Engine Mechanical - 2.8l or 3.0l - Special Tools and Equipment Cadillac SRX II

Illustration Tool Number/Description CH 48027 DW 100-010 EN 49495 J 21867 Digital Pressure Gauge DT 5590 J 5590 J 24254 Bearing and Seal Driver DW 110-030 Engine Overhaul Stand EN 8037 J 8037 Ring Compressor EN 8062 J 8062 Valve Spring Compressor - Head Off EN 8087 J 8087 Cylinder Bore Gauge EN 21867-6 J 21867-6 83 93 852 Oil Pressure Adapter Fitting EN 22738-B J 22738-B Valve Spring Tester EN 24254-A J 24254-A J 24254 Oil Seal Installer EN 28410 J 28410 Gasket Remover EN 28467-B DW 110-060 J 28467-B Universal Engine Support Fixture EN 29184 EN 47635 & J 41998-B EN 47635 J 29184 Oil Seal Installer EN 35667-A J 35667-A Cylinder Head Leakdown Tester EN 36462-A J 36462-A Engine Support Adapter Leg EN 37228 J 37228 KM J 37228 Seal Cutter EN 38416-2 J 38416-2 Crankshaft Button EN 39313 J 39313 Spark Plug Port Adapter EN 41712 J 41712 Oil Pressure Switch Socket EN 41816 J 41816 Crankshaft Balancer Remover EN 41998-B J 41998-B J 41998 Crankshaft Balancer Installer EN 42183 J 42183 Driver Handle EN 42385-700 J 42385-700 High Feature Thread Repair Kit EN 42385-2000 J 42385-2000 Thread Insert Kit EN 43690-A J 43690-A Rod Bearing Clearance Checking Tool EN 43965 J 43965 Thread Repair Extension Kit EN 45000 J 45000 KM J 45000 87 91 360 Seal Remover EN 45027 J 45027 Tensioner Tool EN 45059 J 45059 KM 470-B Angle Meter EN 45299 J 45299 Engine Preluber EN 46101 J 46101 Spark Plug Tube Seal Guide EN 46103 J 46103 Camshaft Actuator Valve Seal Installer EN 46104 J 46104 Water Pump Pulley Holding Tool EN 46106 J 46106 KM 652 Flywheel Holding Tool EN 46109 J 46109 Guide Pins EN 46110 EN 46110-EU J 46110-EU On-Vehicle Valve Spring Compressor EN 46112 Tensioner Retraction Pins EN 46114 Engine Lift Brackets EN 46116 KM 840 (Remover)/EN 47986 (Installer) 83 94 157 Valve Stem Seal Remover/Installer EN 46117 Valve Stem Key Remover/Installer EN 46119 Off-Vehicle Valve Spring Compressor Adapter EN 46120 Valve Guide Reamer EN 46121 Connecting Rod Guide Pin Set EN 46122 Camshaft Position Actuator Check-Ball Valve Remover/Installer EN 46745 J 43654 Piston Pin Clip Remover/Installer EN 47839 Crankshaft Rear Oil Seal Installation Tool EN 47909 Injector Bore and Sleeve Cleaning Kit EN 47971 Oil Pressure Gauge Adapter EN 48243 Engine Assembly Remove/Install Pallet EN 48244 Engine Assembly Remove/Install Pallet Supporter EN 48313 Timing Chain Retention Tool EN 48383 Camshaft Retaining Tool EN 48589-A EN 48589 Crankshaft Rotation Socket EN 48896 HP Fuel Pump Installation Alignment Gauge EN 49102 J 41818 & EN 47985 Crankshaft Bearing Cap Remover EN 49245 Injector Seal Installer Kit EN 49247 Injector Retaining Clip Installer EN 49248 Injector Rail Assembly Remover EN 49982 Timing Chain Retainer GE 6125-1B J 6125-1B KM J 7004 Slide Hammer Adapter GE 7872 J 7872 Magnetic Base Dial Indicator GE 8001 J 8001 Dial Indicator Set GE 28428-E J 28428-E High Intensity Black Light Kit GE 48326 Sealant Dispenser GE 8358 J 8358 Carbon Removal Brush CH 25033-C J 25033-C Pulley Installer CH 25034-C J 25034-C Pulley Remover EN 28467-501 J 28467-501 Engine Support Fixture Adapters EN 36857 J 36857 Engine Lift Bracket CH 42640 J 42640 Steering Column Anti-Rotation Pin
