Fixed & Moveable Window Systems Cadillac DTS I

Fastener Tightening Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Diagnostic Starting Point - Fixed & Moveable Windows

Begin the system diagnosis with the Diagnostic System Check - Vehicle . The Diagnostic System Check will provide the following information

1. The identification of the control modules which command the system.
2. The ability of the control modules to communicate through the serial data circuit.
3. The identification of any stored diagnostic trouble codes (DTC) and their status.

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

The HVAC control module monitors the voltage level on the supply voltage circuit of the rear defog relay. The voltage level should be low while the rear defog relay is de-energized. The voltage will be near system voltage when the HVAC control module energizes the rear defog relay.

Conditions for Running the DTC

Battery voltage must be between 9-16 volts.

Conditions for Setting the DTC

The HVAC control module detects a short to battery or open/high resistance in the defog relay coil control circuit for 1 second or greater.

Action Taken When the DTC Sets

1. The HVAC control module stores the DTC to memory.
2. The rear window defogger will not operate.

Conditions for Clearing the DTC

1. The DTC clears when the fault is no longer detected.
2. The current DTC will become history when the request for the output is removed.
3. The history DTC will clear after 50 consecutive fault-free ignition cycles have occurred.

Reference Information

Schematic Reference

Defogger Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Rear Window Defogger Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
2. «Connector Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-poor)
4. «Wiring Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Command the rear window defogger ON and OFF with the scan tool. The rear window defogger should turn ON and OFF when changing between the commanded states.

Circuit/System Testing

1. Ignition OFF, disconnect the RR DEFOG relay.
2. Test for less than 1.0 ohm between the ground circuit terminal 85 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the control circuit terminal 86 and the ground circuit terminal 85.
4. Ignition ON, command the rear window defogger ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the HVAC control module. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the HVAC control module.
5. If all circuits test normal, test or replace the RR DEFOG relay.

Component Testing

Relay Test

1. Ignition OFF, disconnect the RR DEFOG relay.
2. Test for 60-180 ohms between terminals 85 and 86. If not within the specified range, replace the relay.
3. Test for infinite resistance between the following terminals: 30 and 86 30 and 87 30 and 85 85 and 87 If not the specified value, replace the relay.
4. Install a 25-amp fused jumper wire between relay terminal 85 and 12 volts. Install a jumper wire between relay terminal 86 and ground. Test for less than 2 ohms between terminals 30 and 87. If greater than the specified range, replace the relay.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Relay Replacement (Attached to Wire Harness)»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-introduction) or «Relay Replacement (Within an Electrical Center)»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-introduction)
2. «Control Module References»(/cadillac/dts/i-2005-2011/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for HVAC control module replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The front door, rear door and middle door power window motors communicate with the driver door module (DDM), passenger door module (PDM) and rear door modules and middle door modules over the LIN BUS. The motors contain a logic module which must be normalized or programmed any time the window motor is serviced to provide proper operation and communication between door modules and window motors.

Power window switch activated.

B320A 39

An internal malfunction has been detected by the DDM or PDM in the front power window motor while commanding the window UP/DOWN.

B320A 42

A not normalized/programmed driver or front passenger door power window motor.

B320A 4B

The front window motor experiences a loss of voltage in the B+ circuit or an open/high resistance in the LIN BUS circuit.

The appropriate power window will be inoperative

B320A 39, B320B 39, B320C 39

The affected power window motor has an internal electrical failure and must be replaced before the DTC can be cleared.

B320A 42, B320B 42, B320C 42

The affected power window motor must be programmed before the DTC can be cleared.

B320A 4B, B320B 4B, B320C 4B

The affected power window motor must be calibrated before the DTC can be cleared.

Schematic Reference

Moveable Window Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Power Windows Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
2. «Connector Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-poor)
4. «Wiring Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, command the appropriate door window DOWN and UP with a scan tool. The door window should perform the DOWN and UP function.

B320A 39, B320A 42, B320B 39, B320B 42, B320C 39 or B320C 42

Ignition ON, reprogram the appropriate power window and operate the power window within the conditions for running the DTC, verify the DTC does not reset.

1. If the DTC resets, replace the power window motor.

B320A 4B, B320B 4B or B320C 4B

Ignition ON, command the appropriate power window motor fully DOWN by pressing and holding the window switch for 5 seconds, then command the power window motor fully UP by lifting and holding the window switch for 5 seconds. Operate the power window within the conditions for running the DTC, verify the DTC does not reset

1. If the DTC resets, replace the power window motor.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Side Door Window Regulator Motor Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)
2. «Front Side Door Window Regulator Motor Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)

Symptoms - Fixed & Moveable Windows

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the power window system operation or rear window defogger system operation in order to familiarize yourself with the system functions. Refer to «Rear Window Defogger Description and Operation»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems) .

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the rear window defogger. Refer to «Checking Aftermarket Accessories»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__checking-aftermarket-accessories) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Rear Window Defogger Malfunction»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)
2. «Power Windows Malfunction»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)

Scheme 5

1. Start the engine.
2. Activate the rear window defogger system.
3. Connect a test lamp to ground.
4. Move the test lamp probe from zone 5 to zone 1 along each grid line. If the test lamp shows full brilliance at both ends of the grid lines, inspect for an open or poor connection in the ground circuit of the rear window defogger grid. Refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-poor) and «Connector Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs) . If the test lamp goes out, test the grid line in at least 2 places (1, 3) to eliminate the possibility of bridging the open (2) in the grid line.
5. If an open is discovered replace the rear window. Refer to «Rear Window Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems__rear-window-replacement) .

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

When the rear defogger button is pressed, voltage is supplied to the relay coil and the HVAC control module also illuminates the rear window defogger indicator. Battery positive voltage is supplied at all times to the relay switched input and the relay coil is always grounded. This allows battery positive voltage from the relay switched input through the switch contacts and out the relay switched output to the rear window defogger. Ground for the rear defogger grid is provided by G306 and G307.

Schematic Reference

Defogger Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Rear Window Defogger Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
2. «Connector Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-poor)
4. «Wiring Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, command the rear window defogger ON and OFF with a scan tool. The rear window defogger should turn ON and OFF when changing between the commanded states.
2. Observe the operation of the rear window defogger indicator while pressing the rear window defogger switch. The indicator should turn ON or OFF each time the rear window defogger switch is pressed. If the indicator does not turn ON or OFF with each switch press, replace the HVAC control module.

1. Ignition OFF, disconnect the RR DEFOG relay.
2. Test for less than 1 ohm between the ground circuit terminal 85 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition ON, verify that a test lamp does not illuminate between the control circuit terminal 87 and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
4. Verify that a test lamp illuminates between the B+ circuit terminal 30 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
5. Ignition OFF, disconnect the X1 harness connector at the rear window defogger.
6. Test for less than 1 ohm between the ground circuit terminal A and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
7. Connect the harness connector at the rear window defogger.
8. Ignition ON, connect a 30A fused jumper wire between the B+ circuit terminal 30 and the control circuit terminal 87. Verify the rear window defogger grid is activated. If the rear window defogger grid does not activate, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, test or replace the rear window defogger grid.
9. Connect a test lamp between the control circuit terminal 86 and ground.
10. Command the rear window defogger ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the HVAC control module. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the HVAC control module.
11. If all circuits test normal, test or replace the RR DEFOG relay.

Rear Window Defogger Grid Test

1. Ignition ON, turn on the rear window defogger.
2. Verify that a test lamp illuminates between each rear window defogger grid line and ground. The test lamp should be off when testing at the ground side of the grid and get brighter as the test lamp moves closer to the voltage supply side of the grid. The test lamp should be dim when testing each grid line in the middle. If the test lamp remains bright at the middle of the grid line, test for an open between the test point and the ground side of the grid. If the test lamp remains off at the middle of the grid line, test for an open between the test point and the voltage supply side of the grid.

Relay Test

1. Ignition OFF, disconnect the RR DEFOG relay.
2. Test for 60-180 ohms between terminals 85 and 86. If not within the specified range, replace the relay.
3. Test for infinite resistance between the following terminals: 30 and 86 30 and 87 30 and 85 85 and 87 If not the specified value, replace the relay.
4. Install a 30-amp fused jumper wire between relay terminal 85 and 12 volts. Install a jumper wire between relay terminal 86 and ground. Test for less than 2 ohms between terminals 30 and 87. If greater than the specified range, replace the relay.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Window Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems__rear-window-replacement)
2. «Relay Replacement (Attached to Wire Harness)»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-introduction) or «Relay Replacement (Within an Electrical Center)»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-introduction)
3. «Control Module References»(/cadillac/dts/i-2005-2011/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for HVAC control module replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/cadillac/dts/i-2005-2011/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The front and rear power windows are controlled by the driver door module (DDM) and front passenger door module (PDM). The DDM and PDM each contain power window switches that are integrated into the module. The DDM contains the master power window switch that controls all power window operations. The DDM supplies the left rear power window switch with a 12-volt reference and signal circuit. The power window switch contained in the PDM controls the front passenger window operation only. The PDM supplies the right rear power window switch with a 12-volt reference and signal circuit.

When the driver power window switch is activated to a desired position, the DDM examines the request and checks for messages from other vehicle control modules prohibiting window movement. If no prohibitive messages have been received, the DDM will send a LIN serial data message to the driver door window motor to move the window to the desired position.

When the DDM receives a request to operate one of the right side passenger windows from the driver master control, a GMLAN serial data message is sent to the PDM. The PDM examines the request and checks for messages from other vehicle control modules prohibiting the window movement. If no prohibitive messages have been received, the PDM will send a LIN serial data message to the appropriate window motor to move the window as requested.

The DDM and PDM supply their respective rear power window switches with a 12-volt reference and signal circuit. The rear power window switches contain separate resistors for each switch position. When a rear power window switch is activated, the associated door control module interprets the signal and checks for messages from other vehicle control modules prohibiting the window movement. If no prohibitive messages have been received, the door control module sends a LIN serial data message to the appropriate power window motor commanding the requested window position.

Schematic Reference

Moveable Window Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Power Windows Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
2. «Connector Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-poor)
4. «Wiring Repairs»(/cadillac/dts/i-2005-2011/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for Scan Tool Information

1. Ignition ON, observe the scan tool DDM LF Window Switch, RF Window Switch, LR Window Switch, and RR Window Switch parameters. Verify the parameter cycles between Off, Up, Down, Express Up, and Express Down while operating the applicable switch. If the parameter does not cycle between the specified values, replace the DDM.
2. Observe the scan tool FPDM Passenger Window Switch parameter. Verify the parameter cycles between Off, Up, Down, Express Up, and Express Down while operating the switch If the parameter does not cycle between the specified values, replace the FPDM.
3. Observe the scan tool DDM Window Lockout Switch parameter. The parameter should cycle between On and Off while cycling the window lockout switch. If the parameter does not cycle between the specified values, replace the DDM.
4. Operate each of the vehicle windows using the driver and passenger door window switches. Each window should perform the appropriate Up/Down function. If any window does not perform the commanded Up/Down function, refer to «Door Window Motor Circuit Malfunction»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems) .
5. Operate each of the rear windows using the appropriate rear window switch. Each window should perform the appropriate Up/Down function. If any window does not perform the commanded Up/Down function, refer to «Rear Window Switch Circuit Malfunction»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems) .

Door Window Motor Circuit Malfunction

1. Ignition OFF, disconnect the harness connector at the appropriate window motor.
2. Ignition OFF, test for less than 2.0 ohms of resistance between the ground circuit terminal 4 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition ON, verify a test lamp illuminates between the B+ circuit terminal 1 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
4. Test for 6.0-7.0 volts between the LIN circuit terminal 6 and ground. If greater than the specified range, test the LIN circuit for a short to voltage. If the circuit tests normal, replace the applicable door module. If less than the specified range, test the LIN circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the applicable door module.
5. Ignition OFF, reconnect the harness connector at the window motor.
6. Ignition ON, observe the appropriate scan tool Window Motor Fault Status parameter while raising and lower the window. The parameter should read No Fault. If the parameter reads Motor Fault, Hall Fault, Memory Fault, LIN Fault, Anti-Trap Fault or Thermo Active, test or replace the appropriate power window motor.
7. If all circuits test normal, replace the appropriate door module.

Rear Window Switch Circuit Malfunction

1. Ignition OFF, disconnect the harness connector at the applicable rear door window switch.
2. Ignition ON, test for B+ between the reference voltage circuit terminal 3 and ground. If less than the specified value, test the reference voltage circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the appropriate door module.
3. Ignition OFF, reconnect the harness connector at the rear door window switch. Disconnect the harness connector X2 at the appropriate door module.
4. With the switch in the at-rest position, test for 8.0K-9.0K ohms of resistance between the voltage reference circuit terminal 16 and the signal circuit terminal 14. If not within the specified range, test the signal circuit for an open/high resistance. If the circuit tests normal, test or replace the appropriate rear door window switch.
5. With the switch in the AUTO DOWN position, test for 2.75K-3.75K ohms of resistance between the voltage reference circuit terminal 16 and the signal circuit terminal 14. If not within the specified range, test or replace the appropriate rear door window switch.
6. With the switch in the DOWN position, test for 5.25K-6.25K ohms of resistance between the voltage reference circuit terminal 16 and the signal circuit terminal 14. If not within the specified range, test or replace the appropriate rear door window switch.
7. With the switch in the UP position, test for 1.9K-2.9K ohms of resistance between the voltage reference circuit terminal 16 and the signal circuit terminal 14. If not within the specified range, test or replace the appropriate rear door window switch.
8. If all circuits test normal, replace the appropriate door module.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Side Door Window Switch Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)
2. «Rear Side Door Window Regulator Motor Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)
3. «Front Side Door Window Regulator Motor Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems)
4. «Control Module References»(/cadillac/dts/i-2005-2011/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for DDM and FPDM replacement, setup, and programming

Windshield Replacement

Special Tools

1. J 24402-A Glass Sealant (Cold Knife) Remover
2. J 39032 Stationary Glass Removal Tool
3. Urethane Adhesive Kit GM P/N 12346392 or Equivalent
4. Isopropyl Alcohol or Equivalent
5. Cartridge-type Caulking Gun
6. Commercial-type Utility Knife
7. Razor Blade Scraper
8. Suction Cups

Removal Procedure

1. Open the hood.
2. Remove the windshield wiper arms. Refer to «Windshield Wiper Arm Replacement»(/cadillac/dts/i-2005-2011/remont/wiperwasher-systems/#wiper-system-washer-system) .
3. Remove the air inlet grille. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/dts/i-2005-2011/remont/wiperwasher-systems/#wiper-system-washer-system) .
4. Remove the door sealing weatherstrip from the upper pinchweld flange.
5. Remove the windshield side reveal moldings. Refer to «Windshield Side Reveal Molding Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems) .
6. Remove the rearview mirror. Refer to «Inside Rearview Mirror Replacement»(/cadillac/dts/i-2005-2011/remont/mirrors/#mirror-systems) .
7. Remove the vehicle direction alert alarm warning (VDAAW ) module, if equipped. Refer to «Vehicle Direction Alert Alarm Warning Module Calibration»(/cadillac/dts/i-2005-2011/remont/collisionavoidance/#object-detection-system) .
8. Remove the instrument panel (I/P) upper trim pad. Refer to «Instrument Panel Upper Trim Pad Replacement»(/cadillac/dts/i-2005-2011/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
9. Cover to protect the following parts from broken glass: Upper dash pad Defroster outlets and A/C outlets Seats and carpeting
10. If the windshield reveal molding (1) is stretched or damaged it can not be reused.
11. Remove the windshield reveal molding (1). Grasp the lower corner of the windshield reveal molding (1) by hand and slowly pull the reveal molding away from the windshield. If the windshield reveal molding (1) will not release, use a utility knife in order to cut around the windshield in order to remove the windshield reveal molding.
12. Remove the lower windshield supports (1) from the cowl panel, if equipped.
13. This will allow the urethane adhesive to be separated from the window. Leave a base of urethane on the pinchweld flange. The only suitable lubrication is clear water. Use J 24402-A or J 39032 in order to remove the window.
14. Remove the bottom of the window from the urethane adhesive using a long utility knife or similar tool. Keep the cutting edge of the utility knife against the glass. Do this from inside the vehicle.
15. Remove the windshield (1) from the vehicle with the aid of an assistant.

Installation Procedure

1. Install a stationary window into the opening. Refer to «Adhesive Installation of Stationary Windows»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems__adhesive-installation-of-stationary-windows) .
2. Install the I/P upper trim pad. Refer to «Instrument Panel Upper Trim Pad Replacement»(/cadillac/dts/i-2005-2011/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
3. Install the rearview mirror. Refer to «Inside Rearview Mirror Replacement»(/cadillac/dts/i-2005-2011/remont/mirrors/#mirror-systems) .
4. Install the vehicle direction alert alarm warning (VDAAW ) module, if equipped. Refer to «Vehicle Direction Alert Alarm Warning Module Calibration»(/cadillac/dts/i-2005-2011/remont/collisionavoidance/#object-detection-system) .
5. Install the windshield side reveal moldings. Refer to «Windshield Side Reveal Molding Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems) .
6. Install the door sealing weatherstrip.
7. Install the air inlet grille. Refer to «Air Inlet Grille Panel Replacement»(/cadillac/dts/i-2005-2011/remont/wiperwasher-systems/#wiper-system-washer-system) .
8. Install the windshield wipers arms. Refer to «Windshield Wiper Arm Replacement»(/cadillac/dts/i-2005-2011/remont/wiperwasher-systems/#wiper-system-washer-system) .
9. Remove the double layer of masking tape around the perimeter of the painted surfaces and the interior trim.
10. Close the hood.

1. Remove the windshield. Refer to «Windshield Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems__windshield-replacement) . Remove the upper reveal molding (1) from the windshield (2) starting at the center and working outboard to both ends.
2. Remove the upper reveal molding from the windshield.

1. Install the upper reveal molding (1) to the windshield (2).
2. Align the notch in the molding to the center mark on the upper paint band on the windshield.
3. Press the upper reveal molding on to the windshield starting at the center and working outboard to both sides.
4. Install the windshield. Refer to «Windshield Replacement»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems__windshield-replacement) .

1. Starting at the bottom of the reveal molding, pull the weatherstrip (1) off of the windshield pillar flange.
2. Pull back the rubber extension under the fender.
3. Remove the screws (2) from the reveal molding (3).
4. Remove the reveal molding.

1. Insert the reveal molding (3) to the pillar.
2. Install the screws (2) to the reveal molding (3). Tighten: Tighten the screws to 2 N.m (18 lb in).
3. Tuck the rubber extension under the fender.
4. Install the weatherstrip (1) to the windshield pillar flange.

Scheme 6

Scheme 7

Rear Window Replacement

Tools Required

1. J 24402-A Glass Sealant (Cold Knife) Remover
2. J 39032 Stationary Glass Removal Tool
3. Isopropyl Alcohol or Equivalent
4. Cartridge-type Caulking Gun
5. Commercial-type Utility Knife
6. Razor Blade Scraper
7. Suction Cups
8. Plastic Paddle

1. Open the rear compartment lid in order to access the reveal molding.
2. Remove the four fasteners (1) securing the rear window lower reveal molding (2) to the body.
3. Remove the rear sail panels. Refer to «Sail Panel Replacement»(/cadillac/dts/i-2005-2011/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
4. Disconnect the rear window defogger left electrical connector.
5. Disconnect the rear window defogger electrical connectors.
6. Remove the rear window reveal molding (1).
7. Disconnect the rear window defogger electrical connectors.
8. Remove the OnStar® antenna. Refer to «Cellular Communications/Digital Radio Antenna Replacement»(/cadillac/dts/i-2005-2011/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
9. Cover to protect the following parts from broken glass: Upper dash pad. Defroster outlets and A/C outlets. Seats and carpeting.
10. Remove the rear window reveal molding. Grasp the lower corner of the rear window reveal molding by hand and slowly pull the reveal molding away from the rear window. If the rear window reveal molding (1) will not release, use a utility knife in order to cut around the rear window in order to remove the rear window reveal molding.
11. This will allow the urethane adhesive to be separated from the window. Leave a base of urethane on the pinchweld flange. The only suitable lubrication is clear water. Use J 24402-A or J 39032 in order to remove the window.
12. With the aid of an assistant, use the suction cups in order to lift the rear window from the opening.

1. With the aid of assistant, dry fit the rear window (2) to the opening in order to determine the correct way to position the window in the opening.
2. Use masking tape (1) in order to mark the location of the rear window (2) in the opening.
3. Slit the masking tape at the top edge of the rear window.
4. With the aid of assistant, remove the rear window from the opening.
5. Place the rear window inside up on a clean, protected surface.
6. Install the rear window into the opening. Refer to «Adhesive Installation of Stationary Windows»(/cadillac/dts/i-2005-2011/remont/heated-glassdefoggers/#fixed-moveable-window-systems__adhesive-installation-of-stationary-windows) .
7. Connect the rear window defogger left electrical connector.
8. Connect the rear window defogger right electrical connector.
9. Install the OnStar® antenna. Refer to «Cellular Communications/Digital Radio Antenna Replacement»(/cadillac/dts/i-2005-2011/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
10. Install the rear sail panels. Refer to «Sail Panel Replacement»(/cadillac/dts/i-2005-2011/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
11. Install the rear window lower reveal molding (2).
12. Install the four rear window lower reveal molding fasteners (1). Tighten: Tighten the fasteners to 2 N.m (18 lb in).
13. Remove the double layer of masking tape around the perimeter of the painted surfaces and the interior trim.
14. Close the rear compartment lid.

Scheme 8

Scheme 9

Scheme 10

1. Lift up on the loose area of the reveal molding.
2. Clean the top edge of the window surface and the reveal molding with a 50/50 mixture of isopropyl alcohol and water by volume on a dampened lint-free cloth.

1. Verify all primers and urethane adhesive are within expiration dates.
2. Use a new dauber in order to apply glass prep, clear #1, to the channel area approximately 13 mm (1/2 in) to the upper edge of the window.
3. Wipe the glass primed area immediately with a clean lint-free cloth.
4. Shake the glass primer, black #2, for at least 1 minute.
5. Use a new dauber in order to apply glass primer, black #2, to the top edge of the window.
6. Apply a small bead of urethane adhesive (2) between the window (1) and the pinch-weld.
7. Reinstall the window reveal molding. Start from the loose area and hand-press the reveal molding into place over the edge of the window. Run warm water over the reveal molding in order to speed the setup time of the urethane adhesive. Tape should be applied in order to retain the reveal molding to the window. This will maintain a flush fit with the body. The tape is to be removed after 6 hours.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Window Motor Programming and Setup

When replacing a window motor in the front or the rear doors the new motor must be programmed using the Tech 2.

Follow the procedure below to program power window motors.

1. Install Tech 2 and CANDI module.
2. Select proper year, make and model of vehicle.
3. Select Body.
4. Select Doors.
5. Select Drivers Door Switch or Passenger Door Switch depending on which window motor you are trying to program.
6. Select Special Functions.
7. Select Door Window Test.
8. Select Front Window Motor Programming and follow on tool instructions.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Adhesive Installation of Stationary Windows

1. Remove all mounds or loose pieces of urethane adhesive from the pinch-weld area.
2. If the original window is being reused, remove all but a thin film of the existing urethane adhesive from the window surface by using a clean utility knife or razor blade scraper.
3. Inspect the following components for the causes of a broken window: The pinch-weld flange of the window opening The window reveal molding/lace
4. Inspect for any of the following problems in order to help prevent future breakage of the window: High weld Solder spots on the pinch-weld Hardened sealer Any other obstruction or irregularity in the pinch-weld flange
5. After repairing the opening as indicated, perform the following steps: Remove all traces of broken glass from the outer cowl panel, seats, floor and defroster ducts. Clean around the edge of the inside surface of the window with a 50/50 mixture of isopropyl alcohol and water by volume on a dampened lint-free cloth.
6. Verify all primers and urethane adhesive are within expiration dates.
7. Shake the pinch-weld primer black #3 for at least 1 minute.
8. Use a new dauber in order to apply the primer to the surface of the pinch-weld flange (2).
9. Allow the pinch-weld primer to dry for approximately 10 minutes.
10. Install the new windshield acoustic strip (1) to the windshield (2), if equipped or damaged. The acoustic strip aids in reducing noise.
11. If installing a new window reveal molding/lace if needed, start in the center and work toward each end pressing firmly into place.
12. Position the locator pins on the window into the upper sheet metal slots in order to hold the window in place.
13. With the aid of an assistant, dry fit the window (1) to the opening in order to determine the correct position.
14. Use masking tape in order to mark the locations (1) of the window (2) in the opening.
15. Cut the masking tape in the center and remove the window from the opening.
16. Use a new dauber in order to apply glass prep clear #1 to the area approximately 10-16 mm (3/8-5/8 in) around the entire perimeter of the window inner surface. Immediately wipe the window primed area using a clean, lint-free cloth.
17. Apply a second coat of the glass prep clear #1 to the same area of the glass.
18. Shake the glass primer black #2 for at least 1 minute.
19. Use a new dauber in order to apply the glass primer black #2 to the same areas (2) that glass prep clear #1 was applied.
20. Allow the glass primer to dry for approximately 10 minutes.
21. Cut the applicator nozzle in order to provide a bead of 13 mm (1/2 in) wide and 13 mm (1/2 in) high.
22. Use a cartridge-type caulking gun in order to apply a smooth, continuous bead of urethane adhesive.
23. Use the edge of the window or the inside edge of the reveal molding/lace (1) as a guide for the nozzle in order to apply the urethane adhesive (2) to the inner surface of the window (3).
24. Place the window on the lower supports (2), if equipped with the aid of an assistant, place the window in the opening ensuring that the locator pins on the window align with the upper sheet metal slots in order to hold the window in place.
25. Align the masking tape (1) lines on the window (2) and the body.
26. Press the window firmly into place.
27. Tape the window to the body in order to minimize movement until the urethane adhesive cures.
28. Clean any excess urethane adhesive from the body.
29. Use a soft spray of warm water in order to immediately water test the window.
30. Inspect the window for leaks.
31. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point.
32. Retest the window for leaks.
33. Maintain the following conditions in order to properly cure the urethane adhesive: Partially lower a door window in order to prevent pressure buildups when closing doors before the urethane adhesive cures. Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing times. Do not use compressed air in order to dry the urethane adhesive.
34. Complete the window installation.

Full-Cut Method Description

Use only the full cut method, also known in the field as full strip method, when installing windows.

This method includes the following

1. The replacement of a majority of the urethane adhesive bead. Remove all but approximately 2 mm (3/64 in) of the existing bead of urethane adhesive from the pinch-weld flange.
2. Apply pinch-weld primer to any exposed painted areas on the pinch-weld flange.

No mounds or loose pieces of urethane adhesive should remain on the pinch-weld flange. Do not remove all traces of urethane adhesive.

Adhesive Service Kit Description

The GM of Canada Adhesive Caulking Kit, P/N 10952983, contains the following items

1. Four different primers
2. A tube of urethane adhesive with a nozzle
3. Four daubers
4. Instructions with warnings

Use the urethane adhesive caulking kit for replacement of any urethane adhesive-installed window using the full cut method.

In the United States or Canada, you may use any of the following equivalent urethane adhesive systems which meet GM Specification GM 3651G

1. Dow Automotive - Essex 400HV. One part and requires associated primers.
2. Dow Automotive - Essex U216. Two part and requires associated primers. Call Dow Automotive at 1-800-453-3779 for more information.
3. 3M™ "Fast Cure" Auto Glass Urethane. One part and requires associated primers. Call 3M™ at 1-877-666-2277 for more information.

Use these materials based on specific manufacturer. Do NOT intermix primers or adhesives from one manufacturer to another.

Always follow the system manufacturer's instructions for application, handling, and curing.

Power Windows System Components

The Power Window System consists of the following components

1. Driver Door Module (DDM)
2. Front Passenger Door Module (FPDM)
3. Left rear door switch
4. Right rear door switch
5. Window regulator motors in each of the doors
6. DR MDL/PWR WNDW circuit breaker 25-amp

Power Windows System Controls

The driver power window is controlled by the driver window switch which also serves as the master switch for all windows. The passenger windows can be controlled by the power window switches located on the driver power window switch or from the power window switch mounted locally on its associated door.

The power windows can be controlled in the following modes

1. Up
2. Down
3. Express Up
4. Express down

Driver Window Operation

When the driver power window switch is activated to a desired position, the DDM examines the request and checks for messages from other vehicle control modules prohibiting window movement. If no prohibitive messages have been received, the DDM will send a LIN serial data message to the driver door window motor to move the window to the desired position.

When the DDM receives a request to operate the a right window from the driver master control, a GMLAN serial data message is sent to the FPDM. The FPDM examines the request and checks for messages from other vehicle control modules prohibiting the window movement. If no prohibitive messages have been received, the FPDM will send a LIN serial data message to the appropriate right window motor to move the window as requested.

Rear Window Operation

The DDM and FPDM supply their respective rear power window switches with a 12-volt reference and signal circuit. The rear power window switches contain separate resistors for each switch position. When a rear power window switch is activated, the associated door control module interprets the signal and checks for messages from other vehicle control modules prohibiting the window movement.

If no prohibitive messages have been received, the door control module sends a LIN serial data message to the appropriate power window motor commanding the requested window position.

Express Down Feature

The driver window will travel to the fully down position when the driver window switch is pressed past the first detent. Pressing the driver window switch to the up position will cancel the express down feature.

Lockout Switch Feature

The window lockout switch is part of the driver master control. The lockout function is used to prevent the passenger door windows from being operated from their locally mounted switches. When the lockout switch is pressed momentarily, the switch contacts are briefly closed, the LED indicator on the switch button is illuminated, and the DDM processes the switch signal. The DDM sends the switch status via GMLAN serial data to the FPDM. Both the DDM and FPDM will prohibit the passenger windows from being operated from their locally mounted window switches. When the lockout function has been activated, the passenger door windows can still be operated from the driver master control

Rear Window Defogger

The rear window defogger system consists of the following components

1. HVAC control module
2. Rear window defogger grid
3. REAR DEFOG relay

Battery positive voltage is supplied at all times from the rear defog 3 fuse in the rear fuse block to the switch side of the REAR DEFOG relay in the rear fuse block. When the rear defogger switch is pressed in the HVAC control module. The HVAC then applies a ground to the REAR DEFOG relay. This energizes the relay and allows the battery positive voltage to be applied through the switched side of the relay to the rear window defogger grid. The rear window defogger grid is grounded at all times at G307 and G306.

The rear window defogger will turn off automatically after it has been activated. This time is determined by a dynamic timer which varies the amount of time the rear window defogger is allowed to be on based on ambient temperature and vehicle speed. The rear window defogger will be extended when the ambient temperature is cooler or while the vehicle is in motion.

If the battery is low, the BCM will send a signal to the HVAC, which in turn will disable the rear window defogger by not providing voltage to the REAR DEFOG relay.

See also:
• Diagnostic System Check - Vehicle
• Strategy Based Diagnosis
• Diagnostic Procedure Instructions
• Component Connector End Views
• Circuit Testing
• Connector Repairs
• Testing for Intermittent Conditions and Poor Connections
• Wiring Repairs
• Control Module References
• Diagnostic Repair Verification
• Relay Replacement (Attached to Wire Harness)
• Checking Aftermarket Accessories
• Windshield Wiper Arm Replacement
• Inside Rearview Mirror Replacement
• Vehicle Direction Alert Alarm Warning Module Calibration
• Instrument Panel Upper Trim Pad Replacement
• Fastener Notice
• Front Side Door Trim Panel Replacement
• Cellular Communications/Digital Radio Antenna Replacement
• Glass and Sheet Metal Handling Caution
• Window Retention Caution
• DTC B0283
• Rear Window Replacement
• Adhesive Installation of Stationary Windows
• Windshield Replacement
• Fastener Tightening Specifications
