Interior Trim Cadillac Escalade GMT800

Exterior/interior Trim 58 illustrations ~4398 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Door Sill Trim Plate Screws2 N.m18 lb in
Floor Console Bolts6 N.m53 lb in
Jack and Tool Stowage Container Retaining Nut5 N.m44 lb in
Overhead Console Screws2 N.m18 lb in
Quarter Panel Trim Armrest Screws2 N.m18 lb in
Quarter Panel Trim Screws2 N.m18 lb in
Sunshade Screws2 N.m18 lb in
Tool Storage Compartment Bracket Nuts50 N.m36 lb ft
Tool Storage Compartment Nuts10 N.m88 lb in

Fastener Tightening Specifications

Eliminating Unwanted Odors in Vehicles

GM Vehicle Care Odor Eliminator, GM P/N 12378554, US ACDelco 88900909, Canadian P/N 88901678, may control or eliminate odors in the interior and luggage compartment areas of GM vehicles. This non-toxic, biodegradable, odorless product has been shown to greatly reduce or remove the following types of odor

  1. Objectionable smells of mold and mildew resulting from vehicle water leaks
  2. Customer created odors, such as smoke

You may safely use GM Vehicle Care Odor Eliminator on fabrics, vinyl, leather, carpet, and sound deadening materials. You may also induce this product into HVAC modules and instrument panel ducts for the control of non-bacterial related odors.

Important: This product leaves no residual scent and should not be used as an air freshener.

This product may result in the permanent elimination of an odor and may be preferable to customers whose all majors make them sensitive to perfumes.

This product may effectively remove odors when directly contacting the odor source. In cases such as water leaks, use this product with diagnostic procedures to first eliminate the primary cause of the odor. Then use further applications on the residual odor to permanently correct the vehicle condition.

How to Use this Product

  1. Spray GM Vehicle Care Odor Eliminator directly or as an additive with carpet shampoo in steam cleaners.
  2. Do not use on any interior surface that plain water would deteriorate, because this product will have the same effect. Also avoid letting this product come into contact with vinegar or any acidic substance. Acid-based products will hamper the effectiveness of GM Vehicle Care Odor Eliminator.
  3. Instructions and cautions are printed on the bottle, but additional help is available. If you encounter a persistent or recurring odor, you may call to obtain additional information and usage suggestions. In the USA, call 1-800-955-8591. In Canada, call 1-800-977-4145.

Scheme 1

Scheme 1: Removal Procedure
Scheme 1: Removal Procedure
  1. Remove the sill plate. Firmly pull the sill plate up and out from the retainers.
  2. Remove the sill plate from the vehicle. Start from the front of the door sill. Use a flat-bladed tool in order to pry the door sill plate.

Scheme 2

Scheme 2: Installation Procedure
Scheme 2: Installation Procedure
  1. Install the sill plate.
  2. Push the sill plate down until the sill plate locks into place.

Scheme 3

Scheme 3: Removal Procedure
Scheme 3: Removal Procedure
  1. Use a flat-bladed tool in order to pry the door sill plate.
  2. Remove the sill plate from the vehicle.

Scheme 4

Scheme 4: Installation Procedure
Scheme 4: Installation Procedure
  1. Install the sill plate.
  2. Push the sill plate down until the sill plate locks into place.

Removal Procedure

Use a flat-bladed tool in order to remove the door sill trim plate from the vehicle.

Scheme 5

Scheme 5: Removal Procedure
Scheme 5: Removal Procedure

Installation Procedure

Install the door sill trim plate to the vehicle. Align the retainers along the door sill and press into place.

Scheme 6

Scheme 6: Installation Procedure
Scheme 6: Installation Procedure

Floor Carpet Drying

If the carpet or the pad or insulator is wet, use the following criteria for drying or for replacing the components

  1. For a 1-piece carpet assembly bonded to a cotton or a fiber padding, replace the entire assembly.
  2. For a 2-piece carpet assembly with a cotton or a fiber padding, replace the padding only. While the carpet is out of the vehicle, dry the carpet using the method described below.
  3. For a 1-piece carpet assembly bonded to a foam padding or attached to a synthetic padding, dry the carpet using the method described below.
  4. For a 2-piece carpet assembly with a synthetic padding, dry the assembly using the method described below.

Drying Method

  1. If you observe puddles of liquid on the carpet face, use a wet vacuum to remove the excess moisture.
  2. Blot the face of the carpet with a towel in order to absorb as much moisture as possible.
  3. Point a fan at the affected area and air dry the carpet.

Scheme 7

Scheme 7: Removal Procedure
Scheme 7: Removal Procedure
  1. Remove the front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.
  2. Remove the rear seats. Refer to SEAT REPLACEMENT - REAR NO. 1 (60/40 SPLIT) or SEAT REPLACEMENT - REAR NO. 1 (BUCKET) in Seats.
  3. Remove the front center seat. Refer to SEAT REPLACEMENT - CENTER in Seats.
  4. Remove the floor center console, if equipped. Refer to CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET) or CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET) in Instrument Panel, Gages, and Console.
  5. Remove the lower bracket from the I/P to the floor to allow carpet removal.
  6. Remove the door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) and «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  7. Remove the hinge pillar trim panels from both sides. Refer to «TRIM PANEL REPLACEMENT - HINGE PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  8. Remove the garnish molding center pillar trim. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  9. Lower the midgate.
  10. Remove the third pillar trim. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  11. Remove the carpet from the vehicle.
CAUTIONIn order to avoid personal Injury or vehicle damage when you repair or replace the carpet, use the same thickness and material size as the original installation. Always return the carpet to the original location.

Scheme 8

Scheme 8
Scheme 8
  1. Install the carpet to the vehicle.
  2. Install the third pillar trim. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Raise the midgate.
  4. Install the garnish molding center pillar trim. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the hinge pillar trim panels. Refer to «TRIM PANEL REPLACEMENT - HINGE PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) and «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  7. Install the lower bracket from the I/P to the floor.
  8. Install the floor center console, if equipped. Refer to CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET) or CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET) in Instrument Panel, Gages, and Console.
  9. Install the front center seats, if equipped. Refer to SEAT REPLACEMENT - CENTER in Seats.
  10. Install the rear seats. Refer to SEAT REPLACEMENT - REAR NO. 1 (60/40 SPLIT) or SEAT REPLACEMENT - REAR NO. 1 (BUCKET) in Seats.
  11. Install the front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.

Scheme 9

Scheme 9: Removal Procedure
Scheme 9: Removal Procedure
  1. Remove the front seats. Refer to «SEAT REPLACEMENT - FRONT BUCKET»(/cadillac/escalade/gmt800-2001-2006/remont/seats/#seat-system) in Seats.
  2. Remove the rear seats. Refer to «SEAT REPLACEMENT - REAR NO. 1 (60/40 SPLIT)»(/cadillac/escalade/gmt800-2001-2006/remont/seats/#seat-system) or «SEAT REPLACEMENT - REAR NO. 1 (BUCKET)»(/cadillac/escalade/gmt800-2001-2006/remont/seats/#seat-system) in Seats.
  3. Remove the front center seat. Refer to «SEAT REPLACEMENT - CENTER»(/cadillac/escalade/gmt800-2001-2006/remont/seats/#seat-system) in Seats.
  4. Remove the floor center console, if equipped. Refer to CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET) or CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET) in Instrument Panel, Gages, and Console.
  5. Remove the lower bracket from the I/P to the floor to allow carpet removal.
  6. Remove the door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) and «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  7. Remove the hinge pillar trim panels from both sides. Refer to «TRIM PANEL REPLACEMENT - HINGE PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  8. Remove the garnish molding center pillar trim. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  9. Remove the carpet.
CAUTIONIn order to avoid personal injury or vehicle damage when you repair or replace the carpet, use the same thickness and material size as the original installation. Always return the carpet to the original location.

Scheme 10

Scheme 10
Scheme 10
  1. Install the carpet.
  2. Install the garnish molding center pillar trim. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Install the hinge pillar trim panels. Refer to «TRIM PANEL REPLACEMENT - HINGE PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Install the door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) and «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the lower bracket from the I/P to the floor.
  6. Install the floor center console, if equipped. Refer to CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET) or CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET) in Instrument Panel, Gages, and Console.
  7. Install the front center seats, if equipped. Refer to SEAT REPLACEMENT - CENTER in Seats.
  8. Install the rear seats. Refer to SEAT REPLACEMENT - REAR NO. 1 (60/40 SPLIT) or SEAT REPLACEMENT - REAR NO. 1 (BUCKET) in Seats.
  9. Install the front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.

Scheme 11

Scheme 11: Removal Procedure
Scheme 11: Removal Procedure

Scheme 12

Scheme 12
Scheme 12
  1. Remove the rear seat. Refer to the following procedures in Seats: SEAT REPLACEMENT - REAR NO. 1 (60/40 SPLIT) or SEAT REPLACEMENT - REAR NO. 1 (BUCKET) SEAT REPLACEMENT - REAR NO. 2 SEAT REPLACEMENT - REAR NO. 2 - 50-50
  2. Remove the rear door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Remove the endgate or the liftgate door sill trim plate. Refer to «DOOR SILL PLATE REPLACEMENT - LIFT GATE»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Remove the trim panels for the rear quarter. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER - RIGHT (UTILITY)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM PANEL REPLACEMENT - REAR QUARTER - RIGHT (SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) and to «TRIM PANEL REPLACEMENT - REAR QUARTER - LEFT (UTILITY)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM PANEL REPLACEMENT - REAR QUARTER - LEFT (SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Remove the bolts that retain the cargo tie down hooks to the floor.
  6. Remove the cargo tie down hooks.
  7. Remove the rear carpet from the vehicle.
CAUTIONIn order to avoid personal injury or vehicle damage when you repair or replace the carpet, use the same thickness and material size as the original installation. Always return the carpet to the original location.

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Install the rear carpet to the vehicle.
  2. Install the cargo tie down hooks. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the bolts that retain the cargo tie down hooks to the floor. Tighten Tighten the bolts to 35 N.m (26 lb ft).
  4. Install the endgate or the liftgate door sill trim plate. Refer to «DOOR SILL PLATE REPLACEMENT - LIFT GATE»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the trim panels for the rear quarter. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER - RIGHT (UTILITY)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM PANEL REPLACEMENT - REAR QUARTER - RIGHT (SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) and to «TRIM PANEL REPLACEMENT - REAR QUARTER - LEFT (UTILITY)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM PANEL REPLACEMENT - REAR QUARTER - LEFT (SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  7. Install the rear seat. Refer to the following procedures in Seats: SEAT REPLACEMENT - REAR NO. 1 (60/40 SPLIT) or SEAT REPLACEMENT - REAR NO. 1 (BUCKET) SEAT REPLACEMENT - REAR NO. 2 SEAT REPLACEMENT - REAR NO. 2 - 50-50

Headliner Replacement

CAUTIONDo not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.

Scheme 15

Scheme 15: Removal Procedure
Scheme 15: Removal Procedure

Scheme 16

Scheme 16
Scheme 16
  1. Remove the IP top trim panel. Refer to TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER in Instrument Panel, Gages, and Console.
  2. Remove the hinge pillar trim. Refer to «TRIM PANEL REPLACEMENT - HINGE PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Disconnect the headliner wire connectors from the junction block located next to the brake pedal.
  4. Remove the wire harness retainers along the windshield pillar and I/P assembly.
  5. Remove the center trim pillar moldings. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Remove the third pillar trim pillar moldings. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  7. Remove the rear corner trim pillar moldings. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  8. Disconnect the electrical connector to the rear view mirror.
  9. Remove the upper console. Refer to «CONSOLE REPLACEMENT - OVERHEAD»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  10. Remove the DVD player, if equipped. Refer to DVD PLAYER REPLACEMENT in Entertainment.
  11. Remove the front sunshades. Refer to «SUNSHADE REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  12. Remove the sunshade holders.
  13. Remove the rear coat hook, if equipped. Refer to «COAT HOOK REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  14. Remove the assist handles. Refer to «ASSIST HANDLE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  15. Remove auxiliary climate control console assembly. Refer to HVAC CONTROL ASSEMBLY REPLACEMENT - FRONT AUXILIARY (FRONT OVERHEAD CONTROL A/C ONLY) or HVAC CONTROL ASSEMBLY REPLACEMENT - FRONT AUXILIARY (FRONT OVERHEAD CONTROL HEAT AND A/C) in Heating, Ventilation and Air Conditioning.
  16. Remove the roof mounted air outlet louver by turning counter clockwise in order to remove the retainer.
  17. Remove the retainer.
  18. Remove the sunroof finishing lace, if equipped. Refer to Sunroof Finishing Lace Replacement .
  19. Remove the rear headliner retainers, if needed.
  20. Carefully separate the air duct at the right C-pillar from the headliner.
  21. Carefully separate the headliner from the roof Velcro® retainers.
  22. With the aid of an assistant carefully slide the headliner out through the rear of the vehicle.
  23. Remove the interior dome lamp assembly in order to transfer to the new headliner. Refer to DOME LAMP REPLACEMENT in Lighting Systems.

Scheme 17

Scheme 17: Installation Procedure
Scheme 17: Installation Procedure

Scheme 18

Scheme 18
Scheme 18
  1. Install the interior dome lamp assembly to the new headliner.
  2. With the aid of an assistant carefully slide the headliner in through the rear of the vehicle.
  3. Secure the headliner to the roof Velcro® retainers while aligning the air duct at the right of the third pillar.
  4. Install the retainer through the air outlet louver
  5. Install the air outlet louver by turning clockwise till it is seated in place.
  6. Install the auxiliary climate control assembly. Refer to HVAC CONTROL ASSEMBLY REPLACEMENT - FRONT AUXILIARY (FRONT OVERHEAD CONTROL A/C ONLY) or HVAC CONTROL ASSEMBLY REPLACEMENT - FRONT AUXILIARY (FRONT OVERHEAD CONTROL HEAT AND A/C) in Heating, Ventilation and Air Conditioning.
  7. Install the assist handles. Refer to «ASSIST HANDLE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  8. Install the interior dome lamp. Refer to DOME LAMP REPLACEMENT in Lighting Systems.
  9. Install the rear coat hook, if equipped. Refer to «COAT HOOK REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  10. Install the sunshade holders to the headliner.
  11. Install the front sunshades. Refer to «SUNSHADE REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  12. Install the DVD player, if equipped. Refer to DVD PLAYER REPLACEMENT in Entertainment.
  13. Connect the electrical connector to the rear view mirror, if needed.
  14. Install the upper console. Refer to «CONSOLE REPLACEMENT - OVERHEAD»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  15. Install the rear corner trim pillar moldings. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  16. Install the third pillar trim moldings. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  17. Install the center trim pillar moldings. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) . Important: Ensure that all of the wire harness retainers in the IP and the windshield pillar are all pressed into place in order to prevent rattling during driving.
  18. Connect the headliner electrical connectors to the junction block located next to the brake pedal.
  19. Install the sunroof finishing lace, if equipped. Refer to Sunroof Finishing Lace Replacement .
  20. Install the hinge pillar trim. Refer to «TRIM PANEL REPLACEMENT - HINGE PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  21. Install the IP top trim panel. Refer to TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER in Instrument Panel, Gages, and Console.

Headliner Replacement - Rear

CAUTIONDo not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.

Important: Do not disconnect the headliner wire harness from the junction block.

Scheme 19

Scheme 19: Removal Procedure
Scheme 19: Removal Procedure
  1. Lower the front section of the headliner and suitably support. Refer to «HEADLINER REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim__headliner-replacement) .
  2. Disconnect the electrical connector.
  3. Remove the rear corner moldings. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Remove the rear upper trim molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR UPPER (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «GARNISH MOLDING REPLACEMENT - REAR UPPER (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Remove the rear coat hook.
  6. Carefully release the headliner from the roof support Velcro® retainers.
  7. Remove the headliner from the vehicle.

Scheme 20

Scheme 20: Installation Procedure
Scheme 20: Installation Procedure
  1. Install the rear section of the headliner to the vehicle.
  2. Secure the headliner to the roof support Velcro® retainers.
  3. Connect the electrical connector.
  4. Install the rear coat hook.
  5. Install the rear upper trim molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR UPPER (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «GARNISH MOLDING REPLACEMENT - REAR UPPER (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the rear corner molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  7. Install the front section of the headliner. Refer to «HEADLINER REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim__headliner-replacement) .

Scheme 21

Scheme 21: Removal Procedure
Scheme 21: Removal Procedure
  1. Lower the right side of the headliner. Refer to «HEADLINER REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim__headliner-replacement) .
  2. Turn the retainers in the directions as shown in the graphic and then remove the retainers.
  3. Remove the assist handle from the headliner.

Scheme 22

Scheme 22: Installation Procedure
Scheme 22: Installation Procedure
  1. Install the assist handle through the opening in the headliner.
  2. While holding the assist handle to the head liner install the retainer in the direction as shown in the graphic.
  3. Install the headliner. Refer to «HEADLINER REPLACEMENT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim__headliner-replacement) .

Scheme 23

Scheme 23: Removal Procedure
Scheme 23: Removal Procedure
  1. Remove center pillar trim panel. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  2. Remove the assist handle retraining screws.
  3. Remove the assist handle from the vehicle.

Scheme 24

Scheme 24: Installation Procedure
Scheme 24: Installation Procedure
  1. Install the assist handle to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the assist handle screws. Tighten Tighten the screws to 6 N.m (53 lb in).
  3. Install the center pillar trim panel. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .

Scheme 25

Scheme 25: Removal Procedure
Scheme 25: Removal Procedure

Scheme 26

Scheme 26
Scheme 26
  1. Use a small size flat-bladed tool in order to pry out the outer part of coat hook.
  2. Pull out the outer part of the coat hook.
  3. Push down on the coat hook in order to release the tab from the headliner.
  4. Remove the coat hook from the headliner.

Scheme 27

Scheme 27: Installation Procedure
Scheme 27: Installation Procedure
  1. Install the coat hook into the headliner.
  2. Push in the outer part until the coat hook locks into place.

Scheme 28

Scheme 28: Removal Procedure
Scheme 28: Removal Procedure
  1. Remove the console roof screw.
  2. Disconnect the electrical connectors.
  3. Remove the console.

Scheme 29

Scheme 29: Installation Procedure
Scheme 29: Installation Procedure
  1. Install the console to the roof.
  2. Connect the electrical connectors. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the console roof screw. Tighten Tighten the screw to 2 N.m (18 lb in).

Scheme 30

Scheme 30: Removal Procedure
Scheme 30: Removal Procedure
  1. Remove the screws.
  2. Disconnect the electrical connector, if equipped.
  3. Remove the sunshade.

Scheme 31

Scheme 31: Installation Procedure
Scheme 31: Installation Procedure
  1. Connect the electrical connector, if equipped.
  2. Install the sunshade. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the sunshade screws. Tighten Tighten the screw to 2 N.m (18 lb in).

Scheme 32

Scheme 32: Removal Procedure
Scheme 32: Removal Procedure
  1. Pull the molding straight out in order to release the retainers.
  2. Remove the windshield garnish molding.

Scheme 33

Scheme 33: Installation Procedure
Scheme 33: Installation Procedure
  1. Ensure the bottom of the molding is seated in the slots on the I/P.
  2. Align the molding retainers to the slots.
  3. Press the moldings straight in till fully seated.

Scheme 34

Scheme 34: Removal Procedure
Scheme 34: Removal Procedure
  1. Remove the door sill plates. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  2. Remove the pillar moldings by holding the moldings firmly while pulling out.

Scheme 35

Scheme 35: Installation Procedure
Scheme 35: Installation Procedure
  1. Install the pillar moldings by pushing until the molding locks into place.
  2. Install the door sill trim plates. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .

Scheme 36

Scheme 36: Removal Procedure
Scheme 36: Removal Procedure
  1. Remove the rear window from the vehicle.
  2. Remove the third pillar trim panels. Refer to «GARNISH MOLDING REPLACEMENT - REAR DOOR UPPER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Remove the plastic push pins (1) from the upper garnish molding.
  4. Pull down the upper garnish molding in order to disengage the retaining clips.
  5. Disconnect the electrical connector, if equipped.

Scheme 37

Scheme 37: Installation Procedure
Scheme 37: Installation Procedure
  1. Connect the electrical connector, if equipped
  2. Install the upper garnish molding until it snaps into place.
  3. Install the plastic push pins (1) to the upper garnish molding.
  4. Install the third pillar trim panels. Refer to «GARNISH MOLDING REPLACEMENT - REAR DOOR UPPER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the rear window to the vehicle.

Tools Required

J 38778 Door Trim Pad Clip Removal

Scheme 38

Scheme 38: Removal Procedure
Scheme 38: Removal Procedure
  1. Use the J 38778 in order to remove the rear upper garnish molding. Insert the J 38778 and work along the front edge of the trim panel from one end to the other.
  2. Remove the rear upper garnish molding from the vehicle.

Install the roof rear upper garnish molding to the vehicle until it clicks into place.

Scheme 39

Scheme 39: Installation Procedure
Scheme 39: Installation Procedure

Scheme 40

Scheme 40: Removal Procedure
Scheme 40: Removal Procedure
  1. Remove the rear upper garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR UPPER (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «GARNISH MOLDING REPLACEMENT - REAR UPPER (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  2. Pull down on the upper corners of the garnish molding in order to disengage the retaining clips.
  3. Pull in order to disengage the remaining retaining clips.
  4. Remove the rear corner garnish molding from the vehicle.
  5. Inspect the rear corner garnish molding for broken or missing retaining clips. Replace the retaining clips as needed.

Scheme 41

Scheme 41: Installation Procedure
Scheme 41: Installation Procedure
  1. Install the rear corner garnish molding to the vehicle.
  2. Press on the rear corner garnish molding in order to engage the retaining clips.
  3. Install the rear upper garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR UPPER (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «GARNISH MOLDING REPLACEMENT - REAR UPPER (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .

J 38778 Door Trim Pad Clip Remover

Scheme 42

Scheme 42: Removal Procedure
Scheme 42: Removal Procedure
  1. Remove expanding plastic fasteners at window latch close-out.
  2. Using the J 38778, release the retainers from the retainer seats.
  3. Remove the trim panel from the liftgate.

Scheme 43

Scheme 43: Installation Procedure
Scheme 43: Installation Procedure
  1. Align the retainers with the holes in the liftgate.
  2. Apply pressure to the seat retainers.
  3. Install the expanding plastic retainers at the window latch close-out.

Scheme 44

Scheme 44: Removal Procedure
Scheme 44: Removal Procedure
  1. Remove the rear door sill trim plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  2. Remove the lower rear seat belt cover and bolt.
  3. Remove the trim panel from the vehicle.

Scheme 45

Scheme 45: Installation Procedure
Scheme 45: Installation Procedure
  1. Install the body side lower trim panel to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the lower seat belt bolt. Tighten Tighten the bolt to 70 N.m (52 lb ft).
  3. Install the seat belt cover.
  4. Install the rear door sill trim plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .

Scheme 46

Scheme 46: Removal Procedure
Scheme 46: Removal Procedure
  1. Remove the rear door sill trim plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  2. Remove the lower rear seat belt cover and bolt.
  3. Remove the trim panel from the vehicle.

Scheme 47

Scheme 47: Installation Procedure
Scheme 47: Installation Procedure
  1. Install the trim panel to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the lower seat belt bolt. Tighten Tighten the bolt to 70 N.m (52 lb ft).
  3. Install the seat belt cover.
  4. Install the rear door sill trim plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .

Scheme 48

Scheme 48: Removal Procedure
Scheme 48: Removal Procedure
  1. Remove door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  2. Remove hinge pillar panel.

Scheme 49

Scheme 49: Installation Procedure
Scheme 49: Installation Procedure
  1. Install the hinge pillar panel.
  2. Install the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .

Scheme 50

Scheme 50: Removal Procedure
Scheme 50: Removal Procedure
  1. Remove the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.
  2. Remove the Third-Pillar trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Remove the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim)
  4. Remove the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - LIFT GATE»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Remove the quarter panel trim screws.
  6. Remove the quarter panel trim from the vehicle.

Scheme 51

Scheme 51: Installation Procedure
Scheme 51: Installation Procedure
  1. Install the quarter panel trim to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the quarter panel trim screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Install garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Install the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - LIFT GATE»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the Third-Pillar trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.

Scheme 52

Scheme 52: Removal Procedure
Scheme 52: Removal Procedure
  1. Remove the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.
  2. Remove the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Remove the trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Remove the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Remove the quarter panel trim screws.
  6. Remove the quarter panel trim from the vehicle.

Scheme 53

Scheme 53: Installation Procedure
Scheme 53: Installation Procedure
  1. Install the quarter panel trim to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the quarter panel trim screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Install the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Install the trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.

Scheme 54

Scheme 54: Removal Procedure
Scheme 54: Removal Procedure
  1. Remove the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.
  2. Remove the Third Pillar trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Remove the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Remove the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - LIFT GATE»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Remove the quarter panel trim screws.
  6. Remove the quarter panel trim from the vehicle. Lift the quarter panel to release the quarter panel from the vehicle.

Scheme 55

Scheme 55: Installation Procedure
Scheme 55: Installation Procedure
  1. Install the quarter panel trim to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the quarter panel trim screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Install the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - LIFT GATE»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Install the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the Third Pillar trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.

Scheme 56

Scheme 56: Removal Procedure
Scheme 56: Removal Procedure
  1. Remove the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.
  2. Remove the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  3. Remove the trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Remove the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or to «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Remove the quarter panel trim screws.
  6. Remove the quarter panel trim from the vehicle.

Scheme 57

Scheme 57: Installation Procedure
Scheme 57: Installation Procedure
  1. Install the quarter panel trim to the vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the quarter panel trim screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Install the door sill plate. Refer to «DOOR SILL PLATE REPLACEMENT - FRONT»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «DOOR SILL PLATE REPLACEMENT - REAR»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  4. Install the trim panel. Refer to «TRIM REPLACEMENT - THIRD PILLAR (TAHOE/YUKON/ESCALADE/SUBURBAN)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) or «TRIM REPLACEMENT - THIRD PILLAR (AVALANCHE/ESCALADE EXT)»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  5. Install the garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR CORNER»(/cadillac/escalade/gmt800-2001-2006/remont/exteriorinterior-trim/#interior-trim) .
  6. Install the rear seat. Refer to SEAT REPLACEMENT - REAR NO. 2 or SEAT REPLACEMENT - REAR NO. 2 - 50-50 in Seats.

Scheme 58

Scheme 58: Special Tools and Equipment
Scheme 58: Special Tools and Equipment

More articles — Body & Frame
