Automatic Transmission Removal & Installation Cadillac Eldorado X

Automatic Trans 5 illustrations ~2120 words

APPLICATION

ApplicationTransaxle Model (RPO Code)
Deville, Eldorado & Seville4T80-E (MH1)

TRANSAXLE APPLICATION

WARNINGVehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION.
WARNINGBefore servicing any electrical component, the ignition key must be in the OFF or LOCK position and all electrical loads must be OFF, unless instructed otherwise in these procedures. If a tool or equipment could easily come in contact with a live exposed electrical terminal, also disconnect the negative battery cable. Failure to follow these precautions may cause personal injury and/or damage to the vehicle or its components.
CAUTIONWhen battery is disconnected, vehicle computer may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.
CAUTIONUse the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.

TRANSAXLE

Note. Tools required: Ball Stud Nut Wrench (J-35551), Engine Support Fixture (J-28467-360), Universal Engine Support Fixture (J-28467-B) and Transaxle Jack Adapter (J-41160).

Scheme 60

Scheme 60: Removal
Scheme 60: Removal
  1. Disconnect the negative battery cable from the battery negative terminal.
  2. Remove the headlamp housing upper filler panel.
  3. Remove the diagonal brace.
  4. Remove the air cleaner assembly.
  5. Remove the shift control cable and the bracket at the transaxle.
  6. Remove the torque struts.
  7. Remove the oil cooler lines at the cooler and the oil sending line at the transaxle.
  8. Remove the upper bell housing bolts (2).
  9. Remove the power steering return hose at the auxiliary cooler.
  10. Install plugs in the cooler and the return hose to prevent fluid leakage or contamination. NOTE: Load the support fixture by tightening the wing nuts several turns in order to take the weight of the powertrain off of the mounts and the frame.
  11. Install the universal engine support fixture. (Scheme 60)
  12. Raise the left side of the powertrain (the transaxle side) 1.0" (25.4 mm) above the powertrain resting position with the adjusting screws.
  13. Raise the vehicle.
  14. Support the vehicle with safety stands.
  15. Remove both front tires and wheels.
  16. Remove both front wheel opening splash shields.
  17. Remove both front suspension position sensors from the lower control arms and position out of the way.
  18. Remove both stabilizer links from the struts. See «STABILIZER BAR & BUSHINGS»(/cadillac/eldorado/x-1992-2002/remont/suspension-front/#front-suspension) under REMOVAL & INSTALLATION in FRONT - "E" & "K" BODIES article in SUSPENSION.
  19. Remove both tie rod cotter pins and nuts and separate both tie rods from the steering knuckles. See «OUTER TIE ROD»(/cadillac/eldorado/x-1992-2002/remont/manual-power-steering/#power-rack-pinion-steering-system) under REMOVAL & INSTALLATION in POWER RACK & PINION - GENERAL MOTORS CORP. article in STEERING.
  20. Remove both lower ball joint cotter pins and nuts. Separate both ball joints from the struts. See «LOWER CONTROL ARM BALL JOINT»(/cadillac/eldorado/x-1992-2002/remont/suspension-front/#front-suspension) under REMOVAL & INSTALLATION in FRONT - "E" & "K" BODIES article in SUSPENSION.
  21. Remove both drive axles from the transaxle. See «AXLE SHAFTS»(ref-97168-S11946174412001042500000) under REMOVAL & INSTALLATION in AXLE SHAFTS - GENERAL MOTORS FWD PASSENGER CARS article in DRIVELINE/AXLES.
  22. Remove the fuel filter bracket from the frame.
  23. Remove the A/C splash shield from the frame.
  24. Remove the ABS modulator from the bracket and the support.
  25. Remove the engine oil pan to transaxle bracket.
  26. Remove the torque converter cover. See «TORQUE CONVERTER COVER»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation). NOTE: Mark the flywheel to converter position so that they can be assembled in the same position.
  27. Remove the flywheel to converter bolts.
  28. Remove the powertrain mount nuts from the frame.
  29. Remove the clamp bolt (rotate the steering intermediate shaft so that the steering gear stub shaft clamp bolt is accessible from the left wheel opening). WARNING: Failure to disconnect the intermediate shaft from the rack and pinion steering gear stub shaft can result in damage to the steering gear or to the intermediate shaft. This damage may cause loss of steering control, which could result in an accident and possible personal injury. CAUTION: Do not rotate the steering wheel or move the position of the steering gear once the intermediate shaft is disconnected. This will uncenter the Inflatable Restraint coil in the steering column. If the inflatable restraint coil becomes uncentered, it may be damaged during vehicle operation.
  30. Remove the steering intermediate shaft from the steering gear.
  31. Remove the electrical harness and connector from the front of the frame.
  32. Support the rear of frame with an adjustable jack stand.
  33. Remove the four rear frame bolts.
  34. Lower the jack stand a few inches to gain access to the power steering gear heat shield and the return line fitting.
  35. Remove the power steering gear heat shield and the power steering return line at the gear. Install plugs in the steering gear and pressure line in order to prevent fluid leakage or contamination.
  36. Remove the power steering electrical connector.
  37. Raise the jack stand and reinstall one rear frame bolt on each side finger tight in order to support the frame.
  38. Remove the jack stand.
  39. Remove the support frame.
  40. Remove the six frame mount bolts.
  41. Remove the lower frame and/or raise the vehicle with the steering gear attached.
  42. Remove the following electrical connectors: Three transaxle connectors. VSS connector.
  43. Remove the fuel line bundle from the transaxle.
  44. Remove the left transaxle mount and bracket from the transaxle.
  45. Remove the right transaxle bracket, the mount and the brace. (Scheme 61)
  46. Remove the engine to transaxle heat shield and the bracket.
  47. Support the transaxle using the transaxle jack adapter and a suitable transaxle jack.
  48. Secure the transaxle jack adapter to the transaxle.
  49. Remove the engine to transaxle bolts (1). (Scheme 62)
  50. Lower the transaxle.
  51. Remove the manual shaft linkage and the park/neutral position switch.
  52. Remove the vehicle speed sensor.
  53. Remove the oil return pipe.

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Install the oil return pipe.
  2. Install the vehicle Speed Sensor.
  3. Install the park/neutral position switch and the manual shaft linkage as follows: Tighten the park/neutral position switch bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications). Tighten the manual shaft nut to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  4. Raise the transaxle into position.
  5. Install the engine-to-transaxle bolts (1). (Scheme 62) Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  6. Install the engine to transaxle bracket and heat shield. Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  7. Remove the transaxle jack and the transaxle jack adapter.
  8. Install the right transaxle bracket, mount and brace. (Scheme 61) Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  9. Install the left transaxle bracket and mount to the transaxle. Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  10. Install the fuel line bundle to the transaxle.
  11. Install the following electrical connectors: The transaxle connectors. The VSS connector. The ground. The transaxle harness in order to Install the transaxle clip.
  12. Raise the frame and/or lower the vehicle while locating the engine and transaxle mount studs into the frame, harnesses at the frame, and the frame mount bolt holes to the underbody.
  13. Install two front and two rear frame bolts finger tight in order to support the frame.
  14. Remove the frame support fixture.
  15. Support the rear of the frame with an adjustable jack stand.
  16. Remove two rear frame bolts.
  17. Lower the jack stand a few inches in order to gain access to the power steering gear.
  18. Install the power steering pressure hose at the steering gear. Tighten the fitting to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  19. Install the power steering gear electrical connector and power steering gear heat shield: The ground. The transaxle harness to the transaxle clip.
  20. Raise the jack stand.
  21. Install the six frame mount bolts in the following order: Left side number 2 mount bolt into the body. Left side number one mount bolt into the body. The remaining frame mount bolts.
  22. Install the electrical harness to the front of the frame.
  23. Install the steering intermediate shaft to the steering gear and install the clamp bolt. Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  24. Install the left and right transaxle mount nuts and the right engine mount nuts at the frame. Tighten the nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  25. Install the fuel filter bracket to the frame. NOTE: Line up the flywheel and converter using the marks you made at disassembly.
  26. Install the flywheel-to-converter bolts. Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  27. Pre-tighten the tie rod end nut to specification then an additional 1/3 turn (2 flats). See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications). After tightening the castellated nut to specification, align the slot in the nut to the cotter pin hole by tightening only. NOTE: Do not loosen the nut for cotter pin installation. Fully tighten the tie rod end nut to specification then an additional 1/3 turn (2 flats). See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  28. Install the torque converter cover. Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  29. Install the engine oil pan to transaxle bracket. Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  30. Install the ABS modulator to the bracket.
  31. Install the A/C splash shield at the frame.
  32. Install both drive axles into the transaxle. See «AXLE SHAFTS»(ref-97168-S11946174412001042500000) under REMOVAL & INSTALLATION in AXLE SHAFTS - GENERAL MOTORS FWD PASSENGER CARS article in DRIVELINE/AXLES.
  33. Install both drive axles into the hubs and both drive axle nuts. Tighten the nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications). NOTE: When tightening the ball joint nut, a minimum torque of 37 ft. lbs. (50 N.m) must be obtained. If 37 ft. lbs. (50 N.m) is not obtained, inspect for stripped threads. If threads are satisfactory, replace the ball joint and knuckle. If required, turn the nut up to an additional 60 degrees to allow for installation of the cotter pin.
  34. Install both lower ball joints into the steering knuckles and both ball joint nuts and cotter pins. See «LOWER CONTROL ARM BALL JOINT»(/cadillac/eldorado/x-1992-2002/remont/suspension-front/#front-suspension) under REMOVAL & INSTALLATION in FRONT - "E" & "K" BODIES article in SUSPENSION. Tighten the ball joint nut to specification using ball stud nut wrench. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications). Tighten the nut an additional 120 degrees.
  35. Install both tie rods into the steering knuckles and both tie rod nuts and cotter pins. See «OUTER TIE ROD»(/cadillac/eldorado/x-1992-2002/remont/manual-power-steering/#power-rack-pinion-steering-system) under REMOVAL & INSTALLATION in STEERING - DEVILLE, ELDORADO & SEVILLE article.
  36. Install both stabilizer links to the struts. See «STABILIZER BAR & BUSHINGS»(/cadillac/eldorado/x-1992-2002/remont/suspension-front/#front-suspension) under REMOVAL & INSTALLATION in POWER RACK & PINION - GENERAL MOTORS CORP. article in STEERING. Tighten the nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  37. Install both front suspension position sensors to the lower control arms.
  38. Install both front wheel opening splash shields.
  39. Install both front tire and wheel assemblies.
  40. Lower the vehicle.
  41. Remove the engine support fixture. (Scheme 60)
  42. Install the power steering hose at the auxiliary cooler.
  43. Install the upper bell housing bolts.
  44. Perform the oil cooler flushing procedure.
  45. Install the transaxle cooler pipe fittings at the transaxle. Install the fittings finger tight. Tighten the cooler pipe fittings at transaxle to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  46. Install the oil sending pipe to the transaxle.
  47. Install the torque struts.
  48. Adjust the park/neutral position switch. See «PARK/NEUTRAL POSITION (PNP) SWITCH»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-servicing__parkneutral-position-pnp-switch) under ADJUSTMENTS in SERVICING - DEVILLE, ELDORADO & SEVILLE article.
  49. Install the range control cable and bracket at the transaxle. Tighten the bracket bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  50. Adjust the shift control cable. See «SHIFT CABLE»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-servicing__shift-cable) under ADJUSTMENTS in SERVICING - DEVILLE, ELDORADO & SEVILLE article.
  51. Install the air cleaner assembly.
  52. Install the headlamp housing upper filler panel.
  53. Install the radiator support brace.
  54. Connect the battery negative cable assembly to the battery negative terminal. Tighten the terminal bolt to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  55. Bleed the power steering system. See «HYDRAULIC SYSTEM BLEEDING»(/cadillac/eldorado/x-1992-2002/remont/manual-power-steering/#power-rack-pinion-steering-system__hydraulic-system-bleeding) under LUBRICATION in POWER RACK & PINION - GENERAL MOTORS CORP. article in STEERING.
  56. Add appropriate transaxle fluid as required. See «LUBRICATION»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-servicing) in SERVICING - DEVILLE, ELDORADO & SEVILLE article.
  57. Check the front suspension alignment, adjust the toe as necessary.
  58. Reset the transaxle adapts.
  59. Reset the transaxle oil life indicator.

FRONT TRANSAXLE MOUNT

Note. Tools required: Engine Support Fixture (J-28467-360).

  1. Disconnect the battery negative cable assembly from the battery negative terminal.
  2. Install the engine support fixture. (Scheme 60)
  3. Raise the left side of the powertrain (the transaxle side) 1.0" (25.4 mm) above the powertrain resting position with the adjusting screws.
  4. Raise the vehicle.
  5. Support the vehicle with safety stands.
  6. Remove the right front tire and wheel.
  7. Remove the nuts attaching the mount to the frame. (Scheme 63) The mount should pull away from the frame.
  8. Remove the nuts attaching the mount to the bracket.
  9. Remove the right transaxle mount.
  10. Remove the bolts attaching the bracket to the transaxle.
  11. Remove the transaxle mount bracket.

Scheme 63

Scheme 63
Scheme 63
  1. Install the right transaxle mount bracket and the attaching bolts. (Scheme 63) Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  2. Install the right transaxle mount and nuts at the bracket. Tighten the nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  3. Install the nuts attaching the mount to the frame. Tighten the nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  4. Install the right front tire and wheel.
  5. Remove the safety stands.
  6. Lower the vehicle.
  7. Loosen the engine support fixture adjusting screws in order to lower the powertrain to the powertrain resting position.
  8. Remove the engine support fixture. (Scheme 60)
  9. Connect the battery negative cable assembly to the battery negative terminal. Tighten the terminal bolt to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  1. Raise the vehicle.
  2. Support the vehicle on safety stands.
  3. Remove the attaching bolts and the engine-to-transaxle brace. (Scheme 64)
  4. Remove the torque converter cover.

Scheme 64

Scheme 64
Scheme 64
  1. Install the torque converter cover. Tighten the cover bolt to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  2. Install the engine-to-transaxle brace and attaching bolts. (Scheme 64) Tighten the bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/eldorado/x-1992-2002/remont/automatic-trans/#automatic-transmission-removal-installation__torque-specifications).
  3. Remove the safety stands.
  4. Lower the vehicle.

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Cooler Pipe-To-Transaxle Fittings16 (22)
Drive Axle-To-Hub Nuts110 (145)
Engine Oil Pan-To-Transaxle Bracket Bolts35 (47)
Engine-To-Transaxle Bolts55 (75)
Engine-To-Transaxle Brace Bolts35 (47)
Engine-To-Transaxle Bracket & Heat Shield Bolts35 (47)
Flywheel-To-Torque Converter Bolts44 (60)
Left & Right Transaxle Mount-To-Frame Nuts35 (47)
Left Transaxle Bracket & Mount-To-Transaxle Bolts35 (47)
Manual Shaft Nut15 (20)
Mount-To-Frame Nuts35 (47)
Power Steering Pressure Hose20 (27)
Right Engine Mount-To-Frame Nuts35 (47)
Right Transaxle Bracket, Mount & Brace Bolts35 (47)
Right Transaxle Mount-To-Bracket Nuts35 (47)
Stabilizer Link-To-Strut Nuts49 (65)
Steering Intermediate Shaft-To-Steering Gear Clamp Bolts35 (47)
Tie Rod End Nut74 (100)
Transaxle Mount Bracket Bolts35 (47)
INCH Lbs. (N.m)
Ball Joint Nut89 (10)
Battery Negative Cable-To-Terminal133 (15)
Park/Neutral Position Switch Bolts106 (12)
Range Control Cable Bracket Bolts106 (12)
Torque Converter Cover Bolts106 (12)

TORQUE SPECIFICATIONS
