Steering Wheel & Steering Column Cadillac Escalade GMT800

Fastener Tightening Specifications

Fastener Tightening Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Symptoms - Steering Wheel and Column

Review the system description and operation in order to familiarize yourself with the system functions. Refer to STEERING WHEEL AND COLUMN DESCRIPTION AND OPERATION .

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the steering wheel and column.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Symptoms List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Lock System Does Not Unlock»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
2. «Lock System Does Not Lock»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
3. «Lock System Sticks In Start»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
4. «Key Cannot Be Removed In Off Lock Position»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
5. «High Lock Effort»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
6. «Noise In Steering Column»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
7. «High Shift Effort»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
8. «Looseness In Steering Column»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
9. «Steering Column Tilt Function Inoperative»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Tools Required

J 42640 Steering Column Anti-Rotation Pin

Scheme 17

Scheme 18

Scheme 19

1. Install the J 42640 in the steering column lower access hole. Important: Mark the relationship of the intermediate shaft components in order to assure proper installation.
2. Mark the relationships of the following components: Mark the relationship of the bolt and clamp at both ends of the upper intermediate shaft. Mark the relationship of the upper intermediate shaft to the lower intermediate shaft.
3. Remove the nut and bolt from the lower shaft to upper shaft connection.
4. Remove the nut and bolt (1) from the upper shaft (2) to steering column connection.
5. Slide the intermediate shaft down, out of the steering column connection.
6. Remove the accelerator pedal position sensor. Refer to «ACCELERATOR PEDAL POSITION SENSOR»(/cadillac/escalade/gmt800-2001-2006/remont/removal-installation/#engine-controls-removal-installation__accelerator-pedal-position-sensor) in Engine Controls.
7. Slide the upper intermediate shaft towards the instrument panel, out of the lower intermediate shaft, and remove the shaft from the vehicle.

Installation Procedure

Important: If you are installing the same shaft, align the marks and the relationship of the bolt and clamp made during the removal procedure.

Scheme 20

Scheme 21

Scheme 22

1. Install the lower end of the upper intermediate shaft through the bulkhead, into the lower shaft.
2. Install the upper end of the upper intermediate shaft (2) to the steering column. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
3. Install the bolt and nut (1) at the connection of the upper intermediate shaft to the steering column. Tighten Tighten the nut to 47 N.m (35 lb ft).
4. Install the accelerator pedal position sensor. Refer to «ACCELERATOR PEDAL POSITION SENSOR»(/cadillac/escalade/gmt800-2001-2006/remont/removal-installation/#engine-controls-removal-installation__accelerator-pedal-position-sensor) in Engine Controls.
5. Install the bolt and nut at the connection of the upper intermediate shaft to the lower intermediate shaft. Tighten Tighten the nut to 47 N.m (35 lb ft).
6. Remove the J 42640 from the steering column lower access hole.

J 42640 Steering Column Anti-Rotation Pin

Removal Procedure

Note. The wheels of the vehicle must be straight ahead and the steering column in the LOCK position before disconnecting the steering column or intermediate shaft from the steering gear. Failure to do so will cause the SIR coil assembly to become uncentered, which may cause damage to the coil assembly.

Scheme 23

Scheme 24

1. Set the front wheels in the straight-ahead position.
2. Install the J 42640 in the steering column lower access hole.
3. Mark the relationship of the intermediate shaft components in order to assure proper installation. Mark the relationship of the upper intermediate shaft to the lower intermediate shaft. Mark the relationship of the lower shaft coupler to the steering gear input shaft.
4. Remove the bolt from the upper to lower shaft connection.
5. Remove the bolt from the lower shaft coupler.
6. Remove the intermediate shaft assembly. Slide the shaft towards the dash in order to get the lower shaft coupler clear of the steering gear input shaft.
7. Slide the intermediate shaft down out of the upper shaft.

Scheme 25

Scheme 26

1. Install the upper end of the intermediate shaft into the upper shaft.
2. Install the lower end of the intermediate shaft coupler. If you are reinstalling the same shaft, align the marks made during the removal procedure. Install the lower end of the intermediate shaft coupler onto the steering gear worm shaft.
3. Install the bolt to the lower shaft coupler. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
4. Install the bolt to the upper end of the shaft. Tighten Tighten the upper bolt to 47 N.m (35 lb ft). Tighten the coupler pinch bolt to 47 N.m (35 lb ft).
5. Remove the J 42640 from the steering column lower access hole.

Scheme 27

Scheme 28

Scheme 29

1. Vehicles involved in accidents which result in the following conditions may also have a damaged or misaligned steering column: Frame damage Major body or sheet metal damage Where the steering column has been impacted Where supplemental inflatable restraint systems deployed
2. Inspect the capsules on the steering column bracket assembly. All capsules must be securely seated in the bracket slots and checked for any loose conditions when pushed or pulled by hand. If not, the bracket should be replaced if bolted to the jacket assembly. If the bracket is welded to the jacket assembly replace the jacket assembly.
3. Inspect for jacket assembly collapse by measuring the distance from the lower edge of the upper jacket to a defined point on the lower jacket. Replace the jacket assembly if the measured dimensions are not within specifications.
4. Remove the SIR coil from the steering column and allow the coil to hang freely before the shaft is rotated. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) .
5. Visually inspect the steering shaft for sheared injected plastic (1). If the steering shaft shows sheared plastic, replace the steering shaft.
6. Inspect the steering shaft runout for any frame damage that could cause a bent steering shaft. Using a dial indicator at the lower end of the steering shaft, rotate the steering wheel. The runout must not exceed 1.60 mm (0.0625 in).

Scheme 30

Scheme 31

Scheme 32

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the steering wheel from the column. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the tilt lever from the lower trim cover. Refer to «TILT LEVER REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Important: You must check for 2 pan head tapping screws (1, 2) in the lower trim cover before removal.
4. If necessary, remove the 2 pan head tapping screws (1, 2) from the lower trim cover (3). Remove the lower trim cover (3). If screws are not present in the lower trim cover, proceed to the next step.
5. Gently unsnap the lower trim cover from the upper trim cover. Important: You must check for 2 pan head tapping screws (1, 2) in the lower trim cover (3) before removal.
6. If necessary, remove 1 TORX® head screw (1) from the upper trim cover (2). If a screw is not present, remove the upper trim cover (2).

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Important: If the snap on/off feature on the trim covers was damaged during the removal procedure, you must use screws for the installation procedure. If screws were present in the trim covers before the removal procedure, you must use the screws during the installation procedure.

If there was not any damage done to the trim covers during the removal procedure and no screws were present, proceed to step 3.

Scheme 33

Scheme 34

Scheme 35

1. Install the upper trim cover (2) onto the steering column. Install 1 TORX® head screw (1) into the upper trim cover (2). Tighten Tighten the screw to 1.5 N.m (13 lb in).
2. Install the lower trim cover (3) onto the steering column. Install 2 pan head tapping screws (1, 2) into the lower trim cover (3). Tighten Tighten 1 pan head tapping screw (1) to 3.5 N.m (31 lb in). Tighten 1 pan head tapping screw (2) to 2 N.m (18 lb in).
3. Install the upper and lower trim covers onto the steering column. Important: If column shift, the shift lever seal must be seated in the trim covers.
4. Slide the shift lever seal down the shift lever.
5. Gently snap the upper and lower trim covers together.
6. Install the tilt lever into the lower trim cover. Refer to «TILT LEVER REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Install the steering wheel onto the steering column. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
8. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 42759 Ignition Switch Connector Release Tool

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Important: The abrasion sleeve located on the steering column wire harness assembly must be reinstalled. Make note of what connector is coming out of the abrasion sleeve for installation purposes.
3. Remove the wire harness strap (2) from the steering column and the wire harness assembly (1).
4. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly out of the bulkhead connector (1).
5. Rotate the key alarm connector (1) 90 degrees.
6. Pull the key alarm connector (1) out of the ignition lock cylinder case (2).
7. Remove the passkey connector from the ignition lock cylinder case (2).
8. Insert J 42759 into the ignition lock cylinder case (1) and slide the ignition switch (2) out.

Important: Before installing a new ignition switch, the lock cylinder gear has to be rotated counterclockwise until it hits the stop. Counterclockwise from the drivers perspective. In order to rotate the lock cylinder all the way the key and lock cylinder need to be removed. Once the key and lock cylinder are removed, rotate counterclockwise with a screw driver.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Install the ignition lock cylinder case (1) and slide the ignition switch (2) in.
2. Push the key alarm connector (1) into the ignition lock cylinder case (2).
3. Rotate the key alarm connector (1) 90 degrees so that the key alarm connector (1) locks into place.
4. Install the passkey connector into the ignition lock cylinder case (2).
5. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly into the bulkhead connector (1). Important: The abrasion sleeve must be installed back onto the steering column wire harness assembly. The ignition lock cylinder case wires and connector must be hanging out of the middle of the abrasion sleeve.
6. Attach the wire harness strap (2) to the wire harness assembly (1) and the steering column.
7. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
8. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 44

Scheme 45

1. Disable the supplemental inflatable restraint (SIR) system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Turn the ignition lock cylinder to the START position.
4. Using an awl, insert the tip into the access hole (1) of the ignition lock cylinder.
5. Push down and hold the lock cylinder retaining pin.
6. Release the lock cylinder to the RUN position.
7. Pull the lock cylinder away from the steering column.

Scheme 46

1. Install the ignition lock cylinder into the steering column using the following procedure: Align the positioning locking tab slot on the ignition lock cylinder case assembly to the positioning tab on the ignition lock cylinder. Push the lock cylinder in until the locking tab locks in the ignition lock cylinder case assembly.
2. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
4. Perform the Passlock learn procedure. Refer to PROGRAMMING THEFT DETERRENT SYSTEM COMPONENTS in Theft Deterrent.

Scheme 47

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR. Important: The abrasion sleeve located on the steering column wire harness assembly must be reinstalled. Make note of what connector, in the ignition lock cylinder case, is coming out of the middle of the abrasion sleeve for installation purposes.
2. Remove the steering column tilt head components. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (TILT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the ignition switch. Refer to «IGNITION SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the 3 pan head tapping screws (1) from the ignition lock cylinder case (2). Important: The lock bolt assembly (4) is under slight spring tension from the lock bolt spring (3). Hold the lock bolt (4) in place while removing the ignition lock cylinder case (2).
5. Remove the ignition lock cylinder case (2) and the lock bolt assembly (4) from the steering column tilt head assembly (5).
6. Remove the lock bolt spring (3) from the lock bolt assembly (4).

Scheme 48

1. Install the lock bolt spring (3) into the steering column tilt head assembly (5).
2. Position the cutout in the lock bolt assembly (4) at the 6 o'clock position.
3. Install the lock bolt assembly (4) into the steering column tilt head assembly (5).
4. Push the lock bolt assembly (4) into the steering column tilt head assembly (5) until the lock bolt assembly (4) is flush with the steering column tilt head assembly (5).
5. Align the ignition lock cylinder case (2) with the steering column tilt head assembly (5). NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
6. Screw the 3 pan head tapping screws (1) into the ignition lock cylinder case (2). Tighten Tighten the 3 screws to 7 N.m (62 lb in).
7. Install the ignition switch. Refer to «IGNITION SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Important: The abrasion sleeve must be installed back onto the steering column wire harness assembly. The ignition lock cylinder case wires and connector must be hanging out of the middle of the abrasion sleeve.
8. Install the steering column tilt head components. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (TILT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
9. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 49

Scheme 50

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR. Important: The abrasion sleeve located on the steering column wire harness assembly must be reinstalled. Make note of what connector, ignition lock cylinder case, is coming out of the middle of the abrasion sleeve for installation purposes.
2. Remove the steering column tilt head assembly. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (TILT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the ignition switch. Refer to «IGNITION SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the park lock cable assembly (1) from the ignition lock cylinder case in the following way: Place the steering column lock cylinder set into the OFF position. Place the shift lever clevis into the PARK position. Use a small blade to push against the locking tab on the end of the park lock cable assembly (1). Disconnect the park lock cable assembly (1) from the ignition lock cylinder case.
5. Remove the 3 TORX® screws (2) from the ignition lock cylinder case (1).
6. Remove the ignition lock cylinder case (1) from the steering column tilt head assembly.

Scheme 51

Scheme 52

1. Align the ignition lock cylinder case (1) with the steering column tilt head assembly. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Screw the 3 TORX® screws (2) into the ignition lock cylinder case (1). Tighten Tighten the screws to 7 N.m (62 lb in).
3. Place steering column lock cylinder set into the OFF position.
4. Place the shift lever clevis into the PARK position.
5. Press the locking tab on the end of the park lock cable assembly (1) into the slot in the ignition lock cylinder case.
6. Install the ignition switch. Refer to «IGNITION SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Important: The abrasion sleeve must be installed back onto the steering column wire harness assembly. The ignition lock cylinder case wires and connector must be hanging out of the middle of the abrasion sleeve.
7. Install the steering column tilt head assembly. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (TILT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT (STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
8. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 53

Scheme 54

Scheme 55

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Important: The abrasion sleeve located on the steering column wire harness assembly must be reinstalled. Make note of what connector is coming out of the abrasion sleeve for installation purposes.
3. Remove the wire harness assembly (1) from the wire harness strap (2).
4. Disconnect the turn signal and multifunction switch assembly connector from the SIR system coil connector.
5. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly out of the bulkhead connector (1).
6. Remove the 2 pan head tapping screws (1) and (3) from the turn signal and multifunction switch assembly (2).
7. Remove the turn signal and multifunction switch assembly (2) from the steering column tilt head assembly.

Scheme 56

Scheme 57

Scheme 58

1. Install the turn signal and multifunction switch assembly (2) onto the steering column tilt head assembly. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: Be sure that the electrical contact of the turn signal and multifunction switch assembly (2) rests on the turn signal cancel cam assembly.
2. Screw the 2 pan head tapping screws (1) and (3) into the turn signal and multifunction assembly (2). Tighten Tighten the top pan head tapping screw (1) to 3 N.m (30 lb in). Tighten the side pan head tapping screw (3) to 7 N.m (62 lb in).
3. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly into the bulkhead connector (1).
4. Connect the turn signal and multifunction switch assembly connector to the SIR coil connector. Important: The abrasion sleeve must be installed back onto the steering column wire harness assembly. The ignition lock cylinder case wires and connector must be hanging out of the middle of the abrasion sleeve.
5. Install the wire harness assembly (1) into the wire harness strap (2).
6. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 59

Scheme 60

Scheme 61

1. Remove the 2 TORX® head screws from the lower column trim cover.
2. Remove the lower column trim cover.
3. Roll back the seal on the shift lever (1) until the TORX® head screw (2) is exposed.
4. Remove the TORX® head screw (2).
5. Remove the knee bolster. Refer to KNEE BOLSTER REPLACEMENT in Instrument Panel, Gages and Console.
6. Remove the nuts (1) from the knee bolster deflector bracket NOTE: During removal of the steering column the wire harness retaining clip must be removed and reinstalled after installing the steering column or damage may occur to the wire harness.
7. Remove the wiring harness retaining pin (4) from the instrument panel.
8. Remove the wire straps and open the harness insulation to gain access to the electrical wiring.
9. Remove the wiring from the electrical connector.
10. Remove the shift lever (1).

Scheme 62

Scheme 63

Scheme 64

1. Install the shift lever (1).
2. Connect the shifter electrical connector.
3. Install the wire straps to the harness.
4. Install the harness retaining pin (4) to the instrument panel. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
5. Install the knee bolster deflector bracket and nuts (1). Tighten Tighten the nuts to 9 N.m (80 lb in).
6. Install the knee bolster. Refer to KNEE BOLSTER REPLACEMENT in Instrument Panel, Gages and Console.
7. Install the TORX® head screw. Tighten Tighten the screw to 1.5 N.m (13 lb in).
8. Roll the seal over the TORX® head screw.
9. Install the lower column trim cover.
10. Install the 2 TORX® head screws to the lower column trim cover. Tighten Tighten the screw to 3.5 N.m (31 lb in).

Scheme 65

1. Roll back the seal until the TORX® head screw (2) is exposed.
2. Remove the TORX® head screw (2).
3. Remove the shift lever (1).

Scheme 66

1. Install the shift lever (1). NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the TORX® head screw (2). Tighten Tighten the screw to 1.5 N.m (13 lb in).
3. Roll the seal over the TORX® head screw (2).

J 41396 Park Lock Cable Pliers

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the shift lever. Refer to «SHIFT LEVER REPLACEMENT (WITH TOW/HAUL SWITCH)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «SHIFT LEVER REPLACEMENT (WITHOUT TOW/HAUL SWITCH)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Disconnect the park lock cable assembly (1).
5. The steering column lock cylinder set should be in the OFF-LOCK position.
6. Insert a small screwdriver into the slot on the ignition lock cylinder case and push against the locking tab to remove.
7. Disconnect the automatic transmission shift lock control connector from the park position switch assembly.
8. Slide the park position switch assembly off of the linear shift assembly. NOTE: Do not use excessive force when removing the automatic transmission shift lock control from the steering column. Using excessive force may cause damage to the automatic transmission shift lock control and/or the steering column.
9. Remove the automatic transmission shift lock control from the steering column.
10. Use a small screwdriver to pry the automatic transmission shift lock control from the steering column jacket assembly.
11. Remove the 3 TORX® screws from the linear shift assembly.
12. Remove the linear shift assembly from the steering column support assembly.

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. Install the linear shift assembly onto the steering column support assembly. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Secure the linear shift assembly to the steering column assembly with the 3 flat head tapping screws. Move the linear shift assembly out of the PARK position to install the lower socket tapping screw. Tighten Tighten the 3 TORX® screws to 10 N.m (89 lb in).
3. Install the automatic transmission shift lock control.
4. Install the shift lever clevis and put the column in the neutral position.
5. The neutral position is 2 positions from the park position.
6. Slide the park position switch assembly onto the linear shift assembly.
7. Connect the automatic transmission shift lock control connector onto the park position switch assembly.
8. Connect the park lock cable assembly (1) to the ignition lock cylinder case in the following way: Place the steering column lock cylinder set into the off position. Place the shift lever clevis into the park position. Press the locking tab on the end of the park lock cable assembly (1) into the slot in the ignition lock cylinder case.
9. Install the shift lever. Refer to «SHIFT LEVER REPLACEMENT (WITH TOW/HAUL SWITCH)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «SHIFT LEVER REPLACEMENT (WITHOUT TOW/HAUL SWITCH)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
10. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
11. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Pull the lever out of the steering column.

Scheme 75

Scheme 76

1. Align the lever in the steering column.
2. Push the lever into the steering column.

Scheme 77

Scheme 78

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the inflatable restraint steering wheel module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR.
3. Remove the horn plunger from the steering column by pressing inward to the stop and rotating the horn plunger 90 degrees.
4. Disconnect the captured screws (1,4) to the horn contact plate (2) from the steering wheel (3).
5. Remove the horn switch (2) from the steering wheel (3).

Scheme 79

Scheme 80

1. Install the horn switch (2) to the steering wheel (3). NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Connect the captured screws (1,4) from the horn contact plate (2) to the steering wheel (3). Tighten Tighten the screws to 5.5 N.m (50 lb in).
3. Install the horn plunger to the steering column.
4. Install the inflator module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR.
5. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 81

Scheme 82

Scheme 83

1. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
2. Remove the shroud retaining screws from the back of the steering wheel.
3. Remove the shroud from the steering wheel.
4. Position a blunt ended tool into the wire harness cavity (1) and apply moderate pressure in order to partially remove the steering wheel control switch from the steering wheel.
5. Disconnect the steering wheel control switch electrical connector. Important: The bulbs in the steering wheel control switches are not serviceable. The switches should be replaced only as an assembly.
6. Remove the steering wheel control switch from the steering wheel.

Scheme 84

Scheme 85

1. Position the steering wheel control switch to the steering wheel.
2. Connect the electrical connector to the steering wheel control switch.
3. Install the steering wheel control switch into the steering wheel, ensuring the retaining tabs are fully seated.
4. Install the shroud to the steering wheel. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
5. Install the shroud retaining screws to the steering wheel. Tighten Tighten the screws to 2 N.m (18 lb in).
6. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

J 1859-A Steering Wheel Puller

Scheme 86

1. Disable the supplemental inflatable restraint (SIR) system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the inflator module. Refer to «HORN SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) in SIR.
3. Remove the horn switch. Refer to «HORN SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Make an alignment mark in order to note the relationship of the steering wheel to the steering shaft.
5. Remove the steering wheel nut.
6. Remove the steering wheel, using J 1859-A .

Scheme 87

1. Align the marks made during the removal of the steering shaft and the steering wheel.
2. Install the steering wheel onto the steering shaft. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
3. Install the steering wheel nut to the steering shaft. Tighten Tighten the nut to 40 N.m (29 lb ft).
4. Install the horn switch. Refer to «HORN SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Install the inflator module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR.
6. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Repair Procedure

1. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
2. Wash the wood section of the wheel with wax and grease remover.
3. Mask off the non-wood area of the steering wheel. Important: Do NOT sand through the clear.
4. Sand with 400 grit sand paper first. Finish sanding with 600 grit.
5. Wash the wood section of the wheel again with wax and grease remover.
6. Clear coat the steering wheel. Refer to the 2003 GM Approved Refinish Materials Booklet, GM 4901 M-D-2003 (English) or M-D-F2003 (French).
7. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

Scheme 88

Scheme 89

Scheme 90

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Install the tilt lever onto the steering column tilt head assembly.
4. Use the tilt lever to tilt the column to the UP position. CAUTION: The tilt spring and the spring guide are under pressure. The tilt spring and the spring guide may become a projectile. Secure the spring with locking pliers during removal. Secure the spring with locking pliers during installation. Bodily injury may result during removal and installation of the tilt spring and the spring guide. Always use caution during removal and installation of the tilt spring and the spring guide.
5. Remove the tilt spring (1) from the steering column support assembly (2) and from the steering column tilt head assembly (3) by using the following procedure: Pry up the tilt spring (1) until a bulge occurs and most of the tilt spring tension is removed. Secure the tilt spring (1) with locking pliers. Continue prying up the tilt spring (1) until the tilt spring disengages from the post on the steering column support assembly (2) and from the steering column tilt head assembly (3).
6. Remove the spring guide (1) from the tilt spring (2).

Scheme 91

Scheme 92

Scheme 93

1. Use the tilt lever to tilt the column to the UP position.
2. Install the spring guide into the tilt spring. CAUTION: The tilt spring and the spring guide are under pressure. The tilt spring and the spring guide may become a projectile. Secure the spring with locking pliers during removal. Secure the spring with locking pliers during installation. Bodily injury may result during removal and installation of the tilt spring and the spring guide. Always use caution during removal and installation of the tilt spring and the spring guide.
3. Install the tilt spring (1) onto the steering column support assembly (2) and onto the steering column tilt head assembly by using the following procedure: Install the tilt spring (1) onto the steering column tilt head assembly. Install the tilt spring (1) onto the post on the steering column support assembly (2).
4. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 94

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the turn signal cancel cam assembly. Refer to «TURN SIGNAL CANCEL CAM AND UPPER BEARING THRUST WASHER»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the turn signal and multifunction switch assembly only. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Slide the turn signal switch housing off of the steering column shaft assembly.
5. Remove the tilt head housing and steering shaft as an assembly. Refer to «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Remove the tilt head from the steering shaft.

Scheme 95

1. Install the tilt head onto the steering shaft.
2. Install the tilt head housing and steering shaft as an assembly. Refer to «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Important: The switch mounting bracket must be pressed firmly against the steering column tilt head.
3. Slide the turn signal switch housing onto the steering column shaft assembly.
4. Install the turn signal and multifunction switch assembly only. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Install the turn signal cancel cam assembly. Refer to «TURN SIGNAL CANCEL CAM AND UPPER BEARING THRUST WASHER»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

1. J 23653-SIR Steering Column Lock Plate Compressor
2. J 42137 Steering Column Lock Plate Compressor Adapter

Scheme 96

Scheme 97

Scheme 98

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the turn signal cancel cam and upper bearing thrust washer. Refer to «TURN SIGNAL CANCEL CAM AND UPPER BEARING THRUST WASHER»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the turn signal and multifunction switch assembly only. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Slide the turn signal switch housing off of the steering column shaft assembly. Important: Let the SIR coil hang freely after removal.
5. Remove the SIR coil. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR.
6. Compress the cam orientation plate using J 23653-SIR and J 42137 .
7. Remove the bearing retainer using J 23653-SIR and J 42137 from the steering column shaft assembly.
8. Remove J 23653-SIR and J 42137 from the steering column shaft assembly.
9. Discard the bearing retainer.
10. Remove the following parts from the steering column shaft assembly: The cam orientation plate (5) The turn signal cancel cam assembly (4) The upper bearing spring (3) The upper bearing inner race seat (2) The inner race (1) Remove the tilt head housing and steering shaft as an assembly. Refer to «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) . Remove the tilt head from the steering shaft.

Scheme 99

Scheme 100

Scheme 101

1. Install the tilt head onto the steering shaft.
2. Install the tilt head housing and steering shaft as an assembly. Refer to «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT LEAN SHAFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (COLUMN SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «LOWER BEARING AND STEERING COLUMN JACKET REPLACEMENT (FLOOR SHIFT STANDARD)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Lubricate the lower brass surface of the turn signal cancel cam assembly with GM P/N 12377900 (Canadian P/N 10953529). Lubricate the inner race with GM P/N 12345718 (Canadian P/N 10953516)
4. Install the following parts onto the steering column shaft assembly: The inner race The upper bearing inner race seat (2) The upper bearing spring (3) The turn signal cancel cam assembly (4) The cam orientation plate (5)
5. Install the new bearing retainer onto the steering column shaft assembly.
6. Compress the cam orientation plate using J23653-SIR and J 42137 . Firmly seat the bearing retainer into the groove on the steering column shaft assembly.
7. Remove J 23653-SIR from the steering column shaft assembly.
8. Install the SIR coil. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR. Important: The switch mounting bracket must be pressed firmly against the steering column tilt head.
9. Slide the turn signal switch housing onto the steering column shaft assembly.
10. Install the turn signal and multifunction switch assembly only. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
11. Install the turn signal cancel cam and upper bearing thrust. Refer to «TURN SIGNAL CANCEL CAM AND UPPER BEARING THRUST WASHER»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
12. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

1. J 23653-SIR Steering Column Lock Plate Compressor
2. J 42137 Steering Column Lock Plate Compressor Adapter

Scheme 102

Scheme 103

Scheme 104

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR. Important: Let the SIR coil hang freely after removal.
2. Remove the SIR coil. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR.
3. Remove and discard the bearing retainer using J 23653-SIR and J 42137 .
4. If standard column, remove the following parts from the steering shaft assembly: The cam orientation plate (4) The turn signal cancel cam assembly (3) The upper bearing spring (2) The thrust washer (1)
5. If tilt column, remove the following parts from the steering column shaft assembly: The cam orientation plate (5) The turn signal cancel cam assembly (4) The upper bearing spring (3) The upper bearing inner race seat (2) The inner race (1)

Scheme 105

Scheme 106

Scheme 107

1. If standard column, install the following parts onto the steering shaft assembly: The thrust washer (1) The upper bearing spring (2) Lubricate the turn signal cancel cam assembly (3) with GM P/N 12377900 (Canadian P/N 10953529). The turn signal cancel cam assembly (3) onto the steering shaft assembly The cam orientation plate (4) onto the steering shaft assembly
2. If tilt column, install the following parts onto the steering column shaft assembly: Lubricate the inner race (1) with GM P/N 12345718 (Canadian P/N 10953516) The inner race (1) The upper bearing inner race seat (2) The upper bearing spring (3) Lubricate the turn signal cancel cam assembly (4) with GM P/N 12377900 (Canadian P/N 10953529). The turn signal cancel cam assembly (4) onto the steering shaft assembly The cam orientation plate (5)
3. Install the new bearing retainer onto the steering shaft assembly.
4. Compress the cam orientation plate using J 23653-SIR and J 42137 .
5. Firmly seat the bearing retainer into the groove on the steering shaft assembly.
6. Remove J 23653-SIR .
7. Install the SIR coil. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-driver-side) in SIR.
8. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 42640 Steering Column Anti-Rotation Pin

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

1. Disable the supplemental inflatable restraint (SIR) system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the knee bolster. Refer to KNEE BOLSTER REPLACEMENT in Instrument Panel, Gages and Console. NOTE: The front wheels of the vehicle must be maintained in the straight ahead position and the steering column must be in the LOCK position before disconnecting the steering column or intermediate shaft. Failure to follow these procedures will cause improper alignment of some components during installation and result in damage to the SIR coil assembly.
3. Lock the steering column through the access hole in the lower trim cover using J 42640 .
4. Remove the body control module bracket. Do not disconnect the harness from the body control module. Refer to BODY CONTROL MODULE REPLACEMENT in Body Control System.
5. Disconnect the transmission shift cable (1) from the column.
6. Disconnect the steering column electrical connectors. NOTE: During removal of the steering column the wire harness retaining clip must be removed and reinstalled after installing the steering column or damage may occur to the wire harness.
7. Remove the wiring harness retaining pin (4) from the instrument panel.
8. Remove the upper intermediate shaft pinch bolt (1) from the steering column, and remove the shaft from the steering column.
9. Remove the nuts (1) from the knee bolster deflector.
10. Remove the nuts from the upper support brackets.
11. Remove the nuts from the lower support brackets. NOTE: Once the steering column is removed from the vehicle, the column is extremely susceptible to damage. Dropping the column assembly on the end could collapse the steering shaft or loosen the plastic injections, which maintain column rigidity. Leaning on the column assembly could cause the jacket to bend or deform. Any of the above damage could impair the columns collapsible design. Do NOT hammer on the end of the shaft, because hammering could loosen the plastic injections, which maintain column rigidity. If you need to remove the steering wheel, refer to the Steering Wheel Replacement procedure in this section.
12. Remove the steering column from the vehicle.

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

1. Install the steering column to the vehicle. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the lower column nuts. Tighten Tighten the nuts to 30 N.m (22 lb ft).
3. Install the nuts to upper support brackets. Tighten Tighten the nuts to 30 N.m (22 lb ft).
4. Install the nuts (1) which retain the knee bolster deflector to the instrument panel. Tighten Tighten the retaining nuts to 9 N.m (80 lb in).
5. Install the wiring harness retaining (4) pin to the instrument panel.
6. Connect the steering column electrical connectors to the vehicle wiring harness. Tighten Tighten the connector to 6 N.m (53 lb in).
7. Connect the transmission shift cable (1) to the steering column.
8. Install the body control module bracket. Refer to BODY CONTROL MODULE REPLACEMENT in Body Control System.
9. Install the knee bolster. Refer to KNEE BOLSTER REPLACEMENT in Instrument Panel, Gages, and Console.
10. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
11. Remove J 42640 from the steering column.

Scheme 121

1. Set the front wheels in the straight-ahead position.
2. Set the steering wheel in the LOCK position.
3. Remove the intermediate shaft. Refer to «INTERMEDIATE STEERING SHAFT REPLACEMENT - LOWER»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the nuts from the studs.
5. Remove the seal from the vehicle.

Scheme 122

1. Install the seal to the vehicle. NOTE: Refer to «FASTENER NOTICE»(/cadillac/escalade/gmt800-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the nuts to the studs. Tighten Tighten the nuts to 3 N.m (25 lb in).
3. Install the intermediate shaft. Refer to «INTERMEDIATE STEERING SHAFT REPLACEMENT - LOWER»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

J 21854-01 Pivot Pin Remover

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the tilt spring assembly only. Refer to «TILT SPRING REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Remove the linear shift and the automatic shift lock control. Refer to «LINEAR SHIFT ASSEMBLY REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Inspect the steering column for accident damage. Refer to «STEERING COLUMN ACCIDENT DAMAGE INSPECTION»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Remove the sensor retainer (1) from the steering column jacket assembly (3).
8. Remove the steering shaft position sensor (2) from the steering column jacket assembly (3).
9. Remove the adapter and bearing assembly (1) from the steering column shaft assembly.
10. Remove the 2 pivot pins (3) from the steering column tilt head assembly (1) by using J 21854-01 .
11. Install the tilt lever into the steering column tilt head assembly (1).
12. Pull back on the tilt lever and at the same time pull the steering column tilt head assembly (1) down and away from the steering column.
13. Remove the steering column tilt head assembly (1) with the steering column shaft assembly from the steering column jacket assembly (2).
14. Remove the tilt lever.
15. Remove the steering column shaft assembly (2) from the steering column tilt head assembly (1).
16. Remove the 4 TORX® head screws (2) from the steering column support assembly (1).
17. Discard the 4 TORX® head screws.
18. Remove the steering column support assembly (1) from the steering column jacket assembly.

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Important: Replace the steering column support assembly (1) if the steering column support assembly (1) has been staked 3 times.

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. Attach the steering column support assembly (1) to the steering column jacket assembly (3) with 4 TORX® head screws (2). Tighten Tighten the screws to 17 N.m (13 lb ft).
2. Install the steering column shaft assembly (2) into the steering column tilt head assembly (1).
3. Install the steering column shaft assembly with the steering column tilt head assembly (1) into the steering column jacket assembly (2).
4. Maneuver the tilt knob and push the steering column tilt head assembly (1) up towards the steering column in order to lock the steering wheel lock shoes in place.
5. Lubricate the pivot pins (1) with GM P/N 12346293 (Canadian P/N 992723).
6. Firmly seat each pivot pin (1) into the steering column tilt head assembly.
7. Stake the steering column support assembly in 3 locations around each pivot pin.
8. Install the adapter and bearing assembly (1) onto the steering column jacket assembly by performing the following steps: Align the tab on the adapter and bearing assembly (1) with the slot in the steering column jacket assembly. Push the adapter and bearing assembly (1) onto the steering column shaft assembly until the tab snaps into the slot.
9. Install the steering shaft position sensor (2) onto the steering column jacket assembly (3).
10. Install the sensor retainer (1) onto the steering column jacket assembly (3).
11. Install the linear shift and the automatic transmission shift lock control only. Refer to «LINEAR SHIFT ASSEMBLY REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
12. Install the tilt spring only. Refer to «TILT SPRING REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
13. Install the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
14. Install the steering column into the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
15. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 21854-01 Pivot Pin Remover

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the tilt spring only. Refer to «TILT SPRING REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Inspect the steering column for accident damage. Refer to «STEERING COLUMN ACCIDENT DAMAGE INSPECTION»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Remove the adapter and bearing assembly (1) from the steering shaft assembly.
7. Remove the 2 pivot pins (3) from the steering column tilt head assembly (1) by using J 21854-01 .
8. Install the tilt knob into the steering column tilt head assembly (1).
9. Pull back on the tilt knob and at the same time pull the steering column tilt head assembly (1) down and away from the steering column.
10. Remove the steering column tilt head assembly (1) with the steering shaft assembly from the steering column support assembly (2).
11. Remove the tilt knob.
12. Remove the steering shaft assembly (2) from the steering column tilt head assembly (1).
13. Remove the 4 TORX® head screws (2) from the steering column support assembly (1).
14. Discard the 4 TORX® head screws.
15. Remove the steering column support assembly (1) from the steering column jacket assembly.

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Important: Replace the steering column support assembly if the steering column support assembly has been staked 3 times.

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

1. Attach the steering column support assembly (1) to the steering column jacket assembly with 4 new TORX® head screws (2). Tighten Tighten the screws to 17 N.m (13 lb ft).
2. Install the steering column shaft assembly (2) into the steering column tilt head assembly (1).
3. Install the steering column shaft assembly with the steering column tilt head assembly (1) into the steering column support assembly (2).
4. Move the tilt knob and push the steering column tilt head assembly up towards the steering column in order to lock the steering wheel lock shoes in place. Important: Replace the steering column support assembly if the steering column support assembly has been staked 3 times.
5. Lubricate the pivot pins (1) with GM P/N 12346293 (Canadian P/N 992723).
6. Firmly seat each pivot pin (1) into the steering column tilt head assembly.
7. Stake the steering column support assembly in 3 locations around each pivot pin (1).
8. Install the adapter and bearing assembly (1) onto the steering column jacket assembly by performing the following steps: Align the tab on the adapter and bearing assembly (1) with the slot in the steering column jacket assembly. Push the adapter and bearing assembly (1) onto the steering column shaft assembly until the tab snaps into the slot. Important: Be sure that the electrical contact of the turn signal and multifunction switch assembly (2) rests on the turn signal cancel cam assembly.
9. Install the turn signal and multifunction switch assembly (2) onto the steering column tilt head assembly.
10. Screw the 2 pan head tapping screws (1) into the turn signal and multifunction switch assembly (2). Tighten Tighten the screws to 7 N.m (62 lb in).
11. Install the tilt spring only. Refer to «TILT SPRING REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
12. Install the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
13. Install the steering column into the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
14. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 146

Scheme 147

Scheme 148

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the steering wheel from the column. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Remove the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Remove the linear shift assembly. Refer to «LINEAR SHIFT ASSEMBLY REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Inspect the steering column for accident damage. Refer to «STEERING COLUMN ACCIDENT DAMAGE INSPECTION»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
8. Remove the adapter and bearing assembly (1) from the steering shaft assembly.
9. Remove the steering shaft assembly (1) from the steering column support assembly (2) and the steering column jacket assembly (3).
10. Remove the 4 TORX® head screws (1) from the steering column support assembly (2).
11. Discard the 4 TORX® head screws (1).
12. Remove the steering column support assembly (2) from the steering column jacket assembly (3).

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Scheme 149

Scheme 150

Scheme 151

1. Attach the steering column support assembly (2) to the steering column jacket assembly (3) with 4 TORX® head screws (1). Tighten Tighten the screws to 17 N.m (13 lb ft).
2. Install the steering shaft assembly (1) into the steering column support assembly (2).
3. Install the adapter and bearing assembly (1) onto the steering column jacket assembly.
4. Install the linear shift assembly. Refer to «LINEAR SHIFT ASSEMBLY REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Install the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Install the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Install the steering column into the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
8. Install the steering wheel onto the steering column. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
9. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 152

Scheme 153

Scheme 154

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the steering wheel from the column. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
3. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Remove the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Remove the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Inspect the steering column assembly for accident damage. Refer to «STEERING COLUMN ACCIDENT DAMAGE INSPECTION»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Remove the adapter and bearing assembly (1) from the steering shaft assembly.
8. Remove the steering shaft assembly (1) from the steering column support assembly (2) and the steering column jacket assembly (3).
9. Remove the 4 TORX® head screws (1) from the steering column support assembly (2).
10. Discard the 4 TORX® head screws (1).
11. Remove the steering column support assembly (2) from the steering column jacket assembly (3).

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Scheme 155

Scheme 156

Scheme 157

1. Attach the steering column support assembly (2) to the steering column jacket assembly (3) with 4 new TORX® head screws (1). Tighten Tighten the screws to 17 N.m (13 lb ft).
2. Install the steering shaft assembly (1) into the steering column support assembly (2) and the steering column jacket assembly (3).
3. Install the adapter and bearing assembly (1) onto the steering column jacket assembly. Align the tab on the adapter and bearing assembly (1) with the slot in the steering column jacket assembly. Push the adapter and bearing assembly (1) onto the steering shaft assembly until the tab snaps into the slot.
4. Install the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
5. Install the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT (FLOOR SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) or «IGNITION LOCK CYLINDER CASE REPLACEMENT (COLUMN SHIFT)»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
6. Install the steering column into the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
7. Install the steering wheel onto the steering column. Refer to «STEERING WHEEL REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
8. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Scheme 158

Scheme 159

1. Disable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR. Important: A new sensor must come with a pin installed. If pin is not installed, return and reorder sensor.
2. The steering wheel must be in the straight position.
3. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
4. Set the steering wheel in the LOCKED position.
5. If necessary to lock the column, install the anti rotation pin into the steering column.
6. Remove the nut and the bolt from the upper intermediate shaft connection and slide the intermediate steering shaft down. Important: Do not apply force to the sensor and the bearing assembly in a sideways direction.
7. Remove the sensor connector by using a suitable tool in order to pull the connector down around the right side of the steering column for accessibility.
8. Remove the sensor retainer from the steering shaft. Important: When reusing the sensor (1) you must install a pin into the sensor before it is removed from the steering shaft. By not installing a pin into the sensor it will cause the sensor to lose its centering position and must be discarded. Pin diameter must be in the range of 1.0-2.0 mm. Do not remove the bearing adapter (3).
9. If reusing the sensor (1), remove the position sensor by pulling the sensor straight out from the bearing adapter (3) until the sensor is almost off the steering shaft (2). Install a pin into the sensor before removing from the steering shaft (2). Do not remove the pin until the sensor is re-installed.
10. If replacing the sensor (1), remove the sensor by pulling the sensor straight out from the bearing adapter (3) and off the steering shaft.

Important: Do not apply force to the sensor (1) or the bearing adapter (3) in a sideways direction.

Scheme 160

Scheme 161

1. If reusing the sensor, with the pin still installed, align the sensor onto the steering shaft (2) and into the bearing adapter (3). Important: If installing a new sensor the sensor will come presented. Do not remove the pin until installation is complete.
2. Install the sensor onto the steering shaft (2) and into the bearing adapter (3).
3. The sensor must be set to approximately 3.00 mm gap between the sensor and the bearing adapter.
4. Install the sensor connector.
5. Remove the pin from the sensor. Install the sensor retainer onto the steering shaft. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
6. Slide the shaft up to install the bolt and the nut to the upper intermediate shaft to steering column connection. Tighten Tighten the upper intermediate shaft connection to 47 N.m (35 lb ft).
7. For vehicles with Rear Wheel Steering, check the wheel alignment. Refer to MEASURING WHEEL ALIGNMENT (WITH REAR WHEEL STEERING) or MEASURING WHEEL ALIGNMENT (WITHOUT REAR WHEEL STEERING) in Wheel Alignment.
8. Install the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
9. Enable the SIR system. Refer to «ZONE 3»(/cadillac/escalade/gmt800-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Important: Identify the type of steering wheel position sensor from the illustrations below BEFORE removing the sensor from the steering column. Once you have identified the steering wheel position sensor, follow the instructions listed in the removal procedure.

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

1. Verify the type of steering wheel position sensor.
2. From the technicians point of view, the FRONT of the sensor (1) connector will be on the right. Important: If reusing the existing sensor, you do not have to align the sensor before removal. Centering is not required when it is time to reinstall.
3. Remove the connector from the sensor.
4. Remove the sensor (1) from the adapter and bearing assembly.
5. To install the sensor, proceed to step 1 in the installation section.
6. From the technicians point of view, the FRONT of the sensor will have: A foam ring (2) A pin hole (1) for centering the pin (note location of the pin hole) A flush rotor flange cuff (4) Important: If reusing the existing sensor, you must make an alignment mark on the rotor flange cuff (3) before removing the sensor. Failure to do so will cause misalignment when installing the sensor. A new sensor will be required if misaligned.
7. Make an alignment mark on the flush rotor flange cuff (3).
8. Remove the connector from the sensor.
9. Remove the sensor from the adapter and bearing assembly.
10. To install the sensor, proceed to step 5 in the installation section.
11. From the technicians point of view, the FRONT of the sensor will have: A raised rotor flange cuff (3) An alignment mark (2) on the rotor flange cuff (3) for installation A pin hole (1) for the centering pin (note location of the pin hole)
12. Remove the connector from the sensor.
13. Remove the sensor from the adapter and bearing assembly.
14. To install the sensor, proceed to step 9 in the installation section.
15. From the technicians point of view, the FRONT of the sensor will have: A raised rotor flange cuff (3) An alignment mark (2) on the rotor flange cuff (3) for installation A pin hole (1) for the centering pin (note location of the pin hole) A sensor clip in FRONT of the sensor
16. Remove the connector from the sensor.
17. Remove the sensor clip from the sensor.
18. Remove the sensor from the adapter and bearing assembly.
19. To install the sensor, proceed to step 13 in the installation section.
20. From the technicians point of view, the FRONT of the sensor will have: A flush rotor flange cuff (3) A pin hole (1) for the centering pin (note location of the pin hole) An alignment mark (2) on the flush rotor flange cuff (3) for installation
21. Remove the connector from the sensor.
22. Remove the sensor from the adapter and bearing assembly.
23. To install the sensor, proceed to step 17 in the installation section.
24. From the technicians point of view, the FRONT of the sensor will have: A flush rotor flange cuff (4) A pin hole (2) for the centering pin (note location of the pin hole) An alignment mark (3) on the flush rotor flange cuff (4) for installation A foam ring (1)
25. Remove the connector from the sensor.
26. Remove the sensor from the adapter and bearing assembly.
27. To install the sensor, proceed to step 21 in the installation section.

Important: If reusing the existing sensor, no centering of the sensor is required.

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

1. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated.
2. From the technicians point of view, the FRONT of the sensor (1) connector will be on your right. From the technicians point of view the BACK of the sensor (2) connector will be on your left.
3. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
4. Install the connector to the sensor.
5. From the technicians point of view, the FRONT of the sensor will have: A foam ring (4) A pin hole (7) for the centering pin (note location of the pin hole) A flushed rotor flange cuff (6) An alignment mark (5) for installation
6. From the technicians point of view, the BACK of the sensor will have: Double D flats (1) A foam ring (3) An alignment tab (2) for installing into the adapter and bearing assembly. A view of the inside of the connector Important: If reusing the existing sensor, you must align the marks on the flush rotor flange cuff before installation. The alignment mark must stay aligned until the sensor is seated into the adapter and bearing assembly. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated. If the new sensor did not come with a pin installed, you must reorder a new sensor.
7. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
8. Install the connector to the sensor.
9. From the technicians point of view, the FRONT of the sensor will have: A pin hole (3) for the centering pin (note location of the pin hole) A raised rotor flange cuff (5) An alignment mark (4) for installation
10. From the technicians point of view, the BACK of the sensor will have: Double D flats (1) An alignment tab (2) for installing into the adapter and bearing assembly. Important: If reusing the existing sensor, you must align the marks on the raised rotor flange cuff before installation. The alignment mark must stay aligned until the sensor is seated into the adapter and bearing assembly. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated. If the new sensor did not come with a pin installed, you must reorder a new sensor.
11. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
12. Install the connector to the sensor.
13. From the technicians point of view, the FRONT of the sensor will have: A pin hole (2) for the centering pin (note location of the pin hole) A raised rotor flange cuff (4) An alignment mark (3) for installation
14. From the technicians point of view, the BACK of the sensor will have an alignment tab (1) for installation. This sensor does not have double D flats. Important: If reusing the existing sensor, you must align the marks on the raised rotor flange cuff before installation. The alignment mark must stay aligned until the sensor is seated into the adapter and bearing assembly. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated. If the new sensor did not come with a pin installed, you must reorder a new sensor.
15. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
16. Install the connector to the sensor.
17. From the technicians point of view, the FRONT of the sensor will have: A pin hole (2) for the centering pin (note location of the pin hole) A flush rotor flange cuff (4) An alignment mark (3) for installation
18. From the technicians point of view, the BACK of the sensor will have an alignment tab (1) for installation. This sensor does not have double D flats. Important: If reusing the existing sensor, you must align the marks on the flush rotor flange cuff before installation. The alignment mark must stay aligned until the sensor is seated into the adapter and bearing assembly. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated. If the new sensor did not come with a pin installed, you must reorder a new sensor.
19. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
20. Install the connector to the sensor.
21. From the technicians point of view, the FRONT of the sensor will have: A pin hole (3) for the centering pin (note location of the pin hole) A flush rotor flange cuff (5) An alignment mark (4) for installation A foam ring (6)
22. From the technicians point of view, the BACK of the sensor will have: Double D flats (1) An alignment tab (2) for installing into the adapter and bearing assembly. Important: If reusing the existing sensor, you must align the marks on the flush rotor flange cuff before installation. The alignment mark must stay aligned until the sensor is seated into the adapter and bearing assembly. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated. If the new sensor did not come with a pin installed, you must reorder a new sensor.
23. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
24. Install the connector to the sensor.

Inflatable Restraint Steering Wheel Module Coil Centering

Note. The new SIR coil assembly will be centered. Improper alignment of the SIR coil assembly may damage the unit, causing an inflatable restraint malfunction.

Important: If double wire harness strap is installed onto the wire harness assembly and column, you must reuse the holder for the wire straps during installation.

Remove the wire harness strap(s) where necessary.

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

1. Verify the following conditions before centering the SIR coil: The wheels on the vehicle are straight ahead. The block tooth (1) of the steering shaft assembly is in the 12 o'clock position. The ignition switch is in the LOCK position.
2. If the front (5) of the SIR coil has a centering window (4), and the back side (2) includes a spring service lock (1), perform the following steps: Hold the SIR coil with the face up. While depressing the spring service lock, rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counterclockwise, until the centering window appears yellow and both arrows (3) line up. Release spring service lock between the locking tab. The SIR coil is now centered. Align the centered SIR coil with the horn tower and slide onto the steering shaft assembly.
3. If the front (4) of the SIR coil has a centering window (3), and the back side (1) includes NO spring service lock, perform the following steps: Hold the SIR coil with the face up. Rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counterclockwise until the centering window appears yellow and both arrows (2) line up. This is the CENTER position. While holding the coil hub in the CENTER position, align the SIR coil with the horn tower and slide onto the steering shaft assembly.
4. If the front side (3) of the SIR coil has NO centering window, but the back side (2) includes a spring service lock (1), perform the following steps: Hold the SIR coil with the back side up. While depressing the spring service lock, rotate the coil hub in the direction of the arrow (4) until the coil ribbon stops. Still pressing the spring service lock, rotate the coil hub in the opposite direction 2 1/2 revolutions. Release the spring service lock between locking tabs. The SIR coil is now centered. Align the centered SIR coil with the horn tower and slide onto the steering shaft assembly.
5. For the front side (2) of the SIR coil has NO centering window, and the back side (1) includes NO spring service lock, perform the following steps: Hold the SIR coil with the face up. Rotate the coil hub in the direction of the arrow until the coil ribbon stops. Rotate the coil hub, slowly, counterclockwise, for 2 1/2 revolutions. This is the CENTER position. While maintaining the coil hub in the CENTER position, align the centered SIR coil with the horn tower and slide onto the steering shaft assembly.
6. If double wire harness strap is installed onto the wire harness assembly and column, you must route the wires up against the steering column. One wire harness strap will surround one lead from the coil to the steering column. The other wire harness strap will surround all leads to the steering column.

Steering Wheel and Column Description and Operation

The steering wheel and column has 4 primary functions

1. Vehicle steering
2. Vehicle security
3. Driver convenience
4. Driver safety

Vehicle Steering

The steering wheel is the first link between the driver and the vehicle. The steering wheel is fastened to a steering shaft within the column. At the lower end of the column, the intermediate shaft connects the column to the steering gear.

Vehicle Security on Some Vehicle Models

Theft deterrent components are mounted and designed into the steering column. The following components allow the column to be locked in order to minimize theft

1. The ignition switch
2. The manual transmission steering column lock
3. The ignition cylinder

Driver Convenience

The steering wheel and column may also have driver controls attached for convenience and comfort. The following controls may be mounted on or near the steering wheel or column.

1. The turn signal switch
2. The hazard switch
3. The headlamp dimmer switch
4. The wiper/washer switch
5. The horn pad/cruise control switch
6. The redundant radio/entertainment system controls
7. The tilt or tilt/telescoping functions
8. The navigation/OnStar® features
9. The HVAC controls

Driver Safety

The energy-absorbing steering column compresses in the event of a front-end collision, which reduces the chance of injury to the driver. The mounting capsules break away from the mounting bracket in the event of an accident.

Scheme 179

Scheme 180

See also:
• ACCELERATOR PEDAL POSITION SENSOR
• FASTENER NOTICE
• SIR CAUTION
• REMOVAL & INSTALLATION (DRIVER-SIDE)
• ZONE 3
• SERVICING THE SIR SYSTEM CAUTION
• STEERING WHEEL AND COLUMN DESCRIPTION AND OPERATION
• Lock System Does Not Unlock
