Cadillac ELR I facelift (2015-2016) Transmission circuit, except hybrid

AUTOMATIC TRANSMISSION ASSEMBLY BATT POS VOLT BLK WIRE BLK/BRN WIRE BODY CONTROL MODULE (RIGHT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR BRK APPLY SENS SIG BRK APPLY SENSE SPLY VOLT CENTER CONSOLE CUPHOLDER MOTOR COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DRIVER INFORMATION CENTER DISPLAY ECM/TCM FUSE GRY WIRE GRY/VIO WIRE HI SPD GMLAN SERIAL DATA HI SPEED GMLAN SERIAL DATA (-) ACC WAKUP SERIAL DATA 2 HI SPEED GMLAN SERIAL DATA (-) RUN/CRANK IGN 1 VOLT HI SPEED GMLAN SERIAL DATA - HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY INSTRUMENT CLUSTER LOGIC LOW REF LOW SPD GMLAN SERIAL DATA LT BLU WIRE LT BLU/WHT WIRE LT BLU/YEL WIRE LT GRN WIRE OUT SPD HI SIG OUT OUT SPD LOW SIG POWER DISTRIBUTION SYSTEM RAP RELAY COIL REAR BODY FUSE BLOCK RED WIRE RED/GRY WIRE RED/YEL WIRE RVC FUSE SPORT MODE SW SIG TAP UP/TAP DOWN TPIM/TCM FUSE TRANS IMS MODE SW A BIT SIG TRANS IMS MODE SW B BIT SIG TRANS IMS MODE SW C BIT SIG TRANS IMS MODE SW P BIT SIG TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION OUTPUT SHAFT SPEED SENSOR UNDERHOOD FUSE BLOCK VIO WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL WIRE

AUTOMATIC TRANSMISSION ASSEMBLY BLK WIRE BLK/BLU WIRE BRAKE IND CENTER CONSOLE MULTI-FUNCTION SWITCH COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DRIVE MODE GRN WIRE GROUND GROUND DISTRIBUTION SYSTEM GRY WIRE GRY/VIO WIRE IGN ILL INFO DISPLAY MODULE LEFT TRANSMISSION MANUAL SHIFT SWITCH LINE PRESSURE CONTROL SOLENOID VALVE LINEAR INTERCONNECT NETWORK BUS 2 LOGIC LOW REF LOW SPEED GMLAN SERIAL DATA LT GRN/LT BLU WIRE PC 1 SOLENOID PC 2 SOLENOID PC 3 SOLENOID PC 4 SOLENOID PC 5 SOLENOID PRESSURE CONTROL SOLENOID VALVE 2 PRESSURE CONTROL SOLENOID VALVE 3 PRESSURE CONTROL SOLENOID VALVE 4 PRESSURE CONTROL SOLENOID VALVE 5 RAP RELAY COIL CTRL RIGHT TRANSMISSION MANUAL SHIFT SWITCH SHIFT SOLENOID VALVE 1 SHIFT SOLENOID VALVE 2 SS 1 SS 2 STEERING WHEEL AIR BAG COIL TFP 1 TFP 3 TFP 4 TFP 5 TFT TRANSMISSION CONTROL MODULE TRANSMISSION FLUID PRESSURE SWITCH TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION SHIFT LEVER POSITION INDICATOR VIO/YEL WIRE
