Adjustable Pedal System Cadillac SRX II рестайлинг

Fastener Tightening Specifications

Fastener Tightening Specifications

Scheme 1

Diagnostic Code Index

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

Ground is supplied at all times to the adjustable pedal switch. When the pedal switch is pressed, a 5 V reference voltage is applied through the switch contacts and the switch signal circuit to the memory seat control module. The memory seat control module then commands the adjustable pedals motor to move in response to the switch signal.

Conditions for Running the DTC

The memory seat control module must be powered.

Conditions for Setting the DTC

The forward and rearward switch signal circuits are active at the same time.

Action Taken When the DTC Sets

Adjustable pedals operation will be disabled.

Conditions for Clearing the DTC

1. The current DTC will clear and set the code to history 3 s after the fault is no longer present and the power mode changes to OFF then back to ACC or RUN.
2. The history DTC will clear after 50 consecutive fault-free ignition cycles have occurred.

Reference Information

Schematic Reference

Adjustable Pedal Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Adjustable Pedals Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Ignition ON, vehicle in P (Park), observe the scan tool Adjustable Pedal Control Switch parameters while pressing the adjustable pedal switch in both directions. The readings should change between Inactive and Active for both directions.

Circuit/System Testing

1. Ignition OFF and all vehicle systems OFF, scan tool disconnected, disconnect the harness connector at the S1 Adjustable Pedal Control Switch. It may take up to 2 min for all vehicle systems to power down.
2. Test for less than 10 ohms between the ground circuit terminal 1 and ground. If 10 ohms or greater Ignition OFF. Test for less than 2 ohms in the ground circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, repair the open/high resistance in the ground connection. If less than 10 ohms
3. Ignition ON.
4. Verify the scan tool Adjustable Pedal Control Switch parameter is Inactive. If not Inactive Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module. Test for infinite resistance between the signal circuit terminal 3 for a short to ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance, replace the K40 Seat Memory Control Module. Test for infinite resistance between the signal circuit terminal 5 for a short to ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance, replace the K40 Seat Memory Control Module. If Inactive
5. Install a 3 A fused jumper wire between the signal circuit terminal 3 and the ground.
6. Verify the scan tool Adjustable Pedals Direction Command parameter is Forward. If not Forward Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module. Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If Forward
7. Install a 3 A fused jumper wire between the signal circuit terminal 5 and ground.
8. Verify the scan tool Adjustable Pedals Direction Command parameter is Rearward. If not Rearward Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module. Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If Rearward
9. Test or replace the S1 Adjustable Pedal Control Switch.

Component Testing

1. Ignition OFF, disconnect the harness connector at the S1 Adjustable Pedal Control Switch. It may take up to 2 m for all vehicle systems to power down.
2. Test for infinite resistance between the signal terminal 3 and the ground terminal 1 with the switch in the open position. If less than infinite resistance, replace the S1 Adjustable Pedal Control Switch. If infinite resistance
3. Test for less than 2 ohms between the signal terminal 3 and ground terminal 1 with the switch in the closed position. If 2 ohms or greater, replace the S1 Adjustable Pedal Control Switch. If less than 2 ohms
4. Test for infinite resistance between the signal terminal 5 and the ground terminal 1 with the switch in the open position. If less than infinite resistance, replace the S1 Adjustable Pedal Control Switch. If infinite resistance
5. Test for less than 2 ohms between the signal circuit terminal 5 and ground terminal 1 with the switch in the closed position. If 2 ohms or greater, replace the S1 Adjustable Pedal Control Switch. If less than 2 ohms
6. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

1. «Control Module References»(/cadillac/srx/ii-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for S40 Memory Seat Control Module programming and setup.

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The memory seat control module monitors the location of the adjustable pedals using the adjustable pedals position sensor. The adjustable pedals position sensor is supplied with 5 V reference and ground circuits from the memory seat control module. The position sensor signal circuits are referenced from ground within the memory seat control module. The signal voltage monitored by the module ranges from 0.22-4.75 V and is determined by the wiper location on the resistor within the position sensor.

The memory seat control module must be powered.

B3606 01

The analog input from the adjustable brake pedal position sensor is greater than 4.75 V, the sensor will be considered out of range and the memory seat control module will set this DTC.

B3606 06

The analog input from the adjustable brake pedal position sensor is less than 0.22 V, the sensor will be considered out of range and the memory seat control module will set this DTC.

B3606 5A

This DTC will set if the memory seat control module is controlling the motor in one direction and the adjustable brake pedal position sensor is tracking the motor in the opposite direction. The sensor is either mounted or wired incorrectly, or the polarity of the motor control circuits are reversed.

B3606 61

This DTC will set if the memory seat control module is driving the adjustable pedal motor but does not see a voltage change from the adjustable brake pedal position sensor.

Memory recall functions will be suspended.

1. The current DTC will become a history DTC when the fault is no longer present and the ignition has been cycled.
2. The history DTC will clear after 50 consecutive fault-free ignition cycles have occurred.

Schematic Reference

Adjustable Pedal Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Adjustable Pedals Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool Adjustable Pedals Position Sensor parameters. The readings should be between 1.5 V and 3.4 V and change while adjusting the pedals position.

B3606 01 and B3606 06

1. Ignition OFF, scan tool disconnected, all doors closed, all accessories OFF, open and close drivers door, disconnect the harness connector at the M16 Adjustable Pedal Assembly. It may take up to 2 m for all vehicle systems to power down.
2. Test for less than 10 ohms between the low reference circuit terminal 4 and ground. If 10 ohms or greater Ignition OFF, disconnect the X5 harness connector at the K40 Seat Memory Control Module. Test for less than 2 ohms in the low reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If less than 10 ohms
3. Ignition ON.
4. Test for 4.8-5.2 V between the 5 V reference circuit terminal 6 and ground. If 4.8 V or less Ignition OFF, disconnect the X5 harness connector at the K40 Seat Memory Control Module. Test for infinite resistance between the 5 V reference circuit and ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance Test for less than 2 ohms in the 5 V reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If greater than 5.2 V Ignition OFF, disconnect the X5 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 1 V between the 5 V reference circuit and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V, replace the K40 Seat Memory Control Module.
5. Verify the scan tool Adjustable Pedals Horizontal Position parameter is less than 0.45 V. If 0.45 V or greater Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 1 V between the signal circuit terminal 5 and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V, replace the K40 Seat Memory Control Module. If less than 0.45 V
6. Install a 3 A fused jumper wire between the signal circuit terminal 5 and the 5 V reference circuit terminal 6.
7. Verify the scan tool Adjustable Pedals Horizontal Position parameter is greater than 4.75 V. If 4.75 V or less Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If greater than 4.75 V
8. Test or replace the K40 Seat Memory Control Module.

B3606 61

1. Ignition ON, verify that no other adjustable pedal DTCs are present. If other adjustable pedal DTCs are set, diagnose those DTCs first. If no other adjustable pedal DTCs are set
2. Ignition OFF, disconnect the harness connector at the M16 Adjustable Pedal Assembly.
3. Connect a test lamp between the motor control circuits terminal 2 and terminal 3.
4. Ignition ON, verify the test lamp illuminates while commanding the adjustable pedals to move in both directions with a scan tool. If the test lamp does not illuminate Ignition OFF, remove the test lamp, disconnect the X4 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 2 ohms in each of the control circuits end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If the test lamp illuminates
5. Test or replace the M16 Adjustable Pedal Assembly.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Brake Pedal Assembly Replacement»(/cadillac/srx/ii-2012-2016/remont/mechanical-hydraulic/#hydraulic-brake-system)
2. «Control Module References»(/cadillac/srx/ii-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for memory seat control module programming and setup.

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

After replacement of adjustable pedal mechanical components or if the memory seat control module is reprogrammed or replaced, the adjustable pedals softstop positions must be learned.

The memory seat control module must be powered.

This DTC will set if the pedals actuator softstops are not learned.

Manual and memory adjustable pedals operation will be disabled.

1. The current DTC will become a history DTC when the fault is no longer present and the ignition has been cycled.
2. The history DTC will clear after 50 consecutive fault-free ignition cycles have occurred.

Schematic Reference

Adjustable Pedal Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Adjustable Pedals Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, verify that no other adjustable pedal DTCs are present. If other adjustable pedal DTCs are set, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list) to diagnose those DTCs first. If no other adjustable pedal DTCs are set
2. Observe the scan tool Adjustable Pedals Softstop Learn Status parameter. The parameter reading should be Learned. If not the specified value, perform the scan tool Learn Adjustable Pedals Softstops procedure. Refer to «Adjustable Pedal System Calibration»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) If the DTC resets
3. Replace the K40 Memory Seat Control Module.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for memory seat control module programming and setup.

Symptoms - Adjustable Pedals

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) before using the symptom table in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Adjustable Pedals Description and Operation»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the adjustable pedal system. Refer to «Checking Aftermarket Accessories»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
2. Inspect the adjuster cables for proper connections or damage.
3. Inspect the adjuster screws and slides for damage or conditions which may obstruct movement.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to Adjustable Pedals Malfunction in order to diagnose the symptom.

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The adjustable pedal assembly is moved forward or backward by a motor which is fixed to the brake pedal actuator with a drive cable to the accelerator pedal actuator. The memory seat control module controls the adjustable pedal motor by applying battery voltage to one of the outputs and ground to the other. The adjustable pedal motor is bidirectional and the direction of the pedal assembly travel is determined by which of the motor control circuits is switched to battery positive voltage while the other is grounded. The adjustable pedal forward and rearward switches are inputs to the memory seat control module. When the switch is operated to the forward or rearward direction, it supplies a ground path for the signal inputs from the memory seat control module.

Schematic Reference

Adjustable Pedal Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Adjustable Pedals Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/cadillac/srx/ii-2012-2016/remont/body-electrical/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Verify DTC B3604, B3605, B3606, or B3607 is not set. If any of the DTCs are set, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/cadillac/srx/ii-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list) .
2. Ignition ON, observe the scan tool Adjustable Pedals Control Switch and Adjustable Pedal Direction Command parameters while cycling the adjustable pedal switch between the FWD and RWD position. The appropriate parameter should change between Active and Inactive as commanded. If the parameters do not change between the specified values, refer to «Adjustable Pedal Switch Circuit Malfunction»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .
3. Verify the scan tool Adjustable Pedals Horizontal Position parameter is between 0.45-4.55 V. If not within the specified range, refer to «Adjustable Pedal Position Sensor Circuit Malfunction»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .
4. Command the adjustable pedals to move forward and rearward. The pedals should move in the commanded direction. If the pedals do not move in the commanded direction, refer to «Adjustable Pedal Motor Circuit Malfunction»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .

Adjustable Pedal Switch Circuit Malfunction

1. Ignition OFF and all vehicle systems OFF, scan tool disconnected, disconnect the harness connector at the S1 Adjustable Pedal Control Switch. It may take up to 2 min for all vehicle systems to power down.
2. Test for less than 10 ohms between the ground circuit terminal 1 and ground. If 10 ohms or greater Ignition OFF. Test for less than 2 ohms in the ground circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, repair the open/high resistance in the ground connection. If less than 10 ohms
3. Ignition ON.
4. Verify the scan tool Adjustable Pedal Control Switch parameter is Inactive. If not Inactive Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module. Test for infinite resistance between the signal circuit terminal 3 for a short to ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance, replace the K40 Seat Memory Control Module. Test for infinite resistance between the signal circuit terminal 5 for a short to ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance, replace the K40 Seat Memory Control Module. If Inactive
5. Install a 3 A fused jumper wire between the signal circuit terminal 3 and the ground.
6. Verify the scan tool Adjustable Pedals Direction Command parameter is Forward. If not Forward Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module. Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If Forward
7. Install a 3 A fused jumper wire between the signal circuit terminal 5 and ground.
8. Verify the scan tool Adjustable Pedals Direction Command parameter is Rearward. If not Rearward Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module. Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If Rearward
9. Test or replace the S1 Adjustable Pedal Control Switch.

Adjustable Pedal Position Sensor Circuit Malfunction

1. Ignition OFF, scan tool disconnected, all doors closed, all accessories OFF, open and close drivers door, disconnect the harness connector at the M16 Adjustable Pedal Assembly. It may take up to 2 m for all vehicle systems to power down.
2. Test for less than 10 ohms between the low reference circuit terminal 4 and ground. If 10 ohms or greater Ignition OFF, disconnect the X5 harness connector at the K40 Seat Memory Control Module. Test for less than 2 ohms in the low reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If less than 10 ohms
3. Ignition ON.
4. Test for 4.8-5.2 V between the 5 V reference circuit terminal 6 and ground. If 4.8 V or less Ignition OFF, disconnect the X5 harness connector at the K40 Seat Memory Control Module. Test for infinite resistance between the 5 V reference circuit and ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance Test for less than 2 ohms in the 5 V reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If greater than 5.2 V Ignition OFF, disconnect the X5 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 1 V between the 5 V reference circuit and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V, replace the K40 Seat Memory Control Module.
5. Verify the scan tool Adjustable Pedals Horizontal Position parameter is less than 0.45 V. If 0.45 V or greater Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 1 V between the signal circuit terminal 5 and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V, replace the K40 Seat Memory Control Module. If less than 0.45 V
6. Install a 3 A fused jumper wire between the signal circuit terminal 5 and the 5 V reference circuit terminal 6.
7. Verify the scan tool Adjustable Pedals Horizontal Position parameter is greater than 4.75 V. If 4.75 V or less Ignition OFF, disconnect the X6 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If greater than 4.75 V
8. Test or replace the K40 Seat Memory Control Module.

Adjustable Pedal Motor Circuit Malfunction

1. Ignition ON, verify that no other adjustable pedal DTCs are present. If other adjustable pedal DTCs are set, diagnose those DTCs first. If no other adjustable pedal DTCs are set
2. Ignition OFF, disconnect the harness connector at the M16 Adjustable Pedal Assembly.
3. Connect a test lamp between the motor control circuits terminal 2 and terminal 3.
4. Ignition ON, verify the test lamp illuminates while commanding the adjustable pedals to move in both directions with a scan tool. If the test lamp does not illuminate Ignition OFF, remove the test lamp, disconnect the X4 harness connector at the K40 Seat Memory Control Module, ignition ON. Test for less than 2 ohms in each of the control circuits end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K40 Seat Memory Control Module. If the test lamp illuminates
5. Test or replace the M16 Adjustable Pedal Assembly.

Perform Diagnostic Repair Verification after completing the repair.

1. «Brake and Accelerator Pedal Adjuster Switch Replacement»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system)
2. «Brake Pedal Assembly Replacement»(/cadillac/srx/ii-2012-2016/remont/mechanical-hydraulic/#hydraulic-brake-system)
3. «Control Module References»(/cadillac/srx/ii-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for S40 Memory Seat Control Module programming and setup.

The memory seat module monitors the locations of both pedal assemblies in order to prevent a step over condition from occurring. Any time adjustable pedal system components are replaced, such as a memory seat module or pedal position sensors, the system must be calibrated. The calibration procedure allows the memory seat module to store the position sensor value through the full range of pedal travel.

1. Install a scan tool.
2. Go to the Memory Seat Module, Special Functions menu.
3. Using the scan tool Output Controls operate the pedals to the full forward position.
4. Start the calibration procedure and allow the memory seat module to operate the pedals to the rearward stop and return to the forward stop without activating any switch inputs.

Removal Procedure

1. Disable the supplemental inflatable restraint (SIR) system. Refer to «SIR Disabling and Enabling»(/cadillac/srx/ii-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove the lower steering column shroud (1). Refer to «Steering Column Shroud Replacement»(/cadillac/srx/ii-2012-2016/remont/steering-column-switches/#steering-wheel-and-steering-column) .
3. Disconnect the brake and accelerator pedal adjuster switch electrical connector.
4. Compress the locking tabs and remove the brake and accelerator pedal adjuster switch (1).

Installation Procedure

1. Install the adjuster switch (1) to the steering column.
2. Connect the brake and accelerator pedal adjuster switch electrical connector.
3. Install the lower steering column shroud (1). Refer to «Steering Column Shroud Replacement»(/cadillac/srx/ii-2012-2016/remont/steering-column-switches/#steering-wheel-and-steering-column) .
4. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/srx/ii-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Move the adjustable pedal assembly to the full forward, front of vehicle position prior to removing components. Failure to place the adjustable pedal assembly in the full forward position may result in incorrect accelerator and brake pedal step-over height and improper adjustable pedal function.

1. Move the adjustable pedal assembly to the full forward, front of vehicle position.
2. Remove the driver knee bolster panel. Refer to «Driver Knee Bolster Panel Replacement»(/cadillac/srx/ii-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
3. Rotate the brake pedal adjuster actuator cable collar (1) counter clockwise and disconnect the cable from the brake and accelerator pedal adjuster actuator motor.
4. Release the brake and accelerator pedal adjuster position sensor harness from the brake pedal bracket clip (1).
5. Disconnect the brake and accelerator pedal adjuster position sensor harness electrical connector (2).
6. Position the harness aside.
7. Disconnect the accelerator pedal with position sensor assembly electrical connector.
8. Remove the accelerator pedal with position sensor assembly bolt (1).
9. Remove the accelerator pedal with position sensor assembly (1).
10. Remove the accelerator pedal adjuster actuator bolts (1).
11. Remove the accelerator pedal adjuster actuator (1) from the brake pedal assembly by sliding the actuator assembly downward.

1. Install the accelerator pedal adjuster actuator (1) to the brake pedal assembly.
2. Install the accelerator pedal adjuster actuator bolts (1) and tighten to 9 N.m (80 lb in).
3. Install the accelerator pedal with position sensor assembly (1).
4. Install the accelerator pedal with position sensor assembly bolt (1) and tighten to 9 N.m (80 lb in).
5. Install the brake and accelerator pedal adjuster position sensor harness to the brake pedal bracket clip (1).
6. Connect the brake and accelerator pedal adjuster position sensor harness electrical connector (2).
7. Install the brake pedal adjuster actuator cable to the accelerator pedal adjuster actuator motor.
8. Rotate the brake pedal adjuster actuator cable collar (1) clockwise to secure the cable to the brake and accelerator pedal adjuster actuator motor.
9. Connect the accelerator pedal with position sensor assembly electrical connector.
10. Calibrate the adjustable pedal system. Refer to «Adjustable Pedal System Calibration»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .
11. Remove the driver knee bolster panel. Refer to «Driver Knee Bolster Panel Replacement»(/cadillac/srx/ii-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Note. Move the adjustable pedal assembly to the full forward, front of vehicle position prior to removing components. Failure to place the adjustable pedal assembly in the full forward position may result in incorrect accelerator and brake pedal step-over height and improper adjustable pedal function.

1. Move the adjustable pedal assembly to the full forward, front of vehicle position.
2. Remove the accelerator pedal adjuster actuator (1). Refer to «Accelerator Pedal Adjuster Actuator Replacement»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .
3. Insert a square drive tool into the brake pedal adjuster actuator cable drive, rotate the brake and accelerator pedal adjuster actuator motor drive screw to extend the accelerator pedal adjuster actuator to the full rearward position.
4. Remove adjustable pedal actuator motor retainer by compressing the locking tabs (1).
5. Disconnect the accelerator pedal adjuster actuator lever arm from the actuator motor jack.
6. Slide the adjustable pedal actuator motor (1) upward and disengage the actuator motor jack and screw guide from the adjuster actuator.
7. Remove the brake and accelerator pedal adjuster actuator motor.

1. Install the brake and accelerator pedal adjuster actuator motor to the accelerator pedal adjuster actuator.
2. Slide the adjustable pedal actuator motor (1) downward and engage the actuator motor jack and screw guide in the adjuster actuator.
3. Connect the accelerator pedal adjuster actuator lever arm to the actuator motor jack.
4. Install actuator motor retainer by inserting the locking tabs (1) into the accelerator pedal adjuster actuator.
5. Insert a square drive tool into the brake pedal adjuster actuator cable drive, rotate the brake and accelerator pedal adjuster actuator motor drive screw to retract the accelerator pedal adjuster actuator to the full forward position.
6. Install the accelerator pedal adjuster actuator (1). Refer to «Accelerator Pedal Adjuster Actuator Replacement»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .

Note. Move the adjustable pedal assembly to the full forward, front of vehicle position prior to removing components. Failure to place the adjustable pedal assembly in the full forward position may result in incorrect accelerator and brake pedal step-over height and improper adjustable pedal function.

1. Move the adjustable pedal assembly to the full forward, front of vehicle position.
2. Remove the driver knee bolster. Refer to «Driver Knee Bolster Panel Replacement»(/cadillac/srx/ii-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
3. Release the brake pedal adjuster actuator cable locking collar (1) from the brake pedal adjuster actuator assembly by rotating the collar counterclockwise.
4. Release the brake pedal adjuster actuator cable locking collar (1) from the brake and accelerator adjuster actuator motor by rotating the collar counterclockwise.
5. Remove the brake pedal adjuster actuator cable from the adjustable pedal assembly.

1. Install the brake pedal adjuster actuator cable to the adjustable pedal assembly.
2. Engage the brake pedal adjuster actuator cable locking collar (1) to the brake and accelerator adjuster actuator motor by rotating the collar clockwise.
3. Engage the brake pedal adjuster actuator cable locking collar (1) to the brake pedal adjuster assembly by rotating the collar clockwise.
4. Install the driver knee bolster. Refer to «Driver Knee Bolster Panel Replacement»(/cadillac/srx/ii-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
5. Calibrate the adjustable pedal system. Refer to «Adjustable Pedal System Calibration»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .

Note. Move the adjustable pedal assembly to the full forward, front of vehicle position prior to removing components. Failure to place the adjustable pedal assembly in the full forward position may result in incorrect accelerator and brake pedal step-over height and improper adjustable pedal function.

1. Move the adjustable pedal assembly to the full forward, front of vehicle position.
2. Remove the driver knee bolster panel. Refer to «Driver Knee Bolster Panel Replacement»(/cadillac/srx/ii-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
3. Release the brake and accelerator pedal adjuster position sensor harness from the brake pedal bracket clip (1).
4. Disconnect the brake and accelerator pedal adjuster position sensor harness electrical connector (2).
5. Release the locking tabs and remove the brake and accelerator pedal position sensor (1) from the bracket on the brake pedal arm.

1. Install the brake and accelerator pedal position sensor (1) to the bracket on the brake pedal arm.
2. Ensure the locking tabs on the brake and accelerator pedal position sensor bracket are firmly engaged on the sensor.
3. Calibrate the adjustable pedal system. Refer to «Adjustable Pedal System Calibration»(/cadillac/srx/ii-2012-2016/remont/memory-modules/#adjustable-pedal-system) .
4. Install the driver knee bolster panel. Refer to «Driver Knee Bolster Panel Replacement»(/cadillac/srx/ii-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Adjustable Pedals System Components

The adjustable pedals system consists of the following components

1. The adjustable pedals switch
2. The memory seat control module
3. The adjustable pedals assembly
4. The adjustable pedal position sensor

Scheme 2

Adjustable Pedals System Operation

The adjustable pedals are not operable when the cruise control is engaged.

The adjustable pedal system is controlled by the memory seat module. The adjustable pedals are moved forward or backward by a motor which is fastened to the brake pedal assembly with drive cables to the brake and accelerator pedal actuators.

The adjuster motor is controlled by the memory seat control module through two motor control circuits. In an inactive state both control circuits are closed to ground within the module. The memory seat control module drives the adjuster motor in the forward or rearward direction by closing the appropriate control circuit to battery voltage. The adjuster motor is bidirectional and the direction of the pedal assembly travel is determined by which of the motor control circuits is switched to battery voltage while the other remains grounded.

The adjustable pedals forward and rearward switches are inputs to the module. Battery voltage is supplied to the switch from the memory seat control module. When the switch is operated to the forward or rearward direction the forward or rearward switch signal circuit is closed to the battery voltage circuit. Battery voltage on a switch signal circuit indicates to the memory seat control module that the switch is active.

The memory seat control module monitors the locations of the adjustable pedals using the adjustable pedals position sensor. The position sensor is supplied with a 5 V reference and ground circuit from the memory seat control module. The position sensor signal circuit is referenced from ground within the module. The position sensor signal circuit voltage levels are used by the memory seat control module to determine the positions of the adjustable pedals when storing or recalling memory position settings. Anytime adjustable pedal system components are replaced, including the memory seat control module, the system will not operate until the calibration procedure has been performed. Refer to Adjustable Pedal System Calibration .

See also:
• Diagnostic System Check - Vehicle
• Strategy Based Diagnosis
• Diagnostic Procedure Instructions
• COMPONENT CONNECTOR END VIEWS - INDEX
• Circuit Testing
• Connector Repairs
• Testing for Intermittent Conditions and Poor Connections
• Wiring Repairs
• Control Module References
• Diagnostic Repair Verification
• Brake Pedal Assembly Replacement
• Diagnostic Trouble Code (DTC) List - Vehicle
• Checking Aftermarket Accessories
• SIR Warning
• SIR Disabling and Enabling
• Steering Column Shroud Replacement
• Driver Knee Bolster Panel Replacement
• Fastener Caution
• DTC B3604 or B3605
