Instrument Panel Trim and Console Trim — Cadillac DTS I (2005-2011)

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Drivers Information Switch Screws	2 N.m	18 lb in
Front Floor Console Armrest Cover Screws	2 N.m	18 lb in
Front Floor Console Armrest Hinge Screws	2 N.m	18 lb in
Front Floor Console Armrest Lower Latch Cover Screws	2 N.m	18 lb in
Front Floor Console Armrest Screws	2 N.m	18 lb in
Front Floor Console Ashtray Bolts	2 N.m	18 lb in
Front Floor Console Bolts	9 N.m	80 lb in
Front Floor Console Screws	2 N.m	18 lb in
Front Floor Console Shift Bezel Bolts	2 N.m	18 lb in
Instrument Panel Ashtray Assembly Screws	2 N.m	18 lb in
Instrument Panel Carrier Bolts/Nuts	25 N.m	18 lb ft
Instrument Panel Carrier End Bracket Nuts	50 N.m	37 lb ft
Instrument Panel Center Support Bracket Bolts	25 N.m	18 lb ft
Instrument Panel Cluster Trim Plate Screws	2 N.m	18 lb in
Instrument Panel Compartment Dampener Screws	2 N.m	18 lb in
Instrument Panel Compartment Latch Screws	2 N.m	18 lb in
Instrument Panel Compartment Screws	2 N.m	18 lb in
Instrument Panel Lower Trim Panel Bolt	9 N.m	80 lb in
Instrument Panel Upper Trim Pad Bolts	9 N.m	80 lb in
Knee Bolster Screws	2 N.m	18 lb in

Scheme 15

Scheme 15: Instrument Panel Insulator Panel Replacement - Right Side

Callout	Component Name
1	Push Pin Retainer (Qty: 2)
2	Instrument Panel Insulator Trim Panel Assembly Procedure: Disconnect the courtesy lamp, if equipped.

Scheme 16

Scheme 16: Instrument Panel Insulator Panel Replacement - Left Side

Callout	Component Name
1	Push Pin Retainer (Qty: 2)
2	Instrument Panel Insulator Trim Panel Assembly Procedure: Disconnect the courtesy lamp, if equipped.

Scheme 17

Scheme 17: Driver Knee Bolster Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Screw, Knee Bolster Trim Panel (Qty: 2) Tighten: 2 N.m (18 lb in)
2	Trim Panel, Knee Bolster
3	Clip, Retainer (Qty: 6)

NOTE
Refer to Fastener Notice .

Scheme 18

Scheme 18: Instrument Panel Accessory Trim Plate Replacement - Left Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Plate Assembly, Instrument Panel Trim Tip: Disconnect electrical connector. Remove the driver information switch. Refer to Driver Information Display Switch Replacement .
2	Clip, Retainer (Qty: 3)

Scheme 19

Scheme 19: Instrument Panel Center Trim Panel Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Center Trim Plate Tip: Use J 36346 . See Special Tools .
2	Retainer Clip (Qty: 7)
3	Retainer (Qty: 5)

Scheme 20

Scheme 20: Instrument Panel Cluster Trim Plate Bezel Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Loosen the upper trim pad enough to gain clearance to remove the cluster trim plate. Refer to Instrument Panel Upper Trim Pad Replacement . Remove the instrument panel center air outlet assembly. Refer to Instrument Panel Center Air Outlet Replacement . Remove the instrument panel left accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement - Left Side .
1	Instrument Panel Cluster Trim Plate Screws (Qty: 2) Tighten: 2 N.m (18 lb in)
2	Instrument Panel Cluster Trim Plate

NOTE
Refer to Fastener Notice .

Scheme 21

Scheme 21: Instrument Panel Outer Trim Cover Replacement - Right Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Side Trim Panel Assembly
2	Retainer Clip (Qty: 3)

Scheme 22

Scheme 22: Instrument Panel Outer Trim Cover Replacement - Left Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Side Trim Panel Assembly
2	Retainer Clips (Qty: 3)

Scheme 23

Scheme 23: Instrument Panel Lower Trim Panel Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Remove the instrument panel top pad. Refer to Instrument Panel Upper Trim Pad Replacement . Remove the instrument panel center trim panel. Refer to Instrument Panel Center Trim Panel Replacement . Remove the left instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement - Left Side . Remove the instrument panel cluster assembly. Refer to Instrument Cluster Replacement . Remove the driver knee bolster assembly. Refer to Driver Knee Bolster Replacement . Remove the steering column. Refer to Steering Column Replacement . Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement . Remove the instrument panel ashtray assembly, if equipped. Refer to Ashtray Replacement . Remove the center console, if equipped. Refer to Console Replacement . Remove the radio. Refer to Radio Replacement . Remove the HVAC control Assembly. Refer to Heater and Air Conditioning Control Replacement . Remove the instrument panel left air outlet. Refer to Instrument Panel Outer Air Outlet Replacement - Left Side . Remove the right and left side window air outlet ducts. Refer to Side Window Air Outlet Replacement . Remove the instrument panel right air outlet. Refer to Instrument Panel Outer Air Outlet Replacement - Right Side .
1	Instrument Panel Lower Panel Bolts (Qty: 16) Tighten: 9 N.m (80 lb in)
2	Instrument Panel Lower Panel Assembly Tip: Note the routing of the electric harness prior to removal of the lower panel assembly to aid in the reinstallation. Disconnect the electrical harness connections.

NOTE
Refer to Fastener Notice .

Scheme 24

Scheme 24: Ashtray Side Panel Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Panel Assembly, Ashtray
2	Retainer Clip (Qty: 2)

Scheme 25

Scheme 25: Ashtray Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Screw, Ashtray Assembly (Qty: 4) Tighten: 2 N.m (18 lb in)
2	Ashtray Assembly

NOTE
Refer to Fastener Notice .

Scheme 26

Scheme 26: Instrument Panel Compartment Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Screw, Instrument Panel Compartment (Qty: 7) Tighten: 2 N.m (18 lb in)
2	Compartment Assembly, Instrument Panel Tip: Disconnect the electrical connectors.

NOTE
Refer to Fastener Notice .

Scheme 27

Scheme 27: Instrument Panel Compartment Door Lock Striker Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Compartment Assembly Refer to Instrument Panel Compartment Replacement .
2	Instrument Panel Compartment Striker Rivets (Qty: 3) CAUTION: Refer to Eye Protection Caution .
3	Instrument Panel Compartment Striker Reinforcement Plate
4	Instrument Panel Compartment Striker Assembly

CAUTION
Refer to Eye Protection Caution .

Scheme 28

Scheme 28: Instrument Panel Compartment Door Latch Release Handle Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Latch Assembly, Instrument Panel Compartment. Refer to Instrument Panel Compartment Door Latch Replacement .
2	Handle, Instrument Panel Compartment Latch

Scheme 29

Scheme 29: Instrument Panel Compartment Door Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Compartment Assembly Refer to Instrument Panel Compartment Replacement .
2	Instrument Panel Compartment Door Hinge Pin (Qty: 2)
3	Instrument Panel Compartment Door Assembly Tip: Disconnect the instrument panel compartment dampener from the door assembly.
4	Instrument Panel Compartment Door Bumper (Qty: 2)

Scheme 30

Scheme 30: Instrument Panel Compartment Door Latch Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the instrument panel compartment door inner panel. Refer to Instrument Panel Compartment Inner Panel Replacement .
1	Instrument Panel Compartment Latch Screws (Qty: 3) Tighten: 2 N.m (18 lb in)
2	Instrument Panel Compartment Latch Assembly

NOTE
Refer to Fastener Notice .

Removal Procedure

Remove the instrument panel compartment latch. Refer to «Instrument Panel Compartment Door Latch Replacement»(/cadillac/dts/i-2005-2011/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
Position the instrument panel compartment latch fork bolt in the up position.
Insert the key into the instrument panel compartment lock cylinder.
Rotate the instrument panel compartment lock cylinder clockwise to the 3 o'clock position with the key.
With the key in position, apply a light load and depress the retainer tumbler through the poke hole at the right hand side of the instrument panel compartment latch.
Rotate the key until the instrument panel compartment lock cylinder rotates to about the 5 o'clock position. This will line up the notch at the rear of the instrument panel compartment lock cylinder with the tab in the instrument panel compartment latch housing.
Remove the instrument panel compartment lock cylinder from the instrument panel compartment latch by pulling on the key.

Installation Procedure

Position the instrument panel compartment latch fork bolt in the up position.
Grasp the instrument panel compartment lock cylinder. Depress the rear-most, light-colored tumbler that is flush with the instrument panel compartment lock cylinder surface.
Insert the key. All the tumblers will now stay depressed.
Insert the instrument panel compartment lock cylinder, with the key inserted, into the instrument panel compartment latch housing. Ensure that the front projection pin is at the appropriate 8 o'clock position. The instrument panel compartment lock cylinder will drop into place.
Rotate the key counterclockwise until the key stops.
Remove the key, the tumblers will now release. The instrument panel compartment lock cylinder is now locked into the instrument panel compartment latch housing.
Install the instrument panel compartment latch. Refer to «Instrument Panel Compartment Door Latch Replacement»(/cadillac/dts/i-2005-2011/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Scheme 31

Scheme 31: Instrument Panel Compartment Door Dampener Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Compartment Assembly, Instrument Panel Refer to Instrument Panel Compartment Replacement .
2	Screw, Instrument Panel Compartment Dampener (Qty: 2) Tighten: 2 N.m (18 lb in)
3	Dampener Assembly, Instrument Panel Compartment

NOTE
Refer to Fastener Notice .

Scheme 32

Scheme 32: Instrument Panel Compartment Inner Panel Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Panel Assembly, Instrument Panel Compartment Inner

Scheme 33

Scheme 33: Instrument Panel Lower Extension Replacement - Right Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Lower Extension Assembly
2	Retainer Clips (Qty: 4)

Scheme 34

Scheme 34: Instrument Panel Lower Extension Replacement - Left Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Instrument Panel Lower Extension Assembly
2	Retainer Clips (Qty: 2)

Scheme 35

Scheme 35: Instrument Panel Upper Trim Pad Replacement

Callout	Component Name
Preliminary Procedures Remove the left instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement - Left Side . Remove the right instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement - Right Side . Remover the defroster grille. Refer to Defroster Grille Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the instrument panel center trim plate. Refer to Instrument Panel Center Trim Panel Replacement . Remove the instrument panel center air outlet assembly. Refer to Instrument Panel Center Air Outlet Replacement .
1	Instrument Panel Upper Trim Pad Bolts (Qty: 6) NOTE: Refer to Fastener Notice . Tighten: 9 N.m (80 lb in)
2	Instrument Panel Upper Trim Pad Assembly Tip: Disconnect the electrical connectors.
3	Retainer Clips (Qty: 2)

NOTE
Refer to Fastener Notice .

Scheme 36

Scheme 36: Instrument Panel Center Support Bracket Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Remove the instrument panel carrier assembly. Refer to Instrument Panel Carrier Replacement . Pull the carpet back enough to expose the instrument panel center support bracket bolts.
1	Bolt, Instrument Panel Center Support Bracket (Qty: 4) Tighten: 25 N.m (18 lb ft)
2	Bracket Assembly, Instrument Panel Center Support

NOTE
Refer to Fastener Notice .

Scheme 37

Scheme 37: Instrument Panel Outer Bracket Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the instrument panel carrier assembly. Refer to Instrument Panel Carrier Replacement .
1	Nut, Instrument Panel Carrier Support Bracket - Left (Qty: 4) Tighten: 50 N.m (37 lb ft)
2	Bracket Assembly, Instrument Panel Carrier Support Left
3	Nut, Instrument Panel Carrier Support Bracket - Right (Qty: 4) Tighten: 50 N.m (37 lb ft)
4	Bracket Assembly, Instrument Panel Carrier Support Right

NOTE
Refer to Fastener Notice .

Scheme 38

Scheme 38: Instrument Panel Carrier Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Remove the instrument panel lower trim panel. Refer to Instrument Panel Lower Trim Panel Replacement . Remove the left air distribution duct. Refer to Instrument Panel Outer Air Outlet Upper Duct Replacement - Left Side . Remove the right air distribution duct. Refer to Instrument Panel Outer Air Outlet Upper Duct Replacement - Right Side . Remove the center air outlet duct. Refer to Center Air Outlet Duct Replacement . Remove the floor air outlet duct. Refer to Floor Air Outlet Duct Replacement - Right Side . Remove the left side window defroster outlet duct. Refer to Side Window Defogger Outlet Duct Replacement - Left Side . Remove the right side window defroster outlet duct. Refer to Side Window Defogger Outlet Duct Replacement - Right Side . Remove the screws securing the windshield defroster nozzle duct to the carrier. Refer to Defroster Air Outlet Duct Replacement .
1	Instrument Panel Carrier Assembly Nuts (Qty: 9) Tighten: 25 N.m (18 lb ft)
2	Instrument Panel Carrier Assembly Bolts (Qty: 6) Tighten: 25 N.m (18 lb ft)
3	Instrument Panel Carrier Assembly Tip: Note the routing of the electric harness prior to removal of the carrier to aid in the reinstallation. Disconnect the electrical harness connections. With the aid of an assistant, remove the carrier from the vehicle.

NOTE
Refer to Fastener Notice .

Scheme 39

Scheme 39: Front Floor Console Compartment Door Latch Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
Upper Latch Assembly
1	Screw, Front Floor Console Armrest Cover (Qty: 11) Tighten: 2 N.m (18 lb in)
2	Cover Assembly, Front Floor Console Armrest
3	Latch Assembly, Front Floor Console Armrest Upper
4	Spring, Front Floor Console Armrest Latch
Lower Latch Assembly
5	Screw, Front Floor Console Armrest Lower Latch Cover (Qty: 2) Tighten: 2 N.m (18 lb in)
6	Cover Assembly, Front Floor Console Armrest Lower Latch
7	Latch Assembly, Front Floor Console Armrest Lower
8	Spring, Front Floor Console Armrest Latch

NOTE
Refer to Fastener Notice .

Scheme 40

Scheme 40: Front Floor Console Compartment Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the front floor console cupholder. Refer to Front Floor Console Cup Holder Replacement .
1	Bin Assembly, Front Floor Console. Refer to Instrument Panel Compartment Door Latch Replacement .
2	Clip, Retainer (Qty: 4)

Scheme 41

Scheme 41: Front Floor Console Side Trim Panel Replacement - Right Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Front Floor Console Trim Panel Assembly
2	Retainer Clips (Qty: 4)

Scheme 42

Scheme 42: Front Floor Console Side Trim Panel Replacement - Left Side

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Front Floor Console Trim Panel Assembly
2	Retainer Clips (Qty: 4)

Scheme 43

Scheme 43: Front Floor Console Front Ashtray Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Plate Assembly, Front Floor Console Refer to Front Floor Console Trim Plate Replacement .
2	Bolt, Ashtray Assembly (Qty: 4) Tighten: 2 N.m (18 lb in)
3	Ashtray Assembly, Console

NOTE
Refer to Fastener Notice .

Scheme 44

Scheme 44: Console Shift Lever Bezel Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Front Floor Console Plate Assembly Refer to Front Floor Console Trim Plate Replacement .
2	Console Shift Bezel Bolts (Qty: 4) Tighten: 2 N.m (18 lb in)
3	Console Shift Bezel Assembly

NOTE
Refer to Fastener Notice .

Scheme 45

Scheme 45: Console Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Remove the right and left console trim panels. Refer to Front Floor Console Side Trim Panel Replacement - Right Side and Front Floor Console Side Trim Panel Replacement - Left Side . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1	Bolt, Front Floor Console (Qty: 4) Tighten: 9 N.m (80 lb in)
2	Screw, Front Floor Console (Qty: 2) Tighten: 2 N.m (18 lb in)
3	Console Assembly, Front Floor Console Tip: Disconnect the electrical connector.

NOTE
Refer to Fastener Notice .

Scheme 46

Scheme 46: Front Floor Console Armrest Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Panel Assembly, Console End Refer to Center Console End Panel Replacement .
2	Screw, Console Armrest Hinge (Qty: 4) Tighten: 2 N.m (18 lb in)
3	Armrest Assembly, Front Floor Console

NOTE
Refer to Fastener Notice .

Scheme 47

Scheme 47: Front Floor Console Armrest Hinge Replacement

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Armrest Assembly, Front Floor Console Refer to Front Floor Console Armrest Replacement .
2	Screw, Console Armrest Hinge (Qty: 3) Tighten: 2 N.m (18 lb in)
3	Screw, Console Armrest Hinge (Qty: 3) Tighten: 2 N.m (18 lb in)
4	Hinge Assembly, Front Floor Console Armrest

NOTE
Refer to Fastener Notice .

Scheme 48

Scheme 48: Front Floor Console Trim Plate Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Front Floor Console Plate Assembly Tip: Use a flat-bladed plastic trim tool to lift the rear edge of the console trim plate. Disconnect the electrical connector.
2	Retainer Clips (Qty: 4)

Scheme 49

Scheme 49: Center Console End Panel Replacement

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1	Panel Assembly, Front Floor Console Rear Trim Tip: Disconnect the electrical connector, if equipped with a rear HVAC control module. Remove the rear HVAC control assembly, if equipped. Refer to Auxiliary Heater and Air Conditioning Control Replacement .
2	Clip, Retainer (Qty: 6)

Scheme 50

Scheme 50: Roof Console Replacement

Callout	Component Name
NOTE: Electrostatic discharge (ESD) can damage many solid-state electrical components. ESD susceptible components may or may not be labeled with the ESD symbol. Handle all electrical components carefully. Use the following precautions in order to avoid ESD damage: Touch a metal ground point in order to remove your body's static charge before servicing any electronic component; especially after sliding across the vehicle seat. Do not touch exposed terminals. Terminals may connect to circuits susceptible the ESD damage. Do not allow tools to contact exposed terminals when servicing connectors. Do not remove components from their protective packaging until required to do so. Avoid the following actions unless required by the diagnostic procedure: Jumpering or grounding of the components or connectors. Connecting test equipment probes to components or connectors. Connect the ground lead first when using test probes. Ground the protective packaging of any component before opening. Do not rest solid-state components on metal workbenches, or on top of TVs, radios, or other electrical devices.
1	Overhead Console Assembly Procedure Pull downward on the overhead console to disengage the retainers. Disconnect the electrical connectors.
2	Console Assembly Retainer (Qty: 4)

NOTE

Electrostatic discharge (ESD) can damage many solid-state electrical components. ESD susceptible components may or may not be labeled with the ESD symbol. Handle all electrical components carefully. Use the following precautions in order to avoid ESD damage: Touch a metal ground point in order to remove your body's static charge before servicing any electronic component; especially after sliding across the vehicle seat. Do not touch exposed terminals. Terminals may connect to circuits susceptible the ESD damage. Do not allow tools to contact exposed terminals when servicing connectors. Do not remove components from their protective packaging until required to do so. Avoid the following actions unless required by the diagnostic procedure: Jumpering or grounding of the components or connectors. Connecting test equipment probes to components or connectors. Connect the ground lead first when using test probes. Ground the protective packaging of any component before opening. Do not rest solid-state components on metal workbenches, or on top of TVs, radios, or other electrical devices.

Special Tools

Illustration Tool Number/ Description J 36346 Fascia Retainer Remover

Instrument Panel Trim and Console Trim Cadillac DTS I
