FLOOR JACK
When supporting vehicle with floor jack, the support should be placed at suspension lift points or frame lift points. (Scheme 5)- (Scheme 7).
Scheme 5
Scheme 6
Scheme 7
BUMPER JACK
Bumper jack should be used only on models that are supplied as original equipment and only to change flat tire. If vehicle is not supplied with a bumper type jack do not lift vehicle by the bumper at any time.
Ensure that hoist manufacturers instructions are followed. Do not allow hoist or adapters to contact suspension, exhaust or steering components. Frame contact must be made and adapters used to lift vehicle. (Scheme 5)- (Scheme 7).
FRAME CONTACT HOIST
Proper adapters must contact vehicle in areas shown in illustrations. Adapters must be positioned to distribute load and support vehicle in a stable manner. DO NOT allow lift pads to contact exhaust system components. (Scheme 8)and (Scheme 9).
Scheme 8
Scheme 9
SUSPENSION CONTACT HOIST
Hoist should contact lower control arms or front crossmember, and rear axle as shown in illustrations. (Scheme 10)and (Scheme 11).
