Hybrid Engine Controls - Component Locator - Component Views Cadillac Escalade GMT900

Engine Control Systems 4 illustrations

Scheme 2

Scheme 2: Hybrid Controls Electronic Component Views
CalloutComponent Name
1Drive Motor Generator Control Module Assembly
2Accessory DC Power Control Module (APM) Assembly
3Drive Motor Generator Power Inverter Module (PIM) Assembly
4Hybrid Powertrain Control Module (HPCM)
5Motor Control Module (MCM) 1, Motor Control Module (MCM) 2
6Sight Shield Circuit Breaker
7Drive Motor Generator Power Inverter Module 3 Phase Cable Assembly
8Drive Motor Battery 300 Volt Positive and Negative Cable Assembly
9Drive Motor Generator Assembly - 1st Position
10Drive Motor Generator Assembly - 2nd Position
11A/Trans Output Speed Sensor Assembly
12Drive Motor Generator Battery
13Drive Motor Generator Battery Control Module Assembly
14Drive Motor Battery Cable Terminal Extension Cover Circuit Breaker
15Drive Motor Generator Power Inverter Module 3 Phase Cable Cover Circuit Breaker
16A/Trans Manual Shift Shaft Position Switch Assembly
17Control Solenoid w/Body and TCM Valve Assembly
18A/Trans Auxiliary Fluid Pump Control Module Assembly
19A/Trans Auxiliary Fluid Pump Assembly
20300 Volt AC Compressor w/Control Module Assembly

Scheme 3

Scheme 3
CalloutComponent Name
1Air Conditioner Compressor 300 V B
2Air Conditioner Compressor 300 V B+
3Motor 2 Phase U
4Motor 2 Phase W
5Motor 2 Phase V
6Motor 1 Phase U
7Motor 1 Phase W
8Motor 1 Phase V
9Drive Motor Generator Battery 300 V B
10Drive Motor Generator Battery 300 V B+

Scheme 4

Scheme 4
CalloutComponent Name
1Accessory DC Power Control Module Tray Bracket to Accessory DC Power Control Module Tray Assembly Nut
2Accessory DC Power Control Module Tray Bracket to Front Fender Inner Panel Stud Nut
3Accessory DC Power Control Module Tray Bracket
4Accessory DC Power Control Module to A/C Support Bracket Bolt
5Accessory DC Power Control Module Tray Bracket to Accessory DC Power Control Module Tray Assembly Nut
6Accessory DC Power Control Module Tray Assembly
7Accessory DC Power Control Module Tray Bracket to Battery Tray Bracket Studs
8Accessory DC Power Control Module Tray Bracket

Scheme 5

Scheme 5: Hybrid Controls Component Views
CalloutComponent Name
1Drive Motor Generator Power Inverter Module Cover Seal
2Drive Motor Generator Power Inverter Module Cover Bolt
3Drive Motor Generator Power Inverter Module Cover
4Ball Stud
4Ball Stud
5Accessory DC Power Control Module (APM) Bolts
6Drive Motor Generator Power Inverter Module 3 Phase Cable Cover
7Drive Motor Generator Power Inverter Module Cable Housing Cover Seal
8Drive Motor Generator Power Inverter Module Coolant Pipe Seals
9Drive Motor Generator Power Inverter Module Coolant Inlet Pipe Assembly
10Drive Motor Generator Power Inverter Coolant Outlet Pipe Assembly
11Drive Motor Generator Power Inverter Coolant Pipe Bolts
12Accessory DC Power Control Module (APM) Assembly
13Drive Motor Generator Control Module Seal
14Drive Motor Generator Power Inverter Module Assembly
