Scheme 287
| Callout | Component Name |
|---|---|
| 1 | A/Trans Torque Dampener Assembly |
| 3 | A/Trans Fluid Pump Cover Bolt |
| 4 | A/Trans Torque Dampener (w/Fluid Pump) Housing Assembly |
| 5 | A/Trans Auxiliary Fluid Pump Bolt |
| 6 | A/Trans Auxiliary Fluid Pump Assembly |
| 7 | A/Trans Auxiliary Fluid Pump Gasket |
| 8 | A/Trans Torque Dampener Fluid Passage Plug |
| 9 | A/Trans Torque Dampener Fluid Passage Plug |
| 10 | A/Trans Torque Dampener Housing Gasket |
| 11 | A/Trans Case Assembly |
| 12 | Transmission Fluid Fill Tube Seal |
| 13 | Drive Motor Generator Power Inverter Module (3 Phase) Cable Assembly |
| 14 | Drive Motor Generator Power Inverter Module Cable Retaining Bolt |
| 15 | Drive Motor Generator Power Inverter Module Cable Terminal External Bolt Protective Cover |
| 16 | Drive Motor Generator Power Inverter Module (3 Phase) Cable Cover |
| 17 | 24-Way Assembly Connector Lip Seal |
| 18 | 24-Way Assembly Connector O-Ring Seals |
| 19 | 24-Way Assembly Connector |
| 20 | A/Trans Rear Case Gasket |
| 21 | A/Trans Rear Case Assembly |
| 22 | A/Trans Rear Case Bolt |
| 23 | Gasket (2WD Output Only) |
| 24 | 2WD Output Housing Extension Assembly |
| 25 | 2WD Output Bushing |
| 26 | Output Seal (2WD Only) |
| 27 | A/Trans Rear Case Bolt |
| 28 | Manual Shift Shaft Seal |
| 29 | Manual Shift Shaft |
| 30 | Park Pawl Actuator Assembly |
| 31 | A/Trans Manual Shift Shaft Position Switch Assembly |
| 32 | A/Trans Manual Shift Shaft Position Switch Bolt |
| 33 | Manual Shift Shaft Pin |
| 34 | Hybrid Low, 1-2 Clutch Regulator Valve Seal |
| 35 | A/Trans Fluid Pump Seal Assembly |
| 36 | Control (w/ Body and Valve) Valve Assembly |
| 37 | Control Valve Upper Body Bolt |
| 38 | Control Valve Upper Body Bolt |
| 39 | Manual Shift Detent Assembly |
| 40 | Manual Shift Detent Spring Bolt |
| 41 | A/Trans Control Wiring Harness Extension Harness Assembly |
| 42 | A/Trans Control Wiring Harness Extension Harness O-Ring Seal |
| 43 | A/Trans Auxiliary Fluid Filter Seal |
| 44 | A/Trans Auxiliary Fluid Pump Outlet Pipe |
| 45 | A/Trans Auxiliary Fluid Filter Seal |
| 46 | A/Trans Auxiliary Fluid Pump Filter Assembly |
| 47 | A/Trans Fluid Filter Seal Assembly |
| 48 | A/Trans Fluid Filter Assembly |
| 50 | A/Trans Fluid Pan Gasket |
| 51 | A/Trans Fluid Pan Magnet |
| 52 | A/Trans Fluid Pan Assembly |
| 53 | A/Trans Fluid Pan Bolt |
| 54 | A/Trans Fluid Pan Drain Plug O-Ring Seal |
| 55 | Drain Plug Assembly |
| 56 | A/Trans Wiring Harness Assembly |
| 57 | Drive Motor Generator Power Inverter Module Cable Housing Cover Seal |
| 58 | 2WD Output Housing Extension Assembly Guide Pins |
| 59 | Internal Wire Harness Side Bracket |
Scheme 288
| Callout | Component Name |
|---|---|
| 60 | Input Shaft Thrust Bearing |
| 61 | Internal Gear Retaining Ring - 1st Position |
| 62 | Input Shaft Fluid Seal Ring |
| 63 | A/Trans Torque Dampener Clutch Fluid Seal Ring |
| 64 | Input Shaft |
| 65 | Internal Gear - 1st Position |
| 66 | Sun Gear Carrier Thrust Bearing - 1st Position |
| 67 | Sun Gear Carrier Assembly - 1st Position |
| 69 | Sun Gear Assembly - 1st Position |
| 70 | Generator Drive Motor Bolt |
| 71 | Drive Motor (w/Generator) Assembly - 1st Position |
| 72 | Generator Drive Motor Housing Seal |
| 73 | Sun Gear Shaft Retaining Ring |
| 74 | Sun Gear Shaft Assembly - 1st Position |
| 75 | Internal Gear - 2nd Position |
| 76 | Internal Gear Thrust Bearing Assembly - 2nd Position |
| 77 | Sun Gear Carrier Assembly - 2nd Position |
| 79 | Sun Gear Assembly - 2nd Position |
| 80 | 1-3 Clutch Housing Assembly |
| 81 | Hybrid Direct, 2-3-4 Clutch Housing Thrust Bearing Assembly |
| 82 | Main Shaft Assembly |
| 83 | A/Trans Vent Pipe |
| 84 | A/Trans Case Assembly |
| 85 | 1-3 Clutch Housing Fluid Seal Ring |
| 86 | Center Support Assembly |
| 87 | Center Support Bolt |
| 88 | Drive Motor (w/Generator) Assembly - 2nd Position |
| 89 | Sun Gear Shaft Assembly - 3rd Position - Some Models |
| 90 | Sun Gear - 3rd Position |
Scheme 289
| Callout | Component Name |
|---|---|
| 200 | A/Trans Torque Dampener Fluid Seal Retaining Ring |
| 201 | A/Trans Fluid Pump Seal |
| 202 | A/Trans Torque Dampener (w/Fluid Pump) Housing Assembly |
| 203 | Input Shaft Bushing |
| 204 | A/Trans Fluid Pump Slide O-Ring Seal |
| 205 | A/Trans Fluid Pump Slide Seal Support |
| 206 | A/Trans Fluid Pump Slide Seal |
| 207 | A/Trans Fluid Pump Slide Outer Spring |
| 208 | A/Trans Fluid Pump Slide |
| 209 | A/Trans Fluid Pump Slide Pivot Pin |
| 210 | A/Trans Fluid Pump Vane Ring |
| 211 | A/Trans Fluid Pump Rotor Guide |
| 212 | A/Trans Fluid Pump Vane |
| 213 | A/Trans Fluid Pump Rotor |
| 214 | Pump Slide Fluid Seal Ring |
| 215 | A/Trans Fluid Pump Air Bleed Orifice |
| 216 | A/Trans Torque Dampener Fluid Passage Plug |
| 217 | Pressure Regulator Valve Pin |
| 218 | Valve Retaining Plug |
| 219 | Isolator Valve |
| 220 | A/Trans Fluid Pump Valve Inner Spring |
| 221 | A/Trans Fluid Pump and Auxiliary Fluid Pump Valve |
| 222 | Pressure Relief Ball Valve Spring Pin |
| 223 | Pressure Relief Ball Valve Spring |
| 224 | Pressure Relief Ball Valve |
| 225 | A/Trans Fluid Cooler Bypass Valve |
| 226 | A/Trans Fluid Cooler Bypass Valve Spring |
| 227 | Decrease Orifice |
| 228 | A/Trans Fluid Pump Cover Bolt |
| 229 | A/Trans Fluid Pump Cover Assembly |
| 230 | Transmission Lube Fluid Pressure Regulator Valve |
| 231 | Pressure Regulator Valve Spring |
| 232 | Pressure Regulator Valve Stop |
| 233 | Pressure Regulator Valve |
| 234 | Pressure Regulator Valve Inner Spring |
| 235 | Pressure Regulator Valve Outer Spring |
| 236 | Isolator Valve |
| 237 | Isolator Valve Sleeve |
| 238 | Transmission Fluid Cooler Pipe Fitting Seal |
| 239 | A/Trans Fluid Pump Valve Outer Spring |
Scheme 290
| Callout | Component Name |
|---|---|
| 300 | Control Valve Channel Plate Bolt |
| 301 | Control Valve Upper Body Assembly |
| 302 | A/Trans Fluid Pump Ball Check Valve |
| 303 | Control Valve Body Spacer (w/Gasket) Plate Assembly |
| 304 | Control Valve Channel Plate |
| 305 | Control Valve Channel Plate Spacer Plate Gasket |
| 306 | Control Solenoid Valve Heat Sink (w/Body and TCM) Bolt |
| 307 | Control Solenoid (w/ Body and TCM) Valve Assembly |
| 308 | Control Valve Lower Body Bolt |
| 309 | A/Trans Manual Shift Shaft Position Switch Assembly Bracket |
Scheme 291
| Callout | Component Name |
|---|---|
| 320 | Valve Retaining Clip |
| 321 | Valve Retaining Plug |
| 322 | Auxiliary Line Boost Valve |
| 323 | Auxiliary Line Boost Valve Spring |
| 324 | 1-3 Clutch Regulator Valve |
| 325 | 1-3 Clutch Regulator Valve Spring |
| 326 | Hybrid Direct 2-3-4 Clutch Regulator Valve |
| 327 | Hybrid Direct 2-3-4 Clutch Regulator Valve Spring |
| 328 | Shift Solenoid Valve - Mode A |
| 329 | Hybrid A/Trans Shift Solenoid Spring |
| 330 | Control Valve Body Locating Pin |
| 331 | Hybrid A/Trans Shift Solenoid Spring |
| 332 | Shift Solenoid Valve - Mode B |
| 333 | Actuator Feed Limit Valve Spring |
| 334 | Actuator Feed Limit Valve |
| 335 | Hybrid Low, 1-2 Clutch Regulator Valve Spring |
| 336 | Hybrid Low, 1-2 Clutch Regulator Valve |
| 337 | Hybrid Low, 1-2 Clutch Boost Valve Assembly |
| 338 | Hybrid Low, 1-2 Clutch Boost Valve Spring |
| 339 | Clutch Piston Exhaust Blowoff Ball Valve |
| 340 | Clutch Piston Exhaust Blowoff Ball Valve Spring |
| 341 | Clutch Piston Exhaust Blowoff Ball Valve Plug |
| 342 | Control Valve Body Locator Pin |
| 343 | Control Valve Upper Body Assembly |
Scheme 292
| Callout | Component Name |
|---|---|
| 400 | 4th Clutch Piston Retaining Ring |
| 401 | 4th Clutch Backing Plate |
| 402 | 4th Clutch Plate Assembly |
| 403 | 4th Clutch Plate |
| 404 | 4th Clutch Waved Plate |
| 405 | 4th Clutch Piston Retaining Ring |
| 406 | 4th Clutch Piston Retaining Spring Assembly |
| 407 | 4th Clutch Piston |
| 408 | A/Trans Case Assembly |
Scheme 293
| Callout | Component Name |
|---|---|
| 410 | 1-3 Clutch Retaining Ring |
| 411 | 1-3 Clutch Backing Plate |
| 412 | 1-3 Clutch Plate Assembly |
| 413 | 1-3 Clutch Plate |
| 414 | 1-3 Clutch Plate - Waved |
| 415 | 1-3 Clutch Piston Retaining Ring |
| 416 | 1-3 Clutch Piston Dam |
| 417 | 1-3 Clutch Retaining Spring |
| 418 | 1-3 Clutch Piston |
| 419 | 1-3 Clutch Housing Assembly |
| 420 | 1-3 Clutch Housing Bushing |
Scheme 294
| Callout | Component Name |
|---|---|
| 425 | Hybrid Low, 1-2 Clutch Piston Retaining Ring |
| 426 | Hybrid Low, 1-2 Clutch Backing Plate Assembly |
| 427 | Hybrid Low, 1-2 Clutch Plate Assembly |
| 428 | Hybrid Low, 1-2 Clutch Plate |
| 429 | Hybrid Low, 1-2 Clutch Plate - Waved |
| 430 | Hybrid Low, 1-2 Clutch Return Spring Assembly |
| 431 | Hybrid Low, 1-2 Clutch Piston |
| 432 | Internal Gear - 3rd Position |
| 433 | Internal Gear Thrust Washer - 3rd Position - Steel |
| 434 | Sun Gear Carrier Assembly - 3rd Position |
| 435 | Internal Gear Thrust Bearing Assembly - 2nd Position |
| 436 | Hybrid Direct, 2-3-4 Clutch Hub |
| 437 | Output Shaft Thrust Bearing Assembly |
| 438 | Output Shaft Retaining Ring |
| 439 | Output Shaft Assembly |
| 440 | Hybrid Direct, 2-3-4 Clutch Housing Assembly |
| 441 | Hybrid Direct, 2-3-4 Clutch Housing Thrust Bearing Assembly |
| 442 | Hybrid Direct, 2-3-4 Clutch Housing Seal Ring |
| 443 | Hybrid Direct, 2-3-4 Clutch Support Bolt |
| 444 | Hybrid Direct, 2-3-4 Clutch Support Assembly |
| 445 | Hybrid Direct, 2-3-4 Clutch Support Gasket |
| 446 | Vehicle Speed Sensor Bolt |
| 447 | A/Trans Output Speed Sensor Assembly |
| 448 | A/Trans Output Speed Sensor O-Ring Seal |
| 449 | A/Trans Rear Case Assembly |
| 450 | Park Pawl Shaft |
| 451 | Park Pawl Shaft Hole Plug |
| 452 | Park Pawl Cover Gasket |
| 453 | Park Pawl Cover |
| 454 | Park Pawl Cover Bolt |
| 455 | Park Pawl Actuator Guide Pin |
| 456 | Park Pawl Actuator Guide |
| 457 | Park Pawl Spring |
| 458 | Park Pawl |
| 459 | Internal Gear Thrust Washer - 3rd Position - Plastic |
Scheme 295
| Callout | Component Name |
|---|---|
| 460 | Hybrid Direct, 2-3-4 Clutch Plate Retaining Ring |
| 461 | Hybrid Direct, 2-3-4 Clutch Backing Plate |
| 462 | Hybrid Direct, 2-3-4 Clutch Plate Assembly |
| 463 | Hybrid Direct, 2-3-4 Clutch Plate |
| 464 | Hybrid Direct, 2-3-4 Clutch Plate - Waved |
| 465 | Hybrid Direct, 2-3-4 Clutch Piston Ring |
| 466 | Hybrid Direct, 2-3-4 Clutch Piston Dam |
| 467 | Hybrid Direct,, 2-3-4 Clutch Piston Return Spring |
| 468 | Hybrid Direct, 2-3-4 Clutch Piston Outer Seal |
| 469 | Hybrid Direct, 2-3-4 Clutch Piston |
| 470 | Hybrid Direct, 2-3-4 Clutch Piston Inner Seal |
| 471 | Hybrid Direct, 2-3-4 Clutch Housing Assembly |
Scheme 296
| Callout | Component Name |
|---|---|
| 1 | A/Trans Torque Dampener Housing Assembly |
| 2 | A/Trans Torque Dampener Asembly |
| 3 | Sun Gear Carrier Assembly - 1st Position |
| 4 | Drive Motor (w/Generator) Assembly - 1st Position |
| 5 | Sun Gear Carrier Assembly - 2nd Position |
| 6 | 1-3 Clutch Housing Assembly |
| 7 | 4th Clutch Assembly |
| 8 | Drive Motor (w/Generator) Assembly - 2nd Position |
| 9 | Sun Gear Carrier Assembly - 3rd Position |
| 10 | 1-2 Clutch Assembly |
| 11 | 2-3-4 Clutch Assembly |
| 12 | 2WD Output Housing Extension Assembly |
| 13 | Output Shaft Assembly |
| 14 | Park Pawl Cover |
| 15 | A/Trans Case Assembly |
| 16 | A/Trans Fluid Pan Assembly |
| 17 | Drive Motor Generator Power Inverter Module Cable Assembly - 3 Phase |
| 18 | A/Trans Manual Shift Shaft Position Switch Assembly |
| 19 | Control Valve Upper Body Assembly |
| 20 | Control Valve Channel Plate |
| 21 | A/Trans Fluid Filter Assembly |
| 22 | A/Trans Fluid Pump Cover Assembly |
| 23 | Main Shaft Assembly |
| 24 | A/Trans Auxiliary Fluid Pump Assembly |
| 25 | Input Shaft |
Scheme 297
| Callout | Component Name |
|---|---|
| 25 | 2WD Output Bushing |
| 60 | Input Shaft Thrust Bearing Assembly |
| 66 | Sun Gear Carrier Thrust Bearing Assembly |
| 68 | Internal Gear Thrust Bearing Assembly |
| 76 | Internal Gear Thrust Bearing Assembly |
| 78 | 2-3-4 Clutch Hub Thrust Bearing Assembly |
| 81 | 2-3-4 Clutch Housing Thrust Bearing Assembly |
| 203 | Input Shaft Bushing |
| 420 | 1-3 Clutch Housing Bushing |
| 433 | Internal Gear Thrust Washer - 3rd Position - Steel |
| 435 | Internal Gear Thrust Bearing Assembly |
| 437 | Output Shaft Thrust Bearing Assembly |
| 441 | 2-3-4 Clutch Housing Thrust Bearing Assembly |
| 459 | Internal Gear Thrust Washer - 3rd Position - Plastic |
Scheme 298
| Callout | Component Name |
|---|---|
| 7 | A/Trans Auxiliary Fluid Pump Gasket |
| 10 | A/Trans Torque Dampener Housing Gasket |
| 17 | 24-Way Assembly Connector Lip Seal |
| 18 | 24-Way Assembly Connector O-Ring Seal |
| 20 | A/Trans Rear Case Gasket |
| 23 | Extension Assembly Gasket |
| 26 | Output Seal (2WD Only) |
| 28 | Manual Shift Shaft Seal |
| 42 | A/Trans Control Wiring Harness Extension Harness O-Ring Seal |
| 43 | A/Trans Auxiliary Fluid Filter Seal |
| 45 | A/Trans Auxiliary Fluid Filter Seal |
| 47 | A/Trans Fluid Filter Seal Assembly |
| 50 | A/Trans Fluid Pan Gasket |
| 57 | Generator Power Inverter Module Cable Housing Cover Seal (Qty: 2) |
| 62 | Input Shaft Fluid Seal Ring |
| 63 | A/Trans Torque Dampener Clutch Fluid Seal Ring |
| 72 | Generator Drive Motor Housing Seal |
| 85 | 1-3 Clutch Housing Fluid Seal Ring |
| 201 | A/Trans Fluid Pump Seal |
| 204 | A/Trans Fluid Pump Slide Seal |
| 214 | Pump Slide Fluid Seal Ring |
| 407 | 4th Clutch Piston |
| 416 | 1-3 Clutch Piston Dam |
| 418 | 1-3 Clutch Piston |
| 431 | 1-2 Clutch Piston |
| 442 | 2-3-4 Clutch Housing Seal Ring |
| 445 | 2-3-4 Clutch Support Gasket |
| 448 | A/Trans Output Speed Sensor Seal |
| 452 | Park Pawl Cover Gasket |
| 466 | 2-3-4 Clutch Piston Dam |
| 468 | 2-3-4 Clutch Seal |
| 470 | 2-3-4 Clutch Seal |
Scheme 299
| I.D. | Input Oil | Input Oil | Output Oil |
|---|---|---|---|
| 1 | Line | Auxiliary Line | Line and Auxiliary Line |
