Front Suspension System Cadillac Escalade GMT900

Suspension Front 20 illustrations ~4976 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Brake Hose Bracket Bolt9 N.m80 lb in
Brake Hose Clip Bolts12 N.m106 lb in
Electronic Suspension Control (ESC) Sensor Bracket Bolt25 N.m18 lb ft
Hub and Bearing Assembly to Steering Knuckle Bolts180 N.m133 lb ft
Lower Ball Joint Stud Nut (With Captured Washer)125 N.m92 lb ft
Lower Ball Joint Stud Nut (Without Captured Washer)50 N.m + 130 degrees37 lb ft + 130 degrees
Lower Control Arm Nut - 2500 Series80 N.m59 lb ft
Lower Control Arm to Frame Nuts175 N.m129 lb ft
Shock Absorber Electrical Connector17 N.m13 lb ft
Shock Absorber Module to Frame Nuts - 1500 Series50 N.m37 lb ft
Shock Absorber Module to Lower Control Arm Bolt - 1500 Series50 N.m37 lb ft
Shock Absorber Module to Lower Control Arm Nut - 2500 Series80 N.m59 lb ft
Shock Absorber Tenon Nut - 1500 Series50 N.m37 lb ft
Shock Absorber Tenon Nut - 2500 Series24 N.m17 lb ft
Shock Absorber to Lower Control Arm Bolts - 2500 Series80 N.m59 lb ft
Spring Jounce Bumper Nut - 2500 Series30 N.m22 lb ft
Stabilizer Shaft Insulator Clamp Bolts50 N.m37 lb ft
Stabilizer Shaft Link Nuts24 N.m17 lb ft
Suspension Position Sensor Bolt12 N.m106 lb in
Torsion Bar Support Link Bolt/Screw95 N.m70 lb ft
Upper Ball Joint Stud Nut50 N.m37 lb ft
Upper Control Arm to Frame Nuts190 N.m140 lb ft
Wheel Speed Sensor Mounting Bolt18 N.m13 lb ft

Scheme 1

Scheme 1: Stabilizer Shaft Replacement (2500)
Scheme 1: Stabilizer Shaft Replacement (2500)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the engine shield, if equipped. Refer to Engine Shield Replacement . Remove the stabilizer shaft link. Refer to Stabilizer Shaft Link Replacement (2500) . Remove the stabilizer shaft insulator. Refer to Stabilizer Shaft Insulator Replacement (2500) .
1Stabilizer Shaft

Scheme 2

Scheme 2: Stabilizer Shaft Replacement (1500)
Scheme 2: Stabilizer Shaft Replacement (1500)
CalloutComponent Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front stabilizer shaft links. Refer to Stabilizer Shaft Link Replacement (1500) . Remove the front stabilizer shaft insulators. Refer to Stabilizer Shaft Insulator Replacement (1500) .
1Front Stabilizer Shaft

Scheme 3

Scheme 3: Stabilizer Shaft Link Replacement (2500)
Scheme 3: Stabilizer Shaft Link Replacement (2500)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the engine shield, if equipped. Refer to Engine Shield Replacement . Remove the stabilizer shaft link. Refer to Stabilizer Shaft Link Replacement (2500) . Remove the stabilizer shaft insulator. Refer to Stabilizer Shaft Insulator Replacement (2500) .
1Stabilizer Shaft Link Retaining Nut CAUTION: Refer to Fastener Caution . Procedure Remove all traces of the original adhesive patch. Apply Threadlocker GM P/N 12345382 (Canadian P/N 10953489) BLUE LOCTITE # 242 on the threads of the bolt. Tighten: 23 N.m (17 lb ft)
2Front Stabilizer Shaft Insulator (Qty: 4)
3Front Stabilizer Shaft Washer (Qty: 2)
4Front Stabilizer Shaft Spacer
5Front Stabilizer Shaft Washer
6Front Stabilizer Shaft Bolt
CAUTION
Refer to Fastener Caution .

Scheme 4

Scheme 4: Stabilizer Shaft Link Replacement (1500)
Scheme 4: Stabilizer Shaft Link Replacement (1500)
CalloutComponent Name
Preliminary Procedure: Remove the tire and wheel. Refer to Tire and Wheel Removal and Installation .
1Stabilizer Shaft Link Nut CAUTION: Refer to Fastener Caution . Procedure Remove all traces of the original adhesive patch. Apply Threadlocker GM P/N 12345382 (Canadian P/N 10953489) BLUE LOCTITE # 242 on the threads of the bolts. Tighten: 23 N.m (17 lb ft)
2Stabilizer Shaft Link Bolt
3Stabilizer Shaft Link Washer (Qty: 2)
4Stabilizer Shaft Link Insulator (Qty: 4)
5Stabilizer Shaft Link Spacer
CAUTION
Refer to Fastener Caution .

Scheme 5

Scheme 5: Stabilizer Shaft Insulator Replacement (1500)
Scheme 5: Stabilizer Shaft Insulator Replacement (1500)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the engine shield, if equipped. Refer to Engine Shield Replacement .
1Stabilizer Shaft Clamp Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 50 N.m (37 lb ft)
2Stabilizer Shaft Clamp
3Stabilizer Shaft Insulator Tip: Ensure that the slit in the stabilizer shaft insulator is installed toward the rear of the vehicle.
CAUTION
Refer to Fastener Caution .

Scheme 6

Scheme 6: Stabilizer Shaft Insulator Replacement (2500)
Scheme 6: Stabilizer Shaft Insulator Replacement (2500)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the engine shield, if equipped. Refer to Engine Shield Replacement .
1Stabilizer Shaft Clamp Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 50 N.m (37 lb ft)
2Stabilizer Shaft Clamp
3Stabilizer Shaft Insulator Tip: Ensure that the slit in the insulator is facing the front of the vehicle when installed.
CAUTION
Refer to Fastener Caution .

Lower Control Arm Ball Joint Replacement (1500 )

Special Tools

  1. CH 41805: Ball Joint Remover Install Kit
  2. CH 49240: Ball Joint Crimper and Install Kit

For equivalent regional tools, refer to Special Tools .

Removal Procedure

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the wheel drive shaft, if needed. Refer to «Wheel Drive Shaft Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts__wheel-drive-shaft-replacement-1500) .
  3. Remove the steering knuckle from the vehicle. Refer to «Steering Knuckle Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Using a hammer chisel, remove the locking tabs (1) from the ball joint body.
  5. Position the CH 41805: kit (1) on the lower control arm.
  6. Using the CH 41805: kit (1) and a shallow socket, remove the lower ball joint (2) from the control arm.

Installation Procedure

  1. Position the ball joint in the lower control arm.
  2. Using the and a shallow socket CH 41805: kit (2), CH-49240-3 (1), CH-49240-1 (4) and the CH-49240-2 (2), install the ball joint.
  3. Reverse the CH-49240-2 (3).
  4. Using the CH 41805: kit (2), CH-49240-3 (1), CH-49240-1 (4) and the CH-49240-2 (2), collapse the edge of the ball joint to create the lock tabs (5). Tighten the CH-49240-3 to 250 N.m (184 lb ft).
  5. Rotate the CH 41805: kit (2) 180 degrees and repeat the process.
  6. Install the wheel drive shaft, if needed. Refer to «Wheel Drive Shaft Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts__wheel-drive-shaft-replacement-1500) .
  7. Install the steering knuckle in the vehicle. Refer to «Steering Knuckle Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  8. Install the lower ball joint stud nut and tighten to: First Pass 50 N.m (37 lb ft) Final Pass additional 95 degrees
  9. Remove the supports and lower the vehicle.

Lower Control Arm Ball Joint Replacement (2500, 3500 )

Special Tools

  1. CH 41805: Ball Joint remover/Installer
  2. CH 49240: Ball Joint Crimper and Install Kit

For equivalent regional tools, refer to Special Tools .

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the knuckle from the vehicle. Refer to «Steering Knuckle Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  3. Using a hammer and a chisel, remove the lock tabs (1) from the lower ball joint.
  4. Using the CH 41805: remover/installer (1) and the appropriate adapter, remove the lower ball joint (2).
  1. Position the lower ball joint (1) in the lower control arm.
  2. Align the lower ball joint grease fitting (1) with the channel (2) in the lower control arm
  3. Using the CH 41805: remover/installer (1), the appropriate adapter (3), and the CH 49240: install Kit (2), install the lower ball joint.
  4. Ensure that the ball joint (2) is fully seated against the lower control arm (1).
  5. Using a hammer and a punch, created the lock tabs (1) for the lower ball joint.
  6. Install the knuckle. Refer to «Steering Knuckle Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  7. Install the lower ball joint stud nut and tighten to: First Pass 50 N.m (37 lb ft) Final Pass additional 95 degrees
  8. Remove the support and lower the vehicle.

Note. If removing the knuckle to service the lower ball joint, only perform steps 3, 5, 6, and 7.

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the wheel drive shaft, if equipped. Refer to «Wheel Drive Shaft Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts__wheel-drive-shaft-replacement-1500) .
  4. Remove the wheel bearing and hub assembly. Refer to «Front Wheel Hub, Bearing, and Seal Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  5. Remove the outer tie rod from the knuckle. Refer to «Steering Linkage Outer Tie Rod Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/electronic-steering/#power-steering-system) .
  6. Separate the upper control arm from the knuckle. Refer to «Upper Control Arm Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  7. Separate the lower control arm from the knuckle. Refer to «Lower Control Arm Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement-1500) .
  8. Remove the knuckle from the vehicle.
  1. Install the lower ball joint in the knuckle. Refer to «Lower Control Arm Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement-1500) .
  2. Install upper ball joint in the knuckle. Refer to «Upper Control Arm Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  3. Connect the outer tie rod to the knuckle. Refer to «Steering Linkage Outer Tie Rod Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/electronic-steering/#power-steering-system) .
  4. Install the wheel bearing and hub assembly. Refer to «Front Wheel Hub, Bearing, and Seal Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  5. Install the wheel drive shaft, if equipped. Refer to «Wheel Drive Shaft Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts__wheel-drive-shaft-replacement-1500) .
  6. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  7. Remove the support and lower the vehicle.
  8. Verify the wheel alignment. Refer to «Wheel Alignment Measurement»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-measurement) .
  1. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  2. Remove the wheel drive shaft, if equipped. Refer to «Wheel Drive Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts) .
  3. Remove the wheel bearing and hub assembly. Refer to «Front Wheel Hub, Bearing, and Seal Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Disconnect the outer tie rod from the knuckle. Refer to «Steering Linkage Outer Tie Rod Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/electronic-steering/#power-steering-system) .
  5. Support the lower control arm.
  6. Separate the upper ball joint from the knuckle. Refer to «Upper Control Arm Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  7. Separate the lower ball joint from the knuckle. Refer to «Lower Control Arm Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement-2500) .
  8. Remove the knuckle from the vehicle.
  1. Install the knuckle on the lower ball joint. Refer to «Lower Control Arm Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement-2500) .
  2. Install the upper ball joint in the knuckle. Refer to «Upper Control Arm Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  3. Connect the outer tie rod to the knuckle. Refer to «Steering Linkage Outer Tie Rod Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/electronic-steering/#power-steering-system) .
  4. Install the wheel bearing and hub assembly. Refer to «Front Wheel Hub, Bearing, and Seal Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  5. Install the wheel drive shaft, if equipped. Refer to «Wheel Drive Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts) .
  6. Remove the support from the lower control arm.
  7. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .

Scheme 7

Scheme 7: Upper Control Arm Replacement (1500)
Scheme 7: Upper Control Arm Replacement (1500)
CalloutComponent Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front tire and wheel assembly. Refer to Tire and Wheel Removal and Installation .
1Upper Ball Joint Nut CAUTION: Refer to Fastener Caution . Procedure Disconnect the speed sensor electrical connector. Place a suitable support under the lower control arm and load the suspension. Use the J-42188-B to separate the ball joint from the steering knuckle. See Special Tools . Remove and discard the ball joint nut. Replace with NEW only. Tighten: 50 N.m (37 lb ft) Special Tools: J-42188-B Ball Joint Separator. See Special Tools .
2Upper Control Arm Nut (Qty: 2) Tighten: 190 N.m (140 lb ft)
3Upper Control Arm Alignment Cam (Qty: 4)
4Upper Control Arm Bolt (Qty: 2)
5Upper Control Arm Procedure: Verify wheel alignment. Refer to Wheel Alignment Specifications
CAUTION
Refer to Fastener Caution .

Special Tools

J-42188-B Ball Joint Separator. See Special Tools .

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the retaining bolt for the brake hose and the wheel speed sensor brackets.
  4. Remove the nut at the upper ball joint. Discard the nut.
  5. Disconnect the upper control arm from the steering knuckle using the J-42188-B . See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  6. Remove the upper control arm nuts and the adjustment cams.
  7. Remove the upper control arm.
  1. Install the upper control arm.
  2. Install the upper control arm bolts and tighten to 190 N.m (140 lb ft).
  3. Connect the upper control arm to the steering knuckle.
  4. Install the new nut to the upper ball joint stud and tighten to 50 N.m (39 lb ft).
  5. Install the retaining bolts for the brake hose and wheel speed sensor brackets and tighten to 9 N.m (80 lb in).
  6. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  7. Lower the vehicle.
  8. Verify the wheel alignment. Refer to «Wheel Alignment Specifications»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-specifications) .

Lower Control Arm Replacement (2500)

Special Tools

  1. J 43631: Ball Joint Separator
  2. J 45851: Ball Joint Separator Protector Adapters

Note. For vehicles equipped with the aluminum control arm, the ball joint is NOT serviced separately. If the ball joint is found to have excessive wear and is damaged, replace the lower control arm as an assembly.

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the stabilizer shaft link from the lower control arm. Refer to «Stabilizer Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Remove the torsion bars. Refer to «Torsion Bar and Support Assembly Replacement (Link Style)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) or «Torsion Bar and Support Assembly Replacement (Bushing Style)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  5. Remove the shock absorber. Refer to «Shock Absorber Replacement (2500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  6. Remove the wheel drive shaft. Refer to «Wheel Drive Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts) .
  7. Remove and discard the lower ball joint retaining nut.
  8. Using the J 43631: separator and the J 45851: adapters, remove the lower ball joint from the steering knuckle.
  9. Remove the lower control arm nuts (1) and washers (2).
  10. Remove the control arm bolts (3).
  11. Remove the control arm (4).
  1. Install the lower control arm (4).
  2. Install the lower control arm bolts (3).
  3. Install the washers (2).
  4. Install the lower control arm retaining nuts (1) and tighten to 175 N.m (129 lb ft).
  5. Install the lower ball joint into the steering knuckle.
  6. Install the lower ball joint nut. For those vehicles with the captured washer, tighten the nut to 125 N.m (92 lb ft). For those vehicles without the captured washer, tighten the nut to 50 N.m plus 130 degrees (37 lb ft).
  7. Install the wheel drive shaft. Refer to «Wheel Drive Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts) .
  8. Install the shock absorber. Refer to «Shock Absorber Replacement (2500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  9. Install the torsion bars. Refer to «Torsion Bar and Support Assembly Replacement (Link Style)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) or «Torsion Bar and Support Assembly Replacement (Bushing Style)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  10. Remove the support for the knuckle and upper control arm.
  11. Install the stabilizer shaft link to the lower control arm. Refer to «Stabilizer Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  12. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  13. Remove the supports and lower the vehicle.
  14. Verify the front end alignment. Refer to «Wheel Alignment Measurement»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-measurement) .

Lower Control Arm Replacement (1500)

Special Tools

  1. J 43631: Ball Joint Separator
  2. J 45851: Ball Joint Separator Protector Adapters

Note. For vehicles equipped with the aluminum lower control arm, the ball joint is NOT service separately. If the ball joint in the aluminum lower control arm is found to have excessive wear and is damaged, replace the lower control arm as an assembly.

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the stabilizer shaft link from the lower control arm. Refer to «Stabilizer Shaft Link Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Remove the wheel drive shaft, if equipped. Refer to «Wheel Drive Shaft Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts__wheel-drive-shaft-replacement-1500) .
  5. Using mechanics wire or equivalent, support the knuckle assembly and upper control arm.
  6. Remove and discard the lower ball joint retaining nut.
  7. Remove the lower shock module bolts from the lower control arm.
  8. Using the J 43631 and the J 45851 , remove the lower ball joint from the steering knuckle. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  9. Remove the lower control arm nuts (1) and washers (2).
  10. Remove the control arm bolts (3).
  11. Remove the control arm (4).
  1. Install the lower control arm (4).
  2. Install the lower control arm bolts (3).
  3. Install the washers (2).
  4. Install the lower control arm retaining nuts (1) and tighten to 175 N.m (129 lb ft).
  5. Install the lower ball joint in the steering knuckle.
  6. Install the lower ball joint nut. For those vehicles with the captured washer, tighten the nut to 125 N.m (92 lb ft). For those vehicles without the captured washer, tighten the nut to 50 N.m plus 130 degrees (37 lb ft).
  7. Install the lower shock absorber module mount bolts and tighten to 50 N.m (37 lb ft).
  8. Remove the support for the steering knuckle and upper control arm.
  9. Install the wheel drive shaft, if equipped. Refer to «Wheel Drive Shaft Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts__wheel-drive-shaft-replacement-1500) .
  10. Install the stabilizer shaft link to the lower control arm. Refer to «Stabilizer Shaft Link Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  11. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  12. Remove the support and lower the vehicle.
  13. Align the front end. Refer to «Wheel Alignment Measurement»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-alignment/#wheel-alignment-system__wheel-alignment-measurement) .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the nut from the jounce bumper stud.
  4. Remove the jounce bumper.
  1. Install the jounce bumper.
  2. Install the nut to the jounce bumper stud and tighten to 30 N.m (22 lb ft).
  3. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  4. Lower the vehicle.

Tools Required

J 43631 Ball Joint Remover. See Special Tools .

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the brake rotor. Refer to «Front Brake Rotor Replacement (2500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/mechanical-hydraulic/#disc-brake-system) or «Front Brake Rotor Replacement (1500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/mechanical-hydraulic/#disc-brake-system__front-brake-rotor-replacement-1500-series) .
  4. Use the J 43631 to press the stud from the wheel bearing/hub. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  1. Install a new stud. Use washers and a wheel nut and pull the new stud into the hub.
  2. Install the brake rotor. Refer to «Front Brake Rotor Replacement (2500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/mechanical-hydraulic/#disc-brake-system) or «Front Brake Rotor Replacement (1500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/mechanical-hydraulic/#disc-brake-system__front-brake-rotor-replacement-1500-series) .
  3. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  4. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  3. Remove the rotor. Refer to «Front Brake Rotor Replacement (2500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/mechanical-hydraulic/#disc-brake-system) .
  4. Remove the wheel speed sensor and brake hose mounting bracket bolt from the steering knuckle.
  5. Disconnect the electrical connection for the wheel speed sensor.
  6. Remove the wheel driveshaft nut retaining cover.
  7. Wrap shop towel around the inner and outer wheel drive shaft booth..
  8. Remove the wheel driveshaft assembly retaining nut and washer from the wheel driveshaft assembly. Refer to «Wheel Drive Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts)
  9. Remove the wheel hub and bearing mounting bolts.
  10. Remove the wheel hub and bearing and splash shield from the vehicle.
  11. Remove the O-ring seal from the steering knuckle bore.
  12. Remove the wheel speed sensor from the wheel hub and bearing.
  13. Clean and inspect the O-ring seal.
  14. Replace the seal if the following conditions exist: Nicks Cuts Dry or brittle Compression set
  1. Clean all corrosion or contaminates from the steering knuckle bore and the hub and bearing assembly.
  2. Lubricate the steering knuckle bore with wheel bearing grease or the equivalent.
  3. Install the O-ring to the steering knuckle.
  4. Install the wheel speed sensor to the wheel hub and bearing. Tighten: Tighten the sensor mounting bolt to 18 N.m (13 lb ft).
  5. Install the wheel hub and bearing and splash shield to the vehicle.
  6. Install the wheel hub and bearing mounting bolts. Tighten: Tighten the wheel hub to knuckle bolts to 180 N.m (133 lb ft).
  7. Install the nut and washer retaining the wheel drive shaft assembly to the wheel hub and bearing. Refer to «Wheel Drive Shaft Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/axle-shafts/#wheel-drive-shafts)
  8. Connect the electrical connection for the wheel speed sensor.
  9. Install the wheel speed sensor and brake hose mounting bracket bolt to the steering knuckle. Tighten: Tighten the bolt to 12 N.m (106 lb in).
  10. Install the rotor. Refer to «Front Brake Rotor Replacement (2500 Series)»(/cadillac/escalade/gmt900-2006-2014/remont/mechanical-hydraulic/#disc-brake-system) .
  11. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/escalade/gmt900-2006-2014/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
  12. Lower the vehicle.

Scheme 8

Scheme 8: Front Wheel Hub, Bearing, and Seal Replacement (1500)
Scheme 8: Front Wheel Hub, Bearing, and Seal Replacement (1500)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the brake rotor. Refer to Front Brake Rotor Replacement (1500 Series) . Remove the speed sensor, if equipped. For hybrid vehicles, refer to Front Wheel Speed Sensor Replacement . For non-hybrid vehicles, refer to Front Wheel Speed Sensor Replacement . For vehicles equipped with 4WD, remove the wheel drive shaft from the wheel bearing and hub assembly. Refer to Wheel Drive Shaft Replacement (1500) .
1Wheel Bearing and Hub Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 180 N.m (133 lb ft)
2Wheel Hub and Bearing Assembly Tip: New wheel bearing comes with a wheel speed sensor installed.
CAUTION
Refer to Fastener Caution .

J 36202 Torsion Bar Unloading/Loading Tool. See Special Tools .

Note. When lifting the vehicle to service the torsion bars or related components, DO NOT lift the vehicle by the front suspension. Use the appropriate hoist and lift the vehicle by the frame.

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Install the J 36202 to the adjustment arm and the support assembly. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  3. Using the J 36202 , increase the tension on the adjustment arm until the load is removed from the adjustment bolt and the adjuster nut. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Remove the adjustment bolt (3) and the adjuster nut (4) from the support assembly (1).
  5. Remove the J 36202 , allowing the torsion bar to unload. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  6. Remove the adjustment arm (2) by sliding the torsion bar forward.
  7. Remove the adjustment arm (2) from the support assembly (1).
  8. Remove the upper link mounting bolt (1) and nut (2) from the link (3).
  9. Remove the torsion bar support assembly (4).
  10. Remove the torsion bar from the vehicle.
  1. Position the torsion bar in the lower control arm.
  2. Install the torsion bar in the support assembly.
  3. Install the upper link mounting nut (2) and the bolt (1) in the link (3). Tighten: Tighten the nut to 95 N.m (70 lb ft).
  4. Install the adjustment arm (2) in the support assembly (1).
  5. Install the adjuster bolt (3) and the adjustment nut (4).
  6. Slide the torsion bar rearward until the torsion bar is fully seated in the adjustment arm.
  7. Install the J 36202 on the adjustment arm and the support assembly. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  8. Using the J 36202 , increase the tension on the adjustment arm in order to load the torsion bar. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  9. Align the reference marks, turn the adjuster bolt the same amount of turns as it took to remove it.
  10. Remove the J 36202 from the support assembly. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  11. Remove the safety stand and lower the vehicle.
  12. Measure the Z height. Refer to «Trim Height Inspection»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#suspension-general-diagnosis__trim-height-inspection) .

J 36202 Torsion Bar Unloading/Loading Tool. See Special Tools .

Note. When lifting the vehicle to service the torsion bars or related components, DO NOT lift the vehicle by the front suspension. Use the appropriate hoist to lift the vehicle by the frame.

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Install the J 36202 to the adjustment arm and the crossmember. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  3. Using the J 36202 , increase the tension on the adjustment arm until the load is removed from the adjustment bolt and the adjuster nut. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Remove the adjustment bolt (3) and the adjust nut (4) from the crossmember (1).
  5. Remove the J 36202 , allowing the torsion bar to unload. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  6. Remove the adjustment arm (2) by sliding the torsion bar forward.
  7. Remove the torsion bar crossmember bolt (4) from the weld nut (1).
  8. Remove the crossmember (2) from the crossmember mount (3).
  9. Remove the torsion bar from the crossmember.
  10. Remove the torsion bars from the vehicle.
  1. Position the torsion bar in the lower control arm.
  2. Install the torsion bar in the crossmember (2) on the crossmember mount (3).
  3. Install the torsion bar crossmember bolt (4) in the weld nut (1) and tighten to 110 N.m (81 lb ft)..
  4. Install the adjustment arm (2) in the crossmember (1).
  5. Install the adjuster bolt (3) and the adjuster nut (4).
  6. Install the torsion bar into the adjustment arm until the torsion bar is fully seated.
  7. Install the J 36202 to the adjustment arm and the crossmember. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  8. Using the J 36202 , increase the tension on the adjustment arm to load the torsion bar. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  9. Turn the adjuster bolt the same amount of turns as it took to remove it.
  10. Remove the J 36202 from the crossmember. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  11. Remove the safety stands and lower the vehicle.
  12. Measure the Z height. Refer to «Trim Height Inspection»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#suspension-general-diagnosis__trim-height-inspection) .

Scheme 9

Scheme 9: Torsion Bars Bushing Replacement
Scheme 9: Torsion Bars Bushing Replacement
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the torsion bars. Refer to Torsion Bar and Support Assembly Replacement (Link Style) or Torsion Bar and Support Assembly Replacement (Bushing Style) .
1Front Suspension Torsion Bar Bushing Procedure When installing the NEW bushing, ensure that the inner slot is horizontal. Using the appropriate bushing remover/installer, remove the bushing. After installing the bushing, peen the bushing in three places 120 degrees apart from each other. Measure the trim height. Refer to Trim Height Inspection .

Strut and Shock Absorber Inspection (Coil Over Shock)

Note. The coil over shock assembly DOES NOT have to be removed from the vehicle to perform the following inspection procedure.

Note. A light film of oil on the top portion of the shock absorber tube is normal. DO NOT replace the shock absorber for this condition.

Scheme 10

Scheme 10: Strut and Shock Absorber Inspection (Coil Over Shock)
Scheme 10: Strut and Shock Absorber Inspection (Coil Over Shock)

Condition 1

Oil or fluid residue only on the bottom of the lower shock absorber tube or other coil over shock absorber and originating from the shaft seal, is not a shock absorber related problem. DO NOT replace the shock absorber, look for other external leaks.

Condition 2

Light film/residue on the shock absorber tube, but not on the spring seat and originating from the shaft seal, is a NORMAL condition. DO NOT replace the shock absorber.

Condition 3

Oil drip or trail down the shock absorber tube and originating from the shaft seal, is an ABNORMAL condition. Replace the shock absorber.

Condition 4

An extreme wet film of oil covering the shock absorber tube and pooling in the spring seat and originating from the shaft seal, is an ABNORMAL condition. Replace the shock absorber.

Inspection

  1. Verify the customer's concern is present. If the concern is present, continue to the next step. If the concern is not present, then the vehicle is operating normally.
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Visually inspect each of the shock absorbers for external fluid leaks. Refer to the following conditions 1, 2, 3, and 4 for visual inspection. If conditions 1 or 2 are found, continue to step 4. If conditions 3 or 4 are found, replace shock absorber. Refer to «Shock Absorber Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-rear/#rear-suspension-system) or «Shock Absorber Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-rear/#rear-suspension-system) .
  4. If equipped with electronic suspension control system, ensure that the system is working properly.
  5. Use your hands in order to lift up and push down on each corner of the vehicle 3 times. Remove your hands from the vehicle. If the corner motion exceeds 2 cycles, replace the shock absorber. If the shock absorber does not exceed 2 cycles, NO repair is necessary.

Strut and Shock Absorber Inspection (Shock Absorber)

Note. The shock absorber assembly DOES NOT have to be removed from the vehicle to perform the following inspection procedure.

Note. A light film of oil on the top portion of the lower shock absorber tube is normal. DO NOT replace the shock absorber for this condition.

Scheme 11

Scheme 11: Strut and Shock Absorber Inspection (Shock Absorber)
Scheme 11: Strut and Shock Absorber Inspection (Shock Absorber)

Oil or fluid residue only on the bottom or top of the shock absorber and not originating from the shaft seal, is not a shock absorber related problem. DO NOT replace the shock absorber, look for other external leaks.

Light film/residue on approximately 1/3 (a) or less of the lower shock tube (A) and originating from the shaft seal, is a NORMAL condition. DO NOT replace the shock absorber.

Oil drip or trail down the lower shock tube and originating from the shaft seal, is an ABNORMAL condition. Replace the shock absorber.

An extreme wet film of oil covering more than 1/3 (b) of the lower shock tube and originating from the shaft seal (B), is an ABNORMAL condition. Replace the shock absorber. Refer to Shock Absorber Replacement (1500) or Shock Absorber Replacement (2500) .

Inspection

  1. Verify the customer's concern is present. If the concern is present, continue to the next step. If the concern is not present, then the vehicle is operating normally.
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Visually inspect each of the shock absorbers for external fluid leaks. Refer to the following conditions 1, 2, 3, and 4 for visual inspection. If conditions 1 or 2 are found, continue to step 4. If conditions 3 or 4 are found, replace shock absorber. Refer to «Shock Absorber Replacement (1500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-rear/#rear-suspension-system) or «Shock Absorber Replacement (2500)»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-rear/#rear-suspension-system) .
  4. If equipped with electronic suspension control system, ensure that the system is working properly.
  5. Use your hands in order to lift up and push down on each corner of the vehicle 3 times. Remove your hands from the vehicle. If the corner motion exceeds 2 cycles, replace the shock absorber. If the shock absorber does not exceed 2 cycles, NO repair is necessary.

Scheme 12

Scheme 12: Shock Absorber and Spring Assembly Replacement
Scheme 12: Shock Absorber and Spring Assembly Replacement
CalloutComponent Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . Disconnect the outer tie rod from the steering knuckle. Refer to Steering Linkage Outer Tie Rod Replacement .
1Shock Absorber Module Bolt (Qty: 2) CAUTION: Do not use air powered tools in order to disassemble or assemble any vehicle component. Bolt torques are vital to diagnosis. You can detect bolt torques only when using hand tools. Improper bolt torques can contribute to vehicle repair problems. CAUTION: Refer to Fastener Caution . Procedure Support the lower control arm. Disconnect the electronic suspension control electrical connector. Tighten: 50 N.m (37 lb ft)
2Shock Absorber Module Nut (Qty: 3) Tighten: 50 N.m (37 lb ft)
3Shock Absorber Module Procedure If you are removing the shock module in order to service the components, refer to Shock, Shock Component, and/or Spring Replacement . For the proper disposal procedure of the shock absorber, refer to Shock Absorber Disposal .
CAUTION
Do not use air powered tools in order to disassemble or assemble any vehicle component. Bolt torques are vital to diagnosis. You can detect bolt torques only when using hand tools. Improper bolt torques can contribute to vehicle repair problems.
CAUTION
Refer to Fastener Caution .

CH-48845 Spring Compressor. See Special Tools .

  1. Install the front shock absorber assembly in the CH-48845 . See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  2. Position the shock absorber (2) in the upper retaining bracket of the CH-48845 (1) so the shock absorber will be centered. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  3. Using the CH-48845 (1), compress the front spring (2). See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Using the appropriate size wrench, hold the shock absorber shaft.
  5. Using the appropriate tool, remove and discard the shock absorber nut (1).
  6. Remove the front lower shock absorber (2) and the front spring lower insulator (1).
  7. Remove the front suspension strut mount (1), front spring upper seat (2), front suspension strut bumper (3), front spring upper insulator (4), and the front suspension spring (5) from the spring compressor.
  1. Assemble the front suspension strut mount (1), front spring upper seat (2), front suspension strut bumper (3), front spring upper insulator (4), and the front suspension spring (5) in the spring compressor.
  2. Align the spring seat stop (3), the outboard stud (1), and the center of the lower strut mount (4). The notch in the spring seat (2) should be just to the right of the outboard stud.
  3. Position the shock absorber (2) in the upper retaining bracket of the CH-48845 (1) so the shock absorber will be centered. See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  4. Using the CH-48845 (1), compress the front spring (2). See «Special Tools»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .
  5. Using the appropriate size wrench, hold the shock absorber shaft.
  6. Install the NEW shock absorber nut (1) and tighten. For vehicles equipped with electronic suspension, tighten the shock absorber nut to 80 N.m (59 lb ft). For vehicles equipped with electronic suspension, tighten the electrical connector to 20 N.m (15 lb ft). For vehicles without electronic suspension, tighten the shock absorber nut to 60 N.m (44 lb ft).
  7. Remove the shock absorber assembly from the spring compressor
  8. Install the shock absorber in the vehicle. Refer to «Shock Absorber and Spring Assembly Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/suspension-front/#front-suspension-system) .

Scheme 13

Scheme 13: Shock Absorber Replacement (2500 Series)
Scheme 13: Shock Absorber Replacement (2500 Series)
CalloutComponent Name
Preliminary Procedure: Remove the tire and wheel. Refer to Tire and Wheel Removal and Installation .
1Shock Absorber Retaining Nut CAUTION: Refer to Fastener Caution . Tip: Support the lower control arm with a safety stand. Tighten: 24 N.m (17 lb ft)
2Insulator (Qty: 2) Tip: Install the lower insulator, which is smaller than the upper insulator and plastic pilot ring. Install the upper insulator, which is the larger of the 2 insulators.
3Retaining Nut Tighten: 80 N.m (59 lb ft)
4Mounting Bolt
5Shock Absorber Tip: If replacing the shock absorber, refer Shock Absorber Disposal for the proper disposal procedure.
CAUTION
Refer to Fastener Caution .

Shock Absorber Disposal

WARNINGGas charged shock absorbers contain high pressure gas. Do not remove the snap ring from inside the top of the tube. If the snap ring is removed, the contents of the shock absorber will come out with extreme force which may result in personal injury.
WARNINGTo prevent personal injury, wear safety glasses when centerpunching and drilling the shock absorber. Use care not to puncture the shock absorber tube with the centerpunch.
  1. Make an indentation 10 mm (0.4 in) from the bottom (4) of the tube (3) using a centerpunch.
  2. Clamp the shock absorber in a vise horizontally with the shock absorber rod (1) completely extended.
  3. Drill a hole in the shock absorber at the centerpunch (4) using a 5 mm (3/16 in) drill bit. Gas or a gas/oil mixture will exhaust when the drill bit penetrates the shock absorber. Use shop towels in order to contain the escaping oil.
  4. Make an indentation in the middle (2) of the tube (3) with a centerpunch.
  5. Drill a second hole in the shock absorber at the centerpunch (2) using a 5 mm (3/16 in) drill bit. Oil will exhaust when the drill bit penetrates the shock absorber. Use shop towels in order to contain the escaping oil.
  6. Remove the shock absorber from the vise. Hold the shock absorber over a drain pan horizontally with the holes down. Move the rod (1) in and out of the tube (3) to completely drain the oil from the shock absorber.

General Description

The front suspension allows each wheel to compensate for changes in the road surface without affecting the opposite wheel. Each wheel independently connects to the frame with a steering knuckle, ball joint assemblies, and upper and lower control arms.

Two tie rods connect to the steering arms on the knuckles and to a steering gear.

Rear wheel drive models have a front suspension that consists of the following components

  1. Control arms
  2. Stabilizer shaft
  3. Shock/Coil spring modules

The upper part of each Shock/Coil spring module bolts to the frame. Three insulators, a mounting plate and a nut secure the coil spring to the shock housing. Two bolts secure the lower part of the shock module to the lower control arm.

A spring steel stabilizer shaft controls the side roll of the front suspension. This shaft is mounted in rubber insulators that are held by clamps to the frame side rails. The ends of the stabilizer shaft connect to the lower control arms with link assemblies.

The upper ball joint assembly is integrated into the upper control arm. The assembly attaches to the steering knuckle with a prevailing torque nut.

The lower ball joint assembly is integrated into the control arm. The assembly attaches to the steering knuckle with a prevailing torque nut.

The upper and the lower control arms have pressed-in bushings. The bolts pass through the bushings and join the arms to the frame.

Ball joint assemblies have rubber grease seals. These seals prevent the entry of moisture and dirt. This prevents damage to the bearing surfaces.

Four-wheel drive models have a front suspension that consists of the following components

  1. Control arms
  2. Stabilizer shaft
  3. Shock module/Shock absorbers
  4. Coil Springs (1500 series)
  5. Torsion bars (2500, 3500 series)

The upper part of each shock absorber (2500, 3500 series) extends through a frame bracket. Two insulators and a nut secure the upper part of the shock to the frame. A through bolt secures the lower part of the shock to the lower control arm.

The upper part of each shock module (1500 series) attaches to the frame by 3 nuts. The lower part of the shock module attaches to the lower control arm by 2 bolts.

A spring steel stabilizer shaft controls the side roll of the front suspension. This shaft is mounted in rubber insulators that are held by clamps to the frame side rails. The ends of the stabilizer shaft connect to the lower control arms with link assemblies.

The front end of the torsion bar attaches to the lower control arm. The rear of the torsion bar mounts into an adjustable arm at the torsion bar crossmember. This arm adjustment controls the vehicle trim height.

Both RWD and 4WD models have sealed front wheel bearings. These bearings are pre-adjusted and need no lubrication.

Illustration Tool Number/ Description CH-41805 Ball Joint Remover/Installer CH-48845 Front Spring Compressor CH-49240 Ball Joint Crimp and Install Tool J-24319-B Steering Linkage and Tie Rod Puller J-36202 Torsion Loading/Unloading Tool J-36660-A Torque Angle Meter J-42188-B Ball Joint Separator J-43631 Ball Joint Remover J-45851 Ball Joint Separator Protector Adapters

Scheme 14

Scheme 14: Special Tools
Scheme 14: Special Tools

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

More articles — Suspension
