Driver outside rearview mirror
Passenger outside rearview mirror

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of objects nearby. When an object is detected in the side blind zone, the side object sensor module supplies voltage to illuminate the visual indicator on the appropriate side rear view mirror. Each sensor is supplied B+ and ground. The right sensor receives an additional ground. Both sensors communicate independently on the serial data line. The serial data enters the left sensor in a pass-thru configuration, that connects to the right sensor. The scan tool is able to individually communicate with each sensor.

Outside Rearview Mirrors

The outside rearview mirrors contain an icon that is backlit with high intensity, amber-colored LED's located on the mirror surface. The display brightness adapts to day/night conditions. The side blind zone alert indicator icon in the left or right outside rearview mirror is illuminated if the left or right side object sensor module detects a vehicle in the side blind zone to inform the driver that there is a vehicle driving in the blind spot zone.

Side Blind Zone Alert Driver Information Center Messages

SIDE BLIND ZONE ALERT OFF

This message indicates that the system has been disabled through the driver information center. Refer to the vehicle owners manual for instructions on how to set personalization options on the driver information center.

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. When the message is displayed, the indicators will remain illuminated at all times, notifying the driver that the side blind zone system should not be relied upon when changing lanes. Since the sensors are also used for rear cross traffic alert, this feature will also be inoperative.

SIDE DETECTION SYSTEM UNAVAILABLE

This message indicates that the system has been temporarily disabled because the sensor is blocked or can otherwise not accurately detect vehicles or objects. Such instances may be mud, dirt, snow, ice, or slush build-up on the rear fascia, heavy rainfall, excessive road spray, fascia damage or stickers.

The rear cross traffic alert system will read the GPS latitude and longitude on the serial data bus and calculate if the vehicle is within a Radio Astronomy zone. These zones are located in Europe and Japan and require the sensors to be turned off. The "Side Detection System Unavailable" message will be displayed to the driver when this occurs.

Scheme 25

Scheme 25: Rear Cross Traffic Alert Block Diagram

Callout	Component Name
DA	Serial Data
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
HW	Hard-Wired
HW	Hard-Wired
B218R	B218R Side Object Sensor Module - Right
B218L	B218L Side Object Sensor Module - Left
A11	A11 Radio
K40	K40 Seat Memory Control Module
P45LR	Seat Haptic Movement Motor - Driver Left Rear
P45RR	Seat Haptic Movement Motor - Driver Right Rear

The rear cross traffic alert system is designed to provide enhanced customer visibility while backing up by providing warnings to the driver on impending rear cross traffic. The rear cross traffic alert system is designed to detect and track objects of interest within a specified coverage zone behind the vehicle. The system is designed to alert the driver, with a visual display and either an audible sound or a haptic warning, to the presence of objects of interest that may cause a collision with the host vehicle. Although the system is intended to assist drivers in backing up, it does not replace driver's vision. The driver is responsible to check carefully for objects outside of the coverage zone (e.g., a fast approaching vehicle) for a safe backing maneuver. In the event that the system senses a malfunction through its diagnostic functions, the system will be disabled and the driver will be visually notified.

Rear Cross Traffic Alert System Components

The side blind zone alert system is made up of the following components

Left side object sensor module (also used for side blind zone alert)
Right side object sensor module (also used for side blind zone alert)
Visual Display Icons located on the rear vision display screen
Audio System chime or Haptic Seat notification

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of objects nearby. When an object is detected in the rear cross traffic zone, the module will send out a signal through serial data communication to turn on the visual icons and also audio chime or haptic notification. Each sensor is supplied B+ and ground. The right sensor receives an additional ground. Both sensors communicate independently on the serial data line. The serial data enters the left sensor in a pass-thru configuration, that connects to the right sensor. The scan tool is able to individually communicate with each sensor.

Display Icons

The rear cross traffic alert system visual alert display consists of two visual icons, one on each side of the display screen of the rear vision camera, that are used to alert the driver on rear cross traffic from each side of the host vehicle respectively.

Audio or Haptic Notification

The alert output type can be driver selected to either audio or haptic. The chime location will be left rear for left rear cross traffic alert and right rear for right rear cross traffic alert. The haptic seat system response will be to generate 3 repetitions of haptic vibration in the left rear area of the seat for left cross traffic alert and right rear area of the seat for right cross traffic alert. If there is a problem with the haptic seats, the audio chime will be substituted.

Rear Cross Traffic Alert Driver Information Center Messages

REAR CROSS TRAFFIC ALERT OFF

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. Since the sensors are also used for side blind zone alert, this feature will also be inoperative.

SIDE DETECTION SYSTEM UNAVAILABLE

Scheme 26

Scheme 26: Lane Departure Warning Block Diagram

Callout	Component Name
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
HW	Hard-Wired
HW	Hard-Wired
HW	Hard-Wired
K109	K109 Frontview Camera Module
A11	A11 Radio
P16	P16 Instrument Cluster
K40	K40 Seat Memory Control Module
P45RR	Seat Haptic Movement Motor - Driver Right Rear
P45LR	Seat Haptic Movement Motor - Driver Left Rear
S48C	S48C Multifunction Switch 1 - Instrument Panel

The lane departure warning system is a convenience feature of the front view camera that issues a warning when the system detects that the vehicle has unintentionally crossed a lane marking. The front view camera is located behind the windshield, looking out at the road ahead and detecting any lane markings. When the vehicle unintentionally leaves a detected lane, a visual and audible or haptic (pulses the seat, if equipped) alerts are given to the driver. The visual alert cannot be changed, but the driver can select between audible or haptic alerts in the vehicle personalization menus. See the user's manual for more detailed information on vehicle personalization.

The lane departure warning system is made up of the following components

Front view camera module
Lane departure warning switch / control indicator
Instrument cluster / Vehicle Direction Display
Radio
Safety Alert Seat, if equipped

Front View Camera Module

The camera detects visual queues such as lane markings. When it is determined that the vehicle has unintentionally moved outside of the lane, visual, and audible or haptic warning is given to the driver. The front view camera module receives an input from the lane departure warning switch and controls the lane departure warning switch indicator output. The front view camera module also communicates via serial data with the instrument cluster, radio, and memory seat module to request visual, and audible or haptic alerts.

Lane Departure Warning Switch

The lane departure warning switch provides an input to the front view camera module to turn the lane departure warning system ON and OFF. The front view camera module provides a signal voltage to the normally open momentary switch. When the switch is pressed, the signal circuit is pulled to ground, indicating to the front view camera module that the system has been requested to turn ON or OFF. The lane departure warning switch also contains the lane departure warning switch indicator, which is controlled by the front view camera module to indicate the ON and OFF status of the lane departure warning system. When the system has been enabled by the lane departure warning switch, the front view camera module applies ground to the switch indicator and illuminates the LED. The location of the lane departure warning switch can vary with different vehicles. For the exact location please refer to the user's manual.

Instrument Cluster

The vehicle direction display contains green and amber lane departure warning indicators. These indicate to the driver the current status of the lane departure warning system and are controlled via serial data by the front view camera module. When the vehicle speed is above 56 km/h (35 MPH) and the system has detected the required lane markings and is ready to assist, the green indicator will be illuminated on the vehicle direction display. If the vehicle has unintentionally left the lane, the amber indicator will flash.

Radio

The radio controls the audible alert for the lane departure warning. If the vehicle has unintentionally left the lane, the radio will command three beeps as an audible alert to the driver.

Safety Alert Seat

The memory seat module controls the haptic alert provided by the seats. If the vehicle has unintentionally left the lane, the memory seat module will command three pulses to the left or right side of the seat, depending on the lane departure direction.

Lane Departure Warning System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the user's manual.

Scheme 27

Scheme 27: Forward Collision Alert Block Diagram

Callout	Component Name
HW	Hard-Wired
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
HW	Hard-Wired
HW	Hard-Wired
HW	Hard-Wired
S70L	S70L Steering Wheel Controls Switch - Left
K9	K9 Body Control Module
K109	K109 Frontview Camera Module
A11	A11 Radio
P16	P16 Instrument Cluster
K40	K40 Seat Memory Control Module
P43	P43 Collision Alert Indicators
P45RR	Seat Haptic Movement Motor - Driver Right Rear
P45LR	Seat Haptic Movement Motor - Driver Left Rear

The forward collision alert system is a convenience feature of the front view camera that issues a warning to the driver when a potential collision risk exists. The front view camera is located behind the windshield, looking out at the road ahead and detecting vehicles directly ahead, within a distance of approximately 60 meters (197 ft). The forward collision alert system operates at speeds above 40 kph (25 mph). When the system detects a vehicle in the path ahead, the green vehicle ahead indicator in the vehicle direction display is illuminated. When approaching another vehicle too rapidly, the collision alert symbol will flash in the head-up display (if equipped) or a series of red LEDs in the vehicle direction display. Simultaneously an audible alert can sound or the Safety Alert Seat pulses. The visual alert cannot be changed, but the driver can select between audible or haptic alerts in the vehicle personalization menus. The forward collision alert system can also be turned on or off through the vehicle personalization menus. See the user's manual for more detailed information on vehicle personalization.

Forward collision alert does not warn the driver of any objects that are not detected as a vehicle, like e.g. pedestrians, animals, signs, guard rails, bridges, construction barrels or other stationary or slow moving objects. The forward collision alert timing sensitivity to control the distance to the vehicle ahead can be set using the forward collision alert switch in the left steering wheel controls.

In some cases the camera may detect a vehicle that is not in the path ahead, or the system may occasionally provide unrealistic alerts. This could respond to a turning vehicle ahead, guard rails, traffic signs, or other stationary objects. This is normal operation, the vehicle does not need service. Forward collision alert may sometimes set unnecessary alerts to turning vehicles, vehicles in other lanes, objects that are not vehicles, or shadows. These alerts are normal operation and the vehicle does not need service.

The forward collision alert system is made up of the following components

Front view camera module
Forward collision alert switch
Instrument cluster / Vehicle direction display
Radio
Memory Seat Module and Safety Alert Seat, if equipped

Front View Camera Module

The camera detects vehicles in front of the host vehicle. The front view camera module requests the green vehicle ahead alert indicator in the vehicle direction display ON via serial data when the front view camera system has detected a vehicle in the driving path ahead. The front view camera module also communicates via serial data with the driver information center, radio, and memory seat module to request visual, and audible or haptic alerts.

Forward Collision Alert Switch

The forward collision alert switch provides an input to the front view camera module to select the alert timing sensitivity when approaching another vehicle too rapidly. The front view camera module provides a signal voltage to the normally open switch. When the switch is pressed, the signal circuit is pulled to ground, indicating to the front view camera module that the system has been requested to change the alert timing sensitivity. The first button press shows the current alert timing setting on the driver information center. With every button press, the alert timing sensitivity is changed. The current alert timing setting will be maintained until it is changed. The preset alert timing setting is displayed in the top line of the driver information center. The position of the forward collision alert switch can vary with different vehicles. For the exact position of the switch and possible user settings, please refer to the user's manual.

Instrument Cluster

The Vehicle direction display contains the green vehicle ahead indicator, which indicates to the driver that the Front View Camera system has detected a vehicle in the driving path ahead and is controlled via serial data. When approaching another vehicle too rapidly, the collision alert symbol will flash in the Vehicle direction display. The red Front collision alert display will stay continuously illuminated if the vehicle ahead remains much too close. The vehicle ahead indicator will display amber when following too close to the vehicle ahead.

Radio

The radio controls the audible alert for the forward collision alert system. If the host vehicle is approaching another vehicle too rapidly, the radio will command eight beeps as an audible alert to the driver.

Safety Alert Seat

The memory seat module controls the haptic alert provided by the seats. If the vehicle is approaching another vehicle too quickly, the memory seat module will command five pulses to both sides of the seat.

Forward Collision Alert System Driver Information Center Messages

Active Safety Seat

The user can select between haptic or audible (beeps) alerts. This setting can be found in the vehicle personalization menus. See the user's manual for more detailed information on vehicle personalization.

The adaptive cruise control system is an enhanced cruise control system with the ability to sense and react to forward traffic. Compared to the common cruise control system found on many vehicles, the main functional enhancement of the adaptive cruise control system is the ability to detect the presence of a vehicle in the path of the adaptive cruise control vehicle. Adaptive cruise control retains the existing cruise control feature that controls the vehicle speed to the driver selected speed. However, adaptive cruise control allows a driver to set and maintain a following distance to the preceding nearest vehicle in the path ahead. The active safety control module controller calculates a follow speed limit to ensure an acceptable distance is maintained to the preceding vehicle in front, should one be present. The adaptive cruise control system automatically adjusts the speed when the vehicle comes up behind a slower travelling vehicle in front. The system applies limited automatic braking and throttle control without driver input when necessary to maintain the set following distance. The preceding vehicle's speed and acceleration along with the active cruise control vehicle speed and acceleration and the distance between the two vehicles are factors used by the active safety control module controller to determine the follow speed limit. The vehicle speeds up to the original driver selected set speed when the pathway becomes clear without driver input.

Cruise Control Switch

The cruise control switch, functionally is a common feature that is shared between the adaptive cruise control system and the regular cruise control system. The adaptive cruise control system will not operate if any cruise switch fails. The cruise control switch comprises the following cruise control function switches

On/Off switch
Set/decrease switch
Resume/increase switch

The cruise control function switches are arranged in a resistive ladder design whereby each switch function is set up with different resistance values. The BCM through the cruise control switch signal circuit detects a predetermined voltage value when any cruise control switch function is activated. The associated cruise control function signal detected by the BCM is then sent to the engine control module (ECM) as a GMLAN serial data circuit message. The ECM on receiving the message provides the cruise control function requested by the BCM. The ECM is responsible for recognizing and responding to cruise control switch requests sent by the BCM. The cruise control function switches are used by the ECM to communicate to the active safety control module the driver selected vehicle speed. The driver selected vehicle speed is communicated through GMLAN serial data circuit to the active safety control module and the BCM. The adaptive cruise control system engages and adjusts vehicle speeds based on the activation of the following cruise control function switches

On/Off Switch

The BCM monitors the switch signal circuit in order to determine when the On/Off switch is disabled or activated. The BCM detects a predetermined voltage value on the switch signal circuit. The On/Off switch state is then relayed to the ECM via the GMLAN serial data circuit. The ECM sends the On/Off switch input status to the active safety control module. When the On/Off switch is turned ON, the adaptive cruise control system enters either a standby enabled or a standby disabled mode. The standby enabled mode indicates that every condition required for the adaptive cruise control system to function has been met, but the adaptive cruise control is not engaged. When the adaptive cruise control is in the standby disabled mode, the conditions necessary for the adaptive cruise control system to function has not been met. When the On/Off switch is turned OFF, the adaptive cruise control will enter the disabled mode. The adaptive cruise control will not activate in the disabled mode.

Set/Decrease Switch

The adaptive cruise control system is engaged when the adaptive cruise control On/Off switch is turned ON and the set/decrease switch is momentarily pressed and released . When the set/decrease switch is pressed, the selected vehicle speed is set to the current vehicle speed by the ECM. The vehicle speed must be at or greater than 40 km/h (25 MPH). The selected vehicle speed is displayed by the driver information center. While in the engaged state, the selected vehicle speed and the following distance can be adjusted. Pressing and holding the set/decrease switch, when the adaptive cruise control system is engaged, will decrease the selected vehicle speed without deactivating the adaptive cruise control. Momentarily pressing and releasing the set/decrease switch, when the adaptive cruise control is engaged, decreased the selected vehicle speed by 1.6 km/h (1 MPH) for each time that the set/decrease switch is pressed.

Resume/Increase Switch

The resume/increase switch is used in order to increase the selected vehicle speed when adaptive cruise control is active. The amount selected vehicle speed can be increased from the resume/increase switch depends on how long the switch is pressed. The presence of a slower moving vehicle in the path of the adaptive cruise control vehicle will limit the extent to which the selected vehicle speed can be achieved. If there is no preceding vehicle in front, limiting the adaptive cruise control vehicle acceleration, then the vehicle speed that is attained is the new selected vehicle speed. The current selected vehicle speed is displayed by the driver information center. Acceleration is terminated when the resume/increase switch is released. Momentarily pressing and releasing the resume/increase switch will allow the selected vehicle to accelerate in at 1.6 km/h (1 MPH) increments for each time that the resume/increase switch is momentarily pressed.

Gap Switch

The gap switch allows the driver to determine how closely the adaptive cruise control vehicle follows a target vehicle while adaptive cruise control is engaged. When the adaptive cruise control vehicle speed is being limited due to a slower travelling vehicle, the adaptive cruise control vehicle speed is automatically controlled to the follow speed limit. The gap switch has 3 following distance selections that range from 1-2 s. The gap switch following distance between the adaptive cruise control vehicle and the target vehicle is expressed in time as opposed to actual distance. The distance maintained for a selected gap will vary based on vehicle speed. The faster the vehicle speed, the further back you will follow. The gap setting can only be adjusted when the adaptive cruise control system is engaged. The gap switch is hard-wired to the BCM. Based on voltage variations, the BCM is able to read the gap switch selection and communicates the switch status on the GMLAN serial data circuit to the active safety control module. The gap switch is a momentary switch.

The initial push of the gap switch recalls the current setting and activates the display. Subsequent pushes of the gap switch will change the gap setting.

Driver Information Messages

Adaptive Cruise Control Temporarily Unavailable

The active safety control module will send this message if the adaptive cruise control has been disengage or disabled. There are many reasons that can cause this, some will also set DTCs. Check vehicle for DTCs and also check the adaptive cruise control enable and disengage scan tool data. Definitions of parameters can be found in active safety control module scan tool information.

Service Driver Assist System

This message can be set by either the active safety control module if there is a problem with the driver assist system or by the memory seat module if there is a problem with the haptic seat circuits. Check vehicle for DTCs.

Service Adaptive Cruise Control and Service Front Camera

The message is set if the active safety control module is not communicating to the instrument cluster. Check vehicle for DTCs.

Set Speed

The adaptive cruise control vehicle set speed is displayed at all times in the driver information center when adaptive cruise control is engaged. The active safety control module set speed display request is sent to the instrument cluster via the GMLAN serial data circuit.

Follow Distance

The driver information center displays the driver selected following distance when adaptive cruise control is engaged and the gap switch is active. The current follow distance setting is displayed in the driver information center for a few seconds after the gap switch is pressed to increase or decrease the following distance. The active safety control module follow distance display request is sent to the instrument cluster via the GMLAN serial data circuit.

Vehicle Ahead Indicator

The vehicle ahead indicator is displayed in the instrument cluster hen the radar identifies an in-path vehicle. The vehicle ahead indicator is a warning to the driver that a vehicle is ahead. The indicator also serves as a feedback to the driver that the radar is functioning properly. The active safety control module commands the display of the vehicle ahead indicator via a GMLAN serial data message to the instrument cluster. The vehicle ahead indicator only displays with the adaptive cruise control active and may sometimes display for stationary road objects.

Cruise Engaged

The adaptive cruise control system will engage and adjust vehicle speeds based on the activation of the following cruise switches

On/off
Set/decrease
Resume/increase

Adaptive cruise control will not engage if any inhibit criteria is active. Also, the driver must step on the brakes at each ignition cycle before attempting to engage adaptive cruise control. The engine control module (ECM) looks to the BCM for the brake initial travel achieved signal indicating that the driver has stepped on the brakes before attempting to engage adaptive cruise control.

The vehicle speed must be above 45 km/h (28 MPH) and below 190 km/h (118 MPH) for the adaptive cruise control System to be engaged. In the engaged state, the adaptive cruise control System allows the driver to override the controlled vehicle speed temporarily while still remaining in the engaged state.

Cruise Inhibited

Active Safety Control Module Inhibits

The active safety control module inhibits the adaptive cruise control system when certain conditions exist. Refer to Active Safety Control Module Scan Tool Information for details.

Cruise Disengaged

Active Safety Control Module Disengagement

The Adaptive Cruise Control System disengages when certain conditions occur. Refer to Active Safety Control Module Scan Tool Information for details.

Vehicle Ahead

With input from the front camera module and front long range radar, the active safety control module will issue a command via serial data to turn on the green Vehicle Ahead Indicator. This is an indication that the Forward Collision System is ready to assist.

With input from the Frontview Camera Module and front long range radar module, the Active Safety Control Module evaluates collision threats in the vehicle's forward path and alerts the driver of a potential collision. Alerts will only be possible if the system has detected a vehicle ahead and turned on the green Vehicle Ahead indicator. The active safety control module will send a command via serial data to turn on the forward collision alert telltale when approaching a vehicle directly ahead too quickly. The active safety control module will also send a command via serial data to pulse the driver seat (if equipped) or create a beeping noise through the speakers when approaching a vehicle directly ahead too quickly.

With the input from the Frontview Camera Module, front long range radar and front short range radar, the active safety control module provides a boost to the driver's commanded braking as much as is needed to potentially avoid a frontal impact. Integrated brake assist may activate when the brake pedal is applied quickly by providing a boost to braking based on the speed of approach and distance to a vehicle ahead. The driver can override this behavior by releasing the brake pedal or pressing the accelerator pedal.

With the input from the front camera module and front long range radar, the active safety control module prepares the vehicle's braking system to reduce brake response time. Once the collision is deemed unavoidable, and if the driver still does not react more aggressively, braking is applied automatically. The system may help reduce collision damage and may even help avoid some crashes at very low speeds.

With input from the Frontview Camera Module the Active Safety Control Module will issue a warning via serial data to the instrument cluster to turn on the lane departure warning telltale when the system detects that the vehicle has unintentionally crossed a lane marking. In addition, an audible alert or haptic alert will signal the driver the vehicle has unintentionally left the lane. The memory seat module will command three pulses to the left or right side of the seat depending on the lane departure direction. The front view camera is located behind the windshield, looking out at the road ahead and detecting any lane markings. The system can be turned off by using the lane departure warning switch.

The lane departure warning telltale will be illuminated green when the system is ready to assist and will be a flashing an amber color when crossing the lane unintentionally.

The front long range radar and frontview camera scans the road environment to detect targets within its specified field of view. With input from the front radar and front view camera the active safety control module controller then makes throttle and/or brake commands to the engine control module (ECM) and electronic brake control module (EBCM) via the serial data circuit in order to control the vehicle acceleration/deceleration based on the data from the radar. The ECM and EBCM provide throttle control and automatic braking needed for proper cruise speed adjustment.

Adaptive Cruise Control Temporarily Unavailable

The active safety control module will send this message if the adaptive cruise control has been disengage or disabled. There are many reasons that can cause this, some will also set DTCs. Check vehicle for DTCs and also check the adaptive cruise control enable and disengage scantool data. Definitions of parameters can be found in Active Safety Control Module Scan Tool Information.

Service Driver Assist System

Service Adaptive Cruise Control and Service Front Camera

The message is set if the Active Safety Control Module is not communicating to the instrument cluster. Check vehicle for DTCs.

On/Off switch
Set/decrease switch
Resume/increase switch

On/Off Switch

Set/Decrease Switch

Resume/Increase Switch

The initial push of the gap switch recalls the current setting and activates the display. Subsequent pushes of the gap switch will change the gap setting.

Adaptive Cruise Control Temporarily Unavailable

The active safety control module will send this message if the adaptive cruise control has been disengage or disabled. There are many reasons that can cause this, some will also set DTCs. Check vehicle for DTCs and also check the adaptive cruise control enable and disengage scan tool data. Definitions of parameters can be found in active safety control module scan tool information.

Service Driver Assist System

Service Adaptive Cruise Control and Service Front Camera

The message is set if the active safety control module is not communicating to the instrument cluster. Check vehicle for DTCs.

Set Speed

Follow Distance

Vehicle Ahead Indicator

The adaptive cruise control system will engage and adjust vehicle speeds based on the activation of the following cruise switches

On/off
Set/decrease
Resume/increase

Active Safety Control Module Inhibits

The active safety control module inhibits the adaptive cruise control system when certain conditions exist. Refer to Active Safety Control Module Scan Tool Information for details.

Active Safety Control Module Disengagement

The Adaptive Cruise Control System disengages when certain conditions occur. Refer to Active Safety Control Module Scan Tool Information for details.

Scheme 28

Scheme 28: Side Blind Alert Block Diagram

Callout	Component Name
DA	Serial Data
HW	Hard-Wired
DB	Serial Data - GMLAN Low Speed
HW	Hard-Wired
HW	Hard-Wired
B218R	B218R Side Object Sensor Module - Right
B218L	B218L Side Object Sensor Module - Left
A11	A11 Radio
A9A	A9A Outside Rearview Mirror - Driver
A9B	A9B Outside Rearview Mirror - Passenger

The side blind zone alert system is a feature that utilizes two side object sensor modules to provide enhanced customer convenience by sensing and reporting to the driver that an object is present in one of the driver's side blind zones. This is communicated to the driver by illuminating an icon on the left or right side view mirror, depending on what side of the vehicle the object is detected. This lane change assist system is radar based system in which the sensors transmit and receives energy that is reflected from external objects and used to determine if that object is an object of interest. Although this system is intended to help drivers avoid lane change crashes, it does not replace driver vision and therefore should be considered a lane change aid.

The side blind zone alert system is made up of the following components

Left side object sensor module
Right side object sensor module
Driver outside rearview mirror
Passenger outside rearview mirror

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of objects nearby. The left side object sensor is the master that communicates on serial data. There is a private communication network between the left and right sensors. The scan tool is able to communicate only with the left sensor.

When an object is detected in the left side blind zone, the side object sensor module sends a message to the right sensor through serial data. The right sensor then supplies voltage to illuminate the visual indicator on the left side outside rear view mirror. When an object is detected in the right side blind zone, the right side object sensor will supply a voltage to illuminate the visual indicator on the right side outside rear view mirror. Each sensor is supplied B+ and ground.

Outside Rearview Mirrors

SIDE BLIND ZONE ALERT OFF

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. When the message is displayed, the indicators may remain illuminated at all times, notifying the driver that the side blind zone system should not be relied upon when changing lanes. Check vehicle for DTCs to determine the cause of this notification.

SIDE DETECTION SYSTEM UNAVAILABLE

This message indicates that the system has been temporarily disabled because the sensor is blocked or can otherwise not accurately detect vehicles or objects. Verify there is no damage to rear fascia or there are any bumper stickers that may interfere with the radar signals. Ask the customer if any of the following circumstances were present when the system became unavailable: towing a trailer, having a bike rack attached, mud, dirt, snow, ice, or slush build-up on the rear fascia, heavy rainfall, or excessive road spray.

Scheme 29

Scheme 29: Rear Cross Traffic Alert Block Diagram

Callout	Component Name
HW	Hard-Wired
DA	Serial Data
DB	Serial Data - GMLAN Low Speed
DB	Serial Data - GMLAN Low Speed
HW	Hard-Wired
HW	Hard-Wired
B218R	B218R Side Object Sensor Module - Right
B218L	B218L Side Object Sensor Module - Left
A11	A11 Radio
K40	K40 Seat Memory Control Module
P45LR	Seat Haptic Movement Motor - Driver Left Rear
P45RR	Seat Haptic Movement Motor - Driver Right Rear

The rear cross traffic alert system is a feature that utilized two side object sensor modules to provide enhanced customer convenience while backing up by sensing and providing warnings to the driver on impending rear cross traffic. The rear cross traffic alert system is designed to detect and track moving objects as small as a 125cc motorcycle with rider within a specified coverage zone behind the vehicle. The system is designed to alert the driver, with a visual display and either an audible sound or a haptic warning, if equipped and enabled, to the presence of moving objects of interest that may cause a collision with the host vehicle. Although the system is intended to assist drivers in backing up, it does not replace driver's vision. The driver is responsible to check carefully for objects outside of the coverage zone (e.g., a fast approaching vehicle) for a safe backing maneuver.

The side blind zone alert system is made up of the following components

Left side object sensor module
Right side object sensor module
Visual Display Icons located on the infotainment display screen
Audio system chime
Haptic safety seat (if equipped)

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of moving objects nearby. The left side object sensor is the master that communicates on serial data. There is a private communication network between the left and right sensors. The scan tool is able to communicate only with the left sensor.

When a moving object is detected in the left rear cross traffic zone while the engine is running and the transmission in reverse, the side object sensor module sends a serial data message to the human interface module and memory seat module to provide alerts. Each sensor is supplied B+ and ground.

Display Icons

The rear cross traffic alert system visual alert display consists of two visual icons, one on each side of the display screen of the rearview camera display, that are used to alert the driver on rear cross traffic from each side of the host vehicle respectively. In addition to visual indicators, the audio system will beep (if enabled) and the haptic safety seat will vibrate (if equipped and enabled). Refer to owner's manual for vehicle customization.

Audio or Haptic Notification

REAR CROSS TRAFFIC ALERT OFF

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. Since the side object sensors are also used for side blind zone alert and/or lane change alert, these feature will also be inoperative. Check vehicle for DTCs to determine the cause of this notification.

SIDE DETECTION SYSTEM TEMPORARILY UNAVAILABLE

This message indicates that the system has been temporarily disabled because the sensors are blocked or can otherwise not accurately detect vehicles or objects. Verify there is no damage to rear fascia or there are any bumper stickers that may interfere with the radar signals. Ask the customer if any of the following circumstances that present when the system became unavailable: mud, dirt, snow, ice, or slush build-up on the rear fascia, heavy rainfall, or excessive road spray.
