IDENTIFICATION
| Body Code (1) | Model |
|---|---|
| "C" | Park Avenue |
| "E" | Eldorado |
| "F" | Camaro & Firebird |
| "G" | Aurora & Riviera |
| "H" | Bonneville, Eighty Eight, LeSabre, LSS & Regency |
| "J" | Cavalier & Sunfire |
| "K" | (2) DeVille & Seville |
| "N" | Achieva, Alero, Cutlass, Grand Am, Malibu & Skylark |
| "V" | Catera |
| "W" | Century, Grand Prix, Intrigue, Lumina, Monte Carlo & Regal |
| "Y" | Corvette |
| (1) Vehicle body code is fourth character of VIN. (2) Includes Concours and D'Elegance. | |
| (1) | Vehicle body code is fourth character of VIN. |
| (2) | Includes Concours and D'Elegance. |
MODEL IDENTIFICATION
RIDE HEIGHT ADJUSTMENT
Note. Proper ride height is necessary for correct wheel alignment. Check ride height with vehicle on level floor. Ensure less than 15.5 lbs. of weight is in trunk (other than spare and tools), fuel tank is full (unless specified otherwise), fronts seats are in full rearward position and tires are the correct size and properly inflated. Tire inflation specification can be found on door pillar, sidewall of tire, sun visor or in glove box. On vehicles with electronic chassis controls, ensure all systems are functional before adjusting ride height or wheel alignment.
Visually inspect vehicle for signs of abnormal height from front to rear or side to side. If ride height is not within specification, check, repair or replace suspension components.
"C" & "G" Bodies & Seville
- Ensure Electronic Level Control (ELC) is operating properly (if equipped). Bounce front and rear end of vehicle 3 times. Measure dimension "A" to locate point to measure dimension "J". Measure dimension "J" from underbody points to floor. Measure dimension "Z" between lowest part of ball joint and centerline of control arm bolt. (Scheme 1) See «RIDE HEIGHT SPECIFICATIONS ("C" & "G" BODIES & SEVILLE)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Measure dimension "B" to locate point to measure dimension "K". Measure dimension "K" from underbody points to floor. (Scheme 1) Measure dimension "D" between bottom of wheel bearing face and centerline of outboard control arm bolt. See «RIDE HEIGHT SPECIFICATIONS ("C" & "G" BODIES & SEVILLE)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
"E" & "K" Bodies (Except Seville)
- Ensure Electronic Level Control (ELC) is operating properly. Bounce vehicle 3 times at front and rear. Measure dimension "Z" between centerline of front lower control arm bushing bolt and lowest part of ball joint. From the front side of rear suspension, measure dimension "D" between centerline of front inner bearing bushing bolt and centerline of front outer bushing bolt. (Scheme 2) See «RIDE HEIGHT SPECIFICATIONS ("E" & "K" BODIES - EXCEPT SEVILLE)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures).
- Measure dimensions "A" and "B" to locate measuring points "J" and "K". Measure dimensions "J", "K", "E" and "F" between underbody and floor and center of wheel well and floor. (Scheme 2) See «RIDE HEIGHT SPECIFICATIONS ("E" & "K" BODIES - EXCEPT SEVILLE)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures).
1998 "F" Body & 1998-99 "J" Body
- Lift at front bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Measure dimensions "A", "J" and "Z". (Scheme 3)and (Scheme 4). See «RIDE HEIGHT SPECIFICATIONS (1998 "F" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) or «RIDE HEIGHT SPECIFICATIONS ("J" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Push front bumper down 1.5" (38 mm) and let vehicle rise. Repeat 2 more times. Measure dimensions "A", "J" and "Z". Average readings for ride heights. (Scheme 3)and (Scheme 4). See «RIDE HEIGHT SPECIFICATIONS (1998 "F" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) or «RIDE HEIGHT SPECIFICATIONS ("J" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Lift rear bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push rear bumper down 1.5" (38 mm) and let rise. Repeat 2 more times. On "J" bodies, measure dimensions "B" and "K". On "N" bodies, measure dimensions "B", "K" and "D". (Scheme 3) «RIDE HEIGHT SPECIFICATIONS (1998 "F" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) or «RIDE HEIGHT SPECIFICATIONS ("J" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
1999 "F" Body
Jounce front and rear bumper at least 1.5" (38 mm) and let settle. Measure and note front and rear trim heights. (Scheme 5) Repeat 2 more times. Average measurements for trim heights. See RIDE HEIGHT SPECIFICATIONS (1999 "F" BODY) table.
"H" Body & Metro & Firefly (Canadian)
Note. On Metro & Firefly (Canadian), fuel tank must be at least 1/8 full.
- Bounce vehicle 3 times at front and rear. Measure dimension "Z" between centerline of front lower control arm bolt and lowest part of ball joint. (Scheme 6) See «RIDE HEIGHT SPECIFICATIONS ("H" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- On "H" bodies, measure dimension "D" between centerline of rear lower control arm bolt and lowest point of ball joint (not grease fitting). (Scheme 6) See «RIDE HEIGHT SPECIFICATIONS ("H" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Measure dimension "A" from center of front axle to locate point to measure dimension "J". Measure dimension "J" between front underbody and floor. Measure dimension "B" from center of rear axle to locate point to measure dimension "K". Measure dimension "K" between rear underbody and floor. (Scheme 7) See «RIDE HEIGHT SPECIFICATIONS ("H" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) or «RIDE HEIGHT SPECIFICATIONS (METRO & FIREFLY (CANADIAN))»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
"N" Body
- Lift front bumper about 1.5" (38 mm) and allow vehicle to settle. Repeat 2 more times. Distance "A" is from center of front axle to locate point to measure dimension "J". Dimension "J" is measured from floor to bottom of rocker panel. Measure dimension "Z". Dimension "Z" is measured from bottom of ball joint to bottom of frame rail. (Scheme 3) See «RIDE HEIGHT SPECIFICATION ("N" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Note measurements. Do this 2-3 times, and average measurements.
- Lift rear bumper up about 1.5" (38 mm) and allow vehicle settle. Repeat 2 more times. Distance "B" from center of rear axle to locate point to measure dimension "K". Dimension "K" is measured from floor to bottom of rocker panel. (Scheme 3) See «RIDE HEIGHT SPECIFICATION ("N" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Push rear bumper down about 1.5" (38 mm) and allow vehicle to rise. Repeat 2 more times. Measure dimension "K" again. Average high and low measurements to determine true ride height.
Prizm
Note. Ride height specifications for 1998 Prizm are not available.
- Lift front bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push front bumper down 1.5" (38 mm) and let settle. Repeat 2 more times. Measure dimension "Z" between center of lower control arm mounting bolt and floor. (Scheme 8) See «RIDE HEIGHT SPECIFICATIONS (1999 Prizm)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Lift rear bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push rear bumper down 1.5" (38 mm) and let settle. Repeat 2 more times. Measure dimension "D" between center of rear trailing arm bolt and floor. (Scheme 8) See «RIDE HEIGHT SPECIFICATIONS (1999 Prizm)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
"V" Body
- Ensure Automatic Level Control (ALC) is operative while taking measurements. Lift front bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push front bumper down 1.5" (38 mm) and let settle. Repeat 2 more times. Measure dimensions "J" and "P". Dimension "J" is measured from bottom of rocker panel to floor. Dimension "P" is measured from top of tire to bottom of front tire (diameter). (Scheme 9) See «RIDE HEIGHT SPECIFICATIONS ("V" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Lift rear bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push rear bumper down 1.5" (38 mm) and let settle. Repeat 2 more times. Measure dimensions "K" and "R". Dimension "K" is measured from bottom of rocker panel to floor. Dimension "R" is measured from top of tire to bottom of rear tire (diameter). (Scheme 9) See «RIDE HEIGHT SPECIFICATIONS ("V" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
"W" Body
- Lift front bumper 1.5" (38 mm) and let settle. Push front bumper down 1.5" (38 mm) and allow vehicle to rise and settle. Measure dimension "Z" between center of rear bushing bolt and lowest point of ball joint. (Scheme 10) Measure dimension "A" from center of front wheel to locate point to measure dimension "J". Measure dimension "J" between lower rocker panel to floor. (Scheme 3) See «RIDE HEIGHT SPECIFICATIONS ("W" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. If ride height is not within specification, replace damaged or worn suspension parts.
- Lift rear bumper 1.5" (38 mm) and let settle. Push rear bumper down 1.5" (38 mm) and allow vehicle to rise and settle. Measure dimension "D" from a point 1.18" (30 mm) from outboard of rear hose bracket bolt centerline to trailing arm to knuckle attachment bolt centerline. (Scheme 3)and (Scheme 10). Measure dimension "B" to locate point to measure dimension "K". Measure dimension "K" between from bottom of rocker panel to floor. (Scheme 3) See «RIDE HEIGHT SPECIFICATIONS ("W" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. If ride height is not within specification, repair or replace damaged or worn suspension parts.
"Y" Body (Front)
Note. When taking measurements, the real time damping system must be operative during procedure. If ride height adjustment is necessary, opposite trim height will be affected. Recheck vehicles ride height after each adjustment.
- Lift front bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push front bumper down 1.5" (38 mm) and let settle. Repeat 2 more times. Measure from center of front axle to lower edge of rocker panel (dimension "A") to locate dimension "J" measuring point. Measure dimension "J" from bottom of rocker panel to floor. (Scheme 11) See «RIDE HEIGHT SPECIFICATIONS ("Y" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. If front ride height is not within specification, go to step 3.
- Using Trim Height Measurement Gauge (J42854), measure left and right side dimension "Z" between lowest point of ball joint and center of lower control arm mounting bolt. (Scheme 11) See «RIDE HEIGHT SPECIFICATIONS ("Y" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. If ride height is not within specification, go to next step.
- If ride height adjustment is necessary, Trim Height Adjustment Tool (J42743) must be used to prevent damage to rubber sheer pad on end of adjuster bolt. (Scheme 12) Adjust dimension "Z" by turning the spring adjuster bolt. One complete turn of adjuster bolt equals about 0.08" (2 mm). Remove trim height adjustment tool. Ensure maximum difference between left and right spring adjuster bolt gaps does not exceed 0.196" (5 mm). Recheck ride height. Measure and adjust front spring adjuster bolt gaps. Bolt gaps should be between 0.078-0.944 (2-24 mm). (Scheme 13)
"Y" Body (Rear)
Note. When taking measurements, the real time damping system must be operative during procedure. If ride height adjustment is necessary, the opposite trim height will be affected. Recheck vehicles ride height after each adjustment.
- Lift rear bumper 1.5" (38 mm) and let settle. Repeat 2 more times. Push rear bumper down 1.5" (38 mm) and let settle. Repeat 2 more times. Measure from center of rear axle to lower edge of rocker panel (dimension "B") to locate dimension "K" measuring point. Measure dimension "K" from bottom of rocker panel to floor. (Scheme 11) See «RIDE HEIGHT SPECIFICATIONS ("Y" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. If rear ride height is not within specification, go to step 3.
- Using Trim Height Measurement Gauge (J42854), measure left and right side dimension "D" between lowest point of ball joint and center of lower control arm mounting bolt. (Scheme 11) See «RIDE HEIGHT SPECIFICATIONS ("Y" BODY)»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. If ride height is not within specification, go to next step.
- If ride height adjustment is necessary, adjust dimension "D" by removing spring bolt retainers and turning the spring adjuster bolt. One complete turn of adjuster bolt equals about 0.08" (2 mm). Ensure maximum difference between rear spring stud height does not exceed 0.196" (5 mm). (Scheme 14) Recheck ride height. Measure and adjust front spring adjuster bolt gaps. Rear spring stud height should be between 0.866-1.811 (22-46 mm). Install retainers to bolts.
RIDE HEIGHT SPECIFICATIONS
Note. Corvette ride height specification is not available from manufacturer.
On "C", "G", "H", and "J" body, maximum variation between side-to-side and front-to-rear should not exceed .75" (19 mm). On "N" body, maximum variation between side-to-side should not exceed 0.24" (6 mm). On all other models, maximum variation between side-to-side and front-to-rear should not exceed .47" (12 mm).
| Application | In. (mm) | ||
|---|---|---|---|
| Dimension "A" | |||
| "C" & "G" Body (1) | 23.5 (597) | ||
| Seville | 23.62 (600) | ||
| Dimension "B" | |||
| "C" & "G" Body | 23.13 (588) | ||
| Seville | 23.22 (590) | ||
| Dimension "J" | |||
| "C" Body | 6.44 To 7.25 (164 To 184) | ||
| "G" Body | 6.69 To 7.5 (170 To 190) | ||
| Seville | |||
| Standard Suspension (KS) | 7.05 (179) | ||
| Touring Suspension (KY) | 6.65 (169) | ||
| Dimension "K" | |||
| "C" Body | 8.38 To 9.19 (213 To 233) | ||
| "G" Body | 8.63 To 9.41 (219 To 239) | ||
| Seville | |||
| Standard Suspension (KS) | 9.02 (229) | ||
| Touring Suspension (KY) | 8.58 (218) | ||
| Dimension "Z" | |||
| "C" & "G" Bodies | 1.19 To 2.0 (30 To 50) | ||
| Seville | |||
| Standard Suspension (KS) | 1.57 (39.88) | ||
| Touring Suspension (KY) | 1.18 (29.97) | ||
| Dimension "D" | |||
| "C" & "G" Bodies | 3.0 To 3.75 (79 To 96) | ||
| Seville | |||
| Standard Suspension (KS) | 3.39 (86) | ||
| Touring Suspension (KY) | 2.99 (76) | ||
| (1) (Scheme 1) | |||
| (1) | (Scheme 1) |
RIDE HEIGHT SPECIFICATIONS ("C" & "G" BODIES & SEVILLE)
| Application | In. (mm) | ||
|---|---|---|---|
| Concours, DeVille & Eldorado (1) | |||
| Dimension "A" | 22.84 (580) | ||
| Dimension "B" | 22.17 (563) | ||
| Dimension "J" | |||
| Concours | 6.77 To 7.57 (172 To 192) | ||
| DeVille | 7.16 To 7.96 (182 To 202) | ||
| Eldorado | 8.26 To 9.06 (210 To 230) | ||
| Dimension "K" | |||
| Concours | 7.96 To 7.16 (162 To 182) | ||
| DeVille | 8.35 To 7.55 (172 To 192) | ||
| Eldorado | 8.03 To 8.83 (204 To 224) | ||
| Dimension "E" | |||
| Concours | 27.04 To 27.84 (687 To 707) | ||
| DeVille | 27.43 To 28.23 (697 To 717) | ||
| Eldorado | 27.75 To 28.55 (705 To 725) | ||
| Dimension "F" | |||
| Concours | 17.79 To 18.59 (452 To 472) | ||
| DeVille | 20.98 To 21.78 (533 To 553) | ||
| Eldorado | 27.51 To 28.31 (699 To 719) | ||
| Dimension "Z" | |||
| Concours | 1.25 To 2.05 (32 to 52) | ||
| DeVille | 1.61 To 2.41 (41 To 61) | ||
| Eldorado | 1.57 To 2.37 (40 To 60) | ||
| Dimension "D" | |||
| Concours | 0.7 To 1.5 (28 To 38) | ||
| DeVille | 1.06 To 1.86 (27 To 47) | ||
| Eldorado | 0.74 To 1.54 (19 To 39) | ||
| (1) (Scheme 2) | |||
| (1) | (Scheme 2) |
RIDE HEIGHT SPECIFICATIONS ("E" & "K" BODIES - EXCEPT SEVILLE)
| Application | In. (mm) | ||
|---|---|---|---|
| 1998 Camaro & Firebird (1) | |||
| Dimension "A" | 16.5 (420) | ||
| Dimension "B" | 14.4 (367) | ||
| Dimension "J" | 7.6 To 8.4 (194 To 214) | ||
| Dimension "K" | 8.0 To 8.8 (204 To 212) | ||
| Dimension "D" | 4.2 To 5.0 (108 To 128) | ||
| Dimension "Z" | |||
| With 235-55 Tires | 0.8 To 1.6 (20 To 40) | ||
| With 245-50 Tires | 1.1 To 1.9 (27 To 47) | ||
| (1) (Scheme 4) | |||
| (1) | (Scheme 4) |
RIDE HEIGHT SPECIFICATIONS (1998 "F" BODY)
| Application | In. (mm) | ||
|---|---|---|---|
| 1999 Camaro & Firebird (1) | |||
| Dimension "1" (Side Rocker Panel) | 8.0 (203) | ||
| Dimension "2" (Side Rocker Panel) | 8.2 (208) | ||
| Dimension "3" (Front Fascia) | |||
| Camaro | 17.0 To 17.8 (432 To 452) | ||
| Firebird Except Trans Am With 235/55 Tires | 13.0 To 13.8 (330 To 351) | ||
| Trans Am With 235/55 Tires | 15.9 To 16.7 (404 To 424) | ||
| Dimension "4" (Rear Fascia) | |||
| Camaro | 14.0 To 14.8 (356 To 376) | ||
| Firebird | 14.3 To 15.1 (363 To 384) | ||
| (1) (Scheme 5) | |||
| (1) | (Scheme 5) |
RIDE HEIGHT SPECIFICATIONS (1999 "F" BODY)
| Application | In. (mm) | |
|---|---|---|
| Bonneville, Eighty Eight, LeSabre, LSS & Regency (1) | ||
| Dimension "A" | 23.5 (597) | |
| Dimension "B" | 23.5 (597) | |
| Dimension "J" | 9.0 To 9.8 (229 To 249) | |
| Dimension "K" | 9.3 To 10.1 (236 To 256) | |
| Dimension "D" | 2.69 To 3.44 (68 To 88) | |
| Dimension "Z" | 1.94 To 2.75 (50 To 70) | |
| (1) (Scheme 6)and (Scheme 7). | ||
| (1) | (Scheme 6)and (Scheme 7). |
RIDE HEIGHT SPECIFICATIONS ("H" BODY)
| Application | In. (mm) | |||
|---|---|---|---|---|
| 1998 Cavalier & Sunfire (1) | ||||
| Dimension "A" | ||||
| Cavalier | 31.5 (800) | |||
| Sunfire | 32.16 (817) | |||
| Dimension "B" | 22.05 (560) | |||
| Dimension "J" | 8.77 To 957 (223 To 243) | |||
| Dimension "K" | 9.05 To 9.85 (230 To 250) | |||
| Dimension "Z" | ||||
| With 14" Tires | 0.07 To 0.87 (2 To 22) | |||
| With 15" Tires | 0.15 To 0.65 (-4 To 16) | |||
| With 16" Tires | 0.24 To 0.56 (-6 To 14) | |||
| 1999 Cavalier & Sunfire | ||||
| Dimensions "A" & "B" | (2) | |||
| Dimension "J" | 8.77 To 9.57 (223 To 243) | |||
| Dimension "K" | ||||
| Except Convertible | 9.04 To 9.84 (230 To 250) | |||
| Convertible | 9.24 To 10.04 (235 To 255) | |||
| Dimension "Z" | ||||
| With 14" Tires | 0.24 To 0.56 (-6 To 14) | |||
| With 15" Tires | ||||
| Cavalier 2.2L 4-Door (3) | 0.4 To 0.4 (-10 To 10) | |||
| Cavalier 2.4L 2-Door (4) , Sunfire 2.2L 4-Door (3) & 2.4L 2-Door (4) | 0.32 To 0.48 (-8 To 18) | |||
| Cavalier 2.4L 4-Door (5) , Sunfire 2.4L 2 & 4-Door (5) | 0.35 To 0.45 (-9 To 11) | |||
| Convertible 2.2L (5) | 0.2 To 0.6 (-5 To 15) | |||
| Convertible 2.4L (5) | 0.12 To 0.68 (-3 To 17) | |||
| (1) (Scheme 3) (2) Information is not available for 1999. (3) With active suspension. (4) With ride handling suspension. (5) With soft ride suspension. | ||||
| (1) | (Scheme 3) |
| (2) | Information is not available for 1999. |
| (3) | With active suspension. |
| (4) | With ride handling suspension. |
| (5) | With soft ride suspension. |
RIDE HEIGHT SPECIFICATIONS ("J" BODY)
| Application | In. (mm) | |
|---|---|---|
| Metro & Firefly (Canadian) (1) | ||
| Dimension "A" | 17.75 (450) | |
| Dimension "B" | 17.75 (450) | |
| Dimension "J" | 8.45 To 9.25 (215 To 235) | |
| Dimension "K" | 7.85 To 8.65 (200 To 220) | |
| Dimension "Z" | 1.35 To 2.10 (35 To 55) | |
| (1) (Scheme 6) | ||
| (1) | (Scheme 6) |
RIDE HEIGHT SPECIFICATIONS (METRO & FIREFLY (CANADIAN))
| Application | In. (mm) | |||
|---|---|---|---|---|
| 1998 Achieva, Grand Am & Skylark | ||||
| Dimension "A" | 31.5 (800) | |||
| Dimension "B" | 21.4 (560) | |||
| Dimension "J" | 8.99 To 9.75 (228 To 248) | |||
| Dimension "K" | 9.19 To 9.95 (233 To 253) | |||
| Dimension "D" | (1) | |||
| Dimension "Z" | ||||
| 14" Wheels | ||||
| Achieva, Grand Am & Skylark | 0.19 To 0.94 (4.83 To 23.88) | |||
| 15" Wheels | ||||
| Achieva | .063 To .69 (-1.6 To 17.53) | |||
| Grand Am & Skylark | 0.03 To 0.72 (-3.56 To 18.26 | |||
| 16" Wheels | ||||
| Achieva & Grand Am | 0.14 To 0.61 (-3.56 To 15.5) | |||
| Skylark | 0.09 To 0.66 (-2.29 To 16.8) | |||
| 1998-99 Cutlass & Malibu, 1999 Alero & Grand Am | ||||
| Dimension "A" | (1) | |||
| Dimension "B" | (1) | |||
| Dimension "J" | 8.96 To 971 (227 To 247) | |||
| Dimension "K" | 9.23 To 9.99 (234 TO 254) | |||
| Dimension "D" | ||||
| 15" Wheels (Except Grand Am 4-Door) | 4.47 To 5.22 (113 To 133) | |||
| 15" Wheels Grand Am 4-Door | 4.38 To 5.13 (110 To 130) | |||
| 16" Wheels | 4.40 To 5.15 (111 To 131) | |||
| Dimension "Z" | ||||
| 15" Wheels (Except Grand Am 4-Door) | 0.38 To 0.38 (-10 To 10) | |||
| 15" Wheels Grand Am 4-Door | 0.15 To 0.61 (-16 To 4) | |||
| 16" Wheels | 0.18 To 0.58 (-15 To 5) | |||
| (1) Information is not available. (Scheme 3)for approximate locations. | ||||
| (1) | Information is not available. (Scheme 3)for approximate locations. |
RIGHT HEIGHT SPECIFICATIONS ("N" BODY)
| Application (2) | In. (mm) | |
|---|---|---|
| Dimension "Z" | ||
| With P175/64R14 Tires | 6.88 To 7.68 (175 To 195) | |
| With P185/64R14 Tires | 7.08 To 7.88 (180 To 200) | |
| Dimension "D" | ||
| With P175/64R14 Tires | 9.25 To 10.05 (235 To 255) | |
| With P185/64R14 Tires | 9.44 To 10.24 (240 To 260) | |
| (1) 1998 specifications are not available. (2) (Scheme 8) | ||
| (1) | 1998 specifications are not available |
| (2) | (Scheme 8) |
RIDE HEIGHT SPECIFICATIONS (1999 PRIZM (1) )
| Application | In. (mm) | |
|---|---|---|
| Catera (1) | ||
| Dimension "P" | 27.3 (693) | |
| Dimension "J" | 6.9 (175) | |
| Dimension "K" | 6.5 (165) | |
| Dimension "R" | 27.3 (693) | |
| (1) (Scheme 9) | ||
| (1) | (Scheme 9) |
RIDE HEIGHT SPECIFICATIONS ("V" BODY)
| Application (1) | In. (mm) | ||
|---|---|---|---|
| 1998 Lumina & Monte Carlo | |||
| Dimension "A" | 23.8 (605) | ||
| Dimension "B" | 20.7 (526) | ||
| Dimension "J" | 9.6 To 10.4 (244 To 264) | ||
| Dimension "K" | 9.8 To 10.06 (249 TO 269) | ||
| Dimension "Z" | |||
| Lumina & Monte Carlo (2) , 205/70R15 Tires; Lumina Police & Taxi (3) , 215/65R15 Tires | 2.56 To 3.36 (65 To 85) | ||
| Lumina LS & Police (2) , 205/70R15 Tires | 2.6 To 3.4 (66 To 86) | ||
| Lumina LS (3) , 225/60R16 | 2.36 To 3.16 (60 To 80) | ||
| Lumina , Lumina LS, (2) , 225/60R16 Tires; Monte Carlo Z34, 225/60R16 Tires & Monte Carlo LS 255/60R16 Tires, (3) | 2.32 To 3.12 (59 To 79) | ||
| Dimension "D" | |||
| Lumina & Monte Carlo (2) , 205/70R15 Tires; Lumina Police & Taxi (3) , 215/65R15 Tires | 10.3 To 11.1 (262 To 282) | ||
| Lumina LS & Police (2) , 205/70R15 Tires; Lumina LS (3) , 225/60R16 | 10.35 To 11.15 (263 To 283) | ||
| Lumina , Lumina LS (2) , 225/60R16 Tires | 10.12 To 10.92 To (257 To 277) | ||
| Monte Carlo Z34, 225/60R16 Tires & Monte Carlo LS 255/60R16 Tires, (3) | 10.09 To 10.89 (256 To 276) | ||
| 1998-99 Century & Regal; 1999 Lumina & Monte Carlo | |||
| Dimension "A" | 23.8 (605) | ||
| Dimension "B" | 20.7 (526) | ||
| Dimension "J" & "K" | 8.00 To 8.80 (203 To 223) 8.00 To 8.80 (203 To 223) | ||
| Dimension "Z" | |||
| Century, Lumina, Monte Carlo & Regal With 225/60R16 Tires | 1.49 To 2.29 (38 To 58) | ||
| Lumina & Monte Carlo With 225/70R15 Tires | 1.73 To 2.53 (45 To 65) | ||
| Dimension "D" | |||
| Century, Lumina, Monte Carlo & Regal With 225/60R16 Tires | 9.64 To 10.44 (245 To 265) | ||
| Lumina & Monte Carlo With 225/70R15 Tires | 9.88 To 10.68 (251 To 271) | ||
| Intrigue | |||
| Dimension "A" | 23.8 (605) | ||
| Dimension "B" | 20.7 (526) | ||
| Dimension "J" | |||
| 1998 | 8.00 To 8.80 (203 To 223) | ||
| 1999 | 8.18 To 8.98 (208 To 228) | ||
| Dimension "K" | |||
| 1998 | 8.00 To 8.80 (203 To 223) | ||
| 1999 | 8.38 To 9.18 (213 To 233) | ||
| Dimension "Z" | |||
| 1998 With Soft Ride Suspension | 1.68 To 2.48 (43 To 63) | ||
| 1998 With Firm Ride Suspension | 1.43 To 2.23 (36.3 To 56.3) | ||
| 1999 | 1.57 To 2.37 (40 To 60) | ||
| Dimension "D" | |||
| 1998 With Soft Ride Suspension | 9.94 To 10.74 (252.7 To 277.7) | ||
| 1998 With Form Ride Suspension | 9.73 To 10.53 (247.4 To 267.4) | ||
| 1999 | 10.15 To 10.95 (258 To 278) | ||
| (1) (Scheme 3)and (Scheme 10). (2) With soft ride suspension. (3) With firm ride suspension. | |||
| (1) | (Scheme 3)and (Scheme 10). |
| (2) | With soft ride suspension. |
| (3) | With firm ride suspension. |
RIDE HEIGHT SPECIFICATIONS ("W" BODY)
| Application | In. (mm) | |
|---|---|---|
| Corvette (1) | ||
| Dimension "A" | 35 (889) | |
| Dimension "B" | 31 (787) | |
| Dimension "J" | 5.73 To 6.23 (146 To 158 | |
| Dimension "K" | 5.93 To 6.43 (151 To 163) | |
| Dimension "D" | 4.0 To 4.5 (102 To 114) | |
| Dimension "Z" | 1.48 To 1.98 (38 To 50) | |
| (1) (Scheme 11) | ||
| (1) | (Scheme 11) |
RIDE HEIGHT SPECIFICATIONS ("Y" BODY)
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
FWD Vehicles
When supporting vehicle using floor jack, place support at suspension lift points or frame lift points. Floor jacks may be placed under front crossmember on most models. (Scheme 15)- (Scheme 23).
RWD Vehicles
Floor jack may be used under rear axle or front suspension lower control arms. Observe the following precautions
- DO NOT use jack on any part of underbody.
- DO NOT raise entire vehicle at side rail with jack midway between front and rear wheels, or permanent body damage may result.
- DO NOT allow lifting plate fingers to contact axle cover plate when lifting at rear axle housing.
- If vehicle is equipped with a stabilizer bar, DO NOT lift at rear axle housing. (Scheme 15)- (Scheme 23).
BUMPER JACK
Bumper jack, if supplied as original equipment with vehicle, should only be used to change a flat tire. If vehicle is not supplied with a bumper jack, DO NOT lift vehicle by the bumper at any time.
AXLE CONTACT HOIST
Note. Always follow hoist manufacturer's instructions. DO NOT allow hoist or adapters to contact suspension, exhaust or steering components. Frame contact must be made. Use adapters if necessary.
Hoist should contact lower control arms, or front crossmember and rear axle.
FRAME CONTACT HOIST
Hoist adapters must contact vehicle in specified areas. (Scheme 15)- (Scheme 23). Adapters must be positioned to distribute load and support vehicle in a stable manner. DO NOT allow lift pads to contact body panels or exhaust system components.
| WARNING | If removing rear axle, fuel tank, spare tire or liftgate using single-post hoist, anchor vehicle to hoist. Place jack stands under vehicle, or add weight on rear end of vehicle to prevent tipping when center of gravity changes. |
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
ORDER OF ALIGNMENT
Note. To ensure accurate alignment, align wheels in the following order: rear camber, rear toe-in, front caster, front camber and front toe-in.
"H" Body
Loosen nuts on 2 bolts securing strut to steering knuckle. Install Camber Adjuster (J-29862). (Scheme 24) Rotate bolt on camber adjuster until camber is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten nuts to specification. See TORQUE SPECIFICATIONS table.
Loosen bolts securing front and rear ends of lower control arm to frame. (Scheme 25) Move lower control arm inward or outward as necessary to adjust camber. Tighten bolts to specification. See TORQUE SPECIFICATIONS table.
- Raise and support vehicle. Remove rear wheel. Remove strut. Put strut in a vise. File the upper bolt hole at lower end of strut to make it oblong. (Scheme 26)
- Install strut, but DO NOT fully tighten strut mounting bolts at steering knuckle. Lower vehicle. Adjust camber to specification. See «WHEEL ALIGNMENT SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
"Y" Body
Loosen lower control arm cam bolt nut. Rotate cam bolt until camber is within specification. (Scheme 27) See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten bolts to specification. See TORQUE SPECIFICATIONS table.
All Others
Rear camber is not adjustable. If rear camber is not as specified, repair or replace worn or damaged components.
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Adjust left and right sides separately. Loosen inner adjustment link cam nut. (Scheme 28) Using an 18-mm wrench or socket, rotate cam bolt until toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten cam nut to specification. See TORQUE SPECIFICATIONS table.
Loosen lock nut on tie rod. (Scheme 24) Rotate inner tie rod as necessary until full toe-out position is obtained, then rotate inner tie rod until rear toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten lock nut to specification. See TORQUE SPECIFICATIONS table.
"E" & "K" Body (Except Seville)
Loosen toe link bolt. (Scheme 29) Move wheel inward or outward as necessary until toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten bolts to specification. See TORQUE SPECIFICATIONS table.
Metro & Firefly (Canadian)
Loosen right and left body side control rod cam bolts. Rotate cam bolt until toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten lock nut to specification. See TORQUE SPECIFICATIONS table.
Loosen both tie rod end locknuts. Rotate threaded sleeve until toe-in as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten lock nut to specification. See TORQUE SPECIFICATIONS table.
Loosen tie rod adjuster clamps. Rotate threaded sleeve until rear toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten adjuster clamps to specification. See TORQUE SPECIFICATIONS table.
"W" Body (Lumina & Monte Carlo)
- Adjust left and right sides separately. Lubricate threads of Turnbuckle Adjuster (J-38118). On Lumina and Monte Carlo, install turnbuckle adjuster in rear rod access hole closest to center of rear suspension support and other end to rear suspension support. On Cutlass Supreme, install turnbuckle adjuster between hole in rear suspension rod and hole in jackstand pad. (Scheme 30) On all models, hand-tighten turnbuckle adjuster in direction of adjustment.
- Loosen nut on bolt securing rear suspension rod to crossmember at least 4 turns. Rotate turnbuckle adjuster as necessary until rear toe-in is as specified. See «WHEEL ALIGNMENT SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Tighten rear suspension rod nut at crossmember to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
"W" Body (Century, Grand Prix & Regal)
Adjust left and right sides separately. Loosen nuts at rear wheel spindle rod. Adjust toe to proper setting. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten rear wheel spindle rod nuts to specification. See TORQUE SPECIFICATIONS table.
Loosen lock nut on rear tie rod. Rotate tie rod as necessary until rear toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten lock nut to specification. (Scheme 31) See TORQUE SPECIFICATIONS table.
Rear toe-in is not adjustable. If rear toe-in is not as specified, repair or replace worn or damaged components.
Scheme 28
Scheme 29
Scheme 30
Scheme 31
"C", "G" & "H" Bodies & Seville
- With vehicle on ground (suspension loaded), remove nuts securing strut upper mount to body at each strut tower. (Scheme 32) Raise front of vehicle until strut studs have cleared holes.
- Drill 13/32" holes at each strut stud hole, then file excess material between holes to create an elongated slot. Lower vehicle to install strut into tower. Adjust caster to specification by moving top of strut forward or rearward. See «WHEEL ALIGNMENT SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
Support vehicle by its wheels (suspension loaded). Remove nuts and washers from front strut mounting tower. Move top of strut forward and/or rearward as necessary to adjust caster. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten nuts to specification. See TORQUE SPECIFICATIONS table.
"F" Body
Loosen nuts on bolts securing lower control arm to crossmember. Attach Turnbuckle Adjuster (J-38658) to crossmember and lower control arm. (Scheme 33) Rotate turnbuckle clockwise to increase caster or counterclockwise to decrease caster. Adjust caster to specification. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten nuts to specification. See TORQUE SPECIFICATIONS table. Remove adjuster.
Loosen lower control arm cam bolt nuts. Rotate cam bolts to required camber specification. (Scheme 34) See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten nuts to specification. See TORQUE SPECIFICATIONS table. If unable to achieve specification for caster, washers at upper control arm can be added or subtracted to obtain specification. (Scheme 35)
Caster is not adjustable. If caster is not as specified, check for worn or damaged suspension or body parts. Repair or replace as necessary.
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Loosen nuts on 2 bolts securing strut to steering knuckle. (Scheme 36) Install Camber Adjuster (J-39601). Rotate bolt on camber adjuster until camber is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten nuts to specification. See TORQUE SPECIFICATIONS table.
Loosen nuts on bolts securing strut to steering knuckle. Tighten or loosen camber adjusting bolt as necessary to adjust camber to specification. See WHEEL ALIGNMENT SPECIFICATIONS table. While holding wheel in position, tighten nuts to specification. See TORQUE SPECIFICATIONS table.
Loosen nuts on bolts securing lower control arm to crossmember. Attach Adjuster (J-38658) to crossmember and lower control arm. (Scheme 33) Rotate turnbuckle clockwise to increase camber or counterclockwise to decrease camber. Adjust camber to specification. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten nuts to specification. See TORQUE SPECIFICATIONS table. Remove adjuster.
"J" & "N" body
- Remove nuts and bolts securing strut to steering knuckle. (Scheme 37) If lower bolt hole has been elongated, go to step 3. (Scheme 38) If lower bolt hole has NOT been elongated, go to next step.
- Disengage strut from steering knuckle. Reposition strut at lower control arm. Elongate lower bolt hole. Paint exposed metal with rust-preventive paint or primer.
- Install bolts and nuts, but DO NOT tighten nuts. Move top of wheel inward or outward as necessary until camber is as specified. See «WHEEL ALIGNMENT SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
Remove brake caliper and suspend out of way. Do not disconnect hydraulic line. Remove strut to steering knuckle bolts. Replace with NEW bolts and tighten to 15 ft. lbs. (20 N.m). Clean brake caliper mounting bolt threads to remove any residual locking compound. Apply 272 Threadlock or equivalent to NEW caliper mounting bolts. Install and tighten to specification. Reposition strut to adjust camber to specified range. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten bolts to specification. See TORQUE SPECIFICATIONS table.
"W" Body (Except Century, Grand Prix & Regal)
- Loosen 3 strut cover attaching nuts. Remove strut cover. Lift front of vehicle enough to allow strut attaching studs to clear mounting holes. Cover top of strut to keep metal shavings from damaging strut. Using Template (J-36892) as a guide, file the 3 holes as necessary to allow for camber adjustment. (Scheme 39)
- Paint exposed surfaces with rust-preventive paint or primer. Lower front of vehicle while aligning studs into holes. Install, but DO NOT tighten, 3 strut cover attaching nuts. Set camber to specification. Tighten strut cover attaching nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Raise and support vehicle. Remove rear wheel. Remove strut. Put strut in a vise. File lower end of strut bolt hole to make lower bolt hole oblong. (Scheme 38)
- Install strut, but DO NOT fully tighten strut mounting bolts at steering knuckle. Lower vehicle. Adjust camber to specification. See «WHEEL ALIGNMENT SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- Loosen lower control arm cam bolt nuts. Rotate cam bolts to required camber specification. (Scheme 34) See «WHEEL ALIGNMENT SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table. Tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) table.
- If unable to set camber to specification using cam bolts, upper control arm shims can be added or subtracted. (Scheme 35) Ensure shims are of equal thickness to avoid caster change. If shims are removed to obtain additional negative camber, ensure there is proper clearance between upper control arm and shock absorber with suspension in full rebound.
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Except 1998 Achieva, Grand Am , Skylark, & 1998-99 "V" Body
Center steering wheel and lock in place. Loosen tie rod end lock nut. Loosen clamp securing dust boot to inner tie rod. Rotate inner tie rod until toe-in is as specified. (Scheme 40) See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten lock nut to specification. See TORQUE SPECIFICATIONS table. Ensure steering gear dust boot is straight after adjustment. Tighten dust boot clamp.
1998 Achieva, Grand Am & Skylark
Center steering wheel and keep it centered throughout procedure. Loosen clamp bolts. (Scheme 41) Rotate adjuster (between inner and outer tie rods) until toe-in is as specified. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten clamp bolts to specification. See TORQUE SPECIFICATIONS table.
1998-99 "V" Body
Loosen tie rod adjuster clamps. Rotate threaded sleeve toe position is obtained. See WHEEL ALIGNMENT SPECIFICATIONS table. Tighten adjuster clamps to specification. See TORQUE SPECIFICATIONS table.
Scheme 40
Scheme 41
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| "C" Body | |||
| Adjustment Link Cam Nut | 55 (75) | ||
| Strut-To-Steering Knuckle Nut | 137 (185) | ||
| Strut-To-Strut Body Nut | 35 (47) | ||
| Tie Rod End Lock Nut (Front & Rear) | 47 (64) | ||
| "E" & "K" Body (Except Seville) | |||
| Rear Toe Link Bolt | 66 (90) | ||
| Strut-To-Steering Knuckle Nut | 140 (184) | ||
| Strut-To-Strut Tower Nut | 18 (24) | ||
| Tie Rod End Lock Nut | 46 (63) | ||
| "F" Body | |||
| Lower Control Arm-To-Crossmember Nut | 74 (100) | ||
| Tie Rod End Lock Nut | 35 (47) | ||
| "G" Body & Seville | |||
| Rear Inner Adjustment Link Cam Nut | |||
| "G" Body | 55 (75) | ||
| Seville | 74 (100) | ||
| Strut-To-Steering Knuckle Nut | |||
| G" Body | 137 (185) | ||
| 1998 Seville | 125 (170) | ||
| 1999 Seville | 166 (225) | ||
| Strut-To-Strut Tower Nut | |||
| Except 1999 Seville | 35 (47) | ||
| 1999 Seville | 30 (40) | ||
| Tie Rod End Lock Nut | 47 (64) | ||
| "H" Body | |||
| Strut-To-Steering Knuckle Nut | 140 (190) | ||
| Strut-To-Strut Body Nut | 18 (24) | ||
| Tie Rod End Lock Nut (Front & Rear) | 47 (64) | ||
| "J" Body | |||
| Strut-To-Steering Knuckle Nut | 133 (180) | ||
| Tie Rod End Lock Nut | 55 (75) | ||
| Metro & Firefly (Canadian) | |||
| Rear Cam Bolt Nut | 59 (80) | ||
| Tie Rod End Lock Nut | 33 (45) | ||
| "N" Body | |||
| Strut-To-Steering Knuckle Nut | 133 (180) | ||
| Tie Rod End Clamp Bolt | |||
| 1998 Achieva, Grand Am & Skylark | 31 (42) | ||
| Tie Rod End Lock Nut | |||
| 1998 Cutlass & Malibu | (3) | ||
| Except 1998 Cutlass & Malibu | 50 (68) | ||
| Prizm | |||
| Tie Rod End Lock Nut | 41 (56) | ||
| "V" Body | |||
| Brake Caliper Mounting Bolts | (1) 70 (95) | ||
| Strut-To-Steering Knuckle Bolts | (2) 66 (90) | ||
| Tie Rod Adjuster Clamp Bolts | 11 (15) | ||
| Wheel Lug Nuts | 80 (109) | ||
| "W" Body | |||
| Century, Grand Prix & Regal | |||
| Rear Wheel Spindle Rod | 37 (50) | ||
| Tie Rod End Lock Nut | 50 (68) | ||
| Strut-To-Knuckle Bolts | 90 (122) | ||
| Intrigue, Lumina & Monte Carlo | |||
| Rear Rod-To-Crossmember Nuts | 111 (150) | ||
| Front Strut Cover Plate Nuts | 24 (33) | ||
| Strut-To-Knuckle Nuts | 112 (83) | ||
| Tie Rod End Lock Nuts | 46 (62) | ||
| "Y" Body | |||
| Front Lower Control Arm Cam Bolt Nuts | 125 (170) | ||
| Front Upper Control Arm Bolts | 42 (57) | ||
| Rear Lower Control Arm | |||
| Front Cam Bolt Nuts | 107 (145) | ||
| Rear Cam Bolt Nuts | 70 (95) | ||
| Front Tie Rod End Lock Nuts | 50 (68) | ||
| Rear Tie Rod End Lock Nuts | 44 (60) | ||
| (1) Tighten an additional 37 degrees. (2) Tighten an additional 53 degrees. (3) Tighten to 89 INCH lbs. (10 N.m) plus an additional 210 degrees. | |||
| (1) | Tighten an additional 37 degrees. |
| (2) | Tighten an additional 53 degrees. |
| (3) | Tighten to 89 INCH lbs. (10 N.m) plus an additional 210 degrees. |
TORQUE SPECIFICATIONS
| Application | Preferred | Range | |||||
|---|---|---|---|---|---|---|---|
| "C" Body | |||||||
| Camber (1) | |||||||
| Front | 0.2 | 0.7 To 0.3 | |||||
| Rear | 0.3 | 0.8 To 0.2 | |||||
| Caster (1) | 6 | 5.5 To 6.5 | |||||
| Toe-In (1) | |||||||
| Front | 0.2 | 0.1 To 0.5 | |||||
| Rear | 0.2 | 0 To 0.4 | |||||
| Toe-In (2) | |||||||
| Front | 0.1 (2.5) | 0.05 To 0.25 (-1.3 To 6.4) | |||||
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5.1) | |||||
| "E" & "K" Body | |||||||
| Concours, DeVille & Eldorado | |||||||
| Camber (1) | |||||||
| Front | 0 | 0.5 To 0.5 | |||||
| Rear | 0 | 0.5 To 0.5 | |||||
| Caster (1) | 2.3 | 1.3 To 3.3 | |||||
| Toe-In (1) | |||||||
| Front | 0.2 | 0 To 0.4 | |||||
| Rear | 0.2 | 0 To 0.4 | |||||
| Toe-In (2) | |||||||
| Front | 0.1 (2.5) | 0 To 0.2 (0 To 5.0) | |||||
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5.0) | |||||
| Seville SLS & STS | |||||||
| Camber (1) | |||||||
| SLS | |||||||
| Front | 0.02 | 0.07 To 0.3 | |||||
| Rear | 0.03 | 0.08 To 0.2 | |||||
| STS | |||||||
| Front | 0.2 | 0.7 To 0.3 | |||||
| Rear | 0.6 | 1.1 To -0.1 | |||||
| Caster (1) | 6 | 5.5 To 6.5 | |||||
| Toe-In (1) | |||||||
| Front | 0.2 | 0 To 0.4 | |||||
| Rear | 0.2 | 0 To 0.4 | |||||
| Toe-In (2) | |||||||
| Front | 0.1 (2.5) | 0 To 0.2 (0 To 5) | |||||
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5) | |||||
| "F" Body | |||||||
| Camber (1) | |||||||
| Front | 0.4 | 0.1 To 0.9 | |||||
| Rear | 0 | 0.6 To 0.6 | |||||
| Caster (1) | 5.0 | 4.5 To 5.5 | |||||
| Toe-In (1) | |||||||
| Front | 0 | 0.1 To 0.1 | |||||
| Rear | 0 | 0.15 To 0.15 | |||||
| Toe-In (2) | |||||||
| Front | 0 | 0.2 To 0.2 (-2.5 To 2.5) | |||||
| Rear | 0 | 0.3 To 0.3 (-4.0 To 4.0) | |||||
| "G" Body | |||||||
| Camber (1) | |||||||
| Front | 0.2 | 0.7 To 0.3 | |||||
| Rear | 0.3 | 0.8 To 0.2 | |||||
| Caster (1) | 6 | 5.5 To 6.5 | |||||
| Toe-In (1) | |||||||
| Front | 0 | 0.2 To 0.2 | |||||
| Rear | 0.2 | 0 To 0.4 | |||||
| Toe-In (2) | |||||||
| Front | 0 (0) | 0.1 To 0.1 (-2.5 To 2.5) | |||||
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5.0) | |||||
| "H" Body | |||||||
| Camber (1) | |||||||
| Front | 0.2 | 0.3 To 0.7 | |||||
| Rear | 0.3 | 0.8 To 0.2 | |||||
| Caster (1) | 3.0 | 2.5 To 3.5 | |||||
| Toe-In (1) | |||||||
| Front | 0 | 0.2 To 0.2 | |||||
| Rear | 0.1 | 0.1 To 0.3 | |||||
| Toe-In (2) | |||||||
| Front | 0.1 (2.5) | 0.1 To 0.1 (-2.5 To 2.5) | |||||
| Rear | 0.05 (1.5) | 0.05 To 0.15 (-1.5 To 4.0) | |||||
| "J" Body | |||||||
| Camber (1) | |||||||
| Front | 0.2 | 1.2 To 0.8 | |||||
| Rear | 0.25 | 1.0 To 0.5 | |||||
| Caster (1) | 4.3 | 3.3 To 5.3 | |||||
| Toe-In (1) | |||||||
| Front | 0.1 | 0.15 To 0.35 | |||||
| Rear | 0.2 | 0.1 To 0.5 | |||||
| Toe-In (2) | |||||||
| Front | 0.05 (1.5) | 0.07 To 0.17 (-1.5 To 4) | |||||
| Rear | 0.1 (2.5) | 0.05 To 0.25 (-1.5 To 6.5) | |||||
| "N" Body | |||||||
| 1998 Achieva, Grand Am & Skylark | |||||||
| Camber (1) | |||||||
| Front | 0 | 1.0 To 1.0 | |||||
| Rear | 0.4 | 1.15 To 0.35 | |||||
| Caster (1) | 1.45 | 0.45 To 2.45 | |||||
| Toe-In (1) | |||||||
| Front | 0 | 0.25 To 0.25 | |||||
| Rear | 0.2 | 0.1 To 0.5 | |||||
| Toe-In (2) | |||||||
| Front | 0 (0) | 0.12 To 0.12 (-3.0 To 3.0) | |||||
| Rear | 0.1 (2.5) | 0.05 To 0.25 (-1.5 To 6.5) | |||||
| 1998-99 Malibu & Cutlass, & 1999 Alero & Grand Am | |||||||
| Camber (1) | |||||||
| Front | 0.2 | 1.2 To 0.8 | |||||
| Rear | 0.2 | 0.7 To 0.30 | |||||
| Caster (1) | 4.1 | 3.1 To 5.1 | |||||
| Toe-In (1) | |||||||
| Front | 0.1 | 0.15 To 0.35 | |||||
| Rear | 0.06 | 0.26 To 0.14 | |||||
| Toe-In (2) | |||||||
| Front | 0.05 (1.5) | 0.07 To 0.17 (-1.5 To 4.0) | |||||
| Rear | 0.03 (1) | 0.13 To 0.07 (-2.5 To 2.5) | |||||
| Metro & Firefly (Canadian) | |||||||
| Camber (1) | |||||||
| Front | 0.5 | 0.5 To 1.5 | |||||
| Rear | 0 | 1 To 1 | |||||
| Caster (1) | 3 | 2 To 4 | |||||
| Toe-In (1) | |||||||
| Front | 0.16 | 0 To 0.32 | |||||
| Rear | 0.45 | 0.3 To 0.6 | |||||
| Toe-In (2) | |||||||
| Front | 0.08 (2) | 0 To 0.16 (0 To 4) | |||||
| Rear | 0.23 (6) | 0.15 To 0.3 (4 To 7.5) | |||||
| Prizm | |||||||
| Camber (1) | |||||||
| Front | 0.18 | 0.93 To 0.57 | |||||
| Rear | 0.92 | 1.67 To -0.17 | |||||
| Caster (1) | 1.33 | 0.58 To 2.08 | |||||
| Toe-In (1) | |||||||
| Front | 0.1 | 0.1 To 0.3 | |||||
| Rear | 0.4 | 0.2 To 0.6 | |||||
| Toe-In (2) | |||||||
| Front | 0.05 (1.5) | 0.05 To 0.15 (-1.5 To 4) | |||||
| Rear | 0.25 (5) | 0.1 To 0.3 (2.5 To 7.5) | |||||
| "V" Body | |||||||
| Camber (1) | |||||||
| Front | 1.5 | 2.0 To -1.0 | |||||
| Rear | 1.9 | 2.3 To -1.5 | |||||
| Caster (1) | 4.4 | 3.9 To 4.9 | |||||
| Toe-In (1) | |||||||
| Front | 0.1 | 0.06 To 0.26 | |||||
| Rear | 0.1 | 0.06 To 0.26 | |||||
| Toe-In (2) | |||||||
| Front | 0.05 (1.5) | 0.03 To 0.13 (-1.0 To 3.5) | |||||
| Rear | 0.05 (1.5) | 0.03 To 0.13 (-1.0 To 3.5) | |||||
| "W" Body | |||||||
| Lumina & Monte Carlo | |||||||
| With 15" Wheels | |||||||
| Camber (1) | |||||||
| Front | 0.7 | 0.2 To 1.2 | |||||
| Rear | 0.35 | 0.85 To 0.15 | |||||
| Caster (1) | 1.8 | 1.3 To 2.3 | |||||
| Toe-In (1) | |||||||
| Front | 0 | 0.2 To 0.2 | |||||
| Rear | 0 | 0.3 To 0.3 | |||||
| Toe-In (2) | |||||||
| Front | 0 (0) | 0.1 To 0.1 (-2.5 To 2.5) | |||||
| Rear | 0 (0) | 0.15 To 0.15 (-3.8 To 3.8) | |||||
| With 16" Wheels | |||||||
| Camber (1) | |||||||
| Front | 0.7 | 0.2 To 1.2 | |||||
| Rear | 0.45 | /0.95 To 0.05 | |||||
| Caster (1) | 1.8 | 1.3 To 2.3 | |||||
| Toe-In (1) | |||||||
| Front | 0 | 0.2 To 0.2 | |||||
| Rear | 0 | 0.3 To 0.3 | |||||
| Toe-In (2) | |||||||
| Front | 0 (0) | 0.1 To 0.1 (-2.5 To 2.5) | |||||
| Rear | 0 (0) | 0.15 To 0.15 (-3.8 To 3.8) | |||||
| Intrigue | |||||||
| Camber (1) | |||||||
| Front | 0.91 | 1.41 To -0.41 | |||||
| Rear | 0.52 | 1.02 To -0.02 | |||||
| Caster (1) | 3.05 | 2.55 To 3.55 | |||||
| Toe-In (1) | |||||||
| Front | 0.1 | 0.1 To 0.3 | |||||
| Rear | 0.05 | 0.15 To 0.25 | |||||
| Toe-In (2) | |||||||
| Front | 0.05 (1.5) | 0.05 To 0.15 (-1.5 To 4) | |||||
| Rear | 0.2 (1.5) | 0.07 To 0.12 (-1.5 To 3) | |||||
| "Y" Body | |||||||
| Camber (1) | |||||||
| Front | 0.2 | 0.7 To 0.3 | |||||
| Rear | 0.18 | 0.68 To | |||||
| Caster (1) | 6.1 | 5.6 To 6.6 | |||||
| Toe-In (1) | |||||||
| Front | 0.08 | 0.12 To 0.28 | |||||
| Rear | 0.02 | 0.22 To 0.18 | |||||
| Toe-In (2) | |||||||
| Front | 0.04 (1) | 0.06 To 0.14 (-1.5 To 3.5) | |||||
| Rear | 0.01 (.5) | 0.11 To 0.09 (-3 To 2) | |||||
| (1) Measurement is in degrees. (2) Measurement is in inches (mm). | |||||||
| (1) | Measurement is in degrees. |
| (2) | Measurement is in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (EXCEPT CENTURY, GRAND PRIX & REGAL)
| Operation | Service Allowable | Service Preferred | |
|---|---|---|---|
| Front | |||
| Camber 15" and 16" Tires | 0.20 to 1.20 | 0.7 | |
| Caster | 1.30 to 2.30 | 1.8 | |
| Steering Angle | 3.50 to 3.50 | 0 | |
| Toe (Total) | 0.20 to 0.20 | 0 | |
| Rear | |||
| Camber 15" and 16" Tires | 0.65 to 0.35 | 0.15 | |
| Thrust Angle | 0.15 to 0.15 | 0 | |
| Toe (Total) | 0.20 to -0.40 | 0.1 | |
WHEEL ALIGNMENT SPECIFICATIONS (CENTURY & REGAL)
| Operation | Service Allowable | Service Preferred | |
|---|---|---|---|
| Front | |||
| Camber (Cross) | 1.40 to -0.40 | 0.90 | |
| Caster (Cross) | 2.50 to 3.50 | 3.00 | |
| Steering Angle | 3.50 to 3.50 | 0 | |
| Toe (Total) | 0.30 to -0.10 | 0.10 | |
| Rear | |||
| Camber (Cross) | 1.40 to -0.40 | 0.90 | |
| Thrust Angle | 0.15 to 0.15 | 0 | |
| Toe (Total) | 0.40 to 0.20 | 0 | |
WHEEL ALIGNMENT SPECIFICATIONS (GRAND PRIX)
