Scheme 1
Scheme 1: Engine Covers and Component Assemblies (1 of 2) (LF1, LFW or LFX)
| Callout | Component Name |
|---|
| 1 | Right Camshaft Cover Assembly |
| 2 | Ignition Coil Bolt |
| 3 | Ignition Coil |
| 4 | Spark Plug |
| 5 | Intake Manifold Assembly |
| 6 | Left Camshaft Cover Assembly |
| 7 | Fuel Rail Noise Shield |
| 8 | Fuel Pump Cover |
| 9 | Fuel Pump Cover Bolt |
| 10 | Engine Flywheel |
| 11 | Engine Flywheel Bolt |
| 12 | Engine Assembly |
| 13 | Oil Pan Assembly |
| 14 | Engine Front Cover Assembly |
| 15 | Crankshaft Balancer |
| 16 | Crankshaft Balancer Bolt |
| 17 | Crankshaft Position Sensor Heat Shield Bolt - Large |
| 18 | Crankshaft Position Sensor Heat Shield |
| 19 | Crankshaft Position Sensor Heat Shield Bolt - Small |
Scheme 2
Scheme 2: Engine Covers and Component Assemblies (2 of 2)
| Callout | Component Name |
|---|
| 1 | Water Outlet Bolt |
| 2 | Water Outlet |
| 3 | Water Outlet O-ring |
| 4 | Water Outlet Seal |
| 5 | Knock Sensor Bolt |
| 6 | Knock Sensor |
| 7 | Engine Coolant Heater Assembly |
| 8 | Crankshaft Position Sensor Bolt |
| 9 | Crankshaft Position Sensor |
| 10 | Crankshaft Position Sensor O-ring |
| 11 | Right Cylinder Head Assembly |
| 12 | Right Cylinder Head Gasket |
| 13 | Lower Fuel Rail Noise Shield |
| 14 | Engine Cooling Thermostat Gasket |
| 15 | Engine Cooling Thermostat |
| 16 | Engine Cooling Thermostat Housing |
| 17 | Engine Cooling Thermostat Bolt - Short |
| 18 | Engine Cooling Thermostat Housing Bolt - Long |
| 19 | Fuel Feed Pipe Assembly |
| 20 | Fuel Feed Pipe Assembly Bolt |
| 21 | Fuel Feed Intermediate Pipe Assembly |
| 22 | Fuel Pump Gasket |
| 23 | Fuel Pump O-ring Seal |
| 24 | Fuel Pump |
| 25 | Fuel Pump Bolt |
| 26 | Left Cylinder Head Assembly |
| 27 | Left Cylinder Head Gasket |
| 28 | Oil Level Indicator |
| 29 | Oil Level Indicator Handle O-ring |
| 30 | Oil Level Indicator Tube Bolt |
| 31 | Oil Level Indicator Tube |
| 32 | Oil Level Indicator Tube O-ring |
| 33 | Oil Filter Adapter Assembly |
| 34 | Engine Short Block Assembly |
| 35 | Oil Pump Assembly |
| 36 | Timing Drive Assembly |
Scheme 3
Scheme 3: Camshaft Cover Assembly
| Callout | Component Name |
|---|
| 250 | Left Camshaft Cover |
| 251 | Left Camshaft Cover Gasket |
| 252 | Right Camshaft Cover |
| 253 | Right Camshaft Cover Gasket |
| 254 | Camshaft Cover Spark Plug Port Seal |
| 255 | Camshaft Cover Bolt |
| 256 | Camshaft Cover Bolt Insulator |
| 257 | Ignition Coil Bolt Thread Insert |
| 258 | Oil Fill Cap |
| 259 | Oil Fill O-ring |
| 260 | Left Camshaft Cover PCV Fitting |
| 261 | Right Camshaft Cover PCV Fitting Orifice |
| 262 | Oil Fill Tube |
| 263 | Left Camshaft Cover PCV Fitting O-ring |
| 265 | Left Camshaft Housing Cover Insulator |
| 266 | Right Camshaft Housing Cover Insulator |
| 704 | Ignition Coil |
| 705 | Ignition Coil Bolt |
| 719 | Spark Plug |
Scheme 4
Scheme 4: Camshaft Timing Components
| Callout | Component Name |
|---|
| 1 | Primary Timing Chain Tensioner Bolt |
| 2 | Left Secondary Timing Chain Shoe Bolt |
| 3 | Right Secondary Timing Chain Tensioner |
| 4 | Right Secondary Timing Chain Tensioner Gasket |
| 5 | Right Secondary Timing Chain Guide |
| 6 | Secondary Timing Chain |
| 7 | Camshaft Position Actuator Bolt |
| 8 | Exhaust Camshaft Position Actuator |
| 9 | Intake Camshaft Position Actuator |
| 10 | Right Secondary Timing Chain Guide |
| 11 | Left Camshaft Timing Chain Idler Sprocket |
| 12 | Camshaft Intermediate Drive Shaft Sprocket Bolt |
| 13 | Left Secondary Timing Chain Guide |
| 14 | Left Secondary Timing Chain Tensioner Gasket |
| 15 | Left Secondary Timing Chain Tensioner |
| 16 | Left Secondary Timing Chain Guide |
| 17 | Lower Primary Timing Chain Guide |
| 18 | Lower Primary Timing Chain Guide Bolt |
| 19 | Crankshaft Sprocket |
| 20 | Primary Timing Chain |
| 21 | Right Camshaft Timing Chain Idler Sprocket |
| 22 | Upper Primary Timing Chain Guide |
| 23 | Primary Timing Chain Tensioner Gasket |
| 24 | Primary Timing Chain Tensioner |
Scheme 5
Scheme 5: Intake Manifold
| Callout | Component Name |
|---|
| 1 | EVAP Solenoid |
| 2 | PCV Tube O-ring Seal |
| 3 | PCV Tube |
| 4 | MAP Sensor Bolt |
| 5 | MAP Sensor |
| 6 | Upper Intake Manifold |
| 7 | Upper Intake Manifold Bolt |
| 8 | Throttle Body Gasket |
| 9 | Throttle Body |
| 10 | Throttle Body Bolt |
Scheme 6
| Callout | Component Name |
|---|
| 1 | Fuel Rail Bolt |
| 2 | Fuel Pressure Sensor |
| 3 | Fuel Injector Retainer |
| 4 | Fuel Injector O-ring Seal |
| 5 | Fuel Injector Spacer |
| 6 | Fuel Injector |
| 7 | Fuel Injector Teflon Seal |
| 8 | Fuel Rail |
Scheme 7
Scheme 7: Cylinder Head Assemblies
| Callout | Component Name |
|---|
| 300 | Left Cylinder Head |
| 301 | Right Cylinder Head |
| 302 | Left Cylinder Head Gasket |
| 303 | Right Cylinder Head Gasket |
| 310 | Cylinder Head Bolt |
| 311 | Cylinder Head Front Bolt |
| 313 | Cylinder Head Water Jacket Hole Threaded Plug |
| 318 | Spark Plug Wire Sleeve |
| 319 | Cylinder Head Oil Gallery Expansion Plug - 14 mm |
| 320 | Exhaust Valve |
| 321 | Intake Valve |
| 322 | Valve Rocker Arm |
| 323 | Hydraulic Valve Lash Adjuster |
| 324 | Valve Stem Oil Seal |
| 325 | Valve Spring |
| 326 | Valve Spring Cap |
| 327 | Valve Stem Key |
| 328 | Cylinder Head Camshaft Front Thrust Bearing Cap |
| 328 | Cylinder Head Camshaft Front Thrust Bearing Cap |
| 329 | Camshaft Oil Seal Ring |
| 330 | Left Exhaust Camshaft |
| 331 | Left Intake Camshaft |
| 332 | Right Intake Camshaft |
| 333 | Right Exhaust Camshaft |
| 336 | Cylinder Head Camshaft Cap - Intermediate |
| 337 | Cylinder Head Camshaft Cap Bolt |
| 339 | Cylinder Head Oil Gallery Check Valve |
| 711 | Engine Coolant Temperature Sensor |
Scheme 8
Scheme 8: Engine Front Cover
| Callout | Component Name |
|---|
| 1 | Water Pump Pulley Bolt |
| 2 | Water Pump Pulley |
| 3 | Water Pump Assembly |
| 4 | Water Pump Pulley Gasket |
| 5 | Camshaft Position Actuator Solenoid Valve Seal |
| 6 | Camshaft Position Sensor Bolt |
| 7 | Camshaft Position Sensor |
| 8 | Camshaft Position Sensor O-ring Seal |
| 9 | Camshaft Position Actuator Solenoid Valve Bolt |
| 10 | Camshaft Position Actuator Solenoid Valve |
| 11 | Engine Front Cover Gasket |
| 12 | Engine Front Cover Locating Pin |
| 13 | Engine Front Cover |
| 14 | Engine Front Cover Bolt |
| 15 | Engine Front Cover Seal |
| 16 | Engine Front Cover Bolt |
| 17 | Water Pump Bolt |
Scheme 9
| Callout | Component Name |
|---|
| 1 | Oil Pump Cover Bolt |
| 2 | Oil Pump Bolt |
| 3 | Oil Pump Housing |
| 4 | Oil Pressure Relief Valve |
| 5 | Oil Pressure Relief Valve Spring |
| 6 | Oil Pressure Relief Valve Bore Plug |
| 7 | Oil Pressure Relief Valve Bore Plug Retainer Clip |
| 8 | Oil Pump Driven Gear |
| 9 | Oil Pump Drive Gear |
| 10 | Oil Pump Cover |
| 11 | Lower Primary Timing Chain Guide |
| 12 | Lower Primary Timing Chain Guide Bolt |
Scheme 10
Scheme 10: Engine Block Assembly
| Callout | Component Name |
|---|
| 1 | Crankshaft |
| 2 | Crankshaft Key |
| 3 | Crankshaft Lower Bearing |
| 4 | Crankshaft Bearing Cap |
| 5 | Crankshaft Bearing Cap Outboard Bolt |
| 6 | Crankshaft Bearing Cap Inboard Bolt |
| 7 | Crankshaft Bearing Thrust Cap |
| 8 | Piston Oil Nozzle Bolt |
| 9 | Piston Oil Nozzle |
| 10 | Oil Pan Locating Pin |
| 11 | Crankshaft Bearing Cap Side Bolt - Long |
| 12 | Engine Block Oil Gallery Threaded Plug - 14 mm |
| 13 | Crankshaft Rear Oil Seal Housing Assembly |
| 14 | Crankshaft Rear Oil Seal Housing Assembly Bolt |
| 15 | Transaxle Locating Pin |
| 16 | Piston and Connecting Rod Assembly |
| 17 | Engine Block Coolant Drain Threaded Plug - 14 mm |
| 18 | Engine Block Core Coolant Expansion Plug - 34.3 mm |
| 19 | Cylinder Head Locating Pin |
| 20 | Engine Block |
| 21 | Engine Block Oil Gallery Expansion Plug- 14 mm |
| 22 | Engine Front Cover Stud |
| 23 | Engine Block Oil Gallery Threaded Plug - 20 mm |
| 24 | Engine Block Oil Gallery Expansion Plug - 10 mm |
| 25 | Crankshaft Bearing Cap Side Bolt - Short |
| 26 | Crankshaft Upper Thrust Bearing #3 |
| 27 | Crankshaft Upper Bearing |
Scheme 11
Scheme 11: Piston, Rings, Bearing and Connecting Rod
| Callout | Component Name |
|---|
| 200 | Connecting Rod |
| 201 | Connecting Rod Bolt |
| 202 | Connecting Rod Bushing |
| 203 | Connecting Rod Bearing |
| 210 | Piston |
| 211 | Piston Pin |
| 212 | Piston Pin Retainer |
| 213 | Piston Upper Compression Ring |
| 214 | Piston Lower Compression Ring |
| 215 | Piston Oil Control Rail Ring |
| 216 | Piston Oil Control Ring Spacer |
Scheme 12
Scheme 12: Oil Pan Assembly
| Callout | Component Name |
|---|
| 1 | Oil Pan Baffle Scraper |
| 2 | Oil Pan Baffle Scraper Bolt |
| 3 | Oil Pump Suction Pipe Seal |
| 4 | Oil Pump Suction Pipe Bolt |
| 5 | Oil Pump Suction Pipe |
| 6 | Engine Oil Level Switch Bolt |
| 7 | Engine Oil Level Switch |
| 8 | Engine Oil Level Switch Clip |
| 9 | Engine Oil Level Switch Seal |
| 10 | Oil Pan Bolt - Long |
| 11 | Oil Pan Bolt |
| 12 | Oil Pan Drain Plug Seal |
| 13 | Oil Pan Drain Plug |
| 14 | Oil Pan |
Scheme 13
Scheme 13: Oil Filter Adapter
| Callout | Component Name |
|---|
| 1 | Oil Filter Adapter Gasket |
| 2 | Oil Filter Adapter |
| 3 | Oil Filter Adapter Bolt - Long |
| 4 | Oil Filter Fitting |
| 5 | Oil Filter |
| 6 | Engine Oil Pressure Sensor |
| 7 | Engine Oil Pressure Sensor Seal |
| 8 | Oil Filter Adapter Bolt |
Vehicle Identification Number
The Vehicle Identification Number (VIN) Derivative is located in two places on the engine and is a nine digit number stamped or laser etched onto the block at the vehicle assembly plant. If reading the identification number the following information can be obtained
- The first digit identifies the vehicle division.
- The second digit is the model year.
- The third digit identifies the assembly plant.
- The fourth through ninth digits are the last six digits of the Vehicle Identification Number (VIN).
Scheme 14
The engine block is marked with the VIN on a pad area on the left rear side (1).
Scheme 15
The engine block is marked with the VIN on a pad area on the center lower right side (1).
Engine Traceability Label
The engine traceability label is located in two places on the engine and consists of the broadcast code, bar code and sequence number. This label is used in engine and vehicle assembly plants and is not intended to be permanent. If it is missing refer back to the engine block VIN pad for the permanent ID.
Scheme 16
Scheme 16: Engine Traceability Label
One engine traceability label (1) is located on the left rear side of the engine block. This label is used in engine and vehicle assembly plants and is not intended to be permanent. If it is missing refer back to the engine block VIN pad for the permanent ID.
Scheme 17
Another engine traceability label (1) is located on the rear of the left cylinder head. This label is used in engine and vehicle assembly plants and is not intended to be permanent. If it is missing refer back to the engine block VIN pad for the permanent ID.
Engine Verification Label
The engine verification label is located in two places on the engine and consists of the broadcast code and bar code. This label is used in engine and vehicle assembly plants and is not intended to be permanent. If it is missing refer back to the engine block VIN pad for the permanent ID.
Scheme 18
Scheme 18: Engine Verification Label
One engine verification label (1) is located on the left side of the engine front cover below the exhaust camshaft position sensor. This label is used in engine and vehicle assembly plants and is not intended to be permanent. If it is missing refer back to the engine block VIN pad for the permanent ID.
Scheme 19
Another engine verification label (1) is located on the rear of the right cylinder head. This label is used in engine and vehicle assembly plants and is not intended to be permanent. If it is missing refer back to the engine block VIN pad for the permanent ID.
