BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| Air Conditioning Compressor Clutch Relay | In underhood junction block. |
| ACCY Relay | In underhood junction block. |
| CIGAR Relay | In rear junction block. |
| COOL FAN 1 Relay | In underhood junction block. |
| COOL FAN 2 Relay | In underhood junction block. |
| COOL FAN S/P Relay | In underhood junction block. |
| DAMPER Relay | In rear junction block. |
| DRL Relay | In underhood junction block. |
| ELC Relay | In rear junction block. |
| FOG LP Relay | In underhood junction block. |
| F/PMP Relay | In rear junction block. |
| FRT CTSY Relay | In rear junction block. |
| F/TNKDR REL Relay | In rear junction block. |
| HDLP HI BM Relay | In underhood junction block. |
| HDLP LO BM Relay | In underhood junction block. |
| HORN Relay | In underhood junction block. |
| IGN 1 Relay | In underhood junction block. |
| IGN 1 Relay | In rear junction block. |
| IGN 3 Relay | In rear junction block. |
| INT LP Relay | In rear junction block. |
| LK/CYL Relay | In rear junction block. |
| PARK Relay | In rear junction block. |
| PRK BRK A Relay | In rear junction block. |
| PRK BRK B Relay | In rear junction block. |
| PRK LP Relay | In rear junction block. |
| RAP Relay | In rear junction block. |
| REVERSE Relay | In rear junction block. |
| REV/LKOUT Relay | In rear junction block. |
| RR BLO Relay | In rear junction block. |
| RR CTSY Relay | In rear junction block. |
| RR DEFOG Relay | In rear junction block. |
| START 1 Relay | In underhood junction block. |
| TRK REL Relay | In rear junction block. |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location |
|---|---|
| Rear Compartment Relay Center | Under left rear seat. |
| Rear Junction Block | Under left rear seat. (Scheme 10) |
| Steering Column Fuse Holder | Near base of steering column. |
| Underhood Junction Block | On right side of engine compartment, near power steering pump. (Scheme 9) |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| Adaptive Lumbar Module (Right/Left) | In respective front seat back. |
| Automatic Level Control Module | Under rear of vehicle, near rear suspension carrier. |
| Blower Control Module | Under right side of dash, near center heater outlets. (Scheme 13) |
| Cellular Telephone Module | At front of rear compartment. |
| Continuously Variable Road Sensing Suspension (CVRSS) Module | Behind right rear seat back. (Scheme 8) |
| Cruise Control Module | On center rear of engine compartment, near power brake booster. (Scheme 12) |
| Dash Integration Module (DIM) | On right side of dash, near blower motor. (Scheme 13) |
| Door Module (Left Front) (LFDM) | In front of left front door, near radio speaker. |
| Door Module (Left Rear) (LRDM) | In front of left rear door, near radio speaker. |
| Door Module (Right Front) (RFDM) | In front of right front door, near radio speaker. |
| Door Module (Right Rear) (RRDM) | In front of right rear door, near radio speaker. |
| Electronic Brake Control Module (EBCM) | On left front corner of engine compartment, below air cleaner housing. (Scheme 7) |
| Front Heated Seat Module (Left/Right) | Under respective front seat. |
| Ignition Control Module (Bank 1) (ICM) | Under intake manifold top cover, right side of engine. |
| Ignition Control Module (Bank 2) (ICM) | Under intake manifold top cover, left side of engine. |
| Inflatable Restraint Sensing & Diagnostic Module (SDM) | Under right front seat. |
| Inflatable Restraint Side Impact Sensing Module (SISM) (Left) | On base of left "B" pillar, behind trim panel. |
| Inflatable Restraint Side Impact Sensing Module (SISM) (Right) | On base of right "B" pillar, behind trim panel. |
| Instrument Panel Integration Module (IPM) | Behind center of dash, above radio. |
| Memory Seat Module (MSM) | Under left front seat. |
| Navigation Data Processor | Under center of rear package shelf. |
| Passkey III Reader Exciter | On ignition switch. |
| Passkey III Theft Deterrent Module | Behind left side of dash, right of steering column. |
| Powertrain Control Module (PCM) | At left front corner of engine compartment, below air cleaner. |
| Radio Antenna Module | Above center rear of headliner. |
| Rear Blower Motor Resistor Module | At front of center console, near rear blower motor. |
| Rear Heated Seat Module (Left/Right) | In center of rear seat back. |
| Rear Integration Module (RIM) | Behind right side of rear seat back. (Scheme 8) |
| Rear Object Sensor Control Module | In right side of rear compartment. |
| Remote Keyless Entry (RKE) Module | Under rear package shelf. |
| Steering Column Tilt/Telescoping Module | Behind left side of dash, left of steering column. (Scheme 14) |
| Sun Roof Control Module | Above headliner, near rear of sun roof. |
| Theft Deterrent Module | Behind left side of dash, right of steering column. |
| TV Antenna Module Assembly | Under right side of rear package shelf. |
| Variable Steering Actuator | On left side of power steering rack. |
CONTROL UNITS LOCATION
MOTORS
| Component | Location |
|---|---|
| Air Inlet Actuator | Behind right side of dash, on HVAC module. (Scheme 13) |
| Air Mix Actuator (Driver) | Behind left side of dash, on HVAC module. |
| Air Mix Actuator (Passenger) | Behind right side of dash, on HVAC module. (Scheme 13) |
| Automatic Level Control Compressor | Under rear of vehicle, near rear suspension carrier. |
| Blower Motor | Behind right side of dash, on HVAC module. (Scheme 13) |
| Blower Motor (Rear) | At front of center console, below ashtray. |
| Cooling Fan Motors (Left/Right) | At front of engine compartment, behind radiator. |
| Idle Air Control (IAC) Valve | At rear of engine, on throttle body. (Scheme 3) |
| Mode Actuator | Behind left side of dash, on HVAC module. |
| Rear Mode Actuator | Under front of center console, near rear blower motor. |
| Starter Motor | At center of engine, under intake manifold. |
| Sun Roof Motor | Above headliner, near rear of sun roof. |
| Telescope Actuator | In steering column. |
| Tilt Actuator | In steering column. |
| Windshield Washer Pump | On side of windshield washer reservoir. |
| Windshield Wiper Motor | At right rear of engine compartment, near strut tower. (Scheme 12) |
MOTORS LOCATION
SENDING UNITS & SENSORS
| Component | Location |
|---|---|
| A/C Low Side Temperature Sensor | At rear of engine compartment, on A/C low side line. |
| A/C Pressure Sensor | On lower left front of engine, on A/C compressor. |
| A/C Temperature Sensor (Left/Right) | Under respective side of dash, in A/C duct. |
| Ambient Air Temperature Sensor | On center front of vehicle, near hood latch. |
| Ambient Light Sensor | On top of instrument cluster, in defogger grille. |
| Automatic Level Control Height Sensor | Under rear of vehicle, near rear suspension carrier. |
| Automatic Transaxle Fluid Temperature (TFT) Sensor | In transaxle assembly. (Scheme 11) |
| Automatic Transaxle Input Shaft Speed Sensor | In transaxle assembly. (Scheme 11) |
| Camshaft Position (CMP) Sensor | On front of right cylinder head. (Scheme 4) |
| Crankshaft Position (CKP) Sensor A | On left side of engine block, near base of engine oil level indicator. (Scheme 2) |
| Crankshaft Position (CKP) Sensor B | On left side of engine block, near base of engine oil level indicator. (Scheme 2) |
| Engine Coolant Temperature (ECT) Sensor | On right rear corner of engine, below exhaust gas recirculation valve. (Scheme 3) |
| Fuel Tank Pressure Sensor | On top of fuel tank. |
| Heated Oxygen Sensor (HO2S) Bank 1 Sensor 1 | On right side of engine, on exhaust manifold. (Scheme 4) |
| Heated Oxygen Sensor (HO2S) Bank 1 Sensor 2 | Near rear flange of catalytic converter. (Scheme 5) |
| Heated Oxygen Sensor (HO2S) Bank 2 Sensor 1 | On left side of engine, on exhaust manifold. (Scheme 6) |
| Heater Temperature Sensor (Right/Left) | Behind respective side of dash, in A/C duct. |
| Inside Air Temperature Sensor | Behind left side of dash, left of steering column. |
| Intake Air Temperature (IAT) Sensor | Part of mass air flow sensor. |
| Knock Sensor (KS) | On center top of engine, under manifold top cover. |
| Lateral Accelerometer Sensor | Under left rear seat. (Scheme 10) |
| Manifold Absolute Pressure (MAP) Sensor | On top of throttle body. (Scheme 3) |
| Mass Airflow (MAF) Sensor | In air intake duct. |
| Outside Moisture Sensor | At top center of windshield, near rearview mirror. |
| Steering Wheel Position Sensor (SWPS) | On base of steering column. (Scheme 14) |
| Sun Load Sensor (Right/Left) | On respective side of dash, in defroster grille. |
| Throttle Position (TP) Sensor | On throttle body. (Scheme 3) |
| Vehicle Speed Sensor (VSS) | On transaxle case extension. (Scheme 11) |
| Wheel Speed Sensors (4) | On back of each wheel hub. |
| Windshield Washer Fluid Level Sensor | On top of windshield washer reservoir. (Scheme 9) |
| Yaw Rate Sensor | Left side of rear compartment, near hinge. |
SENDING UNITS & SENSORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| Brake Pressure Modulator Valve (BPMV) | On left front corner of engine compartment, below air cleaner housing. (Scheme 7) |
| Evaporative Emissions (EVAP) Canister Purge Valve | On rear of engine, near throttle body. (Scheme 1) |
| Evaporative Emissions (EVAP) Canister Vent Valve | Under rear of vehicle, near left wheel. |
| Exhaust Gas Recirculation (EGR) Valve | On top right rear of engine, near throttle body. (Scheme 1) |
| Park Brake Release Solenoid | Under left side of dash, on park brake pedal. |
| Pressure Control Solenoid | In transaxle assembly. (Scheme 11) |
| Shift Interlock Solenoid | Under front of center console, on shifter. |
| Starter Solenoid | At center of engine, under intake manifold. |
| Torque Converter Clutch Pulse Width Modulation (TCC PWM) Solenoid Valve | In transaxle assembly. (Scheme 11) |
| Variable Effort Steering Actuator | On left side of power steering gear. |
| 1-2 Shift Solenoid Valve | In transaxle assembly. (Scheme 11) |
| 2-3 Shift Solenoid Valve | In transaxle assembly. (Scheme 11) |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| ABS/TCC Switch | Near top of brake pedal. |
| Automatic Transaxle Fluid Pressure Manual Valve Position Switch | In transaxle assembly. (Scheme 11) |
| Brake Fluid Level Switch | In master cylinder reservoir. (Scheme 12) |
| Coolant Level Switch | In bottom of coolant reservoir. |
| Engine Oil Level Switch | On left front side of engine, near A/C compressor. (Scheme 2) |
| Engine Oil Pressure Switch | On left side of engine, near oil filter adapter. (Scheme 2) |
| Left Front Seat Belt Switch | In seat belt buckle. |
| Park/Neutral Position (PNP) Switch | On transaxle, below throttle body. |
| Power Steering Pressure (PSP) Switch | On power steering high pressure line. |
| Stop Lamp/BTSI Switch | Near top of brake pedal. |
| Sun Roof Limit Switch | Above headliner, near sun roof. |
SWITCHES LOCATION
MISCELLANEOUS
| Component | Location |
|---|---|
| A/C Compressor Clutch | On lower right front corner of engine compartment, on A/C compressor. |
| Battery Thermistor | Under right rear seat, on battery. |
| Data Link Connector (DLC) | Under left side of dash, near steering column. |
| Radio Amplifier | Behind left side of rear seat back. |
| Rear Parking Assist Diagnostic Connector | At right side of rear compartment. |
| Stop Lamp Resistor | In rear compartment lid, in CHMSL harness. |
| Taillamp Resistor (Left/Right) | In respective rear corner of rear compartment lid, taped in harness. |
MISCELLANEOUS LOCATION
CONNECTORS
| Component | Location |
|---|---|
| C100 (20 Pin) | Left of engine compartment, near thermostat housing. |
| C101 (Black, 38 Pin) | Left of engine compartment, near coolant reservoir. |
| C102 (Black, 2 Pin) | Right front corner of engine compartment, near underhood fuse block. |
| C106 (Gray, 4 Pin) | Right rear corner of engine compartment, below windshield wiper motor. |
| C107 (Black, 3 Pin) | Right rear corner of engine, near rear cam cover. |
| C108 (Black, 8 Pin) (W/HID) | Left front corner of vehicle, near left headlamp. |
| C108 (Natural, 7 Pin) (W/O HID) | Left front corner of vehicle, near left headlamp. |
| C109 (Black, 8 Pin) (W/HID) | Right front corner of vehicle, near right headlamp. |
| C109 (Natural, 7 Pin) (W/O HID) | Right front corner of vehicle, near right headlamp. |
| C115 (Black, 10 Pin) | Left side of engine compartment, in transaxle. |
| C200 (Black, 30 Pin) | Left side of dash top, near windshield. |
| C201 (Black, 30 Pin) | Under right side of dash top, near windshield. |
| C202 (Black, 40 Pin) | Under left of dash, near base of steering column. |
| C203 (Black, 18 Pin) | Under right side of dash, near blower motor. |
| C204 (Gray, 6 Pin) | Under right side of upper dash pad, near back of inflatable restraint I/P module. |
| C205 (Black, 2 Pin) | Body harness, 44 cm from P101. |
| C206 (Black, 2 Pin) | Body harness, 44 cm from P101. |
| C220 (1 Pin) | Left front of center console, near rear blower motor. |
| C221 (1 Pin) | Left front of center console, near rear blower motor. |
| C300 (Black, 18 Pin) | Left center of passenger compartment, under driver seat. |
| C303 (Black, 30 Pin) | Left front of center console, near rear blower motor. |
| C304 (Black, 30 Pin) | Right front of center console, near rear blower motor. |
| C305 (Black, 30 Pin) | Left rear of passenger compartment, at base of sail panel. |
| C306 (Blue, 8 Pin) | Under left lower corner of rear seat back, near rear fuse block. |
| C307 (Black, 18 Pin) | Right center of passenger compartment, under right front seat. |
| C309 (Gray, 6 Pin) | Above right rear of headliner, near sun roof. |
| C312 (Blue, 8 Pin) | In front of center console, near rear blower motor. |
| C313 (Blue, 8 Pin) | In center console, near shifter. |
| C315 (1 Pin) | Right rear of passenger compartment, near battery. |
| C317 (4 Pin) | In left front seat, in seat back. |
| C320 (Blue, 8 Pin) | Near rear shelf panel, at base of sail panel. |
| C345 (Black, 30 Pin) | Behind rear seat back, on right side of electronics bay. |
| C346 (Black, 40 Pin) | Behind rear seat back, on right side of electronics bay. |
| C400 (Black, 6 Pin) | Left rear corner of rear compartment, near taillamp. |
| C401 (Black, 6 Pin) | Under left center rear of vehicle, near rear suspension. |
| C402 (Black, 8 Pin) | Left rear corner of rear compartment, near P404. |
| C403 (Black, 6 Pin) | Right rear corner of rear compartment, near taillamp. |
| C405 (Black, 3 Pin) | Right rear of passenger compartment, near rear shelf panel, on base of sail panel. |
| C407 (5 Pin) | Left rear corner of rear compartment, near left taillamp. |
| C408 (Black, 6 Pin) | Right rear of vehicle, behind right rear bumper fascia. |
| C420 (Black, 7 Pin) | Under right rear of vehicle, near wheelhouse. |
| C421 (Black, 2 Pin) | Rear of rear compartment lid, above license plate lamps. |
| C500 (Black, 18 Pin) | Left front corner of passenger compartment, near P500. |
| C502 (Natural, 10 Pin) | In left front door, near door trim panel. |
| C600 (Black, 18 Pin) | Right front corner of passenger compartment, near P600. |
| C603 (Natural, 10 Pin) | In right front door, near door trim panel. |
| C700 (Natural, 17 Pin) | Left side of passenger compartment, in door pillar, near P700. |
| C702 (Black, 18 Pin) | In left rear door, near door trim panel. |
| C800 (Natural, 17 Pin) | Right side of passenger compartment, near P800. |
| C802 (Black, 18 Pin) | In right rear door, near door trim panel. |
CONNECTORS LOCATION
GROUNDS
| Component | Location |
|---|---|
| G101 | Left side of engine compartment, on left core support. |
| G104 | Right side of engine compartment, below fuse block. |
| G105 | Right side of engine compartment, below underhood fuse block. |
| G106 | Lower left front corner of engine, on transmission case, below transmission connector. |
| G108 | Right rear of engine, below exhaust gas recirculation valve. |
| G109 | Lower left front corner of engine, below transmission connector. |
| G110 | Lower left front corner of engine, below transmission connector. |
| G200 | Left front corner of passenger compartment, under front of sill trim plate. |
| G201 | Right front corner of passenger compartment, under front of sill trim plate. |
| G300 | Under left front seat, on No. 2 bar. |
| G301 | Under left front corner of rear seat. (Scheme 10) |
| G303 | Left rear corner of passenger compartment, above rear shelf panel. |
| G304 | Right rear corner of passenger compartment, above rear shelf panel. |
| G306 | Under right front seat, near inflatable restraint sensing diagnostic module connector. |
| G307 | Under right side of rear seat, near battery. |
| G401 | Right rear corner of rear compartment, near C403. |
| G402 | Left rear corner of rear compartment, near C400. |
GROUNDS LOCATION
SPLICES
| Component | Location |
|---|---|
| S100 | In left headlamp harness, 46 cm from high beam headlamp connector. |
| S102 | In right headlamp harness, 46 cm from high beam headlamp connector. |
| S103 | In left headlamp harness, 52 cm from high beam headlamp connector. |
| S104 | In right headlamp harness, 52 cm from high beam headlamp connector. |
| S113 | In transaxle harness, 33.5 cm from C115. |
| S114 | In forward lamp harness, 10 cm from right headlamp breakout. |
| S117 | In engine harness, 54.1 cm from C101. |
| S118 | In engine harness, 25.9 cm from camshaft position sensor connector. |
| S119 | In engine harness, 25.9 cm from camshaft position sensor connector. |
| S120 | In engine harness, 54.1 cm from C101. |
| S126 | In forward lamp harness, 16.5 cm from right headlamp breakout. |
| S130 | In engine harness, 15 cm from EBCM & transmission breakout. |
| S131 | In engine harness, 7 cm from EBCM & transmission breakout. |
| S150 | In body harness, 63 cm from strut actuator. |
| S151 | In body harness, 63 cm from strut actuator. |
| S152 | In body harness, 63 cm from strut actuator. |
| S153 | In body harness, 63 cm from strut actuator. |
| S200 | Body harness, 70 cm from P101. |
| S201 | Body harness, 26 cm from P101. |
| S203 | I/P harness, 55.5 cm from radio connector. |
| S204 | I/P harness, 64.5 cm from radio connector. |
| S205 | I/P harness, 94.5 cm from radio connector. |
| S206 | I/P harness, 8 cm from instrument cluster breakout. |
| S208 | I/P harness, 10 cm from instrument cluster breakout. |
| S209 | I/P harness, 4 cm from left solar sensor breakout. |
| S210 | I/P harness, 22 cm from left solar sensor breakout. |
| S212 | I/P harness, 44 cm from left driver information center switch. |
| S219 | In body harness, 22.5 cm from P101. |
| S222 | In body harness, 15 cm from P100. |
| S224 | In body harness, 21.5 cm from P100. |
| S228 | In body harness, 15 cm from P100. |
| S230 | In I/P harness, 27 cm from right sunload temperature sensor breakout. |
| S232 | In I/P harness, 5 cm from left sunload temperature sensor breakout. |
| S234 | In body harness, 6.5 cm from audio amplifier breakout. |
| S235 | In body harness, 6.5 cm from audio amplifier breakout. |
| S236 | In body harness, 6.5 cm from audio amplifier breakout. |
| S249 | In steering column harness, near steering wheel control connector. |
| S250 | In steering column harness, near steering wheel control connector. |
| S251 | In steering column harness, near steering wheel control connector. |
| S253 | In steering column harness, near steering wheel control connector. |
| S254 | In steering column harness, near steering wheel control connector. |
| S255 | In steering column harness, near steering wheel control connector. |
| S256 | In steering column harness, near steering wheel control connector. |
| S257 | In steering column harness, near steering wheel control connector. |
| S258 | In steering column harness, near steering wheel control connector. |
| S259 | In steering column harness, near steering wheel control connector. |
| S260 | In steering column harness, near steering wheel control connector. |
| S274 | HVAC harness, 79.5 cm from air inlet actuator. |
| S275 | HVAC harness, 73 cm from air inlet actuator. |
| S278 | HVAC harness, 89.5 cm from air inlet actuator. |
| S300 | Body harness, 10 cm from left rear door breakout. |
| S301 | Body harness, 6.5 cm from left rear door breakout. |
| S302 | Body harness, 40 cm from C300 connector breakout. |
| S303 | Body harness, 14 cm from C300 connector breakout. |
| S305 | Body harness, 29 cm from cross-car breakout. |
| S306 | Body harness, 20 cm from cross-car breakout. |
| S307 | Body harness, 60 cm from cross-car breakout. |
| S309 | Headliner harness, 10 cm from overhead console breakout. |
| S310 | Rear heated seat back harness, 11.5 cm from C306 connector. |
| S311 | Rear heated seat back harness, 21.5 cm from C306 connector. |
| S312 | Left seat harness, 42 cm from left lumbar switch connector. |
| S313 (W/Power Seat) | Left seat harness, 52.5 cm from forward/back position sensor. |
| S313 (W/O Power Seat) | Left seat harness, 48.5 cm from left lumbar switch connector. |
| S314 | Right seat harness, 57 cm from right front heated seat module connector. |
| S315 | Right seat harness, 64 cm from right front heated seat module connector. |
| S316 | Console harness, 10 cm from compact disc player connector. |
| S317 | Console harness, 33 cm from rear blower switch connector. |
| S318 | Console harness, 4 cm from compact disc player breakout. |
| S319 | Console harness, 6.5 cm from compact disc player breakout. |
| S320 | Console trim harness, 12 cm from right heated seat switch connector. |
| S321 | Console trim harness, 19 cm from right heated seat switch connector. |
| S322 | Rear blower harness, 12.5 cm from rear blower motor connector. |
| S323 | Left seat harness, 33 cm from forward/back position sensor connector. |
| S324 | Left seat harness, 36 cm from forward/back position sensor connector. |
| S326 | Left seat harness, 47 cm from forward/back position sensor connector. |
| S327 | Left seat harness, 29.5 cm from C300 connector breakout. |
| S328 | Left lumbar harness, 50 cm from C314 connector. |
| S329 | Left lumbar harness, 50 cm from C314 connector. |
| S332 | Body harness, 14 cm from yaw rate sensor. |
| S360 | In OnStar(R) jumper harness, between connector C345 & breakout of vehicle interface unit connector. |
| S361 | In OnStar(R) jumper harness, between connector C345 & breakout of vehicle interface unit connector. |
| S401 | Body harness, 27.5 cm from cellular telephone handset connector. |
| S402 | Left taillamp harness, 8 cm from P402. |
| S403 | Right taillamp harness, 8 cm from P403. |
| S404 | Rear compartment lid lamp harness, 27 cm from right rear license lamp. |
| S405 | Rear compartment lid lamp harness, 27 cm from right rear license lamp. |
| S406 | Rear compartment lid lamp harness, 27 cm from left rear license lamp. |
| S407 | In ultrasonic rear parking assist harness, 36.5 cm from C408. |
| S408 | Trailer harness, 13.5 cm from taillamp connector. |
| S410 | In back-up lamp harness, 27 cm from left back-up lamp connector. |
| S413 | In back-up lamp harness, 14.5 cm from C400. |
| S420 | In back-up lamp harness, 42.5 cm from left back-up lamp connector. |
| S421 | In main body harness, 20.5 cm from rear speaker breakout. |
| S422 | In main body harness, 10.5 cm from rear speaker breakout. |
| S428 | In main body harness, 10.5 cm from rear speaker breakout. |
| S500 | Left front door trim harness, 57 cm from power door lock switch connector. |
| S501 | Left front door trim harness, 52 cm from power door lock switch connector. |
| S600 | Right front door trim harness, 52 cm from power window switch connector. |
| S601 | Right front door trim harness, 25 cm from power window switch connector. |
| S700 | Left rear door trim harness, 18 cm from C702 connector. |
| S701 | Left rear door trim harness, 22 cm from C702 connector. |
| S800 | Right rear door trim harness, 18 cm from C802 connector. |
| S801 | Right rear door trim harness, 22 cm from C802 connector. |
| SP301 | Under left front corner of rear seat. (Scheme 10) |
| SP302 | In body harness, left front of passenger compartment, near center of front door sill. |
| SP308 | In body harness, right front of passenger compartment, near center of front door sill. |
| SP310 | Above center front of headliner, near overhead console. |
SPLICES LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
